A COMPARISON BETWEEN BACKGROUND SUBTRACTION

ALGORITHMS USING A CONSUMER DEPTH CAMERA

Klaus Greff

1,3

, André Brandão

1,2,3

, Stephan Krauß

, Didier Stricker

1,3

and Esteban Clua

German Research Center for Artiﬁcial Intelligence (DFKI), Kaiserslautern, Germany

Federal Fluminense University (UFF), Niterói, Brazil

Technical University of Kaiserslautern, Kaiserslautern, Germany

Keywords:

Foreground Segmentation, Background Subtraction, Depth Camera, Kinect.

Abstract:

Background subtraction is an important preprocessing step in many modern Computer Vision systems. Much

work has been done especially in the ﬁeld of color image based foreground segmentation. But the task is not an

easy one so, state of the art background subtraction algorithms are complex both in programming logic and in

run time. Depth cameras might offer a compelling alternative to those approaches, because depth information

seems to be better suited for the task. But this topic has not been studied much yet, even though the release of

Microsoft’s Kinect has brought depth cameras to the public attention. In this paper we strive to ﬁll this gap, by

examining some well known background subtraction algorithms for the use with depth images. We propose

some necessary adaptions and evaluate them on three different video sequences using ground truth data. The

best choice turns out to be a very simple and fast method that we call minimum background.

1 INTRODUCTION

The release of Microsoft’s Kinect had a huge impact

on computer vision. This device changed the face

of many problems such as gesture recognition (Tang,

2011), activity monitoring, 3D reconstruction (Cui

and Stricker, 2011) and SLAM (Henry et al., 2010;

Sturm et al., 2011).

The fusion of different sensors, combined with a

very low price, makes the Kinect an excellent choice

for many applications. Its certainly most interesting

sensor is the depth camera, that Microsoft used to

ship a product quality gesture control for the Xbox

360. Since then, the Kinect has been used for a

wide variety of problems including skeleton track-

ing (Kar, 2010), gesture recognition (Tang, 2011),

activity monitoring, collision detection (Pan et al.,

2011), 3D reconstruction (Cui and Stricker, 2011) and

robotics.

Many applications, especially those from the ﬁeld

of human computer interaction, utilize a static cam-

era to track moving persons or objects. Those appli-

cations greatly beneﬁt from background subtraction

algorithms, which separate the foreground (objects of

interest) from the potentially disturbing background.

This preprocessing step is well known in computer vi-

sion (for an overview see (Cannons, 2008)) and helps

Figure 1: Foreground objects (right) are detected in depth

images (left) taken by a static depth camera.

to reduce the complexity of further analysis and can

even increase the quality of the overall result.

Also, the task of background subtraction appears

to be easier with a depth image at hand. It is therefore

quite surprising to see that only little work on the sub-

ject can be found. Early publications deal with back-

ground subtraction based on the use of stereoscopic

cameras (Gordon et al., 1999; Ivanov et al., 2000).

There are papers dealing with the Kinect, which men-

tion the use of background subtraction (Kar, 2010;

431

Greff K., Brandão A., Krauß S., Stricker D. and Clua E..

A COMPARISON BETWEEN BACKGROUND SUBTRACTION ALGORITHMS USING A CONSUMER DEPTH CAMERA.

DOI: 10.5220/0003849104310436

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2012), pages 431-436

ISBN: 978-989-8565-03-7

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Stone and Skubic, 2011; Tang, 2011; Xia et al., 2011),

however, there is no publication dealing with the topic

directly.

This paper tries to ﬁll this gap and provide a

starting point for further research. We start by an-

alyzing the characteristics of the Kinect depth cam-

era (Section 2), and their impact on the problem of

background subtraction problem (Section 3). After

that, we we choose four background subtraction algo-

rithms (Section 4), and adapt them to the domain of

depth images (Section 5). Finally we evaluate them

using three different depth videos along with their

ground truth segmentation (Sections 6 and 7).

2 KINECT DEPTH IMAGE

CHARACTERISTICS

We start this section by delivering an overview of the

distinct characteristics of depth images provided by

Kinect. They will provide the basis to analyze the

problems associated with the task of foreground de-

tection. The functional principles of the Kinect will

not be discussed in this paper (Refer to (Khoshelham,

2011) instead).

Although depth image resolution is 640×480 pix-

els but the effective resolution is much lower since the

depth calculation depends on small pixel clusters. The

detection range is between 50 cm and about 5 m with

a ﬁeld of view of approximately 58 °. Depth informa-

tion is encoded using 11 bit for the depth information

and 1 bit indicating an undeﬁned value.

But the most important property is obviously the

usage of distance information instead of color intensi-

ties. This which makes the image independent of illu-

mination, texture and color. Direct sunlight, however,

can outshine the projected pattern, turning many pix-

els to undeﬁned. Certain kinds of material properties

can also hinder a stable depth recognition, including

high reﬂectiveness and transparency or dark colors.

The depth image contains different types of distur-

bances and noise. We characterize the pixels accord-

ing to those errors as follows:

• Stable: A ﬁxed depth value with only a small

variance increasing quadratically with range (see

(Khoshelham, 2011)).

• Undeﬁned: A special value meaning that no

depth information is available. This is typical for

object shadows, direct sunlight, and objects below

the minimum range of 50cm.

• Uncertain: Switching in a random manner be-

tween the undeﬁned and stable state. This is of-

ten the case for boundaries of undeﬁned regions,

reﬂections, transparencies, very dark objects, and

ﬁne-structured objects (e.g. hair).

• Alternating: Switching between two different

stable values.

Occasionally, there are pixels with “uncertain” and

“alternating” characteristics, i.e. they switch between

two different stable values and the undeﬁned state.

It is also important to note that alternation and un-

certainty do not usually occur pixel-wise but cluster-

wise, therefore contours may differ substantially from

frame to frame.

3 FOREGROUND DETECTION

CHALLENGES

In the following we give a summary of challenges

faced by background subtraction algorithms that work

on depth images. The list is based upon the more de-

tailed summary of (Toyama et al., 1999). We recite

only the challenges related to depth images, and also

modiﬁed the descriptions to better reﬂect the charac-

teristics of depth images as provided by the Kinect

sensor.

Moved Objects: The method should be able to adapt

to changes in the background such as a moved

chair or a closed door.

Time of Day: Direct sunlight can outshine the in-

frared patterns used for depth estimation, result-

ing in undeﬁned pixels in the according regions.

If the illumination changes, the state of the pixels

in the affected regions might also change (to sta-

ble or undeﬁned), which results in the pixel class

“uncertain” (see Section 2). This is similar to the

moved object problem.

Dynamic Background This problem, originally re-

ferred to as waving trees in (Toyama et al., 1999),

can be caused by any constantly moving back-

ground object e.g. slowly pivoting fans.

Bootstrapping: In some environments it is neces-

sary to learn a background model in the presence

of foreground objects.

Foreground Aperture: When a homogeneous back-

ground object moves, changes in the inner part

might not be detected by a frame to frame differ-

ence algorithm. This is especially true for depth

images, because there is no color and texture.

Shadows and Uncertainty: The system has to cope

with undeﬁned and uncertain pixels (see Sec-

tion 2) both in the fore- and background. Addi-

tionally, foreground objects often cast shadows,

VISAPP 2012 - International Conference on Computer Vision Theory and Applications

432

which should not be considered to be foreground.

This problem behaves differently with the Kinect

because only the inherent shadow casting of the

sensor is relevant. Also these shadows always re-

sult in an undeﬁned value making it easy to rule

them out as foreground.

We omitted the point “Light Switch” as artiﬁcial

lighting does not affect the Kinect. Furthermore, the

challenges “Sleeping Person” and “Waking Person”

were dropped, because we believe this task is better

solved at a higher level that includes semantic knowl-

edge

. Finally, the “Camouﬂage” problem was also

omitted, since depth images lack both, color and tex-

ture.

4 BASIC METHODS

Many background subtraction and foreground detec-

tion algorithms have been proposed. Cannons (Can-

nons, 2008) provides an overview of the subject. Most

of those algorithms were created having color images

in mind. In our work we chose four standard meth-

ods and adapted to the segmentation of depth images,

achieving three suitable and high quality possible so-

lutions.

First Frame Subtraction: In this method the ﬁrst

frame of the sequence is subtracted from every

other frame. Absolute values that exceed a thresh-

old are marked as foreground.

Single Gaussian: In this method, the scene is mod-

eled as a texture and each pixel of this model is

associated to a Gaussian distribution. During a

training phase pixel-wise mean and variance val-

ues are calculated. Later on pixel values that differ

more than a constant times the standard deviation

from its mean are considered foreground. This

method was used in Pﬁnder (Wren et al., 1997).

Codebook Model: This more elaborate model (Kim

et al., 2005) aggregates the sample values for each

pixel into codewords. The Codebook model con-

siders background values over a long time. This

allows to account for dynamic backgrounds and is

also used to bootstrap the system in the presence

of foreground objects.

Minimum Background: This is one of the

ﬁrst models completely developed depth im-

ages (Stone and Skubic, 2011). During training

stage, the minimum depth value for each pixel

is stored. Afterwards every pixel closer to the

For more in-depth discussion please refer to (Toyama

et al., 1999) Section 4.

camera (depth value smaller than stored value) is

considered foreground. This works well for range

based data because the foreground usually is in

front of the background.

5 ADAPTATIONS

The presented methods need to be adapted in order to

work for depth images. So we developed and included

different improvements: Uncertainty Treatment, Fill-

ing the Gaps and Post-Processing.

Uncertainty Treatment: Treating the undeﬁned

value (zero) as a normal depth information leads to

problems with almost every model (e.g. turning most

shadows into foreground). So the question arises how

to treat undeﬁned values. We certainly do not want

a shadow of an object to be considered foreground.

But sometimes the shadow of some object falls onto

the foreground, for example a hand in front of the

torso. Or the foreground contains undeﬁned regions,

as caused by glass for example. These problems illus-

trates that on a pixel level the question, whether some

undeﬁned value belongs to the foreground or not, is

impossible to decide. This decision clearly requires

additional knowledge (other sensory input, the region

around the pixel). But it is not the task of a fore-

ground detection algorithm to do complex reasoning.

It should merely be a preprocessing step (see Princi-

ple 1 in (Toyama et al., 1999)). Thus, we decided

to treat all undeﬁned values as background for all the

presented methods.

Filling the Gaps: Undeﬁned pixel values can lead

to gaps within the background model learned by each

presented algorithm. Those gaps can lead to errors

because every "deﬁned" pixel value differs from an

undeﬁned background. So depending on the chosen

policy they will either lead to false positives or to

false negatives. In order to close these gaps, an im-

age reconstruction algorithm (like (Telea, 2004)) that

tries to estimate the correct values for the undeﬁned

regions can be used. This can obviously only re-

duce the errors induced by those gaps, and not com-

pletely eliminate it. According to our experiments,

the method from (Telea, 2004) works quite well in

practice.

Post-processing: As discussed earlier, the depth

images as generated by Kinect contain lots of noise.

This leads to a large amount of false positives in form

of very small blobs and thin edges around objects.

The desired foreground (i.e. humans) on the other

hand appears always quite large because of the range

A COMPARISON BETWEEN BACKGROUND SUBTRACTION ALGORITHMS USING A CONSUMER DEPTH

CAMERA

433

constraints of the Kinect sensor. Therefore, morpho-

logical ﬁlters are an easy way of improving the ﬁ-

nal result. We experimented with the erode-dilate-

operation and the median ﬁlter, but both of them

change the contour of the desired foreground. A con-

nected component analysis, on the other hand, com-

bined with an area threshold is suitable to remove the

false positive regions while keeping the foreground

intact. This threshold can be quite high for most ap-

plications (1000 pixels in our case). This ﬁltering is

applied as a post-processing step to all of the pre-

sented methods. However, we also evaluate each of

them without any ﬁltering.

6 EXPERIMENTS

In order to evaluate the different approaches we

recorded a set of three typical sequences for the ap-

plication of human body tracking. All of them are

recorded indoors at 30 fps and with VGA resolution.

Every sequence contains at least 100 training frames

of pure background.

Gesturing 1: The camera shows a wall in a distance

of approximately 3 meters for a few seconds.

Then a person enters and stands in front of the

sensor performing some gestures (641 frames).

Gesturing 2: The same as in the ﬁrst sequence, but

the background contains a lot of edges (643

frames).

Occlusion: This sequence shows an ofﬁce with some

chairs, then a person enters and walks in between

those chairs. The ideal foreground for this se-

quence is marked manually in every frame (567

frames).

The Kinect depth sensor produces data with high

noise at the edges of objects. For this kind of noise a

single frame evaluation would not be representative.

Therefore, we created ground truth videos containing

the ideal foreground segmentation for each sequence.

The ﬁrst two sequences were recorded in a way that

simple distance truncation cleanly separates the fore-

ground. For the third sequence the foreground was

marked manually in each frame.

7 RESULTS AND DISCUSSION

We measured the error of every algorithm using the

absolute amount of false positives N

(background

that was marked as foreground) and false negatives

−

(foreground that was marked as background). To

establish some comparability we also measure an er-

ror ratio for every sequence, that is

and e

−

(1)

respectively, where N

and N

are the total number

of background and foreground pixels in the ground

truth sequence. The results can be found in Table 1

and some selected frames for every video and method

are shown in Figure 2.

The First Frame Subtraction, performs surpris-

ingly well. Unﬁltered, it produces the least false neg-

ative ratio among all considered algorithms. But it

is sensitive to all sorts of noise, so depending on the

background this can lead to many false positives.

The statistical approach used by the Single Gaus-

sian method is affected by the high variances of alter-

nating pixels on the one hand and the low variance of

stable pixels on the other hand. If the constant multi-

plied with the standard deviation is high, this will lead

to false negatives when a foreground object occludes

the high variance region. If the constant is small, sta-

ble pixels will emit a lot of noise. Consequently, we

concluded that the depth values provided by Kinect

cannot be modeled effectively by a single Gaussian

distribution.

The best overall results are achieved by the Code-

book Model and the simple Minimum Background

method. Both methods manage to eliminate the errors

of uncertain and alternating regions without missing

the desired foreground. Since the Minimum Back-

ground method is faster and simpler, we found it to be

the best choice among the algorithms we have consid-

ered. This result might not come as a surprise, since

the Minimum Background method is the only one that

takes advantage of the depth information.

8 CONCLUSIONS

In this paper we have adapted four different ap-

proaches of background subtraction to depth images.

They were evaluated on three different test sequences

using ground truth data. We have identiﬁed a simple

and fast algorithm, the Minimum Background algo-

rithm, that gives close to perfect results. So for the

scenario of a static Kinect and a static background the

problem of background subtraction can be considered

solved. This clearly shows the task of background

subtraction to be much easier for depth images than

for color images.

Nevertheless, there are still some open questions

for future work. Scenarios with a moving Kinect, or

VISAPP 2012 - International Conference on Computer Vision Theory and Applications

434

Table 1: The results for the algorithms run on the test sequences. The rows with e

and e

−

represent false positives and false

negatives respectively. The values are speciﬁed with respect to the total number of background pixels in the ground truth data.

The lowest positive and negative errors are highlighted for each test sequence.

Gesturing 1 Gesturing 2 Occlusion

= 179, 896, 685 N

= 160, 009, 777 N

= 164, 507, 583

= 17, 018, 515 N

= 37, 519, 823 N

= 9, 674, 817

plain, in % ﬁltered, in % plain, in % ﬁltered, in % plain, in % ﬁltered, in %

First Frame e

8.83 2.67 0.71 0.02 1.75 0.09

Subtraction e

−

0.00 0.05 0.00 0.37 0.91 1.58

Single e

0.52 0.19 1.91 0.07 2.40 0.85

Gaussian e

−

8.33 9.15 9.98 13.55 6.42 9.02

Codebook e

0.06 0.01 0.04 0.01 0.24 0.07

Model e

−

0.00 0.03 0.00 0.30 1.32 1.84

Minimum e

0.06 0.00 0.04 0.00 0.19 0.07

Background e

−

0.00 0.02 0.00 0.37 1.20 1.94

Gesturing 1 Gesturing 2 Occlusion

Depth Image

Ground Truth

Single

Gaussian

Codebook

First Frame

Subtraction

Minimum

Background

plain filtered plain filtered plain filtered

Figure 2: Sample images from the segmentation for all methods and all sequences. Every image is presented with and without

ﬁltering (see Post-Processing in Section 5).

a dynamic Background require more sophisticated al-

gorithms. For the problem of bootstrapping we sug-

gest testing more complex background subtraction

techniques, e.g. optical-ﬂow, that try to handle fore-

ground clutter in the training phase. Finally, the color

camera of the Kinect could complement the depth

camera for the task of background subtraction.

ACKNOWLEDGEMENTS

We would like to thank the German Research Cen-

ter for Artiﬁcial Intelligence (DFKI), Federal Flumi-

nense University - Brazil (UFF), CAPES-Brazil, DFG

IRTG 1131 and German Academic Exchange Service

(DAAD).

A COMPARISON BETWEEN BACKGROUND SUBTRACTION ALGORITHMS USING A CONSUMER DEPTH

CAMERA

435

REFERENCES

Cannons, K. (2008). A review of visual tracking. Technical

Report CSE-2008-07, York University, Department of

Computer Science and Engineering.

Cui, Y. and Stricker, D. (2011). 3D shape scanning with a

Kinect. In ACM Transactions on Graphics.

Gordon, G., Darrell, T., Harville, M., and Woodﬁll, J.

(1999). Background estimation and removal based

on range and color. In Computer Vision and Pattern

Recognition, 1999. IEEE Computer Society Confer-

ence on., volume 2.

Henry, P., Krainin, M., Herbst, E., Ren, X., and Fox,

D. (2010). RGB-D mapping: Using depth cameras

for dense 3D modeling of indoor environments. In

Proc. of the International Symposium on Experimen-

tal Robotics (ISER), Delhi, India.

Ivanov, Y., Bobick, A., and Liu, J. (2000). Fast lighting

independent background subtraction. International

Journal of Computer Vision, 37(2):199–207.

Kar, A. (2010). Skeletal tracking using Microsoft Kinect.

Department of Computer Science and Engineering,

IIT Kanpur.

Khoshelham, K. (2011). Accuracy analysis of kinect depth

data. In ISPRS Workshop Laser Scanning, volume 38.

Kim, K., Chalidabhongse, T. H., Harwood, D., and Davis,

L. (2005). Real-time foreground-background segmen-

tation using codebook model. Real-Time Imaging,

11(3):172–185.

Pan, J., Chitta, S., and Manocha, D. (2011). Probabilistic

collision detection between noisy point clouds using

robust classiﬁcation. In International Symposium on

Robotics Research (ISRR).

Stone, E. and Skubic, M. (2011). Evaluation of an inex-

pensive depth camera for passive in-home fall risk as-

sessment. In Pervasive Health Conference, Dublin,

Ireland.

Sturm, J., Magnenat, S., Engelhard, N., Pomerleau, F., Co-

las, F., Burgard, W., Cremers, D., and Siegwart, R.

(2011). Towards a benchmark for RGB-D SLAM

evaluation. In Proc. of the RGB-D Workshop on Adv.

Reasoning with Depth Cameras at Robotics, Los An-

geles, USA.

Tang, M. (2011). Recognizing hand gestures with Mi-

crosoft’s Kinect. Department of Electrical Engineer-

ing, Stanford University.

Telea, A. (2004). An image inpainting technique based on

the fast marching method. Journal of Graphics Tools,

9(1):25–36.

Toyama, K., Krumm, J., Brumitt, B., and Meyers, B.

(1999). Wallﬂower: Principles and practice of back-

ground maintenance. In IEEE International Confer-

ence on Computer Vision, volume 1, pages 255–261,

Los Alamitos, CA, USA. IEEE Computer Society.

Wren, C., Azarbayejani, A., Darrell, T., and Pentland, A.

(1997). Pﬁnder: Real-time tracking of the human

body. Pattern Analysis and Machine Intelligence,

IEEE Transactions on, 19(7):780–785.

Xia, L., Chen, C. C., and Aggarwal, J. K. (2011). Human

detection using depth information by Kinect. In Inter-

national Workshop on Human Activity Understanding

from 3D Data in conjunction with CVPR (HAU3D),

Colorado Springs, CO.

VISAPP 2012 - International Conference on Computer Vision Theory and Applications

436
