INFERRING WEB PAGE RELEVANCE FROM HUMAN-COMPUTER

INTERACTION LOGGING

Vincenzo Deufemia, Massimiliano Giordano, Giuseppe Polese and Genoveffa Tortora

Universit

a di Salerno, Via Ponte don Melillo, Fisciano, SA, Italy

Keywords:

Learning from User Behavior, Implicit Feedback, Mouse Tracking, Search Engines, Display Time, Logging

Information.

Abstract:

Quality of search engine results often do not meet user’s expectations. In this paper we propose to implicitly

infer visitors feedbacks from the actions they perform while reading a web document. In particular, we propose

a new model to interpret mouse cursor actions, such as scrolling, movement, text selection, while reading web

documents, aiming to infer a relevance value indicating how the user found the document useful for his/her

search purposes. We have implemented the proposed model through light-weight components, which can be

easily installed within major web browsers as a plug-in. The components capture mouse cursor actions without

spoiling user browsing activities, which enabled us to easily collect experimental data to validate the proposed

model. The experimental results demonstrate that the proposed model is able to predict user feedbacks with

an acceptable level of accuracy.

1 INTRODUCTION

The goal of Information retrieval (IR) is to ﬁnd rele-

vant documents as response to users queries. In ﬁnite

and controlled information sources, such as document

collections, the vector space model based on the pop-

ular Term Frequency - Inverse Document Frequency

(T f − Id f ) measure is traditionally used to ﬁnd rel-

evant documents (Salton and Buckley, 1988). How-

ever, this approach is impractical in huge and uncon-

trolled environments like the Web, where large quan-

tities of resources constantly compete to draw user

attention. The sheer size of the Web does not al-

low for presenting the entire set of related documents

to the user. In such an environment the quality of

documents plays an important role, and measuring it

merely based on page contents is difﬁcult and may

also be subjective.

One way to derive an objective measure of docu-

ments’ usefulness is to exploit the linked structure of

the Web. PageRank is the most famous method using

link structure analysis (Page et al., 1999). The idea

behind PageRank algorithm is to exploit the macro-

scale link structure among pages in order to capture

the popularity of documents, which can indirectly be

interpreted as an index of their quality. According to

this approach, the popularity of a page is determined

on the basis of the size of a hypothetical user stream

coming to the page. However, link-based algorithms

have currently many disadvantages (Mandl, 2006).

For example, they are vulnerable to spamming, and

links may have several meanings or purposes.

With the advent of Web 2.0, social bookmarking

systems have started showing the potential for im-

proving search capabilities of current search engines.

In these systems, the popularity of a Web page is cal-

culated as the total number of times it has been book-

marked, which is interpreted as the number of users

voting for the page.

There are several differences between “classic”

ranking systems like PageRank, and explicit ones

based on explicit feedbacks (Yanbe et al., 2007).

Explicit ranking systems capture the popularity of

resources among content consumers (page readers),

while PageRank is a result of author-to-author eval-

uation of Web resources. Generally, explicit rank

is more dynamic than PageRank, and social book-

marking systems often ensure shorter time for pages

to reach their popularity peaks (Golder and Huber-

man, 2006). However, despite many advantages of

social bookmarking services, relying on them alone

is currently still not possible due to the insufﬁcient

amount of bookmarked pages available for arbitrary

queries. Furthermore, explicit ranking is subjective,

since users need to explicit vote a web content to

rate it, and not all the web users are keen on voting

653

Deufemia V., Giordano M., Polese G. and Tortora G..

INFERRING WEB PAGE RELEVANCE FROM HUMAN-COMPUTER INTERACTION LOGGING.

DOI: 10.5220/0003938406530662

In Proceedings of the 8th International Conference on Web Information Systems and Technologies (WEBIST-2012), pages 653-662

ISBN: 978-989-8565-08-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

each site they visit. Thus, despite the rapid growth

in the number of bookmarked pages, the combination

of link structure-based and social bookmarking-based

page ranking measures seems to be currently an opti-

mal strategy.

Alternatively, methods that are able to implic-

itly capture user interests are potentially more use-

ful, since there is no noise in the ranking process in-

troduced by subjective evaluations (Agichtein et al.,

2006; Fox et al., 2005). Thus, we have started ex-

ploiting methods for logging user interaction actions

in order to derive an implicit index expressing the web

page usefulness with respect to user interests. In par-

ticular, we propose a new model to interpret mouse

cursor actions, such as scrolling, movement, text se-

lection, while reading web documents, aiming to infer

a relevance value indicating how the user found the

document useful for his/her search purposes (Chen

et al., 2001; Mueller and Lockerd, 2001).

We have embedded the proposed model in a rank-

ing system for the web. In particular, we have im-

plemented the YAR (Yet Another Ranker) system,

which re-ranks the web pages retrieved by a search

engine based on the relevance values computed from

the interaction actions of previous visitors. YAR ha

been implemented by means of light-weight compo-

nents, which can be easily installed within major web

browsers as a plug-in (we used it experimentally with

Google, but any other search engine could be eas-

ily adapted). The implemented components capture

mouse cursor actions without spoiling user browsing

activities, which enabled us to easily collect exper-

imental data to validate the proposed model. The

experimental results demonstrate that the proposed

model is able to predict user feedbacks with an ac-

ceptable level of accuracy.

The paper is organized as follows. Section 2 de-

scribes the metrics for deriving the web page rele-

vance from mouse tracking logging data. An imple-

mentation of the proposed metrics in the context of

ranking systems is presented in Section 3. Section 4

presents an experimental evaluation with analysis of

the results. A comparison with related work is de-

scribed in Section 5. Finally, conclusions and future

work are discussed in Section 6.

2 THE METRICS FOR WEB PAGE

RELEVANCE

In order to compute the web page relevance value we

consider several metrics. The application of all these

metrics will be used to produce a value between 1 and

5, as usually done in social bookmarking systems. In

particular, we have deﬁned the following metrics:

• permanence time,

• reading rate,

• scrolling rate.

The overall rate is obtained through a weighted

sum of the considered metrics. Linear regression has

been used to ﬁnd the weights for metrics that best ex-

plain the observed user feedback.

2.1 Permanence Time

The Permanence Time (PT) is deﬁned as the differ-

ence between the loading and the unloading time of a

web page. Obviously, PT is heavily inﬂuenced by the

way the user reads a text within a document and by the

number of words composing it. Several studies prove

that there are different ways of reading a text, each

corresponding to a different speed, also depending on

reader’s language and age (Hunziker, 2006). Rates

of reading are measured in words per minute (wpm),

and include reading for memorization (less than 100

wpm), reading for learning (100 – 200 wpm), reading

for comprehension (200 – 400 wpm), and skimming

(400 – 700 wpm).

In general, being aware of the reading style seems

to be essential in order to correctly relate the time the

user spends on a page with his/her hypothetical in-

terest. In spite of all those kind of different reading

strategies, the way user reads on the web seems to be

different with respect to the way they read a printed

text. Usually, web users rapidly ﬁnd key elements

of a document, and they usually highlight sections,

paragraphs, and keywords by using the mouse cur-

sor. The web user only reads a small portion of a

web page, usually between the 20% and 28% of it

(Nielsen, 2008).

Furthermore, experimental data show that web

pages containing from 30 to 1250 words are read shal-

lowly, and that the estimated time a user will stay on

the web page, before making a decision about its use-

fulness, is at least 25 seconds plus 4.4 seconds for

each block of 100 words (Nielsen, 2008).

Starting from these results, we deﬁne PT as:

PT =



· (3/Tre f

) + 1 if pT

≤ Tre f

· (2/Tre f

max

) + 4 if pT

> Tre f

(1)

where:

• pT

is the average permanence time and it is de-

ﬁned as pT

= (pw · 0.044) + 25, with pw repre-

senting the number of words composing the page;

• Tre f

max

is the maximum reference time and it is

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

654

deﬁned as Tre f

max

= (pw/150)60. We assume

the reading for learning rate (about 150 wpm in

the average case) as its lower bound;

• Tre f

is the average reference time.

Tre f

is deﬁned to support fast reading strategies,

typical of web users, and when the number of words is

between 30 and 1250 (Nielsen, 2008). Thus, for this

kind of pages the Tre f

is deﬁned as the average per-

manence time. However, for longer documents this

equality might be inaccurate. In these cases we rede-

ﬁne Tre f

as:

Tre f

= pw/v

lett

· 60 (2)

where v

lett

is the reading speed rate corresponding to

the selected reading strategy. As default, we assume

an average rate of v

lett

= 300wpm, which corresponds

to the reading for comprehension strategy.

In conclusion, we associate an average relevance

value of 3 to a document on which the user spends a

time equal to Tre f

. For a shorter permanence time

the relevance value is computed by using the aver-

age time as upper bound. In case of permanence time

greater than the average time, we use Tre f

max

as up-

per bound. In this way, the metric is more sensible to

the different reading strategies.

Notice that the resulting value for PT is in the

range [1,∞]. However if it is greater than 5, we re-

duce it to 5, because we have empirically veriﬁed that

above 5 the user interest does not increase consider-

ably.

2.2 Reading Rate

A common user activity on the web is text ﬁltering.

As shown in many usability studies performed by us-

ing eye tracking, users are often interested in some

portion of the text, and only in some of its contents

(Nielsen, 2006). S/he follows a “standard” reading

schema, called the “F” reading pattern. Thus, by an-

alyzing the mouse activities, we can review the same

reading pattern, and use it to understand how much

the page is useful to the user.

In particular, experimental data show that many

users navigate through the page by pointing with

the mouse cursor near the rows they ﬁnd interesting

(Huang et al., 2011). However, this behavior is not

common to all users. Alternatively, some users might

highlight text either to facilitate reading, to copy it,

or just to print the selected portion. Obviously, these

can all be interpreted as measures of interest. Thus,

we can use such mouse actions to derive a measure,

called Reading Rate (RR), estimating the amount of

text the user reads in the document, which is com-

puted as:

RR = 5 ·



rw + sw



+ 1 (3)

where:

• rw is the number of words followed by the mouse

cursor;

• pw is the total number of words in the document;

• sw is the total number of selected words.

Notice that the number of words followed by the

cursor is added to the number of words selected dur-

ing the page exploration. In fact, often the user moves

the mouse over each selected word to facilitate read-

ing. This can also be taken as a further demonstration

of user interest.

The resulting value for RR is also in the range

[1,∞]. Thus, we normalize it in the range [1,5] for

reasons similar to those used for PT value.

2.3 Scrolling Rate

During a navigation session the web user might not

necessarily read all the contents inside a page. Often,

users scroll the page looking for interesting contents,

or merely to have a complete overview of it.

The main reasons to scroll a page are:

• to navigate from the current section to the next

one;

• to ﬁnd a paragraph, or just some more interesting

keywords;

• to skip the entire content of the page and reach a

link to the next one, like for the classic End User

Licensing Agreements (EULA) pages.

We believe that scrolling should be considered as a

measure of interest for page contents. In other words,

a relevant scrolling activity might witnesses that the

user is interacting with the web page, and that s/he

has not left the browser idle, because s/he is doing

some other activity, leaving the value of the perma-

nence time grow inappropriately. On the other hand, a

highly frequent scrolling activity might convey a low

interest, because the user might be skimming over the

page without ﬁnding contents of interest to him/her.

In these cases, we apply a penalty to the relevance

value. To this end, we need to measure the scrolling

activities during the navigation. We call this measure

Scrolling Rate (SR) and deﬁne it as the following nor-

mal distribution:

SR = 4 ·



exp



−



x − µ





+ 1 (4)

where

INFERRINGWEBPAGERELEVANCEFROMHUMAN-COMPUTERINTERACTIONLOGGING

655

• x = (N

scroll

/PT )·60 is the scrolling frequency ex-

pressed in terms of number of scrolls (N

scroll

) per

minute;

• µ is the mean value (the peak of the curve), which

represents the scrolling frequency in case of high

interest for page contents. We have empirically

determined an optimal value of 25 for this param-

eter;

• σ

is the variance and it represents the range of

scrolling frequencies revealing some interest for

page contents. We have empirically determined

an optimal value of 7.

Thus, the function SR contributes to increase the

relevance value when the scrolling frequency is in the

range 25 ± 7, as also shown in Figure 1. Beyond such

range there is little interest, either because of too fast

or reduced scrolling.

Figure 1: The SR function.

3 AN IMPLEMENTATION OF

THE PROPOSED METRICS

Implicit feedbacks have a wide range of applications.

In this section, we present an implementation of the

proposed metrics in the context of web page ranking.

In particular, we present the YAR system whose ar-

chitecture is depicted in Figure 2. It is based on a

client/server model, where data concerning user inter-

actions are collected on the client side by the Logger,

and evaluated on the server side through the Log Ana-

lyzer. The Logger is responsible for “being aware” of

the user’s behavior while s/he browses web pages, and

for sending information related to the captured events

to the server-side module. The latter is responsible

for analyzing the collected data, applying the metrics,

and deriving relevance values to be successively used

for ranking purposes.

The following subsections provide details on the

modules composing the YAR system.

3.1 The Logging Module

One way to collect data concerning users interac-

tions is to track their eyes’ movements. However,

this would require the use of expensive tools, which

would make it difﬁcult to run large-scale simultane-

ous experiments. Nevertheless, it has been shown

that similar results can also be inferred by tracking

mouse movements. In fact, it has been experimen-

tally proved that in more than 75% of cases the mouse

cursor closely approximates the eye gaze (Chen et al.,

2001; Mueller and Lockerd, 2001). This important

result suggests that mouse tracking might replace eye

tracking, allowing the extraction of many useful infor-

mation about the user interest regarding a web page.

This ﬁnding is also conﬁrmed by a recent study on

the correlation between cursor and gaze position on

search result pages (Huang et al., 2011).

In light of the above arguments, our logging mod-

ule tracks user interaction actions through several de-

vices, but it does not perform eye tracking. In par-

ticular, the logging module tracks the overall and the

effective permanence time over a web page, mouse

cursor movements, page scrolling events, text selec-

tion, and so forth. It is based on the AJAX technology

(Murray, 2006) to capture and log user’s interactions

with a web system through a pluggable mechanism,

which can be installed on any web browser. Thus, it

does not require modiﬁcations to the web sites, or any

other legacy browser extensions. In particular, the ar-

chitecture of the Logger is graphically represented in

Figure 3.

It is structured in the following three main sub-

components:

• Page handler: it handles page loading and unload-

ing events.

• Mouse handler: it handles mouse events.

• Text handler: it handles keyboard related events.

These generic handlers could be overridden with

ad-hoc specializations letting the system ﬁlter differ-

ent kinds of events, so that it can be adapted to many

different application domains.

An important property of the Logger component

is ﬂexibility. The JavaScript code for event captur-

ing may be dynamically conﬁgured in order to record

several kind of events occurring during the user nav-

igation. Each class of events is handled by a speciﬁc

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

656

<<device>>

Client

<<device>>

Server

<<executionEnvironment>>

WebBrowser

<<component>>

Logger

<<component>>

Requester

<<executionEnvironment>>

ApplicationServer

<<component>>

JSON-RPC Server

<<component>>

Rater

<<component>>

Analyzer

<<device>>

DataServer

<<executionEnvironment>>

RDBMS

Figure 2: The YAR system architecture.

handler. Among the parameters that can be conﬁg-

ured for the logger we have:

• list of events to capture;

• sub-set of attributes for each event;

• sections of the web pages (divs or table cells) to

be monitored as event sources;

• time interval between two data transmissions from

the client to the server;

• sensitivity for mouse movements (short move-

ments are not captured).

By acting on these parameters we have the possi-

bility to affect the size of the collected data.

3.2 The Log Analyzer

The Log Analyzer is a server-side module providing

two main functionalities: rating and reporting. The

former is accomplished by the Rater, which rates the

currently opened documents by using data that the

Logger has collected on the server during navigational

sessions. To this end, the metrics adopted for ranking

depend on the application domain. For example, we

can derive metrics for web search applications, met-

rics to evaluate usability of software systems, or to

evaluate the satisfaction of a user while using an au-

tomatic Help Desk system or an E-testing system. The

overriding mechanism used to specialize the Rater is

illustrated in Figure 4.





















!

Figure 3: The logging module.























Figure 4: The rater’s overriding mechanism.

The reporting subsystem ensures the access to the

gathered data by means of domain speciﬁc visual

metaphors. In the web search context, this module

uses a simple graphical pattern to show the rank pro-

duced by the ranker components, and mixes such re-

sults with those provided by the underlying search

engine. All the reporting facilities are accessible

through a web-based application or as a service, as

in the case of information ranking.

3.3 Integration into SERPs

Thanks to the availability of reporting services, we

can ask the system to provide the relevance value for

each link already visited by other users. Thus, apart

from collecting human computer interaction data, and

calculating/updating the implicit rank, we integrate

the rank information within a Search Engine Report

Page (SERP). In particular, we show this in the con-

text of Google search engine, but any other search en-

gine could be used.

The integration with SERP is done by means of

the same technology used to log user interaction data.

We prepared a JavaScript function directly installed

on the user browser in the same way as we integrated

the logging facilities. However, in this case, instead of

logging user interactions, the script scans the SERP

and inquires the implicit rank for each link it con-

tains. Finally, the script modiﬁes the Document Ob-

ject Model (DOM) of the web page in order to show

the rank beside each result. In particular, the rank is

shown by using a simple visual metaphor by depict-

INFERRINGWEBPAGERELEVANCEFROMHUMAN-COMPUTERINTERACTIONLOGGING

657

ing as many Star” symbols as the rank value. Thus,

the system associates from 0 to 5 star symbols to each

link. After each search, YAR shows the new page

instead of the standard SERP page, and all the links

originally found by the search engine are re-ranked

by using the ranking information, if available.

In Figure 5 we can see the Google SERP page

(Figure 5(a)) and the YAR re-ranked page (Figure

5(b)). In particular, the two pages result from the

query: “html5 xhtml2”. Notice that pages that were in

the middle of the original SERP, after YAR re-ranking

are positioned on the top of the list. This means that

they better captured the interest of users who had pre-

viously visited them.

4 EXPERIMENTAL EVALUATION

In this section we validate the proposed implicit feed-

back measure through a user study. The latter has a

twofold goal. On one hand, we need to understand

how the single metrics should be weighted when de-

riving the global implicit feedback measure. On the

other hand, we need to evaluate the effectiveness of

such measure. One way to do this, is to compare the

computed implicit feedbacks with respect to the user

provided ones.

4.1 Evaluation Method

The evaluation was accomplished by two independent

groups of participants. They were prescribed the same

tasks. However, the ﬁrst group (20 participants) ex-

ercised the system in a basic conﬁguration, and the

results where used to derive an optimal parameter

settings for the proposed implicit feedback method.

Based on such settings, the second group (6 partici-

pants) produced results that were used to validate the

effectiveness of the proposed measure.

4.1.1 Participants

We selected twenty-six participants between 22 and

31 years old. Sixteen of them had a bachelor in com-

puter science, four a technical high school degree,

two a gymnasium high school degree, two a master

in linguistics, and two a bachelor in chemistry. Nine

of them were female and seventeen were male. All

the participants had sufﬁcient computer and World

Wide Web experience, and an average of 7.6 years

of searching experience. Each of them underwent a

week time period of search experiments.

4.1.2 User Tasks

In order to evaluate our system, we asked users to

perform web searches and to explicitly rate the use-

fulness of the retrieved web documents. Then, we

needed to compare such rates with those implicitly

derived through the proposed approach. However,

given the magnitude of the web, to have a signiﬁcant

amount of experimental data, we needed to narrow the

scope of user searches in order to guide them towards

a restricted set of web contents. This has been accom-

plished by assigning users speciﬁc webquests (Dodge,

1995). A webquest is a short description of a spe-

ciﬁc topic, on which a user should write an essay by

mainly investigating through web sources. They are

frequently used in e-learning contexts to give learners

a clear purpose and objective when searching through

web sources of knowledge.

Ten webquests in italian language were prepared

for the experiment. They regarded well-known top-

ics such as for example retirement plans, anxiety, and

coffee.

Each participant was requested to select three out

of the ten available webquests, and to solve them. For

each visited page, they were requested to express a

vote representing how they judged the page useful

to solve the speciﬁc webquest. The votes were ex-

pressed in a Likert scale [1, 5] where 1 represented

not useful and 5 useful.

4.1.3 Instruments and Procedure

Each participant had his/her own computer on which

we installed the YAR software. The latter also in-

cluded a module for expressing a vote when leaving a

visited web page.

Other than the twenty-six participants, six com-

puter science students, one undergraduate and ﬁve

graduate, participated in the organization and supervi-

sion of experiments. The undergraduate student pre-

pared all the webquests as part of her bachelor project,

whereas each graduate student was requested to select

four participants, and had the responsibility to con-

duct experiments with them in order to derive an opti-

mal system tuning. After one week of experiments,

they had a meeting with us to analyze and discuss

experimental data, and to reach an agreement on the

proper parameter settings to be used for the exper-

iments with the remaining six subjects. The latter

were selected among computer science students at-

tending a graduate course on web engineering. They

also worked one week, after which they had a ﬁnal

meeting with us to summarize and analyze the exper-

imental results.

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

658

(a) Google rank. (b) YAR rank.

Figure 5: Comparison of web search results without and with relevance values.

4.1.4 System Tuning

The goal of system tuning was to construct a model

that given in input data on implicit user feedbacks

was able to predict the explicit rate that would be

given by the user. To this end, a proper system param-

eter setting was derived by performing a regression

analysis in order to compute optimal weights for the

single metrics: PT, RR, and SR. In particular, we

accomplished regression analysis on the following

ﬁve models:

Model 1: r

= α

+ α

· RR

Model 2: r

= α

+ α

· RR + α

· SR

Model 3: r

= α

+ α

· RR + α

· PT

Model 4: r

= α

+ α

· PT + α

· SR

Model 5: r

= α

+ α

· RR + α

· SR + α

· PT

Starting from the user provided explicit rates r

the goal here was to derive appropriate values for the

constants α

producing an optimal combination of the

metrics RR, S R, and PT to achieve a value close to r

Table 1 presents the results of the regression anal-

ysis based on the experiment accomplished by the ﬁrst

group of twenty participants, which produced 650

data records. The adjusted R

values show the pro-

portion of variance of the dependent variable, namely

the explicit rate of the subjects, with respect to the

independent variables, namely the proposed metrics.

We can observe that by including all the three met-

rics (model 5) we gain the maximum amount of vari-

ability of the dependent variables with respect to the

independent ones. We also observe that the single PT

and SR metrics have more impact on the variance than

RR metrics. This means that the PT and SR are more

strongly related to the explicit rate.

4.1.5 Evaluation Metrics

The quality of the implicit feedback computed by

YAR was evaluated by using the data produced in

the second round of experiments, in which the sec-

ond group of six participants was requested to solve

three webquests on the topics: economy, politics, and

healthcare. Afterwards, we have compared their ex-

plicit rates with respect to the implicit ones by means

of the Root Mean Squared Error (RMSE).

4.2 Results

The experiments performed by the second group pro-

duced a set of 213 data records. Figure 6 shows the

number of web pages visited by each subject to solve

each webquest. Notice that for the same webquest

different subjects visited a highly variable number of

pages. Nevertheless, to this end, we can observe that

some subjects tend to follow their own trend. As an

example, to solve each webquest Subject 1 has visited

a number of pages in a restricted range from 6 to 12,

whereas Subject 3 has visited few pages except for

webquest 1.

Figure 6: Visited web pages per webquest.

Figure 7 shows the distribution of explicit rates

for each subject. This ﬁgure allows us to elicit the

attitude each subject has exhibited while rating web

pages. As an example, Subject 4 has evenly assigned

all the different available rate values, whereas Sub-

ject 5 has shown less variability by assigning all rates

close to 3.

Table 2 shows the RMSE between the implicit

feedback predicted through the proposed model and

the explicit rate provided by the subjects. We can

observe that the combination of all the three metrics

INFERRINGWEBPAGERELEVANCEFROMHUMAN-COMPUTERINTERACTIONLOGGING

659

Table 1: Regression results.

Model adjusted R

F-value p-value α

1 0.375 F(1, 648) = 390.39 <0.001 1.164 0.531 - -

2 0.571 F(2, 647) = 433.15 <0.001 0.649 0.538 0.291 -

3 0.592 F(2, 647) = 472.66 <0.001 0.570 0.291 0.387 -

4 0.693 F(2, 647) = 732.44 <0.001 0.220 0.422 0.349 -

5 0.857 F(3, 649) = 1293.42 <0.001 -0.126 0.372 0.340 0.337

Figure 7: Distribution of rates per subject.

produces the best performances, reducing the error to

the minimum average value of 0.286. Moreover, as it

occurred in the regression analysis, also here the pair-

wise combination SR and PT produces errors that bet-

ter approximate the best RMSE value based on all the

three metrics, whereas the RMSE for model 1 and 3

shows that not using SR metrics yields the worst per-

formances. Similar considerations hold by analyzing

RMSE for single subjects, except for Subject 1 where

the model 2 is worst than model 3.

Table 2: The RMSE values for the analyzed models.

Subjects

Model All 1 2 3 4 5 6

1 0.800 1.109 0.787 0.772 0.762 0.693 1.019

2 0.460 0.719 0.458 0.427 0.447 0.458 0.472

3 0.709 0.688 0.686 0.764 0.771 0.647 0.837

4 0.300 0.410 0.283 0.312 0.490 0.298 0.301

5 0.286 0.283 0.250 0.257 0.339 0.283 0.279

5 RELATED WORK

A well-known strategy to collect data concern-

ing users activities is the think-out-loud method

(Bath, 1967; Best, 1979; Johnston, 1977; Paul and

Rosenkoetter, 1980; McClain, 1983). However, this

method is quite invasive, which can signiﬁcantly in-

ﬂuence user’s behavior. Further, it is difﬁcult to use

it in practice, since it requires considerable efforts in

terms of staff personnel to analyze tape-recorded data.

In the scientiﬁc literature several other approaches

were presented to collect data on user activity (Arroyo

et al., 2006; Atterer et al., 2006; Mueller and Lockerd,

2001), especially in the ﬁeld of web usability studies.

However, in these cases the web-site codes need to be

modiﬁed in order to capture the user interactions, or it

is necessary to change the web browser conﬁguration

by redirecting all the trafﬁc to an ad-hoc proxy sys-

tem. All these solutions lack in scalability and cannot

be used in large scale experiments, conceived to po-

tentially involve any web users.

One of the ﬁrst uses of mouse interaction data is

in the ﬁeld of usability studies. Several works exploit

user interaction data in order to analyze user behavior

and improve usability Cheese (Mueller and Lockerd,

2001), MouseTrack (Arroyo et al., 2006), UsaProxy

(Atterer et al., 2006). They all track user activities by

logging mouse movements, and produce some visual

representation of gathered data highlighting “more in-

teresting” parts of a web page. These data provide

useful insights for web designer about the need to re-

arrange the page layout in order to improve usability.

With the increasing popularity of search engines

several relevance measures have been investigated

(Kelly and Teevan, 2003; Yanbe et al., 2007). In par-

ticular, the increasing number of Social Bookmarking

systems have suggested that their advantages might be

combined with “classic” search tools. A prototype of

a system combining PageRank, social bookmarking

ranking metrics, and general statistics of user “feel-

ings” is described in (Yanbe et al., 2007). In the same

direction, also Google has shown interest for social

bookmarking as witnessed by the launch of services

like “SearchWiki” and “Google Plus”.

However, asking users to explicitly rate web

page contents might somehow disturb their activi-

ties, which can affect the reliability of the rates they

provide. In order to tackle this problem, many ap-

proaches have been proposed to implicitly infer user

rates. For instance, there are approaches on how to in-

terpret click-through data accurately (Joachims et al.,

2005; Jung et al., 2007; Radlinski and Joachims,

2005), or to identify relevant websites using past user

activity (Agichtein and Zheng, 2006; Bilenko and

White, 2008). Behavioral measures that can be used

as evidence of document usefulness include the dis-

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

660

play time on documents, the number of clicks and

scrolling on each content page, the number of vis-

its to each content page, further usage of content

pages, time on search result page before ﬁrst click,

and so forth (Agichtein et al., 2006; Claypool et al.,

2001; Kelly and Belkin, 2004; Konstan et al., 1997;

Xu et al., 2008). Our approach extends these ones

by introducing the reading rate metrics, yielding a

threefold combination of rating metrics, which has

so far proven to sufﬁciently approximate explicit user

ratings. The importance of reading rates is also

witnessed by several studies on the different strate-

gies that humans adopt during the process of reading

(Hunziker, 2006). By exploiting eye-tracking systems

it has been shown that web users adopt peculiar and

original reading strategies (Nielsen, 2006; Nielsen,

2008), which differ from those used for printed text.

6 CONCLUSIONS AND FUTURE

WORK

We have presented a new model to infer user interests

about web page contents from his/her mouse cursor

actions, such as scrolling, movement, text selection,

and the time s/he spends on the page, while reading

web documents. We have embedded the proposed

model in the YAR system, a ranking system for the

web, which re-ranks the web pages retrieved by a

search engine based on the values inferred from the

actions of previous visitors. YAR captures mouse cur-

sor actions without spoiling user browsing activities.

This is an important issue, because often users are not

keen to explicitly rate the usefulness of retrieved web

pages, as requested in social bookmarking systems. In

order to validate the proposed model, we run several

experiments involving a group of twenty-six selected

subjects. The results demonstrate that the proposed

model is able to predict user feedbacks with an ac-

ceptable level of accuracy.

In the future we would like to perform further in-

vestigations on how mouse movements relate to user

interests in the page contents. For instance, we would

like to produce a classiﬁcation of websites based on

typical standard structures (e.g., news sites, blogs,

and so on), so as to differentiate the interpretation of

mouse movements depending on the type of page be-

ing explored. Moreover, we are currently investigat-

ing methods to correlate the implicit feedback to the

semantics of the original search query, so as to reduce

false alarms due to the lexical similarity of words with

completely different meanings. Finally, we are plan-

ning to exploit user actions to select portions of a web

page that could be used as metadata of the pages.

Regarding the experimental evaluation, this is

an ongoing process, and there are many issues that

should still be faced in the future. First of all, although

the results seem to be encouraging, for a complete val-

idation of the proposed model huge experimental data

would be necessary. In particular, the system should

be used on a large scale in order to track a conspic-

uous number of user interaction actions for a larger

set of web pages. Furthermore, the explicit rank is

heavily spoiled by subjectiveness. Thus, the distance

between explicit and implicit ranks should not be the

unique metrics to measure the effectiveness of an au-

tomatic ranking system. For this reason, we are also

investigating alternative test criteria involving domain

experts rather than naive users in the explicit evalua-

tion of web contents.

Finally, we would like to explore the application

of our approach to other application domains, with

particular emphasis on usability studies and mashup

advising.

REFERENCES

Agichtein, E., Brill, E., Dumais, S., and Ragno, R. (2006).

Learning user interaction models for predicting web

search result preferences. In Proceedings of the 29th

International ACM Conference on Research and De-

velopment in Information Retrieval, SIGIR’06, pages

3–10, New York, NY, USA. ACM.

Agichtein, E. and Zheng, Z. (2006). Identifying ”best bet”

web search results by mining past user behavior. In

Proceedings of the 12th ACM Conference on Knowl-

edge Discovery and Data Mining, KDD’06, pages

902–908, New York, NY, USA. ACM.

Arroyo, E., Selker, T., and Wei, W. (2006). Usability

tool for analysis of web designs using mouse tracks.

In Proceedings of Conference on Human Factors in

Computing Systems, CHI’06, pages 484–489, New

York, NY, USA. ACM.

Atterer, R., Wnuk, M., and Schmidt, A. (2006). Know-

ing the user’s every move: user activity tracking for

website usability evaluation and implicit interaction.

In Proceedings of the 15th International Conference

on World Wide Web, WWW’06, pages 203–212, New

York, NY, USA. ACM.

Bath, J. (1967). Answer-changing behaviour on objective

examinations. The Journal of Educational Research,

1(61):105–107.

Best, J. B. (1979). Item difﬁculty and answer changing.

Teaching of Psychology, 6(4):228–240.

Bilenko, M. and White, R. W. (2008). Mining the search

trails of surﬁng crowds: identifying relevant websites

from user activity. In Proceeding of the 17th Inter-

national Conference on World Wide Web, WWW’08,

pages 51–60, New York, NY, USA. ACM.

Chen, M. C., Anderson, J. R., and Sohn, M. H. (2001).

What can a mouse cursor tell us more?: correlation

INFERRINGWEBPAGERELEVANCEFROMHUMAN-COMPUTERINTERACTIONLOGGING

661

of eye/mouse movements on web browsing. In Pro-

ceedings of Conference on Human Factors in Com-

puting Systems, CHI’01, pages 281–282, New York,

NY, USA. ACM.

Claypool, M., Le, P., Wased, M., and Brown, D. (2001). Im-

plicit interest indicators. In Proceedings of the 6th In-

ternational Conference on Intelligent User Interfaces,

IUI’01, pages 33–40, New York, NY, USA. ACM.

Dodge, B. (1995). Webquests: A technique for internet-

based learning. Distance Educator, 1(2):10–13.

Fox, S., Karnawat, K., Mydland, M., Dumais, S., and

White, T. (2005). Evaluating implicit measures to im-

prove web search. ACM Trans. Inf. Syst., 23:147–168.

Golder, S. and Huberman, B. A. (2006). The structure of

collaborative tagging systems. Journal of Information

Science, 32(2):198–208.

Huang, J., White, R. W., and Dumais, S. (2011). No clicks,

no problem: using cursor movements to understand

and improve search. In Proceedings of Conference on

Human Factors in Computing Systems, CHI’11, pages

1225–1234, New York, NY, USA. ACM.

Hunziker, H. W. (2006). Im Auge des Lesers foveale und pe-

riphere Wahrnehmung: vom Buchstabieren zur Lese-

freude (In the eye of the reader: foveal and peripheral

perception - from letter recognition to the joy of read-

ing). Transmedia Zurich.

Joachims, T., Granka, L., Pan, B., Hembrooke, H., and Gay,

G. (2005). Accurately interpreting clickthrough data

as implicit feedback. In Proceedings of the 28th ACM

Conference on Research and Development in Informa-

tion Retrieval, SIGIR’05, pages 154–161, New York,

NY, USA. ACM.

Johnston, J. J. (1977). Exam taking speed and grades.

Teaching of Psychology, 4:148–149.

Jung, S., Herlocker, J. L., and Webster, J. (2007). Click

data as implicit relevance feedback in web search. Inf.

Process. Manage., 43:791–807.

Kelly, D. and Belkin, N. J. (2004). Display time as implicit

feedback: understanding task effects. In Proceed-

ings of the 27th International ACM Conference on Re-

search and Development in Information Retrieval, SI-

GIR’04, pages 377–384, New York, NY, USA. ACM.

Kelly, D. and Teevan, J. (2003). Implicit feedback for infer-

ring user preference: A bibliography. SIGIR Forum.

Konstan, J. A., Miller, B. N., Maltz, D., Herlocker, J. L.,

Gordon, L. R., and Riedl, J. (1997). GroupLens: ap-

plying collaborative ﬁltering to Usenet news. Com-

mun. ACM, 40:77–87.

Mandl, T. (2006). Implementation and evaluation of a

quality-based search engine. In Proceedings of the

Seventeenth Conference on Hypertext and Hyperme-

dia, HYPERTEXT’06, pages 73–84, New York, NY,

USA. ACM.

McClain, L. (1983). Behavior during examinations: A com-

parison of “a”, “c,” and “f” students. Teaching of Psy-

chology, 10(2):69–71.

Mueller, F. and Lockerd, A. (2001). Cheese: tracking

mouse movement activity on websites, a tool for user

modeling. In Proceedings of Conference on Human

Factors in Computing Systems, CHI’01, pages 279–

280, New York, NY, USA. ACM.

Murray, G. (2006). Asynchronous javascript tech-

nology and XML (ajax) with the java platform.

http://java.sun.com/developer/technicalArticles/J2EE/

AJAX/.

Nielsen, J. (2006). F-shaped pattern for reading web con-

tent. http://www.useit.com/alertbox/reading pattern.

html.

Nielsen, J. (2008). How little do users read?

http://www.useit.com/alertbox/percent-text-read.htm

Page, L., Brin, S., Motwani, R., and Winograd, T. (1999).

The pagerank citation ranking: Bringing order to the

web. Technical Report 1999-66, Stanford InfoLab.

Paul, C. A. and Rosenkoetter, J. S. (1980). The relationship

between the time taken to complete an examination

and the test score received. Teaching of Psychology,

7:108–109.

Radlinski, F. and Joachims, T. (2005). Query chains: learn-

ing to rank from implicit feedback. In Proceedings

of ACM Conference on Knowledge Discovery in Data

Mining, KDD’05, pages 239–248, New York, NY,

USA. ACM.

Salton, G. and Buckley, C. (1988). Term-weighting ap-

proaches in automatic text retrieval. In Information

Processing and Management, pages 513–523.

Xu, S., Zhu, Y., Jiang, H., and Lau, F. C. M. (2008).

A user-oriented webpage ranking algorithm based on

user attention time. In Proceedings of the 23rd Na-

tional Conference on Artiﬁcial intelligence - Volume

2, AAAI’08, pages 1255–1260. AAAI Press.

Yanbe, Y., Jatowt, A., Nakamura, S., and Tanaka, K. (2007).

Can social bookmarking enhance search in the web?

In Proceedings of the 7th ACM/IEEE Joint Conference

on Digital Libraries, JCDL’07, pages 107–116, New

York, NY, USA. ACM.

WEBIST2012-8thInternationalConferenceonWebInformationSystemsandTechnologies

662
