On Secure Communication over Wireless Sensor Networks

Stefan Rass

and Michał Koza

Institute of Applied Informatics, Universit¨at Klagenfurt, Universit¨atsstrasse 65-67, 9020 Klagenfurt, Austria

Faculty of Fundamental Problems of Technology, Wrocław University of Technology, Wrocław, Poland

Keywords:

Wireless Sensor Network, Security: Secrecy, Secret Sharing, Perfectly Secure Message Transmission.

Abstract:

This paper investigates (perfectly) secure message transmission over a wireless sensor network. Using a

layered network architecture and a very simple form of routing, we show how to construct an arbitrarily secure

communication channel over a given infrastructure of wireless devices. Our construction is computationally

cheap and requires no cryptographic primitive beyond symmetric encryption on the channels. The security of

the transmission can be made arbitrarily strong (in an information-theoretic sense).

1 INTRODUCTION

Secret message transmission is doubtlessly an impor-

tant aspect in vast amount of communication scenar-

ios, and has been thoroughly studied in the wired do-

main for decades. The increasing interest and expand-

ing range of applications in the wireless domain sheds

a different light on security requirements when de-

signing wireless transmission protocols. In this work,

we propose a simple protocol for transmission over a

wireless infrastructure, which explicitly exploits fea-

tures of the wireless domain to create a highly secure

channel through an otherwise not trustworthy envi-

ronment. The limited capabilities of small wireless

(sensor) devices, such as computational and battery

power or the physical access protection of crypto-

graphic keys, can become and obstacle for using ad-

vanced cryptography. So, we are after slim and com-

putationally cheap protocols.

Fortunately, some features of wireless networks

can be used in order to construct a highly secure

transmission channel. Devices are usually simple and

small, so it can be very challenging for an adversary

to physically locate them in an environment. Such

devices are often also cheap and can be deployed in

large numbers, thus facilitating the use of secret shar-

ing and/or multi-path transmission.

Intuitively, if we can not make the transmission

secure, why not try to make it “invisible”? This it the

road taken in the recent paper of (Klonowski et al.,

2011), and our goal in this work is further exploring

that direction by devising an extended version of their

protocol, hereafter referred to as BasicSWTP. We re-

fer the reader to (Klonowski et al., 2011) for full de-

tails, and will give only a brief review in section 2.

Organization of the Paper. Preliminaries and

groundwork preparation done in Section 2. Section

3 is devoted to a presentation of BasicSWTP and its

extension, along with security proofs. Conclusions

follow in Section 4.

Related and Previous Work. A lot of papers dis-

cuss secret message transmission in wireless net-

works based on symmetric cryptography and key pre-

distribution (e.g. (Perrig et al., 2004; Jaworski et al.,

2009; Cicho´n et al., 2009; Anderson et al., 2004;

Chan et al., 2003; Du et al., 2005)). The main goal

of these protocols is establishing secure channels be-

tween devices, where channels are secured by sym-

metric cryptography. While key managementand pre-

distribution Although our scheme can (and should)

be used with key-predistribution schemes (Klonowski

et al., 2007; Ren et al., 2006), the problem stated in

this paper cannot be solved by symmetric schemes

with key-predistribution only. Nevertheless, the re-

sults in (Chan and Perrig, 2005; Eschenauer and

Gligor, 2002) are notable and related and are an as-

set to our work. Most closely related to ours is the

work of (Di Pietro et al., 2006). Our contribution tar-

gets the same goals, yet in addition comes with an

information-theoretic analysis, which is not provided

in previous related work.

364

Rass S. and Koza M..

On Secure Communication over Wireless Sensor Networks.

DOI: 10.5220/0004018403640367

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 364-367

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

2 PRELIMINARIES

Our network model is the same as in (Klonowski

et al., 2011), which is a wireless multi-hop sensor net-

work. In graph-theory language, the network model

graph G(V, E) is undirected and t-partite. The (pair-

wise disjoint) partition V = L

∪L

∪...

∪L

t−1

is such

that no two nodes within the same layer L

talk to

each other, and every node from L

has a logical link

(i.e. a symmetrically encrpted channel) to every node

in L

i+1

for i = 0, 1,.. . ,t − 2. One way of building

such a layered architecture is using one of many ex-

isting clustering protocols (see (Yuand Chong, 2005))

or general key-distribution protocols (e.g. Difﬁe-

Hellman or (Perrig et al., 2004)). We assume low

level protocol services like cluster level routing, col-

lision avoidance etc., as provided by the network.

The Basic Transmission Protocol BasicSWTP. On

each layer L

the message m appears split into l parts,

which are created by the sender s ∈ L

using XOR-

secret-sharing. A relay node in L

(i ≥ 1) takes its l

incoming share parts, combines them to get its mes-

sage share s

, invokes another sharing on it and for-

wards the new parts to l nodes in L

i+1

. The crux of

(Klonowski et al., 2011)’s construction is a special in-

dexing scheme that pseudorandomly determines the

receivers in the next layer so that all relay nodes

within L

choose the same set of l receivers within

i+1

. This assures that the subgraph of G that is

used for the actual payload delivery always remains t-

partite subgraph, with each intermediate layer having

cardinality l. The parameter l controls the number of

shares, and hence the number of paths in the transmis-

sion, and is called the forking parameter (Klonowski

et al., 2011). Figure 1 shows an example.

Adversary Model. For security, assume that the ad-

versary corrupts no more than K nodes in total, where

a corrupted node has all its content (including any

cryptographic keys) exposed to the attacker. Further-

more, we assume the adversary’s computational pow-

ers sufﬁciently constrained to inhibit a ciphertext only

attack on the symmetric encryption used for any wire-

less transmission in the network. This assumption

is necessary to rule out trivialities by situations in

which the adversary gets all the information ﬂowing

between the sender and the receiver. Notice that this

sort of computational intractability assumption might

indeed permit breaking a public-key encryption.

Security Model. The symbol Π denotes a gen-

eral message transmission protocol. With H(·) and

H(·|·), we denote the unconditional and conditional

Shannon-entropy.

Deﬁnition 2.1 ((Franklin and Wright, 2000)). Take

ε > 0, and let Π be a message transmission proto-

col. Suppose that for conveyance of a message M ∈

{0,1}

∗

, the packets C

,...,C

∈ {0,1}

∗

are transmit-

ted over the network (constituting the protocol’s tran-

script). The adversary’s view on the transmission of

M is adv(M) ⊆ {C

,...,C

}. A protocol ε-secure, if

• H(M|adv(M)) ∈ {0,H(M)}, and

• P(H(M|adv(M)) = 0) ≤ ε,

i.e. the adversary can disclose M with a chance of at

most ε. We call the protocol Π efﬁcient, if the size of

the transcript, i.e.

∑

i=1

|, is polynomial in the size

of the message M, the size of underlying network (in

terms of nodes), and log

. A protocol that is ε-secure

for any ε > 0 is said to enjoy perfect secrecy.

Security of BasicSWTP. The following two results

are found in (Klonowski et al., 2011) and regard the

security of the above sketched transmission scheme:

Theorem 2.1. The strategy of putting all corrupted

nodes in exactly one layer maximizes the probability

of corrupting the message.

Corollary 2.2. In the system with forking parameter

l, with n nodes in each layer, and the adversary capa-

ble of corrupting K nodes, the probability p that the

adversary discloses a secret message is

p =







0, if K < l;









, if l ≤ K < n;

1, if K ≥ n.

(1)

The Concept of Vulnerability. For analyzing secu-

rity, we can set up the transmission as an attacker-

defender-game in the obvious way: the defender

(message sender) chooses the t-partite subgraph of G

for transmission (grayish nodes in ﬁgure 1), while the

attacker chooses his nodes to conquer. The game’s

objective is secret content delivery, so the sender

(player 1) scores 1 every securely delivered message,

and receives zero payoff in case of a successful mes-

sage disclosure by the attacker (player 2). The game

is zero-sum, meaning that the attacker scores 1 for ev-

ery disclosed message and zero otherwise. With this

setting, standard techniques of game-theory let us de-

termine the optimal behavior for both players, with

the optimal strategies of the attacker being character-

ized by theorem 2.1 already. The optimal revenue for

player 1, i.e. the average success-rate of secret mes-

sages delivered under the hypothesis that the attacker

acts optimal too is the game’s saddle-point value v.

See (Rass and Schartner, 2010) for full details on this

game-theoretic approach. The important fact here is

that corollary 2.2 and the details in (Klonowski et al.,

OnSecureCommunicationoverWirelessSensorNetworks

365

2011) already give us the optimal transmission and at-

tack strategies, along with equation (1) providing the

game’s saddle-point value.

3 SECURE TRANSMISSION

It is evident that choosing a larger forking parameter

occupies more of the network and increases the band-

width demand. Hence, lower values of l are desirable,

yet are paid for with less security.

Framework Protocol. Our proposed extension is

running BasicSWTP with a small (ﬁxed) forking pa-

rameter on a set of shares to the message, rather than

on the message as such. Initially, the message m is

shared as m = r

⊕ r

⊕ ··· ⊕ r

(where ⊕ is the bit-

wise XOR). Each r

for i = 1,2,...,k is transmitted

using BasicSWTP with an either chosen or prescribed

(small) forking parameter l. The reconstruction by the

receiver happens in the obvious way. This ”frame-

work protocol”, sketched in ﬁgure 1 as the wrapper

around BasicSWTP, is indeed secure and efﬁcient:

Theorem 3.1. Let the channel be characterized by

the number n of nodes per layer and let the protocol

work with a ﬁxed forking parameter l ≤ n. Assume

that a sender estimates the threshold of the adversary

as K ≤ n. Then, in the sense of Deﬁnition 2.1, arbi-

trarily secure communication is efﬁciently possible if

and only if K < n.

Proof sketch: Corollary 2.2 gives the likelihood

p of secret delivery in a single round, and the XOR-

sharing enforces the attacker to catch all shares when-

ever the message shall be disclosed. So, if p = 1, then

the chance to catch all shares is 1 and the transmission

is insecure. On the contrary, if p < 1, then the chance

to catch all of the shares decays exponentially fast, so

we can choose k large enough to lower this chance be-

low any chosen ε > 0. The bit-complexity is k· l · |m|,

where |m| is the length of the message. The overall

overhead is O



|m| · l · log



, i.e. polynomial.

Secure Key-exchange. We can dress up our claims

in information-theoretic terms too, if we wrap the

framework protocol around BasicSWTP, in order to

exchange keys with assured entropy. The following is

a technical gadget, needed to establish the second of

our results, which is theorem 3.3.

Theorem 3.2 ((Rass and Schartner, 2010)). Let the

sender emit secret messages M of entropy H(M), and

let C denote the information that the adversary can

acquire by eavesdropping. Then the cross-entropy

I(M;C), i.e. the amount of information that leaks

out the channel satisﬁes I(M;C) ≤ ρ · H(M), where

message

sharingsharing

,. .. ,r

layer L

i−1

i+1

BasicSWTP with forking parameter

l = 3 to convey r

,. .. ,r

Figure 1: Example illustration of our protocol.

ρ = maxP(successful attack), and the maximum is

taken over all randomized actions of the attacker.

It should be noted that the value ρ in theorem 3.2

can be obtained using game-theoretic tools (Rass and

Schartner, 2010) or directly from Corollary 2.2.

Theorem 3.3. Let a source with entropy h generate a

sequence of independent random numbers r

,...,r

which are transmitted via BasicSWTP. Let the sender

and receiver derive a common secret κ = r

⊕ r

⊕

··· ⊕ r

. Then, even for a computationally unbounded

adversary, the secret has entropy H(κ) ≥ (1 − ρ

)h,

where ρ is given by Corollary 2.2 applied to the in-

stantiation of BasicSWTP.

Proof sketch: Let the sender transmit k indepen-

dent uniform random numbers r

,...,r

and write

κ = r

⊕ r

⊕ ··· ⊕ r

for the exchanged key κ. By

the stochastic independence, the attack probability

is by Corollary 2.2 no larger than p

. Applying

Theorem 3.2 with p

bounds the leaking informa-

tion I(C;κ) ≤ p

· H(κ), where C denotes the infor-

mation that the adversary gains from eavesdropping.

By deﬁnition, I(C;κ) = H(κ) − H(κ|C), so we get

H(κ|C) ≥ (1− p

) · H(κ).

4 CONCLUSIONS

While (Klonowski et al., 2011)’s protocol, here called

BasicSWTP, achieves good security based on a free

choice of the forking parameter, having multiple such

channels run concurrently can quickly occupy and

congest the infrastructure. For that matter, it appears

reasonable to use another sharing on top of Basic-

SWTP, which lets us work with smaller forking pa-

rameters while not too badly affecting the security (as

theorems 3.1 and 3.3 demonstrate).

Our protocol is simple and creates an arbitrary

secure channel through a potentially hostile environ-

ment. Moreover, it is provably secure and efﬁcient,

SECRYPT2012-InternationalConferenceonSecurityandCryptography

366

and does not rest on computational intractability as-

sumptions beyond what is needed to establish se-

cure symmetrically encrypted channels. Even from

an information-theoretic point of view, it is possible

to use our scheme for secret key-exchange only, so

as to gain security even against a computationally un-

bounded adversary. Moreover, our scheme is light-

weight in the sense of imposing little computational

effort within each relay node. So it can be imple-

mented in cheap and power-limited devices, partic-

ularly small sensor-devices. The protocol offers two

degrees of freedom which lets us control the commu-

nication overhead and ﬁnd a suitable balance between

security and communication overhead. This facili-

tates a fair-use policy of the channel, if multiple ses-

sions run concurrently over the same set of devices.

In future work, we will report on empirical evaluation

via simulation.

Unfortunately, our protocol is vulnerable to

denial-of-service attacks in its present form. The

XOR-sharing as we used is most vulnerable to cor-

rupted shares, since the secret is unrecoverable if one

share is lost or modiﬁed. However, XOR-sharing is

not a must and might be replaced by conventional

polynomial sharing that comes with better error cor-

recting facilities (e.g. Shamir’s scheme). Guarding

against loss of shares and routing attacks are subject

of future research.

This work is written with wireless networks in

mind, but the presented algorithm can work in any

network where the construction of the aforemen-

tioned layered architecture is possible. In particular,

it seems possible to apply it in wired networks like

cascades of mix servers presented in (Klonowski and

Kutylowski, 2005).

ACKNOWLEDGEMENTS

The paper was partially supported by grant S10026

from the Institute of Mathematics and Computer Sci-

ence of the Wroclaw University of Technology.

REFERENCES

Anderson, R., Chan, H., and Perrig, A. (2004). Key infec-

tion: Smart trust for smart dust. In Proc. of IEEE Int.

Conf. on Network Protocols (ICNP).

Chan, H. and Perrig, A. (2005). PIKE: peer intermediaries

for key establishment in sensor networks. In INFO-

COM 2005. Proc. of the 24th Annual Joint Conf. of

the IEEE Computer and Communications Societies.,

volume 1, pages 524–535.

Chan, H., Perrig, A., and Song, D. (2003). Random key pre-

distribution schemes for sensor networks. In Proc. of

the IEEE Symp. on Security and Privacy, pages 197–

213. IEEE Computer Society.

Cicho´n, J., Grza´slewicz, J., and Kutyłowski, M. (2009). Key

levels and securing key predistribution against node

captures. In ALGOSENSORS, pages 64–75.

Di Pietro, R., Mancini, L. V., and Mei, A. (2006). Energy

efﬁcient node-to-node authentication and communica-

tion conﬁdentiality in wireless sensor networks. Wirel.

Netw., 12:709–721.

Du, W., Deng, J., Han, Y. S., Varshney, P. K., Katz, J.,

and Khalili, A. (2005). A pairwise key predistribution

scheme for wireless sensor networks. ACM Trans. Inf.

Syst. Secur., 8(2):228–258.

Eschenauer, L. and Gligor, V. D. (2002). A key-

management scheme for distributed sensor networks.

In CCS ’02: Proc. of the 9th ACM Conf. on Computer

and communications security, pages 41–47. ACM

Press.

Franklin, M. and Wright, R. (2000). Secure communica-

tion in minimal connectivity models. J. of Cryptology,

13(1):9–30.

Jaworski, J., Ren, M., and Rybarczyk, K. (2009). Random

key predistribution for wireless sensor networks using

deployment knowledge. Computing, 85(1–2):57–76.

Klonowski, M., Koza, M., and Kutyłowski, M. (2011). How

to transmit messages via WSN in a hostile environ-

ment. In Proc. of the Int. Conf. on Security and Cryp-

tography (SECRYPT), pages 134–143. SciTePress.

Klonowski, M. and Kutylowski, M. (2005). Provable

anonymity for networks of mixes. In Information Hid-

ing, pages 26–38.

Klonowski, M., Kutyłowski, M., Ren, M., and Rybarczyk,

K. (2007). Forward-secure key evolution in wireless

sensor networks. In CANS, pages 102–120. Springer.

Perrig, A., Stankovic, J. A., and Wagner, D. (2004). Se-

curity in wireless sensor networks. Commun. ACM,

47(6):53–57.

Rass, S. and Schartner, P. (2010). A uniﬁed framework

for the analysis of availability, reliability and security,

with applications to quantum networks. IEEE Trans.

on Systems, Man, and Cybernetics – Part C: Applica-

tions and Reviews, 40(5):107–119.

Ren, M., Das, T. K., and Zhou, J. (2006). Diverging keys in

wireless sensor networks. In ISC, pages 257–269.

Yu, J. Y. and Chong, P. H. J. (2005). A survey of clustering

schemes for mobile ad hoc networks. Communica-

tions, 7(1):32–48.

OnSecureCommunicationoverWirelessSensorNetworks

367
