A Systematic Review of Methodologies and Models for

the Analysis and Management of Associative and

Hierarchical Risk in SMEs

Antonio Santos-Olmo

, Luis Enrique Sánchez

, Eduardo Fernández-Medina

and Mario Piattini

SICAMAN Nuevas Tecnologías. Departament R+D,

Ave Maria, 5. Tomelloso, Ciudad Real, Spain

ALARCOS & GSyA Research Group. Universidad de Castilla-La Mancha,

Paseo de la Universidad, 4, 13071 Ciudad Real, Spain

Abstract. As a result of the growing dependence of information society on

ICTs, the need to know the risks that can affect information is enormously in-

creasing with the purpose of protecting it. This article shows advances in the

identification and management of risks in ICTs, particularly in the case of

SMEs, along with the first proposal of a methodology for management and

analysis of the associative risk in SMEs taking into account not only internal

risks derived from SMEs but also other external risks derived from other enter-

prises in the same sector or collaborating with them. Thus, we will obtain a high

quality risk analysis at low cost using advanced concepts such as “associative

algorithms” and “enterprise social networks”. In the era of globalization, SMEs

no longer work as independent companies but share more and more services,

even facilities, with other companies. Therefore, we cannot obtain an adequate

risk analysis without considering the risks associated with these collaborations.

In this article we present rhe results of a systematic review of methodologies

and models for the analysis and management of associative and hierarchical risk

in SMEs.

1 Introduction

From the point of view of enterprises, it is of utmost importance to put security con-

trols in place that would enable them to be aware of the risks to which they may be

subject, while at the same time controlling these risks carefully [1]. Nevertheless, the

majority of firms have chaotic security systems which have been created with no

proper guides, no documentation and insufficient resources [2].

The truth is that the actual extent to which these systems have been put in place is

really low. This is in spite of the fact that reality has shown that for enterprises to be

able to use information and communication technology with some guarantee, there

needs to be availability of guides, measures and tools that would make it possible for

them to know at any given time what their security level is, as well as to find out the

points of vulnerability not yet covered [3].

Santos-Olmo A., Sánchez L., Fernández-Medina E. and Piattini M..

A Systematic Review of Methodologies and Models for the Analysis and Management of Associative and Hierarchical Risk in SMEs.

DOI: 10.5220/0004102601170124

In Proceedings of the 9th International Workshop on Security in Information Systems (WOSIS-2012), pages 117-124

ISBN: 978-989-8565-15-0

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Some authors [4] suggest that a risk analysis should be carried out as a fundamen-

tal part of the SME. Other authors [5] propose the need to develop a new model of

risk analysis, directly addressing SMEs, considering that the use of techniques of

analysis and risk management, as well as the role of third parties, are essential if the

security of SME information systems is to be guaranteed.

It should also be said that in an age where collaboration is vital, with the present

state of the market being as it is, it is also essential to take a close look at the risk

coming about from the relationship of the company with its environment, as well as

with its circumstances (ever-changing) and other enterprises. These latter may be

third parties in some kind of service which the firm carries out, or they might be co-

participants in multi-enterprise projects.

In addition to this type of risk, those risks that are vertical in kind need to be man-

aged in the company hierarchy, where a subsidiary’s activity may affect the parent

firm, and vice-versa.

The main objective of this work, therefore, is to carry out a systematic review of

the models and methodologies which are either already in existence or in develop-

ment, for analyzing and managing risk. We take a look at associative and hierarchical

risk, as pertinent to SMEs.

2 Planning the Review

In the first place, at this stage we identify the need for the review, pointing out what

its objectives are, which sources will be used to find the primary studies, and whether

there were any restrictions. We also clarify what the inclusion and exclusion criteria

are, as well as which criteria will be used to assess the quality of the primary studies

and how the data from the studies will be extracted and synthesized.

2.1 Formulating the Question

In this section, the research question is defined; the goal here is to make the focus of

interest of the work clear and to settle the nature of the problem to be dealt with and

its main characteristics. This being the case, the research question can be defined as

follows:

Within the context of the planned systematic review, the existing proposals on

models and methodologies of risk analysis are going to be observed. Special emphasis

is going to be placed on those models and methodologies addressing work on associa-

tive risk, hierarchical risk and/or directed at SMEs. The most important ones are ex-

tracted, and a subsequent analysis and comparison of them is undertaken.

What work has been carried out to develop systems of risk analysis, which takes into

account hierarchical and associative risk, as well as application in SMEs?

118

2.2 Selecting the Sources

This phase takes as its objective the selection of the sources that will be used to carry

out the search for primary studies. The criterion for the selection of search sources

will be the possibility of consulting the documents on the Internet or in the digital

library of the University of Castilla La Mancha. This latter facility contains studies in

English, as well as inclusion search engines which make it possible to look up what-

ever interests us with more advanced parameters, as well as to search using a key

word.

The list of sources that was obtained and used to execute the systematic review is

the following: Science Direct, ACM digital library, IEEE digital library, SCOPUS,

Scholar Google, y DBLP.

2.3 Selecting the Studies

Once the sources have been established, the process has to be described, along with

the criterion that we are going to follow in executing the review to choose and assess

the studies.

First of all, the key words chosen were combined with connectors AND and OR,

obtaining the abstract search string shown below.

The procedure for the choice of studies begins by adapting the search string to

each source search engine and the execution of the search, with the latter limited to

work published in the last 7 years. The inclusion criterion acts upon the results ob-

tained when the search is run on the source, allowing us to make an initial selection of

documents which, in the context of the review, will be considered as candidates to

become primary studies.

The exclusion criterion operates on the sub-set of relevant studies obtained and al-

lows us to get the set of primary studies. As primary studies we choose those which,

for example, focus on the application of some standard such as ISO 27001 to risk

analysis in SMEs, or work that defines agile risk management methodology, or which

takes associative or environmental risk into account.

3 Carrying out the Selection and Information Extraction

Under this point, the systematic review is run on each one of the sources selected,

applying all the criteria and procedure specified.

The information extracted from the studies should contain the techniques, meth-

ods, processes, measures, strategies or any type of initiative for the adaptation of the

analysis, management or assessment of risk that is within the reach of SMEs, or that

handles associative or hierarchical risk.

At this point we will give an overview of each of the studies chosen and presented

MethodologyORmodelAND associativeOR hierarchicalAND “riskanalysis”OR“risk

management”OR“riskassessment"ANDSMBORSMEORPYME

119

above, according to the information extracted by means of the Information forms

created:

• Nachtigal, S. “E-business Information Systems Security Design Paradigm and

Model” [6]: The author proposes an Information Systems security model focusing on

organizations based on e-commerce, covering the design and management of Infor-

mation Security in this type of businesses.

• Abdullah, H. “A Risk Analysis and Risk Management Methodology for Mitigating

Wireless Local Area Networks (WLANs) Intrusion Security Risks” [7]: In this work,

the author proposes a Methodology of analysis and management of risk in WLAN

networks. The methodology proposed is based on the risk analysis methodology

known as OCTAVE, although it takes it only as a basis, since a large amount of time

is needed to apply this methodology.

• Bagheri, E. et al. “Astrolabe: A Collaborative Multiperspective Goal-Oriented

Risk Analysis Methodology” [8]: In this work, the authors present a risk analysis

methodology called Astrolabe. It is based on an analysis of the causes of risks in In-

formation Systems.

• Alhawari, S. et al. “Knowledge-Based Risk Management framework for Infor-

mation Technology project” [9]: These authors have a proposal for a conceptual

Framework called Knowledge-Based Risk Management (KBRM), which uses

Knowledge Management (KM) to improve the efficiency of risk management and

increase the probability of success in Information Technology (IT) Projects.

• Strecker, S et al. “RiskM: A multi-perspective modeling method for IT risk as-

sessment” [10]: In this work, its authors propose a conceptual modeling method

known as RiskM, aiming to meet the essential requirements in the sphere of risk eval-

uation in IT.

• Ma, Wei-Ming. “Study on Architecture-Oriented Information Security Risk As-

sessment Model” [11]: This author develops an architecture-oriented information

security risk assessment model (AOISRAM).

• Feng, Nan et al. “An information systems security risk assessment model under

uncertain environment” [12]: What is proposed here is a model for the assessment of

security risks in Information Systems based on the evidence theory (a generalization

of the Bayesian theory of subjective probability).

• Abraham, A. “Nature Inspired Online Real Risk Assessment Models for Security

Systems” [13]: This author of this work explains and discusses the advantages of

using fuzzy inference methods to develop intelligent online risk assessment models.

• Chang, She-I et al. “The development of audit detection risk assessment system:

Using the fuzzy theory and audit risk model” [14]: In this research work the authors

set forth a system for risk detection in auditing. The system is put into operation using

fuzzy theory and the audit risk model to establish with the greatest possible accuracy

the amount of auditory evidence available.

• Yang, Fu-Hong et al. “A Risk Assessment Model for Enterprise Network Security”

[15]: The authors suggest a conceptual modeling proposal for risk analysis in Infor-

mation Systems Security, focusing on the scope of local networks of the enterprise

under threat of infection and propagation of computing viruses. The main advantage

of the model proposed is that it can depict the state of risk on the network in graphic

120

form.

• Wawrzyniak, D. “Information Security Risk Assessment Model for Risk Manage-

ment” [16]: This author proposes an assessment and management model for risk in

Information Systems, setting out to make it above all as flexible and as simple as

possible to use.

• Lin, Mengquan et al. “Methodology of Quantitative Risk Assessment for Infor-

mation System Security” [17]: These authors put forward their proposal for a meth-

odology for assessing security risks in Information Systems; it is based on quantita-

tive methods for obtaining the respective criteria that indicate the way to assess the

general security of the Information System.

• Hewett, R. et al. “A Risk Assessment Model of Embedded Software Systems” [18]:

In this work we see a proposal for a technique for representing and assessing risks

associated with software that is embedded in given systems. The representation tech-

nique proposed is based on dynamic flow-graphs.

• Patel, S.C. et al. “Quantitatively assessing the vulnerability of critical information

systems: A new method for evaluating security enhancements” [19]: The method

which these authors have come up with has the goal of assessing the vulnerability of

an organization when faced with breaches in its systems of information security.

4 Analysis of Results

In Table 1 below, a comparison of the different proposals analyzed may be seen, with

respect to the future proposal that is hoped to be undertaken. The aspects assessed

may be considered to have been fulfilled completely, or partially, or not tackled at all

in the model.

Each one of these aspects analyzed is described as: i) Scope of Application: If the

model is applied in a company comprehensively- i.e., to the security of all the Infor-

mation Systems, or if is applied to only a subset of these; ii) Metrics: The guide in-

cludes mechanisms for measuring the clear criteria of risk, giving detailed infor-

mation on its application and assessment; iii) Qualitative techniques: The model in-

cludes qualitative measurement techniques; iv) Quantitative techniques: The model

includes quantitative measurement techniques; v) Associative: The model takes risk

distribution into account (for example, in outsourced activity, or in activity undertak-

en by the company in partnership with other firms) and it also considers the interrela-

tionship between the firm and its particular setting; vi) Hierarchical: The model takes

the hierarchical relationship between related companies into account; vii) SME-

oriented: The model has been developed to address the particular principles involved

in SMEs; viii) Knowledge reuse: The guide gathers knowledge as regards how the

model is put into operation, and information is collected throughout its use, so that

when the model is installed on subsequent occasions, this knowledge may be reused.

These features that are desirable for a model of analysis and management of asso-

ciative and hierarchical risks for SMEs have been obtained using the application of

the “action-research” method to real-life cases. It is deemed that each one of these

characteristics can be completely fulfilled, partially fulfilled or not taken into account

at all by the model.

121

Table 1. Comparison of the proposal selected.

Name

Global scope

Metrics

Qualitative Techniques

uantitative Technique

Associative

Hierarchical

SME-oriented

Knowledge Reuse

Nachtigal, S. No Part. No No Part. No Part. No

Abdullah, H No No Yes No No No Yes No

Bagheri, E. et al. Yes Yes Yes No No No No No

Alhawari, S. et al. No No No No No No No Yes

Strecker, S et al. Yes No Part. Part. No No No No

Ma, Wei-Ming Yes No No No Part. Part. Part. No

Feng, Nan et al. Yes No Yes Yes Part. No No No

Abraham, A. No No No No Part. No No Yes

Chang, She-I et al. No Part. Part. No Part. No No No

Ngai, E.W.T. et al. No Part. Yes No Part. No No No

Yang, Fu-Hong No No No No Part. No No No

Wawrzyniak, D. Yes No Yes No No No No No

Lin, Mengquan et al. Yes Part. No Yes No No No No

Hewett, R. et al. No No No No Part. No No Yes

Patel, S.C. et al. Yes Part. No Yes No No No No

5 Conclusions and Future Work

In this paper a systematic review of the different models and methodologies for risk

analysis and management has been carried out. The goal has been to study the SME-

oriented proposals that focus on associative and hierarchical risk. As a result of this

review, it has been possible to establish how important risk management and analysis

of Information System security is as part of any enterprise’s effort to sustain perfor-

mance and growth, aspects that are basic to that firm’s being able to fulfill its mission

and reach its organizational goals in a highly competitive environment.

There are numerous sources in the literature that point to and underline the diffi-

culty SMEs have in using traditional methodologies and models of risk analysis. The-

se were designed for large enterprises and their application in SMEs is difficult and

costly. [20, 21].

The main reasons why existing models of analysis and management are not enjoy-

ing success when implemented in SMEs are the following:

• Some of them were developed with large organizations in mind (Major standards

such as CRAMM, ISO/IEC 27005, MAGERIT, OCTAVE, NIST SP 800-39, Mehari,

COBIT o ERMF), as well as in the organizational structures associated with these.

122

Others (Abdullah, Wei-Ming Ma, Nachtigal) have attempted to simplify the model to

make it suitable for companies with limited means. These researchers, however, either

produce incomplete models which tackle only part of the issue, or try to provide basic

guides for the steps to be taken, without going into how to really assess and manage

risk in such a way that the technical personnel of the firm can be involved in the pro-

cess. Furthermore, most of these proposals are theoretical and are still in develop-

ment.

• The majority of the proposals do not take into account the need to address hierar-

chical and associative risks, which are crucial factors in the present structure and

work of enterprises (in which Cloud systems are becoming more and more widely-

employed). All this is especially true in the case of SMEs.

It may be concluded, then, that it is justifiable to produce a new model for implemen-

tation in SMEs, which would allow us to include all those features considered as de-

sirable which have been mentioned above.

All of the standards and proposals for assessing and managing risk studied in this

paper are significant ones, and their contributions will be taken into account in the

development of a methodology that will incorporate all the characteristics desired.

Acknowledgements

This research is part of the following projects: MEDUSAS (IDI-20090557), financed

by the Centre for Industrial Technological Development (CDTI), ORIGIN (IDI-

2010043(1-5)) financed by the CDTI and the FEDER, BUSINESS (PET2008-0136)

awarded by the Spanish Ministry for Science and Technology and MARISMA

(HITO-2010-28) and SISTEMAS (PII2I09-0150-3135) financed by the Council of

Education and Science of the Castilla-La Mancha Regional Government.

References

1. Kluge, D. Formal Information Security Standards in German Medium Enterprises. in

CONISAR: The Conference on Information Systems Applied Research. 2008.

2. Wiander, T. and J. Holappa, Theoretical Framework of ISO 17799 Compliant. Information

Security Management System Using Novel ASD Method., in Technical Report, V.T.R.C.o.

Finland, Editor 2006.

3. Wiander, T. Implementing the ISO/IEC 17799 standard in practice – experiences on audit

phases. in AISC '08: Proceedings of the sixth Australasian conference on Information

security. 2008. Wollongong, Australia.

4. Volonino, L. and S. Robinson. Principles and Practice of Information Security. in 1 edition,

Anderson, Natalie E. 2004. New Jersey, EEUU.

5. Spinellis, D. and D. Gritzalis. nformation Security Best Practise Dissemination: The ISA-

EUNET Approach. in WISE 1:First World Conference on Information Security Education.

1999.

6. Nachtigal, S., E-business Information Systems Security Design Paradigm and Model. Royal

Holloway, University of London, Technical Report, 2009: p. 347.

7. Abdullah, H., A Risk Analysis and Risk Management Methodology for Mitigating Wireless

123

Local Area Networks Intrusion Security Risks. University of Pretoria, 2006: p. 219.

8. Bagheri, E. and A. A. Ghorbani, Astrolabe: A Collaborative Multiperspective Goal-

Oriented Risk Analysis Methodology. IEEE TRANSACTIONS ON SYSTEMS, MAN,

AND CYBERNETICS—PART A: SYSTEMS AND HUMANS, 2009. 39(1): p. 66-85.

9. Alhawari, S. et al., Knowledge-Based Risk Management framework for Information

Technology project. International Journal of Information Management, 2012. 32(1): p. 50-

65.

10. Strecker, S., D. Heise, and U. Frank, RiskM: A multi-perspective modeling method for IT

risk assessment. Inf Syst Front, 2010(13): p. 595–611.

11. Ma, W.-M., Study on Architecture-Oriented Information Security Risk Assessment Model.

ICCCI 2010, Part III, LNAI 6423, 2010: p. 18–226.

12. Feng, N. and M. Li, An information systems security risk assessment model under

uncertain environment. Applied Soft Computing, 2011. 11(7): p. 4332-4340.

13. Abraham, A., Nature Inspired Online Real Risk Assessment Models for Security Systems.

EuroISI 2008, LNCS 5376, 2008.

14. Chang, S.-I., et al., The development of audit detection risk assessment system: Using the

fuzzy theory and audit risk model. Expert Systems with Applications, 2008. 35(3): p. 1053-

1067.

15. Yang, F.-H., C.-H. Chi, and L. Liu, A Risk Assessment Model for Enterprise Network

Security. ATC 2006, LNCS 4158, 2006: p. 293 – 301.

16. Wawrzyniak, D., Information Security Risk Assessment Model for Risk Management.

TrustBus 2006, LNCS 4083, 2006: p. 21–30.

17. Lin, M., Q. Wang, and J. Li, Methodology of Quantitative Risk Assessment for Information

System Security. CIS 2005, Part II, LNAI 3802, 2005: p. 526 – 531.

18. Hewett, R. and R. Seker, A Risk Assessment Model of Embedded Software Systems. 29th

Annual IEEE/NASA Software Engineering Workshop (SEW’05), 2005: p. 8.

19. Patel, S. C., J. H. Graham, and P. A. S. Ralston, Quantitatively assessing the vulnerability

of critical information systems: A new method for evaluating security enhancements.

International Journal of Information Management, 2008. 28(6): p. 483-491.

20. Calvo-Manzano, J. A. et al., Experiences in the Application of Software Process

Improvement in SMES. Software Quality Journal., 2004. 10(3): p. 261-273.

21. Mekelburg, D., Sustaining Best Practices: How Real-World Software Organizations

Improve Quality Processes. Software Quality Professional, 2005. 7(3): p. 4-13.

124
