MOBILE APPLICATION FOR TEXT RECOGNITION (OCR)

Ondrej Krejcar

Department of Information Technologies, Faculty of Informatics and Management, University of Hradec Kralove,

Rokitanskeho 62, Hradec Kralove, 500 03, Czech Republic

Keywords: OCR, MDA, Built-in Camera, Image Processing, Virtual Keyboard.

Abstract: The aim of this project is to develop a simple application for capturing digital photography and its

subsequent processing of OCR technologies. The application operates as an alternative for manual rewriting

of parts of text from printed data using the keyboard on the screen of the device. It is mainly targeted at

short text sections, such as hypertext references and addresses which are hard to be copied and at more

excessive texts which would take long to copy. The emphasis is laid on the simple, fast and intuitive

manipulation. The end platform is represented by PDA device, more precisely MDA which is based on

Windows Mobile operating system.

1 INTRODUCTION

The Smart Phones, such as cell phones and PDA,

especially MDA are the phenomenon nowadays

(Mikulecky, 2009). The number of cell phone users

over 16 years old in the Czech Republic for the year

2009 climbed up to 91%. For the population in the

age group from 16 to 54 years the number is equal to

98%. A great boom in the field of cell phones and

their performance was caused by using the operating

system, such as Symbian, Android or Windows

Mobile. Many of these devices use big colourful

displays with touch screen and with a connection to

32bit processor on which the OS runs and therefore

may be considered a PDA. Moreover, the GSM

module is usually integrated within the standard

PDA together with WiFi module (Brida et al., 2010).

The result is the incorporation of cell phones and

PDA. The name communicator or MDA is

sometimes used for these devices. The usage of

efficient standardized 32bit processors which

support OS makes it possible to develop for these

platforms even complicated applications for

computation.

The primary input system of these devices is the

keyboard in a classic “physical” design or in the

form of virtual keyboard on a display in the casesi of

touch screen, also called the on-screen keyboard.

These types of keyboards provide a comfortable

method of information inscription. Nevertheless, the

typing is approx. 4 times slower than in the case of

computer keyboards. However, this typing speed

may be insufficient if using the PDA as a tool for

fast information recording (e.g. business card

copying or copying parts of text). Most commonly

integrated CCD chip enables the photographing or

recording of a video-sequence. Therefore, it is a

convenient and instant way of capturing information.

Moreover, if this information is time-limited (e.g. it

must return within certain time limit or it is only

displayed for short time period) then it is the only

method.

Nevertheless, sometimes there is a need to

further process this captured text (Liou and Cheng,

2007). The text retyping from these images is

lengthy. Furthermore, if it is necessary to retype

using the PDA it should be accounted for switching

often between an application with displayed image

and the text editor. Every such switching “produce”

time delay which resulted in money losses (Lefley et

al., 2004).

In these cases the usage of OCR technology is

the best solution. The first mobile application OCR

was released to the market already in 2002 (Tariq,

Nauman and Naru, 2010). Certain factors complicate

the usage of OCR in PDA which mostly originated

from the low quality of copies acquired by CCM.

Finally, it is necessary to mention that the common

source for OCR application is a scanner.

A PDA which is supplied by OCR has many

options in a way of utilization. If the user notices an

URL address in some printed document, he can look

at it by taking a picture which consequently opens

262

Krejcar O..

MOBILE APPLICATION FOR TEXT RECOGNITION (OCR).

DOI: 10.5220/0003947002620265

In Proceedings of the 2nd International Conference on Pervasive Embedded Computing and Communication Systems (PECCS-2012), pages 262-265

ISBN: 978-989-8565-00-6

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

the link in a browser. After this picture the business

card with user’s data is saved into contacts, etc.

2 PROBLEM DEFINITION

The accuracy of OCR depends mainly on the quality

of recognizable under layer. The most common

usage of OCR on scanned documents achieves quite

satisfactory results. Using of OCR in PDA with

CCM as a data source recognizer carries number of

problems (Hymes and Lewin, 2008), especially:

• Relatively low computational performance

• Low quality of images for OCR

• Tilt (perspective deformation), skew and

rotation

• Incoherent lighting and shadows

Mainly due to these complications is OCR in PDA

limited to just small parts of text. Therefore, the

insufficient quality of acquired images is

compensated by the size proportion of symbols in

the overall resolution. The existing applications may

be good examples, because they are usually

specialized on business card scanning.

2.1 Existing Applications

2.1.1 Nokia Multiscanner

Nokia Multiscanner is an application designed for

cell phones with Symbian system and spread as a

freeware. The application supports picture taking

and consequently sending it through MMS,

Bluetooth or via infrared (Bodnarova et al., 2010). It

is possible to transfer the image into a text and save

it and at the same time the selection of certain area

can be made by dragging. Another possibility is to

send the image for business card recognition. This

option automatically recognizes contact details on

the business card and fills in the details for adding a

new contact. The OCR engine supports post-

processing on the basis of language dictionaries,

including the Czech language.

2.1.2 CameraDictionary OCR for Moto

It is an application for cell phones with Android,

Symbian and Windows Mobile systems. It operates

on the basis of recorded text recognition and its

immediate translation to another language. Even

though, this recorded language is available in

Chinese or English, the translation is extended by

couple of other languages. Furthermore, it enables

the text recording with consequent signing of the

translated text or so called “Video” regime during

which the cursor appears on the screen. The text

below the cursor is immediately translated.

However, the main disadvantages are the price and

the necessity of internet connection when used.

2.1.3 CamCard - Business Card Reader

CamCard is an application specialized on reading

business cards. It is targeted at cell phones which

run on OS Android, iOS, or Windows Mobile and

BlackBerry phones. The main disadvantage is the

narrow specialization on business cards and its price.

2.1.4 Babel Reader-LE

Babel Reader-LE is a particular version of Babel

Reader for Windows Mobile distributed as a

freeware. It enables capturing of an image and

subsequent storing of this image in a form of text.

Babel Reader-LE is a very simple application.

Moreover, it is possible to adjust the captured image

before the actual recognition e.g. by background

noise removal.

2.2 Conclusion

Nokia Multiscanner is the closest application to the

one being developed. However, it is designed only

for OS Symbian. CameraDictionary OCR and

CamCard are commercial applications which are

very specialized and not free. Finally, the last

mentioned application called Babel Reader was only

invented for text recognition. The selection of these

applications with OCR for cell phones is

significantly limited and the broader application

with OCR which would work as an alternative for a

virtual keyboard is still missing. The newly

developed application which is described in this

article is supposed to fill in these blanks.

2.3 Selection of OCR Engine

Due to the extent of this application, it is planned to

use the existing OCR engine. Following types of

engines were chosen as the most suitable:

• Tesseract OCR – OCR Engine developed by

HP Company in since 1985 until 1995.

Nowadays, it is being improved by Google. It

is offered in C/C++ language.

• Ocrad – another open-source OCR engine.

One of his main advantages is mainly an

automatic transformation of an input image. It

does not accomplish post-processing on the

basis of language dictionaries. It is written in

MOBILE APPLICATION FOR TEXT RECOGNITION (OCR)

263

C/C++ language.

• Puma.NET – an engine for implementation in

C# projects with .NET framework.

• ABBYY Mobile OCR Engine – a commercial

engine used here just for comparison of results.

The Greek letter ω is going to represent the number

of symbols in a reference text and ω

err

is the number

of errors (substituted, missing symbols or additional

symbols). Then the accuracy of match γ

acc

is defined

as:





−





100







In order to identify the accuracy of recognition,

the reference text [Fig. 1] was us\ ed.

Figure 1: Reference image.

Furthermore, this sample was photographed by

Canon PowerShot S3 IS and MDA HTC Touch 2.

Consequently, this sample was transferred back to

the text form using the above mentioned OCR and

compared to the reference text. The accuracy of the

match is expressed in percentages in [Tab. 1].

Table 1: Comparison of OCR engine accuracy.

OCR Original Canon HTC

Tesseract 89,78 % 94,72 % 85,25 %

Ocrad 93,30 % 92,71 % 74,36 %

Puma.NET 92,05 % 90,41 % 25,55 %

ABBYY 95,96 % 94,41 % 87,77 %

The comparison shows that the most exact engine is

ABBYY Mobile OCR Engine. At the same time it

may be noticed that the decreasing quality of sample

results in a gradual increase in number of errors. The

most significant is the rapid increase of errors when

using the Puma.NET engine. In this case, the

application was able to correctly recognize

approximately one quarter of the text from an image

taken by HTC Touch 2. On the other hand, the least

sensitive engine considering the quality is Tesseract

OCR. Even though, the assumptions were different,

Ocrad was proven to be very precise.

3 IMPLEMENTATION

The programming language C# with a connection to

the developing environment Microsoft Visual Studio

2008 was designed for the development of the

described application. Microsoft Windows Mobile

5.0 runs as the end platform. Therefore, the

application should function well on a PDA with this

OS or a higher type of OS (Zelenka, 2009).

3.1 Ouciary Application

The application is practically created in form of a

guide. After the initiation user is able to turn on the

camera and capture the recognized image or simply

choose from a file. This is displayed on the

following images of the application [Fig. 2].

Figure 2: Application after the initiation and text

capturing.

Consequently, the image is modified. According to

the settings, the normalization, automatic rotation

and saturation removal take place.

Furthermore, there is the area selection screen

for recognition. Here it is possible to rotate the

image manually and choose an area for recognition.

Character recognition (described above) is very

helpful during the text selection if this function is

allowed. Moreover, this screen might be absolutely

left out (again according to the settings). The

selection happens by dragging (“rectangle

drawing”). If it is necessary to cancel the whole

selection it is enough to press anywhere on the

image. If no area is chosen, the application

PECCS 2012 - International Conference on Pervasive and Embedded Computing and Communication Systems

264

automatically calculates with the whole image.

After the selection of the area it is possible to

establish individual recognition process. The

progress of recognition is shown here. After the

termination of recognition process the application

automatically moves on to the form for storage.

The resulting text can be seen here in a textbox

and at the same time may be saved into a file or

Windows mailbox.

As it was already mentioned, there is a space

here for adding the functionality in a form of

automatic events in relation to recognized text,

eventually to a “templates” usage for contact

creation according to a business card etc.

The application was tested continuously. The

comparison of Tesseract with other OCR engines

can be found in the table [Table 1].

4 CONCLUSIONS

The output of this work is OCR for devices with

Windows Mobile system. OCR on this platform is

capable of speeding up the work when there is no

requirement for manual transfer of text from an

image. Its usage is mainly connected to integrated

CCM for faster business card capturing or other

short texts.

This solution may significantly speed up the

work after the completion with automatic actions on

the basis of recognized text. An example might be

URL address capturing and consequent its display in

the browser which is much faster than rewriting the

address manually (especially in case of long and

complicated addresses) (Tucnik, 2010). However, it

might be used in the case of business cards and

practically every other printed material which need

to be rewritten. The mobile devices are always

nearby and therefore this method brings instant

capturing of printed texts.

ACKNOWLEDGEMENTS

This work was supported by „SMEW – Smart

Environments at Workplaces“, Grant Agency of the

Czech Republic, GACR P403/10/1310. We also

acknowledge support from student Ales Kurecka in

development of testing application and in several

technical problems they grown during development

phase.

REFERENCES

Kobryn, C., 2000, Modeling components and frameworks

with UML, In COMMUNICATIONS OF THE ACM,

Volume: 43 Issue: 10 Pages: 31-38 DOI: 10.1145/352

183.352199

Bodnarova, A., Fidler, T., Gavalec, M., 2010. Flow

control in data communication networks using max-

plus approach, In 28th International Conference on

Mathematical Methods in Economics, pp. 61-66.

Brida, P., Machaj, J., Benikovsky J., Duha, J., 2010. An

Experimental Evaluation of AGA Algorithm for RSS

Positioning in GSM Networks, In Elektronika ir

Elektrotechnika, No. 8(104), pp. 113-118.

Hymes, K., Lewin, J., 2008. OCR for Mobile Phones.

Stanford University

Labza, Z., Penhaker, M., Augustynek, M., Korpas, D.,

2010. Verification of Set Up Dual-Chamber

Pacemaker Electrical Parameters. In 2nd International

Conference on Telecom Technology and Applications,

March 19-21, 2010, Bali Island, Indonesia, Volume 2,

NJ. IEEE Conference Publishing Services, p. 168–

172.

Lefley, F., Wharton, F., Hajek, L., Hynek, J., Janecek, V.,

2004. Manufacturing investments in the Czech

Republic: An international comparison, In

International Journal of Production Economics,

Volume: 88 Issue: 1 Pages: 1-14 DOI: 10.1016/S0925.

5273(03)00129-4

Liou, CY., Cheng, WC., 2007. Manifold construction by

local neighborhood preservation, In Springer LNCS,

Volume 4985, pp. 683-692.

Mikulecky P., 2009. Remarks on Ubiquitous Intelligent

Supportive Spaces, In 15th American Conference on

Applied Mathematics/International Conference on

Computational and Information Science, Univ

Houston, Houston, TX, pp. 523-528.

Popek, G., Katarzyniak R., 2008. Measuring similarity of

observations made by artificial cognitive agents, In

LNAI, Vol. 4953, pp. 693-702.

Tariq, J. Nauman, U. Naru, M.U., 2010. α-Soft: An

English Language OCR. In Second International

Conference on Computer Engineering and

Applications (ICCEA 2010), IEEE Xplore, DOI 10.11

09/ICCEA.2010.112

Tucnik P.,2010. Optimization of Automated Trading

System's Interaction with Market Environment, In 9th

International Conference on Business Informatics

Research, Univ. Rostock, Rostock, Germany, LNBI,

Vol. 64, pp. 55-61.

Zelenka, J., 2009. Information and Communication

technologies in tourism – influence, dynamics, trends,

In E & M EKONOMIE A MANAGEMENT, Vol. 12,

Issue 1, pp. 123-132

MOBILE APPLICATION FOR TEXT RECOGNITION (OCR)

265
