BRINGING ORDER IN THE BAG OF WORDS
Shihong Zhang, Rahat Khan, Damien Muselet and Alain Tr´emeau
Universit´e de Lyon, F-42023, Saint-
´
Etienne, France
CNRS, UMR 5516, Laboratoire Hubert Curien, F-42000, Saint-
´
Etienne, France
Universit´e de Saint-
´
Etienne, Jean-Monnet, F-42000, Saint-
´
Etienne, France
Keywords:
Bag-of-words, Object Categorization, Spatial Information.
Abstract:
This paper presents a method to infuse spatial information in the bag of words (BOW) framework for object
categorization. The main idea is to account the local spatial distribution of the visual words. Rather than
finding rigid local patterns, we consider the visual words in close spatial proximity as a pouch of words and
we represent the image as a bag of word-pouches. For this purpose, sub-windows are extracted from the
images and characterized by local bags of words. Then a clustering step is applied in the local bag of words
space to construct the word-pouches. We show that this representation is complementary to the classical BOW.
Thus a concatenation of these two representations is used as the final descriptor. Experiments are conducted
on two very well known image datasets.
1 INTRODUCTION
In this paper, we deal with the problem of category-
level classification in the images. This is a chal-
lenging problem in computer vision and one of the
successful solutions is the Bag-of-Words (BOW) ap-
proach (Csurka et al., 2004), which employs the his-
togram of particular image patterns (the visual words)
in a given image. However, one major limitation of
the BOW model is that, it does not retain the spa-
tial relationship among the visual words. Different
methods have been proposed to take advantage of
the spatial distribution of visual words to improve
classification accuracy. For example, Lazebnik et
al. employed the pyramid match kernel proposed
by (Grauman and Darrell, 2005) into BOW frame-
work to account the global distribution of the visual
words among the image and achieved very high clas-
sification accuracy (Lazebnik et al., 2006). Among
local approaches, Zhang et al. (Zhang and Mayo,
2008) improved the classification performance of the
BOW model by discovering intermediate represen-
tations for each object class. Specifically, their ap-
proach includes the spatial relationships between all
the frequent and informative image keypoints in the
smaller regions of the image. A group of works in-
tents to model the co-occurrence patterns of visual
words. Among them, (Sivic et al., 2005) extended the
BOW model using spatial information in their work.
The spatial information, which they term as ”dou-
blets”, is formed from spatially neighboring word
pairs. In (Bhatti and Hanbury, 2010), Bhatti et al.
introduced the pair-wise relations between image fea-
tures. In their work, the image is represented by a con-
catenation of independentvisual words with pair-wise
visual words. Yuan et al. (Yuan et al., 2007) defined
co-occurrence pattern occurring in local proximity as
visual phrase and use this information for classifica-
tion.
Most of the local approaches only consider pairs
of visual words and we argue that we should not
restrict the number of words accounted in the local
neighborhoods. Unfortunately, increasing the number
of words considered in each neighborhoodtends to in-
crease the dimension of the final descriptor. Hence,
we propose an alternative that considers the visual
words in close spatial proximity as a pouch of words
and represents the image as a bag of word-pouches.
The originality of this approach is that it applies a
clustering step in the BOW space in order to ex-
tract the most representative pouches. Bag of word-
pouches is also an orderless representation but in-
terestingly it encodes some spatial information be-
cause each pouch is representative of a group of words
which reside close to each other in the image space.
Unlike the classical methods that introduce spatial in-
formation in the BOW, our approach accounts the spa-
tial distribution of the visual words without increasing
the dimension of the final descriptor. Furthermore our
method, detailed in next Section, is complementary
723
Zhang S., Khan R., Muselet D. and Trémeau A..
BRINGING ORDER IN THE BAG OF WORDS.
DOI: 10.5220/0003859307230726
In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2012), pages 723-726
ISBN: 978-989-8565-03-7
Copyright
c
2012 SCITEPRESS (Science and Technology Publications, Lda.)
to BOW representation and when concatenated with,
provides superior classification accuracy.
2 BAG OF WORD-POUCHES
For image and object classification, the bag of words
approach is the most widely used. The idea consists
in characterizing each image by a histogram of quan-
tized descriptors (Csurka et al., 2004), that are ex-
tracted from the descriptor space thanks to a cluster-
ing algorithm (e.g. k-means). Figure 1 illustrates the
bag of words construction of 3 different images. In
this example, we can see that we have 3 representative
clusters in the descriptor space, each one associated
with one visual word (square, circle and star). Then,
each image is characterized by the histogram of these
”visual words”. This toy example underlines that no
spatial information is accounted in the final represen-
tation. Indeed, whereas the spatial distributions of the
visual words are different between the 3 images, their
respective bag of words are the same.
Image 1 Image 2
Image 3
BOW 1 BOW 2
BOW 3
3 visual words
after kmeans
clustering
Descriptor space
Figure 1: The bag of words (BOW) representation of 3 dif-
ferent images.
In order to infuse some spatial information in the
bag of words approach, we propose to account the
spatial distributions of the visual words in local ar-
eas of the images. The idea is to check if some sets
of visual words often occur in the same neighborhood
for some object classes and not for some others in or-
der to add this discriminative information in the final
representation of the images. Therefore, we propose
to evaluate local bags of words from sub-windows ex-
tracted from the images and to characterize each im-
age by a bag of local bags of words. Following the
metaphor of the bag of words, our approach consists
in bringing some order by adding some pouches to
the bag, so that we put the words into these pouches
(that are inside the bag) instead of mixing them in the
bag. Consequently, the representatives of the most
frequent local bags of words are called word-pouches.
The original part of this work is in the creation of
the word-pouches. These word-pouches are the his-
tograms of visual words that often occur in the same
neighborhood. In order to define these word-pouches,
we extract several sub-windows from all the images
and for each of these sub-windows, we evaluate their
bag of words (local BOW). Then, we create the local
BOW space whose dimension is the number of words
and in which each local BOW is one point. Finally,
we apply clustering in the local BOW space and the
cluster representatives are called the word-pouches.
Once the word-pouches have been defined, for one
image, we extract several sub-windows, evaluate the
local BOW of each of these sub-windows and asso-
ciate it with the nearest word-pouch. Hence, the im-
age is characterized by its bag of word-pouches.
Figure 2 displays the image 2 (see figure 1) from
which we have extracted 3 sub-windows. For each of
these sub-windows, we have evaluated its BOW and
shown the corresponding position in the local BOW
space.
Image 2
Local BOW space
Figure 2: 3 sub-windows extracted from image 2 of figure 1,
their respective local BOW and the corresponding points in
the local BOW space.
Figure 3 shows the BOWP representations ob-
tained for the 3 images of figure 1. In figure 3, we
can see, in the local BOW space, the points associ-
ated with the sub-windows extracted from the 3 im-
ages. After clustering, we obtain 5 word-pouches that
are the bins of the bags of word-pouches. We note
that the BOWP is more representative of the image
contents than the classical BOW of figure 1since the
BOWP of the images 2 and 3 are similar to each other
while being different from this of the image 1.
However, since the clustering step applied in the
local BOW space tends to loose details about the vi-
sual words and since spatial information is more or
less discriminative, depending on the considered cate-
VISAPP 2012 - International Conference on Computer Vision Theory and Applications
724
Image 1 Image 2
Image 3
BOWP 1
LBOW space
sliding window
WP
1
WP
2
WP
3
WP
4
WP
5
WP
1
WP
2
WP
3
WP
4
WP
5
BOWP 2
WP
1
WP
2
WP
3
WP
4
WP
5
BOWP 3
WP
1
WP
2
WP
3
WP
4
WP
5
5 word-pouches after
kmeans clustering
Figure 3: The bag of word-pouches (BOWP) representation
of the 3 images from figure 1.
gory, we propose not to restrict the image description
to the BOWP and to create a descriptor BOW&WP
that is a concatenation of the BOW and the BOWP.
This follows the intuition that rather than putting D
words in a single bag without pouches, it is better
to use less words (D
w
< D) and put them in 2 bags,
the first bag without pouches (BOW representation)
and the second one with pouches (BOWP represen-
tation). The number of pouches in the second bag is
equal to D
p
and the relative numbers of words (D
w
)
and pouches (D
p
) in the two bags are discussed in the
next Section.
3 EXPERIMENTAL RESULTS
For the experiments, we have used two datasets. The
first one is the Caltech101 image dataset (Fei-fei,
2004) from which we consider only the 10 most fre-
quent categories (Caltech10). The second dataset is
the Graz01 image dataset (Opelt et al., 2004) that con-
tains two object categories namely bikes and persons
and a background class. In this section, we present
the average classification accuracy over 10 individual
runs for both datasets.
16 × 16 patches are densely extracted, with 8 pix-
els overlap, and SIFT is used as descriptor (Lowe,
1999). We run a K-means clustering on a random
subset of 50, 000 descriptors to construct the visual
vocabulary. To create the bag of word-pouches, we
empirically find that a square window size of 48 ×
48 pixels with 8 pixels overlap works the best for the
considered datasets. This size of window can accom-
modate 25 visual words given the parameter we have
used in the dense sampling step. A SVM classifier
with intersection kernel (Lazebnik et al., 2006) is used
for all the experiments with the cost parameter (C)
value set to 1.
For the first experiment, the used descriptor
BOW&WP is constituted by D values and is a con-
catenation of a BOW and a BOWP. Then, we evaluate
the average accuracy of this descriptor while vary-
ing the relative numbers of words (D
w
) and word-
pouches (D
p
) within it, i.e. the k’s in the two k-means
algorithms. Since we want to compare descriptors
with the same size, we choose D
w
and D
p
so that
D
w
+ D
p
= D. Hence, we show the result evolution
while increasing D
p
from 0 to 0.75 × D (D = 800)
in figure 4. The aim of this experiment is to de-
fine the best relative amounts of words and word-
pouches for the considered dataset and for a constant-
size descriptor. We can see that, whatever the consid-
ered dataset, accounting spatial information increases
the average accuracy even if the number of words
is decreasing. Since the best overall trade-off is ob-
tained for equal numbers of words and word-pouches,
for the rest of the experiments, we choose these ra-
tios (0.5 ∗ D
w
+ 0.5 ∗ D
p
) and we call this descriptor
BOW&WP.
81,5
82
82,5
83
83,5
84
84,5
85
85,5
86
86,5
87
87,5
1*Dw
+
0*Dp
0.75*Dw
+
0.25*Dp
0.5*Dw
+
0.5*Dp
Caltech
Graz-person
Graz-bike
Figure 4: Average accuracy obtained with 800 dimensional
descriptors on Caltech101 and Graz01 datasets.
Then, we propose to compare the results of our
BOW&WP descriptor and the classical BOW for dif-
ferent values of D. We recall that the dimensions of
BOW&WP and BOW are both equal to D. Figure 5
shows the results for D varying from 200 to 1000. We
can see that for the 3 tested datasets and whatever the
value of D the proposed BOW&WP outperforms the
classical BOW.
Finally, we propose to analyze the relative aver-
age accuracy improvement (RAAI) of BOW&WP re-
BRINGING ORDER IN THE BAG OF WORDS
725
82
82,5
83
83,5
84
84,5
85
85,5
86
86,5
87
200
400
600
800
1000
D
80
80,5
81
81,5
82
82,5
83
83,5
84
84,5
85
200
400
600
800
1000
D
83
83,5
84
84,5
85
85,5
86
86,5
87
87,5
88
200
400
600
800
1000
BOW
BOW&WP
D
Caltech10 Graz - Bikes Graz - persons
Figure 5: Average accuracies on Caltech10 and Graz01.
gards to classical BOW for each category of CAL-
TECH10. The higher the value of RAAI the more the
BOW&WP outperformsthe BOW. Figure 6 shows the
mean RAAI over all the values of D from 200 to 1000
for each category. The categories are ranked in the
order of decreasing RAAI, so that BOW&WP per-
forms better (compared to BOW) on the categories
on the left (in green) than on the categories on the
right (in red). This figure shows that, depending on
the category, the improvement provided by the pro-
posed BOW&WP varies a lot. It can be very high
(more than 10%) for some categories such as chan-
deliers or bonsais that are characterized by rigid and
stable structures and can be negative for some oth-
ers such as leopards that are non-rigid objects whose
poses and viewpoints are highly varying between the
images.
-11
-9
-7
-5
-3
-1
1
3
5
7
9
11
ketch
acc
ord
i
on
f
a
c
e
s_e
a
s
y
hawksbil
l
ca
r
_si
d
e
leop
a
rds
c
h
an
d
el
i
e
r
bonsai
w
a
tch
motorbikes
Figure 6: Relative average accuracy improvements of
BOW&WP regards to classical BOW for the 10 most fre-
quent CALTECH101 categories.
4 CONCLUSIONS AND FUTURE
WORKS
In this paper, we have proposed an original and effi-
cient way to account spatial distribution of the visual
words in the image representations. The idea consists
in accounting the way the visual words are locally or-
ganized. We have shown that adding this information
in the bag of words can help in decreasing the number
of visual words accounted for the construction of the
descriptor while improving the average accuracies.
REFERENCES
Bhatti, N. A. and Hanbury, A. (2010). Co-occurrence bag
of words for object recognition. In Proceedings of the
15th Computer Vision Winter Workshop (CVWW).
Csurka, G., Dance, C. R., Fan, L., Willamowski, J., and
Bray, C. (2004). Visual categorization with bags of
keypoints. In Workshop on Statistical Learning in
Computer Vision, ECCV.
Fei-fei, L. (2004). Learning generative visual models from
few training examples: an incremental bayesian ap-
proach tested on 101 object categories. In Workshop
on Generative-Model Based Vision, CVPR.
Grauman, K. and Darrell, T. (2005). The pyramid match
kernel: discriminative classification with sets of im-
age features. In International Conference of Computer
Vision, pages 1458–1465.
Lazebnik, S., Schmid, C., and Ponce, J. (2006). Beyond
bags of features: Spatial pyramid matching for recog-
nizing natural scene categories. In Computer Vision
and Pattern Recognition (CVPR).
Lowe, D. G. (1999). Object recognition from local scale-
invariant features. In International Conference on
Computer Vision (ICCV).
Opelt, A., Fussenegger, M., Pinz, A., and Auer, P. (2004).
Weak hypotheses and boosting for generic object de-
tection and recognition. In Pajdla, T. and Matas, J.,
editors, ECCV (2), volume 3022 of Lecture Notes in
Computer Science, pages 71–84. Springer.
Sivic, J., Russell, B. C., Efros, A. A., Zisserman, A., and
Freeman, W. T. (2005). Discovering objects and their
location in images. In IEEE Intl. Conf. on Computer
Vision.
Yuan, J., Wu, Y., and Yang, M. (2007). Discovery of collo-
cation patterns: from visual words to visual phrases.
In Computer Vision and Pattern Recognition (CVPR).
Zhang, E. and Mayo, M. (2008). Pattern discovery for
object categorization. In 23rd International Con-
ference Image and Vision Computing New Zealand
2008(IVCNZ 2008).
VISAPP 2012 - International Conference on Computer Vision Theory and Applications
726
