SEMI-SUPERVISED LEARNING OF ALTERNATIVELY SPLICED

EXONS USING EXPECTATION MAXIMIZATION TYPE

APPROACHES

Ana Stanescu and Doina Caragea

Computing and Information Sciences, Kansas State University, Manhattan, KS, U.S.A.

Keywords:

Semi-supervised learning, Expectation maximization, Alternative splicing.

Abstract:

Successful advances in DNA sequencing technologies have made it possible to obtain tremendous amounts

of data fast and inexpensively. As a consequence, the afferent genome annotation has become the bottleneck

in our understanding of genes and their functions. Traditionally, data from biological domains have been an-

alyzed using supervised learning techniques. However, given the large amounts of unlabeled genomics data

available, together with small amounts of labeled data, the use of semi-supervised learning algorithms is de-

sirable. Our purpose is to study the applicability of semi-supervised learning frameworks to DNA prediction

problems, with focus on alternative splicing, a natural biological process that contributes to protein diversity.

More speciﬁcally, we address the problem of predicting alternatively spliced exons. To utilize the unlabeled

data, we train classiﬁers via the Expectation Maximization method and variants of this method. The experi-

ments conducted show an increase in the quality of the prediction models when unlabeled data is used in the

training phase, as compared to supervised prediction models which do not make use of the unlabeled data.

1 INTRODUCTION

Over the last decade, major advancements in the next

generation sequencing technologies have led to an un-

precedented growth in the volume of biological data,

which is now acquired with high speed and low costs.

As the emphasis progressively switches from data

generation to data interpretation (Baldi and Brunak,

2001), the annotation process relies more and more on

automated systems. Many genome annotation tasks

can be formalized as supervised classiﬁcation prob-

lems where a learning classiﬁer system is trained to

produce the best prediction: it learns from observed

instances (a.k.a., labeled data) to make predictions re-

garding new unseen instances (a.k.a., unlabeled data).

For example, labeled instances such as recognized

splice sites, or laboratory established protein func-

tions, can be used to train the classiﬁer, which is sub-

sequently used to categorize new instances for which

such information is still unknown.

Supervised machine learning techniques have

been successfully used for many problems in the ﬁeld

of bioinformatics (Zhang and Rajapakse, 2009) but

their effectiveness relies on the availability of labeled

data in large amounts. Obtaining labeled data remains

a barrier, as it is a slow and expensive process, which

usually requires human effort, while large amounts

of unlabeled instances are easily available. A branch

of machine learning, called semi-supervised learning

(SSL), advocates the use of unlabeled data to improve

classiﬁers learned from small amounts of labeled data

only when large amounts of unlabeled data are avail-

able. SSL approaches have shown great potential in

various domains, such as text (Nigam et al., 2000;

Dai et al., 2007) and image classiﬁcation (Rosenberg

et al., 2005), sentiment categorization (Goldberg and

Zhu, 2006), natural language processing (Collins and

Singer, 1999), yet have not been applied to a great

extent in bioinformatics, where most prominent ex-

ceptions are related to protein analyses (Weston et al.,

2006; Kall et al., 2007). The aim of this study is to

evaluate the suitability of SSL techniques for DNA

sequence classiﬁcation, with focus on predicting al-

ternative splicing events.

Alternative (or differential) splicing was ﬁrst ob-

served in the late 1970’s (Chow et al., 1977) and

was speculated to be an exceptional occurrence.

Since then, due to its omnipresence in all eukaryotic

genomes (Black, 2003), it has been acknowledged as

a natural phenomenon: if its pre-mRNA is alterna-

tively spliced, a gene can encode more than one pro-

tein. Alternative splicing usually takes place after

240

Stanescu A. and Caragea D..

SEMI-SUPERVISED LEARNING OF ALTERNATIVELY SPLICED EXONS USING EXPECTATION MAXIMIZATION TYPE APPROACHES.

DOI: 10.5220/0003791802400245

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2012), pages 240-245

ISBN: 978-989-8425-90-4

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

transcription (of the pre-messenger RNA from DNA)

and right before mRNA translation, giving rise to sev-

eral transcripts (or splice variants), which in turn en-

code different polypeptides, making a gene highly ef-

ﬁcient with respect to the proteome formation.

There are a few manifestations of this phe-

nomenon, some in which exons are spliced out and

others where introns are retained. Our study is fo-

cused on the prediction of alternatively spliced ex-

ons. Exons that are not alternatively spliced are called

constitutive. Thus, we will address the task of dis-

criminating between alternatively spliced exons and

constitutive exons by representing this task as a bi-

nary (yes/no) classiﬁcation problem. We learn prob-

abilistic label Na

ıve Bayes (Nigam et al., 2000) and

Support Vector Machine (SVM) (Vapnik, 1995) clas-

siﬁers from a combination of labeled and unlabeled

data sets using expectation maximization type ap-

proaches in a semi-supervised framework. The main

contribution of our work is experimental and it shows

that semi-supervised approaches, which employ the

expectation maximization technique, are effective at

exploiting the unlabeled biological data.

2 RELATED WORK

The Expectation Maximization technique (EM) origi-

nates from statistics and was later formalized (Demp-

ster et al., 1977) as an iterative algorithm for maxi-

mum likelihood estimation. Its applicability to learn-

ing probability distributions and capability of utiliz-

ing sufﬁciently large amounts of unlabeled data in or-

der to build and improve upon a model makes it a very

powerful technique which has gained a lot of popu-

larity in the ﬁeld of machine learning. It has been

shown to perform well in text classiﬁcation problems

(Nigam et al., 2000). In biological and medical do-

mains, the EM has been used for modeling data for

creating protein proﬁles (Nesvizhskii et al., 2003),

for ﬁnding motifs within sequences (Lawrence and

Reilly, 1990), for image reconstruction through clus-

tering (Lawrence and Reilly, 1990), etc. More re-

cently, in machine learning applications, it has been

found very useful in semi-supervised frameworks, for

text classiﬁcation (Nigam et al., 2000), audio catego-

rization tasks (Moreno and Agarwal, 2003), and im-

age retrieval (Dong and Bhanu, 2003).

Among others, a semi-supervised approach us-

ing EM and Na

ıve Bayes with Probabilistic Labels

was proposed by Nigam et al. (2000) in the context

of text classiﬁcation. Their results on three differ-

ent text corpora show dramatic improvements when

large amounts of unlabeled data are used together

with small amounts of labeled data. We will study

this algorithm and some of its variants in the context

of predicting alternatively spliced exons.

Given our application problem, work on identify-

ing alternatively spliced exons in genomic sequences

is also relevant to the work presented. Tradition-

ally, this type of problem has been solved by con-

ducting wet-lab experiments. As lab work is very

tedious, computational methods which use the align-

ment of Expressed Sequence Tags (EST) to genome

have emerged (Nagaraj et al., 2007). More recently,

prediction of alternative splicing has been the focus of

machine learning research work which makes use of

Support Vector Machines (Dror et al., 2005; Ratsch

et al., 2005) to produce fast and accurate classiﬁers.

Specialized kernels that model similarities between

sequences are used in these studies.

To the best of our knowledge, SSL techniques

using the EM algorithm have not been applied to

the problem of predicting alternatively spliced exons.

The work presented in this paper shows that these

types of approaches constitute a promising direction.

3 DATA AND FEATURES

The dataset used in our experiments is made avail-

able online by the Friedrich Miescher Laboratory of

the Max Planck Society (T

ubingen, Germany), at

the URL: http://www.fml.tuebingen.mpg.de/raetsch/

suppl/RASE/data sets. It contains 3018 DNA se-

quences from the nematode C. elegans. Each com-

prising one exon along with its left and right ﬂank-

ing introns. In short, R

atsch et al. generated these

instances by aligning expressed sequence tags (EST)

against genomic DNA. This modus operandi pro-

duced 2531 constitutive exons and 487 alternatively

spliced exons. The data set has been previously used

by the aforementioned authors in the context of super-

vised learning (Ratsch et al., 2005).

It is known that regulatory elements located both

in introns or exons can inﬂuence alternative splic-

ing (Chasin, 2007). Such regulatory sequences can

be identiﬁed as motifs. In biology, a motif is usu-

ally deﬁned as a short and widespread nucleotide

(or amino-acids) sequence pattern that captures some

commonalities between related sequences, thus hav-

ing a prevalent biological signiﬁcance. We consider

both intronic motifs (a.k.a., intronic regulatory se-

quences) and exonic motifs (a.k.a., exonic splicing

enhancers) to represent our instances as feature vec-

tors. More precisely, we convert each sequence into

a vector, where each dimension corresponds to a mo-

tif, and each value is given by the motif’s frequency

SEMI-SUPERVISED LEARNING OF ALTERNATIVELY SPLICED EXONS USING EXPECTATION

MAXIMIZATION TYPE APPROACHES

241

(count). It is also known that the lengths of an exon

and its ﬂanking introns are discriminative (Dror et al.,

2005) with respect to the problem of predicting if the

exon is alternatively spliced or constitutive. Thus, an

additional set of features used in our work are ob-

tained from lengths.

For our ﬁrst set of features, we use the Intronic

Regulatory Sequences (IRS) established by compara-

tive genomics in Nematodes by Kabat et al. Brieﬂy,

the introns that ﬂank alternatively spliced exons show

evidence of high nucleotide preservation, leading to

the identiﬁcation of similar k-mers between C. ele-

gans and C. briggsae. Kabat et al. (2006) provide

the description of conserved and non-conserved pen-

tamers and hexamers from the upstream and down-

stream introns. Among these, 165 motifs are iden-

tiﬁed in our sequences (using simply scanning) and

therefore used as a feature set subsequently.

The second feature set was obtained using the

method from (Pertea et al., 2007). It consists of 45

Exonic Splicing Enhancers (ESEs). ESEs direct or

enhance accurate splicing of pre-mRNA into messen-

ger RNA; they are usually 6 nucleotides long.

We used the length features (LF) from (Ratsch

et al., 2005). Speciﬁcally, the length of each up-

stream intron, exon and downstream intron (of ev-

ery sequence in the set), was used to generate 30-

dimensional logarithmically spaced vectors, for a to-

tal of 90 features per instance (corresponding to the 3

lengths). Within the same group, we also included a

set of 3D vectors characterizing the frame of the stop

codon (which together results in 15 more features).

Ultimately, we have 315 features based on motifs,

length and frame of the stop codon. The labels of the

instances were not used when generating features.

4 APPROACHES

EM is a probabilistic algorithm which allows the

learning of a model in the presence of missing data,

through iterative parameter estimation. The EM algo-

rithm consists of two steps: (1) The Expectation step,

to ﬁll in the missing data: in our context, the class la-

bels of the unlabeled data, and (2) the Maximization

step, to calculate a maximum a posteriori estimate for

the model parameters.

In a semi-supervised setup, EM can be put into

practice as follows: a classiﬁer is initially trained

with just the labeled data (1). It is then used to clas-

sify the unlabeled data (2). Next, all the data (i.e.,

originally labeled data along with newly classiﬁed in-

stances from the unlabeled set) is used to train a new

classiﬁer (3). Steps 2 and 3 iterate until convergence.

Although EM might look like a heuristic method,

it does have a rigorous foundation. It is guaranteed to

ﬁnd a local optimum of data likelihood (Wu, 1983).

In this paper, for the problem of predicting alternative

splicing in a semi-supervised mode, we ﬁrst use the

EM technique with a generative model as base classi-

ﬁer, namely Na

ıve Bayes (Nigam et al., 2000). Sec-

ond, we also explore EM with a discriminative ap-

proach, Support Vector Machines (SVM), as the base

classiﬁer (Brefeld and Scheffer, 2004).

4.1 SSL using EM and NBM

As described above, the usage of EM in a semi-

supervised framework assumes that a classiﬁer is ﬁrst

learned from the originally labeled data. Given that

our data has partly a motif count representation, we

learn a Na

ıve Bayes Multinomial (NBM) classiﬁer

from the motif representation of the labeled data.

Note that we use the multinomial model to capture

the frequency of a motif, rather than just its pres-

ence or absence, which would require a multi-variate

Bernoulli event model (McCallum and Nigam, 1998).

Following the notation from (Nigam et al., 2000), we

use θ to denote the model parameters and D to rep-

resent the data. Learning the model is equivalent to

ﬁnding θ that maximizes the log of the posterior prob-

ability P(θ|D). This is equivalent to ﬁnding θ that

maximizes log[P(θ) · P(D|θ)]. Next, we use the re-

sulting model to soft-label the instances in the unla-

beled set by assigning them probabilistic class labels.

For each instance in the unlabeled data set we get a

probability distribution over the two classes and use

this distribution to compute fractional counts, mean-

ing that the actual counts in a class are proportional to

the corresponding class probability of that example.

With this new model, we re-label the unlabeled

sequences. This process can be repeated for a ﬁxed

number of steps or until convergence, i.e., the la-

bels from one iteration are very similar to the ones

in the previous iteration. One variation of the EM ap-

proach can be obtained by assigning different weights

to the labeled and unlabeled instances when learning

the NBM (Nigam et al., 2000). This can be achieved

by introducing a new weighting factor which controls

the weight of each newly classiﬁed unlabeled exam-

ple, thus adjusting (decreasing) the inﬂuence of the

unlabeled data over the model and granting more au-

thority to the labeled examples. For this model we use

the formula from (Nigam et al., 2000) where z

i j

is 0

or 1 for the labeled instances (depending on their ac-

tual class) or P(c

) for the unlabeled instances and

C is the set of classes – in our case, positive (1) or

negative (0) – and d

an instance in the labeled data

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

242

set D; when w = 1, the algorithm is identical to the

one described previously:

log(P(θ)) +

∑

∈D

|C|

∑

j=1

i j

log(P(c

|θ)P(d

;θ))

+w(

∑

∈D

|C|

∑

j=1

i j

log(P(c

|θ)P(d

;θ))) (1)

Another popular SSL algorithm is self-training

(aka self-teaching or bootstrapping). It was intro-

duced in (Yarowsky, 1995) where it was used success-

fully in a natural language processing problem. Char-

acterized as a hybrid between EM and Co-Training

(Nigam and Ghani, 2000), it can be used with any

base-classiﬁer to pull more training cases from the

unlabeled set. However, unlike EM which uses all

predictions to update the parameters of its model,

self-training only uses the best predictions at each

round and disregards the instances which are labeled

with low conﬁdence. Unlike Co-Training (Blum and

Mitchell, 1998), it is a single-view learning algorithm.

An important condition is to maintain the ratio of pos-

itive to negative examples across datasets.

4.2 SSL using EM with SVM

Support Vector Machines (SVM) represent a rela-

tively recent family of supervised learning methods

that can be applied to binary classiﬁcation problems,

generally yielding very accurate results. Given their

popularity, we also use SVM as a base classiﬁer in

the above described EM procedure, with a Gaussian

kernel and an error cost C = 0.5. Just like in the case

of NBM, we use the weighting scheme for SVM as

well. Each newly classiﬁed instance from the un-

labeled data set is further used in retraining with a

weight coefﬁcient w. We denote each experiment by

NBMemW(w) and SVMemW(w), where the weight

w ∈ {0.01, 0.1, 0.25, 0.3, 0.5, 0.75}. The self-training

implementation is similar to the one using NBM de-

scribed in Section 4.1. They are indicated as NBM-

self(s,i) and SVMself(s,i) where s is the sample size

and i is the number of iterations.

5 EXPERIMENTAL SETUP

An objective evaluation of any predictive model re-

quires the use of the cross validation technique. To

estimate how well our classiﬁers will generalize to

new data, and to maintain the trend set by (Ratsch

et al., 2005), we employed 5-fold cross validation.

We then split the training set into labeled and unla-

beled subsets of different sizes. The unlabeled sub-

set was simply obtained by intentionally ignoring the

label information. Given that our data is skewed

– we have approximately ﬁve times more instances

labeled as ”constitutive” than we do ”alternatively

spliced”, and so measuring the accuracy of the pre-

dictions would not reﬂect the true value of our clas-

siﬁer (Provost et al., 1998), we have reported the

performance in terms of area under the ROC curve

(AUC)(Huang and Ling, 2005).

In order to assess the behavior of our SSL al-

gorithms, we compare their performance against the

lower and upper bounds of each experiment, in terms

of AUC values. These values will give us an indica-

tion of how much improvement, if any, there can be

expected from using the unlabeled data in a particu-

lar case (i.e., for a particular algorithm and a set of

motifs). First, we run a supervised version of the al-

gorithms, maintaining the same folds, but assuming

no data in the training set to be unlabeled. Recall that

we deliberately treat some instances as unlabeled to

simulate the semi-supervised environment and to be

able to judge out results. This value mainly tells how

good the set of motifs really is and gives an upper

limit for how well we can anticipate to do in the semi-

supervised framework. Learning just from the labeled

subset will give us a lower bound of performance.

6 RESULTS

The ﬁrst experiment involves the NBM classiﬁer with

fractional labels, along with IRS and ESE motifs. The

use of LF is not justiﬁed in this setup, as the values

are not ﬁt for a multinomial model. Figure 1 shows

the performance of the classiﬁer when trained on 5%

of the labeled data along with different amounts of

unlabeled data, varying from 15% to 95%. For the

lower bound (LB), the classiﬁer was trained only on

5% of the labeled data (approximately 120 examples).

It has been observed that when given a weight greater

than 0.5, the unlabeled data adds noise, resulting in

a performance poorer than the LB. The same trend is

maintained when the amount of labeled data is varied

from 5% to 30% while the unlabeled data is ﬁxed at

70%: NBMem(0.1) gives the best results, followed by

NBMem(0.25), NBMem(0.3) and degrading towards

NBMem(1.0). In practice, is not always the case for

the unlabeled data to match the assumptions made by

the generative model, leading to a degradation of the

EM performance (Nigam et al., 2000); this could be

one possible explanation for our DNA data set, since

the EM with NBM implementation outperforms the

SEMI-SUPERVISED LEARNING OF ALTERNATIVELY SPLICED EXONS USING EXPECTATION

MAXIMIZATION TYPE APPROACHES

243

0.83

0.84

0.85

0.86

0.87

0.88

0.89

0.9

0.91

0.92

0.93

0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9

AUC value

Amount of Unlabeled Data

Lower Bound

NBMem (0.1)

NBMem(0.01)

NBMself(200,200)

NBMem (1.0)

Upper Bound

Figure 1: EM and self-training NBM performance with IRS

and ESE motifs when varying the amount of labeled data.

LB only when the contribution of the unlabeled data

is diminished. This suggests that enforcement upon

the inﬂuence of the unlabeled data during training is

useful but if too little importance is given (w = 0.01)

some valuable information remains unexploited. Fur-

thermore, the learned model betters with the increase

in the amount of unlabeled data; so probably if more

unlabeled data is added, the quality will continue to

grow. This hypothesis is worth investigating further

in future work. For the self-training approach we have

set a growth size (i.e., number of instances to be added

to the labeled set at each iteration) of 6, such that the

class ratio (5:1) is maintained. We varied the sample

size (i.e., how many examples are classiﬁed per iter-

ation amongst which the best 6 will be added to the

labeled set) between 50 and 200 and the number of

iterations from 50 to 200. The best scores on average

were achieved for 200 sample size and 200 iterations.

With the SVM implementation of the EM algo-

rithm, the LF can be included. Figure 2 represents

experiments for EM and SVM using IRS, ESE motifs

and also LF. Although there is not much improvement

over the baseline, a weight of 0.1 is still better than all

the other weighting values, however, self-training out-

performs all weights as well as the baseline.

Variations in terms of AUC when the model is

learned from increasing amounts of labeled data while

keeping the amount of unlabeled data ﬁxed to 70%,

show that for the SVM classiﬁer, self-training per-

forms better than the EM variation with weights in

this context too, however the results do not go beyond

the LB. In a strictly supervised setup, NBM achieves

the highest AUC value overall (0.93), followed by

SVM using IRS and ESE motifs (0.921) and SVM

using IRS, ESE and the LF (0.916).

0.76

0.78

0.8

0.82

0.84

0.86

0.88

0.9

0.92

0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9

AUC value

Amount of Unlabeled Data

Lower Bound

SVMemW (0.1)

SVMemW(0.01)

SVMemW (1.0)

SVMself(50,25)

Upper Bound

Figure 2: EM and self-training SVM performance with IRS,

ESE and LF when varying the amount of labeled data.

7 CONCLUSIONS

This work represents an empirical study of EM type

algorithms in the context of SSL applied to the clas-

siﬁcation of DNA sequences, using NBM and SVM

as base classiﬁers. We have shown that unlabeled

data does help improve the quality of the predictions

when the inﬂuence it has over the model in the train-

ing phase is small. In the case of NBM with proba-

bilistic labels, the IRS and ESE motifs are sufﬁcient to

boost the performance over the LBs; when unlabeled

data is added, the predictions improve gradually. For

SVM as base classiﬁer in the EM framework, in addi-

tion to the weighting scheme, self-training also shows

promising results. As expected, over all experiments,

predictions improve with the increase of labeled data

in the training phase. We can also conclude that NBM

is most effective in the supervised framework when

using IRS and ESE motifs.

8 FUTURE WORK

Many aspects that are critical to alternative splicing

classiﬁcation in a semi-supervised setup still need to

be explored: from using more unlabeled data and

more powerful discriminative motifs to feature selec-

tion, parameter ﬁne-tuning via validation setups and

exploring new semi-supervised approaches. Given

that large margin classiﬁcation yields state-of-the-art

results for many prediction problems, including alter-

native splicing (Ratsch et al., 2005), it is deﬁnitely

worth investigating the idea of support vector ma-

chines with specialized kernels, (i.e., kernels for com-

putational biology (Ben-Hur et al., 2008)) in a trans-

ductive (Gammerman et al., 1998) manner as well.

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

244

REFERENCES

Baldi, P. and Brunak, S. (2001). Bioinformatics: the ma-

chine learning approach. MIT Press.

Ben-Hur, A., Ong, C. S., Sonnenburg, S., Scholkopf, B.,

and Ratsch, G. (2008). Support vector machines and

kernels for computational biology. PLoS computa-

tional biology.

Black, D. L. (2003). Mechanisms of alternative pre-

messenger RNA splicing. Annual Review of Biochem-

istry.

Blum, A. and Mitchell, T. (1998). Combining labeled

and unlabeled data with Co-Training. In Proceedings

of the eleventh annual conference on Computational

learning theory. ACM.

Brefeld, U. and Scheffer, T. (2004). Co-EM support vec-

tor learning. In In Proceedings of the International

Conference on Machine Learning.

Chasin, L. A. (2007). Searching for splicing motifs. Ad-

vances in Experimental Medicine and Biology.

Chow, L. T., Gelinas, R. E., Broker, T. R., and Roberts, R. J.

(1977). An amazing sequence arrangement at the 5’

ends of adenovirus 2 messenger RNA. Cell.

Collins, M. and Singer, Y. (1999). Unsupervised models

for named entity classiﬁcation. In In Proceedings of

the Joint SIGDAT Conference on Empirical Methods

in Natural Language Processing and Very Large Cor-

pora.

Dai, W., Xue, G., Yang, Q., and Yu, Y. (2007). Transfer-

ring naive bayes classiﬁers for text classiﬁcation. In

In Proceedings of the 22nd AAAI Conference on Arti-

ﬁcial Intelligence.

Dempster, A. P., Laird, N. M., and Rubin, D. B. (1977).

Maximum likelihood from incomplete data via the

EM algorithm. Journal of the Royal Statistical So-

ciety.

Dong, A. and Bhanu, B. (2003). A new semi-supervised

EM algorithm for image retrieval. Computer Vision

and Pattern Recognition.

Dror, G., Sorek, R., and Shamir, R. (2005). Accurate iden-

tiﬁcation of alternatively spliced exons using support

vector machine. Bioinformatics (Oxford, England).

Gammerman, A., Vovk, V., and Vapnik, V. (1998). Learning

by transduction. In In Uncertainty in Artiﬁcial Intelli-

gence. Morgan Kaufmann.

Goldberg, A. B. and Zhu, X. (2006). Seeing stars when

there aren’t many stars: graph-based semi-supervised

learning for sentiment categorization. In Proceedings

of the First Workshop on Graph Based Methods for

Natural Language Processing. Association for Com-

putational Linguistics.

Huang, J. and Ling, C. X. (2005). Using a u c and accuracy

in evaluating learning algorithms. IEEE Transactions

on Knowledge and Data Engineering.

Kabat, J. L., Barberan-Soler, S., McKenna, P., Clawson, H.,

Farrer, T., and Zahler, A. M. (2006). Intronic alterna-

tive splicing regulators identiﬁed by comparative ge-

nomics in nematodes. PLoS computational biology.

Kall, L., Canterbury, J. D., Weston, J., Noble, W. S., and

MacCoss, M. J. (2007). Semi-supervised learning

for peptide identiﬁcation from shotgun proteomics

datasets. Nature methods.

Lawrence, C. E. and Reilly, A. A. (1990). An expec-

tation maximization (EM) algorithm for the identiﬁ-

cation and characterization of common sites in un-

aligned biopolymer sequences. Proteins.

McCallum, A. and Nigam, K. (1998). A comparison of

event models for naive bayes text classiﬁcation. Di-

mension Contemporary German Arts And Letters.

Moreno, P. J. and Agarwal, S. (2003). An experimental

study of semi-supervised EM. Technical report, HP

Labs.

Nagaraj, S. H., Gasser, R. B., and Ranganathan, S. (2007).

A hitchhiker’s guide to expressed sequence tag (est)

analysis. Brieﬁngs in bioinformatics.

Nesvizhskii, A. I., Keller, A., Kolker, E., and Aebersold, R.

(2003). A statistical model for identifying proteins by

tandem mass spectrometry. Analytical Chemistry.

Nigam, K. and Ghani, R. (2000). Analyzing the effective-

ness and applicability of Co-Training. In Proceedings

of the 9th International Conference on Information

and Knowledge Management. ACM.

Nigam, K., McCallum, A. K., Thrun, S., and Mitchell, T.

(2000). Text classiﬁcation from labeled and unlabeled

documents using EM. Machine Learning.

Pertea, M., Mount, S. M., and Salzberg, S. L. (2007). A

computational survey of candidate exonic splicing en-

hancer motifs in the model plant Arabidopsis thaliana.

BMC bioinformatics.

Provost, F. J., Fawcett, T., and Kohavi, R. (1998). The

case against accuracy estimation for comparing induc-

tion algorithms. In Proceedings of the Fifteenth Inter-

national Conference on Machine Learning. Morgan

Kaufmann Publishers Inc.

Ratsch, G., Sonnenburg, S., and Scholkopf, B. (2005).

Rase: recognition of alternatively spliced exons in

C.elegans. Bioinformatics (Oxford, England).

Rosenberg, C., Hebert, M., and Schneiderman, H. (2005).

Semi-supervised self-training of object detection

models. In Proceedings of the Seventh IEEE Work-

shops on Application of Computer Vision. IEEE Com-

puter Society.

Vapnik, V. N. (1995). The nature of statistical learning the-

ory. Springer-Verlag New York, Inc.

Weston, J., Kuang, R., Leslie, C., and Noble, W. (2006).

Protein ranking by semi-supervised network propaga-

tion. BMC Bioinformatics.

Wu, C. F. J. (1983). On the convergence properties of the

EM algorithm. Annals of Statistics, Vol. 11, No. 1.

Yarowsky, D. (1995). Unsupervised word sense disam-

biguation rivaling supervised methods. In Proceed-

ings of the 33rd annual meeting on Association for

Computational Linguistics.

Zhang, Y.-Q. and Rajapakse, J. C. (2009). Machine learning

in bioinformatics. Wiley.

SEMI-SUPERVISED LEARNING OF ALTERNATIVELY SPLICED EXONS USING EXPECTATION

MAXIMIZATION TYPE APPROACHES

245
