FSMesh

Flexibly Securing Mashups by User Defined DOM Environment

Yi Wang, Zhoujun Li

State Key Laboratory of Software Development Environment, Beihang University, 37 xueyuan road, Beijing, China

Tao Guo, Zhiwei Shi

China Information Technology Security Evaluation Center, Beijing, China

Keywords: Mashup, Html5, Sandbox, Web Workers, Web Application.

Abstract: A growing trend of nowadays web sites is to combine active content (applications) from untrusted sources,

as in so-called mashups, in order to provide more functionality and expressiveness. Due to the potential risk

of leaking sensitive information to these third-party sources, it is urgent to provide a secure “sandbox” for

playing the untrusted content and allow developers to apply flexible security policy at the same time. In this

paper, we propose and implement a new safe framework to prevent untrusted applications from interfering

with each other based on HTML5 technology. By creating a separated fake DOM environment in the

background, developers can load untrusted content into the “sandbox” and apply their custom security

policy in real window or server side when receiving script generated messages from it. The advantage is that

it is very flexible as the security policy is also written in JavaScript and requires minimum learning efforts

for web developers. The drawback is that it is based on element “web workers” and method “postMessage”

introduced in HTML5 and can’t be run in older browsers without these supports.

1 INTRODUCTION

A mashup is a web page that integrates content and

executes JavaScript from different sources. By

combining multiple separated services into a new

application, a mashup generates valuable product.

Facebook applications, gadgets on the iGoogle

homepage, and Google Maps embedded in hybrid

applications are all well known and successful

mashup examples in real world. In most cases, web

pages that display advertisements from ad networks

are also mashups, since they also employ JavaScript

for animations and interactivity. The evolution

within web 2.0 has made mashup an inevitable and

important part of web application but flawed with

security problems.

*This work has been partially supported by the National Natural

Science Foundation of China (No.60973105, No.61170189), the

Research Fund for the Doctoral Program of Higher Education No.

20111102130003 and the Fund of the State Key Laboratory of

Software Development Environment under Grant No.SKLSDE-

2011ZX-03.

HTML Lexer

HTML Parser

Syntax

Decisions

Document Generator

JavaScript Lexer

JavaScript Parser

Syntax

Decisions

JavaScript Runtime

Environment

Document Object

Model API

HTML Code

HTML Parse Tree

JS Code

JS Parse Tree

Instructions

HTML Code via document.write(), innerHTML et al.

JavaScript Code via eval() et al.

Text Node

String Value

Plain Text

HTML ParseTree via document.createElement() et al.

Figure 1: Functional diagram of browsers’ HTML

interpretation process.

Wang Y., Li Z., Guo T. and Shi Z..

FSMesh - Flexibly Securing Mashups by User Deﬁned DOM Environment.

DOI: 10.5220/0003899000960102

In Proceedings of the 8th International Conference on Web Information Systems and Technologies (WEBIST-2012), pages 96-102

ISBN: 978-989-8565-08-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

If inserted into the web page directly, these third-

party code fragments will run with the same

privileges as trusted, first-party code served from the

originating site. Hence, the trusted site is susceptible

to attacks by maliciously crafted pieces of code.

Malicious code may deface web sites to lay down

functionality and hijack user sessions or leak cookies

to cause disasters on user privacy. When simply

embedding code in frames, security threats still arise

as techniques such as CSRF (cross-site request

forge), clickjacking and frame busting may easily

circumvent weak border between the frame and the

main window. Moreover, the none or all security

insurance provided by SOP(same origin policy) of

frames will not enable web developers enough

flexibility in controlling the security level of certain

mashups.

There are various ways to secure mashups, from

static code transformation to dynamic running

protection. But all these methods will ultimately

undergo the browser’s native HTML interpretation

process as depicted in Figure 1(Mike Ter Louw and

V. N. Venkatakrishnan, 2009) and we argue that if

such process can be reproduced in a user customed

way, many problems will be solved without making

modification to the browser or untrusted code.

In this paper, we propose an emulated DOM

environment “sandbox” framework called FSMesh

within which the untrusted code will be parsed and

safely executed in the web workers(Ian Hickson,

2011) similar to browser’s interpretation process. But

its critical window APIs have been implemented with

different operation semantics so as to provide web

developers the mechanism to communicate with real

window and flexibly setup the security policy for

certain external source. As our tool is totally

implemented in JavaScript and can be easily

imported as a library into the original web page. So

this paper makes the following contributions:

• New secure mashup’s framework

• Flexible mechanism for web developer to setup

custom security policy

• Implement a prototype library compatible with

html5 technology.

The rest of this paper is structured as follows. In

Section II and III, we respectively describe design

and implementation of the framework. In Section

IV, we present related work on securing mashups or

advertisements. In Section V, we report empirical

results and analysis. Section VI concludes.

2 FSMesh DESIGN

Suppose that a bulletin board web developer wishes

to allow users to post contents with html tags and

especially enable the execution of script within the

blocks, he has to settle three challenges concerning

functionality and security. First, posted contents

with scripts may contain malicious code, thus

security issue must be settled by restricting the

accessibility of third-party script to the native

window object but allowing the trusted script to

access the untrusted DOM elements. Second, the

normal user interaction with the third-party elements

should be preserved as well as safely handling the

event generated by the scripts from them since it is

the primary requirement for rich internet application.

Finally, flexible and fine-grained security policy

must be able to be applied easily by web developers

and requires little modification to the current version

of web application and browsers.

2.1 Architecture

Main window

Web workers

uste

d C

window,

document,

<script>s,

...

FSMesh(worker part)

Message

processing

Module

FSMesh(window part)

Secure Content

Message

processing &

security

Module

XMLHttpRequest

Figure 2: The architecture of FSMesh framework.

The architecture of our FSMesh framework and its

inner interaction is depicted in Figure 2. Our

approach is to initially relegate the untrusted html

snippet into a newly created web workers with

FSMesh library imported. The snippet is then parsed

and executed under the isolated environment without

any interference from the real window. We then

detect effects generated by the script that would

normally be observable by the user, as the scripts

FSMesh-FlexiblySecuringMashupsbyUserDefinedDOMEnvironment

have not been disabled by our approach. These

effects are emulated, subject to policy-based

constraints, outside the isolated environment for the

user to observe and interact with by message passing

mechanism. User actions obtained in the real

window are also forwarded to the isolated

environment to allow for a response by the script.

Thus we enable a controlled interaction between the

user and the isolated environment, while blocking

several user-defined malicious behaviors.

Web applications that display third-party content

on client browsers are exposed to a wide variety of

threats. Although our framework can alleviate

content security threat, many other security threats

posed by embedding untrusted code are out of the

scope of our target. We do not address browser

vulnerabilities attacks launched through plug-ins,

vulnerabilities in image rendering and so on. We

also do not protect attacks from opaque content (e.g.,

Flash), since many possible attack vectors from

these binary formats require special treatment.

2.2 Content Confinement using Web

Workers

For basic security policy, the developer wants to

ensure outside script does not access the native

global window object. To enforce the policy, we

leverage the new element introduced in html5 “web

workers” as the ideal environment to place user

defined html parsing module and execute script.

Web workers defines an API for running scripts,

basically JavaScript, in the background

independently of any user interface scripts. This

allows for long-running scripts that are not

interrupted by scripts that respond to clicks or other

user interactions, and allows long tasks to be

executed without yielding to keep the page

responsive. To enforce the developer’s content

security policy, scripts are executed in the FSMesh

in web workers. The only way to communicate

between the main window and web workers is

message passing which means any access to code or

data in main window is not permitted. Web workers

is currently supported by some mainstream browser

vender such as Safari, Chrome, Opera and Mozilla

Firefox.

2.3 Controlled Interaction between

Environments

As the web workers is running in the background, it

has to invoke the native rendering mechanism of

browser by sending secure content to the main

window as known of a process called content

mirroring. Moreover, user’s interaction with the

content in main window will be passing forward to

the web workers as scripts are all have to be

executed in that environment for security insurance

with the process called event forwarding. User

custom security policy will be defined in main

window by developers and applied during the two

processes.

2.3.1 Content Mirroring

After content is parsed by the html parser into a

document tree and onload scripts are executed on the

web workers side, it will reflect the nodes of the

document into the main window by transforming

them into string and sending out via message

passing. On the other side, when receiving the html

string from web workers, main window will again

parse it into document. But this time, no script will

be executed as they have been already evaluated in

web workers and also not allowed for security

issues. The document will be transformed into

secure content for them to fill in the block formerly

removed.

2.3.2 Event Forwarding

To facilitate this interaction, events must be captured

on secure content in the main window and forward

these events to the web worker for processing. For

example, if some element possesses onmousemove

attribute and should invoke its script when mouse

move over it, we replace the original script with

clean “catching event” handler on the mirrored

element. The handler only listens for the mouse-

move event and forwards it to the shadow page via a

message. While the web worker receives such

message, it will dispatch the same event to the

element and execute the script safely. For event

handler defined by “addEventListener” on normal

document element, if it is related with keyboard or

mouse event then we treat the element in the same

way as above. Other kinds of event type or event

handler registered with window are discarded.

2.3.3 Policy Definition

As mentioned earlier, access of elements will be

regulated by the FSMesh security module where

policy definition takes place. These policies are

specified by defining validation procedures against

possible malicious content leading to or

communicating with outer space in the untrusted

code. These cases are listed in Table 1 and only

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

minimum trust level is defined (no trust). In this

way, web developer can define any kind of ways to

filter or validate the content or content will be

eliminated without treatment.

3 FSMesh IMPLEMENTATION

The implementation of FSMesh framework is

mainly consisted of DOM emulation module and

message interaction module. For the first module,

we port Envjs (server-side DOM environment

implemented in JavaScript) (John Resig, 2011) of

Rhino version to web worker for DOM emulation. A

few changes are needed for original code base

including replacing core part concerning platforms

and work around internal limitations of web

workers. For the message interaction module, as the

core of security policy enforcement, we introduce

content synchronization on both sides and filtering

functions in the main window side.

Table 1: Possible malicious content requiring security

policy enforcement.

Malicious

content

Example Default

action

‘href’ in <a>

element

<a href=”malicious.com”>… Remove

‘href’

‘action’ in

<form>

element

<form action=”malicious.com”>… Remove

‘action’

‘src’ in

<img>

element

<img src=”mal.com/mal.php”>… Remove

‘src’

http request <script>

var xhr=new XMLHttpRequest();

xhr.open(method, url);

xhr.send(content);

</script>

No http

request

allowed

location

redirection

window.location=”malicious.com”;

</script>

Location

not

changed

3.1 DOM Emulation

Envjs contains a html5 parser together with

definition of html elements that support parsing html

string and execute script node inside. The Rhino

version contains code that is specific for java

environment which is unsuitable for web workers.

Unlike server side program which has no restriction

for system access, browsers limit web workers’

ability in writing files, setting read-only predefined

properties(eg. location, navigator). We work around

this problem by initially assigning “window” as a

blank object and set its prototype to native web

workers’ “this” instead of directly assigning

“window” to be “this” . In this way, we can freely

extends “window” object or will be forbidden when

redefining read-only properties of web workers

otherwise. Injected scripts will be evaluated in “this”

and newly defined variables in “this” can be

accessed transparently by “window” via the property

finding mechanism through the prototype chain.

This process is depicted in Figure 3.

Some core window functions required to utilize

native window of the main page is implemented as

post message to real window with message type

specified. When the main page received such

messages, it will carry out corresponding actions if

security policy permits. As it is not possible to send

request to different origin web site for content by

browser’s SOP rule, we work around the function of

XMLHttpRequest by making the request to an

interface of same web site with the url as an

argument. Developer will set up the interface in the

server side as a proxy to retrieve from outer web site

for content.

Figure 3: Relationship of “this” and “window” in web

workers.

3.2 Content Synchronization

To reflect changes in web workers to main page and

handle event generated in main page in web workers

requires the developer to modify original contents in

three ways. The first modification is to remove the

post content. Second, we add the trigger scripts for

every removed contents to initiate content passing.

The third modification to the original page is to

implement event handling procedures in order to

pass correct event to the web workers. In the same

time, corresponding receiving mechanism in the web

workers side will be implemented for event to

dispatch to the right element.

3.3 Security Policy Enforcement

Although scripts inside web worker have no access

FSMesh-FlexiblySecuringMashupsbyUserDefinedDOMEnvironment

to object reside in main window, some actions have

to be realized in the main window when more

authority is required. So it relies on the developer to

decide the actions for different security policies. We

now describe in detail the individual permissions

granted by policies, how policies are specified, and

how multiple policies are combined to form a

composite policy.

As described earlier in Table 1, we have to deal

with the 5 cases where malicious actions can be

taken when content are mirrored on the main

window. FSMesh framework allows the developer to

override 5 API implementations to achieve the goal

of ensuring such security requirements to be met,

described in Figure 4. The default behavior of these

APIs is no operation which is highest in security

level but lowest in functionality level. It depends on

the specific cases to gain perfect trade-off between

the two factors and decisions are made by the

developers.

setLocation( url ):

Redirect the current location to url.

makeHttpRequest( url, content ):

Make a http request to url with content if ‘post’.

linkFiltering( link ):

Filter malicious href in <a> element.

imgFiltering( src ):

Filter malicious src in <img> element.

formActionFiltering( form ):

Filter malicious action in <form> element.

Figure 4: Security policy in main window.

4 EVALUATION

We evaluated FSMesh by self-made testing mashups

with regard to security and overhead performance.

For the case of security, the mashups are mostly

extracted from cross site scripting website consisted

of various kinds of script attacks from third-party

code. For the case of overhead performance, we

made incremental size of mashups to investigate the

time delay and memory cost caused by message

passing and html parsing of FSMesh framework.

4.1 Security Insurance

We set up Apache web server on our computer with

main test page as the index page and choose Firefox

4.0 as the our testing web browser. We then inject

various kinds of script blocks into the mashups in

the main page aiming to test prevention ability

against different objectives. These script codes

together with their attack goal are shown in Table 2.

Our experiments results support our claims that it

provides strong defense against several potential

attack vectors in which mashups are often exposed.

It should be noted that although attackers may

inject code that can override the core function of the

part of web workers for FSMesh and may transfer

malicious content as messages to main window. But

they won’t be able to find a way to change the code

of the main window’s part which ensures the

enforcement of security policy as the only

communication method between the two parts is

message passing.

4.2 Overhead Performance

To measure mashups rendering latencies caused by

our FSMesh framework, we placed incremental size

of mashups both on original main page and on

modified FSMesh page instrumented with time

benchmarking code. There were a total of 10

instances of mashups with size from 10 nodes to

1000 nodes. The test pages are rendered in Firefox

v4.0.1 on an AMD Athlon X2 4450 (2.30 GHz) PC

with 2.0GB RAM. Each modified FSMesh page

import our implementation source code (663 kB of

JavaScript), which was cached by the web browser

and is not optimized. Time and memory cost are

measured for the 10 test pages with and without

FSMesh framework and result for each case is the

average of 10 tests for accuracy.

Results of this experiment are shown in Figure 5.

Upper line in Figure 5a shows the time required to

render mashups in FSMesh with increasing number

of nodes, while the lower line indicate the same case

for normal rendering. Figure 5b shows the space cost

for both situations with upper line representing

FSMesh and lower line as normal rendering.

It is clear to see that the time latency is

comparably high for our framework and unlike

native rendering, it increase dramatically as the

number of nodes rise. The reason for this is mainly

because html parsing is a time and space consuming

task and web workers’ implementation in Firefox

still has issues in trace jit optimization. To settle this

single problem, it may suffice to replace the our

prototype javascript implementation with native

compiled version installed as a plugin in browser.

Another way is to extend the functionality of web

worker to support built-in parsing and DOM

manipulating. But these approaches will contradict

our main idea of non-modification to web browsers,

as web browser should only be responsible for

browsing the content of web pages. Thus, optimizing

the performance of javascript engine will be an

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

100

Table 2: FSMesh prevents scripts’ attack actions by execute in web workers.

Attack Objective Injection codes No FSMesh FSMesh

Execute arbitrary

code in window

<img src=JavaScript: alert('XSS') /> execute execute in WW

window.location=“http://malicious.com/”; redirect no redirect

var style = document.defaultView.

getComputedStyle (link, null);

get style get style in WW

<img src=nonexistent.gif onload=alert(1)>"; execute execute in WW

window.prompt(“enter your password”); execute execute in WW

document.write(“<script>alert(/XSS/)</script>”); execute execute in WW

Confidential information

leak

document.write(“cookie is:”+document.cookie); output cookie output nothing

xhr.open(“POST”,malicious_url);

xhr.send(document.cookie);

post cookie to

malurl

action filtered

Frame busting

top.location=”http://malicious.com/”; redirect No redirect

Content integrity

violation

var elm=document.getElementById

(“some_id_in_main_page”);

get element get element in WW

var elems=document.getElementsByTagName(“a”); get elements get elements in WW

Clickjacking <iframe src=”some_url”></iframe> iframe created iframe filtered

500

1000

1500

2000

2500

3000

10 100 200 300 400 500 600 700 800 900

nodes

With FSMesh

Without FSMesh

100

120

140

160

180

10 100 200 300 400 500 600 700 800 900

nodes

With FSMesh

Without FSMesh

(a) Time Latency (b) Memory Cost

Figure 5: Rendering overhead with increasing number of DOM nodes.

important area for future work in order to make such

framework practical and it is actually possible. With

the issues in web workers' trace jit optimization

settled, as well as cutting off useless functions in our

framework, the performance of FSMESH will be

comparable to native compiled version.

5 RELATED WORKS

PostMessage (Hickson and Hyatt, 2011) and

sandbox attribute (Hickson and Hyatt, 2011) are

extensions in HTML5 and augments the origin-based

separation of iframes. The sandbox attribute imposes

a set of restrictions, preventing scripts or browser

plugins to run or preventing forms from being

submitted.

MashupOS(H. J. Wang et al., 2007) argments

html tags to support additional trust levels within a

mashup. OMash(S. Crites et al., 2008) represent web

pages as objects, which have public interfaces for

interaction and encapsulates the internal state of a

web page, including associated resources such as

cookies.

The ADsafe subset(D. Crockford 2011) ,

Facebook JavaScript (FBJS) (Facebook 2011) and

Caja(M. S. Miller et al., 2011), which are secure

JavaSript subsets, are active protection mechanism,

which applies a rewriting process to normal

JavaScript by rewriting variable and function names

FSMesh-FlexiblySecuringMashupsbyUserDefinedDOMEnvironment

101

to a unique namespace. Although specific issues

with ADSafe and FBJS(S. Maffeis and A. Taly,

2009) in the security of JavaScript subset are

discovered, they do not break the fundamental of the

language. More importantly, the security of caja-

based JavaScript subsets has been able to prove to be

capability safe(S. Maffeis et al., 2010).

ConScript enables the specification and

enforcement of fine-grained security policies for

JavaScript in the browser(B. Livshits and L.

Meyerovich, 2009). Self-protecting JavaScript(P. H.

Phung, 2009) provides similar security features, but

does not require specific support within the browser.

Policy enforcement is achieved by wrapping

security-sensitive JavaScript operations before

normal script execution.

AdJail(M. Ter Louw et al. 2010) offers a

technique to mediate access to advertisements, which

are embedded as a DOM object and executed in an

iframe while interacting with hosting page. Our work

is comparable with AdJail in the way of seperating

untrusted content and interacting with hosting page,

but we make use of the more secure “web workers”

element in HTML5 considering the drawback of

frames. They utilize the html parsing and script

execution by native frame window with hooked

DOM manipulating APIs. But we argue that such

process is not capable of controlling every phase of

html parsing and browser behavior, and also too

coarse in the case of applying particular security

rules. Instead, by creating a fully implemented fake

DOM environment in the secure web workers, we

have everything at our hand. Thus, any attacks

targeting at frame or navigation will be nullified

while may easily compromise their technique.

6 CONCLUSIONS

In this paper, we present FSMesh as a solution for

the problem of confinement of third-party mashups

to prevents attacks on confidentiality and integrity.

The new safe framework which is based on HTML5

technology creates a separated fake DOM

environment in the background which allows

developers to load untrusted content into the

“sandbox” and apply their custom security policy in

real window. The benefit of FSMesh is both in

flexibility security policy enforcement and minimum

modification of original content. Our approach offers

developers an easy solution for confining untrusted

content in main stream browsers without steep

learning curve or installing new software. Although

the current framework suffers big overhead

performance problem, we believe that it can be

overcome by optimization. We plan to make the idea

possible by first inspecting the source code of web

workers for browsers and make extension for it to

support the function of FSMesh.

REFERENCES

I. Hickson and D. Hyatt (2011). Html 5 working draft

cross document messaging. http://www.w3.org/TR/

html5/comms.html#crossDocumentMessages.

I. Hickson and D. Hyatt (2011). Html 5 working draft - the

sandbox attribute. http://www.w3.org/TR/html5/the-

iframe-element.html#attr-iframe-sandbox.

H. J. Wang, X. Fan, J. Howell, and C. Jackson (2007).

Protection and communication abstractions for web

browsers in mashupos. ACM SIGOPS Operating

Systems Review, 41(6):16.

S. Crites, F. Hsu, and H. Chen (2008). Omash: Enabling

secure web mashups via object abstractions. In

Proceedings of the 15th ACM conference on

Computer and communications security, pages 99-

108. ACM.

D. Crockford (2011). Adsafe. http://www.adsafe.org/.

Facebook (2011). FBJS. http://developers.facebook.com/

docs/fbjs/.

M. S. Miller, M. Samuel, B. Laurie, I. Awad, and M. Stay

(2008). Caja: Safe active content in sanitized

javascript. http://google-caja.googlecode.com/files/

caja-spec-2008-06-07.pdf.

S. Maffeis and A. Taly (2009). Language-based isolation

of untrusted javascript. In 22nd IEEE Computer

Security Foundations Symposium, pages 77-91.

S. Maffeis, J. C. Mitchell, and A. Taly (2010). Object

capabilities and isolation of untrusted web

applications. In Proceedings of IEEE Security and

Privacy'10. IEEE.

B. Livshits and L. Meyerovich (2009). Conscript:

Specifying and enforcing fine-grained security policies

for javascript in the browser. Technical report,

Microsoft Research.

P. H. Phung, D. Sands, and A. Chudnov (2009).

Lightweight self-protecting javascript. In Proceedings

of the 4th International Symposium on Information,

Computer, and Communications Security, pages 47-

60.

M. Ter Louw, K. T. Ganesh, and V. N. Venkatakrishnan

(2010). Adjail: Practical enforcement of confidentiality

and integrity policies on web advertisements. In 19th

USENIX Security Symposium.

John Resig (2011). Envjs – Bring the browser to the

server. http://www.envjs.com/.

Mike Ter Louw and V. N. Venkatakrishnan (2009).

Blueprint: Robust prevention of cross-site scripting

attacks for existing browsers. In IEEE Symposium on

Security and Privacy, Oakland, CA, USA.

Ian Hickson (2011). Web Workers.http://dev.w3.org/

html5/workers/. July 2011

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

102
