ICA-BASED ACTION RECOGNITION FOR

HUMAN-COMPUTER INTERACTION IN

DISTURBED BACKGROUNDS

Wei-Yao Chiu and Du-Ming Tsai

Department of Industrial Engineering and Management, Yuan-Ze University, Taiwan, R.O.C.

Keywords: Human-computer Interaction, Action Recognition, Video Surveillance, Spatiotemporal Representation,

Independent Component Analysis.

Abstract: In this paper, we propose an independent component analysis (ICA) based scheme for action recognition.

The proposed method does not require the feature design or modeling process, and it is computationally

very fast for real-time applications. Experimental results show that it is robust on disturbed backgrounds

where both foreground and background objects are moving simultaneously in the scene. The experiments

also reveal that the proposed method is very effective for human-computer interaction.

1 INTRODUCTION

In this paper, we propose a scheme based on

independent component analysis (ICA) for action

recognition. It uses the exponential motion history

image (EMHI) for spatiotemporal representation of

an action, and the discriminant features are then

automatically extracted from the EMHI by ICA

basis image reconstruction. A complex action can be

constructed with only a few training samples of a

reference action. ICA is used to generate the basis of

action templates from the training EMHI images.

Each action to be recognized can be constructed by a

linear combination of the ICA basis templates. If the

input scene video contains an action similar to the

training sample, then the corresponding EMHI can

be well reconstructed from the linear combination of

the basis templates. The coefficients of the linear

combination are used as the discriminant feature

vector for action classification. It needs only a few

action samples for the training and is robust on

disturbed backgrounds with both moving foreground

and background objects present simultaneously in

the scene. The proposed method can be applied to a

moving background environment, such as a street

scene with moving vehicles.

2 ICA-BASED APPROACH FOR

ACTION RECOGNITION

This section discusses the ICA-based approach for

action recognition that comprises the Exponential

Motion History Image (EMHI) for spatiotemporal

representation of motions, extraction of motion

features by ICA, and the distance measure for

classification.

2.1 Spatiotemporal Representation

The proposed activity recognition scheme first

constructs a global representation of motion that can

describe the changes in both temporal and spatial

dimensions. In this study, we focus on the

recognition of specific activities that can be defined

beforehand. We also use the exponential motion

history image (EMHI) as the spatiotemporal

representation of a video sequence and then apply

the ICA basis images for classifying the pre-

determined actions. For completeness, the

construction of EMHI from a stream of video

sequences is briefly described here, and the

advantage of EMHI over the conventional MHI for

the recognition of specific activities is also analysed.

The existing spatiotemporal representations of

motions generally describe the temporal context

with a fixed duration in a video sequence. The

motion representation from a fixed number of image

519

Chiu W. and Tsai D..

ICA-BASED ACTION RECOGNITION FOR HUMAN-COMPUTER INTERACTION IN DISTURBED BACKGROUNDS.

DOI: 10.5220/0003888605190522

In Proceedings of the International Conference on Computer Graphics Theory and Applications (GRAPP-2012), pages 519-522

ISBN: 978-989-8565-02-0

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

frames may not sufficiently capture the salient and

discriminative properties for a large variety of

activities. A short observation duration cannot

describe the full cycle of an activity. In contrast, an

excessively long observation duration may mix two

or more different activities or reduce the significance

of a unique activity in the spatiotemporal

representation.

Let



yxf

, be the

-th time frame image in a

video sequence. The exponential history image

(EMHI) up to time frame

is defined as

  









x, yEx, yMx, yE

t-tt 1

(1)

where



is the energy update rate,

10 



, and

















otherwise0

if1

foregroundx, y f,

x, yM

Since the activity recognition scheme proposed in

this study does not rely on the parts of the extracted

human body, the accuracy of the segmented

foreground region has no significant impact on the

EMHI spatiotemporal representation. The initial

value of energy is set to zero at time frame 0, i.e.,

0),(



yxE

, for all pixels. The energy of a pixel



x, yE

will be increased if it remains as a

foreground point up to time

. It is decayed only

when it becomes a background point. In eq. (1),



x, yM

is set to 1 if



,pixel at time frame

is a

detected foreground point. Otherwise, it is set to 0

for a background point.

To compare the effectiveness of spatiotemporal

representations from the proposed Exponential MHI

(EMHI) and the conventional MHI, Figure 1

displays the resulting energy images for a set of

various actions. Figure 1(a) shows the first frame of

each action video sequence in the Weizmann dataset

(Gorelick

et al.

2007). Figure 1(b) shows the

corresponding Motion History Image (MHI) of each

action, in which the observed duration is set at 50

frames. Figure 1(c) displays the corresponding

Exponential Motion History Image (EMHI) of each

action, in which the update rate



is given by 0.99.

The conventional MHI representations are too

similar to distinguish the different actions of Jump,

Run, Walk and Side-walk. EMHI, however, can

generate distinguishable representations for the

different repetitive actions. As seen in Figures 1(a2)

and (a3) for the Run and Walk actions, the EMHI

representations show two actions with different leg-

motion patterns. Therefore, EMHI gives a

discriminative spatiotemporal representation for

describing various action patterns, especially for

those that involve prolonged, repetitive motions.

Figures 2(a1)~(a3) show the one-hand wave

action on a disturbed background. The objects

causing disturbance include many pedestrians, cars,

and motorcycles passing through the background.

Figures 2(b1)~(b3) present the conventional MHI

image with great interference from the background

objects. Figures 2(c1)~(c3) illustrate the proposed

EMHI image with low energy noise from the

moving background objects, wherein the waving

motion is still distinctly intensified in the energy

image. From the demonstrative samples in Figures 1

and 2, it is clear that the proposed EMHI can

represent different activities that involve simple or

complex motions on a disturbed background.

(a1) Jump (b1) (c1)

(a2) Run (b2) (c2)

(a3) Walk (b3) (c3)

(a4) Side walk (b4) (c4)

Action video sequence MHI EMHI

Figure 1: Different activities in the Weizmann dataset and

corresponding representations: (a1)-(a4) single person

activity; (b1)-(b4) MHI representation; (c1)-(c4) EMHI

representation.

(a1) t=125 (b1) (c1)

(a2) t=184 (b2) (c2)

(a3) t=322 (b3) (c3)

Action video sequence MHI EMHI

Figure 2: Repetitive one-hand waving on a disturbed

background and corresponding representation: (a1)-(a3)

single person activity; (b1)-(b3) MHI representation; (c1)-

(c3) EMHI representation. (The symbol t represents the

frame number in the video sequence with fps=15.)

2.2 ICA-based Feature Extraction

The proposed EMHI gives the global spatiotemporal

GRAPP 2012 - International Conference on Computer Graphics Theory and Applications

520

representation of an activity. To construct a

classification system for action recognition, the

classical approaches need first to design and extract

discriminant features from the spatiotemporal

representation and then to perform feature selection

to find the best feature combination based on

specific selection criterion, and finally to apply a

classifier to identify individual actions.

In the basic ICA model (Hyvarinen et al., 2000),

the observed mixture signals

can be expressed as

ASX 

where A is an unknown mixing matrix, and S

represents the latent source signals, meaning that

they cannot be directly observed from the mixture

signals

. The source signals are assumed to be

mutually statistically independent. Based on this

assumption, the ICA solution is obtained in an

unsupervised learning process that finds a de-mixing

matrix

W . The matrix W is used to transform the

observed mixture signals

to yield the

independent signals, i.e.

WXY  . The components

of Y, called independent components, must be as

mutually independent as possible.

The objective of the algorithm for an ICA model

is to maximize the statistical independence (non-

Gaussianity) of the ICs. The non-Gaussianity of the

ICs can be measured by the negentropy (Hyvarinen

and Oja, 1997).

For action recognition, a set of training samples

is collected from all reference actions, where each

sample is represented by the EMHI. Let the training

samples involve K specific actions and each

reference action include more than one EMHI

sample. To find the basis images of multiple

reference actions using ICA, let





NjKi ,,2,1;,,2,1,   xX

be a set of

training samples for K reference actions, each

reference action i with

N samples. Training sample

indicates the j-th template sample of action i,

and is represented by its EMHI



r, cE

of size

CR .

The two-dimensional energy image





r, cE

training sample

is first reshaped as a one-

dimensional vector. Denote by







z the

reshaped one-dimensional vector of the training

sample

with

,)(

NNjt 







,,,2,1 Ki 

and .,,2,1

Nj  The k-th element

z is given by



r, cEkz

)(

where

,)1( Crck









for

Rr ,,2,1 

and

Cc ,,2,1 



, given that the image is of size CR



The de-mixing matrix obtained from the FastICA

model is given by

Therefore, the source action

templates can be estimated by

U 

















where

],,,[

21 T

zzzZ 



, and





The data matrices

and U are of size )( CRT



 ,

and the de-matrix

W is of size



. For a total of

T training samples of the reference actions, we can

obtain up to T basis images



uuu ,,,

 from the

ICA. Any action

represented by the EMHI





r, cE can be constructed by a linear combination

of the T basis images

u ’s, i.e.,







uUbx

and



 Uxb

where



U is the pseudo inverse of the basis image

matrix U, and









 UUUU . The coefficient

vector





bbb ,,,





b gives the discriminant

features for describing the contents of the action

For an unknown testing action

test

represented

by its EMHI, the corresponding discriminant feature

test

is calculated by the trained ICA basis images,

i.e.,



 Uxb

x test

test

The distance measure between template sample

and the unknown

test

is defined as

bbbb

 ,min

test

where

is the coeeficient vector of training

sample

Given that the best coefficient vector

ICA-BASED ACTION RECOGNITION FOR HUMAN-COMPUTER INTERACTION IN DISTURBED

BACKGROUNDS

521

achieves the minimum distance, i.e.,

test

minarg

bbb 

The proposed classification then assigns the

unknown

test

x to the reference action

i . In order to

rule out a novel action (i.e., an action irrelevant to

any of the reference actions of interest), a simple

distance threshold can be applied to exclude the

unrecognizable action.

3 EXPERIMENTAL RESULTS

This section evaluates the effectiveness of the

proposed action recognition scheme with the Public

Weizmann action dataset (Gorelick et al., 2007). In

the Weizmann dataset, we compare the experimental

results of the proposed method and several existing

methods with the Weizmann dataset. The Weizmann

dataset contains 90 low-resolution (180

144) video

sequences that show 9 different people, each

performing 10 natural actions of Run, Walk, Skip,

Jumping-jack, Jump forward on two legs, Jump in

place on two legs, Gallop sideways, Wave two

hands, wave one hand, and Bend. All the

backgrounds are stationary. We use 9 training

samples for each individual reference action,

wherein each EMHI training sample is obtained

from the last frame of each sequence. In the training

stage, a total of 90 (10 actions

 9 people) video

representation sequences are collected as the training

data matrix.

The proposed method gave the same detection

results as those of the state-of-the-art methods (e.g.,

volume-based method [27], spatiotemporal methods

(Gorelick et al., 2007); (Hsiao et al., 2008), model-

based method [29] and optical flow-based method

[30]), as seen in Table 1. The existing methods

generally use shapes or silhouettes for the

representation, highly rely on accurate segmentation

of foreground shapes, and require high computation

complexity. They may fail to recognize the actions

of interest on a disturbed background.

The proposed algorithms were implemented

using the C++ language on a Core2 Duo, 2.53GHz

personal computer. The test images in the

experiments were

150200 pixels wide with 8-bit

gray levels. The total computation time from

foreground segmentation and spatiotemporal

representation to ICA feature extraction and distance

measure for an input image was only 0.015 seconds.

It achieved a mean of 67 fps (frames per second) for

real-time action recognition.

Table 1: Performance comparison of different methods on

the Weizmann dataset.

Methods Accuracy

Grundmann et al. 2008 94.6 %

Hsiao et al. 2008 96.7 %

Wang and Suter 2007 97.8 %

Fathi and Mori 2008 100 %

Gorelick et al. 2007 100 %

Our proposed method 100 %

4 CONCLUSIONS

The proposed ICA-based feature extraction and

classification method has been well applied to the

global spatiotemporal representation of EMHI for

recognizing activities that can be observed from a

global, macro viewpoint. It is worth further

investigation to extend the ICA-based scheme for

recognizing subtle activities with micro-observation

representation that can be observed only from a local

viewpoint of detailed body movements of individual

foreground objects.

REFERENCES

Gorelick, L., Blank, M., Shechtman, E., Irani, M., Basri,

R., 2007. Actions as Space-Time Shapes. IEEE Trans.

Pattern Analysis and Machine Intelligence, vol. 29, no.

12, pp. 2247-2253.

Hyvarinen, A., and Oja, E., 1997. A fast fixed-point

algorithm for independent component analysis. Neural

Computation, vol. 9, pp. 1483-1492.

Hurri, J., Gavert, H., Sarela, J., and Hyvarinen, A., 2004.

FastICA Package. Online Available:

http://www.cis.hut.fi/projects/ica/fastica/.

Grundmann, M., Meier, F., and Essa, I., 2008. 3D shape

context and distance transform for action recognition.

In: Proc. IEEE Conference on Computer Vision and

Pattern Recognition.

Hsiao, P. C., Chen, C. S., and Chang, L. W., 2008. Human

action recognition using temporal-state shape contexts.

In: Proc. IEEE Conference on Computer Vision and

Pattern Recognition.

Wang, L. and Suter, D., 2007. Recognition human

activities from silhouettes: Motion subspace and

factorial discriminative graphical model. In: Proc.

IEEE Conference on Computer Vision and Pattern

Recognition.

Fathi, A. and Mori, G., 2008. Action Recognition by

Learning Mid-level Motion Features. In: Proc. IEEE

Conference on Computer Vision and Pattern

Recognition.

GRAPP 2012 - International Conference on Computer Graphics Theory and Applications

522
