SECURITY AND PRIVACY GOVERNANCE

IN CLOUD COMPUTING VIA SLAs AND A POLICY

ORCHESTRATION SERVICE

Marco Casassa Mont

, Kieran McCorry

, Nick Papanikolaou

, Siani Pearson

Cloud and Security Lab, HP Labs, Bristol, United Kingdom

Enterprise Services CTO Office, Hewlett Packard Ltd, United Kingdom

Keywords: Cloud Security, Privacy, SLAs, Decision Support Systems, Enterprise Computing, Information Governance.

Abstract: We present in this paper the novel concept of a policy orchestration service, which is designed to facilitate

security and privacy governance in the enterprise, particularly for the case where various services are

provided to the enterprise through external suppliers in the cloud. The orchestration service mediates

between the enterprises’ internal decision support systems (which incorporate core security and privacy

recommendations) and the cloud-based service providers, who are assumed to be bound by contractual

service level agreements with the enterprise. The function of the orchestration service, which is intended to

be accessed as a trusted service in the cloud, is to ensure that applicable security and privacy

recommendations are actioned by service providers through adequate monitoring and enforcement

mechanisms.

1 INTRODUCTION

The potential offered by cloud computing for the

provision of core business services anytime,

anywhere, to anyone is huge. Customers of cloud

service providers have access to potentially vast

computational resources (not just raw computing

power, but also data storage and networking

infrastructure), and enterprises are enticed to

outsource core business activities and functions to

the cloud due to the benefits of reduced cost and

increased efficiency that can be thus made. It is

actually possible to outsource the work of entire

business units to providers of cloud-based business

software, such as Salesforce.com.

However, security concerns and worries over

customer privacy have proven to be fundamental

barriers to the adoption of cloud-based services.

Enterprises that handle large amounts of customer

data need to take numerous measures to comply with

security standards, data protection laws, and core

business principles with regards to preventing harm

to customers’ data and their reputations.

The usual model of information security

management within the enterprise is given by the

lifecycle depicted in Figure 1. This information

security lifecycle is a very high-level view of the

processes that should be repeatedly carried out in

order to assess and implement security requirements;

we note here that specifically for privacy issues,

there exist similar models of information manage-

ment, including for example privacy impact assess-

ments (see ICO 2009), but we refer to the informa-

tion security lifecycle here as the starting point for

our considerations. The lifecycle does not specify

how the processes of, say, risk assessment, moni-

toring and auditing are implemented in practice,

whether

through a cloud service or otherwise. Our

Figure 1. The Information Security Lifecycle.

670

Casassa Mont M., McCorry K., Papanikolaou N. and Pearson S..

SECURITY AND PRIVACY GOVERNANCE IN CLOUD COMPUTING VIA SLAs AND A POLICY ORCHESTRATION SERVICE.

DOI: 10.5220/0003978406700674

In Proceedings of the 2nd International Conference on Cloud Computing and Services Science (CloudSecGov-2012), pages 670-674

ISBN: 978-989-8565-05-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

focus is on the governance of information within the

enterprise, and the processes that enable both

privacy and security requirements to be satisfied.

What the lifecycle shows is that the handling of

such requirements within the enterprise is a cyclic

process, which requires constant re-assessment and re-

implementation of appropriate measures. For example,

risk assessments need to be conducted regularly in

order to determine necessary data governance practices,

which in turn need to be encoded into policies and

enforced using suitable controls.

The objective in this paper is to describe a means

for automating information governance in

enterprises that outsource important information

processing tasks to external cloud service providers.

Our contribution is the design of a system

component known as a policy orchestrator or policy

orchestration service, and an accompanying

architecture, whose purpose is to automate a

significant part of the governance processes (mainly

the monitoring and enforcement of privacy and

security requirements) in this setting.

1.1 Related Work

Decision support systems for business applications

are covered extensively in Turban et al. (2010). We

note that there is a body of research on algorithms

for decision support systems that support optimal

selection of suppliers (see for example Ghodsypour

and O'Brien, 1998); while in this paper we are not

interested in optimality criteria for supplier selection

directly, the idea of using decision support systems

to manage external suppliers supporting business

functions has some relevance to our ideas.

Governance, risk management and compliance

(GRC) platforms (see Gartner 2011) are widely used

in enterprises to monitor flows of data and ensure

compliance requirements are satisfied throughout

businesses processes.

Agent technology (see e.g. Padgham and

Winikoff 2004) is currently used at the end-points

(systems, apps, solutions and/or processes) to

enforce and monitor activities. However, most

current approaches involve manual steps to inform

these agents about what to do. Information has to be

gathered about the affected systems, including

required configurations and access rights; relevant

people need to be identified and involved to provide

this data; somebody has to instantiate

templates/scripts based on the above details; various

enforcement and monitoring activities need to be

carried out. Potentially new decisions or decision

changes require repeating this process all over again.

Collaborative and knowledge management tools

are of relevance, particularly due to the complexity

of maintaining a large rule base. Knowledge

management techniques and tools are widely used

(see Alavi and Leidner 1999).

Workflow and scripting solutions exist widely

(see Jackson and Twaddle 1997 for an account of the

basic principles involved); the very idea of an

orchestration service is heavily inspired by

workflow management systems, as it can effectively

be regarded as a means to implement workflows for

decision support system recommendations in the

cloud.

2 HANDLING PRIVACY AND

SECURITY GOVERNANCE IN

THE CLOUD

In order to cope with the deluge of rules and

restrictions that need to be met, enterprises use

special information governance platforms, namely,

tools that enable managers, chief information

security officers (CISOs) and privacy officers to

monitor how data is stored, handled and processed at

different control points within the enterprise. In

addition, the use of decision support systems is

commonplace; these are automated tools that

intelligently generate lists of recommendations that,

when followed in practice, will ensure that particular

requirements (for our purposes, security and privacy

requirements) are satisfied.

Decision support systems do not usually include

means to enforce or action the recommendations

they produce; the output of a decision support

system is a visual display of information, often just

an itemized list of actions that a human user should

carry out. In addition, the usefulness of any decision

support system’s output is dependent on the

accuracy and completeness of its rule base; if the

rules that the system incorporates are not up-to-date,

or do not take into account all external factors, such

as, for example, all the different laws and

regulations that impact an enterprise’s security

practices, then that decision support system will not

serve its purpose well, and possibly lead to incorrect

decisions on the part of the human user.

We are interested in designing a system

architecture that helps manage an enterprise’s

information governance practices when it utilizes

cloud services from external suppliers. Our concrete

contribution in this paper is the design of a core

component for such an architecture, namely, the

SECURITYANDPRIVACYGOVERNANCEINCLOUDCOMPUTINGVIASLAsANDAPOLICY

ORCHESTRATIONSERVICE

671

orchestrator, whose function is to monitor and

enforce security and privacy recommendations.

These recommendations would typically be

customised for a particular project/application, and it

is likely that they would be produced automatically

by means of a decision support system – an example

of such a system is the HP Privacy Advisor (see

Pearson et al. 2009). However, the orchestrator is

not intended to be used only with customised, auto-

generated inputs; it might use other sources for

privacy and security rules, such as databases with

pre-defined corporate policies.

Figure 2: Overall system architecture.

The orchestrator takes as its inputs a list of

security and privacy recommendations, the set of

service level agreements detailing the relationship

and expectations of the enterprise with regards to its

suppliers, and a set of templates which map

recommendations to technical policy rules (such as

access control rules for particular types of data). The

output of the orchestrator is a set of policies and a

set of instructions to be carried out and implemented

by the external suppliers. If a particular

recommendation cannot be actioned directly, or is

not satisfied by any of the SLAs available, then the

orchestrator will notify the system user accordingly.

Clearly these functions, which the orchestrator

provides, are of fundamental practical importance to

the enterprise; without them, the entire process of

making sure that security and privacy

recommendations are in fact implemented in

practice becomes fully manual and hence error-

prone. Since the orchestrator is a software service, it

can perform both monitoring and enforcement

functions automatically, with little human

intervention as and when needed.

To drive this point home, consider what actions

are normally needed to practically implement a

decision support system’s recommendations:

• identifying the suitable actions to be carried out

• gathering relevant information at the operational

level (for example, about the system affected, the

people involved, the access rights)

• delegating steps and activities to IT

administrators in charge of specific fields (so that

they can then monitor compliance against the

recommended changes).

Current approaches to security and privacy

governance within the enterprise provide little

visibility about the involved ecosystem (people,

systems, activities); they are primarily manual; and

they do not actively involve all the necessary

stakeholders to deal with the overall process.

The orchestrator, or policy orchestration service,

that we propose performs the following in an

automated manner:

(1) it enables a collaborative exchange of

information between relevant stakeholders;

(2) it ‘orchestrates’ the translation of a decision

support system’s recommendations into a set

of commands corresponding to enforcement

and monitoring activities to be executed by

the external service provider;

(3) it supports the execution and monitoring of

these activities;

(4) it traces and audits them.

We detail these functionalities in the next section.

3 A CLOUD-BASED

ORCHESTRATION SERVICE

The key idea here, as we have discussed in the

previous sections, is to achieve automation in the

way decision support systems’ recommendations are

transformed into enforceable activities by (1)

leveraging workflow capabilities and (2) integrating

multiple sources of information. Specifically we

introduce a framework (in particular, an assurance

service) that provides assurance and “orchestration

capabilities” to achieve this.

There are two processes carried out by the

orchestration service:

• The collaborative creation of Templates to map

various types of decision support system outputs

into enforceable and monitorable actions

• The collaborative instantiation of these

Templates, for a specific set of decision support

system recommendations, in a given project,

into a set for enforceable and monitorable

actions.

Figure 3 illustrates the high level components of this

Assurance Service. We assume the scenario of an

enterprise, with a set of security and privacy

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

672

requirements, which are fed into a decision support

system in order to produce guidelines and

recommendations. In the context of this paper, the

requirements relate to a business process that needs

to be outsourced to external, cloud-based suppliers

or service providers.

Figure 3: Architecture for the Assurance Service (where

DSS = Decision Support System).

The suppliers are bound by service level agreements,

whose statements constitute restrictions and

obligations as to how the business process will be

carried out. The SLAs are fixed and are not

expected, under normal circumstances, to change.

We assume that various organisational decision

support systems interface with the orchestration

service by providing a “formal” representation of the

decisions that have been made, such as lists of

abstract, required actions and activities to be

enforced.

At the very core, within the Assurance Service,

there is an Orchestration Engine, driven by various

workflows (referred to as “workflow templates”)

that can be defined by administrators or as the result

of collaborative activities between various

stakeholders.

The Assurance Service, by means of the Mapper

component, maps the inputs from decision support

systems into suitable workflows that need to be

carried out by the orchestrator.

Specifically, the orchestrator is able to identify

potential issues in the refinement process, for

example due to lack of information, conflicting

inputs or system unavailability and raise exceptions

to be handled by users.

The purpose of the orchestrator component is to

determine whether (and how) a particular business

process can be outsourced subject to the constraints

of the SLAs, and issues appropriate monitoring and

enforcement commands to the external service

providers. The orchestrator also takes a set of

templates (whose exact format depends on the

intended usage scenario – we will not specify this

here) that define how each type of recommendation

produced by the decision support system is mapped

to a technical policy and/or action command to be

executed automatically. For example, a security

recommendation that requires a given data set to be

restricted for exclusive access by a specified group

of users will be mapped to a technical access control

policy (for example, in the standard eXtended

Access Control Markup Language – XACML), and

a set of commands that can be executed to enforce

this access control policy.

In the ideal situation, when all information is

available, the orchestrator (by using these

workflows) will automate the following steps:

• identify the suitable templates required to map

abstract actions into enforceable and/or

monitoring activities. We will refer to these as

“refinement templates”;

• collect from the internal knowledge base the

actual information necessary to instantiate the

templates (e.g. involved systems, required

configurations, involved access rights, etc.)

and instantiate them;

• interact with the relevant entities (people,

systems, applications, processes, etc.) to ensure

that specific actions/items are enforced or

monitored. This step could be mediated by

suitably deployed agents;

• collect and consolidate audit logs from these

various entities.

However, as previously mentioned, this is not so

trivial. The details required for mapping actions into

actionable items might not be available; specific

configurations might still be needed; specific inputs

and authorizations might need to be provided by the

key stakeholders.

In this context, the assurance service, by means

of the orchestrator and an associated Portal,

orchestrates the interactions between the various

stakeholders to obtain the relevant information. This

is again driven by a set of Templates indicating what

information is required to enable the mapping of

abstract decisions into monitorable and enforceable

policies/actions.

The relevant templates might have previously

built by using the same collaborative service, by

factoring in input from different stakeholders, on

how to effectively map specific types of decisions

support system recommendations into enforceable

and monitorable actions.

There might be situations where the relevant

templates are not available. In this case, a process is

DSS

Abstract

Decisions

Knowledge

Base

Tem p la tes

Collaboration Portal

Orchestrator

Logger

Workflows

Agents/

Instrumented

Systems/

Monitoring Systems

Assurance Service

Enforce/

Monitor

Actions

Stakeholders

Exception

Handler

SECURITYANDPRIVACYGOVERNANCEINCLOUDCOMPUTINGVIASLAsANDAPOLICY

ORCHESTRATIONSERVICE

673

initiated by the assurance service/orchestrator to

generate these Templates, by involving the relevant

stakeholders.

Whilst traditional workflows aim at carrying out

various business process steps, in this context the

orchestrator’s main objective is to:

1. enable the refinement of abstract decisions

made by a decision support system, by

integrating know-how from different sources

and triggering the relevant steps, including

interactions with people and systems;

2. support the creation of relevant templates, for

various types of decision support system

outputs.

The Portal is a collaborative web service where

various people in the organisation can register,

access various relevant information, based on their

roles (templates, knowledge bases, etc.), and

contribute to the specification of these information.

The Portal is not passive: it is used by the

orchestrator to require stakeholder interventions, if

necessary. As previously described, the orchestrator

(driven by workflow templates) will prompt the

stakeholders for the necessary information.

We envisage two main interaction mechanisms:

• Stakeholders are asked to intervene and

provide information based on need – i.e. during

the execution of workflows. This is pretty

much standard practice;

• The assurance service, via the portal, actually

provides a collaborative service where the

various involved people can interact upfront,

share information and collaborate to create the

various templates necessary during the

mapping process. In other words, this portal

provides an additional way to generate the

“templates”. These interactions might be

triggered by challenges raised by

administrators and decision makers rather than

just the orchestrations and/or involved

workflows.

In the latter case the assurance service and

orchestrator provide an active ecosystem where

various stakeholders, with different skills and

expertise, can collaboratively discuss and create

material that is relevant for the enforcement of

decisions, within the organisation.

4 REVIEW AND CONCLUSIONS

The main advantage of the orchestration service is

that it addresses the problem of enforcing and

monitoring decisions by:

• Integrating input and contributions of various

stakeholders, by means of an automated

process

• Enabling compliance with agreed decisions

Whilst common solutions in this space rely on

manual interventions and/or automated but very

specific solutions (with static knowledge bases valid

only in very restricted domains – subject to

expensive maintenance/extensions), the proposed

solution solves these problems by collaboratively

involving the various stakeholders in the process;

getting their input to update knowledge bases;

ensuring that templates, scripts and mapping

mechanisms evolve over time, based on needs.

ACKNOWLEDGEMENTS

We acknowledge the valuable input of Tomas

Sander, Prasad Rao and Richard Brown, whose

comments helped shape our ideas around the policy

orchestration service.

REFERENCES

Alavi, M., Leidner, D.E. 1999. Knowledge management

systems: issues, challenges, and benefits.

Communications of the AIS 1 (2).

Gartner. 2011. Magic Quadrant for Enterprise

Governance, Risk and Compliance Platforms.

Ghodsypour, S.H., O'Brien, C. 1998. A decision support

system for supplier selection using an integrated

analytic hierarchy process and linear programming,

International Journal of Production Economics,

Volumes 56–57, 20 September 1998, Pages 199-212.

ICO. 2009. Privacy Impact Assessment Handbook.

Available online at http://www.ico.gov.uk/upload/

documents/pia_handbook_html_v2/files/PIAhandbook

V2.pdf.

Jackson, M., Twaddle, G. 1997. Business Process

Implementation: Building Workflow Systems,

Addison-Wesley.

Padgham, L., Winikoff, M. 2004. Developing Intelligent

Agent Systems: A Practical Guide. Wiley-Blackwell.

Pearson, S., Rao, P., Sander, T., Parry, A., Paull, A.,

Patruni, S., Dandamudi-Ratnakar, V. and Sharma, P.,

2009. Scalable, Accountable Privacy Management for

Large Organizations, INSPEC 2009: 2

International

Workshop on Security and Privacy Distributed

Computing, Enterprise Distributed Object Conference

Workshops (EDOCW 2009), IEEE, pp. 168-175.

Turban, E., Sharda, R., Delen, D. 2010. Decision Support

and Business Intelligence Systems. Pearson.

CLOSER2012-2ndInternationalConferenceonCloudComputingandServicesScience

674
