PROTECTING PRIVATE DATA IN THE CLOUD

Lars Rasmusson and Mudassar Aslam

Swedish Institute of Computer Science, Kista, Sweden

Keywords:

Cloud Computing, Virtualization, Trusted Computing, Binary Translation.

Abstract:

Companies that process business critical and secret data are reluctant to use utility and cloud computing for the

risk that their data gets stolen by rogue system administrators at the hosting company. We describe a system

organization that prevents host administrators from directly accessing or installing eaves-dropping software

on the machine that holds the client’s valuable data. Clients are monitored via machine code probes that are

inlined into the clients’ programs at runtime. The system enables the cloud provider to install and remove

software probes into the machine code without stopping the client’s program, and it prevents the provider

from installing probes not granted by the client.

1 INTRODUCTION

In cloud computing, computing resources are pro-

vided by one or more organizations, and are used by

other organizations. This is usually the only shared

interest between the providers and the clients, and

that distinguishes cloud computing from regular dis-

tributed computing within a company. The limited

shared interest in cloud computing is the fundamental

reason for the client to distrust the cloud provider, as

well as for the provider to distrust the client.

However, cloud computing’s large potential for

more efﬁcient computing, in both technical and eco-

nomical sense, is a strong reason to try to overcome

this mutual distrust.

Research in security for cloud computing has fo-

cused on isolation of the clients’ computation in-

side virtual machines (VM) on various levels to

protect the cloud infrastructure from attacks by

clients, and to protect clients from attacks from each

other (Christodorescu et al., 2009). This problem is

now routinely solved with virtualization.

Current solutions have not done enough to ad-

dress the issue of how to protect the client from the

provider. The lack of protection against the provider

has prevented the adoption of cloud computing for

clients that have private, business critical or conﬁden-

tial data or algorithms i.e. the ﬁnancial, government,

health, pharma, and movie sectors. The risk clients

face of having their data or programs leaked or stolen

by the provider, either deliberately, by mistake, or by

a disgruntled or black-mailed employee, has so far be-

en considered too large. In (Kuttikrishnan, 2011) sev-

eral studies of cloud adoption are summaprized and

reporting as one obstacle that cloud adoption ”in-

volves developing trust and overcoming the fear of

change and loss of control over data and processes.”

While the risk from attacks by the provider are not

unique to the cloud (they are already present in hosted

environments), they are increased by the more short-

lived and anonymous relationships between the par-

ties in clouds with multiple providers and automatic

migration of data and computation.

We propose a novel solution to the problem of mu-

tual distrust. It is based on using trusted computing

to prevent the cloud provider from installing eaves-

dropping software on the platform, on using a binary

translation framework to let the provider install soft-

ware probes into the clients software, and on an initial

negotiation phase to determines which probes may

actually be installed on the platform to satisfy both

provider and client. So, while the provider is locked

out from the client’s VM she is provided with an-

other tool that enables her monitor the client’s VM for

malicious behavior without compromising the client’s

need for data protection.

The next section describes the system architec-

ture. Section 3 explains the current implementation.

It is followed by an analysis of the security of the sys-

tem in section 4. The paper is concluded in section 5

with related work and the contributions made in this

system.

Rasmusson L. and Aslam M..

PROTECTING PRIVATE DATA IN THE CLOUD.

DOI: 10.5220/0003895800050012

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CLOSER-2012), pages 5-12

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Provider

Customer

TPM HW

Xen VMM

Boot loader

Control VM Customer VM

Linux

Authentication

& mgmt SW

Binary Code

Inliner

Customer SW

Life cycle cmds

Supervision cmds

Policy

Allowed

commands

and SW

Signed by

Provider

Figure 1: Computer resource.

2 ARCHITECTURE

Our goal is to have a runtime system for clouds where

the provider can check for e.g. viruses/botnets, un-

licenced software, etc., while at the same time veri-

ﬁably show to a remote client that the provider has

no posibility to extract undue information from the

client’s virtual machine.

2.1 Resources

The cloud infrastructure is composed of computa-

tional resources, a resource management system, and

a PKI with certifying authorities. The computational

resources are the computers, networks and storage

that the provider is offering to clients.

Figure 1 shows a computer in the cloud that is run-

ning a virtualization layer, management software, a

machine code inliner and the client’s software.

The provider conﬁgures the computers by setting

them up for trusted boot, installs the necessary soft-

ware on them (the “trusted software stack”), and reg-

isters their availability to the resource management

system. See step 1 and 2 in ﬁgure 2. The software that

is installed on the computers is responsible for only

permitting authorized commands to be executed. In

particular, it must prevent the provider from gaining

root access or full control over the machine. Trusted

third parties may be required to audit the trusted soft-

ware for bugs and to make sure that the machines are

guarded against physically attacks or modiﬁcations.

2.2 Software Probes

Instead of root access or physical access, the cloud ad-

ministrators are provided with a software tool that en-

ables them to install software probes into the client’s

running program. The probes may check for network

attacks made by the client, for undue hardware access,

or perform software license enforcement by detecting

execution of licensed code. Since they are in soft-

ware, probes can be arbitrarily complex, but to pre-

vent probes from leaking information to the provider,

only safe probes authorized by the client must be in-

stalled. This is assured by the trusted management

software.

A probe is monitoring the CPU state and one or

several memory cells or data structures inside the

client’s VM, in the kernel or in the application pro-

grams. (Constructing probes that look into applica-

tion data structures will require access to symbol ta-

bles or debug information.) When the probe detects

an action, it can update counters or other data struc-

tures in a protected memory area which is not adress-

able by the client software. An appropriate probe may

thus detect execution patterns that the provider has re-

quested to scan for. How the provider gets the infor-

mation from the probe is described in section 2.4.

Probes are built into the code at the time that it

is Jut-In-Time (JIT, immediately before execution)

translated from its original form to the code to be ac-

tually executed. For each machine instruction in the

original code a corresponding function that emulates

the instruction on a virtual CPU exists. To create new

machine code for a sequence of instructions in the

original program, a sequence of function calls are cre-

ated in the LLVM (Lattner and Adve, 2004) interme-

date representation (IR). These calls are then linked

(at run time) with in-memory IR code for the func-

tions, inlined, constant folded, and optimized, before

new machine code is emitted. A cache can be used to

avoid redoing this for loops.

Concretely, probes are implemented as modiﬁ-

cations/extensions to the functions that emulate ma-

chine instructions. For instance, they may count the

number of times a certain memory address is accessed

by the ADD instruction. While this check at ﬁrst will

appear at ever place the ADD instruction occurs, the

optimization step will in many cases be able to re-

move this check based on constant information known

at run-time.

2.3 Procurement

A client wishing to run a private computation on

a cloud resource contacts the resource management

system to get access to a free resource. See steps

3 and 4 in ﬁgure 2. In the negotiation with the re-

source management system the client can negotiate

an acceptable set of probes that may be installed on

the machine, but if no agreement can be made, no re-

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

Client

console

Provider

console

Cloud Infrastructure

Procure-

ment

server

Resources

Cloud

Computer

Cloud

Computer

Cloud

Computer

Cloud

Computer

Cloud

Computer

1. Setup HW

with TPM

2. Install certi-

ﬁed SW

3. Announce resources

5. Integrity veriﬁcation

6. VM Launch

7. Install probes

4. Discover and

negotiate for resource

Trusted

Figure 2: Startup, procurement and launch.

source can be allocated. Once details about payment

have been cleared, the resource management system

issues a resource deﬁnition ﬁle containing a policy de-

scription.

2.4 Resource and Policy Description

File

The resource description contains a policy (see ﬁg-

ure 1) consists of a list of commands that may be

executed, and the identity of the one who may trig-

ger them. For instance the client “C1” may execute

the commands “run” and “destroy” to start and re-

move his virtual machine. The provider “cloudP”

may execute the command “installVirusProbe”, “re-

moveVirusProbe”, and “getVirusProbeReading”. The

meaning of these commands are also deﬁned by the

policy ﬁle, as the commands are deﬁned in program

ﬁles whose checksums are stored in the policy ﬁle.

The resource description ﬁle also contains the

checksums that the trusted software stack will gener-

ate in the Trusted Platform Module (TPM), the public

key of the TPM on the physical computer, and the net-

work address of the resource’s Launch Manager.

The ﬁle is signed by the provider, and the signa-

ture is veriﬁed by the resource computer during the

VM Launch step.

2.5 VM Launch

To start using the resource, the client contacts the

Launch Manager and asks via a challenge response

protocol for proof that the machine has a genuine

TPM on a certiﬁed platform. (See step 5 in ﬁgure 2.)

The Launch Manager asks the TPM chip to provide

the necessary signed certiﬁcates and forwards them

to the client who veriﬁes them. (Essentially, a TPM

chip contains a protected private key that the software

cannot access. The chip maker has supplied a certiﬁ-

cate stating that a chip with the associated public key

was made in their factory. The client asks (via the

Launch Manager) the TPM to sign a partly random

string. The response is checked to see that signatures

and certiﬁcates match.)

Once satisﬁed that the platform is genuine, the

next step for the client is to verify that the correct

trusted software stack is installed. For that, the client

requests a signed dump of the checksum registers in

the TPM. The TPM checksum registers are updated

during system startup, from BIOS (on machine initial-

ization code) start and on, and can only be physically

reset by rebooting the machine. Since all the trusted

software checksums all trusted software it loads in,

the checksum registers will be in a speciﬁc state, de-

pending on which software that has been loaded.

Once the client has veriﬁed that the checksum reg-

isters are in the state described in the resource ﬁle (and

potentially checked with a third party that this soft-

ware stack is indeed to be trusted), it can upload the

private data and code to the cloud, knowing that con-

trol of the machine can only be done via the narrow

command interface deﬁned in the policy description.

(See step 6 in ﬁgure 2.)

2.6 Probe Inlining

The software probes are inlined into the client’s ma-

chine code with a Binary Code Inliner that runs under-

neath the client’s program, essentially as a JIT com-

piling machine emulator. (See step 7 in ﬁgure 2.)

The main reason why the probes are JITed in

rather than inserted as jumps is to enable complex

probes to be mixed into the code everywhere with-

out causing excessive branching, since that is ex-

pensive on modern architectures with deep pipelines,

prefetching, and branch prediction. Another reason is

that the JITed probes can be reduced in size by JIT

optimization using local knowledge of the machine

code.

The Inliner disassembles machine instructions up

until a branch and generates new code that emulates

the instructions in another area of the memory. The

emulation code may be extended with probe code to

do more things than the normal code, such as maintain

counters, track state changes or information ﬂows in

the program, detect the occurrence of certain data in

the memory, etc.

The Inliner optimizes the code to remove constant

checks, inline function calls, reuse partial computa-

tion values, and merge multiple updates to the same

memory location into one. Thus, JITed monitoring

code that does a lot of the same checks all the time

can be greatly reduced in size compared to running

the full monitoring code each time.

PROTECTINGPRIVATEDATAINTHECLOUD

The JITed code is stored into a code cache, and

once an already JITed entry point is called again, the

cached code is used. Since loopy code will achieve

high cache hit rate, the expensive JIT step will be

amortized. The additional cost of probe processing

cannot be amortized since it is new functionality that

is added to the system. The probing cost should thus

be considered as a cost for protection against a om-

nipotent but rogue system administrator.

Turning probes on and off amounts to using dif-

ferent sets of emulation code and using separate code

caches or clearing the code cache when probes are

toggled.

3 IMPLEMENTATION

3.1 Base System

Our current implementation is running on a dual hex-

core Intel Xeon based Ericsson GEP3 board. The

GEP3 has a TPM soldered onto the board (and not

replaceable TPM module). It has a special BIOS that

checksums the BIOS, ﬁrmware and boot loader be-

fore it passes control to the boot loader.

The boot loader is a version of Trusted

Grub (Trusted Grub, 2012) which is conﬁgured to

checksum and load a Xen VMM (Virtual Machine

Monitor, a software layer that provides virtualiza-

tion functionality and isolation), a Linux kernel and

a ramdisk, before it launches Xen. Xen then launches

the Linux kernel in a virtual domain, the Control VM.

The Linux kernel creates checksums of all the bi-

naries and conﬁg ﬁles that are loaded into the sys-

tem and keeps the checksums in a loaded ﬁles list

that can later be checked by a client. Since varying

load order would change and aggregated checksum,

the checksums are not stored in the TPM checksum

registers. Instead, the client has to check the kernel’s

list to make sure that no unauthorized program has

been launched before.

3.2 Launch Manager

After the boot process has ﬁnished, the Launch Man-

ager is started. It is written in Java and uses the IAIK

java Trusted Software Stack (IAIK java Trusted Soft-

ware Stack, 2012) to communicate with the TPM chip

on the board. The Launch Manager is run as a user

level process and has no system level access. Access

to the TPM device and Xen commands are provided

via group permissions and setuid:ed scripts that dou-

ble check the parameters and access rights before ex-

ecution.

Binary code inliner

Libraries (LLVM, Xenlib, ...)

VM Image code ("kernel") - RO

Newly generated machine code

RAM to Client VM

Probe state variables

LLVM reads code

and writes new code

Client code

access

Probe code

access

Inliner may report

probe variables

to dom0

Figure 3: Memory regions inside the client’s Xen domain.

All communication with the Launch Manager is

made over TLS (Transport Layer Security commu-

nication protocol) and uses certiﬁcates to establish

identities of all parties. The launch manager receives

the resource description ﬁle from the client and starts

to accept and execute the commands that are listed

in the resource deﬁnition ﬁle, provided that all ﬁle

checksums are correct. The commands to manip-

ulate the virtual machines are executed with Java’s

Runtime.exec(cmd).

During the launch phase, the Launch Manager

sends back a bind key to the client, which is a pub-

lic key inseparably tied (or bound) to the machine’s

TPM, which the client uses to encrypt its secret data.

The encrypted data can then only be decrypted by the

very TPM on which the bind key was created.

The Launch Manager receives an encrypted tar ﬁle

containing the VM image and other necessary ﬁles

from the client which it decrypts, unpacks and uses

to create the virtual machine. The client’s code is not

set to run directly into another Xen domain. Instead

the Launch manager creates a Customer VM domain

with a Binary Code Inliner kernel, and then sends over

the client’s code and data to the Inliner to execute,

together with the software probe ﬁles to be installed.

3.3 Binary Code Inliner

The Binary Code Inliner is based on the Mini-OS

Xen software. It is a miniature kernel that can be

used for driver domains. The Binary Code Inliner

contains the LLVM libraries necessary for disassem-

bling, building, optimizing and JIT compiling native

machine code.

The Inliner communicates with the Launch Man-

ager over the Xenbus message passing interface, and

via a shared memory page for fast transfer of ﬁles be-

tween the domains.

The Inliner uses different memory regions for the

client’s VM’s RAM and the memory in which the

probes store their state information. (See ﬁgure 3.)

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

Since the pure emulation code never will access the

probes memory area, there is no machine instruction

the client can use to access the probe memory. But

probe code that is mixed in with the emulation code

can access the probe memory as normal memory,

without needing changing the memory context or us-

ing traps. Therefore the JIT compilation can produce

very lightweight and ubiquitous software probes.

The Inliner is written in C++ and C to interface

with LLVM and Mini-OS and is about 2MB in size,

mostly due to the large libraries that it includes. It cur-

rently only supports a subset of the full X86 instruc-

tion set, and more sophisticated optimization such as

optimization across multiple code blocks is not yet

implemented.

4 SECURITY ANALYSIS

4.1 Locking Out the Provider with TC

A rogue system admin may try to eaves-drop and

dump data in the clients’ virtual machines to sell,

use, or to keep “for a rainy day”. Trusted Computing

(TC) with hardware chip (TPM) is used to convince

the client that no eaves-dropping software is installed.

Trusted boot lets the client verify that the system was

started up in a known state, but it is the loaded trusted

software that correctly must prevent remote login and

other undue access, as Trusted Computing (TC) can-

not protect against software bugs in that software.

Some attacks can be detected by TC, i.e. if an in-

trusion has triggered loading of an unexpected binary

it will be listed in the kernel’s loaded ﬁles list, but in

general TPM really relies on having a locked down

trusted software stack. In the described system the

trusted software stack consists of the BIOS, ﬁrmware,

boot loader, Xen, the Linux kernel, the OS conﬁgura-

tion ﬁles, and the Launch Manager and its runtime

system (Java). The need for trust is reduced by layer-

ing. The trust in the Launch Manager does not have

to be complete, as it is partly isolated with OS tech-

niques. The Launch Manager runs as a low privileged

user process that is not allowed to arbitrarily access

VM memory or other xm or xenstore commands. In

the current implementation the Launch Manager is re-

sponsible for decrypting the client’s VM image. This

task should be moved into the kernel, to remove the

ability for a subverted Launch Manager or other pro-

cess in the Control VM to leak decrypted uploaded

client data.

The Launch Manager is written in Java, but may

also execute commands with Runtime.exec(cmd).

The commands that it executes are taken from a policy

ﬁle that was signed by the provider, but the client has

full access to what the commands do and their binary

code. Because their checksums are also in the pol-

icy ﬁle the management commands cannot be modi-

ﬁed neither by the client nor by the provider. To pre-

vent the provider from putting malicious commands

into the policy ﬁle, the client needs an external audi-

tor to vet the code. The cost of the vetting will spur

the adoption of commonly used and well understood

software and policies, or increase demand for formal

computer-checked security proofs.

TC does not guard against physical attacks except

through obscurity and complexity, and in theory TC

can be circumvented by tricking the TPM to be re-

set by physically manipulating its input pins. After a

reset, arbitrary values can be loaded into the check-

sum registers, hiding the presence of malicious soft-

ware. The data in RAM capsules and hard disk is

not encrypted by the TPM. To prevent the hardware

from being physically extracted from the machine the

machines must be guarded, and policies must be en-

forced to for instance never let a single unmonitored

system admin manipulate the machines. Since the

TPM does not encrypt the data in memory or the com-

putation, it does not protect against forced access to

the hardware (e.g. due to a warrant).

TC is vulnerable to TPM chipmakers that issue

false TPM certiﬁcates or put in backdoors in the chip

to extract the private keys, as it enables man-in-the-

middle attacks on the supposedly authenticated com-

munication between the client and the TPM.

4.2 Locking Out the Client

The system relies on standard techniques for locking

out the client from attack on infrastructure and other

clients: the clients’ software is executed in low privi-

leged virtual machines whose access to hardware goes

via a virtual device layer that enforces limits on net-

work access, I/O and memory capacity consumption.

The standard techniques are not sufﬁcient for detect-

ing and blocking botnets and other malicious software

that may thrive in the cloud. A cloud client who is

hacked may be made to run software that causes great

damage on others. To detect such activity, providers

usually have the ability to look deep into their clients’

processes and VMs. Unfortunately, the same abil-

ity also opens up to data-stealing by rogue system

admins. Instead of giving direct and full access to

the admins, the cloud architecture provides a means

for them to inject pre-deﬁned software probes that

probe for characteristic patterns or activities of bot-

nets, viruses, etc., and act or alert only when some-

thing is detected.

PROTECTINGPRIVATEDATAINTHECLOUD

Malicious software in the client may try to cir-

cumvent the probes by overwriting the memory area

where they store state information. They are unable to

do so because each instruction in converted into new

code that cannot explicitly address the probes’ private

memory area.

An attacker may try to disassemble the code to de-

tect the probes, but the machine instructions that the

client will see are read from a different part of the

memory than the actual machine code, because the

memory is virtualized. A client disassembling the in-

struction at its PC register will disassemble its virtual

memory, because the PC (and the other registers) is

virtualized and points into the original code, not the

newly generated code with probes.

The layered design is helpful if there are bugs in

the Binary Code Inliner and LLVM. In the worst case,

an attacker may construct an instruction sequence that

tricks LLVM’s JIT compiler to produce JITed code

that breaks out of the Inliner. The risk is minimal, but

if that happens, the program is still isolated in the Cus-

tomer VM, which is an unprivileged Xen domain, and

it is therefore prevented from attacking the Launch

Manager in the Control VM.

5 RELATED WORK AND

CONTRIBUTIONS

5.1 Related Work

Terra (Garﬁnkel et al., 2003) describes a trusted

virtual machine monitor that uses Trusted Comput-

ing (Trusted Computing Group, 2012) to prevent the

machine owner (provider in our terminology) from

accessing the contents of a virtual machine to pro-

tect its conﬁdentiality. Trusted Computing for cloud

computing is ﬁrst suggested as a possible solution

by (Santos et al., 2009), which so far only contains

early work on protocols for launching and migrat-

ing virtual machines protected by Trusted Comput-

ing. TVDc (Berger et al., 2008) let the client check

the integrity of a Xen dom0 and the user domains via

virtual TPMs, but the TVDc provider is neither locked

out nor given an alternative means for controlling the

client.

Machine code to machine code JIT translation

has been used to speed up execution in the Dynamo

system (Bala et al., 2000). It is not used to insert

additional monitoring code into the generated code.

PIN (Reddi et al., 2004) and DynamoRIO (Bruen-

ing, 2004) are tools that let a user write probes that

are dynamically injected into an application level pro-

gram, not a full OS. The probes are compiled before

injection, and no further optimization is done at run-

time. Their APIs operate on instruction level and ba-

sic block level.

LLVM (Lattner and Adve, 2004) is a compiler

framework that has an intermediate code representa-

tion that enables programmatical modiﬁcation, opti-

mization and JIT compilation at runtime. It is used

in the Binary Code Inliner to produce optimized code

for each translated basic block on the ﬂy.

Xen (Barham et al., 2003) uses hardware based

protection to isolate virtual machines and separate

memory areas. Xen can only monitor a few things,

such as what goes in and out via the virtual devices,

memory and CPU utilization rate.

PINOS (Bungale and Luk, 2007) instruments full

OS by running PIN inside a Xen VM. Its uses the

same low-level API as PIN. XenAccess (Payne et al.,

2007) is a tool that permits looking/sampling into the

memory of a running virtual machine by following

entries and pointers in the symbol tables and data

structures in the VMs memory. It does not enforce

limits, and it does not monitor memory or registers

continuously, but only when an external monitoring

program is explicitly started from outside of the VM.

Van Dijk, et al. (Van Dijk and Juels, 2010) ar-

gue that software alone, such as fully homomorphic

encryption or secure multiparty computation is not

enough to provide privacy-preserving cloud comput-

ing. They point out Trusted Computing’s weakness

with respect to hardware attacks. Parno points out the

problem of getting the TPM key to the client (Parno,

2008). We argue that hardware attacks may be coun-

tered with (human) guards, and that a public key in-

frastructure can prove to a user that the keys are gen-

uine.

While our system uses policies to inline special-

ized machine code into the client’s binary, it has still

been compared to iRODS (Wan et al., 2009), a policy

based system for controling cloud clients’ access to

data. While iRODS enforces policies at speciﬁc en-

forement points, our system may insert control poli-

cies anywhere into the client’s binary. It may also ex-

cercise control over the execution, not just over access

to data. While the iRODS system is more mature,

our system is yet but a (versatile) tool for implement-

ing and executing ﬁne grained policies. Which those

policies will be, what they will measure and how to

implement them concretely still remains to be found

out.

While some recent surveys of multi-tenant clouds

(Rodero-Merino et al., 2012) still ignore the risk of a

rogue provider, Vaquero et. al. (Vaquero et al., 2011)

list what they consider the main threats to IaaS clouds,

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

including malicious insiders, the risk for data loss and

leakage, and account or service hijacking. They sur-

vey current work addressing these threats, i.e. (Con-

standache et al., 2008; Descher et al., 2009; Baldwin

et al., 2009). With respect to the threat of insiders, the

listed solutions only address the task of locking out

the provider. The main purpose of our solution is to

provide an environment that restores some power to

the provider by offering her a versatile tool to, in a

controlled way, inspect the client at run time.

5.2 Contribution

Our contribution is to develop a cloud architec-

ture and proof-of-concept prototype implementation

that (under the Trusted Computing assumptions) can

prove to the client that no eaves-dropping software is

or can be installed on the resource computer.

The cloud administrators’ lost supervisory powers

are partially compensated with a generic tool (probe

inlining) in which invasive checks and enforcement of

the client’s VM for detection and thwarting of dan-

gerous activities can be implemented. The plan is

that probes for botnets, viruses, and cloud infrastruc-

ture attacks will be implemented in this framework,

but speciﬁc probes have not been the focus of our

current work. Probes are installed on a ﬁne-grained

per-instruction level meaning they are always on, and

the probes cannot be accessed or circumvented in any

way by the client’s software.

The idea to only let cloud system admins install

software probes into the clients’ VMs instead of hav-

ing full access to a machine is new. Our approach for

doing that, JIT machine code translation is not new,

but our approach of translating it into an intermediary

compilation format that enables mixing in high level

probing functions, and to optimize entire basic blocks

rather than individual instructions, is to our knowl-

edge not found elsewhere.

We also have contributed a TPM based archi-

tecture in which policies that determine the extent

of probing ﬁrst are negotiated between provider and

client, and later provably enforced by the cloud soft-

ware.

We have presented a security analysis to highlight

the strengths and limitations of the security provided

by this cloud architecture.

The current work consists of the architecture for

the runtime system for the probes, and does not

yet provide any speciﬁc language for declaratively

deﬁning probes. Deﬁning concrete probes for actual

threats remains an issue for future work.

ACKNOWLEDGEMENTS

We wish to thank Christian Gehrmann at SICS and

Andrs Mhes and Rolf Blom at Ericsson for thoughtful

comments and critique. Special thanks to Andrs for

providing, conﬁguring and thoroughly locking down

the GEP3 board and Xen. We also wish to thank the

anonymous reviewers for their helpful comments.

REFERENCES

Bala, V., Duesterwald, E., and Banerjia, S. (2000). Dy-

namo: a transparent dynamic optimization system. In

Proceedings of the ACM SIGPLAN 2000 Conference

on Programming Language Design and Implementa-

tion, PLDI ’00, pages 1–12, New York, NY, USA.

ACM. http://doi.acm.org/10.1145/349299.349303.

Baldwin, A., Dalton, C., Shiu, S., Kostienko, K., and Ra-

jpoot, Q. (2009). Providing secure services for a vir-

tual infrastructure. SIGOPS Oper. Syst. Rev., 43:44–

51. http://doi.acm.org/10.1145/1496909.1496919.

Barham, P., Dragovic, B., Fraser, K., Hand, S., Har-

ris, T., Ho, A., Neugebauer, R., Pratt, I., and

Warﬁeld, A. (2003). Xen and the art of virtu-

alization. SIGOPS Oper. Syst. Rev., 37:164–177.

http://doi.acm.org/10.1145/1165389.945462.

Berger, S., C

aceres, R., Pendarakis, D., Sailer, R., Valdez,

E., Perez, R., Schildhauer, W., and Srinivasan, D.

(2008). TVDc: managing security in the trusted vir-

tual datacenter. SIGOPS Oper. Syst. Rev., 42:40–47.

http://dx.doi.org/10.1145/1341312.1341321.

Bruening, D. L. (2004). Efﬁcient, transparent,

and comprehensive runtime code manipu-

lation. PhD thesis, Massachusetts Insti-

tute of Technology, Cambridge, MA, USA.

http://citeseerx.ist.psu.edu/viewdoc/summary?doi=10

.1.1.68.7639.

Bungale, P. P. and Luk, C.-K. (2007). PinOS: A pro-

grammable framework for whole-system dynamic in-

strumentation. In Proceedings of the 3rd interna-

tional conference on Virtual execution environments,

VEE ’07, pages 137–147, New York, NY, USA. ACM.

http://doi.acm.org/10.1145/1254810.1254830.

Christodorescu, M., Sailer, R., Schales, D. L., Sgan-

durra, D., and Zamboni, D. (2009). Cloud

security is not (just) virtualization security: a

short paper. In Proceedings of the 2009 ACM

Workshop on Cloud Computing Security, CCSW

’09, pages 97–102, New York, NY, USA. ACM.

http://doi.acm.org/10.1145/1655008.1655022.

Constandache, I., Yumerefendi, A., and Chase, J. (2008).

Secure control of portable images in a virtual

computing utility. In Proceedings of the 1st

ACM workshop on Virtual machine security, VM-

Sec ’08, pages 1–8, New York, NY, USA. ACM.

http://doi.acm.org/10.1145/1456482.1456484.

Descher, M., Masser, P., Feilhauer, T., Tjoa, A. M., and

Huemer, D. (2009). Retaining data control to the

PROTECTINGPRIVATEDATAINTHECLOUD

client in infrastructure clouds. Availability, Reliabil-

ity and Security, International Conference on, 0:9–16.

http://doi.ieeecomputersociety.org/10.1109/ARES.20

09.78.

Garﬁnkel, T., Pfaff, B., Chow, J., Rosenblum, M., and

Boneh, D. (2003). Terra: a virtual machine-

based platform for trusted computing. In Pro-

ceedings of the Nineteenth ACM Symposium

on Operating Systems Principles, SOSP ’03,

pages 193–206, New York, NY, USA. ACM.

http://doi.acm.org/10.1145/945445.945464.

IAIK java Trusted Software Stack (2012).

http://trustedjava.sourceforge.net.

Kuttikrishnan, D. (2011). Cloud Comput-

ing: Slow Adoption Rates, Current Ob-

stacles. http://www.datamation.com/cloud-

computing/cloud-computing-slow-adoption-rates-

current-obstacles.html.

Lattner, C. and Adve, V. (2004). LLVM: A Com-

pilation Framework for Lifelong Program Analysis

& Transformation. In Proceedings of the Interna-

tional Symposium on Code Generation and Optimiza-

tion: Feedback-directed and Runtime Optimization,

CGO ’04, pages 75–, Washington, DC, USA. IEEE

Computer Society. http://llvm.org/pubs/2003-09-30-

LifelongOptimizationTR.pdf.

Parno, B. (2008). Bootstrapping trust in a ”trusted”

platform. In Proceedings of the 3rd Con-

ference on Hot Topics in Security, pages 9:1–

9:6, Berkeley, CA, USA. USENIX Association.

http://www.usenix.org/event/hotsec08/tech/full

paper

s/parno/parno.pdf.

Payne, B. D., Carbone, M., and Lee, W. (2007).

Secure and Flexible Monitoring of Vir-

tual Machines. Computer Security Ap-

plications Conference, Annual, 0:385–397.

http://doi.ieeecomputersociety.org/10.1109/ACSAC.2

007.10.

Reddi, V. J., Settle, A., Connors, D. A., and Cohn, R. S.

(2004). PIN: A Binary Instrumentation Tool for

Computer Architecture Research and Education. In

Proceedings of the 2004 workshop on Computer Ar-

chitecture Education: held in conjunction with the

31st International Symposium on Computer Archi-

tecture, WCAE ’04, New York, NY, USA. ACM.

http://doi.acm.org/10.1145/1275571.1275600.

Rodero-Merino, L., Vaquero, L. M., Caron, E., Mure-

san, A., and Desprez, F. (2012). Building safe paas

clouds: A survey on security in multitenant software

platforms. Computers & Security, 31(1):96 – 108.

http://dx.doi.org/10.1016/j.cose.2011.10.006.

Santos, N., Gummadi, K. P., and Rodrigues, R.

(2009). Towards Trusted Cloud Computing.

In Proceedings of the 2009 Conference on

Hot Topics in Cloud Computing, HotCloud’09,

Berkeley, CA, USA. USENIX Association.

http://portal.acm.org/citation.cfm?id=1855533.18555

36.

Trusted Computing Group (2012).

http://www.trustedcomputinggroup.org.

Trusted Grub (2012). http://projects.sirrix.com/trac/trustedg

rub.

Van Dijk, M. and Juels, A. (2010). On the impossi-

bility of cryptography alone for privacy-preserving

cloud computing. In Proceedings of the 5th USENIX

conference on Hot topics in security, HotSec’10,

pages 1–8, Berkeley, CA, USA. USENIX Association.

http://www.usenix.org/events/hotsec10/tech/full pape

rs/vanDijk.pdf.

Vaquero, L. M., Rodero-Merino, L., and Morn,

D. (2011). Locking the sky: a survey on

IaaS cloud security. Computing, 91:93–118.

http://dx.doi.org/10.1007/s00607-010-0140-x.

Wan, M., Moore, R., and Rajasekar, A. (2009). Integra-

tion of cloud storage with data grids. Computing.

https://www.irods.org/pubs/DICE icvci3 mainpaper

pub-0910.pdf.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience
