eBIOMICS

A Website Promoting Good Practices

and Specific Methods for using Bioinformatics Resources

Frédérique Lisacek

, Patrick Koks

, Pascale Berthault

, Grégoire Rossier

, Guy Bottu

Jacques van Helden

, Jean Sylvestre

, Jean-Pierre Kraehenbuhl

and Jack Leunissen

SIB Swiss Institute of Bioinformatics, Geneva, Switzerland

Wageningen University, Bioinformatics Laboratory, Wageningen, Netherlands

SDC Conseil & Edition, Paris, France

Université Libre de Bruxelles, Bruxelles, Belgium

Health Sciences eTraining Foundation (HSeT), Epalinges, Switzerland

Keywords: Bioinformatics, e-learning, -omics, Interactive Platform.

Abstract: eBiomics (www.ebiomics.org) is an e-learning interactive platform in bioinformatics intended as a support

to post-graduate students and scientists involved in -omics or systems biology projects. The heterogeneity

and the multitude of bioinformatics resources (databases or tools) make their individual use and

appreciation difficult though difficulties can be overcome through indexing examples of use in specific

contexts. eBiomics is presented as a didactic guide for an extensive range of on-line databases and tools

commonly referred to in -omics applications. In its self-training version, it was developed with a free

content management system and contains light textual information complemented with numerous

screenshots and visual information in a user-friendly environment. A collection of protocols and case

studies is indexed for finding representative and practical usages of each of the resources described. Most

references to on-line databases and tools are accessible in real time through cross-links. The content covers

main -omics related topics. Such a flexible tool allows keeping up with the constant evolution imposed by

frequent new releases of databases, upgrades of on-line software and regular changes of query interfaces,

which usually precludes from publishing helpful tutorials in books and manuals (otherwise rapidly

becoming obsolete). In addition, it offers access to a self-testing section. A complementing sister website

focused on biomedical academic studies includes part of the self-training content in a different environment.

1 INTRODUCTION

The increase in data generation techniques in the

Life Sciences (so called -omics techniques) makes it

possible to generate huge amounts of scientific data

in even a single experiment. As the cost of such

technology drops simultaneously, the generation of -

omics data comes within reach of many research

groups, exposing more scientists to these data. This

growth in data (techniques) is accompanied by a

subsequent increase in data resources and analysis

tools. The NAR bi-yearly special issues (database

(Galperin and Cochrane, 2011), web server (Benson,

2011)) have captured this trend in the last decade. It

is envisaged that researchers in the Life Sciences

now and in the future will no longer spend most of

their time in the laboratory (the data generation often

being outsourced to an external party), but behind a

computer to analyse the research obtained by an

experiment (Sboner, 2011).

All of this renders it virtually impossible for

students or established scientists that are unfamiliar

with these fields to gain a quick overview and insight

in which tools and/or databases are available and

which are most appropriate for a particular study or

technique. Furthermore, the speed of evolution of

technology renders large parts of practical textbooks

and manuals obsolete on a short-term basis. Teaching

and training requires regular reappraisal and

restructuring to keep up with latest developments.

This aspect is particularly true in bioinformatics as

exemplified in a recent issue of PLoS Computational

Biology partly devoted to bioinformatics education

(Via et al., 2011). The need for frequent update and

for reaching increasing numbers of learners has

logically supported the move to e-learning (Schneider

386

Lisacek F., Koks P., Berthault P., Rossier G., Bottu G., van Helden J., Sylvestre J., Kraehenbuhl J. and Leunissen J..

eBIOMICS - A Website Promoting Good Practices and Speciﬁc Methods for using Bioinformatics Resources.

DOI: 10.5220/0003893703860391

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (SSTB-2012), pages 386-391

ISBN: 978-989-8425-90-4

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

et al., 2011; Wright et al., 2011).

Virtual bioinformatics courses were initiated in

VSNS (de la Vega et al., 1996) or the EMBER

project (2001) mainly focused on sequence analysis.

The latter has been kept alive on and off since the

project end in 2005 highlighting the difficulty of

sustaining this type of effort. Even references

recognised as successful in a recent review (Wright

et al., 2011) like BioManager (Cattley et al., 2010) is

now discontinued. Consequently, a scheme for

knowledge sustainability is a central issue that needs

attending. Successful on-line teaching programmes

like those developed at the universities of

Manchester or Bielefeld (BiBiServ) cited in the

same review (Wright et al., 2011) tend to show that

rooting e-learning strategies into university courses

increases sustainability.

An early version of a self-learning website in

bioinformatics for proteomics (e-proxemis) was

developed in recent years by members of the SIB.

Despite positive feedback and a lifespan of several

years (a few thousand registrations during that time),

the platform was restricted to the proteomics domain

thereby remaining limited in reach (the genomics

and transcriptomics communities are much wider).

The expansion of –omics technology reinforced by

the frequent combination of more than one –omics

approach in biological studies impose a reflection on

the renewal of teaching strategies. This concern is

shared in OpenHelix (Williams et al, 2011) though

the tutorial format on this platform is not interactive.

The eBiomics project presented in this paper

strives to provide an e-learning environment in

which both students and experts can find

information relevant to their field of study. The

purpose of eBiomics is to familiarise users with

bioinformatics analysis flows in diverse -omics

applications. To that end, we revised the e-proxemis

pedagogical strategy to account for the spread of

automated pipelines and tied our effort to an existing

e-learning platform that is already used in master

programmes (provided by the HSeT (Health

Sciences eTraining) Foundation).

The resources that populate the eBiomics

catalogue were selected to reflect both the widely

recognised usage in a given –omics community and

the citations in our collection of case studies. In that

sense they are not bound to a set geographical origin

or to the respective services provided by the

institutes to which the authors belong. The catalogue

is not destined to become exhaustive in terms of

coverage of existing tools but to focus on a selection

that mirrors widely adopted and/or recommendable

practises.

Other content in eBiomics was originally prompted

by the following observation: most published work in

the field of –omics includes a compact description of

data analysis captured in a few paragraphs in the

Material and Methods section of the article. The

unfamiliar reader may recognise but also discover

software names or note references to well-known and

less known databases. The eBiomics platform

proposes the expansion of such condensed paragraphs

in detailed case studies to enhance the reading of an

article in two complementing ways. The approach is

known of “article-based learning”. On the one hand, it

provides a guide to learn about the most popular

individual resources as traditionally done in e-

learning platforms (EMBER, etc). On the other hand,

it illustrates their combined use in several contexts. In

fact, the latter approach assumes that data analysis

follows protocols in much the same way data

generation does. In eBiomics, protocols are presented

as flowcharts, text and put into the context of a

specific case study.

In short, eBiomics was built on past experience

from both EMBER, e-proxemis and on the expertise

of HSeT for grounding e-content in university

programmes. Two versions are hosted on two sites.

The full content is available for self-training

(currently at http://ebiomics.sdcinfo.com/) and

selected content for targeted article-based learning is

transferred to the HSeT site for academic use. The

present paper describes the full content and outlines

the basis of transfer to HSeT.

2 eBIOMICS PRINCIPLES

Besides creating an environment for e-learning and

specific use of bioinformatics resources, pedagogy

and long-term sustainability are the main focus of

eBiomics that constrained its design and

development. Even though a range of books

describes several aspects of bioinformatics (e.g.,

basics, algorithms), electronic media are more

adapted to assisting scientists in mastering day-to-

day usage of data analysis tools and reference

databases. Like books, an e-platform encourages

self-training; unlike books, e-content can easily and

rapidly be updated. Furthermore, the main advantage

of e-tools over books is interactivity, which is

essential for involving learners. Very few initiatives

were launched to take on the challenge.

2.1 Pedagogy for Self-training

The pedagogic strategy is two-fold. Firstly, it is

eBIOMICS - A Website Promoting Good Practices and Specific Methods for using Bioinformatics Resources

387

supported by guided navigation in the full content

website. The content of a page is centrally displayed

and the right side is populated with the variety of

related content available in the 5 sections of

eBiomics. Information content is thus accessible in

multiple ways. Secondly, it focuses on research

articles as the basis of self-training and e-learning

material for the HSeT website.

Figure 1 below illustrates the hierarchy of the

different sections in the full content website. The

structuring principle relies on zooming from the

global view of an analytical workflow to the basic

operation involved in a given step of analysis. The

top layer describes the many possibilities of building

a workflow given a set of analytical tasks. The next

layer describes one specific set of tasks and

associated tools which characterises an in silico

protocol. The next layer describes a case study

within which a protocol is used. A protocol can be

decomposed into steps each of which is viewed as

lower level single operation (specific if fully

described, generic if not).

Figure 1.

2.2 Content

For the first release, the mainstream bioinformatics

domains, namely genomics, proteomics,

transcriptomics and metabolomics, are covered.

Databases and tools can be categorised into one or

more of these domains or in the 'Sequence Analysis

and Annotation' “superdomain”. Indeed, sequence

analysis plays a central role in all –omics domains

and is therefore given a central place. As most of the

underlying data and techniques for analysing data

are also used in systems biology, we deem this

content as a valuable source for students and experts

in this research area as well.

For the full content site, eBiomics relies on the

flexibility of the content management system Drupal

to guarantee the ease of maintenance and update by

contributing authors. Update protocols keep the

maintenance task to a minimum when no major

change is associated with the new release of a

database or tool. They also help the rapid revision of

results that depend on database content (potentially

changing on a daily basis). When a new release

involves substantial changes, extra effort is

unavoidable but the repercussion of changes can be

controlled.

At this stage, the HSeT website only covers the

transcriptomics and proteomics domains with selected

content from its sister site, as explained below.

3 eBIOMICS IMPLEMENTATION

The description in the following 3.1 and 3.2 sections

focuses on the full content website designed for

interactive self-training. Section 3.3 outlines the

correspondence with the HSeT site.

3.1 Structure

The full content website is freely accessible from

www.ebiomics.org via registration for monitoring

purposes. To cater for users who reject the

obligation for registration, a login:demo

/password:demo was created.

As hinted in section 2.1, the website is composed

of several interconnected sections that can be

accessed through different interactive activities. The

5 main sections of eBiomics are:

1) Resources: this is a catalogue of selected

databases and data analysis software that are briefly

described and illustrated with examples. The

catalogue is ordered by categories mainly describing

the biological data (e.g., gene expression, proteins)

or the purpose of analytical approaches (e.g. pattern

search, structure prediction).

2) Conceptual Flowcharts: this is a collection of

clickable images picturing typical data analysis

flows in different -omics studies. No current large-

scale initiative produces datasets that are analysed

with one tool only. It is therefore important to stress

the various steps of analysis and show global views.

3) Protocols: this is a collection of recognised

approaches to problem-solving in common -omics

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

388

applications. Each step of an –omics protocol is

called a generic operation.

4) Case Studies: this is a collection of concrete

studies undertaken to address a biological question.

Since in the vast majority of cases, bioinformatics

analysis summarised in a published article is not

detailed, case studies expand and explain these short

summaries into self-sufficient accounts of

information found in selected publications. A case

study usually describes the implementation of a

specific protocol made of specific operations.

5) Exercises: self-evaluation space. Questions,

quizzes, problems and suggested solutions populate

this section.

3.2 Navigation Scheme

We now detail the various ways of browsing the

multiple categories of content.

3.2.1 Basics

a) To learn about the content of a database or the

purpose of a software tool only known by name, we

recommend looking for its description and examples

of use in the Resources section. Further context-

sensitive information can be accessed by clicking on

related content on the right panel of the page.

Example: the user has heard of Prosite but do

not really know what it is, then click on Resources,

find "Prosite" in the sub-section Databases, click on

"Prosite" and read content.

A resource is always described on the same

template answering the following questions:

- What is it?

- How and when to use?

- In a nutshell

b) To learn about the combined use of software

and/or databases or about the similarity of resources

we suggest checking the Conceptual flowcharts to

apprehend the chronology of tasks in the course of

analysis. Related content is available on the right

panel of the page.

Example: you use the Mascot software for

analysing mass spectrometry data and would like to

know of an alternative tool performing the same

analysis, then click on Conceptual flowcharts and

look at the yellow boxes featuring with the Mascot

box. Click on these boxes to read the content.

3.2.2 Advanced

a) To learn about the most typical data processing,

we encourage exploring the Protocols section.

Related content is available on the right panel of the

page.

b) To learn about the role of bioinformatics-based

analysis in concrete examples of research, we

recommend following the threads proposed in the

Case studies.

Example: you wish to understand the details of a

bioinformatics analysis as part of a global study

identifying disease biomarkers. These details are

given in a Case study where each important

processing step is singled out, explained and builds

up a complete story.

A case study is described on the same template

according to the following progression:

- Introduction

- Step 1 (specific operation 1)

- …

- Step n (specific operation n)

- Conclusion

A specific operation typically entails using one

piece of software or one type of database. It will

therefore be indicated as related content for the

description of that software/database in the Resource

section. A Case study is often based on

the

expansion of the few paragraphs summarising the

data analysis protocol in the Material and Methods

section of published articles describing large-scale

studies.

Finally, the Exercises section is designed to

evaluate the depth of a user's knowledge through

solving problems or answering quizzes. Each

resource or case study is related to relevant

exercises.

3.3 Article-based Learning

The HSeT website hosts its own version of eBiomics

and integrates part of the full content website in a

range of biomedical educative programmes. HSeT

provides tools for supervised e-training that are used

in several master programmes. HSeT mainly targets

medical science education and now relies on

eBiomics content for feeding the bioinformatics

section of its supervised e-training biomedical

programmes.

Practically, proteomics and transcriptomics Case

studies of the full content website were imported

into the HSeT website as simple HTML code along

with all related resource descriptions. Subsequently,

articles are annotated in the HSeT website to

enhance the medical/biological content with HSeT

tools. The final outcome is a multiply enriched

content.

eBIOMICS - A Website Promoting Good Practices and Specific Methods for using Bioinformatics Resources

389

3.4 On-line Illustration

A live demo is the most convincing way of

illustrating the potential benefits of using eBiomics

and this will be detailed during the oral presentation.

As an introduction, the two screenshots below show

the full content and HSeT versions of the same case

study.

Figure 2: View in full content website.

Figure 3: View in HSeT website.

In the full content website (Figure 2), a case study

is introduced with a short text referencing the article

from which it is derived and navigation is detailed

on the right side of the page with a series of

clickable steps.

In the HSeT website (Figure 3), article-based

learning entails displaying the content by main

sections (here Methods) where terms are linked to

further information either in bioinformatics or in

medical science when appropriate. The example

shows that if “peptide mass tolerance” is clicked on

then the grey textbox below is displayed.

4 DISCUSSION

AND CONCLUSION

At present, the most common approach of untrained

scientists consists in running software with default

parameters and extracting data from databases upon

simple keyword search. In eBiomics, training is

regarded as the stepwise guidance of a trainee in

order to: (1) improve and refine his/her information

search strategies, (2) enhance his/her capacities for

critical assessment of results and (3) develop a sense

of extrapolation.

4.1 Target Users

eBiomics serves different user groups. New comers

to bioinformatics following a course in one of the –

omics domains present in eBiomics can answer

questions like: 'How are datasets analysed?', ‘what is

the purpose of this database?’, etc. Advanced users,

typically life science researchers, can answer

questions like: 'which database or tool is available

for my specific analysis or problem?', 'What are the

optimal settings for the algorithm I commonly use?'

or 'Can this or that method be applied in another

context?'

A next step in professionalising and increasing

the applicability of eBiomics to a wider range of

users can be the creation of a true Learning

Management System (LMS) behind the learning

environment. Plug-ins for this are readily available

and this makes Drupal a very suitable system for this

(Fitzgerald, 2009). By adding the possibility of

recording one's reading / learning progress,

bookmarking interesting or difficult sections and

storing test-results (for registered users and

teachers), the system will gain interest as a tool

matching needs for more regular teaching / training

/learning situations.

We also consider the option of expanding

content sharing beyond the existing partnership

potentially on the basis of solutions described in

(Romano et al, 2010).

4.2 Impact and Sustainability

Results in Life Sciences increasingly rely on

automated analysis of experimental data as -omics

sciences generate massive amounts of data. The

control of the quality of bioinformatics analysis has

become crucial for interpreting and valorising

results. In other words, those groups who will master

analysis tools best will produce the most interesting

BIOINFORMATICS 2012 - International Conference on Bioinformatics Models, Methods and Algorithms

390

results. In that respect, the expected impact of

eBiomics can be mostly evaluated in terms of

enhancing the quality of research. The reference to

standards and good practices is essential for students

and researchers involved in -omics applications.

The HSeT version of eBiomics contributes to

increasing its visibility and attracting a regular flow

of new comers. Further integration in master

programmes is considered in order to secure regular

use and longevity.

4.3 Prospects

The website was released with a critical mass of

content that should grow and improve in the coming

years as the partnership between the project partners

is maintained through multiple planned actions for

the popularisation of the website. Compliance with

the SCORM standard (legacy.adlnet.gov/

Technologies/scorm/) is nearly complete and will

also support easy transfer not only between the two

eBiomics sister websites but also potential other.

Further topics will be added as required by the

teaching programmes of partnering universities (in

Switzerland and the Netherlands so far). For

instance, specific systems biology tools like

stochastic modelling could be included in future

releases.

In conclusion, eBiomics is destined to provide an

environment that enables students and researchers in

the field of –omics and systems biology to be trained

or to train themselves, in order to make a better and

more efficient use of the available resources.

ACKNOWLEDGEMENTS

The development of eBiomics was supported by

grant #504187 of the EU Lifelong Learning

Programme Erasmus (multi-lateral project) and by

the Swiss Confederation. The maintenance and

expansion is supported by NBIC (Netherlands

BioInformartic Center).

REFERENCES

Attwood T et al., 2005. EMBER - A European Multimedia

Bioinformatics Educational Resource.

http://www.bioscience.heacademy.

ac.uk/journal/vol6/beej-6-4.aspx

Benson G., 2011. Nucleic Acids Research annual web

server issue in 2011. Nucleic Acids Research, 39,

p.W1-W2

Cattley S, Arthur JW, 2007. BioManager: the use of a

bioinformatics web application as a teaching tool in

undergraduate bioinformatics training. Brief

Bioinform., 8(6):457-65

de la Vega, F. M., Giegerich, R. & Fuellen, G., 1996.

Distance education through the Internet: the GNA-

VSNS biocomputing course. Pacific Symposium on

Biocomputing, pp.203-215.

e-proxemis, Unpublished http://e-proxemis.expasy.org/

Fitzgerald, B., 2009, Drupal for Education and E-learning,

Teaching and Learning in the Classroom using Drupal

CMS, Packt Publishing, Birmingham, UK.

Galperin, M. Y. & Cochrane, G. R., 2011. The 2011

Nucleic Acids Research Database Issue and the online

Molecular Biology Database Collection. Nucleic Acids

Research 39, p.D1-D6.

Romano, P., Giugno, R. & Pulvirenti, A., 2011. Tools and

collaborative environments for bioinformatics

research, Brief. Bioinf. 12(6):549 -561

Sboner et al., 2011. The real cost of sequencing: higher

than you think! Genome Biology, 12(8):125

Schneider, M.V. et al., 2010, Bioinformatics training: a

review of challenges, actions and support

requirements. Brief. Bioinform. 11(6):544-51

Via, A. et al., 2011. Ten Simple Rules for Developing a

Short Bioinformatics Training Course. PLoS Comput

Biol, 7(10), p.e1002245

Williams JM et al., 2010. Openhelix: bioinformatics

education outside of a different box. Brief.

Bioinform. 11(6):598-609

Wright VA et al., 2010, Bioinformatics training: selecting

a relevant content management system – an example

from the EBI. Brief. Bioinform. 11(6):552-62

eBIOMICS - A Website Promoting Good Practices and Specific Methods for using Bioinformatics Resources

391
