EXPRESSING CLOUD SECURITY REQUIREMENTS

IN DEONTIC CONTRACT LANGUAGES

Per H

akon Meland

, Karin Bernsmed

, Martin Gilje Jaatun

, Astrid Undheim

and

Humberto Castejon

SINTEF ICT, Trondheim, Norway

Telenor Research and Future Studies, Trondheim, Norway

Keywords:

Cloud Computing, Security, Requirements, SLAs, Contracts, Brokering.

Abstract:

The uptake of Cloud computing is being hindered by the fact that not only are current Cloud SLAs written

in natural language, but they also fail to cover security requirements. This paper considers a Cloud brokering

model that helps negotiate and establish SLAs between customers and providers. This broker handles security

requirements on two different levels; between the customer and the broker, where the requirements are stated

in natural language; and between the broker and the different Cloud providers, where requirements are stated

in deontic contract languages. We investigate the suitability of seven of those languages for expressing security

requirements in SLAs and exemplify their use in the Cloud brokering model through a practical use case for a

video streaming service.

1 INTRODUCTION

Cloud computing has found its way into the IT ser-

vice delivery model for many of today’s businesses.

Recent numbers show that 10% of current enterprise

application software is running in the Cloud, and a

50% increase is expected within the next four years

(Gartner, 2011). As pointed out by (Liu et al., 2011),

the continued growth will increase the number of ac-

tors in the ﬁeld, making the integration of Cloud ser-

vices too complex to manage for the ordinary Cloud

customer. The Cloud broker represents a promising

and ambitious approach to manage Cloud services

in the near future. Its main purpose is to simplify

the usage, performance and delivery of Cloud ser-

vices and to help negotiate the relationships between

providers and customers. These relationships are

regulated through Service Level Agreements (SLAs),

which have become an important part of the Cloud

service delivery model. An SLA is a binding agree-

ment between the Cloud customer and the Cloud ser-

vice provider, the primary purpose of which is to

state the obligations of the provider, together with the

penalties if the provider fails to uphold the conditions.

Even though service availability is considered to

be a critical issue, the number one barrier against

adopting Cloud computing services is the lack of as-

surance for the safekeeping of data and applications

deployed in the Cloud (ENISA, 2009). Keeping these

in-house is considered to be less of a risk since the

organization has better control of the infrastructure

and conﬁguration. For a Cloud customer to perform

a proper risk analysis he will need to consider for in-

stance where his data and applications will be stored,

whether they will be encrypted at rest and in transit,

and whether international standards such as ISO/IEC

27002 are being adhered to. Even though most public

Cloud providers are happy to answer these types of

questions whenever asked, they will rarely or never

make any promises regarding security in their SLAs.

Rather, their SLAs are standard contracts made to ﬁt

as many as possible and take little responsibility in

case of a security incident or service outage. This

is a major drawback for any potential customer who

needs to ensure that e.g. privacy legislation or inter-

nal security policies are conformed to. We believe

that in order for Cloud computing to reach its full

potential as a mainstream outsourcing alternative, the

customers’ security requirements must be guaranteed

through SLAs.

Existing SLAs cover traditional QoS requirements

such as service performance and availability, as well

as speciﬁcation of reporting and violation handling,

and are written in natural language. In this paper we

638

Meland P., Bernsmed K., Jaatun M., Undheim A. and Castejon H..

EXPRESSING CLOUD SECURITY REQUIREMENTS IN DEONTIC CONTRACT LANGUAGES.

DOI: 10.5220/0003977906380646

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CloudSecGov-2012), pages 638-646

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

have a special focus on SLAs covering security re-

quirements, since they are considered more difﬁcult

to measure and quantify compared to the traditional

ones. As pointed out by (Dwivedi and Padmanabhuni,

2008), security is only represented through policies,

and not enforced through SLAs, and minimal work

has been done on security SLA representation and en-

actment.

This paper considers a Cloud broker model where

the broker help negotiate and establish SLAs be-

tween Cloud customers and Cloud service providers,

based on security requirements expressed by the cus-

tomer. The broker handles security requirements on

two different levels; between the customer and the

broker, where the requirements are stated in natural

language, and between the broker and the different

service providers, where requirements are stated in a

deontic contract language (“a language that can ex-

press the rights and obligations of parties to a contract

in a form that can be parsed by software applications

and processed with other data to determine state infor-

mation about matters governed by the contract” (Leff

and Meyer, 2007)). We provide examples using some

of the existing approaches which may be applicable

for Cloud computing, and investigate their suitability

for the Cloud brokering model though a practical use

case for a video streaming service.

The paper is organized as follows. In Section 2

we discuss the role of security in the context of Cloud

service brokering. In Section 3 we describe a use

case that utilizes a broker to negotiate security re-

quirements, and Section 4 shows some of the deontic

contract language dialects that can be used to specify

security requirements in SLAs. We discuss these ap-

proaches and related work in Section 5, and conclude

the paper in Section 6.

2 CLOUD SERVICE BROKERING

As the uptake of Cloud services increases, we see

a growing number of SaaS, PaaS and IaaS offerings

from a broad set of providers. A Cloud broker is thus

foreseen to become an important part of the Cloud

ecosystem, providing a one-stop shop for consumers,

SMEs and enterprises that look for a complete Cloud

service portfolio covering all their IT needs. This

Cloud broker will act as an intermediary between

the customers and Cloud service providers (see Fig-

ure 1). It will facilitate choosing the best service

providers to fulﬁll the requirements of a customer

based on optimization algorithms. In its simplest

form, this can be translated into picking the cheapest

IaaS provider(s) whose offerings cover a minimum set

of functional requirements. For SaaS, functionality

may be of higher importance, and only small varia-

tions in non-functional requirements will be present.

A Cloud broker will have business relationships with

a set of Cloud providers offering different types of

services. It is expected that the broker will negotiate

and sign an SLA with those providers before includ-

ing their services in its own service portfolio. How-

ever, some SLA requirements and corresponding met-

rics may still be open for negotiation with individual

customers. The customer requirements may then be

used to choose between individual Cloud providers.

However, to achieve this vision, there remain quite

a few challenges related to contract scenarios as pre-

sented by (Leff and Meyer, 2007):

• “Contract documents are created using word pro-

cessing applications. These documents can’t eas-

ily be processed at convenient levels of granular-

ity by automated systems.”

• “Consumers cannot easily compare terms offered

by different providers.”

• “Contract negotiation is slow and expensive. The

inefﬁciencies inherent in human contract negotia-

tion limit the value of the transaction, particularly

where rich parameter sets are involved.”

• “There is no standard way to map a given set of

negotiated contract parameters to a unique set of

contract terms.”

The above challenges could be solved by using

deontic contract languages. However, the customers

may not have the necessary skill or technical exper-

tise to write a deontic contract that can be automat-

ically processed to ﬁnd the best suitable candidates,

and technical contract writing tools have not been

widely accepted (Finnegan et al., 2007). An important

role of the Cloud broker is therefore to help the cus-

tomer translate the requirements into a deontic con-

tract language. This will facilitate dynamic and auto-

matic SLA negotiation between the Cloud broker and

the Cloud service providers, including renegotiation

of SLAs or migration of service components in case

of changing requirements from the users as well as

measured and observed breach of SLAs. Since there

is currently no prevalent standard for expressing con-

tract terms, the Cloud broker would in many cases

need to be multilingual.

3 USE CASE: CLOUDYFILMS

CloudyFilms is a new startup planning to offer video

streaming on demand with a pay-per-view business

EXPRESSINGCLOUDSECURITYREQUIREMENTSINDEONTICCONTRACTLANGUAGES

639

Public

Cloud 1

Public

Cloud 2

Public

Cloud 3

Cloud Broker

IAM

Service Request

Settlement and

Billing

- functional req

- security req

- constraints

-SLA negotiation

-SLA monitoring

-Violation handling

SLA Management

Scheduler

Figure 1: A Cloud broker model for ensuring secure Cloud deployment.

model. In order to minimize investment costs in

hardware infrastructure and increase business agility,

CloudyFilms decides to deploy its service in the

Cloud. For that, CloudyFilms needs different types

of virtual resources, including computation and stor-

age, with different functional, QoS and security re-

quirements. In particular, CloudyFilms needs two

large VMs to run the service portal and the streaming

server, and a small VM to run the customer registry.

It also needs separate storage spaces to store the cus-

tomer data and the video ﬁles (see Figure 2). Though

there are many requirements that would be relevant

for these resources, we have chosen a small subset of

security requirements that are of particular interest for

Cloud computing and brokering:

1. Data Retention. Data shall only be stored for

the period required by the purpose for which they

were collected. When the contract between the

parties expires (or after a speciﬁc time), all con-

sumer data must be deleted so that it cannot be

recovered.

2. Data Location. Data shall only be stored or pro-

cessed in a location under the inﬂuence of the Eu-

ropean Privacy directive.

3. Non-delegation. A service provider may not sub-

contract processing or storage to a third party.

These requirements are targeted towards speciﬁc

resources. For example, the data retention require-

ment is imposed on the customer data storage (S1) to

guarantee that customer data is completely removed

from a provider’s storage in case it is moved to a

new provider. Moreover, the location requirement

is imposed on both the customer data storage (S1)

and on the customer registry’s VM (VM2) to ensure

they will always be hosted in European datacenters.

Finally, the non-delegation requirement is imposed

on the streaming server (VM3) and the video stor-

age (S2). This requirement ensures that, if S2 and

VM3 are replicated on several providers, the selected

providers do not use the same infrastructure (i.e. pre-

venting one of them from sub-contracting infrastruc-

ture/services from the other one, the latter becoming

a single point of failure).

In this use case, there is not a single affordable

IaaS provider able to offer all the resources needed by

CloudyFilms at an affordable price while at the same

time fulﬁlling all the security requirements. Since

dealing with multiple providers is too much of an

administrative and technical burden for such a small

company, CloudyFilms decides to use the services of

a Cloud broker. The broker gets CloudyFilms’ speci-

ﬁcation of hardware, security and QoS requirements,

and uses it to select the cheapest IaaS providers that

fulﬁll those requirements (e.g. it selects provider 2,

in Europe, to host the customer data, even though it

is more expensive than provider 3, in the US - see

Figure 2). With each of the selected providers, the

broker automatically negotiates an SLA on behalf of

CloudyFilms and supervises its enforcement.

4 SPECIFYING SECURITY

REQUIREMENTS IN SLAs

In this section we have selected a set of seven exist-

ing deontic contract languages found in the literature

and for each of them tried to express at least one of

the sample security requirements from Section 3. We

have considered these languages based on the follow-

ing properties:

• Feasibility. How well the language ﬁts the type

of requirements considered in the paper.

• Complexity. The size and expressiveness of the

language.

• Extensibility. The possibility of adding addi-

tional concepts and expressions.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

640

streaming

server

portal

front end

video

storage

customer

data

Functional Req

VM 1: 2 CPU

VM 2: 1 CPU

VM 3: 2 CPU

S1: 1 Gb

S2: 40 Gb

Security Req

VM 1: none

VM 2: location

VM 3: non-delegation

S1: location, retention

S2: non-delegation

VM 1

VM 2

VM 3

S 1

S 2

portal

front end

video

storage

video

storage

customer

data

Service Request

streaming

server

customer

Cloud

Broker

1: US, 5 $

2: EU, 10 $

3: US, 5 $

4: US, 5 $

Figure 2: A Cloud Broker negotiating security requirements.

• Maturity. How long the language has been pub-

licly available.

• Support. Associated documents, tools and other

sources of information.

• Adoption. The current uptake among the relevant

stakeholders.

This is not intended to be an exhaustive survey, but a

sample used to illustrate the diversity and suitability

of current technology for expressing security require-

ments in a machine readable way given the context of

service brokering for Cloud SLAs.

4.1 APPEL

The Platform for Privacy Preferences (P3P) speciﬁca-

tion (Cranor, 2003) allows websites to express their

privacy policies in machine readable format. The pur-

pose is to inform the user about how the personal

information that is collected by the website will be

handled. Privacy preferences are expressed using

APPEL (Cranor et al., 2002), which are evaluated

against the P3P policy ﬁles in order to let user agents

make automated or semi-automated decisions. For

the CloudyFilms use case the APPEL language can

be used to put restrictions on what data is collected

by the provider and how it will be used (in terms of

purpose, recipient and retention). The rule set in List-

ing 1 states that it is not acceptable that the service

provider transfers the customer data to any third party

(non-delegation). Here we have assumed that the cus-

tomer data consists of physical and online contact in-

formation and purchase information.

With APPEL it is straightforward to put restric-

tions onto data storage retention by using the RETEN-

TION element, however, it is not possible to articulate

restrictions on the geographic location.

Writing policies in P3P/APPEL is fairly straight-

forward and there are several tools that help translate

policies stated in natural languages to the machine-

readable format. The language is easily extensible,

however, the restricted vocabulary and the limited

scope (data collection practices for websites) makes it

difﬁcult to express security requirements for service-

oriented architectures such as the Cloud.

Version 1.0 of the P3P speciﬁcation was released

in 2002, representing a cornerstone in the privacy pro-

tection ﬁeld. However, adoption was slow already

from the beginning, and more recent numbers show

that only a fraction of all websites have a P3P pol-

icy (Egelman et al., 2006). The work on the speciﬁ-

cation has been ofﬁcially suspended since 2006.

EXPRESSINGCLOUDSECURITYREQUIREMENTSINDEONTICCONTRACTLANGUAGES

641

Listing 1: An APPEL rule set for restricting access to cus-

tomer data.

1 < a p p e l : RULE b e h a v i o r =” b l ock ”

d e s c r i p t i o n =” S e r v i c e may

t r a n s f e r c u s to m e r d a t a t o 3 r d

p a r t i e s ”>

2 <p3p : POLICY>

3 <p3p :STATEMENT>

4 <p3p :DATA−GROUP><p3p :DATA>

5 <p3p : CATEGORIES a p p e l : c o n n e c t i v e =”

o r”>

6 <p3p : p h y s i c a l />

7 <p3p : o n l i n e />

8 <p3p : o t h e r −c a t e g o r y />

9 </p3p : CATEGORIES>

10 </p3p :DATA></p3p :DATA−GROUP>

11 <p3p : RECIPIENT a p p e l : c o n n e c t i v e =”

o r”>

12 <p3p : same/>

13 <p3p : o t h e r −r e c i p i e n t />

14 <p3p : p u b l i c />

15 <p3p : d e l i v e r y />

16 <p3p : u n r e l a t e d />

17 </p3p : RECIPIENT>

18 </p3p :STATEMENT>

19 </p3p : POLICY>

20 </ a p p e l : RULE>

4.2 RFC 4745

RFC 4745 (Schulzrinne et al., 2007) is a frame-

work for creating authorization policies for access to

application-speciﬁc data. The purpose of the frame-

work is to combine location speciﬁc policies and pres-

ence speciﬁc policies into one common authorization

system. The framework deﬁnes a rule set (i.e. policy),

consisting of conditions, actions and transformations

(i.e. permissions), that are evaluated in order to de-

termine if a request for access to data items should

be permitted or not. There are currently three con-

ditions deﬁned in RFC4745; identity, sphere and va-

lidity, making it possible to put restrictions on who,

where and when data can be accessed. RFC4745

does not directly support any of the example secu-

rity requirements for the CloudyFilms use case, how-

ever, the identity condition may be used to put re-

strictions on the domain attribute for providers who

try to access the data. For example, the rule set in

Listing 2 will block service providers within the do-

mains example.com and example.org. The purpose

of RFC4745 was to increase interoperability by al-

lowing authorization policies to travel with the data,

and could possibly be extended to be applicable to the

Cloud brokering context. The framework has already

been extended and implemented as part of presence-

based systems based on SIP (IBM, 2009).

Listing 2: A rule set expressed according to RFC 4745.

1 < r u l e i d =” f 3 g4 4 r 1”>

2 < c o n d i t i o n s >

3 < i d e n t i t y >

4 <many>

5 < e x c e pt domain =” e xa mp le . com

”/ >

6 < e x c e p t domain =” e xa mp le . o r g

”/ >

7 </many>

8 </ i d e n t i t y >

9 </ c o n d i t i o n s >

10 < a c t i o n s />

11 < t r a n s f o r m a t i o n s />

12 </ r u l e >

Listing 3: A rule set expressed in WS-XACML.

1 XACMLP riv acy Ass erti on

2 R e q u i r e m e n t s

3 RETENTION : d a t a k e p t o n l y u n t i l

t r a n s a c t i o n c o m p l e t e d

4 RECIPIENT : d a t a n o t g i v e n t o a ny 3 r d

p a r t y

5 C a p a b i l i t i e s

6 P r o v i d e c u s t o m e r d a t a

4.3 XACML

XACML (eXtensible Access Control Markup Lan-

guage) (OASIS, 2005) describes both a policy lan-

guage and an access control decision request/response

language. The typical setup is that someone wants to

perform an action on a resource; however, XACML

can also be used to ﬁnd a policy that applies to a given

request and evaluate the request against the policy.

The current version of XACML (2.0) is very lim-

ited for other purposes than access control. How-

ever, in WS-XACML (which is a proposed feature for

XACML 3.0) the client (i.e. customer) can use an

XACMLPrivacyAssertion to make sure that the ser-

vice fulﬁlls an obligation regarding the client’s pro-

vided personal information. Two such assertions will

match if every requirement in each assertion is satis-

ﬁed by at least one capability in the other. The re-

quirement in Listing 3 (expressed in pseudocode to

save space) states that customer data should not be

stored by the provider or forwarded to any third party.

XACML is very powerful and is easily extensible,

but it is considered difﬁcult to write and reason over

XACML policies. It has been widely adopted, espe-

cially within academic research. Version 3.0 (which

is a work in progress) will include additional aspects,

such as delegation, which will make it possible to del-

egate (and put constraints of the delegation of) access

policies.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

642

Listing 4: A WS-Agreement service level objective that

uses P3P to put restrictions on data retention.

1 <wsag : G u a r a n t e e Term

2 wsag : Name=

S e c u r i t y R e q u i r e m e n t s

3 wsag : O b l i g a t e d = P r o v i d e r >

4 <wsag : S e r v i c e S c o p e

5 Se rvi ceN ame =

S t o r e C o n s u m e r D a t a >

6 </wsag : S e r v i c e S c o p e >∗

7 <wsag : S e r v i c e L e v e l O b j e c t i v e >

8 <wsag : C u s t o m S e r v i c e L e v e l >

9 <RETENTION>< s t a t e d p u r p o s e /></

RETENTION>

10 </wsag : C u s t o m S e r v i c e L e v e l >

11 </wsag : S e r v i c e L e v e l O b j e c t i v e >

12 </wsag : Gu ara nte e Ter m>

4.4 WS-Agreement

The WS-Agreement speciﬁcation (Andrieux et al.,

2003) is a protocol for establishing an agreement be-

tween two parties, such as service providers and con-

sumers. It allows the use of any service term, and

is therefore suitable for security agreements as well.

The speciﬁcation provides a template for the agree-

ment, which consists of the name of the agreement

(this is optional), the context (the participants and the

lifetime of the agreement) and the agreement terms.

The agreement terms are used to specify the obliga-

tions of the parties and the associated guarantee terms

are used to provide assurance to the service consumer

on the service quality and/or resource availability of-

fered by the service provider.

WS-Agreement does not include any ontology for

expressing security requirements, but it is possible to

use the service level objectives in the guarantee terms

to put restrictions on data storage location, retention

and non-delegation using any existing security on-

tologies. For example, a service level objective that

uses P3P to put restrictions on the data retention could

look as illustrated in Listing 4.

WS-Agreement is an open standard and it has

been widely adopted for QoS support for service ori-

ented architectures in web and grid contexts.

4.5 Primelife Policy Language

The PrimeLife Policy Language (PPL) is an XML-

based policy language developed by the EU project

PrimeLife (PrimeLife Consortium, 2012). In addition

to access control, PPL provides data handling as an

extension to XACML 3.0 (Ragget, D. et al, 2009).

PPL is focused around data handling and credential

capabilities. The user’s privacy preferences are evalu-

Listing 5: Expressing non-delegation in PPL.

1 < D a t a H a n d l i n g P r e f e r e n c e s >

2 < O b l i g a t i o n s S e t > . . </

O b l i g a t i o n s S e t >

3 < A u t h o r i z a t i o n s S e t >

4 . .

5 <A uthzD ownst reamU sage a l l o w e d =”

f a l s e ”>

6 </AuthzDownstreamUsage>

7 </ A u t h o r i z a t i o n s S e t >

Listing 6: A data retention requirement expressed in BCL.

1 P o l i c y : D a t a R e t e n t i o n

2 Ro l e : P r o v i d e r

3 M o d a l i t y : O b l i g a t i o n

4 T r i g g e r : S t o r e C o n s u m e r D a t a

5 B e h a v i o u r : D e l et e C o n s u m e r Da t a

a f t e r S t o re C o n s u m e r D a t a . d a t e +

ated against the service provider’s data handing poli-

cies and if there is a match a sticky policy can be

attached to the data. PPL supports both data reten-

tion and non-delegation; the latter by making it pos-

sible for a user to specify to whom and under what

circumstances personal data may be forwarded to a

third party (called ”downstream data controller” in the

language speciﬁcation). Non-delegation using PPL

is expressed in Listing 5. In this data handling pol-

icy the AuthorizationsSet will be used to deﬁne what

the service provider can do with the collected infor-

mation and the ObligationsSet deﬁnes the obligations

that the provider promises to adhere to. The current

draft of PPL does not support restrictions in terms of

geographic location of the data storage and process-

ing but the vocabulary is left open and might be ex-

tended to include such restrictions. PPL is still very

young since PrimeLife has just completed, and there

is consequently little adoption.

4.6 Business Contract Language

The Business Contract Language (BCL) (Governatori

and Milosevic, 2006) is an event driven language in-

tended for runtime monitoring of contract terms. A

single event can be used to signify actions of the sig-

natories, temporal occurrences or change of state as-

sociated to a contract variable. Listing 6 shows how

one may express the data retention requirement as an

obligation (pattern that must occur given an event) for

the service provider:

Besides from obligations, modality can be used

to express permissions (allowed behavior) and pro-

hibitions (what must not occur). Given this expres-

siveness, all of our requirement examples should be

EXPRESSINGCLOUDSECURITYREQUIREMENTSINDEONTICCONTRACTLANGUAGES

643

Listing 7: A non-delegation requirement in ConSpec.

1 SCOPE c o m p o s i t i o n

2 SECURITY STATE

3 BEFORE i n v o k e S e r v i c e ( s )

4 PERFORM

5 ( s . non−d e l e g a t i o n ( ) . e q u a l s ( t r u e ) )

−> s k i p

possible to represent in BCL. The language also sup-

ports the expression of violations and their corre-

sponding reparations, which is very relevant for se-

curity policies. The language seems therefore well

suited for security SLA negotiation, and still manages

to have a limited set of constructs. It seems fairly easy

to extend, but there must be a common agreement

on triggers and behavior among the involved parties.

Though BCL was introduced in 2005, there is cur-

rently little available information, tools and activities

related to it.

4.7 ConSpec

The ConSpec language (Aktug and Naliuka, 2008;

Greci et al., 2009) can be used to formally specify

contracts and various security enforcement tasks, and

it is strongly inspired by the policy speciﬁcation lan-

guage PSLang (Erlingsson, 2004) for runtime moni-

toring. It consists of declarations related to the secu-

rity state and, like BCL, deﬁnes events that triggers

actions for updating the states. Listing 7 exempliﬁes

the non-delegation requirement. No speciﬁc variables

are deﬁned after the security state declaration, but the

event clause tells us that the service can only be in-

voked as long as it promises to not delegate the task

to others.

ConSpec is a relatively simple and restricted lan-

guage, with a ﬁnite set of variables, no loops and in-

tended for expressing security requirements. It is well

suited for contract matching, can be somewhat ex-

tended, but is mostly limited to academic use. How-

ever, parsing tools are available and adoption and

documentation is currently being done through the

Aniketos project (Aniketos Consortium, 2012).

4.8 LegalXML

LegalXML is a standard from OASIS for structuring

legal documents and information using XML and re-

lated technologies. A special technical committee de-

veloped eContracts(Leff and Meyer, 2007), which is

an open standard for the markup of contract docu-

ments to enable creation, maintenance, management,

exchange and publication of contract documents and

contract terms. It is intended to be used by automated

Listing 8: An eContract with a location requirement.

1 <?xml v e r s i o n = ” 1 . 0 ” e n c o d i n g =” ut f

−8”?>

2 < c o n t r a c t xmlns =” u r n : o a s i s : names : t c

: e C o n t r a c t s :1 :0” >

3 < t i t l e ><t e x t > P e r s i s t e n t s t o r a g e

l o c a t i o n </ t e x t ></ t i t l e >

4 < c o n d i t i o n s >< c o n d i t i o n name=”EU”>

Eu r o p e a n Union </ c o n d i t i o n ></

c o n d i t i o n s >

5 <body>

6 <b l o c k c o n d i t i o n =”EU”>

7 < t e x t >D ata s h a l l o n l y be s t o r e d

on s e r v e r s l o c a t e d w i t h i n

t h e Eu r o pean Union </ t e x t >

8 </ b l o c k >

9 </body>

10 </ c o n t r a c t >

processing systems rather than lawyers, and to struc-

ture any kind of contract. A simpliﬁed example rep-

resenting the location requirement using eContract is

shown in Listing 8. The grammatical content is repre-

sented inside the “block” element, and the character

data within the “text” element. In this example, we

have used a conditional attribute to express that it has

a jurisdiction limited to the EU.

Though eContracts is a deontic contract language,

the contractual terms within the blocks are still mostly

deﬁned using natural language. The main intention of

eContracts is to represent contracts that have already

been agreed upon and signed by the involved parties

independent of word processing tools. This makes

this approach less suitable for Cloud SLA brokering.

The speciﬁcation deﬁnes 51 core elements, and pro-

vides a generic structure that can be used to encom-

pass a wide range of contracts. The structure is simple

with high degree of freedom. Version 1.0 of the spec-

iﬁcation dates back to 2007, but at the same time the

technical committee was dissolved and to the best of

our knowledge there has been little activity since to

continue the work of eContracts.

5 DISCUSSION AND RELATED

WORK

In the previous section we presented seven different

speciﬁcation languages and investigated to what de-

gree it is possible to express the security requirements

for the CloudyFilms use case. Table 1 shows a com-

parison of the languages based on the properties we

deﬁned in Section 4 using the values {low, medium,

high}.

P3P represents early work in the context of pri-

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

644

Table 1: Comparing the speciﬁcation languages in Section 4.

Language Feasibility Complexity Extensibility Maturity Support Adoption

P3P Medium Low Medium High Medium Medium

RFC4745 Low Low High Low Low Medium

XACML Low Medium High High High High

WS-Agreement High Low High High High High

PPL Medium Medium High Low Low Low

BCL High Medium Medium Medium Low Low

ConSpec High Medium Medium Medium Low Medium

LegalXML Low Low High High Low Low

vacy protection and usage of personal information,

and several of the subsequently developed languages

have been inspired by this work. However, now

this initiative is more or less dead, mostly because

the slow adoption and limited interest from the ser-

vice providers. In our context the main limitation is

data handling preferences, which is shared by PPL.

XACML is designed to be more general purpose than

both P3P and PPL, which is both a strength and a

weakness. WS-Agreement, BCL and ConSpec all

seem suitable for expressing security requirements

in a deontic form, however, neither speciﬁes a secu-

rity term ontology, leaving the problem of translat-

ing security requirements stated in natural language

to a machine-readable format unsolved. According to

(Pearson and Charlesworth, 2009), translation of leg-

islation/regulation to machine readable policies has

proven to be very difﬁcult, and they give an overview

of various projects that have tried to do so.

Other languages that we have not explored in our

Cloud broker use case include for instance ecXML

(Farrell et al., 2004), which has an event based na-

ture similar to BCL. The Contract Expression Lan-

guage (Wang, 2010) is similar to eContracts, mean-

ing that they are designed to express already agreed

upon terms between the involved parties. Web Ser-

vice Level Agreements (WSLA) was designed to be

a ﬂexible SLA deﬁnition language, but is not suitable

for security due to its focus on downtime, through-

put, response time and other quantiﬁable parameters

(WSLA, 2003). The Rule Based Service Level Agree-

ment language (RBSLA) (Paschke, 2005) is another

mark-up language for rule-based policy and contract

speciﬁcations. Though there has been little activity

from RBSLA since 2006, it was based on the still on-

going RuleML initiative (RuleML, 2012). A wider

range of related policy languages and protocols can

be found in papers by (Yag

ue, 2006) and (Dwivedi

and Padmanabhuni, 2008).

Somewhat related to our brokering use case,

(Nepal et al., 2009) present an XML-based contract

language for establishing collaborative services. Al-

though their approach seems more geared toward an

environment of collaborating peers, they do describe a

situation where collaborators contribute through pro-

viding web services. They provide little details on

security aspects, but highlight the need for deletion of

information after a contract termination.

6 CONCLUSIONS

Current Cloud SLAs are written in natural language,

and seldom cover security requirements; this is hin-

dering the uptake of Cloud Computing. We envi-

sion Cloud brokers to have a role in translating cus-

tomer requirements into deontic contract languages,

thus helping users to ﬁnd the most suitable Cloud

providers in a more automated and dynamic way.

Many different contract speciﬁcation languages exist

today, but there is no single “silver bullet” language

that stands out as a prevalent candidate. Further work

is required on the speciﬁcation and reasoning of secu-

rity requirements for Cloud SLA broking, and there is

need for a common ontology that represents contrac-

tual security concepts.

ACKNOWLEDGEMENTS

The research leading to these results has been sup-

ported by Telenor through the SINTEF-Telenor re-

search agreement and the European Union Seventh

Framework Programme (FP7/2007-2013) under grant

no 257930.

REFERENCES

Aktug, I. and Naliuka, K. (2008). Conspec – a formal lan-

guage for policy speciﬁcation. Electron. Notes Theor.

Comput. Sci., 197:45–58.

Andrieux, A., Czajkowski, K., Dan, A., Keahey, K.,

Ludwig, H., Nakata, T., Pruyne, J., Rofrano, J.,

Tuecke, S., and Xu, M. (2003). Web Services

Agreement Speciﬁcation (WS-Agreement). https://

forge.gridforum.org/projects/graap-wg/.

EXPRESSINGCLOUDSECURITYREQUIREMENTSINDEONTICCONTRACTLANGUAGES

645

Aniketos Consortium (2012). Aniketos - ensuring trust-

worthinesss and security in service composition.

http://www.aniketos.eu/.

Cranor, L. F. (2003). P3P: making privacy policies more

useful. Security & Privacy, IEEE, 1(6):50 – 55.

Cranor, L. F., Langheinrich, M., and Marchiori, M. (2002).

A P3P Preference Exchange Language 1.0 (AP-

PEL1.0). World Wide Web Consortium.

Dwivedi, V. and Padmanabhuni, S. (2008). Providing Web

Services Security SLA Guarantees: Issues and Ap-

proaches. In Khan, K. M., editor, Managing Web ser-

vice quality : measuring outcomes and effectiveness,

chapter 13, pages 286–305. IGI Global.

Egelman, S., Cranor, L. F., and Chowdhury, A. (2006).

An analysis of P3P-enabled web sites among top-20

search results. In Proceedings of the 8th int. conf. on

Electronic commerce, ICEC ’06, pages 197–207.

ENISA (2009). Cloud Computing: Beneﬁts, risks and

recommendations for information security. European

Network and Information Security Agency.

Erlingsson, U. (2004). The inlined reference monitor ap-

proach to security policy enforcement. PhD thesis,

Cornell University.

Farrell, A. D. H., Sergot, M. J., Trastour, D., and

Christodoulou, A. (2004). Performance monitoring

of service-level agreements for utility computing us-

ing the event calculus. In Proc. First IEEE Int. WS on

Electronic Contracting, pages 17–24.

Finnegan, J., Malone, P., Maranon, A., and Guillen,

P. (2007). Contract modelling for digital business

ecosystems. In Digital EcoSystems and Technologies

Conference, 2007. DEST ’07., pages 71 –76.

Gartner (2011). Public Cloud Services, Worldwide and

Regions, Industry Sectors, 2010-2015, 2011 Update.

http://softwarestrategiesblog.com/2011/07/02/sizing-

the-public-cloud-services-market/.

Governatori, G. and Milosevic, Z. (2006). A formal analysis

of a business contract language. Int. J. Cooperative

Inf. Syst., 15(4):659–685.

Greci, P., Martinelli, F., and Matteucci, I. (2009). A frame-

work for contract-policy matching based on symbolic

simulations for securing mobile device application. In

Leveraging Applications of Formal Methods, Veriﬁca-

tion and Validation, volume 17 of Communications in

Computer and Information Science, pages 221–236.

Springer. 10.1007/978-3-540-88479-8

16.

IBM (2009). General considerations for setting up security

for presence server. http://publib.boulder.ibm.com/

infocenter/wtelecom/ v7r0m0/ index.jsp?topic=/ com.

ibm. presence.plan.doc/generalsecurity c.html.

Leff, L. and Meyer, P. (2007). eContracts Version 1.0.

Technical report, OASIS. http://docs.oasis-open.org/

legalxml-econtracts.

Liu, F., Tong, J., Mao, J., Bohn, R., Messina, J., Badger, L.,

and Leaf, D. (2011). NIST Cloud Computing Refer-

ence Architecture. NIST Special Publication 500-292.

Nepal, S., Zic, J., and Chen, S. (2009). A contract language

for service-oriented dynamic collaborations. In Col-

laborative Computing: Networking, Applications and

Worksharing, volume 10 of LNICST, pages 545–562.

Springer. 10.1007/978-3-642-03354-4 41.

OASIS (2005). eXtensible Access Control Markup

Language (XACML) Version 2.0. OASIS Open.

http:// docs.oasis-open.org/xacml/2.0/access control-

xacml-2.0-core-spec-os.pdf.

Paschke, A. (2005). RBSLA - A declarative Rule-

based Service Level Agreement Language based on

RuleML. In Int. Conf. Comp. Intelligence for

Modelling, Control and Automation, and Intelligent

Agents, Web Tech. and Internet Commerce, volume 2,

pages 308 –314.

Pearson, S. and Charlesworth, A. (2009). Accountability as

a way forward for privacy protection in the cloud. In

Proc. 1st International Conference on Cloud Comput-

ing, CloudCom ’09, pages 131–144. Springer.

PrimeLife Consortium (2012). Primelife - privacy and

identity management in europe for life. http://

www.primelife.eu/.

Ragget, D. et al (2009). H5.3.2 - Draft 2nd Design for Pol-

icy Languages and Protocols. Technical report, The

PrimeLife project.

RuleML (2012). The Rule Markup Initiative. http://

www.ruleml.org.

Schulzrinne, H., Tschofenig, H., Morris, J., Cuellar, J.,

Polk, J., and Rosenberg, J. (2007). Common Pol-

icy: A Document Format for Expressing Privacy

Preferences. Request For Comments 4745 http://

tools.ietf.org/html/rfc4745.

Wang, X. (2010). Specifying the business collaboration

framework in the Contract Expression Language. In-

ternational Journal of Business Process Integration

and Management, 4(3):200–208.

WSLA (2003). Web Service Level Agreements (WSLA)

Project. http://www.research.ibm.com/wsla/.

Yag

ue, M. I. (2006). Survey on XML-Based Policy Lan-

guages for Open Environments. Journal of Informa-

tion Assurance and Security, 1(1):11–20.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

646
