USING CLOUDS FOR SCIENCE, IS IT JUST KICKING THE CAN

DOWN THE ROAD?

Ewa Deelman

, Gideon Juve

and G. Bruce Berriman

Information Sciences Institute, University of Southern California, Marina del Rey, CA, U.S.A.

Infrared Processing and Analysis Center, California Institute of Technology, Pasadena, CA, U.S.A.

Keywords: Scientific Workflows, Grids and Clouds, Cloud Configuration, Application Management.

Abstract: In this paper we describe issues related to the execution of scientific workflows on clouds, giving particular

emphasis to the challenges faced by scientists when using grids and clouds for workflows. We also mention

some existing solutions and identify areas requiring additional work.

1 INTRODUCTION

Over the past decade grid computing has been put

forward as a platform for conducting science. We

have seen both tightly and loosely coupled parallel

applications making use of national and international

infrastructures such as the Open Science Grid (OSG)

(www.opensciencegrid.org), TeraGrid (http://www.

teragrid.org/), EGI (Kranzlmüller et al., 2010), and

others. These applications have been developed for

domains such as astronomy (Deelman et al., 2008),

bioinformatics (Stevens et al., 2003), earthquake

science (Callaghan et al., 2008), physics (Brown et

al., 2006), and others.

The broad spectrum of distributed computing

provides unique opportunities for large-scale,

complex scientific applications in terms of resource

selection, performance optimization, reliability, etc.

However, many issues of usability, reliability,

performance, and efficient computation remain

challenges in the area of grid computing. Over time

the architecture of the underlying clusters used for

scientific computation has been changing, from

commodity-type architectures connected by high-

performance networks to more complex

architectures and deployments such as those of the

Cray XT5 (Bland et al., 2009) or IBM Blue Gene

(Gara et al., 2005). As the computing architectures

have changed, so has the software used to access

these machines across the wide area networks. For

example, the Globus Toolkit (Foster, 2006) has

undergone many revisions and architectural changes

over the past decade.

Although the various hardware and software

systems have been changing, users have been

dealing with the same issues when executing

applications on these distributed systems. One of

these issues is usability. Much of the software that is

deployed today is very complex and often geared

towards high-end users that have already invested a

large amount of time and effort to learn the ins-and-

outs of the cyberinfrastructure. An average scientist

who is ready to scale up his or her computations to

the large-scale infrastructure is faced with learning

new software components that will move the data to

the computations, schedule the jobs, and bring the

results back. Although these functions seem

relatively straight forward, they involve relying on a

stack of software that includes services (e.g. Condor

(Litzkow et al., 1988) /GRAM (Czajkowski et al.,

1998) /PBS (Bayucan et al., 1999) /local OS) for

scheduling jobs and a data transfer service (e.g.

GridFTP (Allcock et al., 2001)) that is interacting

with a parallel file system (e.g. Lustre (Sun

Microsystems), PVFS, etc.) deployed on the

resource. The software stack can be unreliable and

prone to user, system, and software errors. If an

error occurs in that software stack, then it is very

hard for the user to discover the source of the

problem. Currently there are no debugging tools

available to enable the tracing of the problem.

Tuning the system for performance is an additional

concern. Each of the system components has their

own controls, and exposes only some of them to the

users. As a result, obtaining performance from an

application can be difficult.

127

Deelman E., Juve G. and Bruce Berriman G..

USING CLOUDS FOR SCIENCE, IS IT JUST KICKING THE CAN DOWN THE ROAD?.

DOI: 10.5220/0003958901270134

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CLOSER-2012), pages 127-134

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

In addition to the large-scale cyberinfrastructure,

applications can target campus clusters, or utility

computing platforms such as commercial (Amazon

Elastic Compute Cloud); (Google App Engine) and

academic clouds (Nimbus Science Cloud);

(FutureGrid). However, these opportunities also

bring with them their own set of challenges. It is

hard to decide which resources to use and how long

they will be needed. It is hard to determine what the

cost/benefit trade-offs are when running in a

particular environment. It is also difficult to achieve

good performance and reliability for an application

on a given system.

In the paper, we describe an approach to

managing scientific applications, in particular

scientific workflows, on cloud resources. We use

this example as an illustration of the challenges

faced by such applications on clouds, and postulate

that although cloud computing is, in some ways, an

improvement in distributed computing capabilities,

many issues still need to be addressed.

2 APPLICATION CHALLENGES

Scientific workflows are being used today in a

number of disciplines. They stitch together

computational tasks so that they can be executed

automatically and reliably on behalf of the

researcher. For example, in astronomy, researchers

use workflows to generate science-grade mosaics of

the sky (Berriman et al., 2004); (http://montage.ipac.

caltech.edu). These workflows are composed of a

number of image processing applications that

discover the geometry of the input images on the

sky, calculate the geometry of the output mosaic on

the sky, re-project the flux in the input images to

conform to the geometry of the output mosaic,

model the background radiation in the input images

to achieve common flux scales and background

levels across the mosaic, and rectify the background

that makes all constituent images conform to a

common background level. Finally these normalized

images are added together to form the final mosaic.

The search for exoplanets is another example.

The NASA Kepler mission (http://kepler.nasa.gov/)

uses high-precision photometry to search for

transiting exoplanets around main sequence stars. In

May 2009, it began a photometric transit survey of

170,000 stars that has a nominal mission lifetime of

3.5 years. By the end of 2010, the Kepler mission

had released light curves of 210,664 stars; these light

curves contain measurements made over 229 days,

with between 500 to 50,000 epochs per light curve.

Analysing these light curves to identify periodic

signals, such as those that arise from transiting

planets and from stellar variability, requires

calculations of periodograms that reveal periodicities

in time-series data and estimates of their

significance. Because periodograms require large

amounts of computation to produce, workflows are

being used to coordinate periodogram generation

across distributed computing infrastructures.

Another example is from the earthquake science

domain, where researchers use workflows to

generate earthquake hazard maps of the Southern

California region (W. G. et al., 2006). These maps

show the maximum seismic shaking that can be

expected to happen in a given region over a period

of time (typically 50 years). Each point is obtained

from a single hazard curve and each curve is

generated by a workflow containing ~800,000 to

~1,000,000 computational tasks (Callaghan et al.,

2008). This application requires large-scale

computing capabilities such as those provided by the

NSF TeraGrid (http://www.teragrid.org/).

In order to support such workflows, software

systems need to 1) adapt the workflows to the

execution environment (which, by necessity, is often

heterogeneous and distributed), 2) optimize

workflows for performance to provide a reasonable

time to solution, 3) provide reliability so that

scientists do not have to manage the potentially large

numbers of failures that may occur, and 4) manage

data so that it can be easily found and accessed at the

end of the execution.

2.1 Cloud Issues

Having a number of capabilities, clouds can provide

a variety of different solutions for applications. The

latter have a choice of either adapt themselves to the

new computational models provided by the cloud

(such as MapReduce (Dean and Ghemawat, 2008))

or adapt the cloud to look like a computational

environment that the applications have used so far—

a compute cluster. Although new applications,

especially those in bioinformatics, are willing to

adopt new programming models, other applications,

which have been using long time-validated and

community accepted codes, are not willing to re-

write their applications.

Virtualization in general opens up a greater

number of resources to legacy applications. These

applications are often very brittle and require a very

specific software environment to execute

successfully. Today, scientists struggle to make the

codes that they rely on for weather prediction, ocean

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

128

modelling, and many other computations work on

different execution sites. No one wants to touch the

codes that have been designed and validated many

years ago in fear of breaking their scientific quality.

Clouds and their use of virtualization

technologies may make these legacy codes much

easier to run. With virtualization the environment

can be customized with a given OS, libraries,

software packages, etc. The needed directory

structure can be created to anchor the application in

its preferred location without interfering with other

users of the system. The downside is obviously that

the environment needs to be created and this may

require more knowledge and effort on the part of the

scientist than they are willing or able to spend.

For cluster-friendly applications, clouds can be

configured (with additional work and tools) to look

like a remote cluster, presenting interfaces for

remote job submission and data transfer. As such,

scientists can use existing grid software and tools to

get their work done.

Another interesting aspect of the cloud is that, by

default, it includes resource provisioning as part of

the usage mode. Unlike the grid, where jobs are

often executed on a best-effort basis, when running

on the cloud, a user requests a certain amount of

resources and has them dedicated for a given

duration of time. Resource provisioning is

particularly useful for workflow-based applications,

where overheads of scheduling individual, inter-

dependent tasks in isolation (as it is done by grid

clusters) can be very costly. For example, if there are

two dependent jobs in the workflow, the second job

will not be released to a local resource manager on

the cluster until the first job successfully completes.

Thus the second job will incur additional queuing

delays. In the provisioned case, as soon as the first

job finishes, the second job is released to the local

resource manager and since the resource is

dedicated, it can be scheduled right away. Thus the

overall workflow can be executed much more

efficiently.

3 MANAGING WORK ON

CLOUDS

3.1 Application Management

One approach to managing workflow-based

applications in grid or cloud environments is to use

the Pegasus Workflow Management System

(Deelman et al., 2004). Pegasus runs scientific

workflows on desktops, private clusters, campus

clusters, the Open Science Grid (www.openscience

grid.org), the TeraGrid (http://www.teragrid.org/),

and academic and commercial clouds (Amazon

Elastic Compute Cloud); (Google App Engine);

(Nimbus Science Cloud). Pegasus can be used to run

workflows ranging from just a few computational

tasks to a million tasks. When errors occur, Pegasus

tries to recover when possible by retrying tasks, by

retrying the entire workflow, by providing

workflow-level check-pointing, by re-mapping

portions of the workflow, by trying alternative data

sources for staging data, and, when all else fails, by

providing a rescue workflow containing a

description of only the work that remains to be done

so that the user can resubmit it later when the

problem is resolved (Deelman et al., 2006). Pegasus

cleans up storage as the workflow is executed so that

data-intensive workflows have enough space to

execute on storage-constrained resources

(Ramakrishnan et al., 2007); (Singh et al., 2007).

Pegasus keeps track of what has been done

(provenance) including the locations of data used

and produced, and which software was used with

which parameters (Miles et al., 2007); (Miles et al.,

2008); (Groth et al., 2009).

Pegasus assumes that the workflow management

system and the workflow description live on a

submit host, which is under the user’s control.

Pegasus launches jobs from the submit host to the

execution sites (either local or remote). The notion

of a submit host and execution environment lends

itself well to the Infrastructure as a Service (IaaS)

model of cloud computing (Deelman, 2009) .

Although Pegasus controls workflow execution

through both static workflow restructuring and

dynamic tuning of the job execution, it does not

control the resources where the jobs are executing.

However, managing resources is important in grids

when trying to optimize workflow performance and

is critical in clouds where the resources are not

necessarily preconfigured for the workflow. As a

result, we advocate the approach of building virtual

clusters on the cloud and configuring them in a way

similar to the clusters encountered by grid

applications.

3.2 Building Virtual Clusters

Deploying applications in the cloud is not a trivial

task. It is usually not sufficient to simply develop a

virtual machine (VM) image that runs the

appropriate services when the virtual machine starts

up, and then just deploy the image on several VMs

USINGCLOUDSFORSCIENCE,ISITJUSTKICKINGTHECANDOWNTHEROAD?

129

in the cloud. Often, the configuration of distributed

services requires information about the nodes in the

deployment that is not available until after nodes are

provisioned (such as IP addresses, host names, etc.)

as well as parameters specified by the user. In

addition, nodes often form a complex hierarchy of

interdependent services that must be configured in

the correct order. Although users can manually

configure such complex deployments, doing so is

time consuming and error prone, especially for

deployments with a large number of nodes. Instead,

we advocate an approach where the user is able to

specify the layout of their application declaratively,

and use a service to automatically provision,

configure, and monitor the application deployment.

Figure 1: Wrangler architecture.

The service should allow for the dynamic

configuration of the deployment, so that a variety of

services can be deployed based on the needs of the

user. It should also be resilient to failures that occur

during the provisioning process and allow for the

dynamic addition and removal of nodes.

The Wrangler system (Juve and Deelman, 2011);

(Juve and Deelman, 2011) allows users to send a

simple XML description of the desired deployment

to a web service that manages the provisioning of

virtual machines and the installation and

configuration of software and services. It is capable

of interfacing with many different resource

providers in order to deploy applications across

clouds, supports plugins that enable users to define

custom behaviors for their application, and allows

dependencies to be specified between nodes.

Complex deployments can be created by composing

several plugins that set up services, install and

configure application software, download data, and

monitor services on several interdependent nodes.

The components of the system are shown in

Figure 1. They include: clients, a coordinator, and

agents.

• Clients run on each user’s machine and send

requests to the coordinator to launch, query,

and terminate, deployments. Clients have

the option of using a command-line tool, a

Python API, or XML-RPC to interact with

the coordinator.

• The coordinator is a web service that

manages application deployments. It accepts

requests from clients, provisions nodes from

cloud providers, collects information about

the state of a deployment, and acts as an

information broker to aid application

configuration. The coordinator stores

information about its deployments in an

SQLite database.

• Agents run on each of the provisioned nodes

to manage their configuration and monitor

their health. The agent is responsible for

collecting information about the node (such

as its IP addresses and hostnames), reporting

the state of the node to the coordinator,

configuring the node with the software and

services specified by the user, and

monitoring the node for failures.

• Plugins are user-defined scripts that

implement the behavior of a node. They are

invoked by the agent to configure and

monitor a node. Each node in a deployment

can be configured with multiple plugins.

Users specify their deployment using a simple

XML format. Each XML request document

describes a deployment consisting of several nodes,

which correspond to virtual machines. Each node

has a provider that specifies the cloud resource

provider to use for the node, and defines the

characteristics of the virtual machine to be

provisioned — including the VM image to use and

the hardware resource type — as well as

authentication credentials required by the provider.

Each node has one or more plugins, which define the

behaviors, services, and functionality that should be

implemented by the node. Plugins can have multiple

parameters, which enable the user to configure the

plugin, and are passed to the script when it is

executed on the node. Nodes may be members of a

named group, and each node may depend on zero or

more other nodes or groups.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

130

3.3

Observation of Cloud Failures

We can use Wrangler to build virtual clusters across

heterogeneous clouds. In the example below we ran

the test workflow 3 times provisioning 6 nodes (or

48 cores on each resource): once on FutureGrid

(Sierra host), an academic cloud deployment in the

US, once on Magellan, which was an experimental

cloud deployment supported by the US Department

of Energy, and once on both Sierra and Magellan at

the same time using 6 nodes (48 cores) each (for a

total of 96 cores). Figure 2 illustrates the

deployment, which consists of a Master Node

(submit host) and a virtual cluster running Condor

provisioned by Wrangler.

Figure 2: Virtual cluster using local resources, and cloud

resources from both Sierra and Magellan, that was used to

execute the periodograms workflows.

After some failures we were able to execute 3

complete runs of the periodogram workflow, which

read a total of 5.4 GB of input data, produced 30 GB

of output data, and consumed 713 hours of CPU

time, all within the course of a few hours.

Although Wrangler was able to successfully

provision resources and execute the application, we

found that failures were a major problem. We

encountered several different types of failures while

running this application. Table 1 shows a breakdown

of the number of requests made and the number and

type of failures for both Sierra and Magellan. The

failures we encountered include:

• Failed to start: The request was accepted, but

the VM state went from 'pending' to

'terminated' without reaching 'running'.

• No route to host: The VM is in the 'running'

state and reports to the Coordinator, but does

not respond to network connections, or it

stops responding to network connections after

some time.

• Invalid IP: The provider’s information

service reported a public IP of '0.0.0.0' for the

VM.

• No public IP: VM was assigned two private

IP addresses instead of one public and one

private.

• Request timed out: Resource provider’s web

service hanged and the connection timed out.

These failures were automatically corrected

by retrying the request.

• Insufficient resources: The resource provider

was not able to satisfy the request due to the

lack of available resources.

The failure rate we observed in running this

application was significant. Five out of 20 requests

to Sierra failed, which translates to a failure rate of

25%. Magellan was even worse with 12 out of 28, or

42%, of requests failing. The high failure rate on

Magellan was primarily due to a network outage that

caused several VMs to fail at the same time, and

several failures were caused by a lack of resources,

which is not a failure in the strictest sense. The

effect of each of these failures is a request that did

not result in a usable VM. Although these failures

may, in some cases, be prevented by changes to the

cloud management system, the fact is that such

failures will occasionally occur. Provisioning

systems like Wrangler should be prepared to detect

and manage such failures, otherwise it will be

difficult for an application to achieve meaningful

results.

We found that using Wrangler greatly simplified

the process of provisioning and configuring cloud

resources to execute this application. We were able

to provision resources across two different clouds,

quickly deploy a resource management system, and

perform a non-trivial amount of computation in a

short amount of time. However, we determined that

more work is needed to automatically detect and

recover from failures.

Table 1: Number of requests and number and type of

failures for the periodograms application on Sierra and

Magellan.

FutureGrid/Sierra

NERSC/

Magellan

Requests

20 28

Failed to start

2 0

No route to host

0 5

Invalid IP

1 0

No public IP

1 0

Request timed out

1 1

Insufficient

resources

0 6

Total Failures 5 12

USINGCLOUDSFORSCIENCE,ISITJUSTKICKINGTHECANDOWNTHEROAD?

131

4 RELATED WORK

There has been a considerable amount of work in the

area of scientific workflows (Deelman et al., 2009).

Here we just present related work in the area of

virtual clusters.

Constructing clusters on top of virtual machines

has been explored by several previous research

efforts. These include VMPlants (Krsul et al., 2004),

StarCluster (http://web.mit.edu/stardev/cluster/), and

others (Murphy et al., 2009); (Vöckler et al., 2011).

These systems typically assume a fixed architecture

that consists of a head node and N worker nodes.

They also typically support only a single type of

cluster software, such as SGE, Condor, or Globus.

Many different configuration management and

policy engines have been developed for UNIX

systems. Cfengine (Burgess, 1995), Puppet (Kanies,

2006), and Chef (http://www.opscode.com/chef) are

a few well-known examples. Wrangler is similar to

these systems in that configuration is one of its

primary concerns, however, the other concern of this

work, provisioning, is not addressed by

configuration management systems.

This work is related to virtual appliances

(Sapuntzakis et al., 2003) in that we are interested in

deploying application services in the cloud. The

focus of our project is on deploying collections of

appliances for distributed applications. As such, our

research is complementary to that of the virtual

appliances community.

Wrangler is similar to the Nimbus Context

Broker (NCB) (http://workspace.globus.org) used

with the Nimbus cloud computing system (Keahey

et al., 2008). NCB supports roles, which are similar

to Wrangler plugins with the exception that NCB

roles must be installed in the VM image and cannot

be defined by the user when the application is

deployed. In addition, our system is designed to

support multiple cloud providers, while NCB works

best with Nimbus-based clouds.

Recently, other groups are recognizing the need

for deployment services, and are developing similar

solutions. One example is cloudinit.d (Bresnahan et

al., 2011), which enables users to deploy and

monitor interdependent services in the cloud.

Cloudinit.d services are similar to Wrangler plugins,

but each node in cloudinit.d can have only one

service, while Wrangler enables users to compose

several, modular plugins to define the behavior of a

node.

5 DISCUSSION AND

CONCLUSIONS

We have shown that workflow-based applications

can run successfully on cloud resources using the

same execution model as they use on the grid.

However, there are still many obstacles to making

this mode of execution efficient and robust.

Although cluster configuration tools exist, they need

to be able to deal with the failures we see in the

underlying cloud software. A big challenge, just as

is in the case of grids, is managing the failures,

either by masking them, by presenting them to the

user in an understandable way, and/or by providing

tools to help pinpoint the source of problems.

If one approaches application execution the way

we do, where we stand up a cloud infrastructure that

is similar to what can be found on campus or

national resources, then we still have the same

problems that we see in grids, with a number of

software systems layered on top of each other. We

still have issues of deciphering problems when

errors are not passed gracefully between the

software layers. Just as with grids, there are no

debugging tools or sophisticated user-friendly

monitoring tools for applications running on cloud

environments. Although virtualization can be a very

powerful tool for providing better reliability and

performance, today’s tools do not take full

advantage of it.

Although commercial clouds, such as Amazon,

are currently much more reliable than their academic

counterparts, there are monetary costs associated

with their use. Therefore applications developers and

users need tools to help evaluate the cost and

turnaround time of the entire computational problem

(for example whole sets of workflows—ensembles).

They also need tools to manage these costs for

example by using cost-effective resources or

leveraging allocations on grid systems.

For a number of new bioinformatics

applications, which are entering the arena of cloud

computing, issues of data privacy and security are

critical. Thus a new understanding and evaluation of

the security practices in virtual environments needs

to be developed.

ACKNOWLEDGEMENTS

This work was supported by the National Science

Foundation under grant OCI-0943725.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

132

G. B. Berriman is supported by the NASA

Exoplanet Science Institute at the Infrared

Processing and Analysis Center, operated by the

California Institute of Technology in coordination

with the Jet Propulsion Laboratory (JPL).

REFERENCES

"Open Science Grid," www.opensciencegrid.org.

TeraGrid. Available: http://www.teragrid.org/

D. Kranzlmüller, J. M. Lucas, et al, "The European Grid

Initiative (EGI)," Remote Instrumentation and Virtual

Laboratories, pp. 61-66, 2010.

E. Deelman, G. Singh, et al, "The Cost of Doing Science

on the Cloud: The Montage Example," SC'08 Austin,

TX, 2008.

R. D. Stevens, A. J. Robinson, and C. A. Goble, "myGrid:

personalised bioinformatics on the information grid,"

Bioinformatics vol. 19, 2003.

S. Callaghan, P. Maechling, et al, "Reducing Time-to-

Solution Using Distributed High-Throughput Mega-

Workflows - Experiences from SCEC CyberShake," e-

Science, Indianapolis, 2008.

D. A. Brown, P. R. Brady, et al, "A Case Study on the Use

of Workflow Technologies for Scientific Analysis:

Gravitational Wave Data Analysis," in Workflows for

e-Science, I. Taylor, et al, Eds., Springer, 2006.

A. S. Bland, R. A. Kendall, et al, "Jaguar: The world’s

most powerful computer," Memory (TB), vol. 300, p.

362, 2009.

A. Gara, M. A. Blumrich, et al, "Overview of the Blue

Gene/L system architecture," IBM Journal of Research

and Development, vol. 49, 2005.

I. Foster, "Globus Toolkit Version 4: Software for

Service-Oriented Systems," 2006.

M. Litzkow, M. Livny, and M. Mutka, "Condor - A

Hunter of Idle Workstations," in Proc. 8th Intl Conf.

on Distributed Computing Systems, ed, 1988.

K. Czajkowski, I. Foster, et al, "A Resource Management

Architecture for Metacomputing Systems," in 4th

Workshop on Job Scheduling Strategies for Parallel

Processing, 1998, pp. 62-82.

A. Bayucan, R. L. Henderson, et al, "Portable Batch

System: External reference specification," ed, 1999.

W. Allcock, J. Bester, et al, "Data Management and

Transfer in High-Performance Computational Grid

Environments," Parallel Computing, 2001.

Sun Microsystems. Lustre. http://www.lustre.org

Amazon Elastic Compute Cloud. http://aws.amazon.com/

ec2/

Google App Engine. http://code.google.com/appengine/

Nimbus Science Cloud. http://workspace.globus.org/clouds

/nimbus.html

(2010). FutureGrid. http://www.futuregrid.org/

G. B. Berriman, E. Deelman, et al, "Montage: A Grid

Enabled Engine for Delivering Custom Science-Grade

Mosaics On Demand," in SPIE Conference 5487:

Astronomical Telescopes, 2004.

Montage. Available: http://montage.ipac.caltech.edu

R. W. G., Paul G. Somerville, et al, "Ground motion

environment of the Los Angeles region," The

Structural Design of Tall and Special Buildings, vol.

15, pp. 483-494, 2006.

J. Dean and S. Ghemawat, "MapReduce: Simplified data

processing on large clusters," Communications of the

ACM, vol. 51, pp. 107-113, 2008.

E. Deelman, J. Blythe, et al, "Pegasus : Mapping Scientific

Workflows onto the Grid," in 2nd European Across

Grids Conference, Cyprus, 2004.

E. Deelman, G. Mehta, et al, "Pegasus: Mapping Large-

Scale Workflows to Distributed Resources," in

Workflows in e-Science, I. Taylor, E. Deelman, D.

Gannon, and M. Shields, Eds., ed: Springer, 2006.

A. Ramakrishnan, G. Singh, et al, "Scheduling Data -

Intensive Workflows onto Storage-Constrained

Distributed Resources," in CCGrid 2007.

G. Singh, K. Vahi, et al, "Optimizing Workflow Data

Footprint " Scientific Programming Journal, Special

issue on Dynamic Computational Workflows, vol. 15,

2007

S. Miles, E. Deelman, et al, "Connecting Scientific Data to

Scientific Experiments with Provenance " Third IEEE

e-Science 2007, India. , 2007.

S. Miles, P. Groth, et al, "Provenance: The bridge between

experiments and data," Computing in Science &

Engineering, vol. 10, pp. 38-46, 2008.

P. Groth, E. Deelman, et al, "Pipeline-Centric Provenance

Model, "The 4th Workshop on Workflows in Support

of Large-Scale Science, Portland, OR, 2009.

E. Deelman, "Grids and Clouds: Making Workflow

Applications Work in Heterogeneous Distributed

Environments," International Journal of High

Performance Computing Applications, 2009.

G. Juve and E. Deelman, "Automating Application

Deployment in Infrastructure Clouds," CloudCom

2011,

G. Juve and E. Deelman, "Wrangler: Virtual Cluster

Provisioning for the Cloud (short paper), HPDC'11,

2011.

E. Deelman, D. Gannon, et al, "Workflows and e-Science:

An overview of workflow system features and

capabilities," Future Generation Computer Systems,

vol. 25, pp. 528-540, 2009.

I. Krsul, A. Ganguly, et al, "Vmplants: Providing and

managing virtual machine execution environments for

grid computing," 2004, pp. 7-7.

StarCluster. http://web.mit.edu/stardev/cluster/.

M. A. Murphy, B. Kagey, et al, "Dynamic provisioning of

virtual organization clusters," 2009,

J.-S. Vöckler, G. Juve, et al, "Experiences Using Cloud

Computing for A Scientific Workflow Application,"

ScienceCloud, 2011.

M. Burgess, "A site configuration engine," USENIX

Computing Systems, vol. 8, 1995.

L. Kanies, "Puppet: Next Generation Configuration

Management," Login, vol. 31, 2006.

Opscode, Chef. Available: http://www.opscode.com/chef.

USINGCLOUDSFORSCIENCE,ISITJUSTKICKINGTHECANDOWNTHEROAD?

133

C. Sapuntzakis, D. Brumley, et al, "Virtual Appliances for

Deploying and Maintaining Software," USENIX 2003.

Nimbus. Available: http://workspace.globus.org

K. Keahey, R. Figueiredo, et al, "Science clouds: Early

experiences in cloud computing for scientific

applications," Cloud Computing and Applications,

2008.

J. Bresnahan, T. Freeman, et al, "Managing Appliance

Launches in Infrastructure Clouds," Teragrid

Conference, 2011.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

134
