Transforming SQLITE to Run on a Bare PC

Uzo Okafor, Ramesh K. Karne, Alexander L. Wijesinha and Bharat S. Rawal

Department of Computer and Information Sciences, Towson University, Towson, Maryland 21252 U.S.A.

Keywords: Code Transformation, Bare PC Systems, Bare Machine Computing, SQLITE, Database Systems.

Abstract: SQLITE is a popular small open-source database management system with many versions that run on

popular platforms. However, there is currently no version of the SQLITE application that runs on a bare PC.

Since a bare PC does not provide any form of operating system (or kernel) support, bare PC applications

need to be completely self-contained with their own interfaces to the hardware. Such applications are

characterized by small code size, and have inherent security and performance advantages due to the absence

of a conventional operating system. We describe a general transformation approach that can be used to

transform the SQLITE application to a lean SQLITE application that runs on a bare PC. We present the

current state of this work and identify several important issues that need further research.

1 MOTIVATION

We have developed a variety of bare PC applications

(Appiah-Kubi, 2009 and He, 2008) that run on a

machine without using any operating system (OS),

or kernel. Bare PC systems are also different from

embedded systems. The bare PC architecture is

simple, application-centric, extensible, and lean and

independent of any operating environment. At

present, it is based on a single programming

language C++ with some low-level interface code

written in C or assembly language. The SQLITE

application is a system-level program with

reasonable complexity. It is written in C. The

developers of this application created an

amalgamation package, delivered as two source files

with all environment parameters included in them.

This application is suitable for transformation to a

bare PC, as it is complex, and provides insight for

developing an automated tool for transforming other

applications.

2 INTRODUCTION

The SQLITE application in amalgamation form for

Windows OS (Operating System) has two source

files (shell.c, sqlite3.c) and two header files

(sqlite3.h, sqlite3ext.h). The sizes of shell.c and

sqlite3.c are 86, 016 and 4,323,826 bytes

respectively. The total number of lines of code in

both source files is 129,003, of which 55,691 are

commented lines of code and 40,297 are executable

statements. The code runs in the Microsoft Visual

Studio 2010 Express environment. When the

application runs, a user can perform standard

database functions including those to create tables,

insert data and query a database. The output will be

displayed in a Microsoft Window (there is no

graphics interface). Our task is to transform this

application code so that it will run on a bare PC

without using any operating system/kernel or

embedded software.

This transformation process is different from the

translation done by compilers, interpreters,

programming language parsers and other tools used

for porting. The primary issue involved in

transforming conventional applications to bare

applications is that a bare application needs to run as

a completely self-supporting entity. Transforming

the code involves eliminating operating system

dependencies and system calls from the code, and

using a direct hardware API that is based on the

Bare Machine Computing (BMC) paradigm (Karne

2005 and Khaksari 2012). This paradigm supports

the development of lean, minimal and low cost

applications as proposed in (Soumya, Guerin and

Hosanagar 2011).

There is a considerable amount of work relating

to code transformation and translation e.g., Intel x86

programs can be translated from binary code to

311

Okafor U., K. Karne R., L. Wijesinha A. and S. Rawal B..

Transforming SQLITE to Run on a Bare PC.

DOI: 10.5220/0004015403110314

In Proceedings of the 7th International Conference on Software Paradigm Trends (ICSOFT-2012), pages 311-314

ISBN: 978-989-8565-19-8

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

ARM and Alfa binaries with reasonable code

densities and quality (Hwoang, Lin and Chang,

2010). In (Schoeberl, Korsholm, Kalibera and Ravn,

2011) the Java virtual machine is implemented

directly on hardware in an embedded system (as

extensions of standard interpreters and hardware

objects, which interface directly with the JVM).

SoulPad presents a new approach based on carrying

an auto-configuring operating system along with a

suspended virtual machine on a small portable

device. With this approach, the computer boots from

the device and creates a virtual machine, thus giving

users access to their personal environment, including

previously running computations. BulkCompiler is a

simple compiler layer that works with group-

committing hardware to provide a whole-system

high-performance sequential consistency platform.

They introduce ISA primitives and software

algorithms to drive instruction-group formation, and

to transform code to exploit the groups. None of

these approaches provide a technique to transform

OS-based code to run on a bare PC or a bare

machine.

The rest of the paper is as follows. Section 3

describes the BMC paradigm and its characteristics.

The transformation process is described in Section 4.

Some transformation process issues are identified in

Section 5. Section 6 contains the conclusion.

3 BMC AND RELATED WORK

A conventional OS/kernel or embedded software

acts as middleware between the hardware and an

application. An application programmer is therefore

isolated from an application’s execution

environment and plays a very limited role in

resource control and management. Thus, the

programmer has no direct control of program

execution, which is managed by the OS. In contrast,

Bare Machine Computing (BMC), also called

dispersed operating system computing (DOSC), uses

the BMC paradigm, which eliminates the OS by

introducing an application object (AO). An AO

allows the programmer to assume sole control of the

application and its execution. Therefore, execution

and control knowledge of a given BMC application

now resides with the AO programmer. The BMC

paradigm differs from conventional computing in

two major ways. First, the machine itself is bare with

no existing software i.e., no resources such as the

OS or applications reside on the machine and need

to be protected. Second, an AO programmer is

totally responsible for program execution, control

and management. When a device is bare and has no

valuable resources such as a hard disk, OS or a

kernel to protect, it only becomes necessary to

secure the AO and its hardware interfaces. In the

BMC approach, mass storage can also be on a

network. An AO is built for a given set of

applications to run on a bare machine as a single

monolithic executable that is lean and has minimal

(only essential) functionality. The necessary network

protocols are intertwined with the application and

are not part of the OS-controlled stack or kernel i.e.,

there is no notion of user space and kernel space as

in a conventional system. The code for boot, load,

executable, data and files are stored on an external

storage device such as a USB. When this device is

plugged-in, the machine boots and runs its own

program without using any external programs or

software. No dynamic link libraries or virtual

machine code are present or allowed in BMC. When

an AO is running in the machine, only the software

loaded by the user will run. BMC systems are

currently being investigated for their security

benefits.

In the bare machine computing (BMC)

paradigm, a software program is designed as an AO,

which is self-supporting, self-managed and self-

executable. Once an AO is booted and loaded into a

bare PC, it runs without using any other software

i.e., there is no centralized support of any kind. The

BMC paradigm has been used to develop complex

applications such as Web servers, Webmail servers,

and VoIP soft-phones. These applications use lean

versions of standard network protocols, and security

protocols such as TLS, if needed. The BMC

approach completely eliminates the underlying OS

and centralized middleware. While the BMC

paradigm is similar to approaches that reduce OS

overhead and/or use lean kernels such as Exokernel

(Engler,1998), IO-Lite (Pai, Druschel and

Zwaenepoel, 2000) and Palacios and Kitten ( Lang,

et al ,2010) there are significant differences. In

particular, there is no centralized code that manages

system resources i.e., the application is completely

self-supporting, and the AO programmer controls

and manages the execution environment and the

hardware. The bare PC application development

process and BMC characteristics are described in

greater detail in (Khaksari, Karne and Wijesinha,

2012).

4 TRANSFORMATION PROCESS

We now describe the transformation process in

ICSOFT 2012 - 7th International Conference on Software Paradigm Trends

312

Figure 1: Transformation Process.

detail. Although our focus here is on transforming

SQLITE to run on a bare PC, the techniques and

underlying principles for transforming other

applications will be similar. The overall

methodology for transformation is illustrated in Fig.

1. The SQLITE application can be compiled using a

batch execution file like cpp.bat in a DOS

environment, or it can be compiled using the Visual

Studio environment. When the latter environment is

chosen, it is necessary to set the options to create a

bare executable. When a batch file option is used,

the application is compiled in a DOS window

environment. In both cases, the ultimate objective is

to eliminate any OS dependencies that may be due to

system header files. Removal of a pure system

header file will not cause any compile-time errors.

However, removal of a non-system header file will

generate compiler errors since the source code may

be using some standard definition of variables or

structures. To resolve errors, it may be necessary to

use some new declarations for variables and

functions, and/or to insert some generic header files.

The compilation process is iterative until all

compiler errors are resolved.

The next step is linking. When the above

piled objects are linked, link errors show up mostly

as system calls or OS-dependent interfaces. Each OS

environment has its own system calls. System calls

can be classified based on their type. As with

compiling, the linking process is also iterative until

all link errors are resolved. Link errors can be

resolved by implementing a system call in a bare PC

environment. If the bare PC implementation was not

yet done, we simply put in a prototype and

postponed the implementation. Once all link errors

are resolved, we can create an executable that is

ready to be loaded in a bare PC.

Compiling and linking as described above are

currently done manually. In future, it will be

possible to develop an automated tool for these steps

(ideally, by modifying a Visual Studio tool).

The SQLITE linking process resulted in 88 link

errors. In general, we expect a large number of link

errors. The transformation process has to resolve

these errors in order to generate an executable that

can run on a bare PC.

Figure 2: Classification of System Calls.

The 88 link errors are due to different types of

system calls: we categorize them as shown in Fig. 2.

Some of these calls are duplicates as they are

referenced in two different source files. Some

functions such as string type functions are not

related to the underlying OS. However, many such

functions and the most commonly used application-

level functions are typically bundled with OS

libraries. This makes these applications OS

dependent and makes it harder to port them to other

platforms. The nature of system calls varies

according to the particular OS environment in use.

For example, 542 system calls are cross-referenced

for Linux systems in (FreeBSD/Linux). In our

Transforming SQQLITE to Run on a Bare PC

313

application, we do not need to handle all system

calls that are available in a commercial OS. The

above system calls are implemented in BMC as

direct hardware interfaces (Karne, Jaganathan and

Ahmed, 2005) which are controlled by an AO

programmer

5 TRANSFORMATION ISSUES

In theory, the transformation process is complete

once all system header files are removed and the

necessary bare PC interfaces are provided.

However, this proved to be not the case in practice.

The major obstacles encountered and other problems

include: executable formats, memory map and

layout, base address for relocation, and memory

allocation. The major items in transforming the

SQLITE application to a bare PC application can be

summarized as follows:

 It is a large and complex application that

also interacts with a database

 It uses its own mini-OS structures

 It is very much intertwined with OS header

files and system calls

 It uses internal cache, paging, and memory

management

 It built its own I/O calls on top of standard

I/O.

The issues identified above are unique to the

SQLITE program. Similar issues will arise and need

to be addressed when transforming complex

applications that are closely integrated with the

underlying OS and environments.

6 CONCLUSIONS

Transforming complex applications to run on a bare

PC with no operating system or kernel support is not

trivial. We discussed a methodology for

transforming SQLITE and detailed the steps for

compiling, linking and running the application on a

bare PC. We also identified several design issues

related to the transformation process. In particular,

we identified system calls related to the SQLITE

application and classified them into groups. The

direct bare hardware interfaces (hardware APIs) are

general and can be used to build any bare PC

application (not just SQLITE). This work serves as a

foundation for transforming conventional OS-based

applications to run on a bare PC and will help in

building an automated transformation tool in the

future.

REFERENCES

Ahn, W., Qi, S., Nicolaides, M., and Torrellas, J., 2009.

BulkCompiler: High-Performance Sequential

Consistency through Cooperative Compiler and

Hardware Support. In IEEE/ACM International

Symposium on Micro Architecture.

Appiah-Kubi, P., Karne, R., and Wijesinha, A., 2010. The

Design and Performance of a Bare PC Webmail

Server. In the 12th IEEE International Conference on

High Performance Computing and Communications,

AHPCC.

Engler, D., 1998. The Exokernel Operating System

Architecture. Department of Electrical Engineering

and Computer Science, Massachusetts Institute of

Technology, Ph.D. Dissertation.

FreeBSD/Linux Kernel Cross Reference, http://

fxr.watson.org/ fxr/source/kern/syscalls.c.

He, L., Karne, R., and Wijesinha, A., 2008. Design and

Performance of a bare PC Web Server. In

International Journal of Computer and Applications,

Acta Press.

Hwang,Y., Lin,T., Chang, R., 2010. DisIRer: Converting

a Retargetable Compiler into a Multiplatform Binary

Translator. In ACM Transactions on Architecture and

Code Optimization , Vol. 7, Issue 4.

Karne, R., Jaganathan,K., Ahmed, T., and Rosa, N., 2005.

DOSC: Dispersed Operating System Computing. In

20th Annual ACM Conference on Object Oriented

Programming (OOPSLA).

Karne, R., Jaganathan,K., and Ahmed, T., 2005. How to

run C++ Applications on a bare PC. In 6th ACIS

International Conference on Software Engineering,

Artificial Intelligence, Networking, and Parallel

Distributed Computing (SNPD), p. 50-55.

Khaksari, G., Karne, R., and Wijesinha, A., 2012. A Bare

Machine Application Development Methodology. In

International Journal of Computer Applications

(IJCA), Vol. 19, No.1.

Lange, J., Pedretti, K., Hudson,T., Dinda, P., Cui, Z.,

Xia, L., Bridges, P., Gocke, A., Jaconette, S.,

Levenhagen, M., and Brightwell, R., 2010. Palacios

and Kitten: New High Performance Operating

Systems for Scalable Virtualized and Native

Supercomputing. In Proceedings of the 24th IEEE

International Parallel and Distributed Processing

Symposium.

Pai, V., Druschel, P., and Zwaenepoel, W., 2000. IO-Lite:

A Unified I/O Buffering and Caching System. In

ACM Transactions on Computer Systems, Vol.18 (1),

p. 37-66, ACM.

Schoeberl, M., Korsholm, K., Kalibera, T., and Ravn,

A., 2011. A Hardware Abstraction Layer in Java. In

ACM Transactions on Embedded Computing Systems,

Vol.10, No.04, Article 42.

Soumya,S., Guerin, R., and Hosanagar, K ., 2011.

Functionality-rich Vs Minimalist Platforms: A Two-

sided Market Analysis. In ACM Computer

Communication Review, Volume 41, Number 5, p36-

43.

ICSOFT 2012 - 7th International Conference on Software Paradigm Trends

314
