An Outline of Development Process Framework for Software

based on Open-source Components

Jakub Swacha, Karolina Muszyńska and Zygmunt Drążek

Institute of Information Technology in Management, University of Szczecin, Mickiewicza 64, 71-101 Szczecin, Poland

Keywords: Open-source Software, Software Adaptation, Development Methodology.

Abstract: The open-source community produces a wide range of software products every year. However, there are

often significant differences between the set of functionalities and/or non-functional requirements demanded

by the end-users and what the available software offers. Therefore, often an open-source system cannot

simply be adopted; it has to be adapted. In this paper we propose a new process framework for adapting

open-source software. We call it FEChADO which is an acronym of the six steps it consists of: Find

available solutions, Evaluate solutions from the list, Choose the most appropriate solution, Adapt the

solution, Develop new modules, Obtain users’ feedback. The framework is a direct result of our practical

experiences from developing software based on open-source components.

1 INTRODUCTION

1.1 Motivation

The open-source software (OSS) becomes

increasingly popular and open-source solutions can

be found for many applications. However, ready-

made open-source solutions rarely fully meet the end

users’ requirements. Therefore, most of them require

adaptation in order to make the users satisfied.

Although there is vast literature on software

development process, and significant literature on

selecting open-source software (to be discussed in

section 2), until now little has been written on the

process of developing software based on open-

source components, where it is important both to

choose the most appropriate existing solution and to

adapt it to the requirements of the specific end users.

1.2 Problem Setting

We understand adapting OSS as tailoring it to the

needs of a specific end-user or a group of them. The

permission for users to modify code for private

purposes is a core property of the open-source

software. Such modifications are rarely useful for

other users, so usually there is no reason for further

redistribution of the modified software, and the

relevant license requirements do not matter.

Otherwise, contributing it to the community should

be considered with all such requirements met.

1.3 Approach

We assume open-source software adaptation to be a

repeatable process, hence a framework can be

defined for its efficient execution. Such a framework

could be based on theoretical inference starting with

requirements, or obtained by generalization of

practical experiences. We chose the latter and use

observations made during our involvement in OSS

adaptation projects (see, e.g., Swacha et al., 2011).

We consider six main stages that form the

development process framework, describing an

exemplary method of their implementation. The

proposed framework can be seen as high-level and

flexible as it does not enforce a specific method for

any of the stages; any method is suitable for use

provided it accepts the available inputs and produces

the required outputs.

1.4 Contributions

Our main contribution is the development process

framework that can be used in various organizations

for adapting open-source software.

2 RELATED WORK

Before formulating the proposed process framework

183

Swacha J., Muszy

nska K. and Dr ˛a

zek Z..

An Outline of Development Process Framework for Software based on Open-source Components.

DOI: 10.5220/0004005001830186

In Proceedings of the 14th International Conference on Enterprise Information Systems (ICEIS-2012), pages 183-186

ISBN: 978-989-8565-11-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

numerous research findings, existing solutions and

scientific papers were verified and examined.

The QSOS method for qualification and selection

of open source software (Atos Origin, 2006) is

performed in four stages: definition of frames of

reference, evaluation of software by identifying its

main characteristics, defining its functional coverage

and risks, qualification of the software using filters

to translate needs and constraints to the selection of

most suitable solution, and selection of software

based on the outputs of the previous stages.

M. Cabano et al. (2007) based their context

dependent evaluation methodology on common

structural pattern shared by most widely known

evaluation models like Open Source Maturity Model

by B. Golden (2005), or Business Readiness Rating

for Open Source by Carnegie Mellon West and Intel

(OpenBRR, 2005). The assessment process of the

context dependent methodology is composed of:

context analysis, preliminary selection, and filtered

selection.

R. Galoppini (2011) in his pragmatic

methodology, indicates the best sources to find OSS

and lists evaluation criteria to be applied.

Open-source software evaluation process

described by D.A. Wheeler (2011) consists of four

steps: identify candidates, read existing reviews,

compare the leading programs’ attributes to the

needs and analyze the top candidates in more depth.

A bit different approach, which concentrates on

the software quality is described in a paper by G.

Polancic et al. (2004). It is based on multiple criteria

of quality, that can be checked using accessible

quantitative data.

The main goal of the abovementioned OSS

evaluation methods and frameworks is to identify,

assess, sometimes also compare, and select open

source products. The proposed FEChADO

framework concentrates on software development

process based on existing OSS components, it

assumes that the OSS evaluation process must be

followed by additional adaptation and development

phases.

3 FEChADO FRAMEWORK

We call our process framework FEChADO which is

an acronym of the six steps it consists of (see Fig. 1).

Find available solutions

(specify requirements & list candidates)

Evaluate solutions

(specify criteria, filter & rank candidates)

Choose the best solution

(discuss & choose)

Adapt the selected solution

(core + add-ons + modifications)

Develop new modules

(develop & possibly publish)

Obtain users’ feedback

(ask & improve)

Figure 1: Overview of the FEChADO framework.

3.1 Stage 1: Find Available Solutions

Phase 1.1: Specifying Requirements. In the first

step, the set of functionalities and non-functional

requirements of the end-users has to be defined.

If the general description of the software fits into

an established software category, a list of suggested

requirements may be composed, based on

characteristics of software belonging to that

category. Otherwise, a brainstorming session

involving both designers and users can be organized

to obtain such list.

This list is then used as a base for a questionnaire

to be filled in by the end users. They value each

proposal and are also asked for their own proposals

that were not mentioned in the questionnaire.

The results from the questionnaires are then

processed and analyzed in order to obtain a list of

requirements arranged in three groups: (1) core

requirements (that must be met), (2) additional

requirements (that should be met), (3) special

requirements (that only specific types of end users

believe should be met). The list is then presented to

the end users for correction and re-evaluation.

Phase 1.2: Listing available Solutions. There

are various sources that can be searched for

solutions that possibly match the specified

requirements (see, e.g., Golden, 2005). We

recommend starting with searching open source

project portals, such as sourceforge.net and

freecode.com, as well as using web search engines.

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

184

Multiple search phrases should be tried, as different

words may be used to describe equivalent

functionalities. The search should be continued until

no more matching solutions can be found.

3.2 Stage 2: Evaluate found Solutions

Phase 2.1: Specifying evaluation Criteria. The

evaluation criteria are specified by assigning

measurable fulfilment levels to the requirements.

Every criterion should have at least one defined

fulfilment level: acceptable; that is, solutions

evaluated below this level must not be chosen.

However, there could be more levels defined, so that

solutions that pass the acceptable level could be

compared between each other. A satisfactory level

can be defined, such that no solution can be

evaluated as better with regards to a given criterion

if they both attain this level.

The evaluation criteria can be grouped,

depending on their measurability, into: (1) objective

and easily measurable, (2) objective and not easily

measurable, (3) subjective.

The weights of criteria may be established using

a simple ranking done by end users, or using more

sophisticated approaches, like pair-wise comparisons

(see, e.g., the AHP method – Saaty, 1980).

Phase 2.2: Preliminary evaluation. The goal of

the preliminary evaluation is to shorten the candidate

list by removing software that does not attain

acceptable level for criteria based on the core

requirements. In this phase only objective and easily

measurable criteria should be considered.

Phase 2.3: Main evaluation. This phase starts

with eliminating software that does not attain

acceptable level for objective criteria (now also not

easily measurable) based on the core requirements.

Both the criteria fulfilment levels and criteria

weights are scaled and normalized, and then used to

construct an aggregate measure for each candidate

solution and group of criteria (core criteria,

combined core and additional criteria, and all

criteria). One or two highest-evaluated solutions are

chosen for each group of criteria.

Phase 2.4: In-depth evaluation. The goal of this

phase is to prepare full information that will be

considered for making the choice, including

subjective criteria. Evaluation is done by several

people, working as a team or independently – the

results are averaged in the second case. In contrast to

the two previous phases, the end users should be

involved in the evaluation.

3.3 Stage 3: Choose the Most

Appropriate Solution

Phase 3.1: Discussion of evaluation Results. A

meeting of the stakeholders should be organised that

starts with presentation of the evaluation results after

which every person should express their opinion and

provide additional information that could impact the

choice, e.g.:

 the end users should point to drawbacks or

special advantages of respective solutions,

 the invited experts should clarify, if the

mentioned drawbacks are specific to solutions,

or they are merely results of improper usage,

 the members of the development team should

declare if they are capable of fixing the

drawbacks, and what the cost would be ,

 the sponsors of the project should declare if they

will contribute necessary resources.

Phase 3.2: Making the Choice. The decision on

choosing the solution for adoption is made by the

sponsors of the project. It should be based on the

results of the evaluation process, but if two or more

solutions were evaluated closely, the decision

maker(s) should pick one of them using their own

opinion rather than the aggregated measure value.

3.4 Stage 4: Adapt the Solution

Adapting the solution consists of acquiring,

installing, and configuring the core solution, then the

required add-ons, and, finally, applying

modifications required for the solution to meet the

requirements.

What makes the modifications applied at this

stage distinctive from those of the next stage is that

they are aimed at the requirements of the specific

end user group, and as such they will rarely be

useful for other users, and that they are not usually

defined as a separate entity (module or even

function), being often a list of file/line updates.

Every modification made to the original solution

must be explained in the technical documentation of

the final product, in terms of its purpose, relation to

other modifications, assumed conditions and

possible risk factors. Regression testing should

assure that the modification does not hurt stability,

security or degrade performance of the system.

3.5 Stage 5: Develop New Modules

Sometimes, the modifications related to a certain

group of requirements can be implemented as a new

module for the chosen solution.

AnOutlineofDevelopmentProcessFrameworkforSoftwarebasedonOpen-sourceComponents

185

Developing a module should be done keeping

straight with the guidelines defined in the solution’s

documentation. The new module should integrate

seamlessly with the solution, and be configurable,

preferably from the solution’s administration panel,

if such exists.

If the organization’s internal regulations permit,

and there are no redistribution constraints in the

license of the original solution that could be

violated, it should be considered to contribute the

module to the open-source community.

Having decided to publish the new module, it

should be pruned from elements that have any value

only for the sponsor’s organization. Depending on

the number and character of such elements, it may

be accomplished in three ways: (1) by turning the

adaptation elements into a profile of module

configuration settings, (2) by moving part of

functions to an additional module, only for internal

usage, (3) by forking the module into internal (full)

and external (limited) versions.

If the module published as open source gains

popularity, it may even attract external developers

who may improve it. In such case, it should be

checked if the improved version of the module could

be used instead of the one developed internally.

3.6 Stage 6: Obtain Users’ Feedback

It is important that the end users’ opinions on the

final product are gathered. The opinions that pertain

to the implemented modifications can be used by the

internal development team to improve them.

Contrasting opinions should be resolved via

discussion with the involved users.

The opinions that refer to the chosen solution

should be passed to its original developers,

especially bug reports and feature requests.

In order to facilitate the feedback process, a web

form should be made available for the end users, so

that their opinions could be reported easily.

4 PRACTICAL EXPERIENCES

The development process framework outlined in this

paper has been applied in a complex project

(Swacha et al., 2011), consisting of five components,

four of which were adaptations of open source

systems. The core of the framework was created

after developing the first component of the

mentioned project, and applied, in limited or full

extent, to the remaining ones. The development of

the framework was evolutionary: each application

resulted in experiences that allowed for further

improvement of the framework.

The framework has been positively evaluated by

the respective decision makers and developers.

5 CONCLUSIONS

We have outlined a framework for software

development process based on open-source

components.

The framework described in this paper can be

applied to any software development process that

involves OSS adaptation. It helps achieve quality of

the final products at the same time being simple and

non-obtrusive.

REFERENCES

Atos Origin (2006). Method for Qualification and

Selection of Open Source software, version 1.6.

Retrieved Feb 1, 2012 from www.qsos.org/download/

qsos-1.6-en.pdf.

Cabano, M., Monti, C., Piancastelli, G. (2007). Context-

Dependent Evaluation Methodology for Open Source

Software. In Feller, J. Fitzgerald, B., Scacchi, W. and

Sillitti, A. (Eds.), Open Source Development, Adoption

and Innovation (pp. 301–306). New York: Springer.

Galoppini, R. (2011). How to find an Open-Source

Alternative to a Commercial Software. Retrieved Feb

1, 2012 from http://www.masternewmedia.org/open-

source-software-tools-and-directories-where-to-find-

them-how-to-evaluate-them.

Golden, B. (2005). Succeeding with Open Source. Boston:

Addison-Wesley.

OpenBRR (2005). Business Readiness Rating for Open

Source. Retrieved Feb 1, 2012 from http://docencia.

etsit.urjc.es/moodle/file.php/125/OpenBRR_Whitepap

er.pdf.

Polancic, G., Horvat, R. V., Rozman, T. (2004).

Comparative assessment of open source software

using easy accessible data. In Luzar-Stiffler, V. and

Dobrić, V. H. (Eds.), Proceedings of the 26th

International Conference on Information Technology

Interfaces (pp. 673–678). Zagreb: IEEE.

Saaty, T. L. (1980). The Analytic Hierarchy Process. New

York: McGraw-Hill.

Swacha, J., Muszyńska, K., Komorowski, T. and Drążek,

Z. (2011). Development and maintenance of a multi-

lingual e-Tourism website on the example of

BalticMuseums 2.0 Online Information Platform.

Information Management, 3, 237–246.

Wheeler, D. A. (2011). How to Evaluate Open Source

Software / Free Software (OSS/FS) Programs. Retrie-

ved Feb 1, 2012 from http://www.dwheeler.com/oss

_fs_eval.html.

ICEIS2012-14thInternationalConferenceonEnterpriseInformationSystems

186
