AUTOMATED REGULON CONTENT PREDICTION AND

ESTIMATION OF PWM QUALITY

Elena Stavrovskaya

1,2

, Andrey Mironov

1,2

, Dmitry Rodionov

2,3

, Inna Dubchak

and Pavel Novichkov

Department of Bioengineering and Bioinformatics, Moscow State University, Leninskiye Gory 1-73, Moscow, Russia

Institute for Information Transmission Problems, Moscow, Russia

Burnham Institute for Medical Research, La Jolla, CA, U.S.A.

Lawrence Berkeley National Laboratory, 1 Cyclotron Road, Berkeley, CA, U.S.A.

Keywords: Regulation of transcription, Bacteria, Regulon, PWM.

Abstract: Identification of genes regulated by the same transcription factor (TF) is a major problem in analysis of

regulation. The key step in detection of a group of co-regulated genes (regulon) is prediction of TF binding

sites (TFBS). This is what positional weight matrix (PWM) is for. This matrix is applied to upstream region

of a gene, and high-scoring sites are considered as putative TFBSs. Choice of threshold for the scoring

function is a separate complicated problem. Usually, the threshold is chosen manually. Some methods for

automated threshold detection exist, but they are based on selection of threshold for different functions. In

this paper, we present an approach for regulon prediction based on a probabilistic method of threshold

detection. The optimal probability computed by this method can be used to estimate the quality of the PWM

itself. It can be useful when the matrix is a result of regulatory motif prediction program.

1 INTRODUCTION

Reconstruction of transcriptional regulatory

networks is one of the major challenges that the

bioinformatics community is facing in view of

constantly growing number of complete genomes.

The comparative genomics approach has been

successfully used for the analysis of the

transcriptional regulation of many metabolic systems

in various bacterial taxa. The key step in this

approach is selection of an optimal site score

threshold for the search of potential transcription

factor binding sites (TFBS), given a position weight

matrix. Here we demonstrate that this problem is

tightly coupled with a problem of discovering the

optimal content of regulon and suggest an approach

to solve both problems simultaneously.

In this study we developed an approach for

selection of TFBS score threshold that allows

automatic inference of the regulon content given

known TFBS motif. We developed three

modifications of this approach and extensively

tested them on a set of manually curated regulons.

2 METHOD

2.1 Universal TFBS Score Threshold

At the first step we process all genomes under

analysis and cluster all genes into orthologous

groups (OGs). To enable comparative genomics

analysis we consider only those groups that have at

least two orthologous genes. Using the concept of

OG, the problem of regulon inference can re-

formulated as a problem of selecting a subset of OGs

that most probably have a conservative TFBS.

Then, assuming

to be a potential optimal

threshold, we calculate regulatory potential

for

each orthologous group (OG). A particular OG is

described by two parameters: the number of

orthologous genes

, and the length of upstream

region Li averaged by all genes in an OG. Applying

the TFBS profile to upstream regions of all

orthologs in a group, the number of genes

that

have a potential TFBS with score

Ss 

can be

calculated. We define the regulatory potential in

terms of probability to observe the number of

322

Stavrovskaya E., Mironov A., Rodionov D., Dubchak I. and Novichkov P..

AUTOMATED REGULON CONTENT PREDICTION AND ESTIMATION OF PWM QUALITY.

DOI: 10.5220/0003787403220325

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2012), pages 322-325

ISBN: 978-989-8425-90-4

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

orthologous genes in a group, having at least one

high scoring site, being

or greater, given that

upstream regions are random sequences.

)),,|(log(

SLNKkPR

iiii



At the final step we utilize “Bernoulli Estimator”

(BE) routine (Kalinina, 2004) which assumes that

input values are a mixture from two distributions

representing the noise and the signal. Only

distribution that represents the noise is required for

automatic inference of the optimal threshold

distinguishing the signal from the noise. Applying

BE to regulatory potentials calculated for all OGs

given

S , the most probable content of a regulon

can be automatically identified. Considering all

possible values of

S , the optimal threshold

delivering the minimum to BE probability, can be

obtained.

As a result, the optimal threshold for TFBS score

, the optimal threshold for the regulatory

potential, and the subset of OGs predicted to be

members of the regulon can be calculated. It should

be noted that in this case the same “universal” TFBS

score threshold has been used for all OGs under

consideration

We also implemented two additional

modifications of the developed approach considering

different levels of sensitivity.

2.2 Individual TFBS Score Threshold

In this minor modification, instead of one universal

TFBS score threshold, we use individual threshold

for each OG. It allows to take into account the

possible difference in affinity of TF factor to DNA

binding sites among different members of the same

regulon. It was shown that such differences can be

evolutionary conserved and thus have functional

meaning. (Kotelnikova, 2005)

2.3 No TFBS Score Threshold

This modification is fundamentally different from

the two previous ones. This version does not use

threshold to filter out weak sites, but rather allows

all putative binding sites to contribute to the

regulatory potential of an OG. For a particular OG

of size N we consider a set of N best scores

{

...s

}. The regulatory potential is calculated

as a probability to observe OG with maximum

scores {

...s

} or better by chance.

3 TESTING

3.1 Comparison with the Results of

Manual Analysis

The developed algorithms have been extensively

tested on 62 manually curated regulons from

Shewanella collection retrieved from the RegPrecise

database (http://regprecise.lbl.gov). All regulons

were classified into three classes: i) local (1-2

operons), ii) medium (3-10 operons), and iii) global

(more than 10 operons). As expected, all three

versions performed similarly well on local regulons

representing the most abundant class of regulons in

microbial genomes. For 24 out of 39 local regulons

the regulon content was predicted correctly.

For medium and large size regulons, the

"universal TFBS score threshold" approach was able

to predict 63% and 36% true members of regulons.

The careful analysis of predicted regulon content

revealed that in both cases it comprises the core of

the true regulon with very high TFBS score and high

level of TFBS conservation across all genomes

under analysis. At the same time the specificity is

very high in both cases (95%). Thus the approach

can be used for automatic accurate reconstruction of

the core of regulon, and provides a good starting

point for the detailed manual curation.

3.2 PWM Quality

All the methods of regulatory motif prediction give

some number of variants as output. This gives rise to

the problem of motif quality estimation.

Conservation of nucleotides in PWM positions does

not always reflect the true quality of the motif found.

The best test of motif quality is arrangement of sites

recognized with PWM in the genome: if sites are

found upstream of genes which can be included into

one metabolic pathway, the motif is certainly found

correctly. Unfortunately, we don't always have the

information about gene function. On the other hand,

by applying comparative genomics, we can select

evolutionarily conservative sites. Our approach is

based on comparative genomics; in addition, we

compute the minimal probability of selecting these

sites by chance. This probability could reflect the

motif quality. To verify this assumption, we used the

following test.

It is known that, as a rule, each TF regulates its

own gene. Even when other regulated genes for a TF

are unknown, one can search for motifs upstream of

TF gene in a set of closely related genomes. Such a

motif is a first approximation, and can be improved

AUTOMATED REGULON CONTENT PREDICTION AND ESTIMATION OF PWM QUALITY

323

Table 1: Average results of testing on 62 Shewanella regulons. Sf (sensitivity) is the fraction of the correctly predicted

operons among all the operons under regulation; Sp (specificity) is the fraction of the correctly predicted operons among all

the predicted operons.

universal score threshold individual score threshold no score threshold

Sf Sp Sf Sp Sf Sp

local 0.74 0.74 0.92 0.72 0.86 0.81

medium 0.63 0.95 0.62 0.82 0.63 0.89

global 0.36 0.95 0.41 0.88 0.52 0.91

Table 2: Logarithm of the Bernoulli probability produced by the test of “de novo” motif prediction. The values for the true

motifs are on gray background.

TF motif

method

universal score threshold individual score threshold no score threshold

LexA

LexA_0

-165.22 -117.98 -62.21

LexA_1

-143.41 -118.85 -83.89

NtrC

NtrC_0

-89.54 -69.19 -45.84

NtrC_1

-56.7 -39.25 -29.47

PdhR

PdhR_0

-80.77 -56.56 -35.19

PdhR_1

-68.65 -59.24 -35.99

PdhR_2

-87.81 -62.27 -37.55

TrpR

TrpR_0

-59.66 -38.9 -27.68

TrpR_1

-23.88 -14.96 -14.36

TrpR_2

-54.26 -38.39 -20

TyrR

TyrR_0

-65.86 -58.24 -38.37

TyrR_1

-68.27 -48.05 -32.27

by the further analysis. We selected several known

regulons and used this strategy. We applied the

motif search algorithm SignalX (Mironov, 2000) to

upstream regions of TF genes in a set of Shewanella

genomes.

Next, we applied our approach of regulon

inference to the 2-3 best hits. In almost all cases, the

correct motif has the lowest minimal Bernoulli

probability (see Table 2). In PdhR motifs, the false

motif (PdhR_2) has lower Bernoulli probability in

all the approaches. The reason for this is that this

motif is gc-reach; such a motif will always have a

lower Bernoulli probability, because Shewanella

genomes are gc-poor.

4 CONCLUSIONS

We have developed an approach for an automatic

reconstruction of regulons in microbial genomes

without arbitrary thresholds given the known TFBS

motif. The approach allows automatic selection of

the optimal TFBS score threshold and uses it for

prediction of the regulon content. The testing of the

approach on the manually curated regulons showed

that it performs best on local regulons. In the case of

medium and large size regulons, the approach allows

automatic detection of the core of the regulon and

has low level of overprediction. We also showed that

the same probabilistic schema can be used for

selection of the best candidate PWM in a course of

motif search procedure.

ACKNOWLEDGEMENTS

This work was partially supported by Federal

Agency on Education (#P999), Russian Ministry of

Education and Science (Program “Research and

Development”, contract #07.514.11.4007), Russian

Foundation of Basic Research (grant #09-04-92742).

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

324

REFERENCES

Novichkov P. S., Laikova O. N., Novichkova E. S.,

Gelfand M. S., Arkin A. P., Dubchak I., Rodionov D.

A., 2010. RegPrecise: a database of curated genomic

inferences of transcriptional regulatory interactions in

prokaryotes. Nucleic Acids Res. Jan;38(Database

issue).

Kalinina O. V., Mironov A. A., Gelfand M. S.,

Rakhmaninova A. B., 2004. Automated selection of

positions determining functional specificity of proteins

by comparative analysis of orthologous groups in

protein families. Protein Sci. Feb;13(2).

Kotelnikova E. A, Makeev V. Yu, Gelfand M.S., 2005

Evolution of transcription factor DNA binding sites.

Gene. 347 (2).

Mironov A. A., Vinokurova N. P., Gel’falnd M. S., 2000.

Software for analyzing bacterial genomes. Mol Biol

(Mosk). 34(2).

AUTOMATED REGULON CONTENT PREDICTION AND ESTIMATION OF PWM QUALITY

325
