Security Criteria in Deciding on Migration of Systems to

the Cloud

Rafael Gómez

, David G. Rosado

, Daniel Mellado

and Eduardo Fernández-Medina

Spanish Tax Agency, Madrid, Spain

GSyA Research Group, University of Castilla-La Mancha,

Dept. of Information Systems and Technologies, Ciudad Real, Spain

Abstract. Cloud computing is setting trend in IT world. As it evolves,

providers and clients claim their concern about their pros and cons. Some

proposals have been made on the methodologies to assess criteria for benefits

and risks of the different cloud models. How these proposals deal with security

issues (that most IT executives point out as their top concern)? In this paper we

go into the issue of how we can incorporate security requirements to a decision

making process for whether to migrate legacy systems to the cloud and how to

do it. From systems in control of the firms’ data centers to systems working

partially, if not totally out of their control.

1 Introduction

Mell & Grance propose in [20] the most widespread definition for the ultimate utility

model in the IT field: the cloud computing. They describe cloud computing as “a

model for enabling ubiquitous, convenient, on-demand network access to a shared

pool of configurable computing resources that can be rapidly provisioned and

released with minimal management effort or service provider interaction.”

Some like Jansen & Grance say that cloud might be “at odds with traditional

security models and controls” [15] and, for IT executives, security is a top concern

when they are asked about the major deterrents for adoption of the cloud model [8,

10]. So it's still today [23] (see fig. 1).

But, is this concern really undermining the final decision when we face in the

other plate of the balance the promise of huge savings? How can we model and

calibrate the pros and cons of the whole migrating process of a business? After all,

security criteria are probably some of the most difficult to size of all criteria in the

decision process.

There are authors who see the cloud not as a threat but an opportunity to improve

the security of many legacy systems. Winkler says in [25] that the migration to the

cloud “gives us hope that we can regain control over gaps and issues that stem from

poorly integrated or after-thought security.” Also, Buyya et al. point out in [4] that

Gómez R., G. Rosado D., Mellado D. and Fernández-Medina E..

Security Criteria in Deciding on Migration of Systems to the Cloud.

DOI: 10.5220/0004099600930100

In Proceedings of the 9th International Workshop on Security in Information Systems (WOSIS-2012), pages 93-100

ISBN: 978-989-8565-15-0

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

security can be guaranteed more easily over grids and clusters.

According to a research carried out by MeriTalk among 166 US Federal IT

executives 47% of the existing federal IT applications are based on legacy

technologies that need modernization [24]. The overall federal budget to maintain

this kind of systems can be estimated around the $35.7B, somewhat around 40% of

the overall federal budget for IT (this percentage when applied to the whole world IT

annual budget stands out up to $1.45T). According to Gartner, modernization

technologies for legacy is the fourth in the list of IT executives' priorities [11].

In this paper we present a preliminary research of some of the efforts that have

been made in the field and the concrete references that we have found regarding

issues like the impact of the security criteria in the migration of legacy systems to the

cloud. It is meant to be only the first step into a full research aiming the problem and

how it is presented to private and public organizations, what issues they regard as

important, and how they incorporate security criteria on their decisions.

The paper is structured in seven sections. The first one is this introduction. Section

two presents a definition on the decision problem. Sections three and four present two

related issues: the current state on multi-criteria analysis and the current research on

the legacy systems migration. In section six gives out some related works. Last, in

section seven we present our conclusions and future work.

Fig. 1. Top concerns surrounding cloud computing.

(source The Open Group Cloud Computing Survey 2011)

2 Problem Definition

An organization that plans migrating its legacy systems to the cloud must face several

challenges: to reduce or keep the overall provision costs while ensuring the functional

levels and enhancing or maintaining some other requirements like scalability, security

and privacy, and response when a lack of availability event comes about.

Decision Makers: Most of the times, the leading decision makers are the non IT

executives (i.e. those in the functional areas) and also those who are responsible of the

IT area. Usually all of them work together since there are common interests though

each one might have different concerns about the migration goals.

Goals: In any case, the goal of the decision is not unique and, frequently, they are

conflicting goals. Every project of migration of a system to the cloud (whether or not

is legacy) aims one or more of these:

Cos t

Interoperability & portability

Performance issues

Security

Vendor lock-in

Other

• To reduce the cost associated to the normal work of the system.

• To improve the flexibility of the system to cope with peak times.

• To improve the system availability.

• To ease the sustainable growth of the system.

• To improve the intrinsic security of the system.

• To prepare the organization for a (may be partial) outsourcing of IT function.

Uncertainty and Risks: On the other hand, we must be prepared to accept that either

decision (migrate it or not, and which systems are to migrate, and which model we

choose) have some uncertainties that we must manage. For instance, the main

uncertainty usually comes from the financial side. A sustained growth of the

organization might justify investments and service costs of traditional data centres,

but if a recession strikes, maintaining oversized systems may impose an excessive

cost impossible to reduce with traditional models. Another uncertainty we find is the

question on how technology evolves and the lower costs that the evolution brings.

Impact of Time: A legacy migration (valuable for the organization) is not a long

term project, but its effects are long term and must be planned carefully. First,

because the main driver of the change usually is cost savings (like other outsourcing

processes). Nevertheless, once the decision is made, the utility model will be there for

good. In other words: if the driver is cost savings, the opportunity window may be not

always the same. Furthermore, any outsourcing process implies a cultural change that

needs some time to mature (before and after the project kick off).

Roles: Though there are two clearly identified roles (service providers and clients),

the truth is that there are many others that participate and/or are affected by the

decision: Public Administrations, other companies and people. For instance, when a

European citizen entitles to a EU company to keep their personal data, but when the

company places its data in the cloud, the preservation of the rights is not clear.

Decision Variables: The first decision variable in this kind of decision making

problem is whether migrating the legacy is viable, either in its entirety or some

subsystems, or it's better to keep the system just as it is.

If the migration is proposed, another decision variable is which service and

deployment models we choose for implementing the decision. The service models

that we usually find in literature are: software as a service (SaaS), platform as a

service (PaaS) and infrastructure as as service (IaaS). Deployment models usually

proposed are: public cloud, community cloud, managed cloud, hybrid cloud and

private cloud. Each of the service models and deployment models has different

characteristics of technical implications, cost, scalability, security, propriety, location,

etc. and solutions proposed may be different for each subsystem.

Finally, a third decision variable is what is service level that the company wants to

agree with the cloud service provider for each of the clauses in the service level

agreement (SLA). It can be anticipated that the provider will charge differently for

each service level agreed in the SLA (availability, unattended management,

monitoring, etc.). This variable is, furthermore, quite complex because can imply

different combinations and/or technical developments.

Table 1. Deployment models.

Managed by Property of

infrastructure

Infrastructure

located in

Accessible and used

Public cloud

Party provider 3

Party provider Out of premises Non trusted

Community

cloud

Party provider 3

Party provider /

Community

In premises /

Out of premises

Trusted

Managed

cloud

Party provider 3

Party provider In premises Trusted

Private cloud

Organization / 3

Party provider

Organization / 3

Party provider

In premises Trusted

Hybrid cloud

Organization &

Party provider

Organization &

Party provider

In premises & out of

premises

Trusted & Non trusted

3 Multi-criteria

The first thing we can see when we look at the problem is the fact that we do not face

a situation in which a single goal can be optimized. We have several goals, some of

them conflicting each other, some of them difficult to quantify (therefore to optimize).

Some of the goals (i.e. reducing the maintenance costs and improving the system

availability) are easy to measure, but are at odds with each other. Others, like

improving intrinsic security are hard to measure.

Some works, like [19], have presented into quantifying some aspects of security.

But, when the main driver for the change is economical, the best path is to quantify

security in terms of its economic impact.

Formally, a MCDA problem can be expressed as:

()

(

)

(

){}

Aaag,,ag,agmax

∈… /

(3.1)

Where A is a finite set of possible alternatives

{

}

a,,a,a

…

and

{

(

)

(

)

,…,g

(

)

}

a set of evaluation criteria.

Rarely an MCDA problem includes an alternative that optimizes all the criteria at

once. Furthermore, the solution is not only dependent on all input parameters in (3.1),

but on the beliefs of decision maker. The best solution is a compromise between the

given data and the preferences expressed by the decision makers.

In [12] Guitouni & Martel presented a methodology for a MCDA process

consisting in the non lineal recursive iteration with four steps: 1) structure the

problem, 2) model the preferences, 3) calculate the preference model, and 4) make

recommendations. The goal of the methodology was being able deal with all the

aspects of a decision problem in which a satisfactory solution is the new paradigm.

4 Legacy Systems Migration

The problem of low quality software from the perspective of maintainability and

adaptability of the systems is not new. Actually, this has been the core issue of the

whole practice of software engineering for many years. Whenever a new technology

appears, the products and services that were developed with the previous technologies

become legacy. For a given technology, the word ‘legacy’ is quite ambivalent: for the

owner of the system or for non IT executives ‘legacy systems’ are valuable assets,

whereas for the software practitioner of the IT executive they are a source of risks.

There are many definitions for ‘legacy system’, but probably the most extended in

the software engineering field are found in [22]: a system becomes legacy when

“significantly resist modification and evolution regardless of the technology from

which it is built.” Some point out that legacy systems actually have a social part and

include, not only hardware and software, but processes and people. Another common

characteristic of this kind of systems is that they are classified as critical to business.

As for the methodology to evolve legacy systems we can find a framework in [3],

where Bisbal et al. classify the evolution of legacy from wrapping technologies to

overall redevelopment of the deprecated system, being common the mixed. Properly

speaking, migration is in between wrapping and redevelopment. In [22], Seacord et al.

also offers an approximation to modernizing driven by risk.

Nevertheless, most of the works we have found have one thing in common: they

are not specifically adapted to a given technology (that is, they have not been

tailored). There is little work on how to migrate to service oriented architectures

(SOA), work that should draw our attention since cloud computing actually is an

specific form of provision for this kind of architectures. In [13], Heckel et al., justify

the lack of work in the field of SOA since it’s an area for which concern for

reengineering is quite recent. Actually, if we set our focus into the more specific issue

of cloud computing, references are even less.

5 Security Criteria for Cloud Environments

It’s not surprising that there are plenty of research on security criteria for cloud

computing or SOA, either generic ones or quite specific.

Jansen & Grance’s report [15] is probably the most noticeable set of criteria and

specific issues related to cloud computing. In it, it is made a detailed description on

the criteria and issues related to privacy and security, identifying the pros and cons of

the model set up against its traditional counterpart, and the main points to cover.

They identify some positive aspects of the cloud model: specialization of the

technical people, greater uniformity leads to a greater security and eases automation,

resources availability, platform scalability, uniformity, robustness of the backup and

recovery policies. They also give some negative aspects (i.e. a greater system

complexity from the global perspective or the the loss of direct control either on the

logical or the physical items).

Since cloud computing steams from a set of different technologies like SOA, Web

2.0 and computing as an utility, many of the issues related to privacy and security

were already known. They are only viewed from a new perspective.

Jansen & Grance divide their security criteria in nine sections: security

governance, rules and standards compliance, trust building, security architecture,

identity and access management, software isolation, data protection, system’s

availability and incident response. For each of these sections, they make specific

recommendations.

Two other basic references for cloud security are [5] and [6] from the Cloud

Security Alliance (CSA). CSA presents its guide following three views and fifteen of

security: architecture, governance and operation. Each of the domains represent, to

our decision problem, a set of restrictions to our model that should be evaluated for

each of the legacy piece we have to deal with.

As we can see, none of this threats looks directly linked with the migration of

legacy. Nevertheless, the overall impression is that legacy migration does pose some

specific security questions.

6 Related works

There are plenty of works presenting decision models of some sort related to cloud

migration. One of them even presents a case. But most are not multi-criteria, and

nearly all focus solely on the aspect of expected economic savings.

Probably the most interesting one we have found is presented in [16, 17] which

studies specifically the use of decision support tools. Khajeh-Hosseini et al. present in

[17] two methods supported by tools to asses on the decision process on who is the

best provider and technology solution for cloud computing: though costs modeling,

and benefits and risks analysis. Costs modeling is presented as an extension to the

UML deployment diagram by means of allowing the modeler to incorporate items

like virtual machines or virtual storage, or an unspecific node, or remote applications

or data. In its risks/benefits analysis mode, [16] presents a more deep analysis

regarding the benefits and risks and taking into account diverse factors with an overall

decision outcome as a weighted sum of the risks and the benefits. Both, pros and

cons, are catalogued intro categories: technical, organizational, legal, security and

financial.

Though it’s not specific to MCDA, another interesting work is Schryen’s one in

[21]. In it, it’s presented a model based on fuzzy logic applied to the problem of

investing in security measures for distributed system models. Shryen proposes a

process that starting from a formal specification language for modeling security

conditions and its transformation into logical predicates, he defines some fuzzy sets

and a decision model based on those sets.

Another paper worth mentioning is Huang’s et al. [14]. In it, they use models like

DEMATEL, ANP and Grey Relational Analisys to address the analytical decision

process of baking services cloud migration.

There are other articles published on the issue of decision making for cloud

migration, some of them are closer to our problem (security), others less close:

Andrezejak, Kondo & Ji [1], Bibi, Katsaros & Bozanis [2], Chen & Sion [7],

Fedriksson & Agustsson [9], and Künsemöller & Kark [18]. We haven’t considered

them since, though they are related with MCDA techniques and cloud migration, they

do not deal with the migration concept in the sense that we talk about here.

7 Conclusions and Future Work

From the works we have seen up to now, we conclude that though there are quite a

few papers on the issue of MDCA applied to cloud computing decisions, there is

nothing specifically designed to address the problem of legacy system migration, and,

though some of them point out to security concerns none of them handles the security

issues as factors modeled in a quantitative manner integrated with the overall decision

model, but as constraints that must be ensured.

For that reason, we are working to develop an overall model to help the

practitioners to integrate security into de decision of migrating legacy systems to the

cloud with a MCDA perspective.

Given that any proposed model should take into account the actual beliefs and

preferences of the actual practitioners, we have developed a questionnaire to help us

to understand which are the true concerns of the IT decision makers who must face a

project to migrate part of their systems to the cloud, and how much security is a real

concern and how the value it against economic restrictions like costs.

The questionnaire will look into other issues like the anticipated and the actual

issues regarding the migration process, and the result of the projects (if they are

already finished).

We will feed this questionnaire to several IT executives and further refine our

model so that it can be used to future aid into the decision problem after modeling the

beliefs and preferences of the decision maker.

Acknowledgements

This research is part of the following projects: MEDUSAS (IDI-20090557) and

ORIGIN (IDI-2010043(1-5), financed by the Centre for Industrial Technological

Development (CDTI) and the FEDER, MAGO-PEGASO (TIN2009-13718-C02-01)

awarded by the Spanish Ministry for Science and Technology and SERENIDAD

(PEII11-0327-7035) and SISTEMAS (PII2I09-0150-3135) financed by the Council of

Education and Science of the Castilla-La Mancha Regional Government.

References

1. Andrzejak, A., D. Kondo, and S. Ji. Decision Model for Cloud Computing under SLA

Constraints. in IEEE International Symposium on Modeling, Analysis & Simulation of

Computer and Telecommunication Systems (MASCOTS), 2010. 2010.

2. Bibi, S., D. Katsaros, and P. Bozanis. Application Development. Fly to the Clouds or Stay

in-House. in 19th IEEE International Workshop on Enabling Technologies: Infrastructures

for Collaborative Enterprises (WETICE), 2010 2010.

3. Bisbal, J., D. Lawless, B. Wu, and J. Grimson, Legacy Information Systems: Issues and

Directions. IEEE Software, 1999. 16(5): p. 103-111.

4. Buyya, R., C. S. Yeo, S. Venugopal, J. Broberg, and I. Brandic, Cloud computing and

emerging IT platforms: Vision, hype, and reality for delivering computing as the 5th utility.

Future Generation Computer Systems, 2009. 25(6): p. 599-616.

5. CSA, Security Guidance for Critical Areas of Focus in Cloud Computing. 2009, Cloud

Security Alliance.

6. CSA, Top Threats to Cloud Computing. 2010, Cloud Security Alliance.

7. Chen, Y. and R. Sion. To Cloud Or Not To Cloud? Musings On Costs and Viability. in 2nd

ACM Symposium on Cloud Computing SOCC 2011. 2011.

8. Christiansen, C. A., C. J. Kolodgy, S. Hudson, and G. Pintal, Identity and Access

Management for Approaching Clouds, in IDC White Paper. 2010.

9. Fredriksson, J. and K. Augustsson, Cloud Service Analysis Choosing between an on-

premise resource and a cloud computing service. 2011, Chalmers University of

Technology, University of Gothenburg.

10. Gens, F. IT Cloud Services User Survey, pt.2: Top Benefits & Challenges. 2008; Available

from: http://blogs.idc.com/ie/?p=210.

11. Gomolski, B., Gartner Perspective on IT Spending 2010. 2010, The Gartner Group.

12. Guitouni, A. and J. M. Martel, Tentative guidelines to help choosing an appropriate MCDA

method. European Journal of Operational Research, 1998. 109(2): p. 501-521.

13. Heckel, R., R. Correia, C. M. P. Matos, M. El-Ramly, G. Koutsoukos, and L. F. Andrade,

Architectural Transformations: From Legacy to Three-Tier and Services. Software

Evolution, 2008: p. 139-170.

14. Huang, C.-Y., W.-C. Tzeng, G.-H. Tzeng, and M.-C. Yuan, Derivations of Information

Technology Strategies for Enabling the Cloud Based Banking Service by a Hybrid MADM

Framework. Smart Innovation, Systems and Technologies, 2011. 10: p. 123-134.

15. Jansen, W. and T. Grance, Guidelines on Security and Privacy in Cloud Computing. 2011,

NIST.

16. Khajeh-Hosseini, A., D. Greenwodd, and I. Sommerville. Cloud Migration: A Case Study

of Migrating an Enterprise IT System to IaaS. in IEEE 3rd Int. Conf. on Cloud Computing

(CLOUD 2010). 2010.

17. Khajeh-Hosseini, A., I. Sommerville, J. Bogaerts, and T. P. Decision Support Tools for

Cloud Migration in the Enterprise. in IEEE 4th Int. Conf. on Cloud Computing (CLOUD

2011). 2011.

18. Künsemöller, J. and H. Kark. A Game-Theoretical Approach to the Benefits of Cloud

Computing. in 8th Intl. Workshop on Economics of Grids, Clouds, Systems, and Services

(Gecon2011). 2011.

19. Madan, B. B., K. Goševa-Popstojanova, K. Vaidyanathan, and K. S. Trivedi, A method for

modeling and quantifying the security attributes of intrusion tolerant systems. Performance

Evaluation, 2004. 56 p. 167–186.

20. Mell, P. and T. Grance, The NIST Definition of Cloud Computing 2011, NIST.

21. Schryen, G. A Fuzzy Model for IT Security Investments. in Sicherheit 2010. 2011.

22. Seacord, R., D. Plakosh, and G. Lewis, Modernizing Legacy Systems: Software

Technologies, Engineering Processes, and Business Practices. 1st ed. Addison-Wesley

Professional. 2003.

23. The Open Group, The Open Group Cloud Computing Survey. 2011, The Open Group

24. Tobin, M. and B. Bass, Federal Application Modernization Road Trip: Express Lane or

Detour Ahead? 2011, Meritalk.

25. Winkler, V. J. R., Introduction to Cloud Computing and Security, in Securing the Cloud.

Cloud Computing Security. Techniques and Tactics., E. Syngress, Editor. 2011. p. 25.

100
