ENHANCING PATIENT INFORMATION SHARING THROUGH

SOCIAL NETWORKS

M. Poulymenopoulou, D. Papakonstantinou, F. Malamateniou and G. Vassilacopoulos

Department of Digital Systems, University of Piraeus, Karaoli & Dimitriou 80, Piraeus, Greece

Keywords: Social network, Personal health records, Access control services.

Abstract: Currently, there is an effort for empowering patient self-care and improving the traditional healthcare

delivery models by expanding the concept of healthcare though the provision of advanced online healthcare

services. Those services require increased level of information flow and collaboration among patients and

healthcare professionals. This collaboration and patient information sharing can be achieved by integrating

social networks functionality with personal health records, based on open standards. In fact, social

networking exists to facilitate communication and collaboration and make possible what was only recently

impractical in healthcare, such as trans-regional clinician collaboration through web-based broadcasting

systems, therefore integrating the information included into personal health records. Along these lines, this

paper presents a secure middleware that aims at enabling patient information sharing among patients and

healthcare professionals through social networks functionality and applications, giving particular emphasis

to a security architecture that enforces access control services for protecting the disclosure of patient private

information to unauthorized users.

1 INTRODUCTION

In healthcare the traditional “face-to-face”

healthcare delivery may not fully meet the new

requirements of “e-Patients”, who wish to sit at

home seeking healthcare consultancy or online help

instead of lining up hours just for a few minutes talk

with physicians in hospitals or clinics (Domingo,

2010); (Greene et al., 2011). However, the reality is

that few online healthcare services can be found.

Recently, the Health 2.0 movement aims at

promoting participatory healthcare by suggesting the

collaboration among patients, caregivers, medical

professionals and other healthcare stakeholders

through the use of Web 2.0 technologies like social

networks (SNs) (Domingo, 2010); (Gajanayake et

al., 2011); (Thompson et al., 2011).

The social-networking revolution is coming to

healthcare, at the same time that new Internet

technologies and software programs are making it

easier than ever for healthcare professionals to find

timely, personalized health information online and

for patients to self-manage their medical information

and share it with others (Domingo, 2010);

(Gajanayake et al., 2011). Moreover, several

healthcare social networks (HSNs) have emerged,

such as PatientsLikeMe, Inspire.com, MedHelp,

Sermo and Ozmosis. HSNs provide online technical

infrastructures for physicians to share clinical cases,

images, videos and medical knowledge and for

patients to promote disease awareness, and positive

and proactive behavior, in order to stay healthy

while living with a disease (Domingo, 2010);

(Greene et al., 2011).

Since communication is a critical weakness of

the healthcare delivery system, SNs could

potentially improve communication by establishing

permanent channels (network connections) among

multiple physicians and between physicians and

patients. Also SNs can make the health system more

available, responsive and personalized to the public

by providing access to eHealth services to both the

public and health professionals (Domingo, 2010);

(Thompson et al., 2011); (Williams, 2010). Most of

the eHealth services (e.g. diagnosis, self-treatment,

expert advice, second medical opinion) require the

availability of accurate and updated patient medical

information and therefore some HSNs support

quantified self-tracking by providing easy-to-use

data entry screens for condition, symptom, treatment

and other biological information.

378

Poulymenopoulou M., Papakonstantinou D., Malamateniou F. and Vassilacopoulos G..

ENHANCING PATIENT INFORMATION SHARING THROUGH SOCIAL NETWORKS.

DOI: 10.5220/0003772203780381

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2012), pages 378-381

ISBN: 978-989-8425-88-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

At the same time, there is an increasing interest

by patients on public web-based Personal Health

Records (PHRs) for coordinating their lifelong

health information and make appropriate parts of it

available to those who need it (Cushman et al.,

2010); (Shachak et al., 2010); (Sunyaev et al., 2010).

However, PHRs are mostly designed to meet the

needs of episodic clinical encounters between

patients and health care professionals, and around

the diagnosis and treatment of diseases (Greene et

al., 2011); (Shachak et al, 2010).

Sharing patient data existing on PHRs through

SNs can provide the required patient information to

healthcare professionals, administrators and other

using eHealth services. However, the issues of

patient information security and privacy are some of

the biggest concerns when exposing patient private

information to a social network. Many SNs allow

users to customize some privacy settings and some

online HSNs provide an opportunity to freely obtain

and disclose information about a health condition

without having to divulge one's identity. In addition,

most web-based PHRs like Microsoft Health Vault

and ICW LifeSensor, provide functionality for

filtering the medical data to be shared with others

(Gajanayake et al., 2011); (Sunyaev et al., 2010).

However, there are still open issues as concerns

PHRs and SNs privacy and security and therefore

patients and practitioners still worry about the

wrongful dissemination of medical information.

Nevertheless, currently there are no available

guidelines to help navigate these complex issues

(Cushman et al., 2010); (Thompson et al., 2011);

(Williams, 2010).

The focus of this paper is on the security aspects

of the middleware without compromising the

benefits of information sharing, thus increasing the

overall social value of SNs in healthcare. Hence, a

context-aware access control service is proposed that

extends PHR access control features and enables

sharing of patient data through SNs.

2 MOTIVATION

The basic motivation of this research stems from our

involvement in a recent project concerned with the

employment of a middleware-level solution to

enable patient medical information sharing from

PHRs to advanced eHealth services (online

diagnosis, expert advice, disease management) that

are provided through SNs using their functionality.

Among the requirements of this middleware was to

enable patients setting their access control sharing

preferences on their medical information existing on

PHRs. The security requirements of this middleware

motivated this work and provide the context for the

development of access control services for the

middleware based on a security architecture that

ensures authorized patient information sharing from

PHRs in the domain of SNs, according to specific

user context-based preferences.

To this end, according to the overall middleware

architecture a) advanced eHealth services are

provided using SN functionality (e.g. messaging

mechanisms), b) integrated patient information

(patients active medical problems, diagnosis,

treatment plans and latest medical tests results)

exists on PHR and controlled by patients, c) the

middleware provides functionality for retrieving

patient information from PHR, transforming this into

a standard format and sending it to requesting SN

users and d) the access control services of the

middleware enable setting and enforcing the users

access control policies for their medical information.

3 SECURITY ARCHITECTURE

According to the proposed cloud-based middleware

architecture, as presented in Figure 1, an application

server and an XML base are configured at cloud

servers. At the application server exist the

middleware services that encapsulate middleware

functionality, the web and cloud services used by the

access control services, the context-based access

control mechanism that takes context-based

authorization decisions for accessing (read access is

only allowed through the SN) patient medical data

existing on PHRs and the context manager that hosts

the ontology created to represent context

information. At the XML base are stored the user

access control policies. This architecture takes the

stance that the medical data of PHRs is retrieved in

the form of XML documents according to clinical

standards, as the Continuation of Care Document

(CCD) or the Continuation of Care Record (CCR).

As far as concerns the ontology, Ontology Web

Language (OWL) files have been created that enable

context information sharing in a semantic way and

also context reasoning. Additionally, Semantic Web

Rule Language (SWRL) rules have been written to

capture additional relationships among domain

classes (Beimel et al., 2011).

Context information involves a) user social

information, such as user profiles, relationships,

groups and activities on the SN (e.g. online/offline,

chatting), b) medical data information that includes

ENHANCING PATIENT INFORMATION SHARING THROUGH SOCIAL NETWORKS

379

data elements of PHRs as proposed by CCD/CCR

XML schemas and involves problems, medications,

alerts, procedures, results and other and c) temporal

information, such as time instances or time intervals.

In Figure 2 a small part of the ontology created

in OWL is shown. Context information of the

domain ontology is used to set contextual constraints

on user medical data (stored on PHRs) sharing

preferences. Hence, contextual constraints are

divided to a) user social based constraints that are

specified at user level, at user group level, at SN

relationship level (that links users), at user current

activity level (e.g. user participation on group online

chat), b) medical data based constraints that are

specified at the medical data element level and c)

temporal based constraints (e.g. time interval)

(Wrona et al., 2005).

Figure 1: The middleware architecture.

According to the security architecture, users set

through web service calls their context-aware

sharing preferences. Then, the access control

mechanism communicates with the context manager

to consult the ontology and the relevant SWRL rules

in order to result in new context information and

thus, (if any) new contextual constraints. The user

sharing preferences according to contextual

constraints (initial and inferred) are translated to

context-based access control rules and are stored by

cloud services to the cloud servers in the form of

user access control policy. Thus, for example, a user

access control rule can specify that his/her current

medications can be shared only with users that are

members of his groups named ‘mydoctors’ and

‘mypharmacists’. Another user access control rule

may specify that patient psychological profile can be

read during an online psychotherapy group without

disclosing patient identity, only by the authenticated

users of that group and only for the time period the

online group therapy takes place.

Figure 2: A small part of the OWL ontology.

On SN user request for accessing another (target)

SN user medical data, web services are called to

communicate with the context-aware access control

mechanism to retrieve the (target) user access

control policy, to evaluate the appropriate access

control rules and take decisions for the patient data

elements that should be viewed. Then, middleware

services are called that encapsulate functionality for

retrieving allowed patient data XML elements from

patient PHR, structuring this data in the form of a

CCD-based document and sending it to authorized

requesting user using SN messaging mechanisms.

For example, a physician might request through SN

(e.g. SN application) to view a patient latest

laboratory test results. Then, the appropriate web

services are called to evaluate patient access control

rules and if access is allowed the test results are

structured in the form of a CDD document that is

sent to the requesting user by SN message or email.

4 PROTOTYPE

IMPLEMENTATION

To illustrate the feasibility of the proposed security

HEALTHINF 2012 - International Conference on Health Informatics

380

architecture, a prototype implementation is

presented that is under development. Without the

loss of generality, for the purpose of the prototype

experimental implementation are used the public

cloud infrastructure of Amazon, the social network

of Facebook and the PHR of Microsoft called

HealthVault. Web services based on REST

technology were developed using the open source

Jersey to implement the access control services of

the middleware as well as the middleware

functionality. The HealthVault Application SDK

was used to access data from Microsoft HealthVault

PHR. Regarding the access control mechanism

implementation, the XML access control language

(XACML) is used and XACML policies are created

to represent user sharing preferences that are stored

to the cloud servers using Amazon S3 service

(Wrona et al., 2005). In addition, a web application

loaded in the context of Facebook is created to

provide the user application interface to access the

access control services and the middleware

functionality.

5 CONCLUDING REMARKS

This paper presents a security architecture that aims

at promoting secure patient information sharing

among users at anytime and from anywhere through

the use of SNs that are always available by any

device. In particular, the proposed access control

services ensure authorized patient information

retrieval from PHRs and its provision through SNs

messaging mechanisms and applications/tools

according to user’s access control preferences. To

realize this, there is a need to balance the urge to

protect individuals from potential harm that may be

caused by exposing personal information through

SNs and therefore to ensure that high quality

healthcare can be provided through the use of

eHealth services. In this paper, only the issue of

what other users can see has been addressed.

Questions of how to prevent the organisation in

control of the SN site using personal data which has

been freely shared for commercial gain through SN

functionality are left unanswered. Finally, there are

other problems not addressed here, such as legal and

ethical issues (Cushman et al., 2010).

The proposed security approach constitutes a

technological solution that is clearly implementable.

At present the development of the prototype is still

in the early stage. Thus, testing, user acceptance,

validation, evaluation and performance count on real

use of the eHealth services are still to be done.

REFERENCES

Beimel, D. and Peleg, M., 2011. ‘Using OWL and SWRL

to represent and reason with situation-based access

control policies’, Data and Knowledge Engineering,

vol. 70, pp. 596-615.

Cushman, R., Froomkin, M., Cava, A., Abril, P. and

Goodman, K., 2010. ‘Ethical, legal and social issues

for personal health records and applications’, Journal

of Biomedical Informatics, vol. 43, pp. S51-S55.

Domingo, M., 2010. ‘Managing healthcare through social

network’, IEEE Computer Society, vol. 43, no. 7, pp.

20-25.

Gajanayake, R., Iannella, R. and Sahama, T., 2011.

‘Sharing with care: An information accountability

perspective’, IEEE Computer Society, vol. 15, no. 4,

pp 31-38.

Greene, J., Choudhry, N., Kilabuk, E. and Shrank, W.,

2011. ‘Online social networking by patients with

diabetes: A qualitative evaluation of communication

with Facebook’, Journal of General Internal

Medicine, vol. 26, no. 3, pp. 287-292.

Shachak, A. and Jadad, A., 2010. ‘Electronic health

records in the age of social networks and global

telecommunications’, Journal of the American

Medical Association, vol. 303, no. 5, pp. 452-453.

Sunyaev, A., Kaletsch, A. and Krcmar, H., 2010.

‘Comparative evaluation of Google health api vs.

Microsoft Helathvault api’, International Conference

on Health Informatics - HEALTHINF 2010, Valencia,

Spain, pp. 195-201.

Thompson, L., Black, E., Duff, P., Black,

N., Saliba,

and Dawson, K., 2011. ‘Protected health information

on social networking sites: Ethical and legal

considerations’, Journal of Medical Internet Research,

vol. 13, no. 1.

Williams, J., 2010. ‘Social networking applications in

health care: threats to the privacy and security of

health information’, Proceedings of the 2010 ICSE

Workshop on Software Engineering in Health Care,

Cape Town, South Africa, pp. 39-49.

Wrona, K. and Gomez, L., 2005. ‘Context-aware security

and secure context-awareness in ubiquitous computing

environments’, Proceedings of the XII Autumn

Meeting of Polish Information Processing Society

Conference, pp. 255-265.

ENHANCING PATIENT INFORMATION SHARING THROUGH SOCIAL NETWORKS

381
