Quantitative Assessment of Cloud Security Level Agreements

A Case Study

Jesus Luna, Hamza Ghani, Tsvetoslava Vateva and Neeraj Suri

Department of Computer Science, Technische Universit¨at Darmstadt, Darmstadt, Germany

Keywords:

Cloud Security, Security Assessment, Security Benchmarks, Security Level Agreements, Security Metrics.

Abstract:

The users of Cloud Service Providers (CSP) often motivate their choice of providers based on criteria such as

the offered service level agreements (SLA) and costs, and also recently based on security aspects (i.e., due to

regulatory compliance). Unfortunately, it is quite uncommon for a CSP to specify the security levels associated

with their services, hence impeding users from making security relevant informed decisions. Consequently,

while the many economic and technological advantages of Cloud computing are apparent, the migration of

key sector applications has been limited, in part, due to the lack of security assurance on the CSP. In order to

achieve this assurance and create trustworthy Cloud ecosystems, it is desirable to develop metrics and tech-

niques to compare, aggregate, negotiate and predict the trade-offs (features, problems and the economics) of

security. This paper contributes with a quantitative security assessment case study using the CSP information

found on the Cloud Security Alliance’s Security, Trust & Assurance Registry (CSA STAR). Our security as-

sessment rests on the notion of Cloud Security Level Agreements — SecLA — and, a novel set of security

metrics used to quantitatively compare SecLAs.

1 INTRODUCTION

Despite the pervasive nature of Cloud technologies

and their advocated economic/technological advan-

tages, the migration of applications has been limited,

in part, due to the lack of security assurance by the

CSP. This lack of assurance, along with the current

paucity of techniques to quantify security, often re-

sults in users being unable to assess the security of

the CSP they are paying for. Despite the assump-

tion that a given Cloud provider “seems” secure, is

it actually “secure enough” for my needs? Is my per-

sonal data more secure today than before? How do I

compare against other providers with regards to secu-

rity? These questions have been raised in the security

metrics area, including institutions such as ENISA

(Trimintzios, P., 2011), NIST

(Jansen, W., 2010) and

CIS

(Boyle K., et.al., 2010). The stated belief is

that well-designed security metrics and quantitative

security assessment techniques will both support the

achievement of assurance in CSPs and also motivate

the creation of trustworthy Cloud ecosystems.

Fortunately, security assurance in Cloud comput-

European Network and Information Security Agency.

National Institute of Standards and Technology.

Center for Internet Security.

Cloud SecLA

Comparison

Benchmarking

Compliance

Quantitative Cloud

Security Assessment

Figure 1: Representation of the quantitative Cloud security

assessment presented in this paper. Dashed shapes indicate

the paper contributions.

ing has recently initiated promising steps. In partic-

ular, the Cloud community has identiﬁed that speci-

fying security in Service Level Agreements (termed

as “Security Level Agreements” or SecLA over this

paper) to be useful to model and assess the security

being offered by a CSP (cf. (Dekker, M. and Hogben,

G., 2011) and (Cloud Security Alliance, 2011c)).

Despite the potential advantages related with the

design and use of Cloud SecLAs, the security metrics

and techniques to quantitatively reason about Cloud

SecLAs are still lacking. To address this gap, this

Luna Garcia J., Ghani H., Vateva T. and Suri N..

Quantitative Assessment of Cloud Security Level Agreements - A Case Study.

DOI: 10.5220/0004019900640073

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 64-73

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

paper develops a quantitative security assessment ap-

proach considering a case study using the CSP infor-

mation found on the STAR repository (Cloud Security

Alliance, 2011c).

Our proposed quantitative security assessment ap-

proach is illustrated in Figure 1 and, is based on the

notion of Cloud SecLAs, with the contributions be-

ing:

1. A novel set of security metrics used to compare,

benchmark and assess the security compliance of

the evaluated Cloud SecLAs.

2. A real-world case study of the proposed security

assessment using the CSP information found on

the STAR repository.

Our results aim at impacting the Cloud ecosys-

tem in terms of security and transparency, thus facil-

itating service compliance and removing uncertainty

from CSPs interactions (ultimately helping them to

decrease transaction costs).

The paper is organizedas follows: Section 2 moti-

vates the notion of Cloud Security Level Agreements;

Section 3 presents the proposed quantitative security

assessment techniques, and Section 4 discusses the

results of the contributed security assessment using

the CSP information found on the STAR repository.

Section 5 reviews relevant existing approaches related

with our research.

2 CLOUD SECURITY LEVEL

AGREEMENTS

The notion of SecLAs currently exists in varied di-

mensions (please refer to Section 5 for related state of

the art) and the Cloud is not an exception. The use

of Cloud SecLAs has the potential to provide tangible

beneﬁts to CSPs especially associated with improved

security administration and management practices,

thus allowing for more transparency to end users. It

is clear that the deﬁnition of SecLAs forces a stake-

holder to think about security. However end users can

also beneﬁt from SecLAs by understanding the costs

and beneﬁts associated with this new service model.

Nowadays it is being realized that on the one hand

SecLAs will provide service-based assurance, but on

the other hand it is clear that SecLAs are not intended

to replace electronic assurance mechanisms for secu-

rity policy enforcement (Henning, R., 1999).

The importance of Cloud SecLAs has also been

recognized by ENISA: the development of template

contracts and service level agreements is being high-

lighted as one of the areas to be addressed in the Eu-

ropean Cloud computing strategy. In a recent survey

(Dekker,M. and Hogben, G., 2011)ENISA highlights

that manyCloud customers often do not monitor secu-

rity aspects of their contracted SLA on a continuous

basis. This implies that customers are left unaware

about many important security aspects related to their

services. The risk is that they ﬁnd out about failing se-

curity measures only following a security breach. The

surveydata shows that while SLAs are often used, and

availability is often addressed in these SLAs, security

parameters are less well covered.

As mentioned in our previous work (Luna, J.,

et.al., 2011) and shown in Figure 2, the notion of

Cloud SecLAs is essential in order to quantitatively

assess the security level offered by a CSP. Cloud

SecLAs usually model the CSP security at the service

level and, are based on either a set of security require-

ments (e.g., for compliance reasons) or some kind of

preliminary security threat analysis. The result will be

a collection of security statements (also called “secu-

rity provisions”) related with the CSP’s technical and

organizational security, therefore ranging from provi-

sions like “Backup periodicity” to “Independent au-

dits frequency”. This ﬁnal set of security provisions

will become the Cloud SecLA, just as shownin Figure

2 and discussed in works like (Bernsmed, K., et.al.,

2011) and (Almorsy, M., et.al., 2011).

Apart from the challenges related with the cre-

ation of SecLAs in real Cloud deployments, the cur-

rent paucity of techniques to quantitatively assessing

them has proven to be part of the obstacles in us-

ing SecLAs. To achieve the security assessment part

shown in Figure 2, this paper presents techniques to

quantitatively reason about Cloud SecLAs.

IaaS

PaaS

SaaS

Service level-

Security Requirements,

Threat Modeling

Cloud SecLA

Creating a Cloud SecLAAssessing a Cloud SecLA

Quantitative Security

Levels

Quantitative Security

Assessment

Figure 2: Workﬂow to quantitatively assess Security

Level Agreements in Infrastructure-as-a-Service (IaaS),

Platform-as-a-Service (Paas) and Software-as-a-Service

(SaaS) CSPs.

QuantitativeAssessmentofCloudSecurityLevelAgreements-ACaseStudy

3 SECURITY ASSESSMENT

Based on the notion of Cloud SecLA presented in

Section 2, it is possible to derive a set of security met-

rics to quantitatively assess the CSP from three differ-

ent perspectives: Comparison (Section 3.2), Bench-

marking (Section 3.3) and Compliance (Section 3.4).

However, before actually introducing the con-

tributed assessment metrics it is helpful to have a

mechanism to quantitatively reason about SecLAs.

Our approach utilizes the Reference Evaluation

Methodology — REM — originally proposed in (Ca-

sola V., et.al., 2005) as a technique to quantitatively

evaluate security policies. The basics related with the

use of the REM technique are presented next.

3.1 The Reference Evaluation

Methodology at Glimpse

In its basic form, REM (a) considers a set of security

provisions

to evaluate, (b) formalizes it to facilitate

the further evaluation step over an homogeneous met-

ric space, (c) uses a set of reference levels (known as

Local Security Levels or LSL) to apply a distance cri-

terion, and (d) ﬁnally obtains a number (also called

Global Security Level or GSL) that corresponds to the

policy’s security level.

For the purposes of this paper, only a couple of

REM-related concepts are presented and the inter-

ested readers are referred to (Casola V., et.al., 2005)

for further details.

The ﬁrst concept is the formal representation of

any security policy by a n × m matrix, whose n rows

represent single provisions with a maximum of m pos-

sible LSLs. For example, if the LSL associated to a

Cloud Storage Provider’s provision called “File Sys-

tem Encryption” is 3, then the corresponding vector

will be (1,1,1,0).. The REM concept of LSL is con-

gruent with the notion of security ranges, as presented

in (Irvine, C. and Levin, T., 2001).

The second REM-concept is a criteria used to

quantify GSLs, and deﬁned as the Euclidean dis-

tance

among whatever pair of REM-matrices (A,B).

Just as in Equation 1, the GSL is deﬁned as the square

root of the matrix trace of



(A− B)(A− B)



, where

(A− B)

is the conjugate transpose.

GSL(A, B) = d(A, B) =

Tr((A − B)(A− B)

) (1)

In REM terminology, a security provision is a security

statement in the form {attribute, value}.

The LSL is usually known as the L1-Norm (Weisstein,

W., 2011b) of this vector.

Also known as the Frobenius-Norm (Weisstein, W.,

2011a).

We consider utilizing REM primarily for the ﬂex-

ibility it offers to model and quantitatively evaluate

most classes of security policies (e.g., Certiﬁcate Poli-

cies (Casola, V. et.al., 2007), (Casola, V., et.al., 2007)

and security policies associated with Desktop Grids

(Luna, J. et.al., 2008)). However, as discussed later in

Section 6, our security assessment can be easily ex-

tended to use other SecLA quantiﬁcation techniques.

As a stand-alone security evaluationmethodology,

REM does not provide any additional metric to quan-

titatively reason about the LSL and GSL associated

with each Cloud SecLA. To bridge this gap, our re-

search develops a novel set of metrics to perform the

security assessment of a CSP based on the REM-

quantiﬁcation of its SecLA, as depicted in Figure 2

and in Section 3.2.

3.2 Comparing Security Levels

The metrics introduced next are used to quantitatively

compare the GSL (as computed with Equation 1) of

two or more Cloud SecLAs, by determining where in

the “SecLA metric space — MS —” are. The MS

used in this section and graphically shown in Figure

3, is delimited by the following two SecLA values:

• SecLA(φ) = GSL(φ, φ), where φ is the origin of

the metric space or in other words, a Cloud SecLA

where all LSLs equal zero (i.e., are represented by

the vector (0,0,0,0)).

• SecLA(max)) = GSL(max, φ) is the maximum al-

lowable GSL for any Cloud SecLA under evalu-

ation, and max is the SecLA where all LSLs are

represented by (1,1,1,1).

Notice that the SecLA metric space mentioned

above is able to contain whatever Cloud SecLA that

uses a maximum of four LSLs.

Deﬁnition 1. The following metric computes the rate

among the overall security level of the CSP under

analysis and, the maximum achievable security level

(i.e., the total length of the MS shown in Figure 3):

RateMS(SecLA

CSP

) =

GSL(SecLA

CSP

, φ)

GSL(max, φ)

Where:

• SecLA

CSP

is the SecLA of the CSP to assess.

• GSL(CSP, φ) is the GSL of the CSP as computed

with Equation 1 and, taking as reference level the

origin of MS.

• GSL(max, φ) is the length of the deﬁned MS.

From Deﬁnition 1, it can be observed that the

closer RateMS to 1 is, the more secure the CSP is.

SECRYPT2012-InternationalConferenceonSecurityandCryptography

Figure 3: Metric Space (MS) for quantitatively comparing

Cloud SecLAs.

Because in practice the overall quantiﬁcation of

the Cloud SecLA may “hide” some details related

with the security level of individual provisions, we

propose the metric shown in Deﬁnition 2 to perform a

more ﬁne-grained comparison.

Deﬁnition 2. To quantitatively compare a CSP

with

respect to second CSP

, we proceed to split their

SecLAs into a couple of subsets, just as deﬁned next:

∆

(SecLA

CSP1

, SecLA

CSP2

) =

GSL(SecLA

+CSP1

, SecLA

+CSP2

)

GSL(SecLA

+CSP2

, φ)

∆

−

(SecLA

CSP1

, SecLA

CSP2

) =

GSL(SecLA

−CSP1

, SecLA

−CSP2

)

GSL(SecLA

−CSP2

, φ)

Where:

• ∆

(SecLA

CSP1

, SecLA

CSP2

) is the subset of secu-

rity provisions from CSP

with a security level

greater or equal than CSP

• Analogously, ∆

−

(SecLA

CSP1

, SecLA

CSP2

) is the

subset of security provisions from CSP

with a se-

curity level smaller than CSP

From Deﬁnition 2, the closer both ∆

and ∆

−

are

to 0, the more similar CSP

to CSP

will be.

3.3 Benchmarking Cloud SecLAs

The notion of benchmarking used in Deﬁnition 3 is

to count how many individual provisions of Cloud

SecLA are above/belowof a predeﬁned baseline (e.g.,

user-deﬁned or standard-based). This metric is in-

spired by CIS’ security benchmark tool (Center for

Internet Security, 2009) and, uses the concept of LSL

explained in Section 3.1.

Deﬁnition 3. If two Cloud SecLAs have the same car-

dinality, then the “Benchmarking Score” of a CSP’s

SecLA

CSP

relative to a reference SecLA

REF

is deﬁned

as:

BenchScore(SecLA

CSP

, SecLA

REF

) =

LSL

CSP

|SecLA

CSP

Where:

• |

LSL

CSP,n

| is the number of security provisions

from SecLA

CSP

, such that LSL

CSP

≥ LSL

REF

• |SecLA

CSP

| represents the SecLA’s cardinality

(i.e., the total number of security provisions from

either SecLA

CSP

or SecLA

REF

From Deﬁnition 3, the closer BenchScore to 1 is,

the best SecLA

CSP

has the baseline SecLA

REF

ful-

ﬁlled. However, if BenchScore < 1 then the CSP is

only partially compliant, whereas if BenchScore = 0

then the CSP is not compliant at all with SecLA

REF

3.4 Compliance Assessment

This metric is a case of the Benchmarking Score met-

ric presented in the previous section. The Compliance

Index metric shown next was designed to assess if a

CSP’s SecLA fulﬁlls (or not) some speciﬁc security

compliance criteria.

Deﬁnition 4. Using the same notation from Def-

inition 3, the quantitative “Compliance Index”

(CompIndex) of a CSP relative to a reference crite-

ria is deﬁned as:

CompIndex(SecLA

CSP

, SecLA

REF

) =











1 if LSL

CSP,n

≥ LSL

REF,n

∀LSL

CSP,n

∈ SecLA

CSP

∧

∀LSL

REF,n

∈ SecLA

REF

LSL

CSP

|SecLA

CSP

otherwise

From Deﬁnition 4, if

CompIndex(SecLA

CSP

, SecLA

REF

) = 1 then it

means that the CSP’s SecLA is fully compliant with

the reference criteria SecLA

REF

4 EVALUATION: A PRACTICAL

SECURITY ASSESSMENT

STUDY

A well-known challenge in the security metrics ﬁeld

is related with the empirical validation of metrics

and frameworks (Verendel, V., 2009). Fortunately,

the Cloud Security Alliance (CSA) has recently re-

leased the initial version of their “Security, Trust

& Assurance Registry” (STAR (Cloud Security Al-

liance, 2011c)), a publicly available repository that

documents the security controls provided by CSPs

worldwide. Currently, STAR contains the “Consensus

Assessments Initiative Questionnaire” (CAIQ (Cloud

Security Alliance, 2011b)) reports, which provides

industry-accepted ways to document what security

controls exist in Cloud offerings. The CAIQ con-

tains a set of over 160 questions a Cloud consumer

and Cloud auditor may wish to ask a CSP.

QuantitativeAssessmentofCloudSecurityLevelAgreements-ACaseStudy

The remainder of this section presents the results

obtained from applying the metrics (of Section 3),

to the CAIQ reports stored in the STAR repository.

Please notice that (i) at the time of writing this pa-

per STAR contained only the reports of three CSPs

and, (ii) due to STAR’s usage restrictions we have

anonymized the identity of the CSPs under analysis.

4.1 Testbed

To perform in a semi-automated manner the con-

tributed CSP’s security assessment, we have imple-

mented an initial prototype of the architecture shown

in Figure 4.

STAR

Preprocessor

REM Parsing

GUI

Internal

Reposi-

tory

Analyzer

GUI

Comparison

Benchmarking

Compliance

Cloud Service

Providers

1.- CAIQ Information

2.- CAIQ files

Download Manager

3.- SecLA, GSL 4.- SecLA, GSL

User

5.- Results

Figure 4: Testbed to perform the CSP’s security assessment.

At the core of our testbed are two building blocks

with the following functionality:

1. Preprocessor: after a CSP has uploaded its CAIQ

report to STAR (Step 1 in Figure 4) the Download

Manager will retrieve it (Step 2). Once down-

loaded, the CAIQ report is parsed into the Inter-

nal Repository shown in Figure 4 via the Pars-

ing module. Using a local REM implementation,

the parsed Cloud SecLA is quantitatively evalu-

ated and the resulting GSL/LSL stored into an In-

ternal Repository (Step 3). In the current version

of our prototype, both the downloading and pars-

ing processes are manually performed via the GUI

component.

2. Analyzer: this module will download from the

Internal Repository a set of Cloud SecLAs to as-

sess (Step 4). Depending on the metrics selected

by the User (via the Analyzer’s GUI) this mod-

ule will invoke one or more of the Comparison,

Benchmarking and Compliance components. The

results of the security assessment will be graphi-

cally displayed via the GUI (Step 5).

Using on a working prototype of the testbed ex-

plained above, we show in Section 4.3 the results of

the CSPs’ quantitative security assessment using the

STAR reports.

4.2 Setting Up the SecLAs

Based on the CAIQ responses of the CSP under anal-

ysis, we created for the purposes of our security as-

sessment the following two sets of Cloud SecLAs for

each one of them:

1. CAIQ: this is an initial set of three SecLAs con-

taining all the 171 security provisions from the

different CAIQ’s “control groups” and common

to all the CSPs under evaluation. These 171 provi-

sions are distributed in the following way: Com-

pliance (CO) - 14, Data Governance (DG) - 15,

Facility Security (FS) - 9, Human Resources Se-

curity (HR) - 4, Information Security (IS) - 71,

Legal (LG) - 2, Operations Management (OP) -

5, Risk Management (RI) - 12, Release Manage-

ment (RM) - 5, Resilience (RS) - 11 and Security

Architecture (SA) - 23). These provisions had a

qualitative “YES/NO” answer in the CAIQ, but

there was an additional “Comments” ﬁeld that al-

lowed the CSP to provide further details.

2. CAIQ+: after analyzing the CSP’s answers given

on the CAIQ’s “Comments” ﬁeld, we designed

this additional set with 29 security metrics that

were used to create another three SecLAs (in this

case with 171 + 29 = 200 security provisions). Ta-

ble 1 shows some of these newly proposed met-

rics.

Finally, in order to establish our Metric Space

(cf. Section 3 and Figure 3) we created an additional

SecLA, where all security provisions were set to their

maximum value (LSL = 4).

4.3 Results

Our ﬁrst test consisted in applying the “RateMS” met-

rics (introduced in Section 3.2) to the two sets of

SecLAs described in Section 4.2. Figure 5 show our

obtained results for the three CSPs in STAR. It is in-

teresting to notice that despite CSP

had the highest

security level according to the CAIQ SecLA, once

we have considered the additional set of metrics (the

CAIQ+ SecLA) then it was CSP

the one with the bet-

ter security level associated to its Cloud SecLA. The

reason for this can be easily obtained after reading

both CAIQ reports: on the one hand, CSP

replied

“YES” to almost all the questions on the CAIQ but

their “Comments” were so generic that it was not

possible to obtain further quantitative data to evalu-

ate the additional set of 29 metrics on a reliable way.

SECRYPT2012-InternationalConferenceonSecurityandCryptography

Table 1: Some of the proposed security metrics for the CAIQ, based on the CSP’s responses found on the STAR repository

CID Consensus Assessment Questions Possible values

CO-01.Q1 Supported Audit Assertions formats None, Proprietary, Only one, More

than one

CO-02.Q1 Access requirements to third party audit reports Not speciﬁed, Only to customers, NDA

Required, NDA and written justiﬁca-

tion required

CO-02.Q2 Frequency of the network penetration tests Not speciﬁed, Once per-Year, Twice

per-Year, Monthly

IS-19.Q2 Tenants’ encryption keys management Not speciﬁed, Not supported, Provider

only, Shared management, User only

On the other hand, CSP

’s answers to the original

CAIQ contained more “NO” values than CSP

’s but

its “Comments” were by far much richer in infor-

mation to quantify the corresponding CAIQ+ SecLA.

This demonstrates that disclosing a greater level of

detail on the SecLA is beneﬁcial for the CSP. Also

notice that in all the cases the security levels associ-

ated with the CAIQ+ SecLAs were lower than those

obtained for the CAIQ SecLAs, this was in part be-

cause of the difference between both metric spaces

(MS

CAIQ

= 26.153 whereas MS

CAIQ+

= 28.284).

RateMS Metrics

90.00%

95.00%

100.00%

RateMS(CSP1) RateMS(CSP2) RateMS(CSP3)

CAIQ CAIQ+

Figure 5: Using the RateMS metric to quantitatively com-

pare CSPs. The higher RateMS is, the more security is be-

ing provided by the Cloud SecLA.

For our next test, let us suppose that a current cus-

tomer of CSP

wants to know if either CSP

or CSP

might provide her with a better SecLA. For this pur-

pose our hypothetical user ﬁrst applies the metric pro-

posed in Deﬁnition 2, using CSP

as a baseline. The

obtained results (see Figure 6) show that with the two

policy subsets (CAIQ and CAIQ+), both CSP

and

CSP

had approximately 20% of their provisions with

a higher security level than CSP

’s. However, it is no-

ticeable that the number of provisionswith a lower se-

curity level (∆

−

metric) was by far larger also for both

CSP

and CSP

(approximately 86% for the CAIQ

subset and, between 75% — 79% for the CAIQ+ sub-

set). Once again, the reason is clear when taking

a look at the responses found on the corresponding

CAIQ reports: CSP

replied either with a “YES” or

a better quantitative security value much more ques-

tions that the other providers.

Comparing CSP1 and CSP2 versus CSP3

0.00%

10.00%

20.00%

30.00%

40.00%

50.00%

60.00%

70.00%

80.00%

90.00%

100.00%

Delta+(CSP1) Delta-(CSP1) Delta+(CSP2) Delta-(CSP2)

CAIQ CAIQ+

Figure 6: Quantitatively comparing CSPs with the metric

from Deﬁnition 2.

Now the question that arises for the hypothetical

customer of CSP

is: how the different CSPs com-

pare on the individual categories of their respective

SecLAs? This question can be answered through the

BenchScore metric (cf. Deﬁnition 3), by benchmark-

ing the Cloud SecLAs from both CSP

and CSP

us-

ing as a baseline CSP

. Obtained results are shown

in Table 2, where the BenchScore metric was used

for this purpose (column “Pass” in Table 2), but also

was applied to quantitatively benchmark those Cloud

SecLA provisions from CSP

/CSP

which security

level (i.e., LSL as explained in Section 3.1) fell be-

hind the benchmark (column “Fail” in Table 2). The

results shown in Table 2’s CAIQ+ column are consis-

tent with our previous tests, because we observed that

QuantitativeAssessmentofCloudSecurityLevelAgreements-ACaseStudy

Table 2: Benchmarking CSP

and CSP

versus CSP

CSP

CAIQ CAIQ+ CAIQ CAIQ+

Pass Fail Pass Fail Pass Fail Pass Fail

BenchScore 97.66% 2.34% 87.50% 12.50% 90.06% 9.94% 90.50% 9.50%

CO 7.02% 1.17% 7.00% 7.00% 7.60% 0.58% 12.50% 1.50%

DG 8.77% 0.00% 8.00% 0.00% 8.77% 0.00% 8.00% 0.00%

FS 5.26% 0.00% 4.50% 0.00% 4.68% 0.58% 4.00% 0.50%

HR 2.34% 0.00% 2.00% 0.00% 2.34% 0.00% 2.00% 0.00%

IS 41.52% 0.00% 38.00% 3.50% 37.43% 4.09% 38.00% 3.50%

LG 1.17% 0.00% 1.00% 0.00% 1.17% 0.00% 1.00% 0.00%

OP 2.92% 0.00% 2.50% 0.00% 2.92% 0.00% 2.50% 0.00%

RI 6.43% 0.58% 5.50% 0.50% 7.02% 0.00% 6.00% 0.00%

RM 2.92% 0.00% 2.50% 0.00% 1.75% 1.17% 1.50% 1.00%

RS 5.85% 0.58% 5.00% 1.00% 5.85% 0.58% 5.50% 0.50%

SA 13.45% 0.00% 11.50% 0.50% 10.53% 2.92% 9.50% 2.50%

the number of “failed” provisions increased for CSP

with respect to CSP

(from 2.34% — 12.50%).

As mentioned in Section 3 and seen on Figure 7,

the proposed assessment metrics can be used at dif-

ferent levels of granularity varying from the Cloud

SecLA-level to the individual security provision-

level. With the quantitative level of detail being pro-

vided by the proposed metrics e.g., our hypothetical

user should be able to take a decision about chang-

ing her current CSP depending on how important for

her are the security provisions that “failed” the bench-

marking process. This “weighting” of individual pro-

visions is part of our future work, just as discussed in

Section 6.



































 !"#$

% %

Figure 7: Benchmarking a subset of security provisions for

two different CSPs.

5 RELATED WORK

SLA speciﬁcations and management is becoming an

essential component within several emerging tech-

nologies such as Cloud computing. In the past, SLA

speciﬁcations havebeen mainly considered in the Ser-

vice Oriented Architectures (SOAs) and Web services

ﬁelds like in (Andrieux, K., et.al., ) and (Ludwig, H.,

et.al., ). Unfortunately, one of the major limitations of

these approaches is that they do not take into consid-

eration security aspects even if the need for incorpo-

rating security in SLA was already highlighted some

years ago (Henning, R., 1999).

Despite in the last years some proposals have

started to consider security in SLAs, just very few

of these have focused on Cloud SecLAs. In par-

ticular we highlight (Bernsmed, K., et.al., 2011),

where the authors present a method for managing the

SecLA lifecycle in the context of federated Cloud ser-

vices. That work can be considered complementary

to our research, taking into account that the authors

of (Bernsmed, K., et.al., 2011) discuss the contents of

Cloud SecLAs, but do not further elaborate about the

techniques to quantitatively assess them.

In (Almorsy, M., et.al., 2011), the authors also

propose the notion of evaluating Cloud SecLAs. In

their paper, a metric is introduced to measure a CSP’s

“security categorization” of their information (either

per-tenant or per-service), based on impact metrics for

all the three dimensions of security — conﬁdentiality,

integrity and availability —. However, the resulting

security categorization is qualitative (i.e. specifying

the High, Medium or Low security ranges), contrary

to our quantitative security assessment metrics.

As mentioned in Section 1, to the best of our

SECRYPT2012-InternationalConferenceonSecurityandCryptography

knowledge there are no further works related with

the quantitative security assessment of CSPs and in

particular aimed to empirically validate their security

metrics with real CSP data. Nevertheless for the sake

of completeness, the rest of this section cites the ef-

forts from other Information Technology ﬁelds (e.g,

Web Services and Grid computing) aimed to adopt

and assess SecLAs.

In (Frankova, G. and Yautsiukhin, A., 2007) and

(Krautsevich, L., et.al., 2011), the authors propose a

technique to aggregate security metrics from a web

services’ SecLA, however contrary to our research

they did not propose the techniques to assess their

SecLAs neither empirically validate the proposed

metrics.

The Reference Evaluation Methodology — REM

— (as explained in Section 3.1) was originally pro-

posed in (Casola V., et.al., 2006). The authors intro-

duced a methodology that can be adopted whenever

there is the need of evaluating and comparing secu-

rity SLAs (despite not speciﬁcally Cloud-related) ex-

pressed through the use of standard policy languages.

A similar approach was used in (Casola V., et.al.,

2005) and (Casola, V. et.al., 2007) to quantify the se-

curity of a Public Key Infrastructure, based on its Cer-

tiﬁcate Policy. The security assessment presented in

our paper has been built above the methodology from

(Casola V., et.al., 2006) by quantitatively evaluating a

Cloud SecLA, but contrary to existing works we have

also contributed with: (i) an additional set of security

metrics to quantitatively assess the CSP, (ii) an ini-

tial Cloud SecLA speciﬁcation and, (iii) the building

blocks of an architecture aimed to empirically demon-

strate the assessment of the CSP.

In (De Chaves, S. A., et.al., 2010) the authors

highlight the importance of incorporating security

metrics in SLAs and, in particular, of controlling

and monitoring whether the security metrics are met.

However, contrary to our paper, no further details are

provided about the techniques used to represent and

assess these SLAs.

A metric-based approach for assessing the secu-

rity level of Critical Infrastructures was presented

in (Ghani, H., et.al., 2010). In that article the au-

thors deﬁne appropriate security metrics to monitor

whether the established security requirements are ful-

ﬁlled. Such metrics are also used for the deﬁnition

of SLAs that should capture the deﬁned requirements

as well as the guarantees that the system provides to-

gether with the penalties that have to be applied when

such guarantees are not met. The present paper took

into account our previous experiences from (Luna, J.,

et.al., 2011), in order to contribute with the metrics

and testbed to quantitatively assess Cloud SecLAs.

The works presented in (Irvine, C. and Levin, T.,

2001) and (Neto, A., et.al., 2011) are also related

with the assessment metrics presented in this paper.

In (Irvine, C. and Levin, T., 2001), the authors sup-

port the notion of “Quality of Security” (similar to our

SecLA quantiﬁcation) and the usefulness of security

ranges for quantifying security. Both arguments are

directly related with the security quantiﬁcation tech-

nique used by our framework (cf. Section 3). In

(Neto, A., et.al., 2011) the authors present one of the

few works related with security benchmarking. From

their perspective trust can be used to benchmark secu-

rity by performing the enumeration and accumulation

of the evidence in favor of security that exists in a sys-

tem, in the form of security mechanisms, processes,

conﬁgurations, procedures and behaviors that prevent

the accomplishment of speciﬁc threats that the sys-

tem may be subjected to. These notions are directly

related with the use of metrics for benchmarking se-

curity in our CSP assessment.

Finally, from an industrial perspective SecLAs

must also be considered in security management regu-

lations and standards as mentioned in (Monahan, B.

and Yearworth, M., 2008). The Information Tech-

nology Infrastructure Library (ITIL) is one of the

most prestigious good practices regarding IT Services

Management and, some works have been done on

modeling SLAs considering risks that threaten busi-

ness processes and the requisites detailed in the Ser-

vice Level Management module from ITIL (Feglar,

T., 2004). However, contrary to the approach pre-

sented in our paper the techniques for quantitatively

assessing these SecLAs in ITIL were not proposed in

(Monahan, B. and Yearworth, M., 2008) nor (Feglar,

T., 2004).

6 CONCLUSIONS

In this paper we have presented a practical CSP’s

security assessment use case based on (i) the con-

cept of Security Level Agreements and, (ii) a novel

set of quantitative security assessment metrics. This

practical security assessment has been applied to the

CSP’s information stored in the STAR repository of

the Cloud Security Alliance. To the best of our knowl-

edge there are no previous works related with the

quantitative security assessment of CSPs, and in par-

ticular aimed to empirically validate the applicability

of their security metrics with real CSP data.

The obtained results show that the proposed se-

curity assessment can be performed at different lev-

els of the CSP, ranging from the Cloud SecLA-level

to the individual security provision-level. Our results

QuantitativeAssessmentofCloudSecurityLevelAgreements-ACaseStudy

also demonstrate the need to create meaningful quan-

titative security metrics for CSPs, because despite the

usefulness of initiatives like STAR, it is clear that the

more information is provided by the CSP the more

useful it will become to the end user. Fortunately,

some ongoing works are taking place in work groups

like CSA’s Security Metrics WG (Cloud Security Al-

liance, 2011a) to create and motivate the use of these

more quantitative security metrics for the Cloud.

We have adopted the REM technique to quantify

Cloud SecLAs (as presented in Section 3.1), in partic-

ular due to the ﬂexibility it offers to model and eval-

uate most classes of security policies. However, our

future work will also consider the adoption of other

SecLA evaluation techniques that might appear in the

near future (e.g., the scoring model being developed

by the Common Assurance Maturity Model commu-

nity (Samani, R., et.al., 2011)).

The contributed security assessment metrics (cf.

Section 3) are “Cloud SecLA-neutral”, in the sense

that they are able to work with different security cri-

teria and standards. The only pre-requisite is to deﬁne

the appropriate Cloud SecLA-templates to evaluate

with the REM (as described in Section 3.1). Our cur-

rent efforts in working groups like the CSA are aimed

towards this objective. For example, we expect that

in the near future it might be possible to create and

assess SecLAs derived from both the threat analysis

of real CSP architectures and, existing standards like

e.g., ISO27001 and PCI.

Research works like the one presented in this pa-

per will aid to trigger security transparency and new

types of SecLA-based services in CSPs. Our belief

is that SecLAs will become in the short term a key

factor to enable competition between CSPs based on

security properties.

The work in this paper is not aimed to substi-

tute the Cloud security auditing function. In contrary,

our security assessment rests on the belief that Cloud

SecLAs are trusted in the sense that they have been

previously audited by experts. This is precisely the

base to build the security assurance needed by Cloud

users, just as mentioned in Section 1.

The security assessment presented in this paper is

part of a broader research focusing on quantifying the

end-to-end security in CSPs, because the CSP’s se-

curity level perceived by an end user will depend on

the whole IT-chain, including the security behavior of

the intermediate ISP, the requested CSP and the end

user themselves. The most clear example is related to

availability: despite a CSP advertises 99.99% of ser-

vice availability, in the real-world it will depend on

the availability of intermediate ISPs.

Future work will complement our security assess-

ment metrics (cf. Section 3) with the techniques to

weight individual security provisions and to aggre-

gate, negotiate, predict and tune Cloud SecLAs based

not only on “declarative” information (e.g., the one

from the STAR repository), but also on real-time data

gathered from the service provider’s infrastructure.

The testbed presented in Section 4.1 can be further

improved taking into account both this real-time fea-

ture and the idea of deploying publicly available se-

curity assessment services for the Cloud.

Our ﬁnal goal is the creation of techniques and

tools to empower end users through providing choices

of service providers via the use of end-to-end secu-

rity metrics. Users will be provided with adequate

support to make informed decisions regarding the

trustworthiness of an IT system to enable them to

react depending on the changing conditions of the

system in terms of security and trust. As a conse-

quence, the conﬁdence in the use of IT systems will

increase. End users will also obtain a transparent view

on the SecLAs agreed or expected from their service

providers (Internet Service Providers included), thus

re-balancing the current unequal relationship between

both parties.

ACKNOWLEDGEMENTS

Research supported in part by EC FP7 IP

ABC4TRUST and Loewe TUD CASED.

REFERENCES

Almorsy, M., et.al. (2011). Collaboration-Based Cloud

Computing Security Management Framework. In

Proc. of the IEEE International Conference on Cloud

Computing, pages 364–371.

Andrieux, K., et.al. Web Services Agreement Speci-

ﬁcation (WS-Agreement). Technical Report TR-

WSAgreement-2007, Open Grid Forum.

Bernsmed, K., et.al. (2011). Security SLAs for Federated

Cloud Services. In Proc. of the IEEE Sixth Interna-

tional Conference on Availability, Reliability and Se-

curity, pages 202–209.

Boyle K., et.al. (2010). The CIS security metrics. Technical

Report TR-28, Center for Internet Security.

Casola V., et.al. (2005). A Reference Model for Security

Level Evaluation: Policy and Fuzzy Techniques. Jour-

nal of Universal Computer Science, pages 150–174.

Casola V., et.al. (2006). A SLA evaluation methodology in

Service Oriented Architectures. In Quality of Protec-

tion, volume 23 of Springer Advances in Information

Security, pages 119–130.

Casola, V., et.al. (2007). Interoperable Grid PKIs Among

Untrusted Domains: An Architectural Proposal. In

SECRYPT2012-InternationalConferenceonSecurityandCryptography

Advances in Grid and Pervasive Computing, volume

4459 of Springer Lecture Notes in Computer Science,

pages 39–51.

Casola, V. et.al. (2007). Static evaluation of Certiﬁcate Poli-

cies for Grid PKIs interoperability. In Proc. of the

IEEE Second International Conference on Availabil-

ity, Reliability and Security, pages 391–399.

Center for Internet Security (2009). User Guide for CIS-

CAT. Online: http://benchmarks.cisecurity.org/en-

us/docs/user-guides/CIS-CAT-Users-Guide.pdf.

Cloud Security Alliance (2011a). Se-

curity metrics workgroup. Online:

http://www.cloudsecurityalliance.org/Research.html.

Cloud Security Alliance (2011b). The Consensus

Assessments Initiative Questionnaire. Online:

https://cloudsecurityalliance.org/research/cai/.

Cloud Security Alliance (2011c). The Security,

Trust & Assurance Registry (STAR). Online:

https://cloudsecurityalliance.org/star/.

De Chaves, S. A., et.al. (2010). SLA perspective in secu-

rity management for Cloud computing. In Proc. of the

IEEE Sixth International Conference on Networking

and Services, pages 212–217.

Dekker, M. and Hogben, G. (2011). Survey and analysis

of security parameters in cloud SLAs across the Euro-

pean public sector. Technical Report TR-2011-12-19,

European Network and Information Security Agency.

Feglar, T. (2004). ITIL based Service Level Management

if SLAs cover Security. Journal on Systemics, Cyber-

netics and Informatic, pages 61–71.

Frankova, G. and Yautsiukhin, A. (2007). Service and

protection level agreements for business processes.

In Proc. of the IEEE Second European Young Re-

searchers Workshop on Service Oriented Computing,

page 38.

Ghani, H., et.al. (2010). Assessing the Security of Inter-

net Connected Critical Infrastructures (The CoMiFin

Project Approach). In Proc. of the Workshop on Secu-

rity of the Internet of Things.

Henning, R. (1999). Security service level agreements:

quantiﬁable security for the enterprise? In Proc. of

the ACM Workshop on New security paradigms, pages

54–60.

Irvine, C. and Levin, T. (2001). Quality of security ser-

vice. In Proc. of the ACM Workshop on New security

paradigms, pages 91–99.

Jansen, W. (2010). Directions in security metrics re-

search. Technical Report TR-7564, National Institute

for Standards and Technology.

Krautsevich, L., et.al. (2011). A general method for assess-

ment of security in complex services. In Towards a

Service-Based Internet, volume 6994 of Springer Lec-

ture Notes in Computer Science, pages 153–164.

Ludwig, H., et.al. Web Service Level Agreement (WSLA)

Language Speciﬁcation. Technical Report TR-

WSLA-2003-01-28, IBM.

Luna, J. et.al. (2008). Providing security to the Desktop

Data Grid. In Proc. of the IEEE International Sym-

posium on Parallel and Distributed Processing, pages

1–8.

Luna, J., et.al. (2011). A Security Metrics Framework for

the Cloud. In Proc. of the INSTICC Internation Con-

ference on Security and Cryptography, pages 245–

250.

Monahan, B. and Yearworth, M. (2008). Meaningful secu-

rity SLAs. Technical Report TR-HPL-2005-218, HP

Labs.

Neto, A., et.al. (2011). To benchmark or not to benchmark

security: That is the question. In Proc. of the IEEE

Dependable Systems and Networks Workshops, pages

182–187.

Samani, R., et.al. (2011). Common Assurance Maturity

Model: Scoring Model. Online: http://common-

assurance.com/.

Trimintzios, P. (2011). Measurement Frameworks and Met-

rics for Resilient Networks and Services. Discussion

Draft. European Network and Information Security

Agency.

Verendel, V. (2009). Quantiﬁed security is a weak hy-

pothesis: a critical survey of results and assump-

tions. In Proc. of the ACM Workshop on new security

paradigms, pages 37–50.

Weisstein, W. (2011a). Frobenius Norm. Online:

http://mathworld.wolfram.com/FrobeniusNorm.html.

Weisstein, W. (2011b). L1-Norm. Online:

http://mathworld.wolfram.com/L1-Norm.html.

QuantitativeAssessmentofCloudSecurityLevelAgreements-ACaseStudy
