OCCUPANCY ANALYSIS OF SPORTS ARENAS

USING THERMAL IMAGING

Rikke Gade, Anders Jørgensen and Thomas B. Moeslund

Visual Analysis of People Laboratory, Aalborg University, Aalborg, Denmark

Keywords:

Thermal Imaging, Image Processing, Human Detection.

Abstract:

This paper presents a system for automatic analysis of the occupancy of sports arenas. By using a thermal

camera for image capturing the number of persons and their location on the court are found without violating

any privacy issues. The images are binarised with an automatic threshold method. Reﬂections due to shiny

surfaces are eliminated by analysing symmetric patterns. Occlusions are dealt with through a concavity anal-

ysis of the binary regions. The system is tested in ﬁve different sports arenas, for more than three full weeks

altogether. These tests showed that after a short initialisation routine the system operates independent of the

different environments. The system can very precisely distinguish between zero, some or many persons on the

court and give a good indication of which parts of the court that has been used.

1 INTRODUCTION

In the modern world jobs are becoming ever more

sedentary and less physically demanding. This leads

to higher demands for activities in people’s spare

time, which puts a still growing pressure on the sports

arenas. From 1964 to 2007 the number of athletes has

quadrupled with a steady increase (Pilgaard, 2009).

Surveys also show that people are dropping the classic

club sports in favour of more ﬂexible sports (Brixen

et al., 2010). This calls for a better and more optimal

use of the existing sports arenas to keep up with this

growing trend.

In order to improve the utilisation of a sports

arena, its existing use must be examined. This in-

cludes examining the number of users using the arena

at the same time and the occupancy of the court. Ad-

ministrators are especially interested in whether the

arena is empty, used by a few people or full and the

time for when the occupancy changes. The position

of the users is also important as they might only use

half a court, which means the other half could be

rented out to another group. Manual registration of

this would be cumbersome and expensive and an au-

tomatic approach is therefore needed. For such a sys-

tem to work in general it should be independent of the

size of the court, lighting conditions and without any

interaction with the users. This can be obtained with

a camera.

Detecting people with a camera raises some priva-

cy issues though. Not all people like surveillance and

the fear of being observed could keep some people

out of the arenas. This work therefore proposes an au-

tomatic method to analyse the occupancy of a sports

arena using thermal imaging. One of the advantages

of thermal cameras is that the persons recorded cannot

be identiﬁed, which is an important factor if the sys-

tem is to be accepted by the users of the sports arena.

On top of that, thermal cameras are invariant to light-

ing, changing backgrounds and colours, which make

them more desirable for a general application.

2 RELATED WORK

Automatic detection and tracking of sports players is

a research area important for all sports analysis. Most

systems are using visual cameras. In (Needham and

Boyle, 2001) a tracking system is proposed speciﬁ-

cally for indoor football players, while (Saito et al.,

2004) proposes a tracking system for outdoor foot-

ball using multiple cameras. The tracking system pro-

posed in (Xing et al., 2011) focuses on more general

sports video and it is tested on both football, basket-

ball and hockey.

The large research area regarding automatic iden-

tiﬁcation of human subjects and their behaviour in-

clude both visual and thermal cameras. There exist a

number of surveys and books on the subject, includ-

ing (Ko, 2008), (Turaga et al., 2008), (Wei and Yunx-

277

Gade R., Jørgensen A. and B. Moeslund T..

OCCUPANCY ANALYSIS OF SPORTS ARENAS USING THERMAL IMAGING.

DOI: 10.5220/0003843202770283

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2012), pages 277-283

ISBN: 978-989-8565-04-4

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

iao, 2009) and (Moeslund et al., 2011).

Thermal cameras measure the amount of thermal

radiation, which lies in the long-wavelength infrared

spectrum (8-15 µm). All objects with a temperature

higher than the absolute zero emit thermal radiation.

The intensity and dominating wavelength depends on

the temperature.

Thermal cameras have a clear advantage over vi-

sual cameras in night conditions, therefore the main

focus for systems using thermal cameras have been

on security applications and trespasser detection. A

few papers with the purpose of detecting trespassers

include (Wong et al., 2009) and (Wong et al., 2010).

Other work using thermal cameras include sys-

tems for pedestrian detection and tracking. In (Wang

et al., 2010) a pedestrian detection method is pre-

sented based on the Shape Context Descriptor with

the Adaboost cascade classiﬁer framework. (Bertozzi

et al., 2003) proposes the pedestrian detection as part

of a driver assistant system while (Davis and Sharma,

2004) proposes a people detection system for differ-

ent environments based on contour analysis.

Most vision systems, including the systems men-

tions above, are only tested on very short video se-

quences, proving the concept in one or few condi-

tions. In this work the most important issue is sta-

bility over a long time period and under different con-

ditions. Therefore the system will be tested over three

weeks and in ﬁve different arenas. The main results

will be average values showing the tendency of occu-

pancy for hours or days.

3 METHODS

3.1 System Overview

The desired system should take a thermal grey scale

image as input and ﬁnd every person in the image. In

order to analyse the nature of the problems related to

this work, ﬁve different sports arenas were selected

and used to develop and test the system. During the

initial investigations some typical difﬁculties to obtain

the result were registered. Some of these difﬁculties

were occlusions and reﬂections from both persons and

other warm objects, e.g. lamps, on the ﬂoor. These

typical difﬁculties must all be addressed in order to

make a general system.

As the intention is to monitor the long term use of

a sports arena, the system should always be operat-

ing. Therefore data should be processed in soft real-

time to avoid data pile ups. The output of the system

should be, for a given time, the number of users on

the court and their position.

The system should be independent of the camera’s

viewing angle in relation to the court, as long as the

camera can observe the court and is placed in a suf-

ﬁcient height to avoid users covering each other too

much. The users’ size, level of activity and posture

should not have an effect on the measurement either.

Figure 1 shows a diagram of the system structure.

The overall idea is to develop a system that can

detect persons in a thermal image and, with the in-

puts from the initialisation, ﬁnd the persons’ positions

at the court. As mentioned in the introduction, the

data should be categorised after the occupancy level

into zero, some and many people and presented in a

timetable.

3.2 Initialising the System

The initialisation routine must be conducted for each

new mounting of the camera. This routine handles the

adjustments necessary to ﬁt the system to the layout of

the actual sports arena. First the court must be found

in the image to avoid that cold or hot objects outside

the court inﬂuences the system. As it is only wanted

to measure the players at the court, spectators should

also be removed. Deﬁning the court in the images

gives the opportunity to remove all objects standing

outside the court. During the initialisation the corners

of the visible part of the court should be marked in

the image, and lines connecting them deﬁne the out-

line of the court. To ﬁnd the persons’ positions at

the court a mapping from the image to the court must

be found. Using at least four corresponding points in

image and world coordinates, a homography matrix

H can be calculated (Criminisi, 1997).

After initialising this matrix the mapping between

image coordinates and world coordinates is calculated

as P

= H p

, where P

are the weighted world coor-

dinates [P

W ]

and p

are the image coordinates

. The real world coordinates are found by

dividing P

with the weight W .

At least four corresponding points must be used

in order to calculate H, but tests of the homography

show that using more points increase the precision.

This is due to nonlinearity in the mapping, as the lens

has some barrel effect. Therefore it is desirable to

use as many points in the initialisation as possible.

In this work a two-dimensional grid with steps of 5

metres is used to mark the points at the court. A hot

or cold object is necessary to detect the grid points in

the image.

3.3 Run-time

This continuous loop receives an image from the ther-

VISAPP 2012 - International Conference on Computer Vision Theory and Applications

278

Thermal Camera Input

Find Court Corners in the Image

Person Detections

Find each Person's Position

Map to Court Coordinates

Run-time

Initialisation

Hour

Monday Tuesday Wednesday Thursday Friday Saturday Sunday

7-8

8-9

9-10

10-11

11-12

12-13

13-14

14-15

15-16

16-17

17-18

18-19

19-20

20-21

21-22

22-23

School School School School School

Club

Club Club Club Club

Club

Figure 1: Diagram showing the system steps.

mal camera and after a number of functions it deliv-

ers a set of regions each containing one person. First

the thermal camera captures a grey scale image. The

warm objects (persons) are bright while the surround-

ings are dark grey. After capturing a frame the ﬁrst

step is to extract the warm objects. For this an auto-

matic threshold method based on Maximum Entropy

is used (Kapur et al., 1985). This method maximises

the sum of the entropy above and below the thresh-

old value s, by iterating through every possible value.

The threshold function is only run for the pixels

inside the court area, to avoid disturbance from spec-

tators. The result is a binary image where ideally the

persons are white and anything else is black. If the

maximum entropy is below a speciﬁed threshold TH

there are no persons on the court and the frame can be

discarded.

The white regions are now found using the con-

tour ﬁnding algorithm described in (Suzuki and Abe,

1985). If there are no valid regions i.e. regions larger

than a speciﬁed minimum area the frame is discarded.

3.3.1 Split Tall Regions

People standing behind each other, seen from the

camera’s point of view, can often be found as one tall

region as shown in ﬁgure 2(a). In order to split such

regions into the right number of people, it must be in-

vestigated when a region is too high to contain only

one person. Using the camera’s height c, the vertical

resolution r

and vertical ﬁeld-of-view f

of the cam-

era, the height in pixels can be found as a function of

the person’s height p and distance to the camera x:



tan

−1



c−p



−tan

−1







Statistics show that only 0.26% of Danish conscripts

were taller than 2 metres (DST, 2006), therefore 2

metres is chosen as the height limit. So for each re-

gion found in the image the distance to the camera

is calculated using the homography and if the pixel

height corresponds to more than 2 metres, the algo-

rithm should try to split the region horizontally. This

is done by ﬁnding the convex hull and the convexity

defects of the contour, as shown in ﬁgure 2(b). The

point selected to split from is the defect point with the

largest depth and a maximum absolute gradient of 1.5.

The gradient is calculated for the line from the defect

point perpendicular on the line between the convexity

defect start and end points (green points and yellow

line in ﬁgure 2(c)). The defect point between the legs

of the person has the largest depth, but is discarded

because the gradient is too high. Also the defect point

should not be in the top or bottom fourth of the region,

to avoid e.g. feet or head to be split from the body. As

shown in ﬁgure 2(d) the region is split horizontally

from the selected point.

The algorithm starts with the defect point with

largest depth and continues until a point with an ac-

ceptable gradient and location is found. If no accepted

points are found, the region will not be split. If the re-

gion has been split, the algorithm will start over and

examine the height of the resulting regions.

OCCUPANCY ANALYSIS OF SPORTS ARENAS USING THERMAL IMAGING

279

(a) (b) (c) (d)

Figure 2: Example on division of tall regions. Note that

black and white colours are reversed for better visibility.

The blue line is the convex hull, red marks indicate convex-

ity defects and the yellow line the orthogonal depth of the

defect.

3.3.2 Remove Reﬂections

Just as visible light, infrared waves are also reﬂected

in glossy surfaces, but as the infrared reﬂections are

created by the persons themselves they are always

pointing towards the camera. Therefore the mirror

axis will be roughly horizontal, and reﬂections could

be removed by trying to mirror them in a region

above. An example can be seen in ﬁgure 3(a)(Left).

(a) (b)

Figure 3: Persons having their reﬂection removed. The red

areas mark the reﬂections after they have been mirrored and

translated. In (b) the reﬂection is ﬁrst split from the person

by the algorithm splitting tall regions.

In order to remove reﬂections the system searches

for regions that are below a larger or equally sized re-

gion. If such a region is found it is mirrored up in the

upper region to see if it ﬁts in the person region. If it

does not, the reﬂection is translated one pixel horizon-

tally and checked again. This continues up to three

pixels in all directions. If more than 90 % of the re-

ﬂection is within the person region it is marked as a

reﬂection and removed. Figure 3(a)(Right) shows a

situation where 77 out of 79 pixels are within the per-

son region resulting in a coverage of ≈ 97%.

In some cases the reﬂection is connected to the

person who created it. See ﬁgure 3(b)(Left). In these

situations the region should ﬁrst be split by the func-

tion splitting tall regions. Figure 3(b) shows a situ-

ation where a region is ﬁrst split and secondly the

reﬂection can be removed. Here 72 of 74 (≈ 97%)

reﬂection pixels are within the person.

3.3.3 Split Wide Regions

People standing close to each other will often form

one large region. In order to count the people correct

such regions must be divided into regions containing

only one person. For groups of people standing side

by side, seen from the camera’s point of view, it will

often be possible to separate them based on their head

position. Since their heads are narrower than the body

they can often be separated by cutting vertically from

the minimum points of the upper edge.

As it is not desired to split regions containing only

one person, two criteria for the regions must be sat-

isﬁed before looking for a minimum point to split

from. Measuring the features of several regions gives

the criteria that to contain more than one person the

height of the bounding box must be less than ﬁve

times the width and the contour of the region must be

longer than the bounding box perimeter. If these cri-

teria are satisﬁed and a minimum point can be found

at the upper edge of the region, the region will be di-

vided.

The points are now found as convexity defects in

the same way as described for the tall regions. In-

stead of measuring the angle this method uses the y-

coordinates of the points. The found point must be

located on the upper edge of the region and have a

y-value greater than both the convexity defect’s start

and end point to make it a minimum point.

As for splitting the tall regions, the algorithm will

continue until no more regions are split.

3.3.4 Sort Regions

The ﬁnal step is to sort the regions. After the re-

gions have been split and the reﬂections have been

removed, the remaining regions are now investigated

before they are counted as a person. If a region’s

area does not match its distance to the camera it is

removed. This could be a small region which is found

in the foreground where persons typically would be

larger. This step also calculates the person’s position

VISAPP 2012 - International Conference on Computer Vision Theory and Applications

280

on the court, using the homography from the initiali-

sation. This is done for the lowest middle pixel of the

accepted regions, which will be the position on the

ﬂoor.

3.4 Occupancy of the Court

A user’s position will be given as a x,y coordinate

with multiple decimals. In order to examine the occu-

pancy a method must be found that preserves the po-

sition, but also mimics the size of a person. Therefore

every found region is represented as a 3D gaussian

distribution with a height of 1 and σ = 5, equivalent

to a radius of 1 metre for 95 % of the volume. This

is also roughly the radius of a person. An example

for one frame can be seen in ﬁgure 4 where 8 persons

have been found.

Figure 4: A single frame where 8 persons have been found.

For longer periods these frames can be summed to

show the occupancy of the court during e.g. an hour.

4 RESULTS

4.1 Objective

As described in section 2 a very important parame-

ter for the system is the stability in changing condi-

tions and in changing set-ups. Therefore the system

is tested in ﬁve different arenas, capturing more than

three weeks altogether. For all tests in different are-

nas the same parameters of the system has been used.

Only the initialisation of the system, described in sec-

tion 3.2, depends on the arena. By measuring the en-

tropy of a number of frames with and without people,

the entropy threshold TH is chosen to be 4.1. The

thermal camera used in the test is an AXIS Q1921-E,

with a resolution of 384×288 pixels and a horizontal

ﬁeld-of-view of 55

◦

4.2 Annotation of Data

Capturing three weeks continuously with 30 fps gives

a total of 54,432,000 frames, which would be nearly

impossible to manually annotate. Therefore it is cho-

sen to manually annotate 54,000 frames, resulting in

30 minutes of video. This will be used for calculat-

ing the precision of the system. But as this test does

only evaluate the system during one speciﬁc activity

an additional test will be conducted. A period of 36

consecutive hours will be sampled and manually an-

notated with 0.04 fps (1 frame per 25 seconds). This

is covering two days with different sports activities

and a night. Even though the frame rate here is low

this will still give a good evaluation of the system and

ensure that it is tested with both a varying number of

people and different types of sports. The data from

the full test period of more than three weeks will be

evaluated by random checks against the videos.

4.3 30 Minutes Test

The results for the 30 minutes period are calculated

as a mean number for every ﬁve minutes. The auto-

matic results compared to the ground truth (manually

annotated data) are shown in ﬁgure 5 with black and

red.

Figure 5: Manual (red) and automatic (black) result for six

ﬁve minutes periods, sampled with 30 frames per second,

and automatic results (green) sampled with 0.04 frames per

second.

Calculating the error of the automatic system,

sampled with 30 fps, for each ﬁve minutes period

gives an average error of 20.5 %. Comparing the

green line to the black line shows that in 4 out of 6 pe-

riods the automatic results with different sample rates

are nearly the same, while for the last two periods the

difference is about 0.5 person. From this it is con-

cluded that even with a sample rate decreased to 0.04

fps the results will still be reliable.

OCCUPANCY ANALYSIS OF SPORTS ARENAS USING THERMAL IMAGING

281

4.4 Two Days Test

For the 36 hours, sampled with 1 frame per 25 sec-

onds, a mean error is found for every ﬁve minutes,

and stated as a mean error for each hour, since the

activities in the arena are typically the same for at

least an hour. This method is used for both the er-

ror measured in persons and per cent. The hours are

then categorised by the maximum number of people,

to investigate the relation between the error and the

number of persons. See the results in table 1.

Table 1: Error categorised by the maximum number of peo-

ple during the hour.

# persons # hours Mean error Mean error (%)

0 12 0.0017 0.17 %

1-2 15 0.0428 7.35 %

7-15 9 0.5100 11.76 %

For the nine hours with maximum 7-15 persons

on the court the error for each hour lies from 4-20

%, with an average of 11.76 % as stated in table 1.

It is clear that the error for detecting empty arenas is

very low, and the error increases with the number of

persons. This will typically be due to occlusions. As

mentioned in section 3.1 the occupancy level should

be categorised to zero, some or many users, which

means that the precise number of people is not critical

for this application.

The 30 minutes test described in section 4.3

showed an error of 20.5 %, which is equivalent to the

maximum error found during this two day test. The

video of 30 minutes had a high activity level and a

highly varying number of people on the court, with

up to 14 people in each frame. Therefore it is also

expected that it should have a higher error than the

average videos.

4.5 Evaluation of Positions

The calculated positions of the persons will be evalu-

ated by visually comparing the manually marked po-

sitions with the automatic found positions. This is

done for the 36 hours sampled with 1 frame per 25

seconds. An example of one hour showing a hand-

ball match can be seen in ﬁgure 6. The upper im-

age shows the positions found by the system and the

lower image shows the true position found manually

for the same period. There are found more people

manually than automatic during this hour, resulting in

darker colours in the bottom image, but it is evident

that there is a high correlation between the two im-

ages and the overall picture is the same. Note that the

camera could only see the left half of the court.

(a) (b)

Figure 6: Positions of users during a handball match. Left:

Automatic. Right: Ground truth. Note that there are found

more people manually than automatic, resulting in darker

colours in the bottom image.

As mentioned in section 1 the position should be

used to examine whether the entire court is being used

or only part of it. Therefore the main point in evaluat-

ing the found positions is not to examine the position

of each person, but to ensure that the overall picture of

the occupancy during a booking is correct. This cor-

relation between automatic and manually found posi-

tions is found to be very high for all 36 hours.

4.6 One Week Evaluation

The main objective for this system is to analyse the

use of the sports arenas. Most sports arenas in Den-

mark have a booking system, where the local schools

and sports clubs book their hours in the arena. To

evaluate the use of the arenas the bookings should

be considered. Seven consecutive days in one sports

arena has been chosen, and the use is here measured

as a mean number of persons per hour. The number is

categorised as zero, some or many persons to describe

the level of occupancy. Table 1 showed that the preci-

sion of the system depends on the number of persons,

the error increases when the number increases. As the

error is very low for detecting empty arenas and few

people on the court, the error of the exact number will

not have a visible effect on the categorisation.

Finally the utilisation is compared to the booking

as shown in ﬁgure 7. White areas are not booked,

red areas are booked but never used, orange areas are

booked and used by two or less persons in average,

the green area are booked and used by more than two

persons in average while the blue areas are used by

more than two persons, but not booked. During this

test a frame rate of 1 fps has been used.

Figure 7 indicates that during the measured seven

days 21.2 % of the booked hours are not used, while

23.4 % are used by an average of two or less persons,

which either means that the arena has only been used

for a very short period of the hour, or there have been

only one or two people at the court. One hour are

used but not booked, which could also be a problem,

VISAPP 2012 - International Conference on Computer Vision Theory and Applications

282

Figure 7: Table of utilisation compared to the booking.

White areas are not booked, red areas are booked but never

used, orange areas are booked and used by two or less per-

sons in average, green areas are booked and used by more

than two persons in average and blue areas are used by more

than two persons, but not booked.

depending on the policy for the administration of the

arena.

5 CONCLUSIONS

This work presented an approach for automatic de-

tection of persons using thermal cameras. For the in-

tended application in sports arenas the privacy issue

is important, therefore a thermal camera is chosen.

The system shows very satisfactory results, with

only a short initialisation it works independently of

the changing conditions in different arenas. The sys-

tem can easily distinguish between an empty arena,

few or many people. The work will continue with

further tests of the system and work on improving the

segmentation of people. This could be by including

temporal information or by using a more detailed hu-

man template for comparison with the found regions.

For future work there are a lot of possibilities for de-

veloping new features, including analysis of the activ-

ity level, activity type and user type.

ACKNOWLEDGEMENTS

We would like to thank Aalborg municipality for sup-

port and for providing access to the sports arenas.

REFERENCES

Bertozzi, M., Broggi, A., Grisleri, P., Graf, T., and Mei-

necke, M. (2003). Pedestrian detection in infrared im-

ages. In Intelligent Vehicles Symposium, 2003. Pro-

ceedings. IEEE, pages 662 – 667.

Brixen, S., Larsen, K. H., Lindholm, J. V., Nielsen, K. F.,

and Riiskjær, S. (2010). Strategi 2015: En Situations-

analyse (Strategy 2015: A Situation Analysis). DGI.

Criminisi, A. (1997). Computing the plane to plane homog-

raphy. Technical report, University of Oxford.

Davis, J. and Sharma, V. (2004). Robust detection of peo-

ple in thermal imagery. In Pattern Recognition, 2004.

ICPR 2004. Proceedings of the 17th International

Conference on, volume 4, pages 713 – 716 Vol.4.

DST, D. S. (2006). Tabel 44: De værnepligtiges

højde (conscripts’ height in 2006).

http://www.dst.dk/aarbogstabel/44.

Kapur, J., Sahoo, P., and Wong, A. (1985). A new method

for gray-level picture thresholding using the entropy

of the histogram. Computer Vision, Graphics, and Im-

age Processing, 29(3):273 – 285.

Ko, T. (2008). A survey on behavior analysis in

video surveillance for homeland security applications.

In Applied Imagery Pattern Recognition Workshop,

2008. AIPR ’08. 37th IEEE, pages 1 –8.

Moeslund, T. B., Hilton, A., Kr

uger, V., and Sigal, L.

(2011). Visual Analysis of Humans - Looking at Peo-

ple. Springer.

Needham, C. J. and Boyle, R. D. (2001). Tracking multi-

ple sports players through occlusion, congestion and

scale. In British Machine Vision Conference, pages

93–102.

Pilgaard, M. (2009). Sport og Motion i Danskernes Hverdag

(Sport and Exercise in the Everyday Life of Danish

People). Idrættens Analyseinstitut.

Saito, H., Inamoto, N., and Iwase, S. (2004). Sports scene

analysis and visualization from multiple-view video.

In Multimedia and Expo, 2004. ICME ’04. 2004 IEEE

International Conference on, volume 2, pages 1395

–1398 Vol.2.

Suzuki, S. and Abe, K. (1985). Topological structural anal-

ysis of digitized binary images by border following.

Computer Vision, Graphics, and Image Processing,

30(1):32 – 46.

Turaga, P., Chellappa, R., Subrahmanian, V., and Udrea, O.

(2008). Machine recognition of human activities: A

survey. Circuits and Systems for Video Technology,

IEEE Transactions on, 18(11):1473 –1488.

Wang, W., Zhang, J., and Shen, C. (2010). Improved human

detection and classiﬁcation in thermal images. In Im-

age Processing (ICIP), 2010 17th IEEE International

Conference on, pages 2313 –2316.

Wei, W. and Yunxiao, A. (2009). Vision-based human mo-

tion recognition: A survey. In Intelligent Networks

and Intelligent Systems, 2009. ICINIS ’09. Second In-

ternational Conference on, pages 386 –389.

Wong, W. K., Chew, Z. Y., Loo, C. K., and Lim, W. S.

(2010). An effective trespasser detection system us-

ing thermal camera. In Computer Research and De-

velopment, 2010 Second International Conference on,

pages 702 –706.

Wong, W. K., Tan, P. N., Loo, C. K., and Lim, W. S. (2009).

An effective surveillance system using thermal cam-

era. In Signal Acquisition and Processing, 2009. IC-

SAP 2009. International Conference on, pages 13 –17.

Xing, J., Ai, H., Liu, L., and Lao, S. (2011). Multiple

player tracking in sports video: A dual-mode two-way

bayesian inference approach with progressive obser-

vation modeling. Image Processing, IEEE Transac-

tions on, 20(6):1652 –1667.

OCCUPANCY ANALYSIS OF SPORTS ARENAS USING THERMAL IMAGING

283
