Java2OWL: A System for Synchronising Java and OWL

Hans J¨urgen Ohlbach

Institute for Informatics, University of Munich, Munich, Germany

Keywords:

Java, OWL, Translation, Semantic Programming.

Abstract:

Java2OWL is a Java software library for synchronising Java class hierarchies with OWL concept hierarchies.

With a few extra annotations in Java class ﬁles, the Java2OWL library can automatically map Java class hier-

archies to OWL ontologies. The instances of these Java classes are automatically mapped to OWL individuals

and vice versa. OWL reasoners can be used as query processors to retrieve instances of OWL concepts, and

these OWL individuals are mapped to corresponding instances of the Java classes. Changes of the Java ob-

ject’s attributes are automatically mapped to changes of the corresponding attributes of the OWL individuals,

thus keeping Java and OWL synchronised. With minimal programming overhead the library allows one to

combine the power of programming (in Java) with the expressivity and the reasoning power of OWL. This

paper introduces the main ideas and techniques. The detailed documentation and the open source library itself

can be downloaded from http://www.pms.iﬁ.lmu.de/Java2OWL.

1 MOTIVATION

Object oriented programming languages like Java

combine the procedural aspects of programming with

some declarative-logical features contained in the

Java class hierarchy and the instance-class relation-

ship. Whereas the procedural aspects are as strong as

one can expect from modern programming languages,

the logical aspects are rather restricted. In particular

• the ontology, i.e. the logical structure, implicitly

contained in the class hierarchy of Java programs

is only accessible from within the program and

can not be exported to other systems;

• the instance-class relationship is ﬁxed at the cre-

ation time of an object. Objects can not live in-

dependently of classes and can not change their

membership relation to classes;

• the class hierarchy in Java is a tree; no multiple

inheritance is possible;

• there is no logical reasoning available. This

means in particular that ﬁne grained selection of

objects is difﬁcult.

Nevertheless, these are desirable features, which is

indicated by the rising popularity of modelling lan-

guages like UML, and in particular by the more

and more widespread use of the logic-based Ontol-

ogy Working Language (OWL

). OWL is the W3C-

OWL: http://www.w3.org/TR/owl2-overview/

standard for Description Logics (Baader et al., 2003;

Lutz, 2003). Its main features are

• one can deﬁne ontologies independently of any

particular application or programming language;

• the OWL-language is very expressive and more

features are being added as one learns how to ex-

tend the logical calculus for them;

• since it is logic based, various forms of reasoning

can be performed;

• the class hierarchy can be a DAG, thus, multiple

inheritance is allowed;

• individuals can live independently of classes.

Their membership relation with classes is deter-

mined by logical reasoning, and it can change

when new information about an individual be-

comes available;

• there are expressive languages which can be used

to pose complex queries to an ontology. They are

evaluated by logic reasoners.

The disadvantage of OWL is the lack of procedural

features; OWL is no programming language. For an

OWL ontology together with an A-Box (a set of in-

dividuals) one can draw all possible inferences, i.e.

compute the class hierarchy and the membership re-

lation of the individuals with the classes. After this,

however, the ontology becomes a static object which

can do nothing by itself.

Ohlbach H..

Java2OWL: A System for Synchronising Java and OWL.

DOI: 10.5220/0004106400150024

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2012), pages 15-24

ISBN: 978-989-8565-30-3

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

An OWL ontology just living in a ﬁle system is

not of much use. Therefore application interfaces

(API) have been developed which allow programs to

load an ontology, access its data, manipulate the on-

tology, and save it back to ﬁles, all within ordinary

programs. The most recent one is the Java OWL API

for OWL-version 2 (Horridge and Bechhofer, 2011),

developed as part of the CO-ODE project

and the

TONES project

in the Manchester University

. It al-

lows one to load, access and manipulate the structure

of OWL ontologies and to integrate them with OWL

reasoners.

Java programs using the OWL API for loading

ontologies have two class hierarchies in parallel, the

Java class hierarchy and the OWL class hierarchy. For

applications where these hierarchies are sufﬁciently

different, this is no problem. If, however, the class

hierarchies overlap, one gets a considerable synchro-

nisation problem. Overlapping class hierarchies are

of interest if one wants to add procedural features to

the classes. Since OWL has no procedural features,

the only choice is to deﬁne correspondingJava classes

with the corresponding methods.

As an illustrating example, consider the partial

modelling of university structures. There are peo-

ple, students, tutors, lecturers, professors, secretaries,

technical staff etc. There are programmes of study,

Bachelor, Master and PhD programmes. There are

lectures, seminars, excursions etc. There are scien-

tiﬁc areas, natural sciences, humanities, social sci-

ences etc. All this can be modelled in OWL, but

there is no chance to add procedural features to these

OWL classes. This can only be done in corresponding

Java classes. Combining Java classes and their meth-

ods with corresponding OWL classes as the basis of

OWL-reasoning, however, may turn out to be a very

useful thing. The Java methods do the computation,

and the OWL classes can in particular be used to se-

lect sets of individuals by determining the instances

of OWL concept expressions.

The Java2OWL library presented in this paper tar-

gets the synchronised coexistence of Java classes and

OWL classes. It makes it possible to exploit the

strengths of both systems without too much program-

ming overhead.

2 A TYPICAL WORKFLOW

A typical workﬂow in the development and applica-

OWL API: http://owlapi.sourceforge.net/

CO-ODE project: http://www.co-ode.org/

TONES project: http://www.tonesproject.org/

Manchester University: http://owl.cs.manchester.ac.uk/

tion of Java programs using the Java2OWL library

consists of two major phases:

1. the preparation phase, which consists of the pro-

gramming and the compilation phase,

2. the Java application phase which starts with the

steps a Java application has to perform in order to

work with the Java2OWL library.

2.1 The Preparation Phase

This phase consists of the following steps:

1. Background Ontology. Most applications which

want to use ontologies do not start from scratch,

but us already existing ontologies, or develop spe-

cialised ontologies for this application. Therefore

the Java2OWL library assumes the existence of

a “background ontology” with predeﬁned classes

and properties. This background ontology can be

loaded into the Java2OWL-compiler which then

extends it with OWL classes generated from Java

classes.

2. Annotating Java Classes. Java classes which

are to be mapped to OWL classes must be an-

notated in a special way. The class-level anno-

tations control the generation of OWL classes and

the method-level annotations control the genera-

tion of the OWL-properties. Typically, the Java

class has getter methods, setter methods, and for

collection-valued attributes, adder and remover

methods. The annotations of the getter methods

are sufﬁcient to tell the system how to access and

manipulate the Java-attributes and to synchronise

them with the OWL-properties.

3. Compiling the Extension Ontology. The anno-

tated Java classes are mapped to newly gener-

ated OWL classes which are added to the back-

ground ontology. The getter methods are mapped

to OWL-properties, either data properties, map-

ping objects to data types like integer, or object

properties, mapping objects to other objects. The

so extended background ontology is then saved as

“extension ontology”.

4. Extending the Extension Ontology. In some ap-

plications it may be necessary to manually extend

the extension ontology, for example by adding

special individuals. Therefore one can manipulate

the extension ontology outside the Java2OWL-

system in an almost arbitrary way before it is used

in the application program.

5. Injecting Synchronisation Code into the Java

Classes. Since Java classes and OWL classes co-

exist in the Java2OWLsystem, their instances also

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

coexist. This means, for each Java object which is

an instance of an annotated Java class, there is a

corresponding OWL individual. This OWL indi-

vidual should mirror the attributes of the Java ob-

ject. If the Java object changes its attributes, the

changes should automatically trigger changes of

the attributes of the OWL individual. The code

for forwarding the changes of the Java-attributes

to the OWL side must be contained in the setter,

adder and remover methods of the Java class. In

order to relieve the Java programmer from writ-

ing this “synchronisation code” the Java2OWL li-

brary contains a “Synchroniser” class which auto-

matically injects the “synchronisation code” into

the compiled Java classes. This can be done either

in a separate step after the ordinary Java compila-

tion, or it can be done “on the ﬂy” in the class

loader.

2.2 The Java Application Phase

As soon as all the preparations have been successfully

completed, i.e. the Java application with the annotated

classes has been build and the extension ontology is

ready to be used, the application can start. These are

the typical steps, the application must do before its

main job can start:

1. Setting Up the System. This is simply done

by creating a J2OManager. The J2OManager it-

self creates all other components and installs a

default OWL-reasoner. One can create several

J2OManagers, but they are completely indepen-

dent of each other and do not interact with each

other.

2. Loading the Extension Ontology

3. Linking the Extension Ontology. In this step

the internal data structures are created which keep

track of the correspondences between Java classes

and OWL classes.

4. Creating Java-objects and OWL Individuals.

The system is now ready to create instances of

classes. It is possible to instantiate Java classes

and let the Java2OWL-system map them to OWL

individuals. The other direction is also possible.

OWL individuals contained in the A-Box of the

extension ontology can be mapped to instances of

the corresponding Java classes.

5. Keeping Java-objects and OWL Individuals

Synchronised. Changes to the attributes of in-

stances should only be done by calling setter,

adder, and remover methods of the Java-objects.

The injected synchroniser-code automatically for-

wards the changes to the OWL-side.

6. Reclassiﬁcation of Instances. OWL is logic

based. Therefore OWL reasonerscan derive infor-

mation which was only implicitly contained in the

OWL ontology generated from the Java side. This

derived information can then be mapped back to

the Java side. There are two typical situations

where this can occur:

• An Object’s Class May Be Changed. Consider

a Java class

Student

with attribute

semester

and a subclass

Freshman

whose semester is

frozen to the value 1. An instance of the

Java class

Student

whose semester is set to 1

should now become an instance of

Freshman

This is not directly possible in Java. In the

Java2OWL-system, however, the Java-objects

are contained in wrapper-objects. Therefore

it is possible to exchange a Java-object in-

side a wrapper object with another Java ob-

ject. In the

Student

Freshman

-example this

would be performed by creating an instance of

Freshman

and transferring all non-static ﬁelds

of the

Student

-instance to the new

Freshman

instance. The new

Freshman

-instance then re-

places the

Student

-instance inside the wrapper

object.

• An Object’s Attributes May Be Changed. Con-

sider a Java class with a transitive

has-Part

at-

tribute. If this is mapped to OWL then an OWL

reasoner can derive the transitive closure of the

has-Part

relation. Mapped back to Java the

has-Part

attribute is automatically ﬁlled with

the transitive closure of the

has-Part

relation.

The application program can ask the Java2OWL-

system at any time to do this reclassiﬁcation of

instances whose attributes have been changed.

3 JAVA CLASS HIERARCHY

VERSUS OWL CLASS

HIERARCHY

The intrinsic Java ontology which is implicitly con-

tained in the Java class hierarchy is simpler than the

OWL ontology: mono-inheritance causes the Java

class hierarchy to be become a tree, and the con-

structor mechanism for generating new instances of

classes causes Java objects to be an instance of ex-

actly one Java class. In contrast to this, OWL has

multi-inheritance, and OWL individuals may be in-

stances of several classes. Mapping a Java ontology to

an OWL ontology is therefore not problematic. This

part of the Java2OWL library is purely technical.

Java2OWL:ASystemforSynchronisingJavaandOWL

The Java2OWL library, however has three further

features which are more problematic:

• it can map OWL individuals back to Java objects,

• it can attach attributes to Java objects, which

are not foreseen in the Java class deﬁnition, and

which must therefore be immediately forwarded

to the OWL side,

• it can reclassify Java objects when further infor-

mation becomes available.

If OWL individuals are to be mapped back to Java ob-

jects, we have to deal with the problem that an OWL

individual may be an instance of several OWL classes.

Therefore one can not just create an instance of one

particular Java class as corresponding Java object. If

extra attributes can be attached at Java objects by for-

warding them to the OWL side, this may cause a new

situation. For a Java object o as an instance of the Java

class C which corresponds to a unique OWL object o

′

as instance of the OWL class C

′

the OWL instance

′

may suddenly become an instance of other OWL

classes, and therefore there is no longer this unique

correspondence between o and o

′

. The problem turns

up when the Java object is reclassiﬁed to incorporate

the new information.

The solution to these problems in the Java2OWL

library so far is experimental because no real applica-

tion where these problems turned up have been tried.

The solution is to encapsulate the correspondences

between Java objects and OWL individuals in indi-

vidual wrappers. An individual wrapper encapsulates

an OWL individualtogether with several Java objects.

The typical example which illustrates the

multi-inheritance phenomenon is the OWL class

Amphibious-Vehicle

as subclass of

Ship

and

Surface-Vehicle

. Since in Java there can not

be a class

Amphibious-Vehicle

extending

Ship

and

Surface-Vehicle

, there is a problem. In Java

one could in principle deﬁne either

Ship

as a class

and

Surface-Vehicle

as an interface, and then

deﬁne a class

Amphibious-Vehicle

extending

Ship

and implementing

Surface-Vehicle

, or the other

way round. In this case, however, there can not

be instances of

Surface-Vehicle

, which might

not be a good idea. Therefore when mapping an

Amphibious-Vehicle instance from OWL to Java,

Java2OWL creates an individual wrapper containing

a Java Ship instance and a Java Surface-Vehicle

instance. It takes care that the common attributes of

both Java objects are pointer-equal.

Even when multi-inheritance is avoided at the

OWL side, there can be situations where an OWL

individual must be mapped to several Java objects.

As an example consider a Java class

Student

and a

Java class

Teacher

which have nothing to do with

each other, except that the

Teacher

class has an at-

tribute

teaches

(some students). Both

Student

and

Teacher

are mapped to the OWL ontology. Now sup-

pose,

James

is an instance of

Student

, and we add

the extra information that

James

is not only a student,

but teaches another student

Tom

. This information is

not attached to the Java object

James

, but forwarded

to the corresponding OWL individual

James’

. At this

moment,

James’

becomes an instance of the OWL

class

Teacher’

. If this information is mapped back

to the Java side, besides the Java object

James

instance of the Java class

Student

, we need also

an instance, say

James-Teacher

, of the Java class

Teacher

. Both Java objects can be wrapped in an

individual wrapper, which at ﬁrst glance, solves the

problem.

There is, however, a further problem. Sup-

pose

James

does not teach another student

Tom

, but

James teaches himself,

James

. The Java instance

James-Teacher

has an attribute

teaches

of type

Student

. This attribute has to be ﬁlled with James,

but which James, the

Student

instance

James

or the

Teacher

instance

James-Teacher

? In this case it is

clear by the type of the

teaches

attribute, that the

Student instance

James

is the only Java object which

can be put into the

teaches

attribute. In other exam-

ples, however, there may be several choices. The cur-

rent implementation is such that it takes the ﬁrst one

whose Java class ﬁts the class of the attribute. Only

practical applications can show what is really needed

in these situations.

4 COMPONENTS OF THE

LIBRARY

This section gives a brief overview of the main com-

ponents of the system.

4.1 Annotated Java Classes

The ﬁrst aspect a programmer who wants to use

Java2OWL is confronted with, is the structure of the

Java classes to be mapped to OWL classes. The fol-

lowing restrictions to the structure of the Java classes

are important:

• There must be a constructor method with an

empty argument list. It is used when OWL in-

dividuals are mapped to Java objects.

• All attributes which are to be mapped to OWL-

attributes must be accessible by getter, setter,

adder and remover methods.

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

• The mapping of Java classes to OWL classes

is controlled by special annotations of class and

method deﬁnitions.

4.1.1 The Class-level Annotation

A simple example illustrates the annotation of classes:

@J2OWLClass(name = "Person",

OWLSuperClasses = "LivingThing")

public class TestPerson {...}

The

name

-attribute

Person

causes the mapping

of the Java class

TestPerson

to a newly cre-

ated OWL class

Person

. The

OWLSuperClasses

attribute

LivingThing

causes the generated OWL

class

Person

to become a subclass of the OWL class

LivingThing

, which must be part of the background

ontology.

Besides

name

and

OWLSuperClasses

, three

further attributes can be used in the annota-

tion:

EquivalentClass

synchronise

and

naming

EquivalentClass

with an OWL class expression in

Manchester Syntax

as value causes the generated

OWL class to be equivalent to the given class expres-

sion.

synchronise

triggers the insertion of synchro-

niser code into the setter, adder and remover methods.

naming

controls the assignment of names to the gen-

erated OWL individuals.

4.1.2 The Method Level Annotations

The Java2OWL annotations control the mapping of

Java-attributes to OWL-properties. OWL distin-

guishes two kinds of properties:

OWLDataProperty: these describe basic datatype-

valued attributes of individuals. OWL has a num-

ber of basic data types built-in, for example, in-

teger, ﬂoat, double, etc., but also strings. Exam-

ples could be a string-valued

name

-attribute, or an

integer-valued

age

-attribute.

OWLObjectProperty: these describe relations be-

tween OWL individuals. Examples are the

hasPart

relation between physical objects, or the

hasParent

relation between persons.

Both property types can be functional or non-

functional i.e. relational. Functional properties have

a single value, whereas relational properties can have

any number of values, including no values at all.

On the Java side there are the instance-variables

which, depending on their type, can take primitive

data types as values, references to other Java-objects,

Manchester Syntax: http://www.w3.org/2007/OWL/

wiki/ManchesterSyntax

but also references to container objects like sets, ar-

rays etc. It is good Java practice to keep the instance

variables private and to access them with getter and

setter methods. Therefore the mapping from Java-

attributes to OWL-properties is speciﬁed by annotat-

ing getter methods instead of the instance variables.

Java2OWL assumes the following conventions:

getter Methods: They have no arguments and usu-

ally return the value of a private variable. Since

Java is strongly typed, the return type of the get-

ter methods can be used to determine the kind

of OWL-property to be generated. The following

cases are distinguished:

• The return type of the getter method is a primi-

tive data type or the type

String

. In this case a

functional OWLDataProperty is generated.

• The return type of the getter method is an ar-

ray or a container class for primitive data types

or strings. In this case a relational OWLDat-

aProperty is generated.

• The return type of the getter method is a

Java2OWL annotated Java class. In this case

a functional OWLObjectProperty is generated.

• The return type of the getter method is an array

or a container class for a Java2OWL annotated

Java class. In this case a relational OWLOb-

jectProperty is generated.

setter Methods: Setter methods usually overwrite

the value of a private variable. They are called

with at least one argument and need not return a

value. The type of the ﬁrst argument must be such

that it accepts the result of the corresponding get-

ter method.

adder Methods: Collection-valued attributes, arrays

or collections, need not change the whole set at

once, but add single elements one by one. Adder

methods therefore take an element of the collec-

tion as ﬁrst argument and add it to the set.

remover Methods: remover methods for collection-

valued attributes take an element of the set as ﬁrst

argument and remove it from the set.

clearer Methods: clearer methods for collection-

valued attributes empty the whole collection at

once.

For each attribute to be mapped there must be exactly

one annotated getter method which returns the entire

set of values, either a single object if there is just one

value, i.e. the attribute is functional, or an array or a

collection of objects if there are multiple values.

For each attribute there is a particular group of get-

ter, setter, and optionally adder and remover methods

which belong together. Therefore it is convenient to

Java2OWL:ASystemforSynchronisingJavaandOWL

annotate the getter methods only and specify in the

annotation the other methods belonging to the group.

A typical example for an annotated getter method is

@J2OWLProperty(name = "hasName",

setter="setName")

public String getName() {

return name;}

public void setName(String name) {

this.name = name;}

The speciﬁcation of

@J2OWLProperty

is:

public @interface J2OWLProperty {

String name() default "";

boolean local() default false;

String setter() default "";

String adder() default "";

String remover() default "";

String clearer() default "";

boolean transitive() default false;

boolean symmetric() default false;

boolean asymmetric() default false;

boolean reflexive() default false;

boolean irreflexive() default false;

boolean total() default false;

int atleast() default -1;

int atmost() default -1;

boolean addRangeAxiom() default true;}

The meaning of these attributes is:

name: is the name of the corresponding OWL-

property.

local: If this ﬂag is set to true then the generated

name is preﬁxed with the class name.

setter, adder, remover: These are the comma sepa-

rated names of the corresponding methods which

are responsible for the same attribute.

clearer: This must be the name of a parameter-

less method which empties collection valued at-

tributes.

transitive, symmetric, asymmetric, reﬂexive,

irreﬂexive: These are properties of OWLObject-

Properties.

total: If this ﬂag is set to true it enforces that the

functional properties is total, but only for the

OWL class generated from this particular Java

class.

atleast, atmost: They specify the minium and maxi-

mum number of role ﬁllers for relational proper-

ties.

addRangeAxiom: If

addRangeAxiom

is true then

corresponding range type axiom is speciﬁed for

the OWL-property generated from the getter

method.

4.2 The Java2OWL Compiler

The Java2OWL compiler, implemented in the class

J2OCompiler

, generates OWL classes from anno-

tated Java class ﬁles. For the preparation phase it has

a main method such that it can be called to generate

the extension ontology from a given list of compiled

Java classes.

The program reads the background ontology, cre-

ates an extension ontology, reads the class ﬁles, anal-

yses its annotations, ﬁlls the extension ontology with

the translated Java classes and saves the extension on-

tology. Error messages are printed to System.out.

Notice that not all Java class ﬁles to be translated

need to be given as input. For a given class C to

be compiled to OWL the J2OCompiler automatically

translates the following classes:

• all annotated superclasses of C,

• all annotated static inner classes of C,

• all annotated range type classes of the annotated

getter methods in C.

In the application phase (see Sect. 2.2) its meth-

ods can be used to link the Java classes with the OWL

classes i.e. to build the internal data structures neces-

sary for managing the correspondences between Java

and OWL.

4.2.1 Compile Time Errors

The

J2OCompiler

analyses annotated Java class and

combines the extracted structures with the back-

ground ontology. In this step it tries to detect as many

programming errors as possible.

Here are examples for errors it can detect:

• Inconsistencies in the annotations of getter meth-

ods. For example, a relation can not be declared

reﬂexive and irreﬂexive at the same time.

• Java data types which can not be mapped to OWL

data types:

The Java data types which can be mapped to

OWL data types are the primitive Java data types

boolean, byte, short, int, long, ﬂoat, double and

the String type. All other built-in Java data types,

for example BufferedString, are not mapped to

OWL data types. A speciﬁcation like

@J2OWLProperty(name = "hasName")

public BufferedString getName() {

return name;}

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

therefore causes an error.

• Classes without necessary Java2OWL annota-

tions:

Consider a class

Person

with a getter method

@J2OWLProperty(name = "hasAddress")

public Address getAddress() {

return address;}

This causes a functional Object Property

hasAddress

to be created, which maps indi-

viduals of type

Person

to individuals of type

Address

. If there is no class

Address

in the

background ontology and the Java class

Address

is not annotated, the relation

hasAddress

makes

no sense in the extension ontology.

The

J2OCompiler

can of course not detect all errors

which may course trouble at run time. Therefore run

time error handling is also necessary (see Sect. 4.4.2).

4.3 Synchronisation between Java and

OWL

4.3.1 Java to OWL Synchronisation

Java to OWL synchronisation means that changes to

attributes of Java objects are forwarded to the corre-

sponding OWL individuals. The Java2OWL library

provides two different possibilities to do this:

Life Synchronisation. This means that all changes

to the attributes of Java objects are immediately

forwarded to the corresponding OWL individual.

This is only possible if the annotated Java classes

got ‘synchroniser code’ injected. Life Synchroni-

sation can be turned on and off at any time. This

can be done at class level, i.e. for all instances of

a given class. The activation/deactivation of class

level life synchronisation can be overwritten by

activating/deactivating it for single objects.

Block Synchronisation. This means that changes to

the attributes of Java objects are not forwarded to

OWL for a while, and at some time the application

decides to do this ‘en bloc’ for all attributes of the

object.

4.3.2 The Java2OWL Synchroniser

The

J2OSynchronizer

-class is used to insert extra

‘synchroniser code’ into the setter, adder, remover

and clearer methods of the compiled Java class ﬁles.

It can be used in two ways:

• the J2OCompiler calls it when a corresponding

ﬂag is set,

• the

J2OSynchronizerAgent

calls it in its

premain-method. This causes a further trans-

former to be installed in the class loader. This

transformer calls the J2OSynchronizer to inject

the synchronizer code when a compiled class is

loaded.

The bytecode manipulation for injecting the

synchroniser code has been programmed with the

Byte Code Engineering Library

(Apache Commons

BCEL

) (Dahm, 1999). An alternative would have

been to use AspectJ

(Colyer et al., 2004). With the

BCEL-library, however, certain optimisations of the

byte-code were possible, which were not supported

by AspectJ.

4.4 The J2OOntology Manager

The

J2OOntologyManager

is a kind of interface be-

tween the OWL API and the application. The OWL

API consists of three main components:

• the

OWLOntologyManager

which stores all the

data belonging to an ontology,

• a

OWLDataFactory

which creates the structures

necessary to interact with the ontology,

• a reasoner. There can be several reasoners, but

only one can be active within a J2OManager at

any time.

The current version of the Java2OWL library supports

three reasoners, HermiT (Birte Glimm et al, 2010),

Pellet (Sirin et al., 2007) and FaCT++ (Tsarkov and

Horrocks, 2006).

Since the interaction with the OWL API is some-

times quite cumbersome, the

J2OOntologyManager

hides the pecularities of the OWL API. Its main tasks

are:

• loading and saving ontologies;

• setting up reasoners;

• getting information about the components of the

ontology;

• making changes to the extension ontology.

• querying the ontology with expressions in Manch-

ester Syntax. OWL individuals as answers to the

queries are automatically mapped to Java objects.

4.4.1 The Interaction with the OWL API

The OWL API stores information about an ontology

in two ways:

http://commons.apache.org/bcel/

AspectJ: http://www.eclipse.org/aspectj/

Java2OWL:ASystemforSynchronisingJavaandOWL

• The

OWLOntologyManager

in the OWL API it-

self has an internal representation of the ontology.

Various interface method can access this informa-

tion.

• The reasoner must of course also have an internal

representation of the ontology. Since reasoners

in different programming languages are available

(FaCT++, for example, is written in C++), the in-

formation about the ontology must be forwarded

from the

OWLOntologyManager

to the reasoner.

Changes to an ontology are therefore done in three

steps:

1. Logical axioms are created and stored in a list.

This does not yet change the ontology itself at all.

2. The

OWLOntologyManager

is asked to apply the

changes, i.e. to integrate the axioms into the on-

tology.

3. The new information is forwarded to the rea-

soner. This may either be done as soon as the

OWLOntologyManager

integrates a new axiom, or

the changes may be buffered and made effective

at a later step. In this case the ontology may

have become inconsistent before the reasoner has

a chance to check it. The

J2OOntologyManager

makes sure that whenever the reasoner is asked to

do something, the buffer is ﬁrst ﬂushed to the rea-

soner.

4.4.2 Sources of Inconsistencies in the Extension

Ontology

Inconsistency is not a relevant notion in an ordinary

programming context. Therefore it is a reasonable

question to ask where inconsistencies in Java2OWL-

managed ontologies can come from. Certain sources

of inconsistencies, which can be detected by the com-

piler, have been discussed in Sect. 4.2.1. In this sec-

tion we discuss inconsistencies which may show up at

run time.

Here are some examples for inconsistencies:

• Inconsistencies between the background ontology

and the annotations of getter methods:

In a background ontology, one might for example

specify a functional property

hasName

, and in a

Java class a getter method. An annotated getter

method may be

@J2OWLProperty(name = "hasName")

public String[] getNames() {

return names;}

where the return type is an array. This is not in-

consistent with the functionality of

hasName

long as the result of the

getNames()

-method has

just a single element. As soon as the

getNames()

method returns a longer array, it becomes incon-

sistent with the required functionality of

hasName

This is a case where a compiler could issue a

warning, but the situation may be intended and

there may be no problem at run time.

• Constraint Violations:

The annotation

@J2OWLProperty(name = "hasFriend",

atmost = 3)

public Set<Person> getFriends() {

return friends;}

speciﬁes that one can have at most three friends.

getFriends()

returns a set with more than

three friends, this contradicts the constraint

atmost = 3

4.4.3 Checking the Consistency of the Extension

Ontology

Checking for inconsistencies by the reasoner is an ex-

pensive operation. Therefore it is a strategic decision

when to check the consistency of the extension ontol-

ogy. During development and debugging it is useful

to ﬁnd inconsistencies as early as possible. To this

end, the

J2OManager

can be put into debug mode.

It causes each change to the ontology to be immedi-

ately forwarded to the

OWLOntologyManager

and to

the reasoner and to ask the reasoner to immediately

check the consistency.

If the system is not in debug mode then changes

to the ontology are buffered as long as possible.

The changes to the ontology are forwarded to the

OWLOntologyManager

and to the reasoner

• either when the reasoner is asked to compute some

information,

• or when new information overwrites old informa-

tion, and it is necessary to retrieve the old in-

formation in order to generate the corresponding

remove-axioms.

4.5 The J2OClass Manager

The class

J2OClassManager

manages the correspon-

dences between the Java classes and the OWL classes.

To this end it has two auxiliary data structures:

ClassWrapper

which stores the pair [Java Class,

OWL Class] together with information about the

mapped attributes.

PropertyWrapper

which stores the correspon-

dences between the Java getter, setter, adder,

remover and clearer methods on the one side, and

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

the corresponding OWL-property on the other

side.

If the

J2OClassManager

is asked to get for a Java

class the correspondence to the OWL class it does not

return an OWL class, but a

ClassWrapper

. From the

ClassWrapper

one can get the OWL class. The same

holds for the attributes.

4.6 The J2OIndividual Manager

The

J2OIndividualManager

manages the corre-

spondences between the Java objects and the

OWL individuals. The main purposes of the

J2OIndividualManager

are therefore

• mapping Java objects to OWL individuals and

vice versa and

• synchronising the Java object’s attributes with the

corresponding OWL properties.

The correspondences between Java objects and

OWL individuals are encapsulated in the class

IndividualWrapper

. Individual wrappers are actu-

ally the object level front end to the OWL ontology.

Each individual wrapper contains one OWL individ-

ual and, due to multi-inheritance of OWL one or more

corresponding Java objects. The most important op-

erations, an individual wrapper can perform are:

• activating/deactivating life synchronisation

• block synchronisation with OWL

• reclassiﬁcation of the Java objects,

• attaching extra attributes to the objects which are

not foreseen in the Java class deﬁnitions. These

attributes are actually attached at the OWL indi-

vidual in the OWL ontolgoy.

5 PERFORMANCE OF THE

SYSTEM

A thorough performance analysis of the Java2OWL

system is not really possible. The input are Java pro-

grams and OWL ontologies, and there is no clear out-

put which can be measured. Moreover, a signiﬁcant

part of the system is the OWL reasoner, and this is not

under control of the Java2OWL system. The com-

plexity of the OWL reasoning tasks depends on the

OWL constructs used in the application. The com-

plexity classes range from polynomial to undecidable.

Typical examples are in the PSPACE range, which

means that heuristics have an important inﬂuence on

the behaviour of the reasoners.

The few experiments whose results are listed be-

low might give a rough impression on the perfor-

mance of the various parts of the system. They have

been performed with a Java class

Student

, with at-

tributes

name

and

semester

and a subclass

Freshman

which are students in the ﬁrst semester. The classes

have been translated to OWL and then a number of

measurements have been performed.

In all experiments a sequence of lists of

Student

instances have been created, and for each list a certain

operation has been performed. The time it took to per-

form the operation on the list has been measured, and

divided by the length of the list. The resulting times

in milliseconds indicate the time it took to perform

a single operation. The lengths of the lists are 2000,

..., 10000. The measurements were done with a Dell

notebook with a 2.2 GHz dual core processor.

Java to OWL Axioms. Each

Student

has been

translated to OWL axioms, but the axioms are not

yet integrated into the ontology. The times in mil-

liseconds per operation are:

size 2000 4000 6000 8000 10000

ms 0.19 0.04 0.01 0.032 0.0055

It is not clear why the times are so different. One

effect could be the Just-in-Time compilation of

Java which after a while decides to compile the

Java methods into native machine code.

Java to OWL Indivdiduals. In this experiment the

translated Student instances are integrated as

OWL individuals into the OWL ontology. The

times in milliseconds per operation are:

size 2000 4000 6000 8000 10000

ms 0.39 0.16 0.016 0.011 0.03

Java to OWL Individuals with Consistency Test.

In this experiment the translated Student in-

stances are integrated as OWL individuals into

the OWL ontology, and each time a consistency

test is performed by the OWL reasoner. All three

reasoners are tried. The times in milliseconds per

operation are:

size 2000 4000 6000 8000 10000

FaCT++ 0.14 0.046 0.013 0.07 0.09

Pellet 0.13 0.076 0.064 0.077 0.1

HermiT 0.17 0.120 0.037 0.031 0.09

Java-OWL Synchronisation. This time the

Student

instances which have been mapped

to OWL get their semester changed to 1, and this

is forwarded to the ontology. It does not involve

OWL reasoning. The times in milliseconds per

operation are:

size 2000 4000 6000 8000 10000

ms 0.07 0.012 0.0077 0.11 0.0075

Java2OWL:ASystemforSynchronisingJavaandOWL

Querying OWL. In this experiment we take the

Student

instances whose semester had been

changed to 1, and map them to OWL individu-

als. Afterwards the OWL reasoner is asked to re-

trieve all instances of the OWL

Freshman

class.

All three reasoners are tried. The operation is

much more expensive than the previously inves-

tigated operations. Therefore only much smaller

lists of

Student

instances are tried. The times in

milliseconds per operation are:

size 200 400 600 800 1000

FaCT++ 0.455 0.187 0.167 0.22 0.18

Pellet 7.57 8.02 12.3 15.3 22.4

HermiT 5.14 10.0 17.12 27.8 37.6

For this class of examples FaCT++ is about 20

times faster than the other reasoners. Since OWL

reasoning is a heuristically controlled search there

may well be other classes of examples where the

other reasoners are faster.

OWL to Java. In this experiment the

Student

in-

stances whose semester had been changed to 1,

and which had been mapped to OWL individu-

als are deleted, and afterwards reconstructed as

Freshman

instances form the OWL individuals.

The times in milliseconds below indicate how

long it took to turn an OWL individual into a Java

object.

size 2000 4000 6000 8000 10000

ms 0.119 0.13 0.222 0.198 0.238

Reclassiﬁcation. In this experiment the

Student

in-

stances whose semester had been changed to 1 are

reclassiﬁed to

Freshman

instances. All three rea-

soners are tested. The times in milliseconds per

operation are:

size 200 400 600 800 1000

FaCT++ 1.11 0.43 0.29 0.29 0.3

HermiT 5.48 9.49 16.22 25.73 35.08

Pellet 7.58 13.13 16.36 20.05 29.24

Again, FaCT++ is much faster than the other rea-

soners.

The times vary quite a lot with the different lengths of

the lists. An important observation is, however, that

the times per operation do not depend much on the

size of the data. Sometimes the operations become

even faster with increased amounts of data.

6 SUMMARY

This paper gives a short introduction into the

Java2OWL library for synchronising Java with OWL.

A more substantial description is contained in the

technical report (Ohlbach, 2012). It can be down-

loaded from http://www.pms.iﬁ.lmu.de/Java2OWL.

From this website one can also download the library

itself, and even the whole NetBeans project.

The system has not yet been tested in a real appli-

cation. It is planned to use it for a university wide

information system. It is quite clear that real ap-

plications will require further changes to the library.

Suggestions for improvements may be E-mailed to

ohlbach@lmu.de.

REFERENCES

Baader, F., Calvanese, D., McGuinness, D., Nardi, D., and

Patel-Schneider, P. F., editors (2003). The Description

Logic Handbook: Theory, Implementation, and Appli-

cations. Cambridge University Press.

Birte Glimm et al (2010). Optimising ontology classiﬁ-

cation. In Patel-Schneider, P. F., Pan, Y., Hitzler,

P., Mika, P., Zhang, L., Pan, J. Z., Horrocks, I., and

Glimm, B., editors, Proc. of the 9th Int. Semantic

Web Conf. (ISWC 2010), volume 6496 of LNCS, pages

225–240, Shanghai, China. Springer.

Colyer, A., Clement, A., Harley, G., and Webster, M.

(2004). Eclipse AspectJ : Aspect-Oriented Program-

ming with AspectJ and the Eclipse AspectJ Develop-

ment Tools. Addison-Wesley.

Dahm, M. (1999). Byte code engineering. In Proceedings

JIT’99, pages 267–277. Springer-Verlag, Springer-

Verlag.

Horridge, M. and Bechhofer, S. (2011). The OWL API:

A Java API for OWL ontologies. Semantic Web,

2(0):11–21.

Lutz, C. (2003). Description Logics with Concrete

Domains—a survey. In Advances in Modal Logics

Volume 4. King’s College Publications.

Ohlbach, H. J. (2012). Java2OWL – a system for synchro-

nising Java and OWL. Technical Report PMS-FB-

2012-02, Institute for Informatics, University of Mu-

nich.

Sirin, E., Parsia, B., Grau, B. C., Kalyanpur, A., and Katz,

Y. (2007). Pellet: A practical OWL-DL reasoner. Web

Semantics, 5(2):51–53.

Tsarkov, D. and Horrocks, I. (2006). FaCT++ Descrip-

tion Logic reasoner: System description. In Proc. of

the Int. Joint Conf. on Automated Reasoning (IJCAR

2006), volume 4130 of Lecture Notes in Artiﬁcial In-

telligence, pages 292–297. Springer.

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment
