A New Query Suggestion Algorithm for Taxonomy-based Search Engines

Roberto Zanon

, Simone Albertini

, Moreno Carullo

and Ignazio Gallo

7Pixel S.r.l., Binasco (MI), Italy

Dipartimento di Scienze Teoriche e Applicate, University of Insubria, Varese, Italy

Keywords:

Query Suggestion, Query Log, Query Session, User Experience.

Abstract:

The objective of this work is the realization of an algorithm to provide a query suggestion feature in order

to support the search engine of a commercial web site. Starting from web server logs, our solution creates a

model analyzing the queries submitted by the users. Given a submitted query, the system searches the most

adequate queries to suggest. Our method implements an already known session based proposal enriching it

by exploiting speciﬁc information available in the current context: the category the user is browsing on the

web site and a solution to overcome the limits of a pure session based approach considering also similarity

between queries. Quantitative and qualitative experiments show that the proposed model is suitable in terms

of resources employed and user’s satisfaction degree.

1 INTRODUCTION

Search engines have assumed increasing importance

for the Internet users, becoming the main point of ref-

erence to access any other service or information on

the web. The users expect that these research systems

would provide increasing assistance and simplicity al-

lowing the user to reach his goal. For this reason all

the main search engines are going to introduce addi-

tional services in order to support the user such as,

automatic correction of the query, the suggestion of

related queries and the suggestion of related multime-

dia content.

Several research ﬁelds related to the study of the

user behavior grew, starting from the query analysis

(Mat-Hassan M., 2005), the classiﬁcation of particu-

lar types of queries (Ortiz-Cordova A., 2012) to the

deﬁnition of similarity and correlation relations, and

so on. This is a difﬁcult problem, because the queries

contain unstructured data; thus, they often are very

short or equivocal for a direct use. For example, in

an online store we can exploit the navigation path fol-

lowed by an user in order to infer its interests and to

enhance its experience providing suggestions that can

be used for presenting products the user may be inter-

ested in. With query suggestion we mean the task of

proposing a set of different possible alternative search

texts to a user who submitted a query, so that they

could help him reaching what he is looking for.

The ﬁeld of Web Usage Mining studies techniques

for gathering information to proﬁle the users, for ex-

ample analyzing the web server log and the applica-

tion level data for each user session (Srivastava and

Cooley, 2000; Pierrakos et al., 2003). Such infor-

mation allows to create algorithms able to predict the

need and the desires of users just analyzing their be-

havior and trying to reduce that information to an al-

ready known behavior pattern.

The objective of this work is the realization of

an algorithm for providing a query suggestion fea-

ture in order to support the search engine of a com-

mercial web site (Shoppydoo, 2012). The system de-

sign is based on models already proposed by the lit-

erature (Boldi et al., 2008; Cao et al., 2008). From

the literature we notice that there are two main ap-

proaches: document-based (Baeza-yates et al., 2004)

and session-based (Boldi et al., 2008). The ﬁrst ap-

proach exploits the URLs the user clicks after hav-

ing subtimmed a query while the other is based on

the consecutiveness of the queries submitted within

each user session. The most studied and promising

approach for developing a query suggestion system

is the session based one (M.P. Kato, 2011). This ap-

proach states that when a user types a query q, then

the system should suggest the queries that previous

users submitted after having typed the same query

q. This method is justiﬁed by the behavior of the

users: when the ﬁrst query they submit do not lead to

the expected results, they tend to restate it following

well known logical schemes like ”reformulation for

generalization“, ”reformulation for specialization“ or

”equivalent reformulation“ (Boldi et al., 2009).

151

Zanon R., Albertini S., Carullo M. and Gallo I..

A New Query Suggestion Algorithm for Taxonomy-based Search Engines.

DOI: 10.5220/0004108001510156

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2012), pages 151-156

ISBN: 978-989-8565-29-7

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Another aspect a query suggestion system could

follow is the exploitation of the context the user is ac-

tually browsing. So it is possible to classify the sys-

tems in context aware, like (Cao et al., 2008), and non

context aware. We can also say an algorithm is in-

cremental or non incremental, depending on whether

it modiﬁes its internal structure as it is given a new

query or it has a ﬁxed set-up and may be only queried

(Broccolo et al., 2010).

2 PROPOSED METHOD

Each query suggestion algorithm is composed by two

main modules: a background module which holds

and manages the data structures and an online process

which provides the suggestions to the front end ap-

plication and makes use of the underlying data struc-

tures.

Starting from the web server logs, the proposed

solution creates the ﬁrst module in the following man-

ner:

1. Pre-processing. It parses the web server logs in

order to extract the queries and the related infor-

mation.

2. Creation of the sessions. A set of sessions is built,

that is a set of lists of queries performed by the

same user within a certain amount of time.

3. Construction of the model. The algorithm builds

the data structures for representing the sessions

in order to efﬁciently mine all the information

needed for the suggestions.

4. Pruning of the data structures. The algorithm

must reduce the dimension of the data structures.

The second module of the algorithm inspects the

data structures previously generated applying a rank-

ing function, returning the suggested queries given a

query q.

(Baeza-yates, 2007) presents an analysis of the

processes that could be used to generate the data

model which represents the queries and their rela-

tions. In the proposed work we followed an approach

inspired by the word graph and session graph. The

development took into account that the system must

be generic in order to have the possibility to use it also

in other websites but, on the other hand, as much spe-

ciﬁc as we can to exploit all the available information

from the available query logs.

The proposed solution is inspired by (Boldi et al.,

2008) but with some important differences. The ﬁrst

difference is that we are in a context where the objects

to query are grouped into categories: the goal is to

provide a query suggestion system for a website that

lists commercial products sold by several merchants.

So we have an implicit taxonomy and it is possible

to exploit additional information considering the user

is given the possibility to select a category to browse

within and to submit queries for only that category.

The category information is optional but it is a power-

ful tip for the system in order to select the suggested

queries: it allows our algorithm to distinguish queries

that would be syntactically indistinguishable. How-

ever, the concept of categories is also present in ﬁelds

different from the price comparison: for example, a

similar information is exploited by Yahoo! directo-

ries

. Another important difference is that, in addi-

tion to suggest the queries that belongs to the subtree

which starts with the given query, it selects also the

queries that follow the queries with the search string

similar to the input search text. The similarity among

strings is not usually considered sufﬁcient because of

the short length and ambiguity of the queries: anyway

in this setting it is possible to adopt this approach be-

cause the majority of the queries is associated with a

category known in advance, which gives a semantic

contribution to the process.

Following the classiﬁcation given by (Broccolo

et al., 2010), we can consider our algorithm as

an incremental session-based non context-aware ap-

proach.

2.1 Creation of the Sessions

The process starts analyzing the log ﬁles from the web

server. The ﬁelds that are considered when ﬁltering

the log are the query string and the category id, ex-

tracted from the URL parameters; the user id if avail-

able or the IP address; the timestamp. Log entries

different from searches or originated by bots are not

considered.

A logical session is a sequence of queries with the

same user id and where for each pair of queries, they

were submitted not far more than thirty minutes.

Our system exploits the session information in or-

der to create a query graph which models the con-

secutiveness relation of the queries with, in addition,

another graph on the same set of queries which mod-

els the similarity among the search texts. An index is

mainteined in order to provide fast access to the nodes

of the graph.

2.2 Creation of the Query Graph and

the Index

The query graph is similar to the query ﬂow graph

http://dir.yahoo.com/

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

152

Algorithm 1: Building of the query graph and the indexes.

Require: set of sessions

Ensure: query index I

and category index I

← new HashTable {query index}

← new HashTable {category index}

for all session ∈ sessions do

for all consecutive couples of queries (q

, q

) ∈ session do

query node ← add or get node if already exists from I

given

(h(q

), q

)

add next node q

to query node

← I

(h(q

.category)) if exists or a new hashTable

for all term ∈ q

.search text do

add (term, q

) to I

if the entry don’t exists

end for

return I

, I

presented in (Boldi et al., 2008). It is represented by

an adjacency list, where each node is a unique cou-

ple <category, query string>. Two nodes are linked

by an edge if the two queries appear at least in a ses-

sion consecutively and the weight on the edges are

integer values which mean the number of times the

two queries appear consecutively in a session. An

hash table is used in order to efﬁciently access the list,

with a hash function on the couples <category, query

string> as key. The indexes allows to trace back to a

node of the graph starting from the couple <category,

term>, where term is a word of the query. It is re-

alized using two hash tables: a category hash table

where the key is a function on the category id and

the value is another hash table nested in the ﬁrst one.

This is a hash table of terms where the values are sets

of queries which contains that term.

Algorithm 1 shows the pseudocode of the proce-

dure for building the indexes and the query graph. It

takes linear time in the number of the queries. Con-

cerning this, we can notice that all the operations on

the hash tables with the hash function h need constant

time and the inner loop on the terms in the search text

can be assumed upper bounded because, as we can see

in section 3, the average number of terms per query is

2 and in the 99% of the queries, they contain less than

6 terms.

After having constructed the graph, it is recom-

mended to prune it removing all the edges which have

a low weight or the nodes with a small amount of oc-

currences for essentially two reasons: it should re-

move useless information that could undermine the

quality of the results and for performance issues as

logs always grow, so will do the data structures.

2.3 Creation of the Similarity Graph

A typical problem encountered by session based sys-

Algorithm 2: Search for similar queries.

Require: input query q, number of queries to return k, category index I

Ensure: list of similar queries similar

← I

[category(q)] {term index for the category}

similar

←

for all term ∈ terms(q) do

if I

contains term then

append all the queries from I

[h(term)] to similar

end if

end for

sort similar

by similarity with q.

return the ﬁrst k queries in similar

tems, which exploits query logs, is the high percent-

age of single queries or couples of queries that are

present together in the logs.

The problem of the sparsity of the queries

emerges: given an input query, it is likely that the sys-

tem will have few or no information about it. This

is a typical issue of session based systems which ex-

ploits the query logs. In order to solve it the proposed

algorithm also takes into account the similar queries

already processed by the system. We say two queries

are similar if they belong to the same category and

have a similar search text. In order to measure the

similarity between search texts the algorithm makes

use of the Jaccard similarity coefﬁcient (Tan et al.,

2005) on the set of words of the search text, not con-

sidering the stopwords.

The procedure for computing the similarity mea-

sure is shown in Algorithm 2. It obtains the term

hash table I

for the category associated with the input

query q and, for each term in the query, it adds the

set of queries having this term to the set of all similar

queries. Then, this list similar

is sorted by similarity

in respect to the input query calculating the Jaccard

similarity measure. Finally the algorithm returns the

ﬁrst k queries in that list. The complexity of this algo-

rithm depends on the number of similar queries N

. It

needs O(N

· log(N

)) as it is the time for sorting the

similar queries.

In order to avoid running the Algorithm 2 for each

input query in the online phase, the system build a

graph on the same set of nodes of the query graph

deﬁning new non oriented edges which represents the

similarity relations among queries. This is very close

to the index adopted by (Cao et al., 2008) for ﬁnd-

ing the queries given a query represented as a vec-

tor in the selected url space. It allows to look for

the queries similar to the input search text when it is

already present in the graph: this situation happens

about half the time. Deﬁning N

as the number of

nodes in the graph (after the pruning) and N

the aver-

age number of similar queries per query, the similarity

graph building process takes O(N

· N

· log(N

)).

ANewQuerySuggestionAlgorithmforTaxonomy-basedSearchEngines

153

Algorithm 3: Search for related queries.

Require: input query q, max number of recommended queries m, query and

category indexes I

, I

Ensure: set of queries related

if I

contains q then

similar ← similar queries for I

[q]

else

similar = f ind similar(I

, q, k) {Algorithm 2}

end if

for all q

∈ similar do

related ← related ∪ next queries of q

end for

sort related by the ranking function r

return the ﬁrst m entries in related

2.4 Online Query Suggestion

Algorithm 3 shows how the online phase works.

Given an input query q it acts as follow.

1. Search for the queries similar to q. The algorithm

looks for the node

in the query graph, either if

it exists or not. If it exists, the algorithm selects

the queries in the children nodes of

2. It selects all the nodes

which represent a the

queries similar to q, following the edge of the

similarity graph. It selects the queries from the

nodes next to

and add them to a set as candi-

date queries for the suggestion.

3. The set of candidate queries is ordered by a rank-

ing function r and the ﬁrst m queries are returned.

The adopted ranking function sums the normal-

ized weights of the link in the similarity graph and

the weight on the link in the query graph that al-

lowed to get to it. In case of equality, the queries

are ordered by the number of occurrences in the

query logs.

In the worst case the complexity of Algorithm 3 de-

pends on the call to Algorithm 2, that is f ind similar

in the listing. This call takes O(N

· log(N

)). The

number of queries related can be considered constant

as it is k · N

, where N

is the number of subsequent

nodes for a node in the query graph and k is the max-

imum number of similar queries for each node. Since

the graph is sparse, N

can be considered constant, so

the time for ordering the queries in the related set is

constant too.

3 EXPERIMENTS

An evaluation conducted on two datasets with dif-

ferent characteristics is fundamental for verifying the

generic nature of the proposed system. The two

datasets have the following differences:

1. Number of queries per day. Shoppydoo has about

200.000 queries per day, while Trovaprezzi about

one million.

2. Typologies of queries. The users of Shoppydoo

are usually more specialized, so the queries are

more focused into some categories and they are

more correct and precise. On the other hand,

Trovaprezzi is for the most used by inexperienced

users, so the queries are more equally distributed

among several categories. Anyway, these queries

are sometimes “wrong” as they contain words

with no meaning or lead to no results.

3. Session identiﬁer. On Shoppydoo the users are

identiﬁed by IP address, while on Trovaprezzi by

HTTP session ID. In the ﬁrst case it is more dif-

ﬁcult to obtain accurate user sessions because the

queries from the same IP can be from several dif-

ferent users.

4. Length of the sessions. On Shoppydoo, a ses-

sion last 2,5 queries in average, while 3 queries

on Trovaprezzi.

For all the experiments we used a system with 2,4Ghz

32 bit CPU with 4Gb of RAM.

By analyzing the logs we noticed that about the

50% of the queries has a search text which appears

only once, while the 6% appears two times. The

amount of queries that are unique or that have few oc-

currences justiﬁes the employment of methods to ﬁnd

similar queries in order to compute the suggestions.

The queries are very short and tend to be com-

posed by two words. The 99% of all the queries

have less then 6 words. This characteristic allowed us

to consider constant the number of words per query

while presenting the algorithms in Section 2.

In order to analyze the complexity of the algo-

rithm we considered a collection of queries that goes

from the queries submitted in a day to the set of

queries submitted within eight days for Shoppydoo

(240k to 1,8m queries), and a set of queries up to two

days for Trovaprezzi (up to 2,4m queries).

3.1 Temporal Complexity

Figure 1 shows the time needed for building the query

graph and for pruning it. In this experiment we choose

to eliminate the links in the query graph that have uni-

tary weight, that is the links between queries appear

as consecutive in the sessions only once. The same

graph shows the time necessary to create the similar-

ity graph. The maximum number of links per node is

set to 16, that is the double of the number of suggested

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

154

100

150

200

250

300

0 500 1000 1500 2000 2500

Seconds

Thousands of queries

Shoppydoo QG

Trovaprezzi QG

Shoppydoo SG

Trovaprezzi SG

Figure 1: Time needed to build the query graph (QG) along

with the indexes for the two datasets and the time needed

for the similarity graph (SG) on both the datasets.

0.0000

0.0010

0.0020

0.0030

0.0040

0.0050

0.0060

0.0070

0.0080

0 500 1000 1500 2000 2500

Seconds

Thousands of queries

Shoppydoo

Trovaprezzi

Figure 2: Online time necessary to generate the suggestions

varying the number of analyzed queries.

queries the online phase would return in a reasonable

setup.

Finally, in Figure 2 we can see the average time taken

by the online phase. This value has been calculated

using 500 different queries that do not belongs to the

set of queries used to build the underlying model.

Even if we built the graph with an increased number

of queries it would be possible to maintain constant

this times with a pruning or with a simpliﬁcation of

Algorithm 2 used to ﬁnd the similar queries, for ex-

ample modifying it to look for them only in the simi-

larity graph and not searching for the similar queries

if we do not ﬁnd the entry in the query index as re-

ported in Algorithm 3.

3.2 Quality Evaluation

In order to evaluate the results of the query suggestion

algorithm we adopted two metrics similar to what it

is possible to ﬁnd in literature: the coverage, which

indicates for how many input queries the algorithm

returns at least a minimum amount of suggestions,

and the quality, which denotes how many suggestions

which are useful to the user we obtain. It was not pos-

sible to confront the proposed solution with the eval-

0 500 1000 1500 2000 2500

Thousands of queries

Shoppydoo

Trovaprezzi

Figure 3: Coverage as the number of queries increases.

uations available in literature because we do not use

a unique dataset. Thus, we chose to use different pa-

rameters for the evaluation for example the number of

required suggestions in order to consider the results

satisfactory, or which input query to employ in the

quality tests. Regarding this last issue, our tests use

random queries taken from the set of all the queries

available from the web server log and do not select,

for example, the most frequent ones.

For the evaluation of the coverage we used 500

queries selected randomly from the logs. A set of

suggested queries is considered sufﬁcient if it con-

tains at least eight suggestions. We chose this num-

ber because the main search engines display a number

of suggestions close to the chosen one. For instance,

Google and Bing display eight suggestions while Ya-

hoo from three up to ten.

The employed hardware for the following evalua-

tions is the same described in the header of this sec-

tion with, in addition, a 64 bit Intel Xeon 2,66Ghz

system with 8Gb of RAM used to perform the ofﬂine

phase, that is the building of the data structures.

The experiments conducted led to the results pre-

sented in Figure 3. Another experiment was run using

the queries for ﬁve days from Trovaprezzi, reaching a

coverage of 37,2%.

In the end, we evaluate the quality of the queries

that are suggested by the proposed algorithm. The

evaluation is performed by humans using a web ap-

plication designed for this purpose. The user who

utilizes the application is asked if he considers the

suggestions related to the original query he submit-

ted or not. Thirty people were involved in this task

and we collected about 150 opinions. The 70,1% of

these expressed a positive judgment about the corre-

lation of the suggested queries with the original one

and its usefulness.

The underlying model was built using ﬁve days of

queries from the log of Trovaprezzi, that is about 6

million queries.

The proposed system returns bad results espe-

ANewQuerySuggestionAlgorithmforTaxonomy-basedSearchEngines

155

cially if it is given long and inaccurate queries. As the

length of the query increase, the system is not able to

ﬁnd equal or at least very similar queries in the graph,

so the suggested queries are too generic in respect to

the original intent of the user or they lacks of correla-

tion.

Taking a look to the queries that led to good sug-

gestions, we noticed they are manly speciﬁc product

names, product types and brands. For this kind of

queries the system is able to reformulate the search

texts for specialization, equivalent reformulation and

parallel movement.

The web application devised to evaluate the qual-

ity has also been employed for measuring the re-

sponse times of the query suggestion system, logging

the time taken for generating the page with the sug-

gestions. The average time has been 0,0059 seconds,

which allows to employ the system in an online real

time environment.

4 CONCLUSIONS

The initial objective was the realization of a solution

in order to enhance the search feature in an web ap-

plication for price comparison implementing a query

suggestion system. We realized a system that could

take advantage from all the available data about the

queries submitted to the web sites, while keeping a

generic approach as much as possible, in order to al-

low the proposed solution to be applicable even on

different search engines.

The implemented system is considered satisfac-

tory in respect to the requirements we had set. This

is conﬁrmed by the experiments where, given 6 mil-

lions queries from a web site logs, the users consider

the suggestions good, measuring a quality of 70% and

a coverage of 37%, which are the queries which lead

to at least eight suggestions.

Thus the performance are good, as the system in

the online phase need about 1,3Gb of memory and it

responds with a latency less then one hundredth of

second.

The most promising possible future developments

involve two aspects of the system. Firstly, the im-

provement of the ranking function, adding more pa-

rameters to consider clicks and relations among sug-

gested queries and click-through rates, thus consider-

ing a linear combination of more factors rather than

just adding the normalized weights from the graphs.

Secondly, the deﬁnition of different similarity mea-

sures in place of the Jaccard index.

REFERENCES

Baeza-yates, R. A. (2007). Graphs from Search Engine

Queries.

Baeza-yates, R. A., Hurtado, C. A., and Mendoza, M.

(2004). Query Recommendation Using Query Logs

in Search Engines.

Boldi, P., Bonchi, F., Castillo, C., Donato, D., Gionis, A.,

and Vigna, S. (2008). The query-ﬂow graph: model

and applications. In International Conference on In-

formation and Knowledge Management, pages 609–

618.

Boldi, P., Bonchi, F., Castillo, C., and Vigna, S. (2009).

From ”dango” to ”japanese cakes”: Query reformula-

tion models and patterns. In Web Intelligence, pages

183–190.

Broccolo, D., Frieder, O., Nardini, F. M., Perego, R., and

Silvestri, F. (2010). Incremental Algorithms for Effec-

tive and Efﬁcient Query Recommendation.

Cao, H., Jiang, D., Pei, J., He, Q., Liao, Z., Chen, E., and Li,

H. (2008). Context-aware query suggestion by mining

click-through and session data. In Knowledge Discov-

ery and Data Mining, pages 875–883.

Mat-Hassan M., L. M. (2005). Associating search and nav-

igation behavior through log analysis. Journal of the

American Society for Information Science and Tech-

nology, 56(9):913–934.

M.P. Kato, T. Sakai, K. T. (2011). Query session data vs.

clickthrough data as query suggestion resources. In

ECIR 2011 Workshop on Information Retrieval Over

Query Sessions.

Ortiz-Cordova A., J. B. (2012). Classifying web search

queries to identify high revenue generating customers.

Journal of the American Society for Information Sci-

ence and Technology. cited By (since 1996) 0; Article

in Press.

Pierrakos, D., Paliouras, G., Papatheodorou, C., and Spy-

ropoulos, C. D. (2003). Web usage mining as a

tool for personalization: A survey. User Mod-

eling and User-Adapted Interaction, 13:311–372.

10.1023/A:1026238916441.

Shoppydoo (2012). http://www.shoppydoo.it.

Srivastava, J. and Cooley, R. (2000). Web usage mining:

Discovery and applications of usage patterns from

web data. SIGKDD Explorations, 1:12–23.

Tan, P.-N., Steinbach, M., and Kumar, V. (2005). Introduc-

tion to Data Mining. Addison Wesley.

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

156
