A DYNAMIC WRAPPER METHOD FOR FEATURE

DISCRETIZATION AND SELECTION

Artur Ferreira

1,3

and Mario Figueiredo

2,3

Instituto Superior de Engenharia de Lisboa, Lisboa, Portugal

Instituto Superior T´ecnico, Lisboa, Portugal

Instituto de Telecomunicac¸˜oes, Lisboa, Portugal

Keywords:

Feature discretization, Feature selection, Static discretization, Dynamic discretization, Wrapper approach,

Linde-Buzo-Gray algorithm.

Abstract:

In many learning problems, an adequate (sometimes discrete) representation of the data is necessary. For in-

stance, for large number of features and small number of instances, learning algorithms may be confronted

with the curse of dimensionality, and need to address it in order to be effective. Feature selection and fea-

ture discretization techniques have been used to achieve adequate representations of the data, by selecting an

adequate subset of features with a convenient representation. In this paper, we propose static and dynamic

methods for feature discretization. The static method is unsupervised and the dynamic method uses a wrapper

approach with a quantizer and a classiﬁer, and it can be coupled with any static (unsupervised or supervised)

discretization procedure. The proposed methods attain efﬁcient representations that are suitable for learning

problems. Moreover, using well-known feature selection methods with the features discretized by our methods

leads to better accuracy than with the features discretized by other methods or even with the original features.

1 INTRODUCTION

Datasets with large numbers of features and (rela-

tively) smaller numbers of instances are challenging

for machine learning methods. In fact, it is often the

case that many features are irrelevant or redundant for

the task at hand (e.g., learning a classiﬁer) (Yu et al.,

2004; Peng et al., 2005); this may be specially harm-

ful with relatively small training sets, where these ir-

relevancies/redundancies are harder to detect.

To deal with such datasets, feature selection (FS)

and feature discretization (FD) methods have been

proposed to obtain data representations that are more

adequate for learning. FD aims at ﬁnding a represen-

tation of each feature that contains enough informa-

tion for the learning task at hand, while ignoring mi-

nor (possibly irrelevant) ﬂuctuations. FS aims at re-

ducing the number of features, thus directly targeting

the curse of dimensionality problem, often allowing

the learning algorithms to obtain classiﬁers with bet-

ter performance. A byproduct of FD and FS is a re-

duction of the memory required to represent the data.

Both FD and FS are topics with a long re-

search history and a vast literature; regarding FD, see

(Dougherty et al., 1995), (Liu et al., 2002), (Witten

and Frank, 2005) for extensivereviews of many meth-

ods; regarding FS, see (Guyon et al., 2006), (Hastie

et al., 2009), and (Escolano et al., 2009) for compre-

hensive coverage and pointers to the literature.

1.1 Our Contribution

In this paper, we propose an unsupervised method for

static FD and a new method for dynamic FD. The dy-

namic discretization method uses a wrapper approach

with a quantizer and a classiﬁer, and can be cou-

pled with any static (unsupervised or supervised) dis-

cretization procedure. The dynamic method assesses

the performance of each feature as discretization is

carried out; if it is found that the original representa-

tion is preferable to the discretized one, the original

feature is kept.

The remaining text is organized as follows. Sec-

tion 2 reviews supervised and unsupervised FD and

FS techniques. Section 3 presents the proposed static

and dynamic methods for FD. Section 4 reports the

experimental evaluation of our methods in compari-

son with other techniques. Finally, Section 5 ends the

paper with some concluding remarks and directions

for future work.

103

Ferreira A. and Figueiredo M. (2012).

A DYNAMIC WRAPPER METHOD FOR FEATURE DISCRETIZATION AND SELECTION.

In Proceedings of the 1st International Conference on Pattern Recognition Applications and Methods, pages 103-112

DOI: 10.5220/0003788201030112

 SciTePress

2 BACKGROUND

This section brieﬂy reviews some of the most com-

mon unsupervised and supervised FD and FS tech-

niques that have proven effective for many learning

problems. This description is hugely far from be-

ing exhaustive, as FD and FS are two ﬁelds with

a long research history. The interested reader is

referred to the works of (Dougherty et al., 1995),

(Kotsiantis and Kanellopoulos, 2006), (Liu et al.,

2002), and (Witten and Frank, 2005), for re-

views of FD methods. Reviews of FS methods

were done by (Guyon and Elisseeff, 2003), (Guyon

et al., 2006), (Hastie et al., 2009), and (Escolano

et al., 2009); see also the following special issue:

jmlr.csail.mit.edu/papers/special/feature03.html.

2.1 Feature Discretization

FD can be performed in supervised or unsupervised

modes, i.e., using or not the class labels, and aims at

reducing the amount of memory as well as improv-

ing classiﬁcation accuracy (Witten and Frank, 2005).

The supervised mode may lead, in principle, to better

classiﬁers. In the context of unsupervised scalar FD

(Witten and Frank, 2005), two efﬁcient techniques are

commonly used:

. equal-interval binning (EIB), i.e., uniform quan-

tization with a given number of bits per feature;

. equal-frequency binning (EFB), i.e., non-uniform

quantization yielding intervals such that, for each

feature, the number of occurrences in each inter-

val is the same, leading to a uniform (i.e., maxi-

mum entropy) distribution; this technique is also

known as maximum entropy quantization.

In EIB, the range of values is divided into bins

of equal width. It is simple and easy to implement,

but it is very sensitive to outliers, thus may lead to

inadequate discrete representations. The EFB method

is less sensitive to outliers. The quantization intervals

have smaller width in regions where there are more

occurrences of the values of each feature.

Recently, we have proposed (Ferreira and

Figueiredo, 2011) an unsupervised scalar discretiza-

tion method, based on the well-known Linde-Buzo-

Gray (LBG) algorithm (Linde et al., 1980). The LBG

algorithm is applied individually to each feature and

stopped when the MSE distortion falls below a thresh-

old ∆ or when the maximum number of bits q per fea-

ture is reached (setting ∆ to 5% of the range of each

feature and q ∈ {4, . . . , 10} were found to be adequate

choices). That algorithm, named unsupervised LBG

(U-LBG 1), which produces a variable number of bits

per feature, has been shown to lead to better classiﬁ-

cation results than EFB on different kinds of (sparse

and dense) data (Ferreira and Figueiredo, 2011). The

key idea of using the LBG algorithm in this context

is that if we can represent a feature with low MSE,

we have a discrete version that approximates well the

continuous version of that feature, thus this represen-

tation should be adequate for learning. Algorithm 1

presents the U-LBG1 procedure.

Algorithm 1: U-LBG1.

Input: X, n× p matrix training set (p features, n patterns).

∆: maximum expected distortion.

q: the maximum number of bits per feature.

Output:

X: n× p matrix, discrete feature training set.

, ..., Q

: set of p quantizers (one per feature).

1: for i = 1 to p do

2: for b = 1 to q do

3: Apply the LBG algorithm to the i-th feature to

obtain a b-bit quantizer Q

(·);

4: Compute MSE

∑

j=1

− Q

))

;

5: if (MSE

≤ ∆ or b = q) then

6: Q

(·) = Q

(·); {/* Store the quantizer. */}

= Q

); {/* Quantize feature. */}

8: break; {/* Proceed to the next feature. */}

9: end if

10: end for

11: end for

It has been found that unsupervised FD methods

tend to perform well in conjunction with several clas-

siﬁers; in particular, the EFB method in conjunction

with na

ıve Bayes (NB) classiﬁcation produces very

good results (Witten and Frank, 2005). It has also

been found that applying FD with both EIB and EFB

to microarray data, in conjunction with support vec-

tor machine (SVM) classiﬁers, yields good results

(Meyer et al., 2008).

There are also many supervised approaches to fea-

ture discretization. (Fayyad and Irani, 1993) have ap-

plied an entropy minimization heuristic to choose the

cut points, and thus the discretization intervals. The

experimental results show that the proposed method

leads to the construction of better decision trees than

the previous methods. An efﬁcient FD algorithm

for use in the construction of Bayesian belief net-

works (BBN), was proposed by (Clarke and Barton,

2000). The partitioning minimizes the information

loss, relative to the number of intervals used to rep-

resent the variable. Partitioning can be done prior to

BBN construction or extended for repartitioning dur-

ing construction. A supervised static, global, incre-

mental, and top-down discretization algorithm based

on class-attribute contingency coefﬁcient was pro-

posed by (Tsai et al., 2008).

Very recently, a supervised discretization algo-

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

104

rithm based on correlation maximization (CM) was

proposed by (Zhu et al., 2011); it uses multiple cor-

respondence analysis (MCA) to capture correlations

between multiple variables. For each numeric fea-

ture, the correlation information obtained from MCA

is used to build the discretization algorithm that maxi-

mizes the correlations between feature intervals/items

and classes.

2.2 Feature Selection

In this subsection, we brieﬂy describe two FS meth-

ods that have prove successful in many problems. For

this reason, we have included them on the experimen-

tal evaluation of our methods.

The well-known (supervised) Fisher ratio (FiR)

(Furey et al., 2000) of each feature is deﬁned as

FiR



(−1)

−

(+1)



var(X

)

(−1)

+ var(X

)

(+1)

, (1)

where

(±1)

and var(X

)

(±1)

, are the mean and vari-

ance of feature i, for the patterns of each class. The

FiR measures how well each feature alone separates

the two classes.

The (supervised) minimum redundancy maximum

relevancy (mRMR) method of (Peng et al., 2005)

adopts a ﬁlter approach to the problem of FS, thus

being fast and applicable with any classiﬁer. The key

idea is to compute both the redundancy between fea-

tures and the relevance of each feature. The redun-

dancy is computed by the mutual information (MI)

(Cover and Thomas, 1991) between pairs of features,

whereas relevance is measured by the MI between

features and class label.

3 PROPOSED METHODS

This section presents our proposals for FD. Subsec-

tion 3.1 presents a static unsupervised FD method,

whereas Subsections 3.2 and 3.3 detail our dynamic

wrapper methods for FD and joint FS/FD, respec-

tively.

3.1 Static Discretization

We address static discretization with a new unsuper-

vised proposal. The ﬁrst new proposal for FD is

named U-LBG2, and it is a minor modiﬁcation of

previous method U-LBG1, described as Algorithm 1

in Subsection 2.1. The proposed modiﬁcation is to

use a ﬁxed, rather than variable, number of bits per

feature, q, according to the MSE distortion criterion.

This method exploits the same key idea as the pre-

vious one, that is, a discretization with a low MSE

will provide an accurate representation of each fea-

ture, being suited for learning purposes. Algorithm 2

describes the proposed U-LBG2 method.

Algorithm 2: U-LBG2.

Input: X, n× p matrix training set (p features, n patterns).

q: the maximum number of bits per feature.

Output:

X: n× p matrix, discrete feature training set.

, ..., Q

: set of p quantizers (all with q bits).

1: for i = 1 to p do

2: Apply the LBG algorithm to the i-th feature to ob-

tain a q-bit quantizer Q(·);

3: Q

(·) = Q(·); {/* Store the quantizer. */}

= Q

); {/* Quantize feature. */}

5: end for

As compared to U-LBG1 algorithm, the key dif-

ferences are: now we are using more bits, since each

discretized feature will be given the same (maximum)

number of bits q; only one quantizer is learned for

each feature. Both unsupervised LBG-based proce-

dures aim at obtaining quantizers that represent the

features with a small distortion. The proposed proce-

dures are more complex than either EIB or EFB, thus

may be expected to perform better.

3.2 Dynamic Discretization Wrapper

The key motivations to propose a wrapper dynamic

discretization method are as follows. This method,

by adopting a wrapper working mode in conjunction

with a classiﬁer, has higher complexity than a static

discretization method. However, it is expected that

the increased complexity pays off in the sense that

we should be able to choose a more adequate number

of bits per feature, as compared to static discretiza-

tion methods. As a consequence, we may hope to

attain better classiﬁcation accuracy with the dynam-

ically discretized features.

The proposed approach for dynamic discretization

relies on the use of a static unsupervised or supervised

FD algorithm (such as EIB, EFB, U-LBG1, or U-

LBG2) which is applied sequentially to the set of fea-

tures. The key idea is to discretize each feature with

an increasing number of bits and to evaluate how the

classiﬁcation accuracy evolves with the discretization

of each feature. The classiﬁcation accuracy is com-

pared against the accuracy obtained with the feature

in its original representation. The number of bits that

leads to the maximum accuracy is chosen to discretize

the feature.

Before giving the details of our algorithm, we

show some experimental results that motivate the de-

A DYNAMIC WRAPPER METHOD FOR FEATURE DISCRETIZATION AND SELECTION

105

5 10 15 20 25 30

Test error of each feature on WBCD with 4 bits

Feature

Err

Figure 1: Test set error rate of na¨ıve Bayes using only a

single feature, discretized with q = 4 bit by the U-LBG2

algorithm, on the WBCD dataset. The horizontal dashed

line is the test set error rate obtained with the full set of

p=30 features.

5 10 15 20 25 30

Test error of each feature on WBCD with 8 bits

Feature

Err

Figure 2: Test set error rate of na¨ıve Bayes using only a

single feature, discretized with q = 8 bit by the U-LBG2

algorithm, on the WBCD dataset. The horizontal dashed

line is the test set error rate obtained with the full set of

p=30 features.

tails of the method. Fig. 1 and Fig. 2 show the test

set error rate of each feature obtained for the WBCD

dataset using the na¨ıve Bayes classiﬁer, on discrete

features with the static U-LBG2 procedure with q = 4

and q = 8, respectively. We observe that the test set

error rates achieved individually by several features

are quite close to the error attained with the full set of

features (for example, features 8, 23, or 28 in Fig. 1).

Another interesting remark about Figs. 1 and 2 is that

increasing the number of bits per feature does not nec-

essarily lead to a decrease in the classiﬁcation error;

again, if we look into the individual test set error rates

of features 8, 23, and 28, now with q = 8 bits (Fig. 2),

we observe an increase in the test set error rates with

respect to q = 4 bits (Fig. 1).

In order to gain insight into how the test set er-

ror rate of each feature evolves during discretization,

we compare the test set error rate of each feature with

its U-LBG2 discretized version with q ∈ {1, . . . , 10}.

Fig. 3 and Fig. 4 show the test set error rate of fea-

tures 17 and 25, again with the na¨ıve Bayes classiﬁer,

respectively, for the WBCD dataset.

0 1 2 3 4 5 6 7 8 9 10

Error of feature 17 on WBCD

q (1 to 10) bits / feature ; 0 = Original feature

Err

Figure 3: Test set error rate of na¨ıve Bayes using solely

feature 17 of the WBCD dataset (original feature and U-

LBG2 discretized with q ∈ {1, . . . ,10}).

0 1 2 3 4 5 6 7 8 9 10

Error of feature 25 on WBCD

q (1 to 10) bits / feature ; 0 = Original feature

Err

Figure 4: Test set error rate of na¨ıve Bayes using solely

feature 25 of the WBCD dataset (original feature and U-

LBG2 discretized with q ∈ {1, . . . ,10}).

In the case of feature 17, discretization neverleads

to a lower test set error rate, as compared to the orig-

inal representation. On the other hand, for feature

25, the use of a larger number of bits leads to an im-

provement in the accuracy. These experimental re-

sults show typical situations that we observe with dif-

ferent types of data and depend on the statistics of

each feature, leading us to the following observations:

• some features are worth to be discretized up to

number of bits q;

• for other features, it is preferable not to discretize

them.

Algorithm 3 details our dynamic wrapper dis-

cretization (DWD) method. We use the following

notation: @class(X, y) denotes a function that learns

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

106

some classiﬁer (e.g., support vector machine, na

ıve

Bayes, K-nearest-neighbors) from the training set in

matrix X with labels y and returns the obtained er-

ror rate; @quant(·, b) denotes any of the unsupervised

(or supervised) scalar static discretization algorithms,

such as those mentioned above or any other, with b

bits. This algorithm performs its actions solely on the

training set portion of the data; it does not require the

existence of a separate hold-out test set.

Algorithm 3: DWD - Dynamic Wrapper Discretiza-

tion.

Input: X, n× p matrix training set (p features, n patterns).

y: n-length vector with class labels.

q: the maximum number of bits per feature.

@quant: a static discretizer.

@class: a supervised classiﬁer.

Output:

X: n× p matrix, discretized version on X.

, ..., Q

: set of p quantizers (one per feature).

1: for i = 1 to p do

2: err

← @class(X

, y): training error rate using only

the i−th feature;

3: for b

= 1 to q do

= @quant(X

, b

);

5: err

← @class(

, y);

6: end for

7: end for

8: Find b

= arg min

j∈{0,1,...,q}

err

, for i = 1,..., p.

9: for i = 1 to p do

10: if b

= 0 then

11:

= X

; {/* Don’t discretize the i-th feature */}

12: else

13: Q

(·) = @quant(·, b

); {/* Store quantizer*/}

14:

= Q

);

15: end if

16: end for

In line 2, @class provides the baseline error, that

is, the training error rate with the original represen-

tation of each feature. A similar idea is applied in

line 5, where the classiﬁer is applied to each dis-

cretized feature. Notice that if a discretized feature

never reaches a training error below the baseline, the

original representation is kept. We thus have a dy-

namic wrapper discretization procedure that produces

a hybrid dataset in the sense that it may contain both

discretized and non-discretized features. As a ﬁnal

note on DWD (Algorithm 3), notice that the for loop

in line 3 does not need to start at b

= 1; we can set

the minimum number of bits per feature to some small

value, such as 3 or 4, thus computing fewer quantizers

and performing fewer evaluations.

3.3 Optimized Dynamic Discretization

For medium to high-dimensional datasets, the pro-

posed DWD method, as detailed in Algorithm 3, be-

comes computationally demanding. The need dis-

cretize each feature several times, and evaluate the

correspondingclassiﬁcation accuracies, can make this

method prohibitive for higher dimensions (as it hap-

pens with many wrapper methods). The efﬁciency of

both the quantizer and the classiﬁer is a key point to

avoid this computational burden. In order to decrease

the running time of our DWD algorithm, we havecon-

sidered that:

• the evolution of the test set error rates shown in

Fig. 1 and Fig. 2 suggest that for some features

there is no improvement on the classiﬁcation per-

formance if we use a larger number of bits; more-

over, some (irrelevant) features will always lead

to low accuracy, regardless of the number of bits

we use for discretization;

• the results in Fig. 3 and Fig. 4, show that for some

features, there is no gain in discretizing them.

Combining these two ideas we propose the fol-

lowing optimization in order to delete the irrelevant

features as a pre-processing stage: after computing

the error of each feature, err

← @class(X

, y) in line

2 of Algorithm 3, we keep only a fraction η of the

top rank features. We thus avoid the discretization of

many irrelevant features, saving execution time while

simultaneously improving the classiﬁcation accuracy

and reducing the amount of memory needed to repre-

sent the dataset. This optimization can been seen as

wrapped FS process acting as a pre-processing stage

for the DWD algorithm; for this reason, we name

this optimized version of DWD as DWD-FS, being

a wrapper for both discretization and selection.

4 EXPERIMENTAL EVALUATION

This section reports experimental results obtained by

our FD techniques on several public domain datasets.

We use linear support vector machines (SVM), na

ıve

Bayes (NB), and K-nearest-neighbors (KNN) (with

K = 3) classiﬁers, implemented in the PRTools

tool-

box (Duin et al., 2007). We start by assessing the

behavior of static discretization methods in Subsec-

tion 4.1 and proceed to the analysis of the dynamic

discretization methods in Subsection 4.2. In Subsec-

tion 4.3, we perform a running time analysis of these

methods. Finally, in Subsection 4.4, we apply FS

methods on the original and on the discretized fea-

tures to check if the discrete features lead to an in-

crease in the classiﬁcation performance. The experi-

http://www.prtools.org/prtools.html

A DYNAMIC WRAPPER METHOD FOR FEATURE DISCRETIZATION AND SELECTION

107

Table 1: 11 UCI datasets and 5 microarray datasets used

in the experiments; p, c, and n are the number of features,

classes, and patterns, respectively.

Dataset Name p c n

Phoneme 5 2 5404

Pima 8 2 768

Abalone 8 2 4177

Contraceptve 9 2 1473

Wine 13 3 178

Hepatitis 19 2 155

WBCD 30 2 569

Ionosphere 34 2 351

SpamBase 54 2 4601

Lung 55 3 32

Arrhythmia 279 16 452

Colon 2000 2 62

SRBCT 2309 4 83

Lymphoma 4026 9 96

Leukemia 1 5327 3 72

9-Tumors 5726 9 60

ments were carried out on a common laptop computer

with 2.16 GHz CPU and 4 Gb of RAM.

Table 1 brieﬂy describes the public domain bench-

mark datasets from the UCI Repository (Frank and

Asuncion, 2010) that were used in our experiments.

We chose several well-known datasets with different

kinds of data. We have also included public domain

microarray gene expression datasets

4.1 Analysis of Static Discretization

Fig. 5 shows the typical MSE decay obtained by the

U-LBG1 algorithm using up to q = 10 bits, when dis-

cretizing features 1 and 18 of the Hepatitis dataset.

This plot shows that even for features that start with a

high distortion (with a single bit), the MSE drops fast

(roughly exponentially fast).

Table 2 shows a comparison of three static FD

methods, namely EFB, U-LBG1, and U-LBG2 for

some standard datasets, using up to q = 7 bits. The

EIB method is not considered here, since it usually

attains poorer performance than the EFB method. For

each FD method, we show the average test set error

rate of the na¨ıve Bayes classiﬁer for ten runs with dif-

ferent training/test replications and the total number

of bits allocated for the set of quantizers. Table 3

shows a similar set of results, using linear SVM clas-

siﬁers. Comparing the results in Table 2 and Table 3,

we see that on these datasets, the linear SVM classi-

ﬁers attain better results than the na¨ıve Bayes classi-

ﬁers. In some cases, the linear SVM classiﬁers attains

better performance on the original features than on the

discretized ones. The EFB method has good results,

http://www.gems-system.org/

1 2 3 4 5 6 7 8 9 10

100

150

200

250

q (1 to 10) bits

MSE

MSE distortion on Hepatitis by U−LBG1

Feature 1

Feature 18

Figure 5: MSE evolution as a function of the number of bits

q ∈ {1, . . . , 10}, for the features 1 and 18 of the Hepatitis

dataset, using the U-LBG1 algorithm.

despite its simplicity; however, on microarray data

which we have a large number of features and a small

number of patterns (large p, small n) as well as multi-

class problems, the U-LBG methods tend to perform

better. Moreover, on the micoarray datasets, the na¨ıve

Bayes classiﬁer performs poorly, so we don’t even re-

port those results.

4.2 Dynamic Discretization

We now compare static discretization versus DWD

and its optimized version DWD-FS, as described in

Subsection 3.3. Table 4 shows a comparison of the

static FD methods, EFB and U-LBG1 with their dy-

namic versions incorporated into our DWD method

(Algorithm 2), with linear SVM classiﬁers for wrap-

ping and evaluation.

The results in Table 4 suggest that the DWD

method tends to produce better results for datasets

with higher number of features. For low-dimensional

datasets, (roughly with p < 20), the additional com-

plexity of the dynamic wrapper method does not lead

to better results as compared to the static versions.

The DWD method tends to produce discrete repre-

sentations with a smaller number of bits, as compared

to the static counterparts. For the higher-dimensional

datasets in Table 4, the use of the DWD algorithm

generally improves the performance of the wrapper

static discretizer for both EFB an U-LBG1. The

Phoneme and Abalone datasets exhibit a behavior

such that the use of the original features is preferable;

none of the static or dynamic versions attains better

results.

Table 5 shows the test results of static, DWD, and

DWD-FS U-LBG2 discretization with q = 7 bits. For

the DWD-FS algorithm we keep the percentage η of

the top rank features; the choice of η leads to select m

features. In these tests, we use the KNN classiﬁer.

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

108

Table 2: Total number of bits per pattern (T. Bits) and Test Set Error Rate (Err, average of ten runs, with different random

training/test partitions) for the static discretization methods, with up to q = 7 bits, using the na¨ıve Bayes classiﬁer. The best

test set error rate is in bold face (in case of a tie, the best is considered the one with fewer bits).

EFB U-LBG1 U-LBG2

Dataset Original Err T. Bits Err T. Bits Err T. Bits Err

Phoneme 21.30 30 22.30 9 22.80 30 20.60

Pima 25.30 48 25.20 30 25.20 48 25.80

Abalone 28.00 48 27.60 15 27.20 48 27.70

Contraceptive 34.80 54 31.40 15 38.00 54 34.80

Wine 3.73 78 4.80 27 3.20 78 3.20

Hepatitis 20.50 95 21.50 32 21.00 39 18.00

WBCD 5.87 180 5.13 60 5.87 180 5.67

Ionosphere 10.60 198 9.80 49 17.40 198 11.00

SpamBase 15.27 324 13.40 54 15.73 324 15.67

Lung 35.00 318 35.00 74 35.83 318 35.00

Arrhythmia 32.00 1392 51.56 553 30.22 1392 41.56

Table 3: Total number of bits per pattern (T. Bits) and Test Set Error Rate (Err, average of ten runs, with different random

training/test partitions) for the static discretization methods, with up to q = 7 bits, using the linear SVM classiﬁer. The best

test set error rate is in bold face (in case of a tie, the best is considered the one with less bits).

EFB U-LBG1 U-LBG2

Dataset Original Err T. Bits Err T. Bits Err T. Bits Err

Phoneme 22.60 30 24.00 8 21.80 30 22.70

Pima 27.50 48 28.50 27 29.30 48 27.60

Abalone 24.30 48 23.20 16 27.80 48 23.70

Contraceptive 36.50 54 34.60 15 39.80 54 37.20

Wine 4.80 78 1.87 25 5.33 78 1.33

Hepatitis 14.50 114 16.00 33 16.00 114 13.00

WBCD 4.67 180 3.07 59 2.80 180 2.80

Ionosphere 16.60 198 19.60 43 13.80 198 16.00

SpamBase 12.93 324 16.73 54 20.40 324 18.53

Lung 18.33 330 17.50 85 19.17 330 20.83

Arrhythmia 33.33 1392 31.78 550 32.89 1392 33.33

Colon 14.44 12000 11.11 9723 12.78 12000 10.56

SRBCT 0.00 13848 0.53 2793 0.20 13848 0.37

Lymphoma 0.57 24156 0.57 5910 0.00 24156 0.57

Leukemia1 11.43 26635 10.48 24306 5.71 26635 7.62

9-Tumors 22.22 28630 14.67 24906 12.00 28630 14.22

Table 4: Total number of bits per pattern (T. Bits) and Test Set Error Rate (Err, average of ten runs, with different random

training/test partitions) for the static and dynamic discretization methods for EFB and U-LBG1, with up to q = 7 bits, using

linear SVMs. The best test set error rate is in bold face (in case of a tie, the best is considered the one with fewer bits).

Static DWD Algorithm

EFB U-LBG1 EFB U-LBG1

Dataset Original Err T. Bits Err T. Bits Err T. Bits Err T. Bits Err

Phoneme 21.17 35 23.33 8 23.33 29 24.33 7 21.50

Pima 27.67 56 27.33 28 28.67 28 26.83 25 28.50

Abalone 23.00 56 24.67 16 27.67 26 25.33 13 26.00

Contraceptive 34.00 63 31.67 15 36.67 22 34.50 14 34.00

Wine 2.40 65 0.53 25 4.27 55 1.60 20 1.87

Hepatitis 20.50 95 21.50 32 21.00 39 18.00 29 19.00

WBCD 4.22 210 3.22 59 2.11 125 2.78 52 4.56

Ionosphere 13.40 165 20.00 43 13.00 126 18.40 40 12.40

SpamBase 14.20 260 15.87 52 17.73 82 11.87 52 14.20

Lung 22.22 371 23.61 76 25.00 81 22.22 65 22.22

These results show the adequacy of the DWD-FS

algorithm as compared to the other two. In the major-

ity of these tests, it attains the lowest test set error rate

using fewer features and fewer bits per feature; it thus

A DYNAMIC WRAPPER METHOD FOR FEATURE DISCRETIZATION AND SELECTION

109

Table 5: Total number of bits per pattern (T. Bits) and Test Set Error Rate (Err, average of ten runs, with different random

training/test partitions) for the static, DWD, and DWD-FS discretization methods for U-LBG2, with up to q = 7 bits, using

the KNN (K = 3) classiﬁer. η is the percentage of the top rank features and m is the average number of features for the ten

runs. The best test set error rate is in bold face (in case of a tie, the best is considered the one with less bits).

Static U-LBG2 DWD U-LBG2 DWD-FS U-LBG2

Dataset Original Err T. Bits Err T. Bits Err η m T. Bits Err

Phoneme 22.15 35 22.35 35 22.15 0.8 4.0 28 21.90

Pima 26.10 56 26.10 50 26.00 0.8 6.0 40 27.00

Abalone 26.20 56 24.60 49 26.50 0.8 6.0 42 24.20

Contraceptive 44.60 63 45.30 13 45.50 0.8 7.0 11 43.60

Wine 27.20 91 6.13 84 14.67 0.8 10.0 65 12.27

Hepatitis 29.50 133 29.00 42 30.00 0.8 15.0 38 29.50

WBCD 7.07 210 3.93 209 6.93 0.8 24.0 167 3.80

Ionosphere 18.40 231 18.80 215 16.00 0.8 26.0 174 20.80

SpamBase 16.07 378 17.20 186 23.00 0.8 42.4 169 26.47

Lung 23.33 378 28.33 63 24.17 0.8 42.8 52 22.50

Table 6: Total time (in seconds) taken to discretize features

by the three static FD methods, namely EFB, U-LBG1, and

U-LBG2, using up to q = 7 bits. The fastest discretization

method is in bold face.

Dataset EFB U-LBG1 U-LBG2

Phoneme 0.20 0.27 0.79

Wine 0.09 0.05 0.14

Hepatitis 0.10 0.05 0.10

WBCD 0.24 0.29 0.86

SpamBase 0.32 0.07 0.40

Arrhythmia 1.23 0.96 1.55

Colon 11.66 21.81 18.12

SRBCT 32.60 23.57 52.57

Lymphoma 32.17 18.72 49.25

Leukemia 1 31.56 47.39 38.74

9-Tumors 43.49 64.85 55.77

leads to an improvement on the results of the KNN

classiﬁer on both the original and U-LBG2 features.

The only test in which there are no beneﬁts from the

discretization is on the sparse data SpamBase dataset;

in this case, the original features are preferable for the

KNN classiﬁer.

4.3 Running Time Analysis

Table 6 shows a comparison of the time taken to dis-

cretize features by the three static FD methods, EFB,

U-LBG1, and U-LBG2, using up to q = 7 bits. The

U-LBG1 (Algorithm 1) also uses ∆ = 0.05range(X

These results show that the EFB and U-LBG2 tend

to take roughly the same time, allocating a maximum

of q bits per feature. The U-LBG1 algorithm usually

is faster since it stops before reaching the maximum

q bits; in fact, many features are discretized with a

number of bits much smaller than q.

Table 7 shows a similar comparison of the time

taken to discretize features by the DWD and DWD-

FS methods (with η = 0.8) using EFB discretization

and na¨ıve Bayes classiﬁer, using up to q = 7 bits. The

Table 7: Time (in seconds) taken to discretize features by

EFB, DWD and DWD-FS methods (wrapped with EFB dis-

cretization and na¨ıve Bayes classiﬁer), using up to q = 7

bits. We show the average time for ten runs.

Dataset EFB DWD EFB DWD-FS EFB

Phoneme 0.04 1.94 3.04

Wine 0.10 5.30 6.97

Hepatitis 0.09 7.01 9.80

WBCD 0.20 11.40 21.94

SpamBase 0.34 19.92 28.13

Arrhythmia 1.26 141.27 175.56

Colon 12.11 725.51 962.57

SRBCT 33.95 1270.97 1621.65

dynamic versions take much more time than the static

version. The choice of the classiﬁer also inﬂuences

the time taken for the discretization. For medium to

high-dimensionaldatasets (p > 200), the implementa-

tions (without optimizations) of DWD and DWD-FS

are too time-consuming for practical applications.

4.4 Leveraging Feature Selection

In order to asses the quality (informativeness) of the

discretized features, we run a few tests using FS on

the original and on the discretized features. The key

idea of these tests is to show how the use of FS on the

discretized features can have beneﬁts, as compared to

the original ones.

In Fig. 6, we report na¨ıve Bayes classiﬁer test set

error rates with the features selected by the mrMR

method; we compare the original features with the

discretized versions obtained with the static and dy-

namic U-LBG1 methods. We observe that the use

discretized features seems to help the FS criterion,

since lower test error rates are achieved when com-

pared with the original ones.

In Fig. 7 and Fig. 8, we report na¨ıve Bayes test

set error rates with the features selected by the FiR

method, for the Hepatitis and the Ionosphere datasets,

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

110

5 10 15 20 25 30

m (# features)

Test set error rate on WBCD

Baseline

Original + mrMR

U−LBG1 Static + mrMR

U−LBG1 DWD + mrMR

Figure 6: Test set error rate (average of ten runs, with dif-

ferent training/test partitions), as functions of the number

of features, for the na¨ıve Bayes classiﬁer, using FS by the

mrMR method, for the WBCD dataset on original, static,

and dynamically discretized features.

6 8 10 12 14 16 18

m (# features)

Error [%]

Test set error rate on Hepatitis

Baseline

Original + FiR

EFB Static + FiR

EFB DWD + FiR

Figure 7: Test set error rate (average of ten runs, with dif-

ferent training/test partitions), as functions of the number

of features, for the na¨ıve Bayes classiﬁer, using FS by the

FiR method, for the Hepatitis dataset on original, static, and

dynamically discretized features.

respectively; we compare the original features with

the discretized versions obtained with the static and

dynamic EFB methods. For both datasets, the dis-

crete features are more adequate for FS as compared

to the original features.

5 CONCLUSIONS

In this paper, we have proposed static and dynamic

methods for feature discretization (FD). The static

method is unsupervised and the dynamic method uses

a wrapper approach with a quantizer and a classiﬁer,

and it can be coupled with any static unsupervised (or

supervised) discretization procedure. The key idea of

the dynamic method is to assess the performance of

5 10 15 20 25 30

12.5

13.5

14.5

15.5

m (# features)

Error [%]

Test set error rate on Ionosphere

Baseline

Original + FiR

EFB Static + FiR

EFB DWD + FiR

Figure 8: Test set error rate (average of ten runs, with dif-

ferent training/test partitions), as functions of the number of

features, for the na¨ıve Bayes classiﬁer, using FS by the FiR

method, for the Ionosphere dataset on original, static, and

dynamically discretized features.

each feature as discretization is carried out; if the orig-

inal representation is preferable to the discrete fea-

ture, then it is kept. An optimized version of this dy-

namic method uses a pre-processing stage which con-

sists in a wrapper feature selection process.

The proposed methods, equally applicable to bi-

nary and multi-class problems, attain efﬁcient repre-

sentations, suitable for learning problems. Our exper-

imental results, on public-domain datasets with dif-

ferent types of data, show the competitiveness of our

techniques when compared with previous approaches.

The use of the features discretized by our methods

lead to better accuracy than using the original or dis-

cretized features by other methods.

As future work, we plan to optimize the imple-

mentation of our dynamic discretization method, and

to devise its ﬁlter version, suitable to tackle dynamic

discretization on (very) high-dimensional datasets.

REFERENCES

Clarke, E. and Barton, B. (2000). Entropy and MDL dis-

cretization of continuous variables for Bayesian be-

lief networks. International Journal of Intelligent Sys-

tems, 15(1):61–92.

Cover, T. and Thomas, J. (1991). Elements of Information

Theory. John Wiley & Sons.

Dougherty, J., Kohavi, R., and Sahami, M. (1995). Super-

vised and unsupervised discretization of continuous

features. In International Conference Machine Learn-

ing — ICML’95, pages 194–202. Morgan Kaufmann.

Duin, R., Juszczak, P., Paclik, P., Pekalska, E., Ridder, D.,

Tax, D., and Verzakov, S. (2007). PRTools4.1: A Mat-

lab Toolbox for Pattern Recognition. Technical report,

Delft Univ. Technology.

A DYNAMIC WRAPPER METHOD FOR FEATURE DISCRETIZATION AND SELECTION

111

Escolano, F., Suau, P., and Bonev, B. (2009). Information

Theory in Computer Vision and Pattern Recognition.

Springer.

Fayyad, U. and Irani, K. (1993). Multi-interval discretiza-

tion of continuous-valued attributes for classiﬁcation

learning. In Proceedings of the International Joint

Conference on Uncertainty in AI, pages 1022–1027.

Ferreira, A. and Figueiredo, M. (2011). Unsupervised joint

feature discretization and selection. In 5th Iberian

Conference on Pattern Recognition and Image Analy-

sis - IbPRIA2011, pages 200–207, Las Palmas, Spain.

Frank, A. and Asuncion, A. (2010). UCI machine learning

repository, available at http://archive.ics.uci.edu/ml.

Furey, T., Cristianini, N., Duffy, N., Bednarski, D., Schum-

mer, M., and Haussler, D. (2000). Support vector

machine classiﬁcation and validation of cancer tissue

samples using microarray expression data. Bioinfor-

matics, 16(10):906–914.

Guyon, I. and Elisseeff, A. (2003). An introduction to vari-

able and feature selection. Journal of Machine Learn-

ing Research, 3:1157–1182.

Guyon, I., Gunn, S., Nikravesh, M., and Zadeh (Editors), L.

(2006). Feature Extraction, Foundations and Applica-

tions. Springer.

Hastie, T., Tibshirani, R., and Friedman, J. (2009). The El-

ements of Statistical Learning. Springer, 2nd edition.

Kotsiantis, S. and Kanellopoulos, D. (2006). Discretization

techniques: A recent survey. GESTS International

Transactions on Computer Science and Engineering,

32(1).

Linde, Y., Buzo, A., and Gray, R. (1980). An algorithm for

vector quantizer design. IEEE Trans. on Communica-

tions, 28:84–94.

Liu, H., Hussain, F., Tan, C., and Dash, M. (2002). Dis-

cretization: An Enabling Technique. Data Mining and

Knowledge Discovery, 6(4):393–423.

Meyer, P., Schretter, C., and Bontempi, G. (2008).

Information-theoretic feature selection in microarray

data using variable complementarity. IEEE Journal

of Selected Topics in Signal Processing (Special Is-

sue on Genomic and Proteomic Signal Processing),

2(3):261–274.

Peng, H., Long, F., and Ding, C. (2005). Feature selec-

tion based on mutual information: Criteria of max-

dependency, max-relevance, and min-redundancy.

IEEE Transactions on Pattern Analysis and Machine

Intelligence, 27(8):1226–1238.

Tsai, C.-J., Lee, C.-I., and Yang, W.-P. (2008). A dis-

cretization algorithm based on class-attribute contin-

gency coefﬁcient. Inf. Sci., 178:714–731.

Witten, I. and Frank, E. (2005). Data Mining: Practical

Machine Learning Tools and Techniques. Elsevier,

Morgan Kauffmann, 2nd edition.

Yu, L., Liu, H., and Guyon, I. (2004). Efﬁcient feature

selection via analysis of relevance and redundancy.

Journal of Machine Learning Research, 5:1205–1224.

Zhu, Q., Lin, L., Shyu, M., and Chen, S. (2011). Effective

supervised discretization for classiﬁcation based on

correlation maximization. In IEEE International Con-

ference on Information Reuse and Integration (IRI),

pages 390–395, Las Vegas, Nevada, USA.

ICPRAM 2012 - International Conference on Pattern Recognition Applications and Methods

112
