DYNAMIC JAVA COMPONENTS IN PERVASIVE SYSTEMS

A Review of the Feasibility of Dynamic Data Processing on Wireless Platforms

Alexander Dannies, Javier Palafox-Albarrán, Walter Lang and Reiner Jedermann

Institute for Microsensors, -actuators and -systems, University of Bremen, Otto-Hahn-Allee NW1, Bremen, Germany

Keywords: Java, Data Processing, Wireless Sensors, OSGi, Dynamic Components, Pervasive Computing.

Abstract: A wireless sensor network (WSN), which is one type of pervasive system, has the goal of networking

heterogeneous systems and communicating through a gateway. However, it is also necessary to provide

dynamic features to wireless nodes for updating applications and services during runtime. Dynamic updates

can be handled either by the intrinsic features of Java or by advanced frameworks such as MIDP or OSGi.

This paper investigates the software background and the feasibility of these three options in the context of

WSNs. Java Virtual Machines were tested on sensor nodes and gateways currently available on the market.

Two synthetic benchmarks were utilized to compare their performance. In addition, we tested the

performance of an exemplary algorithm for a real life application during transportation in food logistics.

Our experimental results showed that the performance of the benchmarks varied by a factor of more than

50, depending on the platform. Nevertheless, our chosen example algorithm could be executed on all

platforms within an acceptable amount of CPU time. Pre-processing of data can be applied on wireless

devices to reduce communication volume and provide conclusions instead of raw data. However the use of

advanced frameworks, enabling extended dynamisation, are so far very limited.

1 INTRODUCTION

The vision of omnipresent information processing in

everyday environments, for example in logistic

transport and production processes by a network of

pervasive systems, becomes more and more feasible

with the decreasing cost and increasing

computational power of wireless devices.

Pervasive systems have the aim of networking

everyday life by the use of intelligent objects. They

can utilize different technologies and systems with

different computational capabilities. Wireless sensor

networks (WSN) are examples where different

hardware types are involved. These devices

communicate with the external world through a

gateway which possesses extended communication

and processing capabilities.

The nodes are placed in an environment in order

to sense physical parameters, communicate with the

network’s neighbours and determine useful actions.

One of the most important challenges is to deploy

applications in which families of hardware devices

interact with each other. As mentioned by Vazquez,

Almeida, Doamo, Laiseca and Orduña (2009), it is

desirable to implement monitoring solutions based

on WSNs with distributed intelligence in which

sensor populated scenarios may communicate with

internet-based solutions.

Our vision of an intelligent network, in the

project “Intelligent Container” (IMSAS, 2011),

includes the capability to handle dynamic changes in

the environment. The network nodes should be able

to interpret and to react to environmental data and

situations that were unknown at the time of their

installation and initial programming as access to the

container is not possible during transport. Therefore

it is necessary to provide dynamic features in

wireless network nodes to allow updating during

runtime, not only of one application but also the

services provided. For example, the sensor can be

moved to a new environment, which requires a

modified network protocol to make the best use of

the available gateways, whereas the remainder of the

software remains unchanged. Alternatively, the

intelligent data processing may consist of multiple

services which are updated at different time

intervals.

The concept of the Open Source Gateway

initiative (OSGi) enables Java software modules to

be updated or replaced on a system during runtime,

for example remotely over an internet-connection.

Dannies A., Palafox-Albarrán J., Lang W. and Jedermann R..

DYNAMIC JAVA COMPONENTS IN PERVASIVE SYSTEMS - A Review of the Feasibility of Dynamic Data Processing on Wireless Platforms.

DOI: 10.5220/0003802300580066

In Proceedings of the 2nd International Conference on Pervasive Embedded Computing and Communication Systems (PECCS-2012), pages 58-66

ISBN: 978-989-8565-00-6

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Research has been carried out including OSGi in

pervasive systems, but the main focus is telematics

systems (Lee et al., 2006) and mobile agents (Lee et

al., 2010) as its merits make it suitable for these

purposes.

Implementing dynamic features in WSNs is even

more complicated. The difference between WSNs

and other pervasive systems is that the main concern

is the energy consumption of the application. In

Rellermeyer et al., (2008) they go one step further,

making the concept of OSGi compatible with

resource-constrained devices. They propose OSGi-

like services in devices with no JVM and with

limited operating system support. The only full

OSGi framework exists on the gateway.

The question arises whether it is possible to have a

full OSGi heterogeneous system which is energy

aware and intelligent, or whether pure Java without a

middleware on top is sufficient at the lower levels.

The aim of this paper is to investigate the

feasibility of OSGi and Java implementation in

several WSN platforms. Verifying this would allow

a shift in the paradigm from a centralised WSN – in

which the majority of sensors are just collecting

environmental data and transmitting these to one

processing unit – to a WSN with sensors which are

pre-processing data to reduce network traffic and

save energy. The requirements for a specific

application can differ from our selected application

domain of interest, which is monitoring during

transportation in food logistics. The main issues to

be taken into account are the time needed for the

platforms to perform complex computer operations

and the limitations of each of them regarding

resource requirements for enabling a dynamic

platform.

First, in section 2 we will provide an overview of

Java and dynamic components. Section 3 will

explain the methods used to test the performance

and the configuration, followed by section 4 which

describes the hardware platforms used in the

experiments. In section 5 we discuss the results and

finally offer conclusions.

2 STATE OF THE ART

Java and OSGi are two promising technologies for

solving the challenge of dynamic software updates.

The former is well-known to be portable and

independent of platform. Pervasive Java (also called

wireless Java and mobile Java) attempts to bridge

the gap between different devices and platforms.

However, Java Standard Edition (JavaSE) was

conceived for personal computers and is not suitable

for resource constrained devices. Realising this

need, Sun Microsystems introduced the Java 2

Platform, Micro Edition. The second system, OSGi,

is based on Java with a focus on modular, service-

oriented architecture (SOA) as well as dynamic

installation and updates of bundles.

2.1 Java as Dynamic Language

Java is the most common language that meets the

requirement of the ability to extend software with

dynamic code segments, because dynamic class

loading is one of its intrinsic features. Some of the

additional benefits one obtains by choosing Java are

object-oriented programming and automated

memory and heap management (garbage collector).

Furthermore, using Java as a programming language

is programming platform-independent. This so

called concept of “write once, run anywhere”

(WORA) becomes possible through the use of a Java

virtual machine (JVM) which is adapted to specific

hardware architecture, e.g. x86 or ARM. The JVM

does not execute a compiled program, but rather a

Java bytecode which will be interpreted differently

on each platform.

2.1.1 Limitations of JavaME

It has to be questioned whether JavaME is still

sufficient for the increasing demands of data

processing algorithms. The situation-dependent

loading and installation of new software bundles

requires flexible class loaders. Storage of recorded

data and knowledge might require a file system.

Most data analysis algorithms require floating or

even double precision arithmetic.

JavaSE is the standard platform for programming

in the Java language. It consists of a Java virtual

machine for executing the compiled class-files (the

Java program) and a set of libraries which makes it

possible to access, e.g. the file system, graphical or

network interfaces from a Java program.

The Java Micro Edition (JavaME) is aimed at

embedded systems, e.g. mobile phones with limited

resources. A developer programming for a platform

using JavaME has to keep in mind that he is

restricted to the features of JRE 1.3. Three

components belong to the JavaME-stack: the

configuration which contains the Java virtual

machine, the profile, which adds a certain set of

API, and optional packages for additional

functionality in regards to the profile scope. There

are two configurations: The Connected Device

DYNAMIC JAVA COMPONENTS IN PERVASIVE SYSTEMS - A Review of the Feasibility of Dynamic Data

Processing on Wireless Platforms

Configuration (CDC) includes almost the entire

scope of JavaSE except for GUI-related libraries. In

contrast, the Connected Limited Device

Configuration (CLDC) only contains the minimum

amount of classes necessary to enable the operation

of a JVM. In version CLDC 1.1, the previous

version has been extended by the classes double and

float, so that floating-point operations now are

enabled. On the other hand, the Java-math-library is

still not available.

On top of the configuration, a profile can be

chosen which fits the desired target application. For

example, the Mobile Information Device Profile

(MIDP) for mobile devices such as mobile phones,

or the Personal Profile for consumer electronics.

Applications written based on the former profile are

called MIDlets.

2.2 Java Virtual Machines

In this paper, four selected JVMs are installed in

diverse sensor nodes in order to be tested, namely

JamVM (Lougher, 2010), JamaicaVM (Siebert,

2002), Squawk (Oracle, 2011a) and SwissQM

(Müller, Alonso and Kossmann, 2007). The first two

JVMs are based on the JavaSE standard. The third is

based on the JavaME standard, and the fourth was

specifically developed for sensor nodes.

JamVM is an open source JVM which makes use

of the GNU Classpath (Lougher, 2010). The

developers claim that their implementation is

extremely small and still able to support the full

specification, including class-unloading and native

support. It supports several operating systems such

as Linux, Mac and Solaris as well as different

hardware architectures like PowerPC, ARM and

AMD64.

JamaicaVM is a commercial JVM of AICAS. It

provides, according to the developer, Hard Realtime

Execution, Realtime Garbage Collection, the best

trade-off between runtime performance and code

size, dynamic loading, multi-core support, and

native support. It is available for diverse operating

systems like Linux and Windows, and several

architectures like x86 and ARM. In addition to the

traditional method of building a JVM and executing

a class-file, the JamaicaVM Builder offers another

solution. All files relevant to the application (a set of

class files) and the Jamaica VM are combined into a

standalone application in a single executable file.

Squawk is a JavaME VM which targets small

resource constrained devices. Its core is mostly

written in Java. Classes are not transferred directly

to the execution environment but combined in a

suite and prelinked to each other, which results in a

reduced size of around one third of the original size.

The omission of dynamic class loading in these

immutable suites significantly decreases the start up

time of the applications. Squawk utilizes the concept

of isolates, where an application can be represented

as an object. This allows common suites to be shared

between multiple applications that run in the single

JVM which can lead to a significantly reduced

memory footprint.

Finally, SwissQM is a combination of a JVM

and a query machine (QM) that was developed

specifically to be run on platforms with TinyOS as

operating system, such as TelosB (Crossbow, 2011).

It is based on 16-bit integer values, and floating-

point types are not supported. It only supports 37

instructions of the instruction set of the JVM

specification, and adds 22 specific instructions

related to processing queries. Programs are executed

at every sampling period or when data from other

nodes arrive. It has a small footprint – 33kB of Flash

and 3kB of SRAM memory – and is able to execute

up to six QM programs concurrently in TelosB, but,

in principle, it can run an arbitrary number of

concurrent programs.

2.3 Management of Software Bundles

Furthermore, several Java based frameworks can be

found that make the exchange of software bundles

easier. Software agent platforms such as the Java

Agent DEvelopment Framework (JADE)

(Bellifemine et al., 2008), a Mobile Agent Platform

for WSNs based on JavaSun Spots (MAPS) (Aiello

et al., 2011), and the Agent Factory Micro Edition

(AFME) (Müller, 2007) are mainly found in

academic research.

There are two different application models (AM)

for the Java language. On the one hand, the

unmanaged approach exists, which is basically the

start of the static method main() when executing a

class file. On the other hand, there are several

concepts for managed AMs like applets (for web

browsers), Xlets (for advanced content on Blu-ray

discs), MIDlets (for mobile devices like mobile

phones), OSGi Bundles and the OSGi R4 Mobile

Expert Group (MEG) AM.

Here, we wish to compare the two concepts of

MIDlets and OSGi Bundles.

2.3.1 MIDlets

A device running a Mobile Information Device

Application (called a MIDlet) has an environment

PECCS 2012 - International Conference on Pervasive and Embedded Computing and Communication Systems

which enables the user to choose MIDlets for

installing, starting and removing. This so called

Application Management Software (AMS) to control

the life-cycle is responsible for the interaction with

the user as well as for error handling. MIDlets have

three possible states: paused, active and destroyed.

To achieve modularity with MIDlets, a method

needs to exist which enables the communication

between different software modules which can be

updated independently of each other. For this the

following two approaches are possible. On the one

hand, the Record Management Store (RMS) enables

indirect communication between MIDlet-suites

(introduced in MIDP2.0) and on the other hand,

Inter-MIDlet-Communication (IMC) enables direct

communication between MIDlets (introduced in

MIDP3.0). However, at the moment there is no SDK

available, which supports MIDP3.0. The question

can be raised whether it will ever be available

because the standard was approved in the end of

2009 but has not yet been introduced in SDKs. This

is reasoned by the fact that the development of

applications for mobile devices has shifted to

android applications and the like. With the RMS-

approach, every MIDlet can access record stores

created of other MIDlets in the same suite. Starting

from MIDP2.0 it is also possible that MIDlets of a

second suite outside the first suite access the record

store, but only when allowed by the MIDlet which

created the record store. The data inside the record

store stays as long as the suite stays on the device,

independent of the status of the MIDlet (active or

paused). If the device is switched off and then on

later, the data is still available. When a MIDlet suite

is removed from a device the record store is no

longer available.

2.3.2 OSGi

Sometimes just running a Java-application on a

device is not enough because the modularity is

missing, for example when new implementations

have to be integrated into the running program. To

add this functionality, the Open Services Gateway

initiative framework (OSGi) can be used. This

concept enables the remote update or replacement of

Java software modules on a system during runtime,

for example over an internet-connection. So the

concept of OSGi enables a high degree of dynamics

because it is possible to update an existing piece of

software running on a device without being on site

or restarting the machine.

In order to be able to use the concept of OSGi an

OSGi framework on top of a Java Virtual Machine

(JVM) is necessary. This framework utilizes a so-

called Service Registry to make it possible to

modularise and manage applications and their

services with the help of a component model by

using bundles and services. On the one hand there

are open source frameworks available for the current

specification “OSGi Service Platform Release 4“

(R4), namely Apache Felix, Eclipse Equinox and

Makewave Knoplerfish and next to it a R3

implementation named Concierge from the Institute

for Pervasive Computing, ETH Zurich. On the other

hand there are commercial OSGi frameworks

available, e.g. ProSyst Software mBedded Server

and Makewave Knopflerfish Pro to name two of

them.

It is possible to run OSGi on mobile phones, e.g.

with Linux as an OS and JavaME VM with the CDC

configuration and FP 1.1. Even though OSGi was

originally designed for environments with CDC or

above, it is generally possible to implement OSGi in

a CLDC environment. The “mBS Mobile for

JavaME” from ProSyst proves that, but with the

limitation to version R3 of the OSGi specification.

The platform requirement is a J2ME CLDC/MIDP

2.0 compatible JVM. Typically OSGi R4 needs 8

MB volatile memory and a CPU clock speed of at

least 150 MHz to operate (Prosyst, 2010).

The basic feature of OSGi is to enable access to

certain Java classes which are published as services,

while protecting the remaining code against external

access, which largely depends on user defined class

loaders.

The inclusion of user defined class loaders

produces a lot of overhead for the JVM, which is the

reason why they were excluded from the CLDC

profile. This raises the challenge to find another

mechanism to implement code sharing and isolation

in an optimised OSGi framework.

The Request for Proposal (RFP) 126 (Bottaro

and Rivard, 2009) suggests a new approach – the

implementation of a new OSGi specification which

aims to replace a profile, e.g. MIDP. So on top of the

CLDC1.1 configuration, the OSGi ME Profile is

used to add an OSGi environment to resource-

constrained environments. In addition to keeping the

core features of the OSGi technology and the Java

ME CLDC compliance, the proposition includes a

strengthened robustness and a simplification which

requires much less resources and thus enables mass

deployment. Although the RFP sounds promising it

remains to be seen whether the concept offers what

it promises. In 2010 it was mentioned in Bottaro and

Rivard (2010) that the specification would soon be

public and that the company IS2T was about to sell

DYNAMIC JAVA COMPONENTS IN PERVASIVE SYSTEMS - A Review of the Feasibility of Dynamic Data

Processing on Wireless Platforms

the first OSGi ME. In autumn 2011 the specification

was made public and IS2T has a reference

implementation and sells early solutions. The

question arises if and when an open-source solution

will be accessible.

3 METHODS

In order to have a reference point for the abilities of

the different platforms (see section 4) we are using

two synthetic benchmark-algorithms: Dhrystone

which uses integer values and LINPACK which uses

floating point values. Due to the fact that the

whetstone benchmark uses trigonometric functions it

is not possible to execute it on platforms with

CLDC1.1, at least without the use of external

classes. So as a replacement we used the LINPACK

benchmark.

In addition, we tested the performance of an

exemplary algorithm for the analysis of sensor data

as an example of a real life application.

3.1 Feedback-hammerstein

The exemplary algorithm estimates the three

parameters required for a model that represents the

factors affecting the temperature inside a

refrigerated container transporting perishable goods,

and does not need any matrix inversion. The so-

called Feedback-Hammerstein system takes into

account the effect of organic heat using a static non-

linear feedback system. In order to provide an

accurate prediction, the model parameters have to be

iterated over three days at a measurement interval of

one hour, equivalent to 72 cycles. Details of the

algorithm are described in Palafox-Albarrán,

Jedermann and Lang (2011).

3.2 Test Configurations

There are three options available to run Java code.

Option one is the compilation of the Java code

into the Java VM. This is mainly used for standard

functions and services. Whilst this approach results

in fast execution speed, it does have some

drawbacks. Firstly, it is no longer possible to update

the code. And secondly, the code size increases

because the compiled native code is less memory-

efficient than byte code. The second option is that

the code is interpreted at run-time by the VM. This

can be a class-file or jar-file. The third option is that

the code is compiled just-in-time (JIT) before

execution. This is especially beneficial for classes,

which are often called or contain a high number of

nested loops. Which of these options are available

depends on the implementation of the VM.

The open-source solution JamVM only enables

the second option. In constrast to the open-source

solution, the JamaicaVM implements the Realtime

Specification for Java (RTSJ) and a deterministic

garbage collection. It also supports all three options

described above. The footprint and execution time of

a built-in-application (option 1) can be influenced

immensely by choosing the correct settings for the

parameters in the building process, such as heapsize,

timeslicing, stack size, percentage compiled or

number of threads, just to name some of the many

options available.

3.2.1 OSGi

A preliminary OSGi implementation on the sensor

platform Imote2 (Memsic, 2011) was conducted by

Wessels, Jedermann and Lang (2010). Back then, an

executable was built with the JamaicaBuilder which

contains the Jamaica VM in version 3.4 and the

Equinox Framework in version 3.4.

In addition to this we used the current version (6)

of the JamaicaVM and the equinox framework in

version 3.7. The newer JamaicaVM has the

capability of creating a JVM with an integrated just-

in-time (JIT)-compiler. Furthermore an open-source

solution of a JVM was used, namely JamVM in

version 1.5.4 (with classpath in version 0.98). These

configurations were utilized for the tests on both

ARM-platforms (see section 4 for details). On the

x86- platform both JVM were tested.

3.2.2 MIDlets and Java Archives

On the other sensor platforms OSGi implementation

was not possible. On Preon32 and SunSPOT the

benchmarks were written in Java in their

corresponding development environments and then

transferred to the devices as MIDlets or Proglets

(Virtenio VM) respectively.

In SwissQM, the user query is run as a bundle in

the SwissQM gateway and not in the sensor node. It

sends bytecode to the sensor network for query

processing purposes on the sensor nodes. The

limited VM on the sensor nodes is not capable of

running complex operations; user defined functions

are possible but they are written in a C-like language

and only integer types and no arrays are supported.

This makes it very difficult to program even simple

algorithms like Feedback-Hammerstein as it requires

at least simple matrix operations like addition and

multiplication.

PECCS 2012 - International Conference on Pervasive and Embedded Computing and Communication Systems

4 INTRODUCTION OF TESTED

HARDWARE PLATFORMS

Tables 1 and 2 contain the different platforms we

used with their properties.

Table 1: 802.15.4 Wireless sensor platforms.

TelosB Imote2 Sun SPOT Preon32

CPU

(MHz)

MSP 430

(8)

PXA 271

(416)

SAM 9G20

(400)

Cortex-M3

(72)

RAM 10 kB 32 MB 1 MB 64 kB

OS TinyOS Linux None None

JVM Swiss QM any Squawk Custom

Java

Edition

Reduced

byte code

CLDC 1.1

almost

CLDC 1.1

Table 2: Telematics platforms.

DuraNAV VTC6100

CPU

(MHz)

PXA255

(400)

N270

(1600)

RAM 64 MB 1 GB

OS Linux Linux

JVM Any Any

Java Edition SE SE

OSGi Any Any

4.1 Wireless Sensor Platforms

All the tested wireless sensor platforms (Table 1)

support the communication standard 802.15.4 (IEEE

Computer Society, 2006).

The sensor node TelosB with the smallest

memory footprint and the slowest CPU from our

selected test field runs TinyOS, a small, open-

source, energy-efficient software operating system.

It is an event driven OS designed for sensor network

nodes that have limited resources. TinyOS is an

embedded operating system written to provide

interfaces and components for common abstractions

such as packet communication, routing, sensing,

actuation and storage. Applications are built using

nesC, an extension of the C programming language

optimised for the memory limits of sensor networks.

Support, libraries are already available, such as the

nesC compiler.

The advantages of Imote2 are high processing

capabilities in comparison with TelosB, a large

memory, and power saving abilities by the scalable

processor. The design is modular and stackable with

interface connectors for expansion boards on both

the top and bottom sides, it allows the

interconnection of additional devices, such as

temperature sensor cards.

Regarding the operating system, it can run Linux

(e.g. built with OpenEmbedded) that allows

exhausting the possibilities of Imote2 and the

development of higher application software which

enhances single motes.

The company Virtenio has developed a new

concept of a sensor node (Preon32). By using a 32-

Bit ARM-Cortex-M3 microcontroller in

combination with a Java virtual machine for the

device it becomes possible to execute Java

applications on the sensor node. The limiting factor

is the power of the CPU which has a maximum

clock of 72 MHz and also RAM of 64 KB in size.

Access to hardware components like the radio is

written in C and can be used through the Java Native

Interface (JNI). For wireless communication the

ATRF231 radio chip is utilized. Support for IPv6 is

currently under development. In addition, this sensor

node has the possibility of being connected to the

CAN-Bus – the support for this feature is also

currently under development.

The Sun Small Programmable Object

Technology (SunSPOT) is a mote developed by Sun

Microsystems (Oracle, 2011b), currently available in

an 8th revision. It features support for IPv6. The

difference with respect to all the other platforms is

the built-in lithium-ion-battery, which can be

charged via the USB-interface.

4.2 Telematics

Beside the wireless sensor we also tested two

telematics units for two reasons: Firstly, they can

bridge the gap between the local sensor network and

the outside world. This becomes possible by the use

of WLAN or UMTS for enabling access to the

internet. In order to make it possible to connect the

telematics unit to the WSN, one wireless sensor acts

as a base station. The connection is established via a

serial connection (RS232 or USB). Secondly, we

include them as a reference for embedded platforms

with extended computation capabilities. Telematics

units are typically used to supervise goods inside

trucks or containers; they collect data from local

sensors and send compressed messages over the

GPRS network; but the typical hardware units are

not restricted to these applications.

We have not tested Java-enabled cell phones or

smartphones based on the Android operating system,

because we have only focused on embedded devices

which can operate without human involvement.

DYNAMIC JAVA COMPONENTS IN PERVASIVE SYSTEMS - A Review of the Feasibility of Dynamic Data

Processing on Wireless Platforms

5 PERFORMANCE

MEASUREMENTS

Micro benchmarks or mini test applications can only

give a rough estimation of the capabilities of a

system. The performance of a real-world application

is almost always different. It should also be noted

that in cases where a JIT-compiler is used, some

warm-up-time is required, and the result of such

benchmarks is thereby affected. So the execution

time in the long run – after the warm-up phase – can

be much faster. Results of real-world tests at

extended periods of time are more meaningful.

Table 3 presents the results for the different

benchmarks executed on the reference platform

VTC.

Table 3: Results of the chosen benchmarks on the

reference platform (VTC).

Dhrystone Linpack

Feedback-Hammerstein

523 ms 45,778 Mflops/s 7 ms

Combined with the resulting performances of the

chosen benchmarks on the other platforms, ratios

were calculated, which are displayed in the

following figures.

Figure 1: Results of the Dhrystone 2.1 benchmark.

As can be seen in Figure 1, the processing power

of the platforms is correlating with the CPU and

RAM at hand. Although the CPU clock-rate of

DuraNAV, Imote2 and SunSPOT are the same, the

performance seems to be linked to the available

RAM of the systems. So the order of the

performances is the same as the devices sorted by

memory in descending order.

In contrast to the previous benchmark, Figure 2

shows a different outcome. Here the requirement for

RAM seems to be less significant. The SunSPOT

performance is the best followed by DuraNAV and

Imote2. This could be explained by the newer CPU

architecture of SunSPOT which seems to have

improved floating-point processing power.

Figure 2: Results of the Linpack benchmark.

Figure 3 depicts the results for the exemplary

tested real-world algorithm. Here the best

performance is produced by the DuraNAV (96 ms)

followed by SunSPOT (108 ms) and Imote2

(139 ms). A correlation between the need for

memory or processing capabilities cannot be directly

determined.

Figure 3: Results of the Feedback-Hammerstein algorithm.

In all three benchmarks, Preon32 has the poorest

performance which is obviously caused by the

extremely low amount of available RAM in

combination with a low clock-rate. It is possible to

pre-process data with this node with chosen

algorithms, whilst keeping in mind that the resources

are extremely limited. Although the execution time

for the Feedback-Hammerstein-algorithm was

around 285 times slower than on the reference

platform, the absolute value of 2027 ms is still fast

enough to be applicable, because it is only executed

every three days.

SunSPOT exhibits a good overall performance if

the algorithms are not dependent on large amounts

of memory.

Figure 4 compares the execution time on Imote2

and DuraNAV of the benchmarks as a class-file or

an OSGi-bundle. The execution time of the

PECCS 2012 - International Conference on Pervasive and Embedded Computing and Communication Systems

Dhrystone benchmark on the Imote2 is around 8%

slower when deployed as an OSGi-bundle instead of

being executed from a class-file. In contrast, the

execution time of the Feedback-Hammerstein-

algorithm as an OSGi-bundle is around 10% faster

on DuraNAV and around 6.8% faster on Imote2 than

when executed from a class-file.

The dynamics is higly improved with the usage

of an OSGi-framework, so that a trade-off in a

reduction in execution time can be accepted.

It remains to be seen how the execution time

varies on SunSPOT when an OSGi implementaion is

possible.

Figure 4: Difference in execution time in % between OSGi

and class.

6 CONCLUSIONS

The selection of the right framework and platform

depends on the requirements of the application.

They can be divided into two: those requiring

computations of complex time-consuming

operations and those requiring large amounts of

memory.

At the moment, OSGi implementation is not

applicable for pervasive networks in the way that is

desired. Only Imote2 has enough resources for

making an OSGi-framework available on a sensor-

platform. It can manage complex mathematical

operations and store large amounts of data. But due

to discontinued development since it was introduced

to the market, its power consumption remains

relatively high. Therefore the platform can be used

for scientific evaluation but is not applicable for

remote WSNs where one of the main features should

be long battery life-time. The mentioned request for

proposal for a JavaME implementation of OSGi

sounds promising, but it is not yet available.

Data pre-processing of sensor nodes reduces

communications resulting in lower energy

consumption. Although the execution times of

Preon32 for the chosen algorithms were not the best,

it can be used for calculations which do not rely on a

lot of data because of the limited amount of RAM.

SunSPOT can be used for data-processing with even

more data because of the increased amount of

available memory. Especially on floating-point

algorithms, the newer CPU has its advantages. It

will have to be assessed how the OSGiME profile

changes the application of dynamic components in

WSNs.

ACKNOWLEDGEMENTS

The research project “The Intelligent Container” is

supported by the Federal Ministry of Education and

Research, Germany, under reference number

01IA10001, and by the German Research

Foundation (DFG) as part of the Collaborative

Research Centre 637 “Autonomous Cooperating

Logistic Processes”.

REFERENCES

Aiello, F., Fortino, G., Gravina, R. & Guerrieri, A. (2011).

A Java-based agent platform for programming

wireless sensor networks. Computer Journal, 54, 439-

454.

Bellifemine, F., Caire, G., Poggi, A. & Rimassa, G.

(2008). JADE: A software framework for developing

multi-agent applications. Lessons learned. Information

and Software Technology, 50, 10-21.

Bottaro, A. & Rivard, F. (2009). RFP 126 - OSGi ME: An

OSGi Profile for Embedded Devices. OSGi Alliance.

Bottaro, A. & Rivard, F. (2010). OSGi ME An OSGi

Profile for Embedded Devices. OSGi Community

Event, London, UK, September 2010.

Breymann, U., Mosemann, H. (2008). Java ME :

Anwendungsentwicklung für Handys, PDA und Co.

München; Wien: Hanser

Crossbow (2011). TelosB Datasheet [Online]. Retrieved

September 5 2011,

http://www.willow.co.uk/TelosB_Datasheet.pdf

IEEE Computer Society. (2006). Wireless medium access

control (MAC) and physical layer (PHY)

specifications for low-rate wireless personal area

networks (WPANs) [Online] Retrieved September 6,

2011, from http://standards.ieee.org/getieee802/

download/802.15.4-2006.pdf.

IMSAS, (2011). The intelligent container: Networked

intelligent objects in logistics“. [Online]. Retrieved

September 6, 2011, from http://www.intelligent

container.com

Jedermann, R., Palafox-Albarrán, J., Jabbari, A. and Lang,

W., (2011). Embedded intelligent objects in food

logistics -Technical limits of local decision making.

In: Hülsmann, M., Scholz-Reiter, B. and Windt, K.

DYNAMIC JAVA COMPONENTS IN PERVASIVE SYSTEMS - A Review of the Feasibility of Dynamic Data

Processing on Wireless Platforms

(eds.) Autonomous cooperation and control in

logistics. Berlin: Springer

Lee, S., Kim, I., Rim, K. and Lee, J., (2006). Service

mobility manager for OSGi framework. In: Gavrilova,

M., Gervasi, O., Kumar, V., Tan, C., Taniar, D.,

Laganá, A., Mun, Y. and Choo, H. (eds.).

Computational science and its applications - ICCSA

2006. Berlin / Heidelberg: Springer.

Lee, J., Lee, S.-J., Chen, H.-M. & Lee, W.-T., (2010).

Telematics services through mobile agents. In: Zeng,

Z. & Wang, J. (eds.). Advances in neural network

research and applications. Berlin / Heidelberg:

Springer.

Lougher, R., (2010). JamVM [Online]. Retrieved

September 6, 2011, from http://jamvm.sourceforge.

net.

Memsic, (2011). Imote2 High-performance Wireless

Sensor Network Node [Online]. Retrieved September

5 2011, from http://www.memsic.com/support/

documentation/wireless-sensor-networks/category/7-

datasheets.html?download=134%3Aimote2.

Müller, R., Alonso, G. and Kossmann, D., (2007). A

virtual machine for sensor networks. Proceedings of

the 2nd ACM SIGOPS/EuroSys European Conference

on Computer Systems. Lisbon, Portugal: ACM.

Oracle. (2011a). Squawk Development Wiki [Online].

Retrieved September 6, 2011, from http://java.net/projects/

squawk/pages/SquawkDevelopment.

Oracle. (2011b). SunSPOT [Online]. Retrieved September

6, 2011, from http://www.sunspotworld.com.

Palafox-Albarrán, J., Jedermann, R. and Lang, W., (2011).

Energy-efficient parameter adaptation and prediction

algorithms for the estimation of temperature

development inside a food container. In: Cetto, A. J.,

Ferrier, J.-L. and Filipe, J. (eds.) Lecture Notes in

Electrical Engineering - Informatics in Control,

Automation and Robotics. Berlin: Springer.

ProSyst. (2010). The world’s smallest OSGi solution.

[Online]. Retrieved September 6, 2011, from

http://www.prosyst.com/index.php/de/html/news/detai

ls/18/smallest-OSGi.

Rellermeyer, J. S., Duller, M., Gilmer, K., Maragkos, D.,

Papageorgiou, D. and Alonso, G., (2008). The

software fabric for the Internet of Things. In:

Floerkemeier, C., Langheinrich, M., Fleisch, E.,

Mattern, F. & Sarma, S. E. (eds.) Proceedings of the

IEEE International Conference on the Internet of

Things. 26-28 March 2008, Zurich, Switzerland.

Schmatz, K.-D., (2007). Java Micro Edition Entwicklung

mobile JavaME-Anwendungen mit CLDC und MIDP.

Heidelberg: dpunkt.verlag GmbH

Siebert, F., (2002). Hard Realtime Garbage Collection,

Karlsruhe: aicas GmbH.

Vazquez, J., Almeida, A., Doamo, I., Laiseca, X. &

Orduña, P., (2009). Flexeo: An architecture for

integrating wireless sensor networks into the Internet

of Things. 3rd Symposium of Ubiquitous Computing

and Ambient Intelligence. 22-24 October 2008,

Salamanca, Spain.

Virtenio, (2011). 2.4 GHz Funkmodul „Preon32” mit

überlegener Technik [Online] Retrieved September 6,

2011, from http://www.virtenio.com/de/produkte/hard

ware/preon32.html.

Wessels, A., Jedermann, R. and Lang, W., (2010).

Embedded context aware objects for the transport

supervision of perishable goods. In: Zadeh, A. (ed.)

Recent advances in electronics, hardware, wireless

and optical communications. Cambridge, UK: Wseas

Press.

PECCS 2012 - International Conference on Pervasive and Embedded Computing and Communication Systems
