UNTRACEABLE ANONYMOUS SERVICE CONSUMPTION

IN SaaS

Vinícius Pacheco and Ricardo Puttini

Department of Electrical Engineering, University of Brasília - UnB, Brasília, Brazil

Keywords: Cloud Computing, Software as a Service, Privacy, Multi-layer Security, Anonymity, Untraceable

Communication, E-cash.

Abstract: Several cloud computing providers are emerging to provide web services that encapsulate common business

logic in the cloud. However, these Software as a Service (SaaS) offers are currently based in trust

relationships between cloud consumers and providers. Consumer must trust the provider not to disclose

sensitive data exchanged during service provision, as such leak can compromise consumer’s privacy and

threaten its business. In this paper, we propose a privacy enhancing framework to protect consumer

information privacy against excessive exposure to cloud computing providers. Our design is essentially

based on anonymity technology, as conventional encryption and authentication security mechanisms do not

supply enough protection to consumer’s privacy; particularly, when the provider itself is considered a threat.

The design consists in a multi-layered framework, where different anonymity techniques are employed

together to protect the privacy of different types of consumer information, during both administrative (e.g.,

legal contracting and financial transactions) and technical (e.g., message exchanges) interactions. We also

describe a complete connection anonymity SaaS service consumption scheme based on e-cash as the main

tool for generating and managing anonymous credentials in the cloud.

1 INTRODUCTION

Software-as-a-Service (SaaS)

is a cloud computing

delivery model where a cloud provider offers and

provides application-level software services that

encapsulate parts of the consumer’s business logic.

SaaS service consumption is done through message

exchanges between the cloud consumer and the

cloud provider. Messages contain consumer’s data

and metadata and can often carry sensitive

information about the consumer’s business.

In this paper, we present an approach to protect

cloud consumer’s information privacy using

anonymity technology. We aim at establishing an

anonymity framework that enables message

exchanges in SaaS to happen anonymously and the

Although the term SaaS, as a cloud computing service model,

applies to a broad type of applications that can be accessed and

utilized as a service, this framework focuses in a particular subset

of the SaaS paradigm, where services are understood as

decoupled parts of business logic that are accessible through

simple request-response message exchange patterns (MEP),

expressed in a service contract, most likely available as SOAP or

REST web services.

consumer’s consumptions to remain untraceable.

Still, the consumer has proper access to services and

the provider can correctly authenticate, account, and

charge for service usage.

Díaz et al. in (Claudia Díaz et al., 2002) divide

anonymity, inside the context of privacy, into data

anonymity and connection anonymity. Data

anonymity relates to removing any identifying

information from the data itself, and, on the other

hand, connection anonymity focuses on protecting

the identities of source and destination during

communications.

The main contribution of our work consists in the

provision of connection anonymity in SaaS service

consumption. In short, our proposal consists in

establishing a pay-as-you-go service consumption

scheme in which the services are anonymously paid

for at the same time of service consumption, using

electronic cash primitives that are embedded in the

message metadata.

Although not in the focus of this research paper,

we acknowledge that data anonymity and network-

level connection anonymity are important building

blocks of a cloud computing anonymity framework.

Pacheco V. and Puttini R..

UNTRACEABLE ANONYMOUS SERVICE CONSUMPTION IN SaaS.

DOI: 10.5220/0003930700960101

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CLOSER-2012), pages 96-101

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Appropriated considerations about these issues are

pointed out in our formulation.

2 SERVICE CONSUMPTION

IN SaaS

Our target scenario consists in an enterprise

organization (consumer) making use of a particular

service that a provider organization (provider) offers

in the cloud as SaaS. This service consumption will

be made through message exchanges, performed

through the network. Our goal is to improve

information privacy in SOAP (and potentially,

REST) web services consumption. In this case, there

is a technical contract for each service that specifies

simple request-response message exchange patterns

(MEP) for each operation provided in the service.

Without loss of generality, our analysis concentrates

in the case of decoupled point-to-point interactions

using simple MEPs, but more complex compound

MEPs can also benefit from the proposed

framework.

The typical scenario for SaaS cloud computing

model starts with the service provider publishing the

service along with the respective service usage

conditions.

Next, the consumer interacts with the service

directory to locate the appropriate service that

provides the needed business functionality and

evaluates the service consumption conditions in the

service contract. This is the service discovery.

During service consumption, consumer requests

and receives services from provider using message

exchanges, which can, for example, be based on

SOAP standard.

Finally, provider invoices the consumer

according to the amount of service that was

consumed and receives the due payment.

2.1 Threat Model

Consumer’s information in the cloud is often

subjected to an increased number of threats, most of

them related to information exposure to the network,

to the provider shared IT environment – which can

allow access from other users (tenants) – and, in the

end, to the provider organization itself.

Amongst the possible SaaS threat models,

including, for instance, a network eavesdropper or a

malicious user sharing the same IT environment

with the consumer, none of these will have more

access to consumer’s information than the actual

service provider. Thus, the focus of this work is to

consider the provider as a possible origin of misuse

of consumer’s information. Providing information

privacy in the interactions between consumer and

provider will, in most cases, also enhance privacy

against other less powerful adversaries.

2.2 Privacy Assessment

Roger Clarke (Clarke, 1997) defines information

privacy as “the interest an individual has in

controlling, or at least significantly influencing, the

handling of data about themselves.” In the purpose

of this research, we drill down into information

privacy and present the following dimensions of the

concept:

• ID Privacy: to conceal the subject’s ID.

• Location Privacy: to not reveal the physical

whereabouts of the subject.

• Behavior Privacy: to hide not the content but

how this content is handled. Focuses in not

disclosing the correlation of the subject’s

information over time.

• Content Privacy: to conceal the subject’s

information.

Considering the scenario described, various types

of consumer information expose privacy,

specifically, during the message exchanges.

Following, we analyze how each can compromise

the privacy dimensions presented.

2.2.1 Message Metadata

In SaaS message exchanges, the provider needs to

authenticate, authorize and account (AAA) for the

service consumption. This also enables the provider

to correctly charge the consumer for service usage,

on demand. AAA is usually based on identification

credentials contained in message metadata.

Usual AAA credentials provide a direct link to

consumer’s ID. Besides, if this link can be done for

all messages, the provider can correlate messages

(and service usage) over time, compromising,

consequently, behavior privacy. The provider can

analyze these evidences to figure out when and how

the consumer conducts its business. It is important to

state that behavior privacy is affected even when the

message payload is not available, as information

about who is taking part in communications, along

with communication volume and patterns, can reveal

sensitive information. For message metadata,

location and content privacy are not considered.

2.2.2 Message Data

Message Data refers to the message payload present

UNTRACEABLEANONYMOUSSERVICECONSUMPTIONINSaaS

in the message exchanges. It is the information

needed by the provider in order to perform the

correct computations in the service consumption.

Message payload, as an item of interest, impacts

both ID and content privacy.

Vis-à-vis ID privacy, message payload can be

inspected and analyzed to reveal the consumer’s

identification, as consumer’s data can have semantic

links to consumer’s ID. As for content privacy, the

message payload is comprised of the actual

consumer’s data. Location and behavior privacy are

not considered in this type of consumer information.

2.2.3 Network-level Communications

Messages are sent through the network, typically in

the Internet, which implies that both consumer and

provider know each other’s network credentials

(e.g., IP addresses).

IP addresses affect both ID and location privacy.

Current IP addressing schemes link easily the IP

address to its owner and can be rapidly tied to a

geographic position (Beresford and Stajano, 2003).

Network traffic analysis, for instance, of TCP

connections transporting service messages, can

expose behavior privacy, revealing the correlation

between successive service usages over time.

Network protocols’ payload eavesdropping (content

and ID privacy) are not considered here, as this

information is the same as those in message

metadata and message data discussed before.

3 SaaS ANONYMITY

FRAMEWORK

3.1 Multi-layer Design

Safeguarding the anonymity of the consumer during

SaaS service consumption enables the protection of

business’ interests, avoiding the link between

message requests and their respective consumer.

However, as seen in the last section, ID, location,

behavior and content privacy relate to various types

of consumer information present in different layers

of interaction between consumer and provider.

Therefore, anonymity techniques can be employed

in a multi-layer design, enabling the use of different

and complementary techniques. In our framework,

the overall anonymity is preserved by adding up the

protection provided at each layer.

We are currently considering three different

layers in our anonymity framework, corresponding

to each type of consumer information described in

the previous privacy assessment: Message Metadata,

Message Data and Network.

Each layer utilizes specific anonymity

technology to enhance privacy of the respective

items of interest. The multi-layer design is a salient

feature of our framework: the anonymity technology

used in each level can be replaced or adapted to

meet specific requirements. Our goal is to make the

design flexible enough so it can be adjusted and also

evolve accordingly to privacy requirements,

producing the best fit to the privacy needs.

The first layer, Message Metadata, is a

distinguishing characteristic of the cloud computing

scenario. As for the remaining layers, Message Data

and Network, the approach can leverage on

established anonymity technologies, not directly

specific to the cloud computing model. Hence, in

this Section, we discuss general solutions for each

layer, but we present a detailed design only for the

first layer, in the next Section.

In a companion paper, we consider the case of

traceable anonymous service consumption, using

group signatures as the main anonymity technology

(Pacheco and Puttini, 2011).

The challenge in anonymous service

consumption in a cloud computing environment

relates to the need of the consumer to have access to

services, with appropriate SLA, and the need of the

provider to account and receive the payment related

to service provision. In conventional SaaS scenarios,

such as the one described in Section 2, SLAs are

usually specified in the service contract (WSDL),

which can be easily searched for and selected

anonymously by the consumer. However, the service

provision itself requires the consumer to be

authenticated in order to allow the accounting and

the billing for service usage. Moreover, consumer

and provider are directly bond by the invoice-

payment process, which represents a strong

impairment to anonymity.

In our design, we aim at anonymous service

consumption, implying consequently also in

anonymous payment. The basic idea consists in

using an anonymous electronic payment to be

performed at the time of service consumption. Our

approach is based on e-cash systems (Chaum, 1982),

(Okamoto and Ohta 1992), (Camenisch et al., 2005),

which fulfills two basic requirements: (1) consumers

must be able to obtain and use (pay for) e-cash

anonymously; and (2) providers must be able to

securely verify the payment immediately, during the

service consumption, i.e., after receiving the service

request (request message) and before providing the

service (response message). Note that in this

scheme, each service consumption instance is paid

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

for separately. This way, it is also desired that the

anonymous payment system supports offline micro-

payments (Camenisch et al., 2005), whose value can

be adjusted to the price of a single service

consumption instance.

When using our anonymous electronic payment

design, the consumer will simply include the

payment credential (i.e., an electronic coin or bill)

within the actual service request message metadata.

Upon receiving the service request message, the

provider verifies the payment and provides the

requested service in return, accordingly to the SLA

specified in the service contract. This simple

interaction scheme excludes the need of any kind of

previous bond between consumer and provider,

which can compromise the anonymity of the

interaction. The consumer is not even authenticated,

so the service consumption remains untraceable by

the payment transaction. However, if a more formal

and even legal bond between consumer and provider

is required, for instance, in order to limit the access

to the services or to provide compensations in case

of misuse or SLA unconformities, there is the

alternative of using traceable anonymity, which is

discussed in a companion paper (Pacheco and

Puttini, 2011). Traceable anonymity cannot be based

on e-cash systems, as those are usually untraceable,

and the design presented in (Pacheco and Puttini,

2011) is based on group signatures, instead.

3.2 Message Metadata Anonymity

In typical SaaS service consumption, the messages

being exchanged contains Message Metadata related

to AAA credentials. A context specific characteristic

of these credentials in the cloud computing model

relates to the billing process. However, AAA

credentials relate directly to the consumer’s ID. In

our design, these credentials are replaced by a

simple e-cash credential that is also the payment for

the service single usage. E-cash credentials are

anonymous and cannot be traced back to the

consumer.

3.3 Message Data Anonymity

Message Data anonymity relates to data anonymity

and can build upon an appropriated combination of

techniques to anonymize data.

Data anonymity can be challenging in cloud

computing services, as there are many different

types of data and data structures that are possible in

business logic and service design. A service-by-

service analysis may be required to establish the

appropriated data anonymity technique in order to

achieve efficient and effective data protection in

relation to privacy.

3.4 Network Anonymity

Network level anonymity has been an important

research topic since Chaum's mix-net design

(Chaum, 1981).

Standing as a state of art low-latency MixNet

system is The Second-Generation Onion Router -

Tor – (Dingledine et al, 2004), an improvement over

The Onion Routing project.

Tor is being extensively used and tested by a

dedicated community without major breakdowns,

and is a suitable technique for network-level

anonymity in cloud computing scenario. Also, as

cloud computing service consumption is in most

cases not tolerant to high latency channels, the fact

that Tor is a low-latency anonymity system

corroborates its selection.

4 UNTRACEABLE ANONYMOUS

SERVICE CONSUMPTION

4.1 Description

In this Section, we present the detailed design of our

untraceable anonymous SaaS service consumption

approach. Our proposal aims at providing

connection anonymity in order to protect consumer’s

ID, location and behavior privacy dimensions from

the provider during service consumption. The

requirements for that are threefold:

• Anonymous Payment System: consumer must

be able to obtain and use (pay for) anonymous

untraceable payment credentials, which can be

readily verified by the provider, before

authorizing the access to and supplying the

requested service.

• Message Metadata (ID): service consumption

request messages contain anonymous payment

credentials whose equivalent value in real

currency equals the price for a single use of the

service being requested. These credentials do not

reveal the consumer’s ID at the moment of the

service consumption, and also cannot be traced

back to the consumer later.

• Correlation of Data and Metadata over time:

subsequent service consumptions are not linkable

to each other, i.e., it is not possible for the

provider to correlate any two different service

consumptions to the same consumer.

UNTRACEABLEANONYMOUSSERVICECONSUMPTIONINSaaS

Figure 1: Untraceable anonymous service consumption.

Our proposal consists in including anonymous

payment in the service consumption request

message, in the form of untraceable electronic cash

(e-cash).

A third party is needed to issue the electronic

cash (e-cash), which is acquired by consumers in

exchange for real money (withdraw operation), and

to receive the e-cash used in electronic payments,

which will be exchanged back by the provider for

real money (deposit operation). This third party

organization is called “E-cash Bank” or simply

“Bank”, and is usually an institution with ability to

perform financial transactions electronically, i.e.,

operating in financial market place. Note that the

Bank is a mere electronic payment processing entity

and it does not take any other role in service

consumption itself. Especially, the Bank has no

access to the messages exchanged during service

consumption. The scheme is shown in Figure 1.

Basically, consumer and provider will “open an

account” with the Bank. This means that both

consumer and provider recognize the e-cash

credentials issued by the Bank. Before service

consumption, the consumer must obtain the e-cash

credentials with the Bank; this operation is called e-

cash “withdraw”. In this step, the consumer is

exchanging real money (e.g., pre-payment or credit

operation) (1a) for electronic cash issued by the

Bank (1b). The consumer (“buyer”) embeds the e-

cash credentials in the service request messages (2a).

During service consumption, messages are

exchanged anonymously

. The provider (“seller”),

In order to leverage on the complete potential of the anonymity

framework, message data shall be anonymized before sending it

to the provider, and message should be delivered by the network

through a network-level anonymity tool, such as Tor.

upon reception of the service request (2b), verifies

the payment credential, checks its validity and, if the

credential is correct, stores the e-cash and provides

the service. Finally, the provider will exchange the

e-cash credentials back (3a) for real money with the

Bank (3b). This operation is called e-cash “deposit”.

Note that the system uses a pay-as-you-go (on

demand) pricing and the services are actually paid

for anonymously at each service consumption

instance.

The buyers (i.e., consumers) in e-cash systems

enjoy untraceable anonymity, meaning that the e-

cash credentials reveal no information about the

consumer identity and even the e-cash issuer (Bank)

cannot trace back the consumer’s identity from the

used e-cash. Therefore, the provider must have good

security policies and measures in place because a

malicious consumer carrying valid e-cash will not be

prone to identification in any case.

5 PRIVACY ASSESSMENT

In this Section, we present the privacy assessment

for the proposed SaaS anonymity framework. The

analysis drills down into the influence of each layer

of the framework, and the respective anonymity

technique employed in the protection of consumer’s

information privacy.

5.1 Message Metadata

With e-cash credentials, the provider can

authenticate service requests, but cannot distinguish

which consumer has actually signed the message.

Electronic money has the untraceability propriety.



CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

100

This is true, even for successive messages signed

(paid) by the same consumer. This relates to the ID

privacy dimension present in the AAA credentials;

and the behavior dimension that could be grasped in

the correlation of the MEPs over time.

5.2 Message Data

Content privacy dimension and the identification

information that can be possibly unveiled by also

inspecting the message payload have to be

approached accordingly to the specific

characteristics of each cloud service. This data

anonymity customization need originates from the

fact that each cloud service is provided differently

and computes consumer data distinctively.

5.3 Network-level Communications

For the Network Anonymity layer there are two

items of interests: IP and TCP connections over

time. IP affects ID and location privacies and TCP

connections over time influences the behavior

dimension. However, Tor, as a mix-net scheme, can

anonymize IP source addresses, and the addresses

used are also changing over time. As a consequence,

TCP connections over time become uncorrelated.

6 CONCLUSIONS

In this paper we have presented a privacy enhancing

framework for SaaS service consumption, based on

anonymity techniques. The design uses a multi-layer

approach, allowing the combination of different

anonymity techniques, in a flexible manner. Privacy

assessments have shown that there are different

types of consumer information that can compromise

different privacy dimensions, while our multi-layer

approach can be successful in protecting consumer

privacy through anonymity.

The salient feature of the layered design is the

flexibility to approach each level of interaction

between consumer and provider, and the respective

sensitive information and privacy dimensions, in a

separate way. Privacy protection at each level adds

up to increase consumer’s privacy.

We presented a complete design for an

untraceable anonymous service consumption

scenario, where a Bank emits electronic cash to be

used by the consumer and received by the provider.

ACKNOWLEDGEMENTS

The authors sincerely thank CDT of University of

Brasília and the Swedish Institute of Computer

Science for the support offered.

REFERENCES

Beresford, A., Stajano, F., 2003. Location Privacy in

Pervasive Computing. In IEEE Pervasive Computing

journal, Volume 2 Issue 1.

Camenisch, J., Hohenberger, S., Lysyanskaya, A., 2005.

Compact E-Cash. In Lecture Note on Computer

Science, Eurocrypt 2005, pages 302-321, Springer

Verlag.

Chaum, D., 1981. Untraceable electronic mail, return

addresses, and digital pseudonyms. In

Communications of the ACM, Volume 24, Number 2.

Chaum, D., 1982. Blind signatures for untraceable

payments. In David Chaum, Ronald L. Rivest, and

Alan T. Sherman, editors, Advances in Cryptology —

CRYPTO ’82, pages 199– 203.

Clarke, R., 1997. Introduction to Dataveillance and

Information Privacy, and Definitions of Terms. In

http://www.rogerclarke.com/DV/Intro.html.

Díaz, C., Seys, S., Claessens, J., Preneel, B., 2002.

Towards measuring anonymity. In Proceedings of the

2nd international conference on Privacy enhancing

technologies.

Dingledine, R., Mathewson, N., Syverson, P., 2004. Tor:

The second-generation onion router. In Proceedings

of the 13th USENIX Security Symposium.

Okamoto, T., Ohta, K., 1992. Universal Electronic Cash,

1992. In Advances in Cryptology – Crypto ’91, page

324-325, Springer-Verlag.

Pacheco, V., Puttini, R., 2011. SaaS Anonymity

Framework. Manuscript.

UNTRACEABLEANONYMOUSSERVICECONSUMPTIONINSaaS

101
