A Collaborative Firewall for Wireless Ad-Hoc Social Networks

Leonardo Maccari

DISI, University of Trento, Povo, Italy

Keywords:

Collaborative Firewall, Wireless Ad-Hoc Networks, Security, Privacy.

Abstract:

A collaborative ﬁrewall can be realized in a multi-hop distributed wireless network when all or some of the

nodes in the network agree on a ﬁltering policy and enforce it when routing a packet. Cooperative ﬁrewalling

introduces many challenges, how to distribute the rules, how to enforce them, how to reduce the global rule-set

in order to limit the impact on the network performance. This paper studies the performance of a collabora-

tive ﬁrewall when only a subset of the nodes of the ad-hoc network ﬁlter the packets. In order to achieve

higher performances the integration with OLSR protocol is proposed. Simulations on realistic scenarios are

performed and the source code of the simulator is released.

1 INTRODUCTION

A ﬁrewall is a bastion host that divides two segments

of a network with different trust levels. Packet ﬁl-

tering may be applied at network layer or at higher

layers (i.e. application ﬁrewalls) in order to enforce

ﬁner policies for security and performance reasons.

In a multi-hop wireless network the concept of bas-

tion host and network segments fade. The network

may access the Internet across a gateway which can be

used to ﬁlter part of the contents, but there is no stan-

dard mean of applying network-wide ﬁltering policies

inside the multi-hop network.

This paper focuses on the integration of routing

and packet ﬁltering in order to implement a collabora-

tive ﬁrewall, that is, a best effort network-wide ﬁlter-

ing function in which nodes will participate in order

to ﬁlter out as much of the unwanted trafﬁc as possi-

ble. The three main contributions of this paper are:

• tests are performed on real devices to justify the

need for optimization with large rule-sets. Our

tests show that rule-set size has a serious impact

on the average round trip time even with rule-sets

smaller than the ones considered in literature.

• The integration with OLSR routing is proposed to

limit the collaborative ﬁltering to a subset of the

MPR nodes.

• Simulations are performed on realistic mobility

and path-loss models. The source code of the sim-

ulator is released to the public in order to stimulate

the interest in this research topic.

2 COLLABORATIVE

FIREWALLING

A collaborative ﬁrewall can be implemented in an ad-

hoc network if the nodes of the network distribute

their rule-sets, i.e. the rules that they want to be ap-

plied to the trafﬁc directed to them, or generated by

them. Each node in the network will collect the rule-

sets of all the other nodes and build a global rule-set

made of the union of the single rule-sets that will be

used to ﬁlter the packets before forwarding them.

A collaborative ﬁrewall is useful in a wireless ad-

hoc network for mainly three reasons: performance,

security and privacy. From a performance point of

view it avoids the waste of network resources. If node

tries to connect to node N

on a service N

does

not support, the TCP packets sent to N

are wasting

resources along all the path from N

to N

. If node N

acts as a gateway it may want to limit the services or

the nodes that can access the Internet. A collaborative

ﬁrewall can be used in all the situations in which it is

necessary to limit the impact of unwanted trafﬁc. For

instance nodes may agree to ﬁlter ﬁle-sharing appli-

cations or other resource greedy applications. From a

security point of view it can be a valuable instrument

to limit the impact of attacks against the network. Port

scans, ﬂoods, password brute force on open services

can be stopped using speciﬁc rules. Note that a node

may locally ﬁlter the trafﬁc directed to himself, but

this has only a limited effect against a ﬂooding attack

that can saturate the whole path from the attacker to

the victim. Under a privacy point of view an user may

290

Maccari L..

A Collaborative Firewall for Wireless Ad-Hoc Social Networks.

DOI: 10.5220/0004071802900295

In Proceedings of the International Conference on Security and Cryptography (SECRYPT-2012), pages 290-295

ISBN: 978-989-8565-24-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

want to limit the scope of the communicationsthat are

generated by himself. For instance, the user may wish

to send broadcast chat messages only to the nodes that

are inside a certain geographical area (assuming the

nodes support some localization protocol). Another

example is to limit his visibility to a certain distance

(in terms of hops) from his position in the topology.

One way to achieve this is to modify the routing mes-

sages with ﬁrewall actions, removingthereferences to

the node outside a certain range (consider that routing

messages are not generated only by the user’s node).

Some of these functions could be achieved with

other means, for instance, group communications can

be achieved with group-based cryptography and ser-

vice discovery protocols can avoid opening unwanted

connections. Some other instead are typical of ﬁre-

walls, like application layer ﬁltering and reactive ﬁl-

tering. A collaborative ﬁrewall is a valuable instru-

ment not only because it will achieve the second set

of goals but also because it will help solving the oth-

ers without increased complexity, since ﬁrewalling is

supported in many operative systems.

A distributed ﬁrewall can be imagined as an in-

strument made of three building blocks:

1. A rule-set generation tool. This can be completely

user generated, derived by high-level policies or

even generated in a reactive way.

2. A rule-set distribution protocol, which can be em-

bedded in the routing protocol used.

3. A rule-set enforcement policy that will try to limit

the number of effectively enforced rules per node

in order to save energy and limit the search time.

The most common organization for rule-sets is

the linear list. The price to pay for simplicity is the

time of the search that is linear with the size of the

rules. Many approaches exist to improve the look-

up time of the search on large rule-sets using com-

plex data structures. Most of these techniques are

imagined for rule-sets where only network and trans-

port layer ﬁelds are matched, so the regularity of

the patterns to be matched can be used to organize

the rule-sets. This is impossible with application-

layer ﬁltering, that is needed for many useful traf-

ﬁc ﬁltering functions. Moreover, most of those tech-

niques are aimed at slowly varying rule-sets since they

move the complexity from the search operation to the

data structure organization. In a mobile ad-hoc net-

work nodes often enter and exit the network and may

change their rule-set, so that the cost of keeping the

data structure updated may be higher than the cost of

a linear search. A review of the difﬁculties of using

standard packet classiﬁcation techniques in wireless

distributed network can be found in (Fantacci et al.,

2008).

In a wired network the most common ﬁrewall con-

ﬁguration is to set the default rule to drop all the pack-

ets and to explicitly permit the allowed services. This

approach is hard to implement in ad-hoc networks,

since the changes in topology and in rule-sets take

some time to propagate in the network. At any time

the global rule-set calculated by a node may be out-

dated and the ﬁrewall may take wrong decisions. It is

tolerable to have false negatives (i.e. packets that are

forwarded by a node even if a rule exists that would

drop them) but not to drop valid packets. For this rea-

son the default rule must be set to allow the pack-

ets and each rule will produce a drop. As a conse-

quence, for each valid packet the whole rule-set must

be scanned.

Cooperative ﬁrewalling is a known subject in liter-

ature, an initial model has been proposed by Bellovin

et al. in (Ioannidis et al., 2000) where the ﬁre-

wall is moved from a bastion host to the endpoints

of a still traditional centralized network. Recently,

the subject has received more attention, Bellovin

proposed a distributed policy enforcement platform

(Zhao et al., 2008a; Zhao and Bellovin, 2009; Zhao

and Bellovin, 2010; Zhao et al., 2011), as well as

other authors (Alicherry et al., 2008). Other works

focus on the application of hash functions to speed-

up rule-matching (Fantacci et al., 2008; Neira et al.,

2008) or on rule-set reduction techniques (Taghizadeh

et al., 2011). Similarly, if higher security is required

deny-by-default networks ﬁlter the communications

between two nodes if a previous security handshake

has been not performed (Zhang et al., 2008; Alicherry

et al., 2009). This paper explores an alternative ap-

proach,the possibility of limiting the number of nodes

that ﬁlter the packets in the network introducing inte-

gration with OLSR routing protocol to achieve more

efﬁciency.

3 CONSIDERED SCENARIO

The network model that is the focus of this paper is a

mobile ad-hoc social network where a group of peo-

ple create a multi-hop network to support the typi-

cal applications of social networking, similarly to the

model presented in (Li et al., 2012). The fragmen-

tation of mobile software platforms and the lack of

common protocols have slowed the penetration of ad-

hoc networks out of academia but recently there is a

concentrationof available operative systems and peer-

to-peer networking standards are emerging ( such as

Wi-Fi Direct, IEEE 802.11s). In general there seems

to be more interest in this topic from market players

ACollaborativeFirewallforWirelessAd-HocSocialNetworks

291

(for instance Qualcomm and Nokia

Such a network may be composed by a large num-

ber of nodes with pedestrian mobility that generate

the typical trafﬁc of social networks, such as chat or

lightweight ﬁle-sharing (photo sharing, proﬁle shar-

ing, vCard sharing...). For this paper, the chosen

routing protocol is OLSR since it better ﬁts a situa-

tion in which the nodes need to know who is on-line.

Rule-sets have been piggybacked to OLSR HELLO

and TC messages. Instead of moving whole rule-sets

only a numeric ID is used. The assumption is that the

rule-sets are known in advance on the devices since

the applications come with a set of pre-deﬁned rule-

sets. The users will choose one and sponsor just the

ID in HELLO messages, that in turn will be included

in TC messages. Alternatively, the users may periodi-

cally sponsor the whole rule-set at large intervals and

just the ID on OLSR messages. OLSR can be hard-

ened with cryptographic credentials in order to avoid

well-known attacks against routing, as in (Zhao et al.,

2008b). This will assure that the rule-set can not be

spoofed or altered by some malicious users.

How big a rule-set can be? client hosts are nor-

mally equipped with few rules while border routers

can be equipped with tens of thousands of rules.

Application layer rules are a powerful instrument to

avoid the spread of worms and spam, as well to shape

the access to services. They can be used on clients

in order to have a high security level irrespective of

the security of the applications that run on the device.

Empirically, a rule-set size between 10 and 50 rules

can be considered realistic, but the more services the

network offers, the more it can grow, especially for

application layer rules. In the simulation scenarios of

next section each node randomly chooses a 20 rules

rule-set out of a set of ten. With a realistic network

size (up to 100 nodes), the global rule-set that is the

union of all the rule-sets can grow up to thousands.

For simplicity only network and transport layers are

used as matching parameters in the simulations.

The mobility model is the one introduced in (Mu-

solesi and Mascolo, 2006). It describes communities

of people and shows statistical properties close to the

ones measured on real traces. The path-loss model

is a dual-slope model enriched with a ray-tracing al-

gorithm (Sommer et al., 2011). A realistic mobil-

ity model and the presence of obstacles will generate

topologies close to real ones.

To limit the overhead due to ﬁrewalling (for in-

stance, in terms of delay introduced) rule-sets can be

reduced as in (Taghizadeh et al., 2011), or the number

of nodes that act as ﬁrewalls can be limited. In both

cases false negatives will be generated. To evaluate

http://pervacy.eu/?p=171

the performance of the ﬁrewall two metrics are used:

M1: counts the false positives hop-by-hop, that is, each

time a packet is forwarded from the sender to the

destination IP (or to the point when it is dropped).

M2: counts the false positives end-to-end, that is, it

counts the packets that arrive to the destination IP.

M1 measures the inefﬁciency of the ﬁrewall as a mean

to reduce the trafﬁc overhead for the whole network.

M2 measures the inefﬁciency in ﬁltering trafﬁc di-

rected against a certain host.

4 OLSR-BASED

COLLABORATIVE

FIREWALLING

To test the impact of large rule-sets on real devices the

delay introduced by the ﬁrewall in mobile devices was

measured. The tests were performed on two smart-

phones equipped with 400MHz and 600MHz ARM

processors and a dedicated GPU. Even if the market

offers faster CPUs for high-end devices, the proces-

sors used for the tests can be correctly considered as

representing an average processor that can be found

on smartphones, e-book readers, tablets.

The tests were performed using a PC connected

over a wired USB connection with the mobile device

in order to avoid the ﬂuctuations of the Wi-Fi media.

This does not inﬂuence the test since the aim is to

havea measure of the delay due to the processing time

of the CPU. The mobile device was equipped with a

Linux kernel 2.6 and conﬁgured with rule-sets of in-

creasing size. The PC sent 300 UDP ECHO request,

the mobile devices answered with ECHO replies af-

ter having checked all the rules in the rule-set. For

each test the average round trip time (RTT) was cal-

culated and subtracted by the value measured with-

out any rule-set present. The rule-sets were composed

for 25% of layer 4 rules and for 75% of layer 7 rules

(string matching on the ﬁrst 50 bytes of the packet).

Figure 1 reports the results. It can be noticed that,

as expected, the delay increases linearly with rule-

set size and that the delay introduced is relevant even

for few hundreds rules. In a network made of one

hundred nodes with rule-sets made of 30 rules the

global rule-setwill be made of 3000 rules which intro-

duces an average delay of 16 ms per hop. In the net-

work used for the simulations an average path length

of 3.2 hops has been measured, with standard devi-

ation around 1.5, that accounts for an average RTT

increment oscillating between 54ms and 150ms, to be

added to the delay introduced by the other layers. In

SECRYPT2012-InternationalConferenceonSecurityandCryptography

292

0.001

0.002

0.003

0.004

0.005

0.006

0.007

0.008

0.009

0.01

0.011

0.012

0.013

0.014

0.015

0.016

0.017

0.018

0.019

0.02

0.021

0.022

0 500 1000 1500 2000 2500 3000

Average increment in packet processing time

Ruleset size

Average processing time with mixed layer3/7 rules

400MHz processor

600MHz processor

Average

Figure 1: The delay introduced (seconds) changing rule-set

sizes.

works like (Taghizadeh et al., 2011) very large rule-

sets have been used (up to 10000). This test shows

that actually the impact on network performance is

present even with smaller sizes and that increased

CPU load can discourage nodes to to participate in

the collaborative ﬁrewall.

4.1 OLSR and Firewall Integration

The focus of this section is on a situation in which

not all the nodes are willing to participate to the dis-

tributed ﬁrewall, in particular when only a subset of

the nodes are computationally able to handle large

rule-sets. In this situation the collaborative ﬁrewall

is realized with a set of ﬁrewall nodes that is a subset

of the total (from now on those nodes will be simply

called the ﬁrewalls).

The ﬁrewalls will have a larger impact on the net-

work if the routing protocol is modiﬁed in order to

make them forward more trafﬁc. In OLSR this can

be accomplished using a higher willingness parame-

ter. The willingness parameter determines how much

a node is willing to be elected MPR. Once elected

MPR the node will generate TC messages, forward

the broadcast trafﬁc and will be preferentially selected

as a next hop to any other destination in the network

(as suggested in section 10, step 3.2 of RFC 3626).

MPRs play a fundamental role in OLSR but since

they generate control messages their number should

be kept as low as possible. The willingness is ex-

pressed with a value that ranges from 0 to 7. With a 0

value the node will never be chosen as an MPR, while

with 7 the node will always be chosen. For other val-

ues, when a node has two neighbors that can indiffer-

ently be elected MPR, the one with highest willing-

ness will be preferred. The value default is 3.

In ﬁgures 2(a) and 2(b) are reported metrics M1

and M2 for a network of 60 nodes in which only an

increasing fraction of randomly chosen nodes is a ﬁre-

wall. Details of the simulations are reported in table

Table 1: Simulation parameters.

Dimension 600m x 600m, 60 nodes

Speed uniform in [0.5, 2] mps

Rule-set size 20/1200 (single/global)

Total open ports 25

Obstacles 2 obstacles, 70m x 80m

Duration 2000 seconds

Trafﬁc avg. of 4800 UDP ECHO per

run, random destination

1. Two curves are present in each ﬁgure, one refers

to the overall performance of the distributed ﬁrewall

when willingness in set to 3 for every node (the curve

marked as “Willingness off”), the second refers to the

case of choosing 7 for nodes that are active ﬁrewall

and 2 for nodes that are not ﬁrewalls. All the metrics

are shown as a fraction of the unwanted packets that

get delivered when there is no active ﬁrewall.

As a ﬁrst remark it can be noted that the M2 met-

ric decreases quite sharply even when only 20% of

the nodes are ﬁrewalls, then it slows down for higher

percentages. This is expected since the probability

of reaching a random destination follows a binomial

distribution with parameter p chosen as the fraction of

ﬁrewalls against the total number of nodes. When the

number of ﬁrewalls increases, only packets that travel

along short routes will not be ﬁltered. As a conse-

quence, also M1 has the same trend since for each

packet that is ﬁltered, in average, a number of hops

equal to half of the average route length is saved (if

the ﬁrewalls are chosen at random).

As a second remark it can be noted that chang-

ing the willingness parameter produces a signiﬁcant

improvement. Even when only 10% of the nodes are

ﬁrewalls, around 40% of the packets are dropped be-

fore destination (metric M2), which makes a generic

communication very hard to complete. When 20%

of the nodes are ﬁrewalls a denial of service attack

against a node can be mitigated for the 65% of its ef-

fect against the target (metric M2) and 45% against

the whole network (metric M1).

Figure 2(c) reports the distribution of the MPR se-

lector set sizes for 4 runs with different parameters.

The selector set size is the size of the set of nodes that

elected the same node as MPR. This graph is shown

in order to verify the impact on the choice of MPR

nodes in the network. It can be seen that the impact

on the network is minimal and mostly positive. In av-

erage there are 30.58 MPR when 30% of the nodes

are ﬁrewalls against 34.16 when the willingness pa-

rameter is not changed. The distribution of the MPR

selector set is more polarized, meaning that there are

less nodes that have few selectors.

This result can be counter-intuitive, since more

ACollaborativeFirewallforWirelessAd-HocSocialNetworks

293

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9

Fraction of packets not filtered

Fraction of firewall nodes

M1 metric

Willingness on

Willingness off

(a)

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9

Fraction of packets not filtered

Fraction of firewall nodes

M2 metric

Willingness on

Willingness off

(b)

0 2 4 6 8 10 12 14

Number of MPRs

MPR selector set size

MPR selector set size distribution

Willingness off

Willingness on, 10%

Willingness on, 20%

Willingness on, 30%

(c)

0.1

0.2

0.3

0.4

0.5

0.6

0.7

2 4 6 8 10

Fraction of packets not filtered

MPR selector set size threshold

M1 and M2 metric

(d)

0 2 4 6 8 10 12 14

Number of MPRs

MPR selector set size

MPR selector set size distribution

Simple configuration

Realistic configuration

(e)

0.05

0.1

0.15

0.2

0.25

0.3

0.35

0.4

0.45

1 2 3 4 5 6 7 8 9

Fraction of packets not filtered

MPR selector set size threshold

M1 metric

Simple configuration

Realistic configuration

(f)

Figure 2: Metrics M1 (a) and M2 (b) increasing the fraction of ﬁrewall nodes. MPR selector set size distribution (c). M1 and

M2 against the MPR selector set size threshold (d). Comparison between simple and realistic scenarios (e,f).

nodes are forced to be MPR than with standard

OLSR. Actually, with OLSR the MPR choice is per-

formed independently by each node which means that

even if each node minimizes its own set, the inter-

section of all the MPR sets is not minimized. Hav-

ing some nodes with higher willingness polarizes the

choice thus reducing the intersection.

4.2 MPR-based Filtering

In this section another conﬁguration is considered in

which all the nodes have equivalent resources. In or-

der to reduce the overhead introduced in the RTT it is

necessary to limit the set of ﬁrewalls trying to identify

the nodes that are more central in the topology.

Centrality is a known concept in networking (Kat-

saros et al., 2010) that can be estimated with a few

metrics. For the purpose of ﬁltering the shortest-path

betweenness seems the wisest choice, since it rep-

resents the fraction of shortest multi-hop routes that

pass through a node. OLSR gives an approximated

global knowledge of the full topology. It is theoret-

ically possible for each node to calculate and keep

up-to-date its betweenness but in practice it is com-

putationally very costly. Betweenness can be approx-

imated limiting the scope of the calculation to only

the 2-hop neighbors. An MPR node is, by design, a

node that maximizes the betweenness between the se-

lector and its 2-hop neighborhood. Being an MPR is

a local esteem of centrality, thus, the chosen strategy

consists in ranking the MPRs using the size of their

selector set and then implementing the ﬁrewall only

in the nodes that have a rank over a certain threshold.

In ﬁgure 2(d) M2 and M1 metrics are reported

when the threshold is varied from the 11 to 1 (the x

axis is inverted in order to make the graph visually

comparable with the ones in ﬁgure 2(a) and 2(b)). It

is interesting to note that for a value of 9 and 7, which

roughly corresponds to the x-value of 10% and 20%

in ﬁgure 2(b) M2 is about half of the case when nodes

are selected randomly, meaning that the choice of the

MPR selector set size is an useful approximation of a

centrality measure. Note that the overall distribution

of the MPR selector sets size is known to any node

(every TC carries the selector set of an MPR). Given

this distribution some topological properties of the

network may be derived. The possibility of dynam-

ically choosing the MPR threshold to obtain a wanted

value for M1 or M2 is considered as a future work.

4.3 Impact of Simulation Scenario

In order to stress the importance of using correct mod-

els, some simulations have been repeated with a ran-

dom way-point mobility without obstacles. We re-

fer to this conﬁguration as simple conﬁguration and

to the model with obstacles, shadowing and Musolesi

mobility as the realistic conﬁguration. While the two

conﬁgurations are functionally comparable (the aver-

age size of the routing table differs for 1.5 destina-

SECRYPT2012-InternationalConferenceonSecurityandCryptography

294

tions) the simple conﬁguration generates shorter av-

erage paths (2.7 hops versus 3.2) and there is a big

difference is in the distribution of the MPR selector

set sizes as reported in ﬁgure 2(e) (for a total of 36

against 47). In ﬁgure 2(e) metric M1 is compared, the

curves seem very close but the difference in the MPR

selector set sizes makes the same threshold value cor-

respond to a different number of ﬁrewalls in the net-

work. If instead of comparing the MPR threshold the

two curves are compared using the number of ﬁre-

walls per simulation (roughly this can be done shift-

ing the curve for the simple scenario two units left),

then an average 10% difference can be measured. In

conclusion this comparison suggests that the MPR se-

lector size threshold used as an approximation of cen-

trality seems to be independent from the topology at

this network size and that the simple scenario overes-

timates the ﬁrewall performance compared to a real-

istic one due to the shorter average path.

5 CONCLUSIONS

Cooperative ﬁrewalls can positively impact the per-

formances of ad-hoc and mesh networks. They play

a useful role in the enforcement of security policies,

for reactive security when the network is under attack,

to perform trafﬁc shaping or to limit the diffusion of

trafﬁc without relying on the support of applications.

Nevertheless, large rule-sets are hard to be handled

by the limited computation power of common mo-

bile devices. In this paper the impact of the com-

putational overhead has been measured showing that

thousands of rules introduce a large delay in RTT. It

has been shown that limiting the number of ﬁrewalls

in the network still allows to ﬁlter a high percentage

of unwanted trafﬁc and that without adding complex-

ity, the performances can be improved using the in-

formation produced by OLSR. Since the behavior of

a routing protocol is very scenario-dependent a net-

work simulator with realistic mobility and path-loss

models has been realized on top of Omnet++ plat-

form. The source code is available on the project site:

www.pervacy.eu.

ACKNOWLEDGEMENTS

Financed by Provincia di Trento under The Trentino

programme of research, training and mobility of

post-doctoral researchers, incoming Post-docs 2010

CALL 1, PCOFUND-GA-2008-226070

REFERENCES

Alicherry, M., Keromytis, A., and Stavrou, A. (2008).

Distributed ﬁrewall for manets. Technical report,

Columbia University.

Alicherry, M., Keromytis, A. D., and Stavrou, A. (2009).

Evaluating a collaborative defense architecture for

manets. In Conference on Internet multimedia ser-

vices architecture and applications, IMSAA.

Fantacci, R., Maccari, L., Ayuso, P., and Gasca, R. (2008).

Efﬁcient packet ﬁltering in wireless ad hoc networks.

Communications Magazine, IEEE, 46(2):104 –110.

Ioannidis, S., Keromytis, A. D., Bellovin, S. M., and Smith,

J. M. (2000). Implementing a distributed ﬁrewall. In

ACM Conference on Computer and Communications

Security, Athens, Greece.

Katsaros, D., Dimokas, N., and Tassiulas, L. (2010). Social

network analysis concepts in the design of wireless ad

hoc network protocols. Network, IEEE, 24(6):23 –29.

Li, J., Wang, H., and Khan, S. U. (2012). A semantics-

based approach to large-scale mobile social network-

ing. ACM/Springer Mobile Networks and Applica-

tions, 17.

Musolesi, M. and Mascolo, C. (2006). A community based

mobility model for ad hoc network research. In In-

ternational workshop on Multi-hop ad hoc networks:

from theory to reality, REALMAN ’06.

Neira, P., Gasca, R., Maccari, L., and Lefevre, L. (2008).

Stateful ﬁrewalling for wireless mesh networks. In

New Technologies, Mobility and Security, NTMS ’08.

Sommer, C., Eckhoff, D., German, R., and Dressler, F.

(2011). A Computationally Inexpensive Empirical

Model of IEEE 802.11p Radio Shadowing in Urban

Environments. In 8th Conference on Wireless On de-

mand Network Systems and Services (WONS 2011).

Taghizadeh, M., Khakpour, A., Liu, A., and Biswas, S.

(2011). Collaborative ﬁrewalling in wireless net-

works. In Joint Conference of the IEEE Computer and

Communications Societies, INFOCOM 2011.

Zhang, H., DeCleene, B., Kurose, J., and Towsley, D.

(2008). Bootstrapping deny-by-default access control

for mobile ad-hoc networks. In Military Communica-

tions Conference, 2008. MILCOM 2008. IEEE.

Zhao, H. and Bellovin, S. M. (2009). Source preﬁx ﬁltering

in ROFL. Technical Report CUCS-033-09, Depart-

ment of Computer Science, Columbia University.

Zhao, H. and Bellovin, S. M. (2010). High performance

ﬁrewalls in MANETs. In International Conference on

Mobile Ad-hoc and Sensor Networks.

Zhao, H., Chau, C.-K., and Bellovin, S. M. (2008a).

ROFL: Routing as the ﬁrewall layer. In New Security

Paradigms Workshop.

Zhao, H., Lobo, J., Roy, A., and Bellovin, S. M. (2011).

Policy reﬁnement of network services for MANETs.

In The 12th IFIP/IEEE International Symposium on

Integrated Network Management (IM 2011).

Zhao, S., Aggarwal, A., Liu, S., and Wu, H. (2008b). A

secure routing protocol in proactive security approach

for mobile ad-hoc networks. In Wireless Communica-

tions and Networking Conference, WCNC 2008.

ACollaborativeFirewallforWirelessAd-HocSocialNetworks

295
