Benchmarking with TPC-H on Off-the-Shelf Hardware

An Experiments Report

Anna Thanopoulou

, Paulo Carreira

2,3

and Helena Galhardas

2,3

Department of Electrical and Computer Engineering, National Technical University of Athens, Athens, Greece

Department of Computer Science and Engineering, Technical University of Lisbon, Lisbon, Portugal

INESC-ID, Lisbon, Portugal

Keywords:

Database Benchmarking, Database Performance Tuning, Decision Support.

Abstract:

Most medium-sized enterprises run their databases on inexpensive off-the-shelf hardware; still, they need

quick answers to complex queries, like ad-hoc Decision Support System (DSS) ones. Thus, it is important

that the chosen database system and its tuning be optimal for the speciﬁc database size and design. Such

choice can be made in-house, based on tests with academic database benchmarks. This paper focuses on the

TPC-H database benchmark that aims at measuring the performance of ad-hoc DSS queries. Since ofﬁcial

TPC-H results feature large databases and run on high-end hardware, we attempt to assess whether the test

is meaningfully downscalable and can be performed on off-the-shelf hardware. We present the benchmark

and the steps that a non-expert must take to run the tests. In addition, we report our own benchmark tests,

comparing an open-source and a commercial database server running on off-the-shelf hardware when varying

parameters that affect the performance of DSS queries.

1 INTRODUCTION

In the day-to-day operations of a medium-sized en-

terprise, two types of queries are executed: Online

Transaction Processing (OLTP) and Decision Sup-

port (DSS). The former are basic information-retrieval

and -update functions. The latter are aimed at assist-

ing management decisions based on historical data. In

addition, DSS queries can be further categorized into

reporting and ad-hoc queries, depending on whether

they are executed routinely or in a spontaneous fash-

ion, respectively. As one would expect, the most chal-

lenging queries are the DSS ones as they are more

complex and deal with a larger volume of data; even

more so, ad-hoc DSS queries are challenging as they

do not allow for prior system optimization. Hence, it

is highly important to facilitate their execution.

The time needed to execute ad-hoc DSS queries

is above all related to the database design and size.

Furthermore, for a given database, time depends on

the choice of the RDBMS and its tuning. Given the

wide offer of database systems as well as their great

complexity, it is crucial yet not trivial for the enter-

prise to determine the best choice for its needs, both

in terms of price and in terms of performance. There-

fore, it would be very helpful to realize a quantitative

comparison of database systems performance under

various comparable conﬁgurations, possibly using a

benchmark.

The Transaction Processing Performance Council

(TPC) benchmark TPC-H sets out to model a busi-

ness database along with realistic ad-hoc DSS ques-

tions. It has been extensively used by database soft-

ware and hardware vendors as well as researchers

(Somogyi et al., 2009; Guehis et al., 2009). However,

TPC-H ofﬁcially published results refer to very large

databases running on high-end hardware that are dif-

ﬁcult to compare to the reality of a small enterprise.

Moreover, understanding TPC-H requires signiﬁcant

technical expertise and, to the best of our knowledge,

no step-by-step guide exists in literature, apart from

generic guidelines for benchmark execution (Oracle,

2006; Scalzo, 2007).

This paper examines whether TPC-H can be used

as a tool by small enterprises as well as which would

be the best way to do so. Speciﬁcally, our contribu-

tions are: (i) a comparison of the performance of a

commercial and an open-source database system ex-

ecuting a small-scale TPC-H test under various com-

parable conﬁgurations on off-the-shelf hardware; and

(ii) insights into the tuning parameters that inﬂuence

DSS performance at this scale.

205

Thanopoulou A., Carreira P. and Galhardas H..

Benchmarking with TPC-H on Off-the-Shelf Hardware - An Experiments Report.

DOI: 10.5220/0004004402050208

In Proceedings of the 14th International Conference on Enterprise Information Systems (ICEIS-2012), pages 205-208

ISBN: 978-989-8565-10-5

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Complete process for running the TPC-H tests. The term query stream refers to a sequential execution of each of

the 22 TPC-H queries, in the order speciﬁed by TPC.

2 AN OVERVIEW OF TPC-H

The TPC-H benchmark models the activity of a prod-

uct supplying enterprise. For that purpose, it uses a

simple database schema comprised by eight base ta-

bles. Tables have different sizes that change propor-

tionally to a constant known as scale factor (SF). The

available scale factors are: 1, 10, 30, 100, 300, 1000,

3000, 10000, 30000 and 100000. The scale factor de-

termines the size of the database in GB. Tables are

populated using DBGEN, a data generator provided

in the TPC-H package to populate the database tables

with different amounts of synthetic data.

The benchmark workload consists of 22 queries,

representing frequently-asked decision-making ques-

tions, and 2 update procedures, representing periodic

data refreshments. The update procedures are called

refresh functions. From a technical standpoint, the

queries include a rich breadth of operators and se-

lectivity constraints, access a large percentage of the

populated data and tables and generate intensive disk

and CPU activity. The TPC-H workload queries are

deﬁned only as query templates by TPC. The syntax

is completed providing random values for a series of

substitution parameters, using QGEN, an application

provided in the TPC-H package.

2.1 TPC-H Tests

TPC-H comprises two tests: the load test and the

performance test. The former involves loading the

database with data. The latter involves measuring the

system performance against a speciﬁc workload. As

soon as the load test is complete, the performance test,

which consists of two runs, can start. Each run is an

execution of the power test followed by an execution

of the throughput test. The power test aims at mea-

suring the raw query execution power of the system

with a single active session. This is achieved by se-

quentially running each one of the 22 queries. The

throughput test aims at measuring the ability of the

system to process the most queries in the least amount

of time, possibly taking advantage of I/O and CPU

parallelism. Thus, the throughput test includes at least

two query sessions that run in parallel. The minimum

number of query streams is speciﬁed by TPC and in-

creases together with the scale factor. Figure 1 illus-

trates the steps for running a complete TPC-H test.

2.2 Performance Metrics

After running the tests, we get three types of timing

measurements: the database load time, the measure-

ment interval and the timing intervals. The measure-

ment interval is the total time needed to execute the

throughput test. The timing intervals are the execu-

tion times for each query or refresh function. Next,

these timing measurement results must be combined

to produce global, comparable metrics. To avoid con-

fusion, TPC-H uses only one primary performance

metric indexed by the database size: the compos-

ite query-per-hour performance metric represented as

QphH@Size, where Size represents the size of data in

the test database as implied by the scale factor. This

metric weighs evenly the contribution of the single

user power metric (processing power metric repre-

sented as Power@Size) and the multi-user through-

put metric (throughput power metric represented as

T hroughput@Size). Finally, the price/performance

metric represented as Price − per − QphH@Size

serves to make a price/performance comparison be-

tween systems.

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

206

Table 1: TPC-H full test results for increasing memory size. In SQL Server, we varied the total server memory; in MySQL,

the buffer and sort memories, with a 3:1 ratio as recommended by MySQL developers. Fill factor is kept at 90% for SQL

Server and 15/16 (default) for MySQL. Page size is kept at 8KB (which is the default for SQL Server) for both systems.

Memory Size Test

total server memory 16 MB 64 MB 128 MB 256 MB 512 MB 768 MB 1024 MB

load test

SQL Server 46min 20min 19min 17min 16min 16min 36min

MySQL 48min 23min 20min 16min 16min 14min 57min

performance test

SQL Server 4h54min 1h13min 1h 52min 41min 40min 1h9min

MySQL 5h32min 1h28min 1h13min 1h2min 56min 54min 1h44min

QphH@1GB

SQL Server 19.13qph 78.55qph 90.20qph 102.30qph 130.76qph 131.80qph 86.03qph

MySQL 17.41qph 75.70qph 79.84qph 89.77qph 103.67qph 105.10qph 70.63qph

Price-per-QphH@1GB

SQL Server 73.08$ 17.80$ 15.49$ 13.67$ 10.69$ 10.61$ 16.25$

MySQL 28.72$ 6.60$ 6.26$ 5.57$ 4.82$ 4.76$ 7.80$

3 EXPERIMENTS

The goal of our experiments was to showcase a set

of useful TPC-H tests that any small enterprise could

perform in order to choose the database system and

tuning conﬁgurations that offer optimal ad-hoc DSS

performance in their system. In addition, we ran these

tests ourselves on off-the-shelf hardware, aiming at

some take-away rules-of-thumb for choosing between

a commercial (SQL Server 2008) and an open-source

(MySQL 5.1) database system and optimizing tuning

for DSS queries at this scale.

We are interested in the characteristics of ad-hoc

DSS workloads and the tuning parameters that affect

their performance, for a given database. Since DSS

queries deal with large amounts of data within scans,

sorts and joins, the size of the buffer pool and the sort

buffer play an important role. Following the same

logic, the ﬁll factor and the page size can also in-

ﬂuence performance, as they can contribute to more

rows per page thus keeping more sequential data in

the data cache.

However, not all these parameters can be set by the

user in each of the database systems at hand. In SQL

Server, it is not possible to set the size of the buffer

pool or the sort buffer; only the total size of mem-

ory that the system can use can be set, by determining

its minimum and maximum values. MySQL, on the

other hand, allows to set a speciﬁc size for the buffer

pool and the sort buffer. Also, while SQL Server op-

erates with a ﬁxed page size of 8 KB, in MySQL the

user can set the page size to 8, 16, 32 or 64 KB. Fi-

nally, in SQL Server it is possible to specify the ﬁll

factor for each page, while MySQL manages the free

space automatically, with tables populated in sequen-

tial order having a ﬁll factor of

/16.

In light of these differences, we decided to run two

general types of tests: the memory size test and the

number of rows per page test. Tables 1, 2 and 3

Table 2: TPC-H full test results for increasing ﬁll factor

in SQL Server. Page size is kept at default value of 8KB.

Memory size is set at a medium value of 128KB.

MS SQL Server- Number of Rows per Page Test

ﬁll factor 40% 60% 80% 100%

load test 27min 22min 20min 19min

perf. test 2h2min 1h9min 1h3min 59min

QphH@1GB 34.59qph 80.10qph 89.34qph 91.58qph

PPQphH@1GB 40.42$ 17.45$ 15.65$ 15.23$

Table 3: TPC-H full test results for increasing page size

in MySQL. Fill factor is kept at default value of 15/16.

Total memory size is set at a medium value of 128KB,

with a buffer/sort memory ratio of 3:1 as recommended by

MySQL developers.

MySQL- Number of Rows per Page Test

page size 8 KB 16 KB 32 KB 64 KB

load test 20min 18min 17min 17min

perf. test 1h13min 59min 52min 50min

QphH@1GB 79.84qph 92.41qph 106.20qph 109.38qph

PPQphH@1GB 6.26$ 5.41$ 4.71$ 4.57$

show the test results. For the number of rows per page

test, note that the resulting range of number of rows

per page is different for the two database systems, but

that serves exactly the purpose of verifying whether

allowing the user to specify much larger page sizes

gives MySQL an advantage.

In the interest of simulating the environment of a

smaller enterprise, we chose inexpensive off-the-shelf

hardware (an AMD Athlon processor with 1GB of

RAM and a SATA 80 GB hard disk) and the lowest

possible scale factor (yielding a 1 GB database). We

ﬁnd it interesting to provide some results with a lower

scale factor, as the only available ones to date are the

ofﬁcial TPC-H results starting at 100 GB. Finally, for

the price/performance metric calculations, we consid-

ered the hardware cost to be approximately 500$ and

the software cost to be the current price of 898$ for

SQL Server 2008 (circa 2010) and 0$ for MySQL 5.1.

BenchmarkingwithTPC-HonOff-the-ShelfHardware-AnExperimentsReport

207

Figure 2: Inﬂuence of memory size. Larger bubbles repre-

sent greater price per query per hour.

Figure 3: Inﬂuence of data per page (product of page size

and ﬁll factor). Larger bubbles represent greater price per

query per hour.

3.1 Discussion

As illustrated in Figure 2, in the case of memory

size test, for both database systems performance im-

proves dramatically as we move from 16 to 768 MB

of memory. The system ends up reaching its full po-

tential around 512 MB; moving to 768 MB does not

make much difference, and reaching 1024 MB actu-

ally leads to a performance decrease. In this case,

the server allocates all physical memory to the cache

causing part of the latter to be on virtual memory thus

triggering further I/O operations.

For the same memory size, increasing either the

page size or the ﬁll factor improves performance, as

illustrated in Figure 3. This makes sense because in

full scans relevant data are next to each other; thus,

the more data per page the less I/O operations and the

better the performance. Increasing the page size is

less effective than increasing the ﬁll factor, as seen by

the trendlines steepness in Figure 3 for MySQL and

SQL Server respectively. In any case, increasing the

memory size has an inﬂuence that exceeds both those

of increasing the page size and the ﬁll factor.

In addition, it is clear that, for approximately the

same conﬁgurations, the performance of MySQL is

slightly worse. This may mean that there are other

tuning parameters that cause performance deteriora-

tion when left in their default values. Most likely,

however, this performance difference indicates the su-

periority of SQL Server query optimizer when dealing

with complex queries.

Finally, even though the tests run faster in SQL

Server, the price/performance metric favors MySQL

by far. The additional 898$ for SQL Server do not

seem to be worthy for such low-scale needs.

4 CONCLUSIONS

We can conclude that the TPC-H test is meaning-

fully downscalable. Even with a low scale factor, we

could still observe differences between different sys-

tems and conﬁgurations. However, our intuition is

that its set-up time and complexity make the bench-

mark an unlikely choice for a medium-sized enter-

prise without a team of experts.

Running TPC-H motivated us to look into the fac-

tors that inﬂuence the performance of DSS queries.

We concluded that the most inﬂuential tuning option

is undoubtedly the memory size. Yet, other parame-

ters (ie. page size, ﬁll factor) also inﬂuence perfor-

mance.

Since the systems do not have identical tuning op-

tions, it is hard to ascertain whether we tuned them

fairly. For similar tuning, MySQL is consistently

slower than SQL Server. We think this is due to differ-

ent query optimizer philosophies. Yet, MySQL may

take a little longer to execute the TPC-H tests but it

has a higher price/performance ratio. If not chasing

optimal performance, it is a viable alternative.

REFERENCES

Guehis, S., Goasdoue-Thion, V., and Rigaux, P. (2009).

Speeding-up data-driven applications with program

summaries. In IDEAS’09, 2009 Int’l Database En-

gineering and Applications Symposium. ACM Press.

Oracle (2006). Conducting a data warehouse benchmark.

Scalzo, B. (2007). Top 10 Benchmarking Misconceptions.

Quest Software, 121007 edition.

Somogyi, S., Wenisch, T., Ailamaki, A., and Falsa, B.

(2009). Spatio-temporal memory streaming. In

ISCA’09, 36th Annual Int’l Symposium on Computer

Architecture. ACM Press.

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

208
