ON THE CROSSOVER OPERATOR FOR GA-BASED OPTIMIZERS

IN SEQUENTIAL PROJECTION PURSUIT

Soledad Espezua, Edwin Villanueva and Carlos D. Maciel

Sao Carlos School of Engineering, University of Sao Paulo, Sao Carlos, Brazil

Keywords:

Projection pursuit, Sequential projection pursuit, Genetic algorithms, Crossover operators.

Abstract:

Sequential Projection Pursuit (SPP) is a useful tool to uncover structures hidden in high-dimensional data

by constructing sequentially the basis of a low-dimensional projection space where the structure is exposed.

Genetic algorithms (GAs) are promising ﬁnders of optimal basis for SPP, but their performance is determined

by the choice of the crossover operator. It is unknown until now which operator is more suitable for SPP. In this

paper we compare, over four public datasets, the performance of eight crossover operators: three available in

literature (arithmetic, single-point and multi-point) and ﬁve new proposed here (two hyperconic, two ﬁtness-

biased and one extension of arithmetic crossover). The proposed hyperconic operators and the multi-point

operator showed the best performance, ﬁnding high-ﬁtness projections. However, it was noted that the ﬁnal

selection is dependent on the dataset dimension and the timeframe allowed to get the answer. Some guidelines

to select the most appropriate operator for each situation are presented.

1 INTRODUCTION

The collection of data sets with large amounts of mea-

sured features is becoming increasingly common in

many industrial and science areas. This makes di-

mension reduction an active research topic in data

mining, machine learning and statistics. Projection

pursuit (PP) (Friedman and Tukey, 1974; Friedman,

1987) is a framework of methods proposed to deal

with such high-dimensional data sets that has become

very popular in the statistical literature. PP faces the

curse of dimensionality by searching for ”interest-

ing” low-dimensional projections of the data, where

the interestingness of the projections is assessed by a

pre-deﬁned function, known as projection pursuit in-

dex (PP index). Thus, the most interesting projection

spaces are found by optimizing such function.

A wide range of data-mining problems can be

tackled with PP (Daszykowski et al., 2007), depend-

ing on the PP index used. For instance, PP can

perform the well known principal components anal-

ysis - PCA, with the variance being the PP index

(Daszykowski et al., 2007). Several PP indices have

been proposed in the literature for different applica-

tions (some reviews can be found in (Berro et al.,

2010; Rodriguez-Martinez et al., 2010; Jee, 2009; Lee

et al., 2005)). Indeed, there are PP indices suitable

for clustering analysis (Bolton and Krzanowski, 2003;

Pena and Prieto, 2001), classiﬁcation (Demirci et al.,

2008; Lee et al., 2005), feature selection (Guo et al.,

2001) and regression analysis (Ren et al., 2007).

One of the major problem in PP lies in the opti-

mization of the PP indices (Berro et al., 2010). Most

optimization methods were developed in the con-

text of exploratory projection pursuit - EPP, where

the target space is of one, two or three dimensions

(Bolton and Krzanowski, 2003; Nason, 1995; Posse,

1995a; Posse, 1995b; Posse, 1990; Friedman, 1987).

Gradient-based methods were the ﬁrst to be used

(Jones and Sibson, 1987; Huber, 1985). However, it

was noted that such methods can easily get stuck in lo-

cal optima close to the starting point, capturing noise-

induced structures (Friedman, 1987). This led some

researches to develop more global optimization meth-

ods, such as (Pena and Prieto, 2001; Posse, 1995a)

and (Friedman, 1987). Although their proposals are

appropriate for EPP, they have difﬁculties to scale

beyond three-dimensional projections, mainly due to

computational constraints in computing the indices in

such spaces. This difﬁculty was circumvented with

the emergence of the sequential projection pursuit

(SPP) (Guo et al., 2000), an algorithm that can per-

form projections onto higher-than-three dimensional

spaces in a simple way. SPP opened new possibilities

for PP, such as feature selection (Guo et al., 2001) and

feature extraction for machine learning (Rodriguez-

Espezua S., Villanueva E. and D. Maciel C. (2012).

ON THE CROSSOVER OPERATOR FOR GA-BASED OPTIMIZERS IN SEQUENTIAL PROJECTION PURSUIT.

In Proceedings of the 1st International Conference on Pattern Recognition Applications and Methods, pages 93-102

DOI: 10.5220/0003784400930102

 SciTePress

Martinez et al., 2010). In SPP, the bases of the pro-

jection space (PP factors) are sought one after the

other instead of all together. Each PP factor is ob-

tained by optimizing one-dimensional PP index over

residual data (data resulting from removing the struc-

ture found in the previous PP factors). A binary ge-

netic algorithm (GA) was presented as the index op-

timizer of SPP. The use of a GA for optimizing PP

indices was also proposed by (Chiang et al., 2001)

in the so-called projection pursuit evolutionary algo-

rithm (PPEA). (Webb-Robertson et al., 2005) argued

later that the GA optimizer in SPP is slow in obtain-

ing the PP factors and proposed an alternative to it:

the random scan sampling algorithm (RSSA). Some

other global methods for optimization of PP indices

were proposed in recent years, such as simulated an-

nealing (SA) (Lee et al., 2005) and particle swarm op-

timization (PSO) (Berro et al., 2010).

Based in the success of GA in many problems,

we believe that their potential was underexplored as

optimizers for SPP. Some desirable features of GAs

are attractive for SPP, such as (Srinivas and Patnaik,

1994): 1) GAs can search the solution space (that is

known to be multimodal) in a parallel and multidi-

rectional way, giving more chance to ﬁnd highly in-

formative projections; 2) at any time we can take a

solution, which get better with time; 3) one can con-

trol the diversity of the population, which can be use-

ful for EPP since many alternative solutions are re-

quired for inspection; and 4) GAs can be straightfor-

wardly implemented in parallel and distributed plat-

forms, expanding the applicability of PP to problems

with huge data sets. Despite these desirable features,

the performance of a GA is determined by the set of

genetic operators and parameters used, whose deter-

mination is not an easy task and heavily dependent on

the problem addressed. In particular, the choice of the

crossover operator is of key importance in the success

of a GA, since it is the primary search mechanism

that a GA relies, responsible for the rapid exchange

of useful information among solutions to locate better

solutions (Srinivas and Patnaik, 1994). Despite the

acceptable results reported with the crossover opera-

tors used in the original SPP and PPEA, the selection

of them was arbitrary. Nevertheless, it is unknown if

some other operators can perform better in the opti-

mization of PP factors for SPP.

Moving in this direction, we present in this

paper a comparative experimental study of eight

crossover operators: three currently used in SPP and

PPEA (arithmetic crossover and single and multi-

point crossover) and ﬁve new proposed here (one sin-

gle extension of the arithmetic crossover, two hyper-

conic crossovers and two ﬁtness-biased crossovers).

The performance of the crossover operator in a pro-

totypical GA is assessed by measuring the mean ﬁt-

ness of the population at different stages of evolution

and the converged ﬁtness and number of generations

needed to converge. The study was carried out over

four public datasets of increasing dimension ranging

from 13 to 166 variables. Also, the inﬂuence of the

evolutionary pressure in the performance of the differ-

ent operators is analyzed. The results showed that the

proposed hyperconic crossover operators tend to ﬁnd

projections with ﬁtness values higher than the other

operators, with one of such operators clearly excelling

in higher dimensions. The multi-point crossover was

also competitive in low dimensions. The ﬁnal selec-

tion of the crossover operator is dependent on the

dataset dimension and the tolerable time to get the

answer. Some guidelines to aid in the selection of

the most suitable crossover operator for SPP are pre-

sented.

The paper is organized as follows. Section 2 intro-

duces some important concepts of PP, SPP, and GAs.

Section 3 describes the crossover operators studied.

Section 4 presents the experimental setup. The re-

sults and discussions are presented in Sections 5 and

6. Finally, our conclusions are presented in Section 7.

2 BACKGROUND

2.1 Projection Pursuit

The projection pursuit concept was formally intro-

duced in the paper of (Friedman and Tukey, 1974),

although the seminal ideas were originally posed by

(Kruskal, 1969). To describe the idea of PP we as-

sume that the data set is arranged in a n × p matrix

X with n instances and p attributes or variables. PP

seeks a m-dimensional projection space (m < p), de-

ﬁned by the orthonormal bases A ∈ R

p×m

, where the

projected data X ·A expose information of interest.

The degree of interestingness of the projection is mea-

sured by the function I, called the projection pursuit

index (PP index). Thus, PP can be formulated as the

optimization problem:

∗

= argmax

{I(X ·A)} (1)

s.t A

·A = I.

The choice of the PP index is a key considera-

tion. A great deal of research has been centered on

the construction of a globally useful and robust in-

dex, but the effectiveness of an index is often depen-

dent on the application and characteristics of the given

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

dataset (Rodriguez-Martinez et al., 2010). One domi-

nant consideration in the developing of PP indices has

been the so-called afﬁne invariance (Jee, 2009). A PP

index I is said afﬁne invariant if I(X) = I(sX+v) for

a nonsingular linear transformation s and a constant

vector v. Thus, afﬁne invariance ensures that changes

in scale and location of the projected data do not affect

the index value. A common approach to insure afﬁne

invariance is sphering the original data matrix X to

have zero mean and identity covariance matrix. This

can be done by the following transformation (Posse,

1995a):

Z = Λ

−1/2

Q(X −E[X]) (2)

where Q and Λ are respectively the eigenvector

and eigenvalue matrices resulting from the eigen-

decomposition of the covariance matrix Σ = QΛQ

For simplicity, in the rest of the paper we will refer to

the original data matrix X as the sphered version of it.

In clustering applications, entropy is commonly

used as the PP index of the projected data(Jones and

Sibson, 1987). However, the entropy calculation is

computationally intensive, requiring high-order inte-

grals and a density estimator. A simpler and robust al-

ternative to entropy is the Holes PP index (Cook et al.,

1993), which returns comparable (and often better)

results than entropy (Webb-Robertson et al., 2005).

The Holes index is deﬁned for one-dimensional pro-

jection as:

Holes

= 1 −

∑

i=1

−

(3)

where y

is the projection of the ith data instance x

onto the direction of the basis vector a, y

= x

·a. We

adopt Holes as the PP index to be optimized in all

experiments presented in this paper.

Sequential projection pursuit (SPP) (Guo et al.,

2000) tackles the m-dimensional constrained opti-

mization problem in Equation 1 by converting it into

a sequence of m one-dimensional optimization prob-

lems. The ﬁrst basis (PP factor) a

in A is obtained by

searching (with a GA) a p-dimensional vector of unit

length that maximizes the PP index. Once the ﬁrst PP

factor a

is found, the data set is projected onto it, ob-

taining the score vector y

= X ·a

. The residual data

is then computed as X = X −y

·a

. The process is

then repeated on this residual data to obtain a

, y

a new residual data, subject to the constraint that a

is orthogonal to a

. In this way, the predeﬁned m PP

factors are obtained in SPP.

2.2 Genetic Algorithms

Genetic Algorithms (GAs) (Holland, 1975) belong to

a class of algorithms inspired in Darwinian evolution-

ary theory. GAs start from a population of individuals

(potential solutions) normally generated at random.

Each individual is then assigned a ﬁtness value by

means of a ﬁtness function (which encodes the prob-

lem objective function). The algorithm enters to an

evolutionary loop, where each iteration (generation)

produces a new population for the next generation.

In each generation, multiple individuals are stochas-

tically selected from the current population (based on

their ﬁtness) and recombined by a crossover operator

(and possibly randomly mutated by a mutation opera-

tor) to form an offspring population which is inserted

to the current population by a replacement operator.

The GA used in this paper for the evaluation of the

crossover operators encodes the individuals as real-

value unit-length vectors. This representation is used

instead of the binary representation to avoid loss of

precision. Thus, an individual i is a candidate ba-

sis vector a

= [a

,. .., a

]

to project the data

X·a

. The ﬁtness function is the Holes PP index. Sev-

eral crossover operators are tested (Section 3), those

that work over binary strings (single and multi-point

crossover) are naturally extended to our real represen-

tation, maintaining the coefﬁcients of the vectors as

unbreakable units (genes). The selection operator is

implemented as tournament selection: we randomly

choose ts individuals (the tournament size) from the

current population (of size w) and return the best indi-

vidual. With this selection method, w/2 pairs of dif-

ferent individuals are selected to form the mating pool

for crossover. For each pair of this mating pool a uni-

form random number is generated in the unit interval,

if such number is less than a predeﬁned number cr

(crossover rate parameter) the crossover is performed

and two new offspring are generated, otherwise the

offspring are clones of the parents. Mutation is no

used in the present study in order to no obscure the

inﬂuence of the studied crossover operators. Replace-

ment is carried out by selecting the best w individuals

of the joint population of parents and offspring.

3 CROSSOVER OPERATORS

Eight crossover operators are presented here, three

commonly used in the literature: arithmetic, single

and multi-point crossover and ﬁve new proposed for

this paper: one extension of the arithmetic crossover,

two hyperconic crossovers and two ﬁtness-biased

crossovers. All operators require two parent individu-

als as input and return two offspring as output. Parent

individuals are denoted by a1 = [a1

,. .., a1

]

and

a2 = [a2

,. .., a2

]

and the offspring individuals by

b1 = [b1

,. .., b1

]

and b2 = [b2

,. .., b2

]

. The

ON THE CROSSOVER OPERATOR FOR GA-BASED OPTIMIZERS IN SEQUENTIAL PROJECTION PURSUIT

function Normalize(x) produces a unit vector in the

direction of x, thus, Normalize(x) = x/

√

·x. This

operation is performed in all crossover operator in

order to maintain constant the scale of the projection.

Crossover1 (Arithmetic Inner Crossover). This op-

erator was adopted in PPEA (Chiang et al., 2001).

The offspring are produced as follow:

b1 = Normalize(ra1 + (1 −r)a2)

b2 = Normalize((1 −r)a1 + ra2) (4)

where r is a uniform random number from [0,0.5].

The offspring vectors are contained in the plane of

the parents and located symmetrically in both sides

of the bisectrix of the parents and limited by them.

Crossover 2 (Arithmetic Inner-outer Crossover).

This operator is proposed here as an extension of

Crossover1. The offspring are produced in the same

way as in Equation 4. The only difference is in the

random number r, which is generated uniformly in

the interval [−0.5,0.5] . Thus the offspring vectors

are contained in the plane of the parents and located

symmetrically in both sides of the bisectrix of the

parents. By contrast with Crossover1, the offspring

can be outside of the region delimited by the parents

forming a maximum angle with respect to the bisec-

trix of up to 2θ, being θ the angle between any parent

and the bisectrix.

Crossover3 (Single-point Crossover). This is a tra-

ditional operator in the GA that has been formulated

to recombine binary strings. We implement here a

real version of this operator. First, a random position

r is chosen uniformly from the set {1, 2,..., p −1}.

Next, the offspring are created as follow:

b1 = Normalize([a1

,. .., a1

,a2

r+1

,. .., a2

]

)

b2 = Normalize([a2

,. .., a2

,a1

r+1

,. .., a1

]

) (5)

Crossover4 (Multi-point Crossover). This operator

can be viewed as an extension of Crossover3. First, a

random binary vectors (mask) of length p is created

with similar numbers of 0s and 1s. Next, the offspring

b1 is created by placing the corresponding values

of a1 in the positions where the mask is 1 and the

values of a2 in the other positions. b2 is created in a

complementary way, i.e., b2 has the values of a2 in

the positions where the mask is 1 and the values of

a1 in other positions.

Crossover5 (Inner Hypercone Crossover). We

propose this operator to allow the offspring to be

outside the plane of the parents. The offspring

can be located inside the hypercone resulting from

rotating the parents around their bisectrix and sym-

metric to it. First, the bisectrix is calculated as

m = Normalize(a1 + a2). Next, a plane of crossover

is selected containing such bisectrix. Therefore, one

of the basis of that plane is the same bisectrix. The

other base v is a vector orthogonal to it that can

be constructed by randomly choosing one non-zero

component of m, m

, and one position l 6= j; with

this, the orthogonal vector is composed as: v

= 0

(i 6= j,l), v

= 1, and v

= −m

. The basis of the

plane of crossover are then Q = [m,v]. In this plane,

the bisectrix is over the abscissa and the parents are

located at angles θ and −θ. Offspring b1

is chosen

in polar coordinates in this plane as: e

, where θ

is uniformly selected from [0, θ]. Offspring b2

symmetric to offspring b1

, thus b2

= e

−θ

. The

offspring in the original space are recovered with the

plane basis as: bi = Q ·bi

, i = 1, 2. In this crossover

scheme there are up to p(p − 1) different planes

where the crossover can take place, all intersecting at

the parent bisectrix.

Crossover6 (Inner-outer Hypercone Crossover).

This operator is proposed here as an extension of

Crossover5. Like such operator, the offspring can

be in one of the p(p −1) possible crossover planes

symmetric to the bisectrix of the parents. By contrast

with Crossover5, the offspring are allowed to be

outside the hypercone generated by rotating the

parents around their bisectrix. The procedure to

produce the offspring is similar to Crossover 5. The

only difference is the interval where θ

is sampled,

which is [0,2θ]. Consequently, the offspring can

born in a wider hypercone than that of Crossover5,

containing this later.

Crossover7 (Fitness-biased Inner Crossover). We

propose this operator to guide the creation of the off-

spring by the ﬁtness of the parents. The crossover

takes place in the plane of the parents, as Crossover 1

and Crossover 2. By contrast with them, the offspring

are no more symmetric to the bisectrix of the parents.

The basis vector in the plane are chosen so that the

parent with more ﬁtness forms a negative angle with

respect to the abscissa. Let denote a

best

the parent

with best ﬁtness and a

worst

the other parent. The ba-

sis vectors in the plane are Q = [m,v], where m is

the bisectrix and v is computed as Normalize(a

worst

−

worst

·m)m). In this plane, the bisectrix is over the

abscissa and the parents are located at angles −θ (the

best parent) and θ (the worst parent). A uniform ran-

dom angle θ

is sampled from the interval [−θ,θ].

Then, this angle is distorted (in favor to −θ) with the

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

following function:

(biased)

= 2θ((θ

+ θ)/2θ)

−θ (6)

where β > 1 controls the amount of dis-

tortion. In our experiments we use β =

(Fitness(a

best

)/Fitness(a

worst

))

. The function

in Equation 6 produces an angle in the same interval

[−θ,θ]. With θ

(biased)

computed, the ﬁrst offspring

b1 is constructed as explained in Crossover 5. The

offspring b2 is produced similarly choosing another

Crossover8 (Fitness-biased Inner-outer

Crossover). This operator is proposed here as

an extension of Crossover7 (like Crossover2 extends

Crossover1). The procedure is similar to Crossover7.

The only difference is in the interval from which θ

(and therefore θ

(biased)

) is sampled. This interval is

[−2θ,2θ]. Thus the offspring vectors are contained

in the plane of the parents, with the tendency to fall

closer to the best parent, both on its left and right

sides.

4 EXPERIMENTAL STUDY

4.1 Datasets

Four public datasets were selected for our study from

the UCI repository (Frank and Asuncion, 2010). The

selection was performed trying to have a collection of

datasets with increasing number of features (almost

geometric increase) to analyze the inﬂuence of the in-

creasing dimension over the crossover operators.

Wine Dataset. This dataset is known as the Wine

recognition data. The data are the results of a

chemical analysis of samples of three types of

wines in Italy. The dataset consist of 178 in-

stances and 13 continuous features (constituents

found for each wine).

WDBC Dataset. This dataset is known as the Wis-

consin Diagnostic Breast Cancer. Each data

sample describe characteristics of the cell nuclei

present in a digitized image of ﬁne needle aspi-

rate of breast mass. The dataset consist of 569 in-

stances and 30 real-valued features that describe

characteristics of the cell nuclei present in the im-

age.

Sonar Dataset. This dataset content features ex-

tracted from bouncing of sonar signals collected

from metal cylinders and cylindrically-shaped

rocks positioned on a sandy ocean ﬂoor. The

dataset consist of 208 instances and 60 real-valued

attributes. Each attribute represents the energy

within a particular frequency band integrated over

a period of time.

Musk Dataset. In this dataset are stored features that

represent different conformations of molecules

that are judged by human experts. The dataset

consist of 476 instances and 166 attributes labeled

according to whether or not they contain a musk

odor.

4.2 Evaluation

The performance of the different crossover operators

are evaluated in the prototypical GA described in Sub-

section 2.2. Three hundred replicates are performed

for each dataset to obtain consistent statistics. Figure

1 depicts a replicate, which consists in: 1) generate an

initial random population by choosing w = 10p ran-

dom vectors from R

and normalizing them to be unit

length vectors; 2) starting from this initial population,

evolve two instance of the GA for each crossover op-

erator: one for ts = 1% of the population and one for

ts = 5% of the population (in total 16 GA instances

are evolved per replicate); 3) record the following

statistics for every GA instance: the mean ﬁtness of

the evolving population at 20 generations, the mean

ﬁtness of the evolving population at 200 generations,

and the mean ﬁtness and number of generations when

the population reaches convergence. We consider that

a population has converged when the difference be-

tween the maximum and mean ﬁtness of the popula-

tion is less than 1e

−7

. In some cases convergence is

achieved before 200 generations; there, the GA is kept

running to reach 200 generations. Otherwise, the al-

gorithm is stopped as soon as convergence is reached.

If convergence is not achieved in a maximum of 5000

generations, the GA instance is stopped anyway. In

all cases the crossover rate is set to 1 and the muta-

tion is disabled. This implies that the couples in the

mating pool always produce their offspring by cross-

ing over. The recorded statistics are averaged over the

300 replicates in each dataset.

Figure 1: Example of replicate executed to get statistics of

the performance of the crossover operators.

ON THE CROSSOVER OPERATOR FOR GA-BASED OPTIMIZERS IN SEQUENTIAL PROJECTION PURSUIT

(a) Wine dataset.

(b) WDBC dataset.

(d) Musk dataset.

Figure 2: Results for the mean ﬁtness (curves) and num-

ber of generations (bars) at convergence (averaged over 300

replicates). The left scale is for the number of generations

and the right scale is for the ﬁtness values (Holes PP index).

With this experimental setup we try to measure the

contribution of the crossover operator on the perfor-

mance of the GA. For a same replicate and tourna-

ment size, all GA instances start from the same pop-

ulation, so the only inﬂuential factor on the GA per-

formance is the crossover operator. One of the per-

formance measures is the mean ﬁtness of the popu-

lation at different stages of evolution. This will tell

us which operators would be more appropriate if we

have a time frame to get the answer. The other per-

formance measures are the maximum achievable ﬁt-

ness and the number of generations needed to reach

it. With these measures, we are enabled to infer the

exploratory capabilities of the operators and their efﬁ-

ciencies. Also important, the analysis of the crossover

operators at different selective pressure levels (de-

ﬁned by the tournament size) is useful, since the be-

havior of the crossover operator can be affected by

this factor.

5 RESULTS

Figure 2 shows the results of the average values of

ﬁtness and number of generations at convergence for

the different crossover operators and tournament sizes

analyzed. Each subﬁgure corresponds to a differ-

ent dataset. With respect to the number of gener-

ations needed to converge, a similar pattern can be

seen for all datasets and tournament sizes: Crossover6

has the highest value and clearly differentiated from

the others; Crossover4 has the second highest val-

ues; Crossover1 and Crossover7 have almost identical

values, which are the lowest values of all operators;

Crossover2 and Crossover8 have also matching val-

ues, which are the second lowest values; Crossover3

and Crossover5 have mixed values, with Crossover3

surpassing Crossover5 only when ts = 1% in all but

Musk dataset. These results can be also visualized

in Figure 3, which shows the mean number of gen-

erations of convergence as a function of the dataset

dimension for the two tournament sizes. It can be

seen two groups of operators with different trend with

respect to the dimension, independent of the tourna-

ment size. The ﬁrst group, integrated by Crossover1,

Crossover2, Crossover3, Crossover7 and Crossover8,

shows a decrease in the number of generations for

convergence as the dimensionality is increased. The

second group, formed by Crossover4, Crossover5 and

Crossover6, shows an increase in the number of gen-

erations for convergence as the dataset dimension

is increased, with Crossover6 having the fastest in-

crease. When the tournament size is varied from ts =

1% to ts = 5%, the number of generations for con-

vergence decreases for all crossovers operators and

datasets (also observed in Figure 2), but the general

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

(a) ts = 1%. (b) ts = 5%.

Figure 3: Plot of the number of generations needed for convergence (averaged over 300 replicates) with respect to the dataset

(ordered according to its dimension) for two selective pressure. The scale is logarithmic to visualize differences.

behavior of the number of generations vs. dimension-

ality is unchanged.

With respect to the ﬁtness of the converged so-

lutions, we can observe in Figure 2 that the ﬁtness

values achieved with the different crossover operators

in all datasets are negatively affected by the increase

of the tournament size from 1% to 5%. Crossover5

and Crossover6 are the least affected operators to this

change, with Crossover6 being almost insensitive. In

addition, Crossover6 converged to solutions with bet-

ter ﬁtness than the other operators, being this behavior

more pronounced on datasets of higher dimensional-

ities (Sonar and Musk). Crossover4 presents the sec-

ond highest values in its converged solutions when

ts = 1%. When ts = 5%, the solutions produced by

Crossover4 are slightly surpassed by those produced

by Crossover5 in higher dimensionalities. Crossover3

has the next best ﬁtness values, closely followed by

Crossover8. Crossover1, Crossover2 and Crossover7

produce similar solutions with the lowest ﬁtness val-

ues.

Figure 4 shows for each dataset the mean ﬁtness

of the evolving population at 20 and 200 genera-

tions for ts = 1%. At both number of generations, it

can be observed an interesting difference between the

datasets with low dimensions (Wine and WDBC) and

the datasets with higher dimensions. In the ﬁrst group

of datasets, Crossover4 and Crossover6 are very com-

petitive in ﬁtness, generating the highest values of all

operators. Crossover5 is also competitive at 20 gen-

erations in such datasets, but unlike Crossover4 and

Crossover6, it quickly reaches its maximum, mak-

ing a poor improvement of the ﬁtness from 20 to

200 generations. In the datasets with higher dimen-

sionalities (Sonar and Musk), Crossover6 presents a

clear superiority to the others operators at both num-

ber of generations sampled. At 200 generations in

those datasets, Crossover4 continues to be the sec-

ond best operator in producing high-ﬁtness solutions,

but when the number of generations is lowered to

20 it is overcome by Crossover5. Crossover3 and

Crossover8 produce the next best solutions in all

datasets, with Crossover3 having a better ﬁtness en-

hancement with the increment of the number of gener-

ations. Crossover1, Crossover2 and Crossover7 pro-

duce the lowest-ﬁtness solutions in all datasets, re-

gardless the number of generations. They present an

irrelevant increment of the mean ﬁtness going from 20

to 200 generations. In addition, Crossover(1,2,3,7,8)

tend to ﬁnd solutions of similar ﬁtness as the dataset

dimension is increased.

6 DISCUSSION

From the above results, it is clear that the performance

of the analyzed crossover operators is affected by the

dimension of the original data and the selective pres-

sure used to evolve the GA. Based on the ﬁtness of the

converged solution, it can be inferred that producing

the offspring somewhere in the hypercone around the

bisectrix of the parents (Crossover(5,6)) improves the

idea of producing the offspring only in the plane of the

parents (as Crossover(1,2,7,8)), giving an increased

exploratory power to the GA. This strengthening of

the search power is even more remarkable if the off-

spring is allowed to born outside the hypercone of the

parents (generated by rotating them around their bi-

sectrix), as Crossover6. The negligible sensitivity of

Crossover(5,6) to the change of the selective pressure

can also be explained by their good exploratory prop-

erties, since they produce offspring in a wider space,

being less prone to converge to the ﬁrst local opti-

mum they found as the selective pressure is increased.

The drawback of the hyper-conical operators, espe-

cially Crossover6, is the high number of generations

ON THE CROSSOVER OPERATOR FOR GA-BASED OPTIMIZERS IN SEQUENTIAL PROJECTION PURSUIT

(a) Wine dataset.

(b) WDBC dataset.

(d) Musk dataset.

Figure 4: Results for the mean ﬁtness of the evolving popu-

lations (averaged over 300 replicates) at 20 and 200 gener-

ations.

needed to converge, which rapidly grows with the di-

mension of the data. However, if the convergence cri-

terion is a ﬁxed number of generations, Crossover6

gives solutions with competitive ﬁtness, outperform-

ing considerably the other operators in high dimen-

sional datasets.

The idea of recombining the parents by transfer-

ring some coordinates of one parent and the rest of

coordinates of the other parent, as in Crossover(3,4),

proved also to be effective for the purpose of PP factor

optimization. It was found that transferring the coor-

dinates as independent units (Crossover4) gives more

search performance than transferring the coordinates

in blocks, as in Crossover3. Unlike Crossover(5,6),

the search performance of these operators is notice-

ably degraded by the increase of the selective pres-

sure. This suggests that such operators heavily rely on

the diversity of the population (given by low selective

pressure) to produce better results. The average num-

ber of generations to achieve convergence is also con-

siderable in Crossover4 (is the second highest after

Crossover6) and, as Crossover6, it grows quickly with

the dimension of the data. For a ﬁxed number of gen-

erations and in low-dimensional datasets Crossover4

is as competitive as Crossover6 in ﬁtness of the solu-

tions. But in high dimensions it performs worse.

The proposal of biasing the production of the

offspring by the ﬁtness of the parents, as in

Crossover(7,8), proved to be not as effective as the

production of the offspring inside (or outside) the

hypercone of the parents. However, some gain is

obtained in ﬁtness with almost the same number of

generations of convergence of their non-biased ver-

sions (Crossover(1,2)). The number of generations to

achieve convergence with these non-hyperconic oper-

ators (Crossover(1,2,7,8)) is very low in all datasets

and decrease slightly with the dimension of the data.

This behavior could be explained by the fact that the

dimension of the space where the offspring are gener-

ated (the plane of the parents) does not grow with the

dimension of the data (as in the other operators), so

such space is more and more restrictive as the dimen-

sion increases, turning them more prone to ﬁnd local

optima.

Based on the above ﬁndings we can infer some

guidelines to select the crossover operator for a GA

as optimizer of PP factors. First, if we have a ﬁxed

time frame to get the answer and the dataset has a low

dimension (as Wine or WDBC), it would be more ad-

visable to choose Crossover4 with low selective pres-

sure (1% of the population size) or Crossover6 with

low to moderate selective pressure (1-5% of the pop-

ulation size). Second, if we have a ﬁxed time frame

for the answer but the dataset has moderate to high

dimension (as Sonar or Musk), the most appropriate

option would be Crossover6. Third, if the time is not a

constraint and the dataset has low dimension, the best

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

100

options to consider would be Crossover4 with low se-

lective pressure or Crossover(5,6) with moderate se-

lective pressure. Finally, if the time is not a constraint

and the dataset is high-dimensional, the best option to

consider would be Crossover6 with moderate selec-

tive pressure.

7 CONCLUSIONS

Sequential Projection Pursuit - SPP is a useful

method to ﬁnd interesting linear projections of multi-

dimensional data. The main problem in SPP is the op-

timization of the PP index function, which measures

how interesting the projection is. Genetic algorithms

are promising optimizer of SPP, but their success is

dependent on the selection of their genetic operators.

One of the most important operators is the crossover,

which is responsible for the rapid exchange of useful

information among solutions. This article addressed

the problem of which crossover to choose in the de-

sign of a GA-based optimizer for SPP. An experimen-

tal study was presented, comparing the performance

of eight crossover operators: three available in litera-

ture (arithmetic crossover and single and multi-point

crossover) and ﬁve new proposed here (one single ex-

tension of the arithmetic crossover, two hyperconic

crossovers and two ﬁtness-biased crossovers). The

study was carried out over four public datasets of

increasing dimension. The results showed that one

of the proposed hyperconic operators tends to ﬁnd

projections with higher ﬁtness than the other oper-

ators, clearly excelling in higher dimensions. This

interesting performance was also observed at differ-

ent stages of evolution. The multipoint crossover op-

erator presented the second best performance in ﬁt-

ness, being competitive with the hyperconic operator

in low dimensional datasets. The ﬁnal selection of

the crossover operator is dependent on the precision

required, the dimension of the dataset and the tolera-

ble time to get the answer. Some guidelines to select

the most appropriate operator for each situation were

presented.

This study is an important step towards the de-

sign of efﬁcient GA-optimizers for SPP. We are cur-

rently investigating other PP indices and the inﬂu-

ence of mutation on the performance of the pre-

sented crossover operators. Also, different evolution-

ary strategies are being studied to take advantage of

the features of the proposed operators.

ACKNOWLEDGEMENTS

The authors acknowledge the CAPES/ PEC-PG -

Brazil for the scholarship granted to the ﬁrst author

of this article.

REFERENCES

Berro, A., Marie-Sainte, S. L., and Ruiz-Gazen, A. (2010).

Genetic algorithms and particle swarm optimization

for exploratory projection pursuit. Annals of Math-

ematics and Artiﬁcial Intelligence, 60(1-2, SI):153–

178.

Bolton, R. and Krzanowski, W. (2003). Projection pursuit

clustering for exploratory data analysis. Journal of

Computational and Graphical Statistics, 12(1):121–

142.

Chiang, S.-S., Chang, C.-I., and Ginsberg, I. (2001). Unsu-

pervised target detection in hyperspectral images us-

ing projection pursuit. Geoscience and Remote Sens-

ing, IEEE Transactions on, 39(7):1380 –1391.

Cook, D., Buja, A., and Cabrera, J. (1993). Projection

pursuit indexes based on orthonormal function ex-

pansions. Journal of Computational and Graphical

Statistics, 2(3):225–250.

Daszykowski, M., Kaczmarek, K., Heyden, Y. V., and Wal-

czak, B. (2007). Robust statistics in data analysis - a

review: Basic concepts. Chemometrics and Intelligent

Laboratory Systems, 85(2):203– 219.

Demirci, O., Clark, V. P., and Calhoun, V. D. (2008). A pro-

jection pursuit algorithm to classify individuals using

fMRI data: Application to schizophrenia. Neuroim-

age, 39(4):1774–1782.

Frank, A. and Asuncion, A. (2010). UCI machine learning

repository.

Friedman, J. H. (1987). Exploratory projection pursuit.

American Statistical Association, 82(397):249–266.

Friedman, J. H. and Tukey, J. W. (1974). A projection

pursuit algorithm for exploratory data analysis. IEEE

Trans. Comput., 23(9):881–890.

Guo, Q., Wu, W., Massart, D., Boucon, C., and de Jong,

S. (2001). Feature selection in sequential projection

pursuit. Analytica Chimica Acta, 446(1-2):85–96.

Guo, Q., Wu, W., Questier, F., Massart, D., Boucon, C., and

de Jong, S. (2000). Sequential projection pursuit using

genetic algorithms for data mining of analytical data.

Analytical Chemestry, 72(13):2846–2855.

Holland, J. H. (1975). Adaptation in Natural and Artiﬁcial

Systems. University of Michigan Press, Ann Arbor,

MI, USA.

Huber, P. J. (1985). Projection pursuit. Annals of Statistics,

13(2):435–475.

Jee, J. R. (2009). Projection pursuit. Wiley Interdisciplinary

Reviews: Computational Statistics, 1(2):208–215.

Jones, M. C. and Sibson, R. (1987). What is projection pur-

suit? Journal of the Royal Statistical Society. Series A

(General), 150(1):pp. 1–37.

ON THE CROSSOVER OPERATOR FOR GA-BASED OPTIMIZERS IN SEQUENTIAL PROJECTION PURSUIT

101

Kruskal, J. (1969). Toward a practical method which helps

uncover the structure of a set of multivariate observa-

tions by ﬁnding the linear transformation which opti-

mizes a new ’index of condensation’. Statistical Com-

putation, pages 427–440.

Lee, E., Cook, D., Klinke, S., and Lumley, T. (2005). Pro-

jection pursuit for exploratory supervised classiﬁca-

tion. Journal of Computational and Graphical Statis-

tics, 14(4):831–846.

Nason, G. (1995). Three-dimensional projection pursuit. J.

Royal Statistical Society, Series C, 44:411–430.

Pena, D. and Prieto, F. (2001). Cluster identiﬁcation using

projections. Journal of the American Statistical Asso-

ciation, 96(456):1433–1445. 160th Annual Meeting

of the American-Statistical-Association, BOSTON,

MASSACHUSETTS, FEB, 2000.

Posse, C. (1990). An Effective 2-dimensional Projec-

tion Pursuit algorithm. Communications in Statistics-

Simulation and Computation, 19(4):1143–1164.

Posse, C. (1995a). Projection pursuit exploratory data anal-

ysis. Computational Statistics and Data Analysis,

20:669–687.

Posse, C. (1995b). Tools for two-dimensional exploratory

projection pursuit. Computational and Graphical

Statistics, 4(2):83–100.

Ren, Y., Liu, H., Yao, X., and Liu, M. (2007). Prediction

of ozone tropospheric degradation rate constants by

projection pursuit regression. Analytica Chimica Acta,

589(1):150–158.

Rodriguez-Martinez, E., Goulermas, J. Y., Mu, T., and

Ralph, J. F. (2010). Automatic induction of projection

pursuit indices. IEEE Transactions on Neural Net-

works, 21(8):1281–1295.

Srinivas, M. and Patnaik, L. (1994). Genetic Algorithms -

A Survey. Computer, 27(6):17–26.

Webb-Robertson, B. J. M., Jarman, K. H., Harvey, S. D.,

Posse, C., and Wright, B. W. (2005). An improved

optimization algorithm and bayes factor termination

criterion for sequential projection pursuit. Chemomet-

rics and Intelligent Laboratory Systems, 77(1-2):149–

160.

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

102
