Social Information Systems

The End of Shadow Applications?

Marc Quast

and Mark J. Handel

University of Grenoble, Campus C207, 220 Rue de la Chimie, 38400 Saint-Martin d’Hères, France

The Boeing Company, MC 7L-70, PO Box 3707, Seattle, WA 98124, U.S.A.

Keywords: Information Systems, Business Applications, Enterprise Architecture, Social Software Engineering.

Abstract: In large corporations, line-of-business organizations frequently introduce unofficial “shadow” applications

to work around the limitations of the established information system. This paper presents a software

architecture designed to alleviate this phenomenon, and reuses examples from a recent industry experience

report to demonstrate how shadow application proliferation could be avoided without sacrificing flexibility

and reactivity. We present the initial results of our prototype, and discuss the possibility of a social

information system designed to both reduce the present chaos and enable the cooperative design and

evolution of business applications.

1 INTRODUCTION

Delivering the right information at the right time to

the right persons is one of the most important

requirements of today’s business world (Spahn and

Wulf, 2009). Nevertheless, corporate information

systems are a widespread source of frustration

(Newell et al., 2007). Business units do not accept

the poor service provided by their IT departments

and build up independent IT resources to suit their

specific or urgent requirements (Zarnekow et al.,

2006).

As a result, information systems of large

corporations are a web of numerous applications. At

the center we find a fairly small set of stable and

robust enterprise applications. These are surrounded

by a larger set of semi-official applications and a

very large number of unofficial applications. We

adopt the term of shadow application proposed by

Handel and Poltrock (2010) for the last two

categories, i.e. applications introduced by business

units to satisfy requirements not met by official

applications.

Though the benefit of “getting the job done” is

sufficient to justify, and indeed pay for, their

existence, shadow applications raise serious

problems: duplicated and inconsistent data is

commonplace, and having critical information and

functionality scattered, unreachable and managed

outside of standard IT processes is obviously not

what comes to mind when envisioning a well-

structured and robust information system.

Building upon our industry experience

, this

paper proposes a potential solution. After a short

definition of shadow applications, their main

characteristics and the causes of their emergence, we

propose an alternative architecture for business

applications which could prevent the systematic

recourse to shadow applications in their vicinity,

using two use cases from (Handel and Poltrock,

2010) to illustrate its effects. We present our

prototype implementation and our first results, and

discuss the possibility of a social information system

designed to both reduce the present chaos and enable

the cooperative design and evolution of business

applications.

2 UNDERSTANDING

SHADOW APPLICATIONS

Shadow applications are characterized by their

purpose. If application A exists to work around the

limitations of application B, or if A’s features belong

in B according to its users, A can be considered a

The authors have a cumulated experience of over thirty years in

the development and operation of business applications in

industrial environments

Quast M. and J. Handel M..

Social Information Systems - The End of Shadow Applications?.

DOI: 10.5220/0003985000050015

In Proceedings of the 14th International Conference on Enterprise Information Systems (ICEIS-2012), pages 5-15

ISBN: 978-989-8565-10-5

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

shadow application. This partial definition illustrates

the subjective nature of the phenomenon.

Shadow applications are also characterized by

their ownership. If it is owned by the IT department,

it is an official application; otherwise it is a shadow

application. The important distinction is not so much

“IT or not IT” but “ownership by the actor

effectively using the application”. This allows the

owner to quickly adapt the tool without consulting

other parties or relying on the IT organization’s

priorities. It also provides him with full control over

the visibility of the data and access to features.

Individual spreadsheets meet this definition.

These are often used for simple data storage and

manipulation, as a substitute for more robust

business applications. This is a very common and

possibly dominant use case since their introduction

(Nardi and Miller, 1990), and Handel and Poltrock

(2010) qualify such spreadsheets as shadow

applications.

“Official” and “shadow” are relative concepts,

and apply recursively at various levels of an

organization. In other terms, multiple layers of

shadow applications exist, the final one being

personal applications.

Shadow applications are typically loosely

integrated with some official and other shadow

applications. However, manual synchronization is

not uncommon (Hordijk and Wieringa, 2010).

We define a shadow application as an application

which:

 works around another application’s limitations

and

 is both functionally and technically owned by the

organization using it.

Shadow applications are usually considered a

“necessary evil” (Hordijk and Wieringa, 2010).

Organizations cannot work without them, but would

prefer to avoid the data duplication they imply as

well as the burden they represent in development

and maintenance costs.

The benefits of shadow applications must

outweigh the drawbacks; otherwise line-of-business

organizations would not develop, deploy, and

maintain them. We will refer to the main benefits of

shadow applications as perceived by their owners as

the “AVI capabilities.”

 The owner has full Autonomy to implement new

features.

 The owner decides about Visibility of the

application to the larger organization.

 The owner can Integrate (manually or

automatically) with other applications.

2.1 Examples of Shadow Applications

A recent experience report contributes observations

about shadow applications in a 10 year engineering

project (Handel and Poltrock, 2010). In this paper,

we will use fictional examples derived from the

information disclosed in this report.

 “Luxury can report delays on process instances,

but not the reasons for these delays which are

managed by a shadow application.”

 “Sometimes the tasks tracked by Luxury were

informally decomposed into subtasks; (…) Luxury

had no provisions for this kind of task

decomposition.”

We make the assumption that Luxury tracks

requests, a common use case in engineering

environments. Figure 1 below shows a fictional

central database of an official application and two of

its shadow applications, managing delay analyses

and subtasks respectively.

Figure 1: Example of fictional official database and

associated shadow application data.

While spreadsheets are arguably the most

common form, shadow application architectures are

limited only by the owner’s resources, including

full-blown business applications and, more

fashionably, third-party applications in the “stealth

cloud”, i.e. cloud services being consumed by

business users without the knowledge, permission or

support of the IT department (Gotts, 2010.).

associated shadow applications

official application

REQUEST

id title state owner

planned

end

actual

end

123 assess technology T CLOSED Ruben 04.may 10.may

456 validate new supplier Z CLOSED Barney 27.aug 12.sep

789 align X with standard Y OPEN Johanna 10.oct

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

2.2 Causes of Shadow Application

Emergence

Shadow applications emerge to work around the

shortcomings of official applications (Zarnekow et

al., 2006). Thus we need to understand the causes

for these problems.

Large organizations are not consistent and

orderly systems. Referring both to groups and

individuals, Kling (1991) describes working

relationships as “multivalent with and mix elements

of cooperation, conflict, conviviality, competition,

collaboration, control, coercion, coordination and

combat (the c-words)”. Requirements from different

stakeholders are thus often divergent or conflicting,

which explains why the difficulty of requirements

engineering increases exponentially with the number

and diversity of participants. Ackerman (2000)

indicates that when there are hidden or conflicting

goals, people will resist articulating these. Under

such circumstances, it is a challenge to converge on

a consistent set of requirements and deliver a

working application at all. But widespread

dissatisfaction with the result is almost guaranteed

by construction.

As an aggravating factor, corporations are not

static. They must adapt to changes in their

environment like new markets, technologies or

regulations. Though the aforementioned c-words

impact is often obvious at the time of application

introduction, the continuous evolution of business

requirements turns this into a subtle though

continuous problem. Any change in any

stakeholder’s universe can invalidate the initial

compromises and demand new rounds of discussion,

yielding further dissatisfaction.

Besides inter-organization conflicts, some c-

words foster shadow application emergence by

themselves. A successful shadow application and the

knowledge it captures is usually highly visible

within an organization, and its ownership provides

recognition (competition) and power (control,

coercion).

There are other contributing factors. The

widespread practice of reducing IT costs lowers both

reactivity and quality of IT support, inciting business

units to help themselves (Hoyer and Stanoevska-

Slabena, 2008). Technical obsolescence, a

consequence of either respectable age or unfortunate

choice of foundation technologies, can make it

difficult to find the right skillset to implement

changes. This paper focuses on the following factors

leading to shadow application emergence.

 Business unit considers it impossible to converge

on a single set of requirements fulfilling all

stakeholders’ requirements.

 Business unit does not want to rely on slow or

expensive third parties.

 Business unit considers it in its best interest to

produce a new system they own.

2.3 Preventing Shadow Application

Proliferation

Our opinion is that with present software

architectures, no matter how carefully official

applications are crafted, over time they will spawn

shadow applications whenever resourceful

communities have urgent unsatisfied needs.

Our hypothesis is that if an application provides

the AVI capabilities, the need for shadow

applications is greatly reduced. Today’s software

architectures cannot provide these capabilities

because the components of a business application

(such as data elements, workflows, or forms) are

shared among organizations. This sharing is both the

main reason why business applications exist and the

main reason for the emergence of their shadow

counterparts. We therefore propose an application

architecture with a fundamentally new and different

sharing principle.

3 REQUIREMENTS FOR AN

ALTERNATIVE APPLICATION

ARCHITECTURE

In this section we attempt to express the AVI

capabilities as a set of requirements for an

application architecture, with the following

definitions.

 Actor designates an individual or a group of

individuals, for example the entire company, an

organization, department, project team, or

community.

 Elements are runtime application components,

like business entities (in our previous example a

“Request”), workflows, forms, reports, or even

configuration entries. With this definition an

Application is a collection of related Elements.

3.1 Functional Requirements

Our first two requirements cover the most central

operations in shadow application development.

SocialInformationSystems-TheEndofShadowApplications?

R1: Actors can extend existing Elements.

R2: Actors can add new Elements.

Example 1 below reuses an observation from

(Handel and Poltrock, 2010) to illustrate how an

application satisfying R1 and R2 could defuse the

need for shadow applications.

Example 1 – Luxury

The official application manages Request entities, with

among others attributes title, state and delay.

The “Quality” department needs to record the

reasons for delays when they occur. Using R2, they

introduce a new Element DelayAnalysis with attributes

like reasonForDelay and analyst and associations with

existing Element Request. Behind the scene, this

leverages R1 to extend the Request Element with the

reverse association delayAnalyses. This blends the new

Element and extensions with the original Luxury

entities thus enabling intuitive bi-directional

navigation.

Other operations are adding missing attributes to

an existing business element or adding more detailed

states in an existing workflow. Example 1 highlights

a new problem: the extensions are of interest only to

a subset of the application’s users, and may be

confidential. To avoid cross-Actor pollution and

conflicts, both R1 and R2 imply that Actors are

isolated from each other by default, which yields the

requirement R3.

R3: Actors have private spaces.

Elements are hosted in such private spaces and are

by default not visible outside of them. We call these

spaces Perspectives. In a typical enterprise setting,

today’s official applications would be Perspectives

providing ‘scaffolding’ Elements, i.e. skeletons of

business entities and associated high-level rules and

functionality. Organizations at various levels would

have their own Perspectives, hosting the extensions

and additional Elements reflecting their concerns

and level of detail. Individuals could likewise

replace their spreadsheets with private extensions

and Elements hosted in a private Perspective.

However, completely isolated Perspectives would

defeat the purpose of enterprise applications, which

yields R4.

R4: Actors can share the Elements they own.

In the report, Luxury refers to both a business process and

the supporting official application(s). We only refer to the

latter here.

Perspectives can make selected Elements visible,

either to everybody (“public”) or to a restricted set

of Perspectives. We call this operation export.

Obviously the previously mentioned official

Perspectives would export their Elements to all

users. And business-unit-level Perspectives would

export their Elements to the relevant Actors. Even

individuals can share their Elements with others.

It is interesting to note here that this empowers

the entire employee base to contribute to the overall

information system, which we think provides

significant benefits we will discuss later in this

paper. The downside is that this could lead to

cacophony through an overwhelming amount of

available Elements, dictating R5.

R5: Actors can select relevant Elements.

Thus, a symmetrical import operation is

necessary. An Actor must be able to select among all

Elements available to him only the ones he considers

relevant. Instead of building his environment from

scratch an Actor would inherit the Elements from

the groups he belongs to, but must be able to

unimport these if not relevant for him. Example 2

below, again from Handel and Poltrock (2010),

illustrates how R1-R5 could have avoided another

real-life shadow application.

Example 2 – Fallen

“Official application Fallen had produced a shadow

application which added translations into Japanese

next to English data fields.”

Extending existing entities with additional

attributes is a typical use case of R1. Such extensions

would be owned by the Japanese branch of the

company, and hosted on their servers in a Perspective

(R3) we can call http://fallen.acme.co.jp/Translations.

Employees of the Japanese branch would inherit

these extensions, and some groups or Japanese

employees could even choose to unimport the initial

English attributes (R5). The extensions could be

exported to other Japanese-spoken employees in other

regions (R4).

Our previous use of the term Application

encompassed a broad spectrum, from full-blown

enterprise systems to private spreadsheets. Likewise,

for Perspectives we envision a broad range from big

Perspectives hosting self-sufficient third-party

applications to tiny individual Perspectives with just

a few extensions replacing spreadsheets. Some

Perspectives may just factorize the optimal list of

import and unimport declarations for a given

organization or community.

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

3.2 Usability Requirements

A significant percentage of today’s shadow

applications are created by people without software

engineering skills using office software like

spreadsheets (Nardi and Miller, 1990). This

observation makes usability a key requirement.

R6: No programming is required for R1-R5.

The last item may sound like reviving the dream

of software without programmers. However, the

data-centric nature of business applications makes it

much less difficult for end-users to participate than

more feature-centric software; significant

contributions of entities, attributes, simple formulas

and associations can be made through a forms-based

interface, especially in the presence of example

instances (Markl, Altinel, Simmen and Singh, 2008).

Contributions are not limited to what can be done

by end-users through forms. A language-based

representation of perspectives and elements is still

necessary for professional software developers.

Even for business units, contractors and interns have

always been a means to get access to development

skills beyond their internal competence to

implement complex shadow applications. In a

perspective-centric architecture, such expert

contributions would still be possible, with the

benefit of being better integrated with the rest of the

information system.

4 CONCEPTUALIZATION

Figure 2 below shows the high-level meta-model of

our proposal. It is centered on a classical enterprise

directory component with Users and Groups.

Perspectives are hosted by Repositories.

Perspectives can define Fragments, which can be

either self-sufficient (R2) or extensions of a

Fragment from another Perspective (R1).

Repositories can live on different servers.

At runtime, a User opens a Session, which

determines a set of Perspectives – owned by the

User or inherited from the Groups he is member of.

This in turn determines a set of Fragments, which

can be woven into Elements. The Session becomes

the Application, tailored to the connected user’s

profile. We call this a virtual private application,

private because it reflects the user’s unique

combination of elements, virtual because it does not

exist outside of the session.

Figure 2: Meta-model of Perspective-centric architecture.

In a perspective-centric architecture, applications

are thus dynamically composed at runtime. Today,

commercial-off-the-shelf (COTS) applications need

to suit the requirements of a variety of customers

and provide some degree of flexibility through

configuration and customization mechanisms

(Brehm, Heinzl, and Markus, 2001). We consider

our proposal a generalization of these mechanisms

found in application platforms like issue-tracking,

PLM and ERP systems.

5 PROTOTYPE

We have designed and implemented a first prototype

of a perspective-centric system. Considering the

complexity of the general case of extensible

Elements, our prototype mainly focuses on data, i.e.

business entities.

5.1 End-user Experience

Our main objective was to verify that the dynamic,

perspective-centric nature of the system could be

made transparent to end-users during normal use.

The screenshots below show two different users

connected to a Luxury-like application, both

displaying a request object. The first user belongs to

the quality group and thus sees DelayAnalysis

objects, the second user is from the planning group

and sees SubTask objects.

It is important to stress the additive nature of the

system, as opposed to subtractive, i.e. filtering. In a

filtering approach, somewhere an Element would

exist with all attributes, which get filtered out

depending on the users’ profile. In our approach,

Fragments exist in various places and get pulled

together by the Session. The main visible difference

with a regular system is the presence of edit buttons,

which allow inspection and tailoring of the

connected user’s model as illustrated in the next

defines ►

repository

Repository

Actor

▲

owns

hosts ►

(un)imports ►

Perspective

Fragment

User Group

members

groups

directory

dynamic ui

repository

client session

repository

2 2

4 4

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

mechanism which composes Elements. Usage is

then similar to any distributed system, i.e. accessing

an object triggers several requests (4).

The communication between components is

standard REST over HTTP. The protocol has been

kept simple in order to enable integration of legacy

systems in a perspective-centric landscape through

the development of wrappers.

5.3 Limitation

The main conceptual limitation of our first prototype

is the focus on data only. Considering the centrality

of data in business applications, we think that the

results presented in the next section still represent a

significant contribution.

6 INITIAL RESULTS

From a technical point of view, the prototype has

demonstrated the feasibility of asynchronous

runtime composition of a data model, the

transparency for end-users during normal use, and

end-user update of the data model in their own

perspective.

As first proof-of-concept, we have instantiated

the prototype with a project tracking use case and a

configuration of 3 groups and 5 individuals with

different perspectives. The prototype has been able

to compose the individual models on the fly, proving

the validity of the concepts of Perspective and

Fragment.

We have presented this prototype to 8

information system professionals from 6 different

industrial and educational organizations. All of them

have over 20 years of experience and have witnessed

the emergence of numerous shadow applications.

Though they did raise some concerns, covered in the

discussion section of this paper, their reactions to the

proposal varied from fairly positive to enthusiastic. 4

out of 8 subjects have volunteered for evaluating the

prototype with real application data.

As a second proof-of-concept, we have

instantiated the prototype with the Luxury-like use-

case presented in previous sections of this paper.

The “Luxury” perspective and its associated

“quality” and “operations” perspectives have

allowed a unified representation of the three points

of view. We were able to walk through use cases of

both the Luxury and Fallen shadow applications, and

show that technically they would have been avoided

with a mature perspective-centric implementation.

The highly dynamic nature of the proposal

initially made all interviewed professionals

uncomfortable, illustrating the fairly conservative

attitude they adopt regarding the architecture of

business applications, particularly the data layer.

One manager has expressed a desire to restrict the

perspective-centric nature of an application to the

initial phases of its life, and to “freeze” the model

once it has been collaboratively built and validated.

This directly contradicted his earlier statements of

continuously evolving and conflicting requirements,

which he acknowledged. Experimentation with

industry datasets is now required to validate our

initial results.

7 DISCUSSION

Perspectives represent different, finer and more

connected information system grains than

applications. We think they allow an information

system to evolve organically in a unified and more

controlled way than today’s proliferation of shadow

applications, without sacrificing the business units’

ownership of their specific application elements. The

reactivity and autonomy their mission demands is

thus preserved.

7.1 Towards Social Information

Systems

A perspective-centric application architecture

represents a major shift of responsibilities from IT

departments towards the community of users, not

unlike the freedom spreadsheets have provided

(Nardi and Miller, 1990). An IT department’s main

responsibility would be to provide the platform on

which anyone (the IT department itself, but also

business organizations and individual employees)

could contribute elements in their area of expertise.

We think this could leverage the collective

intelligence (Surowiecki, 2004) and energy of

employees to collaboratively build and maintain the

corporate information system, in a form of internal

crowd-sourcing.

Considering today’s mostly feudal management

of information systems, this is a fairly disruptive

proposal. Indeed, during our interviews most

subjects have raised the concern that it could result

in chaos. This concern typically takes the official

applications as a reference, while in our opinion it

only represents the tip of the information system

iceberg. When including all shadow applications in

the picture, information systems today can already

not guarantee the overall consistency, and rely upon

SocialInformationSystems-TheEndofShadowApplications?

humans to keep the whole together. However, as one

architect interviewed observed, the chaos is often

feared to be in core business attributes. But these are

often the best-understood and least controversial of

the data elements; uncertainty is greatest on the

highly domain-specific attributes. By properly

segregating these into the correct perspectives,

overall uncertainty may actually be reduced.

Collecting all shadow application data in a

unified infrastructure may seem to aggravate

inconsistency, but in reality it just reveals the present

state. We think a unified infrastructure would

provide additional leverage to the previously

mentioned human factor in at least two ways.

In the consumer-space, “social” mechanisms like

tagging, rating, voting, and targeted sharing have

proven effective in organizing huge repositories of

consumer-contributed data (Surowiecki, 2008). In a

business environment, users could organize

application elements through similar mechanisms.

We think dealing with authenticated professionals is

an even more beneficial setting than the consumer

space for social technologies to apply, and envision

social information systems where elements are

contributed from the bottom up, shared with other

Actors, ranked and improved through social

feedback mechanisms and eventually gradually

“promoted” to more central perspectives.

This could result in the democratic (or

meritocratic) evolution of a corporation’s

application landscape, a generalization of today’s

frequently requested transfer of shadow applications

from business units to IT departments (Handel and

Poltrock, 2010).

As opposed to today’s situation where shadow

applications are mostly disconnected from their

parent applications and extremely heterogeneous in

their implementation, a unified architecture would

make the continuous evolution and divergence

observable. Indicators could be envisioned (number

of extensions, number of unimports…) and

dashboards built to monitor application evolution.

Pattern-matching techniques could be used to

automatically detect convergence opportunities

(Ahmadi, Jazayeri, Lelli and Nesic, 2008;

Sabatzadeh, Finkelstein and Goedicke, 2010) and

notify the owners of the candidate elements,

fostering convergence discussions.

7.2 Impact on Collaboration

Although the goal of the proposed architecture is to

make evolution a continuous process, introduction of

significant chunks still require traditional projects.

From a functional point of view, the painful and

hazardous process of elaborating the union of

divergent requirements could be replaced by the

identification of the intersection, containing only the

elements all stakeholders agree on, and then spawn

smaller groups to discuss the next level of detail,

thus reducing the risk of conflict and communication

overhead. We think Perspectives would thus contain

the various layers of boundary objects (Star, 1990)

around which people collaborate.

From a technical point of view, private spaces

could help in integrating running development

projects with live production environments,

facilitating continuous integration and delivery

(Fowler, 2010a). Boundaries between mockup,

prototype, beta and production environments could

be smoothened and concurrent development made

easier, as well as quick experimentation encouraged.

7.3 Evaluation in the Real World

One of the challenges of this work is to find suitable

ways to evaluate the underlying concepts of social

information systems. A standard approach would be

to deploy this with a small group of users, and study

its usage. However, if it were deployed in this

fashion, it would become just one more shadow

application, and many of the benefits of a

perspective-centric system would be lost. On the

other hand, this approach is new and unfamiliar

enough to both potential users and IT organizations

that a major implementation would be difficult to

accomplish. As illustrated by the aforementioned

discomfort of the IT professionals, this requires a

significant shift in thinking by IT and line-of-

business managers about how crucial data is stored

and managed. A successful perspective-centric

system requires not only technological

sophistication, but also a degree of organizational

change that is not always present (the “c-words”).

7.4 Challenges and Further Work

A real deployment of such a social architecture

would almost certainly exhibit a high degree of

coupling of its elements, making the system

vulnerable to the evolution of central elements.

However, since all dependencies are explicit,

evolution policies could be defined. For example, if

a high-level perspective deletes an element, it could

be marked as orphan and be proposed to adoption to

owners of perspectives which import or extend it.

We think a significant number of common

business application features can be implemented in

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

a generic way in the form of functional aspects

(Filman, Elrad, Clarke and Akşit, 2008) to be

applied by an end-user while building his model. For

example, if a particular attribute demands

traceability this could be a single checkbox on the

model’s form, a simple boolean annotation on the

model itself, and could tell a repository to produce

history records with timestamp, user, and previous

value. We are working on more complex aspects like

lifecycle management and authorization.

The manipulation of model and instances

through the same interface presents both the

opportunity to leverage contributions from people

without modeling skills and the risk to confuse them.

Beyond the prototype’s naïve forms for model

manipulation, we consider usability for contributors

with a broad spectrum of software skills a challenge.

For contributors with software engineering skills, the

development of robust application code on top of a

dynamic foundation is not trivial, and needs

appropriate programming language bindings.

Other challenges are not new but rather inherited

from the present situation. As an example, a user

could define an extension concatenating two

attributes, and export this extension to colleagues

who do not have permission to see the initial data.

This is similar to what happens when people extract

confidential data in today’s shadow applications,

breaking the initial authorization mechanism. A

perspective-centric system would actually improve

on this situation; by having a complete view of all

the attributes, a system would be able to detect and

warn about possible permission violations.

At a higher level, perspective-centric

architectures present a number of interesting

challenges, like monitoring and convergence

mechanisms, and adapting the consumer-space

social recommendation mechanisms to application

elements in a business environment.

8 RELATED WORK

We consider the work presented in this paper a novel

combination of existing approaches. Shadow

applications are a widely known but widely accepted

problem. They are frequently mentioned when

studying information system agility (Desouza, 2007)

or dissatisfaction with business applications (Hoyer

and Stanoevska-Slabena, 2008), but not always

considered as a problem (Handel and Poltrock,

2010).

Situational applications are enterprise

applications built on-the-fly by business units to

solve a specific business problem (Markl et al.,

2008), and can be considered a superset of shadow

applications. Situational applications have attracted

recent interest from enterprise mashup researchers

(Hoyer and Fischer, 2008) who aim at allowing end

users to integrate and combine services, data and

other content (Bitzer and Schumann, 2009) to bridge

the IT/business gap. Mashups can be interpreted as

an evolution of service-oriented architectures (Watt,

2007), which expose business functionality as

standard and composable services.

Mashups are part of the broader topic of end-user

development (Nestler, 2008); (Sutcliffe, 2005),

which advocates the empowerment of end-users to

implement their own specific requirements, and has

intensively studied spreadsheets (Nardi and Miller,

1990); (Spahn and Wulf, 2009) and more recently

collaborative and social aspects in enterprise settings

(Ahmadi et al., 2009).

Model-Driven Engineering (Schmidt, 2006)

elevates the level of abstraction at which software is

developed, turning models into central and

productive artifacts, with a specific models@runtime

branch focusing on model interpretation. The

Software Language Engineering (Kleppe, 2008) and

Domain-Specific Languages (Fowler, 2010a)

domains, related to MDE by the heavy reliance on

meta-models, focus on domain expert involvement

in software development and configuration through

specific textual representations.

The Component-Based Software Engineering

(McIlroy, 1968) community is actively researching

robust dynamic systems, where components can

appear and disappear during execution. It provides

foundation concepts and technologies for making a

social application cope with dynamic elements and

services of variable reliability.

Linked Data (Bizer, Heath, and Berners-Lee,

2009) integrates distributed, loosely coupled and

independently managed repositories of persistent

entities, but targets an internet-wide database and

mostly-read access.

Social Software Engineering focuses on the

understanding of the human and social aspects of

software engineering. It covers both the social

aspects in the software engineering process and the

engineering of social software (Ahmadi et al., 2008).

In the Requirements Engineering domain, Lohmann

et al. (2009) propose to apply social mechanisms

like voting and commenting. Studies on ViewPoints

(Sabetzadeh et al., 2010) have focused on capturing

divergent concerns but aim at reconciling these at

the specification and design level.

The tailoring of enterprise systems, from simple

SocialInformationSystems-TheEndofShadowApplications?

configuration to the modification of commercial

code, is a topic of sufficient complexity for (Brehm

et al., 2001) to propose a typology. Recent interest in

cloud computing has yielded research in multi-

tenancy (Jansen et al., 2010), a way to configure the

same software installation for various isolated

organizations.

9 CONCLUSIONS

In this paper we have presented an alternative

architecture for business applications designed to

reduce shadow application proliferation. We have

described the main characteristics of shadow

applications, the causes of their emergence, and have

proposed an architecture principle to defuse this

phenomenon based on an isolation mechanism we

call perspectives. We have presented our prototype,

our first results on real-life use cases and the

encouraging feedback it has received.

We have discussed our broader vision of a social

information system leveraging the collective

intelligence of an organization’s employees, and the

possibility of democratic evolution through the use

of social mechanisms.

We have no silver bullet claim, rather a

potentially interesting paradigm worth exploring.

We have no revolution claim either, merely an

original combination of existing approaches and a

generalization of business application configuration

mechanisms. This is enabled by continuously

growing processing power versus fairly stable core

requirements of business applications, a better

understanding of distributed systems, and recent

social technologies.

ACKNOWLEDGEMENTS

This work has been funded by Nano-2012 grant

MoDeSI. The authors would like to thank the

participating interviewees for their time and helpful

comments.

REFERENCES

Ackerman, M. S., 2000. The Intellectual Challenge of

CSCW: The Gap Between Social Requirements and

Technical Feasibility, Human-Computer Interaction,

Volume 15

Ahmadi, N., Jazayeri, M., Lelli, F. and Nesic, S., 2008. A

Survey of Social Software Engineering, IEEE/ACM

ASE - Workshops

Ahmadi, N., Jazayeri, M., Lelli, F. and Repenning, A.,

2009. Towards the Web of Applications: Incorporating

End User Programming into the Web 2.0

Communities, Proc SoSEA 2009, ACM

Bitzer, S. and Schumann, M., 2009. Mashups : An

Approach to Overcoming the Business/IT Gap in

Service-Oriented Architectures, Value Creation in e-

Business Management, ISBN 978-3-642-03131-1

Bizer, C., Heath, T. and Berners-Lee, T., 2009. Linked

Data - The Story So Far, International Journal on

Semantic Web and Information Systems

Brehm, L., Heinzl, A. and Markus, M. L., 2001. Tailoring

ERP Systems: A Spectrum of Choices and their

Implications, Proc HICSS, IEEE

Desouza, K. C., ed., 2007. Agile Information Systems :

Conceptualization, Construction and Management,

ISBN 978-0-7506-8235-0

Filman, R. E., Elrad, T., Clarke, S. and Akşit, M., 2008.

Aspect-Oriented Software Development, ISBN 0-321-

21976-7, Addison-Wesley, 2008

Fowler, M., 2010. Domain-Specific Languages, ISBN

978-0-321-71294-3, Addison-Wesley

Fowler, M. Continuous Delivery: Reliable Software

Releases through Build, Test, and Deployment

Automation, ISBN 978-0-321-60191-9, Addison

Wesley, 2010

Gotts, I., 2010. A New Cloud: The Stealth Cloud?,

http://www.cio.com/article/630164, October 2010

Handel, M. and Poltrock, S., 2010. Working Around

Official Applications : Experiences from a Large

Engineering Project, Proc CSCW, ACM Press

Hoyer, V. and Fischer, M., 2008. Market Overview of

Enterprise Mashup Tools, Proc ICSOC, Springer

Verlag

Hordijk, W. and Wieringa, R., 2010 Rationality of Cross-

System Data Duplication: A Case Study, Proc CAiSE,

Springer Verlag

Hoyer, V. and Stanoevska-Slabena, K., 2008. The

Changing Role of IT Departments in Enterprise

Mashup Environments, Proc SOC, Springer-Verlag

Jansen, S., Houben, G-J. and Brinkkemper, S., 2010.

Customization Realization in Multi-tenant Web

Applications: Case Studies from the Library Sector,

Proc ICWE, Springer-Verlag

Kleppe, A., 2008. Software Language Engineering:

Creating Domain-Specific Languages Using

Metamodels, ISBN 9780321553454, Addison-Wesley

Kling, R., 1991. Cooperation, Coordination and Control in

Computer-Supported Work,

Communications of the

ACM, Volume 34 Issue 12

Lohmann, S., Dietzold, S., Heim, P., Heino, N., 2009. A

Web Platform for Social Requirements Engineering,

Software Engineering Workshops 2009

Markl, V., Altinel, M., Simmen, D. and Singh, A., 2008.

Data Mashups for Situational Applications, Proc

MBSDI 2008, Springer-Verlag

McIlroy, D., 1968. Mass-Produced Software Components,

Software Engineering, Report on a conference

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems
