Generics and Reverse Generics for Pharo

Alexandre Bergel

1∗

and Lorenzo Bettini

2†

Pleiad Lab, Computer Science Department (DCC), University of Chile, Santiago, Chile

Dipartimento di Informatica, Universit

a di Torino, Torino, Italy

Keywords:

Generic Programming, Pharo, Dynamically Typed Languages.

Abstract:

Generic programming is a mechanism for re-using code by abstracting speciﬁc types used in classes and

programs. In this paper, we present a mechanism for adding generic programming in dynamically typed

languages, showing how programmers can beneﬁt from generic programming. Furthermore, we enhance the

expressiveness of generic programming with reverse generics, a mechanism for automatically deriving new

generic code starting from existing non-generic one. We implemented generics and reverse generics in Pharo

Smalltalk, and we successfully used them to solve a problem of reusing unit test cases. This helped us to

identify a number of bugs and anomalies in the stream class hierarchy.

1 INTRODUCTION

The notion of generic programming has been origi-

nally introduced in statically typed programming lan-

guages to ease manipulation and reuse of collection

classes and algorithms. On the other hand, because of

their ﬂexible type systems, dynamically typed object-

oriented languages have been left out of the scope of

generic programming. The need for generic program-

ming in a dynamically typed setting has been less

prominent since no restriction applies over the kind

of elements a collection may contain.

Furthermore, in a dynamically typed language like

Smalltalk, where types are absent in declarations of

linguistic entities (like methods, ﬁelds, local vari-

ables), it might look odd to talk about generic pro-

gramming. However, there is still a crucial context

where types (i.e., class names) appear statically: class

references. When creating an object, the class name is

hardcoded in the program, and this makes the object

instantiation process hard to abstract from.

There are well-known patterns to deal with this

problem, such as Factory Method (Gamma et al.,

1995), Dependency Injection (Fowler, 2004), Virtual

classes (Bracha et al., 2010) and ad-hoc linguistic

constructs (Cohen and Gil, 2007). However, these

∗

This author has been partially supported by Program U-

INICIA 11/06 VID 2011, grant U-INICIA 11/06, University

of Chile, and FONDECYT 1120094.

†

This author was partially supported by MIUR (Project

PRIN 2008 DISCO).

mechanisms are effective when future extensions are

foreseen. They provide little help in a scenario of

unanticipated code evolution in which the program-

ming language does provide dedicated evolutionary

construct. This paper is about ﬁxing this issue for dy-

namically typed languages using generics.

As popularized by mainstream statically typed

programming languages, generic programming pro-

vides a mechanism for deﬁning template classes

where some types are variables/parameters and then

for providing arguments for those type variables, thus

instantiating template classes into concrete and com-

plete classes. In the following, we then use the

term template class to refer to a class where some

types are parametrized; accordingly, we refer to a

concrete/complete class when all the arguments for

parametrized types are provided.

Reverse generics (Bergel and Bettini, 2011) is the

dual mechanism that enables the deﬁnition of a tem-

plate class from a complete class. We call this mecha-

nism generalization. It allows obtaining a brand new

generic class from an existing class by “removing”

hardwired class references, and by replacing them

with parametrized types. For instance,

G<T> = C>C’<

generates the new generic class G<T> starting from

the class C by replacing each reference of a class C’

contained in C with the type parameter T in G. It is the

dual operation of the instantiation operation offered

by generics. The generic G may be instantiated into

G<U> for a provided class U. Note that, the reverse

363

Bergel A. and Bettini L..

Generics and Reverse Generics for Pharo.

DOI: 10.5220/0004027503630372

In Proceedings of the 7th International Conference on Software Paradigm Trends (ICSOFT-2012), pages 363-372

ISBN: 978-989-8565-19-8

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

generics mechanism satisﬁes the property

C = (C>T<) <T>.

Finally, an important point is that the original class

C remains unmodiﬁed. Indeed, reverse generics are

useful under the basic assumptions that (i) the code to

be reused has to be left intact (it cannot be the subject

of refactoring) and (ii) the host programming does not

implicitly support for looking up classes dynamically

(as this is the case in most dynamically languages, ex-

cept NewSpeak the supports virtual classes (Bracha

et al., 2010)). In particular, we aim at providing,

through our implementation of reverse generics, a

generative approach, where new generic code is (au-

tomatically) generated starting from existing one, and

the latter will not be modiﬁed at all; for this reason,

reverse generics are not, and they do not aim at, a

refactoring technique (we also refer to Section 7).

This paper extends the Pharo Smalltalk program-

ming language with generics and reverse generics.

We adapted the reverse generics to cope with the

lack of static type information (in (Bergel and Bettini,

2011) reverse generics were studied in the context of

statically typed languages such as Java and C++). Re-

quirements on type parameters can be deﬁned as a

safety net for a sound instantiation; we provide mech-

anisms for structural and nominal requirements both

for generics and reverse generics in Pharo.

The generic mechanisms we implemented do not

depend on any Pharo facilities suggesting that gener-

ics and reverse generics are likely to be transpos-

able to other dynamically typed languages. Although

it has been realized in a dialect of Smalltalk, noth-

ing prevents them from being applied to Ruby and

Python. Even though similar mechanisms have been

proposed in Groovy (Axelsen and Krogdahl, 2009),

to the best of our knowledge, this is the ﬁrst attempt

to add a generic-like construct to Smalltalk. (The

Groovy case is discussed in the related work section).

We employed reverse generics to face a classical

code reuse problem. Unit tests in Pharo are inher-

ited from Squeak, a Smalltalk dialect that served as

a base for Pharo. Those tests have been written in a

rather disorganized and ad-hoc fashion. This situation

serves as the running example of this paper and was

encountered when evolving the Pharo runtime. This

helped us identify a number of bugs and anomalies in

the stream class hierarchy.

The contributions and innovations of this paper

are summarized as follows: (i) deﬁnition of a mecha-

nism for generics in Pharo (Section 2); (ii) description

of the reverse generics model in Pharo (Section 4);

(iii) description of the implementation of both mech-

anisms (Section 5); (iv) applicability to a non triv-

ial case study (Section 6). Section 7 summarizes the

related work and Section 8 concludes the paper and

gives some perspectives on future work.

2 GENERICS IN PHARO

This section presents a mechanism for generic pro-

gramming for the Pharo/Smalltalk programming lan-

guage

. The presentation of the mechanism is driven

by a test-reuse scenario. We will ﬁrst deﬁne a test

called GCollectionTest. This test will be free from a

particular class of the collection framework. GCollec-

tionTest will be instantiated twice, for two different ﬁx-

tures based on OrderedCollection and SortedCollection

Consider the following code snippet containing a

test that veriﬁes elements addition.

”Creation of the class T”

GenericParameter subclass: #T

”Creation of the class GCollectionTest with a variable”

TestCase subclass: #GCollectionTest

instanceVariableNames: ’collection’

”Deﬁnition of the setUp method”

”It instantiates T and add 3 numbers in it”

GCollectionTest>> setUp

collection := T new.

collection add: 4; add: 5; add: 10.

”Deﬁnition of the test method testAddition”

”It adds an element in the collection deﬁned in setUp”

GCollectionTest>> testAddition

| initialSize |

initialSize := collection size.

collection add: 20.

self assert: (collection includes: 20).

self assert: (collection size = (initialSize + 1)).

GCollectionTest is a pretty standard unit test in the

spirit of the xUnit framework (most of the 115 classes

that test the Pharo collection library follow a very

similar structure). No reference to a collection class

is made by GCollectionTest. The method setUp refers

to the empty class T. GCollectionTest may be instanti-

ated into OrderedCollectionTest and SortedCollectionTest

as follows:

”Instantiate GCollectionTest and replace

occurrences of T by OrderedCollection”

(GCollectionTest @ T-> OrderedCollection)

as: #OrderedCollectionTest

”Replace T by SortedCollection”

(GCollectionTest @ T -> SortedCollection)

as: #SortedCollectionTest

http://www.pharo-project.org

A ﬁxture refers to the ﬁxed state used as a baseline for

tests. We consider the setUp method only in our situation.

ICSOFT2012-7thInternationalConferenceonSoftwareParadigmTrends

364

The generic class GCollectionTest has been instan-

tiated twice, each time assigning a different class to

the parameter T. We adopted the convention of deﬁn-

ing generic parameter as subclasses of GenericParam-

eter. This convention has a number of advantages, as

discussed in Section 5. Since GCollectionTest contains

references to T, it is a generic class. There is therefore

no syntactic distinction between a class and a generic

class. GCollectionTest is a generic class only because T

is a generic parameter and T is referenced in setUp.

Pharo has been extended to support the (... @ ... ->

...) as: ... construct. These three operators deﬁnes the

life cycle of a generic in Pharo.

Compared to the Java generics mechanism, gener-

ics for Pharo operates on class references instead of

types. A class provided as parameter may be freely in-

stantiated, as in the example above. Generics in Pharo

are similar to a macro mechanism. In that sense, it

shares similarities with C++ templates but using a dy-

namically type stance.

3 REQUIREMENTS FOR

GENERIC PARAMETERS

In order for a generic class to be instantiated, a class

needs to be provided for each generic parameter. To

prevent generic instantiation to be ill-founded, re-

quirements for a generic parameter may be declared.

These requirements are enforced when a generic

class is instantiated. Requirements are formulated

along nominal and structural deﬁnitions of the base

code.

Nominal Requirements. Static relationship between

types may be veriﬁed when instantiating a generic

class. In the example above, T must be a subtype of

Collection

. This is speciﬁed by deﬁning a method re-

quirements that returns myself inheritsFrom: Collection:

T>> requirements

ˆ(myself inheritsFrom: Collection)

In that case, instantiation of GCollectionTest raises

an error if a class that is not a subclass of Collection is

provided as parameter.

Note that we introduced the myself pseudo vari-

able. This variable will be bound to the class provided

as the generic parameter when being instantiated.

The variable self, which references the receiver

object, cannot be used within requirements.

We use the following convention: a class is a type when

considered at compile time, and it is an object factory at

runtime.

Structural Requirements. In addition to nominal re-

quirements, a generic parameter may be also struc-

turally constrained. A constraint is satisﬁed based on

the presence of some particular methods. In the ex-

ample above, a method check may return

myself includesSelectors: {#add: . #includes: . #size}

In that case, only a class that implements the method

add:, includes:, and size can be provided in place of T.

We express a requirement as a boolean expression.

The keyword inheritsFrom: and includesSelectors: are

predicates. They may therefore be combined using

boolean logic operators. For instance, we can express

all the above requirements as follows:

T>> requirements

ˆ(myself inheritsFrom: Collection)

and: [myself includesSelectors:

{#add: . #includes: . #size}]

Dynamically typed languages favor sophisticated

debugging and testing sessions over static source code

veriﬁcation. The lack of static type annotation makes

any isolated check on a generic not feasible. Com-

pleteness of T’s requirements cannot be veriﬁed by

the compiler, thus, it is up to the programmers to pro-

vide a set of satisfactory requirements when deﬁning

generic parameters. In practice, this has not been a

source of difﬁculties.

4 REVERSE GENERICS IN

PHARO

This section presents the reverse generics mecha-

nism in Pharo; we will use a scenario that consists

of reusing unit tests. Consider the following class

WriteStreamTest taken from an earlier version of Pharo:

ClassTestCase subclass: #WriteStreamTest

WriteStreamTest >> testIsEmpty

| stream |

stream := WriteStream on: String new.

self assert: stream isEmpty.

stream nextPut: $a.

self deny: stream isEmpty.

stream reset.

self deny: stream isEmpty.

The class WriteStreamTest is deﬁned as a subclass

of ClassTestCase, itself a subclass of SUnit’s TestCase.

WriteStreamTest deﬁnes the method testIsEmpty, which

checks that a new instance of WriteStream is empty

(i.e., answers true when isEmpty is sent). When the

character $a is added into the stream, it is not empty

anymore. And resetting a stream moves the stream

GenericsandReverseGenericsforPharo

365

pointer at the beginning of the stream, without remov-

ing its contents. WriteStreamTest has 5 other similar

methods that verify the protocol of WriteStream.

We consider that most of the important features of

WriteStream are well tested. However, WriteStream has

27 subclasses, which did not receive the same atten-

tion in terms of testing. Only 3 of these 27 classes

have dedicated tests (FileStream, ReadWriteStream and

MultiByteFileStream). Manually scrutinizing these 3

classes reveals that the features tested are different

than the one tested in WriteStreamTest

The remaining 24 subclasses of WriteStream are ei-

ther not tested, or indirectly tested. An example of an

indirect testing: CompressedSourceStream is a subclass

of WriteStream for which the feature of WriteStream

are not tested. CompressedSourceStream is essentially

used by the ﬁle system with FileDirectory, which is

tested in FileDirectoryTest.

The situation may be summarized as follows:

WriteStream is properly tested and has 22 subclasses,

but none of these subclasses have the features deﬁned

in WriteStream tested for their particular class.

This situation has been addressed by refactoring

the collection framework using TraitTest (Ducasse

et al., 2009). We make a different assumption here:

the base system must be preserved, which implies that

a refactoring is not desirable. Refactoring may have

some implications on the overall behavior, especially

in terms of robustness and efﬁciency. It has been

shown that inheritance is not that helpful in this sit-

uation (Flatt and Felleisen, 1998; Bergel et al., 2005).

With our implementation of reverse generics in

Pharo, a generic class GStreamTest can be obtained

from the class WriteStreamTest by turning all refer-

ences of WriteStream into a parameter that we name

Generic

named: #GStreamTest

for: WriteStream -> T @ WriteStreamTest

Following a Java-like syntax (Bergel and Bettini,

2011), the above code corresponds to the following

reverse generic deﬁnition:

class GStreamTest<T> = WriteStreamTest>WriteStream<

The generic GStreamTest is deﬁned as a copy of

WriteStreamTest for which all references to WriteStream

have been replaced by the type T introduced in the

previous section (Section 2). GStreamTest may now be

instantiated by replacing all references of WriteStream

with untested subclasses of WriteStream as illustrated

in Section 2:

According to our experience, this is a general pat-

tern. Often programmers focus essentially on testing added

methods and variable when subclassing.

”Instantiate GStreamTest and replace occurrences of T

by ZipWriteStream”

(GStreamTest @ T-> ZipWriteStream)

as: #ZipWriteStreamTest

”Replace T by HtmlFileStream”

(GStreamTest @ T -> HtmlFileStream)

as: #HtmlFileStreamTest

Figure 1 summarizes the generalization and in-

stantiation of the WriteStreamTest example. Reverse

generic targets class instantiation and sending mes-

sages to a class.

The above scenario could be solved by having a

super abstract class in which the class to be tested

is returned by a method. This method could then be

overridden in subclasses (factory method design pat-

tern (Gamma et al., 1995)). However, this solution

is not always the best approach: First, tests of the

collection libraries cannot be optimally organized us-

ing single inheritance (Ducasse et al., 2009). Second,

the code to be reused may not always be editable and

modiﬁable. This is often a desired property to mini-

mize ripple effects across packages versions.

4.1 Requirements when Generalizing

We have previously seen that requirements may be

deﬁned on generic parameters (Section 3). These re-

quirements equally apply when generalizing a class.

Turning references of WriteStream into a parameter T

may be constrained with the following requirements:

T>> requirements

ˆ(myself inheritsFrom: Stream)

and: [ myself includesSelectors: {#isEmpty . #reset} ]

Further requirements could be that the parame-

ter T understands the class-side message on:, and the

instance-side message nextPut:. However, this will

be redundant with the requirement myself inheritsFrom:

Stream, since Stream deﬁnes the method nextPut: and

on:.

Requirements may also be set for class methods,

e.g.,myself class includesSelector: {#new: } makes the

presence of the class method new: mandatory.

4.2 Capturing Inherited Methods

Instantiating a generic G, which is obtained from gen-

eralizing a class C, makes copies of C with connec-

tions to different classes. This process may also copy

superclasses of C when methods deﬁned in super-

classes need to have new references of classes. This

situation is illustrated in Figure 2.

A different example is adopted in this ﬁgure. The

class AbstractFactory has an abstract method create.

ICSOFT2012-7thInternationalConferenceonSoftwareParadigmTrends

366

testIsEmpty

testNextPut

...

WriteStreamTest

testIsEmpty

testNextPut

...

GStreamTest

testIsEmpty

testNextPut

...

ZipWriteStreamTest

testIsEmpty

testNextPut

...

HtmlFileStreamTest

Generalization:

GStreamTest =

WriteStreamTest>WriteStream<

Generic

instantiation:

HtmlFileStreamTest =

GStreamTest<HtmlFileStream>

Generic

instantiation:

ZipWriteStreamTest =

GStreamTest<ZipWriteStream>

| stream |

stream := WriteStream

on: String new.

self assert: stream isEmpty.

...

| stream |

stream := HtmlFileStream

on: String new.

self assert: stream isEmpty.

...

| stream |

stream := ZipWriteStream

on: String new.

self assert: stream isEmpty.

...

| stream |

stream := T

on: String new.

self assert: stream isEmpty.

...

Figure 1: Reusing WriteStreamTest.

PointFactory is a subclass of it that creates instances

of Point (not represented on the ﬁgure). This class is

subclassed into EnhPointFactory that overrides create to

count the number of instances that have been created.

Consider the generic

GEnhFactory<T> = EnhPointFactory>Point<.

This generic may be instantiated with a class Car to

produce cars instead of points:

CarFactory = GEnhFactory<Car>.

The class Point is referenced by the superclass of

EnhPointFactory. Generalizing and instantiating Enh-

PointFactory has to turn the Point reference contained in

PointFactory into Car. This is realized in reverse gener-

ics by automatically copying also the superclass into

a new generic class with a generated name.

The class inheritance is copied until the point

in the hierarchy where no superclass references a

generic parameter.

5 IMPLEMENTATION

The homogeneity of Pharo and in general of most

of Smalltalk dialects greatly eases the manipulation

of a program structural elements such as classes and

methods. In Smalltalk, classes and methods are ﬁrst-

class entities. They can be manipulated as any ob-

ject. A compiled method is a set of bytecode instruc-

tions with an array of literals. This array contains

all references to classes being used by this compiled

method (Goldberg and Robson, 1983).

Instantiating a generic is made by copying a class,

assigning a different name, and adjusting the array of

literals with a different set of class bindings. An ex-

ample of this procedure is depicted in Figure 3.

A number of design decisions were made:

• The Pharo syntax has not been modiﬁed. This has

the great advantage of not impacting the current

development and source code management tools.

This is possible since classes are ﬁrst-class objects

in Pharo.

• The Smalltalk meta-object protocol has not been

extended. Again, this decision was made to limit

the impact on the development tools. As a conse-

quence, there is no distinction between a generic

and a class, thus the generic mechanism can be

implemented as a simple library to load.

Indeed these design choices are based also on

past experience in Smalltalk extensions: the last

signiﬁcant change of the language was realized in

2004 (Lienhard, 2004), when traits have been intro-

duced in Squeak, the predecessor of Pharo. In the

current version of Pharo, the support of traits is frag-

ile at best (bugs are remaining and many tools are not

traits aware). This experience gained with traits sug-

gests that realizing a major change in the program-

ming language is challenging and extremely resource

consuming.

GenericsandReverseGenericsforPharo

367

create

AbstractFactory

Object

create

^ Point new

PointFactory

create

super create.

counter := counter + 1

counter

EnhPointFactory

create

^ Car new

*GeneratedName 2*

create

super create.

counter := counter + 1

counter

CarFactory

CarFactory =

GEnhFactory<Car>

create

^ T new

*GeneratedName 1*

create

super create.

counter := counter + 1

counter

GEnhFactory

GEnhFactory =

EnhPointFactory>Point<

Figure 2: Copying superclasses, illustrated with a generic class factory.

testNextPut

testIsEmpty

...

WriteStreamTest

TestCase

45 <41> pushLit: WriteStream

46 <42> pushLit: String

47 <CC> send: new

48 <E0> send: on:

49 <68> popIntoTemp: 0

50 <70> self

...

testNextPut

testIsEmpty

...

ZipWriteStreamTest

45 <41> pushLit: ZipWriteStream

46 <42> pushLit: String

47 <CC> send: new

48 <E0> send: on:

49 <68> popIntoTemp: 0

50 <70> self

...

testNextPut

testIsEmpty

...

HtmlFileStreamTest

45 <41> pushLit: HtmlFileStream

46 <42> pushLit: String

47 <CC> send: new

48 <E0> send: on:

49 <68> popIntoTemp: 0

50 <70> self

...

Figure 3: Final results when ZipWriteStreamTest and HtmlFileStreamTest have been produced.

Note that, by using our reverse generics, one

can modify only the original existing code (i.e., the

classes that are not generic), and then, automatically,

spread the modiﬁcations to the one obtained by re-

verse generics.

The implementation presented in this paper

is freely available (under the MIT license) at

http://www.squeaksource.com/ReverseGeneric.html.

6 CASE STUDY: APPLICATION

TO THE PHARO STREAM

HIERARCHY

The situation described in Section 4 is an excerpt of

the case study we realized. For each of the 24 sub-

classes of WriteStream, we instantiated GStreamTest.

This way, about 24 new unit tests were generated.

The WriteStreamTest class deﬁnes 6 test methods. We

therefore generated 24 * 6 = 144 test methods. Each

of the generated test is a subclass of ClassTestCase,

which itself deﬁnes 3 test methods. Running these 24

unit tests executes 144 + 27 * 3 = 225 test methods.

Running these 225 test methods results in: 225

runs, 192 passed, 21 failures, 12 errors. Since the

6 tests in WriteStreamTest pass, this result essentially

says that there are some functionalities that are veri-

ﬁed for WriteStream, but they are not veriﬁed for some

of its subclasses. An example of the culprit test meth-

ods for the failures are CrLfFileStreamTest>> testNew

and LimitedWriteStreamTest>> testSetToEnd. The fact

that these two tests fail uncovers some bugs in the

classes CrLfFileStream and LimitedWriteStream.

The body of CrLfFileStreamTest>> testNew is

self should: [CrLfFileStream new] raise: Error

meaning that a CrLfFileStream should not be instanti-

ated with new. However, the class can actually be

instantiated with new, resulting in a meaningless and

unusable object.

Another example of a bug was found in Limited-

ICSOFT2012-7thInternationalConferenceonSoftwareParadigmTrends

368

WriteStream. This class is used to limit the amount

of data to be written in a stream. The body of

LimitedWriteStreamTest>> testSetToEnd is:

LimitedWriteStreamTest>> testSetToEnd

| string stream |

string := ’hello’.

stream := LimitedWriteStream with: ”.

stream nextPutAll: string.

self assert: stream position = string size.

stream setToEnd.

self assert: stream position = string size.

self assert: stream contents = string

It essentially veriﬁes the behavior of the stream

index cursor. This test signals an error in the ex-

pression stream nextPutAll: string. By inspecting what

triggered the error, we discovered that when a Limit-

edWriteStream is instantiated with with: ”, the object is

initialized with a nil value as the limit, resulting in a

meaningless comparison (newEnd > limit in the method

LimitedWriteStream>> nextPutAll:).

Not all the test methods that fail and raise an er-

ror are due to some bugs in the stream class hierar-

chy. We roughly estimate that only 11 test methods

of these 33 methods have uncovered tangible bugs.

The remaining failures and errors are due to some dif-

ferences on how class should be initialized. For ex-

ample, the test StandardFileStreamTest>> testSetToEnd

raises an error because a StandardFileStream cannot be

instantiated with the message with: (it is instantiated

with ﬁleNamed:, which requires a ﬁle name as argu-

ment). Although no bug have been located, this er-

roneous test method suggests that the method write:

should be canceled (i.e., raise an explicit error saying

it should be not invoked).

This experiment has a number of contributions:

• it demonstrates the applicability of our generics

and reverse generics to a non-trivial scenario,

• it helped us identify a number of bugs and anoma-

lies in the Pharo stream hierarchy.

7 RELATED WORK

When Java generics were designed, one of the main

intent was to have the backward compatibility with

the existing Java collection classes. The enabling

mechanism is that all the generic type parameters

must be “erased” after the compilation (type erasure

model (Odersky and Wadler, 1997; Bracha et al.,

1998)). Therefore, all the run-time type information

about parametrized types are completely lost after the

compilation, thus making impossible to execute all

the operations which require run-time types, such as,

e.g., object instantiations. This limits the expressive-

ness of Java generics (Allen and Cartwright, 2002):

for instance, if T is a generic type, the code T x = new

T() is not valid.

For these reasons, the generic type system of Java

cannot be considered “ﬁrst-class”, since generic types

cannot appear in any context where standard types can

appear (Allen et al., 2003).

On the contrary, the generic programming mech-

anisms provided by C++ do not suffer from all these

issues. In particular, the C++ compiler generates a

different separate copy for each generic class instanti-

ated with speciﬁc types (and the typechecking is per-

formed on the instantiated code, not on the generic

one). Therefore, while in Java a Collection<String>

and a Collection<Integer> would basically refer to the

same class (i.e., the type erased class Collection), in

C++ they would refer to two separate classes, where

all the type information remains available. There-

fore, in C++, all the operations which require run-

time types are still available in generic classes, and

hence the C++ type generic system can be considered

“ﬁrst-class” (notably, C++ templates were formalized

and proved type safe (Siek and Taha, 2006)). For in-

stance, if T is a generic type, the code T *x = new T() in

C++ is perfectly legal, since C++ templates are sim-

ilar to a macro expansion mechanism

. We refer to

Ghosh (Ghosh, 2004) and Batov’s work (Batov, 2004)

for a broader comparison between Java generics and

C++ templates.

In order for generic types to be used and type

checked in a generic class, those types must be con-

strained with some type requirements. Constraints on

generic types are often referred to as concepts (Ka-

pur et al., 1981; Austern, 1998). Java generics re-

quire explicit constraints, thus a concept is deﬁned

using a Java interface or a base class, and a type sat-

isﬁes a concept if it implements that speciﬁc interface

or it extends that speciﬁc base class. On the con-

trary, the C++ compiler itself infers type constraints

on templates and automatically checks whether they

are satisﬁed when such generic type is instantiated.

In our implementation, generic parameters can be as-

signed constraints using nominal (similarly to Java)

and structural requirements (similarly to concepts), as

illustrated in Section 3.

In dynamically typed languages, like Smalltalk,

where types are not used in declarations, the con-

text where generics are useful is in object instantia-

Actually, C++ templates are much more than that: (par-

tial) specialization of templates is one of the main features

that enables computation at compile time, often referred

to as template metaprogramming (Abrahams and Gurtovoy,

2004).

GenericsandReverseGenericsforPharo

369

tion; thus, with this respect, the generics presented in

this paper are related to C++ templates, rather than

to Java generics. The generics needed in the con-

text of Smalltalk act at a meta-level, by generating

new classes starting from existing ones, thus, they

have similarities with generative programming mech-

anisms (Eisenecker and Czarnecki, 2000) and C++

meta programming (Abrahams and Gurtovoy, 2004).

This meta programming mechanism is evident also in

our generics and reverse generics implementation in

Pharo: new code is generated starting from existing

one, without modifying the latter. This takes place in

two steps: with reverse generics a brand new generic

version is obtained starting from existing code; then,

by instantiating generic classes, the generic code is

adapted and reused in a new context.

There seem to be similarities among reverse

generics and some refactoring approaches: however,

the intent of reverse generics is not to perform reverse

engineering or refactoring of existing code, (see, e.g.,

(Duggan, 1999; Dincklage and Diwan, 2004; Kiezun

et al., 2007)) but to extrapolate possible generic “tem-

plate” code from existing one, and reuse it for gener-

ating new code. Note that this programming method-

ology will permit modifying only the original existing

code, and then, automatically, spread the modiﬁca-

tions to the one obtained by reverse generics.

A ﬁrst attempt to automatically extract generic

class deﬁnitions from an existing library has been

conveyed by Duggan (Duggan, 1999), well before the

introduction of generics into Java. Besides the reverse

engineering aspect, Duggan’s work diverges from re-

verse generics regarding downcast insertion and pa-

rameter instantiation. Duggan makes use of dynamic

subtype constraint that inserts runtime downcasts. A

parametrized type may be instantiated, which requires

some type-checking rules for the creation of an ob-

ject: the actual type arguments must satisfy the up-

per bounds of the formal type parameters in the class

type.

Kiezun et al. propose a type-constraints-based al-

gorithm for converting non-generic libraries to add

type parameters (Kiezun et al., 2007). It handles the

full Java language and preserves backward compati-

bility. It is capable of inferring wildcard types and

introducing type parameters for mutually-dependent

classes. Reverse engineering approaches ensure that

a library conversion preserves the original behavior of

the legacy code. This is a natural intent since such a

conversion is exploited as a refactoring. Instead, the

purpose of reverse generics is to replace static types

references contained in existing classes with special-

ized ones and then to produce a brand new class.

A limitation of ﬁrst-order parametric polymor-

phism is that it is not possible to abstract over a type

constructor. For instance, in List<T>, List is a type

constructor, since, given an argument for T, e.g., Inte-

ger, it builds a new type, i.e., List<Integer>. However,

the type constructor List itself is not abstracted. There-

fore, one cannot pass a type constructor as a type ar-

gument to another type constructor. Template tem-

plate parameters

(Weiss and Simonis, 2001) in C++

provides a means to abstract over type constructors.

Moors, Piessens and Odersky (Moors et al., 2008) ex-

tended the Scala language (Odersky et al., 2008) with

type construction polymorphism to allow type con-

structors as type parameters. Therefore, it is possible

not only to abstract over a type, but also over a type

constructor; for instance, a class can be parametrized

over Container[T]

, where Container is a type construc-

tor which is itself abstracted and can be instantiated

with the actual collection, e.g., List or Stack, which are

type constructors themselves. The generics mecha-

nism presented in this paper acts at the same level of

ﬁrst-order parametric polymorphism, thus, it shares

the same limitations. An interesting extension would

be to be able to switch to the higher level of type con-

structor polymorphism, but this is an issue that still

needs to be investigated.

The Dependency Injection pattern (Fowler, 2004)

is used to “inject” actual implementation classes into

a class hierarchy in a consistent way. This is useful

when classes delegate speciﬁc functionalities to other

classes: messages are simply forwarded to the object

referenced in a ﬁeld. These ﬁelds will have as type

an interface (or a base class); then, these ﬁelds will be

instantiated with derived classes implementing those

interfaces. This way the actual behavior is abstracted,

but we need to tackle the problem of “injecting” the

actual implementation classes: we do not have the im-

plementation classes’ names hardcoded in the code of

the classes that will use them, but we need to initialize

those classes somewhere. Moreover, we need to make

sure that, if we switch the implementation classes, we

will do that consistently throughout the code. Typi-

cally this can be done with factory method and ab-

stract factory patterns (Gamma et al., 1995), but with

dependency injection frameworks it is easier to keep

the desired consistency, and the programmer needs to

write less code. The reverse generics mechanism is

not related to object composition and delegation, i.e.,

the typical context of the inversion of control philoso-

phy that dependency injection tries to deal with. With

reverse generics the programmer does not have to de-

sign classes according the pattern of abstracting the

actual behavior and then delegate it to factory meth-

The repetition of “template” is not a mistake.

Scala uses [] instead of <>.

ICSOFT2012-7thInternationalConferenceonSoftwareParadigmTrends

370

ods; on the contrary the reverse generics mechanism

allows generating new code (i.e., new classes) from

existing one, without modifying the original code.

Package Template (Sørensen et al., 2010) is a

mechanism for reusing and adapting packages by re-

binding class references. A version has been proposed

for Groovy (Axelsen and Krogdahl, 2009). Pack-

age Template offer sophisticated composition mecha-

nisms, including class renaming and merging. The re-

verse generics mechanism is able to turn a non generic

class into a generic one, while Package Template is

not designed for this purpose.

Traits (Ducasse et al., 2006) were intro-

duced in the dynamically-typed class-based language

Squeak/Smalltalk to counter the problems of class-

based inheritance with respect to code reuse. Al-

though both traits and generic programming aim at

code reuse, their main contexts are different: traits

provide reuse by sharing methods across classes (in

a much more reusable way than standard class-based

inheritance), while generic programming (and also

our generics) provides a mechanism to abstract from

the type implementing speciﬁc behavior. Combining

our generic mechanism with traits looks promising in

that respect, also for the meta-programming features

of traits themselves (Reppy and Turon, 2007).

8 CONCLUSIONS

The mechanisms presented in this paper provide fea-

tures both to write generic code in a dynamically

typed language and to extrapolate possible generic

“template” code from existing one, and reuse it for

generating new code. In our approach, class gener-

alization and generic instantiation is based on class

copying, similarly to C++ templates. Although this

implies some code duplication in the generated code,

this is consistent with the meta-level which is typical

of generative programming mechanisms (Eisenecker

and Czarnecki, 2000).

Since highly parametrized software is harder to

understand (Gamma et al., 1995), we may think of

a programming methodology where a speciﬁc class is

developed and tested in a non-generic way, and then

it is available to the users via its “reversed” generic

version (in this case, we really need the non generic

version for testing purposes, so the code must not be

refactored). Therefore, reverse generics can be used

as a development methodology, not only as a way to

turn previous classes into generic: one can develop,

debug and test a class with all the types instantiated,

and then expose to the “external world” the generic

version created through reverse generics.

A limitation of the implementation presented in

this paper is that the generic parameters (like T in Sec-

tion 2 and Section 4) are global subclasses, thus there

can be only one such generic parameter (together with

its requirements, Section 3 and Section 4.1). How-

ever, in this ﬁrst prototype implementation of gener-

ics and reverse generics in Pharo, this did not prevent

us from using these mechanisms to class hierarchies

(like the case study of Section 6) and to study their ap-

plicability. Of course, in future versions, we will deal

with this issue, and remove the “globality” of generic

parameters.

At the best of our knowledge, no generic (and

reverse generic) programming language construct is

available in Smalltalk, Ruby and Python that achieve

the same capabilities as we presented in this paper. It

is subject of future work to further investigate whether

our proposal can be applied to other dynamically

typed languages.

REFERENCES

Abrahams, D. and Gurtovoy, A. (2004). C++ Template

Metaprogramming: Concepts, Tools and Techniques

from Boost and Beyond. Addison-Wesley.

Allen, E., Bannet, J., and Cartwright, R. (2003). A First-

Class Approach to Genericity. In OOPSLA, pages 96–

114. ACM.

Allen, E. and Cartwright, R. (2002). The Case for Run-time

Types in Generic Java. In PPPJ, pages 19–24. ACM.

Austern, M. H. (1998). Generic Programming and the STL:

using and extending the C++ Standard Template Li-

brary. Addison-Wesley.

Axelsen, E. W. and Krogdahl, S. (2009). Groovy package

templates: supporting reuse and runtime adaption of

class hierarchies. In DLS, pages 15–26. ACM.

Batov, V. (2004). Java generics and C++ templates. C/C++

Users Journal, 22(7):16–21.

Bergel, A. and Bettini, L. (2011). Reverse Generics:

Parametrization after the Fact. In Software and Data

Technologies, volume 50 of CCIS, pages 107–123.

Springer.

Bergel, A., Ducasse, S., and Nierstrasz, O. (2005). Class-

box/J: Controlling the Scope of Change in Java. In

OOPSLA, pages 177–189. ACM.

Bracha, G., Odersky, M., Stoutamire, D., and Wadler, P.

(1998). Making the future safe for the past: adding

genericity to the Java programming language. In

OOPSLA, pages 183–200. ACM.

Bracha, G., von der Ah

e, P., Bykov, V., Kashai, Y., Maddox,

W., and Miranda, E. (2010). Modules as Objects in

Newspeak. In ECOOP, pages 405–428. Springer.

Cohen, T. and Gil, J. (2007). Better Construction with Fac-

tories. JOT, 6(6):103–123.

GenericsandReverseGenericsforPharo

371

Dincklage, D. V. and Diwan, A. (2004). Converting Java

classes to use generics. In OOPSLA, pages 1–14.

ACM.

Ducasse, S., Nierstrasz, O., Sch

arli, N., Wuyts, R., and

Black, A. P. (2006). Traits: A Mechanism for ﬁne-

grained Reuse. ACM TOPLAS, 28(2):331–388.

Ducasse, S., Pollet, D., Bergel, A., and Cassou, D. (2009).

Reusing and Composing Tests with Traits. In TOOLS,

volume 33 of LNBIP, pages 252–271. Springer.

Duggan, D. (1999). Modular type-based reverse engineer-

ing of parameterized types in Java code. In OOPSLA,

pages 97–113. ACM.

Eisenecker, U. W. and Czarnecki, K. (2000). Genera-

tive Programming: Methods, Tools, and Applications.

Addison-Wesley.

Flatt, M. and Felleisen, M. (1998). Units: Cool Modules

for HOT Languages. In PLDI, pages 236–248. ACM.

Fowler, M. (2004). Inversion of Control Con-

tainers and the Dependency Injection pattern.

http://www.martinfowler.com/articles/injection.html.

Gamma, E., Helm, R., Johnson, R., and Vlissides, J.

(1995). Design Patterns: Elements of Reusable

Object-Oriented Software. Addison-Wesley.

Ghosh, D. (2004). Generics in Java and C++: a comparative

model. ACM SIGPLAN Notices, 39(5):40–47.

Goldberg, A. and Robson, D. (1983). Smalltalk 80: the

Language and its Implementation. Addison-Wesley.

Kapur, D., Musser, D. R., and Stepanov, A. A. (1981). Tec-

ton: A Language for Manipulating Generic Objects.

In Program Speciﬁcation, volume 134 of LNCS, pages

402–414. Springer.

Kiezun, A., Ernst, M. D., Tip, F., and Fuhrer, R. M. (2007).

Refactoring for Parameterizing Java Classes. In ICSE,

pages 437–446. IEEE.

Lienhard, A. (2004). Bootstrapping Traits. Master’s thesis,

University of Bern.

Moors, A., Piessens, F., and Odersky, M. (2008). Generics

of a higher kind. In OOPSLA, pages 423–438. ACM.

Odersky, M., Spoon, L., and Venners, B. (2008). Program-

ming in Scala. Artima.

Odersky, M. and Wadler, P. (1997). Pizza into Java: Trans-

lating theory into practice. In POPL, pages 146–159.

ACM.

Reppy, J. and Turon, A. (2007). Metaprogramming with

Traits. In ECOOP, volume 4609 of LNCS, pages 373–

398. Springer.

Siek, J. and Taha, W. (2006). A semantic analysis of C++

templates. In ECOOP, volume 4067 of LNCS, pages

304–327. Springer.

Sørensen, F., Axelsen, E. W., and Krogdahl, S. (2010).

Reuse and combination with package templates. In

MASPEGHI, pages 1–5. ACM.

Weiss, R. and Simonis, V. (2001). Exploring template tem-

plate parameters. In Perspectives of System Informat-

ics, volume 2244 of LNCS, pages 500–510. Springer.

ICSOFT2012-7thInternationalConferenceonSoftwareParadigmTrends

372
