Keywords-based Automatic Multimedia Authoring in the Cloud
Abdelkader Outtagarts, Sylvain Squedin and Olivier Martinot
Alcatel-Lucent Bell Labs, Route de Villejust, Nozay, 91620, France
Keywords: Automatic Video Editing, Authoring, Mashups, Speech2text, Annotation, Reasoning, Collaboration, Web
2.0.
Abstract: In this paper, we describe our work on automatic multimedia authoring or editing. Our approach is based on
keyword extracted from the audio embedded in videos. A model approach of mashup based on keywords is
proposed. A video editing testbed has been designed and implemented. Using speech2text keywords
generator component, the audio files uploaded in the video editing testbed are transcribed and analyzed in
order to extract keywords. The keywords are used to edit automatically videos in order to produce mashups.
1 INTRODUCTION
Video editing is the process of selecting segments
from a set of raw videos and chaining them by
adding piece of audio, effects and transition in order
to create a new video or mashup. Most available
video editing tools are time-consuming and require
specific knowledge. There is therefore, an increasing
demand for simple, user-friendly online video
editing tools. Online video editing tools can afford
less costly and more accessible processes that can be
completed anytime, anywhere. In this context, this
paper presents a new tool to facilitate the creation
and handling of video content. What our video editor
wants to enable is a keyword-based automatic video
editing deployed in the cloud with a previewing web
client. Videos are coming from video sharing
platforms, directly from the webcam, uploaded
video files by users or captured from camera
network. They can be composed and viewed on the
fly. Those compositions, called video mashups can
be shared and modified collaboratively, and their
privacy easily is managed. This video editor is also a
research testbed for studying automatic video editing
and summarization based on text and statistical data
and metadata. The paper is organised as follows. In
the section 2, we present the video editing model.
The video editing testbed is detailed in the section 3.
We’ll present the current status of our research the
section 4. The model and algorithms validation
methods are described in the section 5. Conclusions
are drawn in Section 6.
Automated video editing and summarisation
have gained momentum in recent years. Many
algorithms such as shot detection are developed to
extract representative key-frames from video. The
majority of authors use video analysis or signal
processing in order to perform automatic video
composition (mashup). Among the authors, Hua et
al. (Hua and Zhang, 2009) develop an approach for
extracting temporal structure and determining the
importance of a video segment in order to facilitate
the selection of highlight segments. They also
extract temporal structure, beats and tempos from
the incidental music. In order to create more
professional-looking results, the selected highlight
segments satisfy a set of editing rules and are
matched to the content of the incidental music. The
strategy of (Hua and Zhang, 2009) is to parse the
video sequence into hierarchical structures
consisting of scenes, shots, and sub-shots. For
music, they segment it into clips by strong beats, and
for each clip, tempo is estimated, which indicates the
speed of the music sub-clips. In their system, the
video segment selection is also based the work
proposed by Ma et al. (2002). Hua et al. (2009)
refine the method by adding an “attention fusion”
function, which generates improved results. Müller
Arisona et al. (2008) present Odessa framework,
which automates the preparation of footage during
composition and the editing process. Real-time
audio analysis extracts music feature vectors, which
are mapped to editing parameters of a video
montage engine. The engine can be controlled
through high-level editing parameters, such as
looping speed or cutting rate. The authors apply a
reverse editing of a video. The original video is
analysed and re-organised in terms of individual
141
Outtagarts A., Squedin S. and Martimot O..
Keywords-based Automatic Multimedia Authoring in the Cloud.
DOI: 10.5220/0004073701410147
In Proceedings of the International Conference on Signal Processing and Multimedia Applications and Wireless Information Networks and Systems
(SIGMAP-2012), pages 141-147
ISBN: 978-989-8565-25-9
Copyright
c
 2012 SCITEPRESS (Science and Technology Publications, Lda.)

scenes, groups, and shots. Odessa implements
methods such as audio beat tracking or music
similarity analysis to operate in real-time. Takemae
et al. (2005) propose an automatic video editing
system using stereo-based head tracking in
multiparty conversations for conveying the contents
of the conversations to the viewers. Their system can
automatically detect participants’ head 3D position
and orientation during a conversation. Based on the
detection results, the author’s system selects the shot
of the participant that most participants’ heads are
facing. This approach exploits participants gaze
behaviour to select the most effective shots of
participants. Mudhwuchutyula et al. (2004) propose
an automatic mechanism for XML based video
metadata editing, in tandem with video editing
operations. An implementation framework for
editing metadata in accordance with the video
editing operations is demonstrated. The video
metadata editing mechanism has been implemented
in the context of Digital Video Album (DVA)
system for editing metadata in accordance with
presentation/ summarization operations performed
on video. Foote et al. (2002) have presented a music
video creation system that can automatically select
and align video segments to music. Authors have
analyzed both audio and video sequences in order to
automatically create music videos for a given sound
track.
As a conclusion of the state of the art, existing
video editing solutions are time consuming. To
facilitate video edition, many authors have worked
in automatic video editing and summarization. The
most algorithms developed to extract representative
key-frames from video are based on video and/or
audio analysis. These solutions require significant
processing especially when it must deal with
hundreds or thousands of videos.
2 MODEL
A video mashup is a combination of video and audio
sequences, effects and transitions. The manual video
editing is recommended when a user is working with
a small number of media. When the number of
media increases, it is necessary to help users by
managing automatically the abundance of media. In
the example of mashup shown in the figure 1, a
video mashup consists of a set of video clips,
transitions, titles... The videos are trimed to select
only the interested segments or clips to build a small
movie or a video mashup. After the trims, the
selected clip will correspond to a time t
k
as shown
in the figure 1. The position (start attribut) of the
video clip in the mashup and attribute values (length,
trimstart, trimend, metadata positions in the
mashup,…) are stored in a database using XML
format.
Figure 1: Detailed video mashup.
A video is a sequence of video frames captured
by a webcam, phones or other devices during a
certain time. A video v
k
containing (n-i) frames
during the time t
i
<t<t
n
, is given by (Figure 1):
),.....(
nik
ffv 
(1)
The corresponding audio sequence contained in the
video is represented by:
),.....(
nik
aaA 
(2)
k
A
is an audio sequence containing (n-i) number of
audio frames.
Between the times t
i
and t
n
, the extracted
keywords from the corresponding audio of video file
is given by the following expression:
 
,...,
21
vkwvkwvKW
k

(3)
k
vKW
is the keyword list extracted during between
t
i
and t
n
of the video
k
V
The video V
k
can be represented with both video
frames, audio frames and metadata (keywords).
 











,...,
),...,(
),...,(
21
kwkw
aa
ff
V
ni
ni
k
(4)
A video transition is the visual movements as one
picture or video clip inserted between two video
sequences. It is the way in which video
sequences/shots are joined together. Preferably, a
transition must be related to the context of the
Title
(meta-data)
Caption (meta-data)
ts
t
te
t
k
t
: time corresponding to the sequence V
k
k
t
ts
t
: media mash trimstart
te
t
: media mash trimend
0
v
l
tricker (meta-data)
Textbox (meta-data)
Transition
T
m
i
t
n
t
ink
ttt 
),.....(
nik
ffv 
),.....(
nik
aaA 
 
,...,
21
kwkwKW
k

SIGMAP 2012 - International Conference on Signal Processing and Multimedia Applications
142

created mashup video. We can represent a transition
with a matrix containing a suite of video frames and
keywords/tags which describes the transition.
 












,...,
),...,(
21
1
tkwtkw
ff
T
mnn
m
(5)
Where
m
T
is a transition and tkw
i
keywords/tags
corresponding to the transition
m
T
.
A Mashup M is basically represented by a
sequence of non-overlapping sequences from a
multiple video:




xj
j
j
VM
0
(6)
x is the number of video sequences. Transitions can
be added between video sequences to join them.
A mashup when encoded become a video and
identified by a suite of frames of images, audios and
keywords.
 















,...,
21
kwkw
a
f
M
j
j
j
j
(7)
The challenges in this work is how, from one or
more keywords, we can automatically selecting
segments/sequences/shots from a set of raw videos
and chaining them by adding transition in order to
create a new video or mashup.
Figure 2: Video mashups.
Automatic video editing helps to manage the
abundance of the media by proposing mashups for
users. As showed in the figure 2, the feedback of
users is necessary to validate the mashups.
We consider two possible users feedbacks which
can be introduced in the automatic video editing
algorithms:
Implicit: This user feedback is characterized by the
number of times the video is viewed as well as
modifications done in the proposed mashup.
Explicit: Here the user gives his opinion directly or
delete the proposed mashup. These parameters can
be added to the model in order to automatically
taking into account the user feedback by using
machine learning algorithms.
3 VIDEO EDITING TESTBED
3.1 Description
The video editor testbed platform allows online and
collaborative video edition. This testbed is
composed on six main components: a web-based
video editing application, import multimedia,
mashup browser and media manager, a database, an
XML2Video converter and an automatic video
editor engine:
 Video Editing Application: It is a web-based
video editor flash applet which has not need pre-
installation of editing software in client’s devices. It
allows online video editing or video mashup creation
and annotation. Using the video editing application
user has possibilities to modify videos using
function such as: drag and drop media, trim, cut,
adding audio, image, effects and transitions… All
the mashups and text data are stored in Mysql
database using XML format. The XML descriptor
contains metadata such as : trim start/end attributes
of videos and audios, videos and mashups length,
the beginning and the end of a title, a caption, a
textbox…
 Mashup Browser: this function allows
displaying the private and public video mashup, the
contributors for each mashup, links to edit the
composition and to export the composition into the
streaming server.
 Mysql Database: Two types of data are stored in
the video editor testbed database: Critical data and
statistical data. The critical data include: users, the
media used to create compositions and compositions
created by users. The statistical data are collected
and processed to perform automatic annotation of
the media. This data include: specific changes to a
composition for each edition, How a user edits in
compositions, metadata added by users and the data
associated with imported videos.
Users
Video mashups
Videos
audio
audio
audio
audio
audio
Video Editing Engine
Keywords-based Automatic Multimedia Authoring in the Cloud
143

 Import Multimedia Features:
 Import from Tivizio: Using REST APIs, a
user can collect videos from Tivizio, an
enterprise video sharing platform.
 Webcam Video Recorder: this function allows
user to record a pitch in order to create a video
mashup using other media and metadata.
 Import from camera network: using Camera
Search Engine component, a user navigate in
camera network to collect images which are
imported into the video editing application using
REST APIs in order to be part of a video
composition.
 Upload file from the device: from PC or
Android OS devices, a user is able to upload
media with standard format.
 XML2Video Converter: this component allows
converting XML descriptor of a video composition
generated by the video editing application
component into a file video format. This feature
allows also exporting the video to Tivizio or
Youtube.
 Automatic Video Editor Engine: this function
allows for instance, automatic video edition based
on keyword and rule.
 Video Editing Testbed APIs: REST APIs are
provided for uploading videos, setting/getting
metadata and composing mashup using keyword.
3.2 Data and Algorithm
Our algorithm of automatic video editing is based on
keywords extracted from audio file of the video and
other parameters of the media. A media can be a
video, an image, an audio file or a mashup. As
described in table 1 which shows the media table,
the main attribute of a media used the automatic
video editing algorithm are:
- The type
- The Meta data
- The mashup descriptor
- The media viewed counter
When uploaded in the video editing testbed, the
video frames and audio file are extracted and stored
the multimedia database. Other data are stored in
MySql database in the media containing attributes
described in the table 1.
Two types of data are stored in the database:
a- Critical Data
The first type of data is required to operate the video
editing testbed:
- Users,
- The media used to create compositions,
- Compositions created by users.
b- Statistical
The second type of data stored in the database is
linked to the use of the video editor. This data is
used to compile statistics. Indeed, it is expected in
this research project using all data collected to create
an engine for implicit automatic annotation of
videos. This is roughly able to understand "who
publishes what and how»:
- Specific changes to a composition for each
edition
- How user edits compositions
- Metadata added by users
- The data associated with imported videos
Table 1: Media table description.
Media
m_id
Media id
u_user
Username
m_type
video, image, audio, mash
m_label
Media name
m_metadata
Keywords metadata
Ex :
<speech2keywords
begin='00.00.16' end='00.01.15'
keywords='service provider |
quality service | right combination |
irrational |'>
</speech2keywords>
m_duration_seconds
duration
m_ source_url
Media url
m_date
Creation date
m_xml_string
Mashup XML descriptor
m_last_update
Update the date
m_view_count
Viewed counter
m_fps
Number of frame per seconds
m_audio
url of the audio file
4 CURRENT STATUS OF OUR
RESEARCH
The post-production video editing requires
significant processing, when we have to analyze a
large number of media, hundreds or thousands of
videos, audios and images. That is why we propose a
solution based only on text data and metadata. These
data and metadata are obtained in three ways:
- Classical video annotation by users,
- Implicit annotation video by inheritance of the
text data added by users during the compositions.
This annotation approach is described below.
SIGMAP 2012 - International Conference on Signal Processing and Multimedia Applications
144

- Extracting the text from the audio:
speach2keyword during the media upload process.
The annotations collected by each media are
analyzed using text processing and statistical
algorithms for improving the media description. The
automatic video algorithms use these text data in
order to generate an XML descriptor as an output of
video composition. An example of the XML mashup
descriptor is given in the figure 3. Each segment of a
clip is represented as a link to the original one,
which maintains associated data in the case of being
deleted or moved, as well as some more
descriptions. The transitions and effects are either a
link with descriptions and media links.
Figure 3: Example of XML mashup descriptor.
Figure 4: Global architecture of the video editing testbed.
The figure 4 shows the global architecture of the
video editing testbed. On this figure main
component are detailed in this paper such as:
 Speech2keyword generator,
 Implicit Video Annotations and,
 keyword-based video editing.
4.1 Speech2keyword Generator
Speech-to-text engine like Nuance speech
recognition engine, Sphinx or other are really
efficient for a limited of vocabulary, but can be less
efficient when voice or accent is not trained by the
system. Currently we obtain 50 to 80% quality for
the text transcription. In some cases we do not need
the full text transcription but only an idea of the
concepts and subjects addressed by the speaker. The
idea is to reduce errors of the Speech-to-text engine
with the Speech2keyword generator, that is able to
extract the keywords in a time-based manner from
the speech transcription in real-time. Next steps are
to apply semantic algorithms to improve the
consolidation/disambiguation of extracted keywords
and reduce the errors.
The current implementation includes ASR
(Automatic Speech Recognition) of Nuance
(Beaufays et al., 200) and semantically methods to
extract keywords (Figure 5).
Figure 5: Speech2keyword generator.
The quality of the speech to text is key element
in the keyword extractor and when the voice or
accent is not trained by the system. The result of the
transcription success is about 50 to 80% depending
on audio file input.
The cosine similarity computation is used to
compare the both extracted keywords is given by :
 
   
1
22
11
.
cos
n
ii
i
nn
ii
ii
AB
AB
similarity
AB
AB




  



(8)
Where A and B are vectors of attributes.
To show the speech2keyword generator
efficiency with an example, we have converted a
text to mp3 file and have used the audio file to
extract the transcription and keyword using alchemy
APIs. To convert text to mp3, we have used a web-
based free access tools text2speech.org
(http://www.text2speech.org/). The following
< descriptor >
<mashup width="320" height="240" id="c8ddafe1233b29125e4f69be8123f763"
label=“XML descriptor example>
<clip type="video" id="5eef274620a55a78b6c90a845cfcf307" begin=“100"
end=“200"
label=http://www.youtube.com/watch?v=HlxIWmA4pMk" length=“100“
description= " Shot description …. " />
< clip type="video" id=“jgjg274620a55a78b6c90a845dfhf67" begin=“0"
end=“100"
label=http://www.youtube.com/watch?v=_uI_4kJCy9E" length=“100“
description= " Shot description …. " />
<media group="video" type="video" id="5eef274620a55a78b6c90a845cfcf307"
label="http://www.youtube.com/watch?v=HlxIWmA4pMk"
source=" http://www.youtube.com/watch?v=HlxIWmA4pMk"
fps="10" duration=“1000“
description= " General description …. " />
<media group="video" type="video" id=" jgjg274620a55a78b6c90a845dfhf67 "
label="http://www.youtube.com/watch?v=_uI_4kJCy9E"
source=" http://www.youtube.com/watch?v=_uI_4kJCy9E"
fps="10" duration=“800“
description= " General description …. " />
</ mashup>
</descriptor >
Multimedia
Database
Text data,
Metadata
and Mashups
Video editing GUI
Automatic data
analysis
and processing
Automatic video
Editing and
summarization
XML2Video
Converter
Implicit
Automatic
annotation
Speech2Keyword
generator
Keywords-based Automatic Multimedia Authoring in the Cloud
145

parameters have been used:
Voice type: American Male 1
Volume scale :5
The original text is:
Video editing is the process of selecting segments from a
set of raw videos and chaining them by adding piece of
audio, effects and transition in order to create a new video
or mashup. Most available video editing tools are time-
consuming and require specific knowledge. There is
therefore, an increasing demand for simple, user-friendly
online video editing tools. Online video editing tools can
afford less costly and more accessible processes that can
be completed anytime, anywhere.
The transcription using speech2keyword generator
of the generated audio file by text2speech.org is
given below:
<metadata>
<session id="11">
<stream id="mp3 text2speech">
<audio>
<speech2keywords begin="00.00.00" end="00.00.15"
sentences="Video editing just the process of selecting
segments from a set of wrong videos and shaving them by
having piece of audio effects and transitions in order to
create a video on the sharp most Available video editing
tools are time consuming and require specific knowledge
there is therefore an increasing demand for simple user
friendly online video editing tools online video"
</speech2keywords>
</audio>
</stream>
</session>
</metadata>
As can be seen, there some difference between the
audio transcriptions and the original text. The
following table compares the keywords extracted
from original text with the keywords extracted by
speech2keyword generator using Alchemy
algorithm. More than 60% of keywords are identical
allowing us to confirm that the quality of the
transcript is acceptable. This result is very
interesting for automatic video editing to quickly
edit a mashup when a user is dealing with a large
number of videos.
4.2 Implicit Video Annotations
The proposed approach allows, implicitly,
annotation of videos. A user when composing the
video adds textual data such in titles, captions,
textboxes and tickers in order to enrich his video
mashup. A video mashup is composed by video
clips. These videos are trimmed by the user to select
only the interested segments or clips to build his
small movie or a video mashup. The figure 6 shows
an example of implicit annotation of a video
inherited from mashup user annotations. Text
processing and statistics analysis will be performed
in the future work in order to obtain a better
description of each video shots or segments.
Table 2: Comparing original text with speech2keyword
generator.
Original text using
http://www.alchemyapi.com/
api/demo.html
speech2keyword generator
using Alchemy
video editing tools
online video editing
Most available video
user-friendly online video
new video
raw videos
specific knowledge
chaining
time-consuming
video editing
video editing tools
user-friendly
online video
Available video
wrong videos
audio effects
specific knowledge
time-consuming
online
accessible processes
tools
anywhere
<metadata>
<annotations>
<annotation>
<type>textboxeffect</type>
<text>The buffalo before the attacks of lions</text>
<start>51</start>
<duration>9.1</duration>
</annotation>
<annotation>
<type>textboxeffect</type>
<text>A clan of lions attacking a buffalo</text>
<start>142</start>
<duration>71</duration>
</annotation>
<type>titletheme</type>
<text>Wild animals</text>
<start>0</start>
<duration>5</duration>
</annotation>
</annotations>
<mashlabel>WildAnimals</mashlabel>
<othermedia>
<label>Lions Hunt Buffalo.flv</label>
<label>Rhinoceros attacking tour bus.flv</label>
</othermedia>
</metadata>
Figure 6: Implicit media annotation.
4.3 Keyword-based Automatic Video
Editing
In our research, the video compositions are based on
text data added by users directly of implicitly and
SIGMAP 2012 - International Conference on Signal Processing and Multimedia Applications
146

meta-data extracted by media analyzers
(speech2keyword generator). The text data will be
continually processed using text processing and
statistical algorithms in order to better describing
shot, sequences or all media file. For instance, the
video composition allows automatic video
composition by keyword (Figure 7). First a user or
an application performs an HTTP request with a
“keyword”, a user and the name of the rule as
parameters (1). The keyword is processed (2) and a
search request is sent to the database (3). Using
rules, the automatic video editor (4) compose an
XML descriptor which chain different video shots
matching with the keyword. Audio file can be added
in the video composition if the keyword matches
with auto description. The XML descriptor of the
composition is stored in the database (5). An end
user can perform the following function using the
web based video editing application: play the
composition (6 and 7), modify the video
composition (8) and render the composition by
converting the XML descriptor on video format.
5 MODEL AND ALGORITHM
VALIDATIONS
The video editing testbed has been built for studying
and testing automatic video editing based on text
data. To experiment the automatic video editing
algorithms, we will use a video dataset with multiple
semantic concepts in using video. We propose two
methods to experimentally validating models and
algorithms of automatic video editing: Mashup
validation by users and comparison of the mashups
to one or more reference mashups (depending on the
context). For the first methods, the algorithms will
use the user profiles. The user feedbacks analysis
information will be processed and injected in the
algorithms in order to improve future compositions.
For the second, representative users will create
reference mashups in different domains or subjects.
The algorithms will be tested the mashup compared
to reference mashups.
6 CONCLUSIONS AND FUTURE
WORKS
In this paper, we have proposed an approach of
automatic video editing which is derived using
algorithm and rules based on keyword. The text data
is collected in three ways: direct user annotations,
implicit annotation during the video edition and by
extracting keywords from video analysis. For the
future we plan to create more complex models and
algorithms of video composition to allow composing
video from a sentence.
Figure 7: Automatic video editing engine.
REFERENCES
Hua, X.-S., Zhang, H.-J., 2009. Automatic Home Video
Editing, Signals and Communication Technology,
Springer, 353-386.
Hua, X.-S., Zhang, H.-J., 2003. AVE - Automated Home
Video Editing, ACM MM.
Ma, Y. F., Lu, L., Zhang, H. J., Li, M. J., 2002. A User
Attention Model for Video Summarization. ACM MM,
533–542.
Müller Arisona, S., Müller, P., Schubiger-Banz, S.,
Specht, M., 2008. Computer-Assisted Content Editing
Techniques for Live Multimedia Performance, R.
Adams, S. Gibson, and S. Müller Arisona (Eds.):
DAW/IF, CCIS 7, 199–212.
Takemae, Y., Otsuka, K., Yamato, J., 2005. Automatic
Video Editing System Using Stereo-Based Head
Tracking for Multiparty Conversation, CHI 2005,
1817-1820.
Takemae, Y., Otsuka, K., Yamato, J., 2005. Development
of Automatic Video Editing System Based on Stereo-
Based Head Tracking for Multiparty Conversations,
IEEE.
Mudhwuchutyula, C. L., Kankunhalli, M. S., Mulhem, P.,
2004. Content Based Editing of Semantic Video
Metadata, IEEE International Conference on
Multimedia and Expo.
Foote, J., Cooper, M., and Girgensohn, A., 2002. Creating
Music Videos Using Automatic Media Analysis, ACM
MM.
Beaufays, F., Sankar, A., Williams, S., Weintraub, M.,
2003. Learning Name Pronunciations in Automatic
Speech Recognition Systems, Proceedings of the 15th
IEEE International Conference on Tools with
Artificial Intelligence.
Text processing
+
Video editor
+
Algorithms
(rules)
Multmedia
database
End-user Web 2.0
Manual Video
Composer
XML descriptor
Text data
And meta-
data
Data
keyword
function compose($Sentence, $id, $method=“algorithm name")
1
Media streaming
2
3
4
5
6
7
XML2AVI
converter
VideoXML
9
8
http://<server>/cove/api/get/compose/
keyword/<rule>/<user>/<keyword>
Keywords-based Automatic Multimedia Authoring in the Cloud
147
