A Data-Centric Approach for Networking Applications

Ahmad Ahmad-Kassem

, Christophe Bobineau

, Christine Collet

, Etienne Dublé

Stéphane Grumbach

, Fuda Ma

, Lourdes Martinez

and Stéphane Ubéda

INRIA, INSA-Lyon, Villeurbanne, France

Grenoble Institute of Technology, Grenoble, France

CNRS, Grenoble, France

INRIA, Villeurbanne, France

Keywords: Declarative Networking, Programming Abstraction, Case-based Distributed Query Optimization.

Abstract: The paper introduces our vision for rapid prototyping of heterogeneous and distributed applications. It

abstracts a network as a large distributed database providing a unified view of "objects" handled in networks

and applications. The applications interact through declarative queries including declarative networking

programs (e.g. routing) and/or specific data-oriented distributed algorithms (e.g. distributed join). Case-

Based Reasoning is used for optimization of distributed queries by learning when there is no prior

knowledge on queried data sources and no related metadata such as data statistics.

1 INTRODUCTION

The trend towards complex distributed applications

is accelerated with wireless networking technologies

interconnecting an increasing number of

heterogeneous devices (mobile and wearable, energy

constrained, personalized), which generate large

amounts of data. Devices usually take part in

dedicated ad hoc networks, where applications

deployment, configuration and management are

tedious and require significant human involvement

and expert knowledge. To improve the application

programming there is a need for high-level

programming abstraction

Demonstration of portability, extensibility,

integration and pervasive adaptation have been done

with variants of the Datalog rule-based language

applied to express communication algorithms and

declarative overlays through queries (Loo et al.

2006; Condie et al., 2008; Chen et al., 2010).

Several systems, such as TinyDB (Madden et al.,

2005) or Cougar (Demers et al., 2003) sensor

network systems, use the relational model to

represent device features and application data and

offer SQL-like languages to manage data

application. These systems also offer solutions to

perform efficient data dissemination and query

processing (centralized but also distributed).

Our vision – materialized in the UBIQUEST

system -- is to go a step further than the promising

declarative networking approach providing a unified

view of "objects" handled in networks and

applications. The environment is perceived as a

distributed database and the applications interact

through declarative queries (Loo et al., 2006; Mao,

2010). However, some necessary adaptations have to

be made: (i) to localize data or define the scope of a

query, (ii) to consume, filter and aggregate data

(continuous queries), (iii) to consider query

operators that may correspond to protocols, (iv) to

revisit query optimization. For this later aspect we

propose to use Case-Based Reasoning (CBR) –

providing a way to optimize queries when there is no

prior knowledge on queried data sources and

certainly no related metadata such as data statistics.

This approach is well adapted to social systems (e.g.

games, social networks), where data is pushed or

pulled with incomplete knowledge in a dynamic

environment.

The paper is organized as follows. Section 2

gives an overview of our approach and Section 3

presents its key elements. Section 4 gives a general

presentation of the UBIQUEST system. Section 5

concludes the paper.

147

Ahmad-Kassem A., Bobineau C., Collet C., Dublé E., Grumbach S., Ma F., Martinez L. and Ubéda S..

A Data-Centric Approach for Networking Applications.

DOI: 10.5220/0004111301470152

In Proceedings of the International Conference on Data Technologies and Applications (DATA-2012), pages 147-152

ISBN: 978-989-8565-18-1

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

2 DATA-CENTRIC APPROACH

The declarative approach is used to abstract the

network as a large distributed database providing

unified view of "objects" handled by both the

networks and applications. Such a database stores

information about the declarative programs, routers

configuration, states and characteristics of the

network. Rule-based programs correspond to

network operations or protocols triggered by data

updates. Rules are evaluated over local data and may

communicate results to other nodes in the network

using communication primitives.

The UBIQUEST approach we propose merges

the strengths of two areas (i) databases, and (ii)

declarative networking. With this approach a

programmer can specify the behavior of the system /

application (the what) rather than having to describe

the details of the system (the how). This allows

going one step further in the overlapping approaches

for example with destinations of messages resulting

of a query.

Figure 1: The UBIQUEST approach.

An UBIQUEST system runs on a set of

computing devices interconnected through a wireless

network (Figure 1). Every device embeds a virtual

machine in charge of data management, processing

queries (data selection and updates) and messages

propagation. The UBIQUEST virtual machine (VM)

(see Figure 2) is composed of:

 a Local Data Manager System (DMS) to manage

application data, network data and additional

information for distributed query evaluation,

 an UBIQUEST Engine to efficiently process

queries and rule programs,

 APIs and Communication modules to exchange

queries and data between nodes.

Figure 2: UBIQUEST node components.

All exchanges between nodes related to

communication protocols, to resource discovery or

to any other applicative aspects are carried out by

queries and data. This blurs the traditional

distinction between communication and application

layers. Queries are defined using either rule-based

languages for network data query expressions or

declarative query languages for querying application

data with a global point of view. Query optimization

is based on a CBR-based approach and pseudo-

random query plan generation. The CBR paradigm

means that we learn the cost of query plans (case)

while executing them. These cases are used for

generating plans for further similar queries. If there

is no convenient case, we use classical heuristics and

random choice (e.g. when there is no statistics for

join ordering and selection of algorithms).

To illustrate our approach, let us consider an

application concerning a virtual world game divided

in areas and having some avatars that are located

within a single area at a time (see Figure 3). Each

node of an UBIQUEST system has information on

its own avatars and their neighbors (avatars located

in the same area). Such information is stored in an

Itemset data structure of type:

Positions(Avatar avatar{key}, Int Area, NodeID

owner)

Figure 3: Application scenario.

DATA 2012 - International Conference on Data Technologies and Applications

148

For example, at node D the Position table (see

Table 1) has two tuples showing that it is the owner

of the Grey avatar that is in the area 2; also the Blue

avatar is in the same area but owned by node I.

Table 1: Positions table at node D.

Such a Positions table is actually a fragment of a

virtual table that maintains the information on all the

avatars, giving for each of them, the area in which it

is and its owner node. Table 2 gives the virtual

global Positions table for our application example.

Table 2: Global Positions table.

Considering this global view, the query to select

all avatars in the virtual world and the zone where

they are located is: SELECT Area, Avatar

FROM Positions;

This query will be executed globally.

Let us assume now that the Yellow avatar, owned

by node G, is moved from area 7 (where avatar

Green owned by node J is localized) to area 8 where

the Red avatar (node E) is localized. Table 3 shows

the Positions table after this operation.

Table 3: Global Positions table after modification.

The movement is coded by several updates

executed at node G (owner of Yellow) for cleaning

area 7, changing the Area attributes of the avatar and

finally for storing the new area exploration. The

update for cleaning the area 7 is:

Delete from Positions

Where Area = (LOCAL Select Area

from Positions

where Avatar = 'Yellow')

and Area not in (LOCAL Select Area

from Positions

where Avatar <> 'Yellow'

and Owner = SELF)

Stored on SELF;

The keyword LOCAL indicates that the query

has to be evaluated by the node over local data only.

The sub-queries are local and the delete operation

too as it concerns only data stored on SELF. Such a

query is executed at the node level and processed in

a distributed way with the following principles:

1. No centralized control. Query processing is

performed in an environment that is highly

dynamic, and has to adapt to and recover from

the network evolution. The control needs to be

fully distributed over the network.

2. Scarce metadata. The network being highly

dynamic, there is no stable knowledge on the

data organization. Resource discovery is

combined with networking protocols.

3. Everything in the database. The network

management is done through queries.

To conclude there is a need for adapting query

expression and execution to network condition,

application needs and query load.

3 DATA STRUCTURES

AND LANGUAGES

Network and application data in UBIQUEST are

Itemsets (cf. Section 3.1). Data distribution is

discussed in Section 3.2 and nodes exchanged

messages in Section 3.3. Section 3.4 describes the

rule-based languages for writing programs that are

installed on each node, where they run concurrently.

Finally, Section 3.5 presents the SQL-like query

language for describing queries or updates.

3.1 Items and Itemsets

The item is the unit of data manipulation: rules (in

programs) are evaluated for each new item (new

fact), and a query is processed item by item

following the classical iterator model. An Item is

composed of a set of attribute/value couples, values

are taken in predefined data types including integer,

float, string, date and NodeId (node identifier type).

The predefined attribute LocalID value (of type

NodeId) is the identifier of the current node.

An Itemset is a set defined by a name and the

structure shared by its items, i.e. a set of attributes

(name, type). Key attributes are used to identify one

specific item. An example of Itemset is the Positions

table in our application example.

3.2 Data Distribution

UBIQUEST supports only horizontal fragmentation

A Data-Centric Approach for Networking Applications

149

of Itemsets. This means that a global Itemset is

distributed over several (maybe all) UBIQUEST

nodes. Any participant node stores a (local) Itemset

or a fragment with the same schema as the global

one. Each item of the global Itemset is actually

stored in one or more nodes. Data distribution is

application-driven: applications decide on which

node(s) items have to be stored. This is possible

using either rule-based programs or DLAQL updates

(see Sections 3.4 and 3.5).

3.3 Message Structure

A message is the unit of communication among

nodes. A message has two main parts: (i) a

networking information and (ii) a payload where the

content of the message (i.e. queries or items) is

embedded. The networking information may contain

a logical destination of the message defined as a

query.

The payload has three parts: (i) A tag identifying

the type of content (e.g. declarative query, query

results, facts); (ii) A ContentId identifying in a

unique way the content; (iii) The Content itself:

declarative queries or data (query results or facts).

3.4 Rule Languages

The proposed rule-based languages (Netlog and

Questlog) extend Datalog with communication

primitives, as well as aggregation and non-

deterministic constructs standard in network

applications. The computation of rule programs is

distributed and the facts deduced can be either stored

locally on an UBIQUEST node on which the rules

run, or sent to other nodes.

3.4.1 Netlog

Netlog (Grumbach and Wang 2010) programs are

sets of recursive rules of the form head:-body, where

the head is derived when the body is satisfied. Rules

are evaluated in forward chaining and are triggered

by insertion of new items in the database. The

execution of rules may lead to transmission of items

to neighboring node(s). For example, the following

Netlog rules that are deployed on all nodes, compute

all routes in the network:



Route(SELF, dest, dest, 1):- Link(SELF, dest).



Route(self, dest, neigh, l2):- Link(SELF, neigh),

Route(neigh, dest, _, l1), l2 := l1 + 1.

The first rule computes trivial routes to

neighbors, stores them locally on the relation

Route(Self, destination, nextHop, numberOfHop),

and broadcasts them to neighbors. When received by

neighbors, the second rule is satisfied and new

routes with an increasing number of hops is

deduced, stored locally, and broadcasted to

neighbors. This process continues recursively until

getting a fix-point where no new route is obtained.

3.4.2 Questlog

Questlog programs are also sets of recursive rules

but evaluated in backward chaining to answer

queries coming from a local application or a distant

node. The execution may lead to a sub-query

emission to neighboring node(s), and may imply the

return of items as the result of queries.

For example, the following two rules can be used

to compute (on demand) routes between node orig

and dest; nh and l being free variables.

route(@orig, dest, dest, 1)  link(orig, dest).

If the destination is a neighbour, then the body is

satisfied, that results in a route stored locally and

sent back to the origin node of the query.

route(@orig, dest, nh, l+1)  link(orig,

dest); link(orig, nh); ?route(@nh, dest, _, l).

This rule is applied when the destination is not a

neighbor of the node “orig” (

Ølink(orig, dest)). The

rule sends a sub-query to all neighbouring nodes to

ask them if they know a route to the destination

(Link(orig, nh), ?Route(@nh, dest, _, l)). The @

operator ahead of a variable represents the node

where the sub-query will be sent. When a sub-query

returns a result, the second rule is applied

recursively to propagate the result to the origin node.

3.5 Data Location Aware Query

Language

The Data Location Aware Query Language

(DLAQL) extends the well-known SQL2 data

manipulation language to conform to the data

distribution policy of UBIQUEST. This means that a

DLAQL expression may explicitly indicate on

which UBIQUEST node data has to be stored.

3.5.1 DLAQL as a Subset of SQL2

With DLAQL, one can express classical SELECT-

FROM-WHERE queries using nested sub-queries,

aggregation functions, arithmetic expressions, and

selection, join and union operations. However,

SELECT expressions in DLAQL cannot use: group

by/having clauses, nested queries except in the

WHERE clause, synchronous sub-queries, and

DATA 2012 - International Conference on Data Technologies and Applications

150

EXISTS and UNIQUE condition operators.

3.5.2 Scope of DLAQL Queries

A DLAQL expression is defined considering a global

schema of Itemsets. It is evaluated considering the

value of the Itemsets (union of the fragments). The

LOCAL clause can be used to indicate that only local

data has to be used to evaluate conditions (WHERE

clause). Furthermore, if LOCAL is used with update

queries, modifications are applied on local Itemset

fragments only. For example, the following query

updates only local avatars of the Positions Itemset

that are located in Area number 5.

LOCAL UPDATE Positions SET …

WHERE Area = 5;

3.5.3 DLAQL and Data Locality

The STORE ON clause can be used in INSERT /

DELETE / UPDATE query expressions to indicate

where the data has to be inserted, or where is the

deleted or updated data. The clause specifies a list of

node identifiers that are explicitly given (values of

type NodeIds) or calculated as the result of a query.

For example, the following DLAQL query

inserts the new item (‘MyAvatar’, 5, SELF) in the

Positions Itemset stored at the local node SELF (the

current node where the query is executed) and in the

Positions Itemset of any node owning an avatar in

the area number 5.

INSERT INTO Positions

VALUES (‘MyAvatar’, 5, SELF)

STORE ON SELF, (SELECT Owner FROM

Positions WHERE Area = 5);

4 THE UBIQUEST SYSTEM

An UBIQUEST node is a device equipped with an

UBIQUEST Virtual Machine (UBIQUEST VM)

complemented with a Device wrapper that allows

device/VM interaction. The UBIQUEST VM is

composed of: (i) a Local DMS, (ii) an UBIQUEST

API, and (iii) an UBIQUEST Engine responsible of

efficient execution of UBIQUEST programs/queries.

4.1 Local DMS

The Local DMS stores and manages data as

Itemsets: application data (e.g. sensed data), network

data (e.g. routing tables, neighbor table), rule-

programs (e.g. distributed algorithms that can be

dynamically loaded/removed to/from the system),

and internal data (e.g. device specific data) used for

running other UBIQUEST VM components.

Figure 4: UBIQUEST node components.

4.2 UBIQUEST API

The UBIQUEST API manages all interactions

between the UBIQUEST Engines and the rest of the

world: local applications, device sensors and other

UBIQUEST VM through message exchange

As shown in Figure 4, the API is composed of:

(I) the Application API, in charge of the interaction

with applications running on the local node, (ii) the

Reception and Emission modules to deal with

message exchange among UBIQUEST nodes, (iii)

the Sensing API that locally stores data coming from

sensors embedded in the physical device, and (iv)

the Payload Dispatcher, which manages Payload

exchange among UBIQUEST VM sub-components

according to their Tag.

4.3 Distributed Query Engine

The Distributed Query Engine evaluates DLAQL

queries. It is composed of: (i) a Query Scheduler, (ii)

a Query Optimizer and (iii) an Execution Engine.

The Query Scheduler rewrites a global query into a

set of sub-queries and schedules their evaluation

(e.g. an update global query is decomposed into a

sequence of select, delete and insert sub-queries to

read the old value, delete it and inserting the new

value). Moreover, this module rewrites a query

considering local and distant Itemset fragments

generating a query (or set of queries) equivalent to

the original one.

The Query Optimizer is based on the Case-Based

Reasoning (CBR) machine learning approach

(Stillger, Lohman, Markl and Kandil, 2001). It

retrieves and adapts query plans using the

experiences gained from the execution of past

similar queries. When no knowledge is available it

randomly generates query plans using classical

heuristics (Ioannidis 1996). Query plans are trees

A Data-Centric Approach for Networking Applications

151

with computation operators, classical data access

operators or rule-based program invocations.

The Execution Engine executes a query plan P

using the well-known Iterator model (Graefe 1993)

for the physical operators. It also coordinates the

local and distant sub-queries and constructs a final

result from sub-query results. During the execution,

the cost parameters (energy, time, memory etc.) are

measured and a new case is built.

4.4 Rule Program Engine

The Program Engine receives payloads from the

Payload Dispatcher and has to treat their Contents

containing items (new facts or query results) or

predicates corresponding to a query.

If a Content contains new facts, the Program

Engine identifies which rule-program has to be

triggered by comparing new facts with predicates in

the rule head, then it retrieves the corresponding

rules from the DMS and evaluates them in forward

chaining mode till a fixpoint is reached.

If a Content contains a predicate corresponding

to a query, the Program Engine identifies which

rule-program has to be triggered by comparing the

predicate with rule bodies, then it retrieves the

corresponding rules from the DMS and evaluate

them in backward chaining till the full query result is

computed. If a Content contains query results, these

results are exploited to continue query evaluation.

In addition, the Program Engine during

processing propagates new items or new queries to

other nodes, through the UBIQUEST API, and/or

stores new items in the DMS. The Program Engine

has some additional functions, such as timers,

necessary for networking protocols, it also uses

optimization techniques, such as the triggering of

rules by new facts, which avoid unnecessary

computations, when there are no changes in the

input of rules.

5 CONCLUSIONS

This paper proposes a unified abstraction for the

management of application and network data, which

abolishes the separation between application and

communication layers. Applicative data, network

management operations, even configuration are

treated as transactional queries or updates. The

integration between queries and communication

protocols is one of the fundamental contributions of

the approach.

This allows the definition of rule programs for

networking protocols, which optimize queries or

query optimization strategies, which optimize

network distribution.

We are currently working on a better integration

of the two kinds of languages and on the

implementation of an UBIQUEST system prototype.

We also develop a simulation and emulation

environment for a detailed analysis and evaluation of

queries for a large class of algorithms and protocols.

ACKNOWLEDGEMENTS

This work has been supported by the ANR-09-

BLAN-0131-01 UBIQUEST Project (http://ubiquest

.imag.fr), financed by the French National Research

Agency (ANR).

REFERENCES

Chen, X., Mao, Y., Z. Mao, M., Van der Merwe, J., 2010.

Decor: Declarative network management and

operation. SIGCOMM Comput. Commun. Rev., 40:61-

66.

Condie, T., Chu, D., Hellerstein, J. M., Maniatis, P., 2008.

Evita raced: metacompilation for declarative networks.

Proc. VLDB Endow., 1:1153-1165.

Demers, A. J., Gehrke, J., Rajaraman, R., Trigoni, A.,

Yao, Y., 2003. The cougar project: a work-in-progress

report. SIGMOD Record, 32(4):53-59.

Graefe, G. 1993. Query evaluation techniques for large

databases. ACM Computing Surveys, vol. 25, Issue 2.

Grumbach, S., Wang, F., 2010. NetLog, a rule-based

language for distributed programming. In M. Carro

and R. Pea, editors, PADL, volume 5937 of Lecture

Notes in Computer Science, pages 88-103.

Ioannidis, Y., 1996. Query optimization. ACM Comput.

Surv., 28(1):121-123.

Loo, B. T., Condie, T., Garofalakis, M. N., Gay, D. E.,

Hellerstein, J. M., Maniatis, P., Ramakrishnan, R.,

Roscoe, T., Stoica, I., 2006. Declarative networking:

language, execution and optimization. In ACM

SIGMOD International Conference on Management of

Data, Chicago, Illinois, USA.

Madden, S., Franklin, M. J., Hellerstein, J. M., Hong, W.,

2005. Tinydb: an acquisitional query processing

system for sensor networks. ACM Trans. Database

Syst., 30(1).

Mao, T., 2010. On the declarativity of declarative

networking. SIGOPS Oper. Syst. Rev., 43:19{24}.

Stillger, M., Lohman, G., Markl, V., Kandil, M., 2001.

Leo - db2's learning optimizer. In: Proceedings of the

27th International Conference on Very Large Data

Bases, pages 19-28, San Francisco, CA, USA.

DATA 2012 - International Conference on Data Technologies and Applications

152

Skyline Query Processing on Heterogeneous Data

A Conceptual Model

Nurul Husna Mohd Saad, Hamidah Ibrahim, Fatimah Sidi and Razali Yaakob

Department of Computer Science, Faculty of Computer Science and Information Technology,

Universiti Putra Malaysia, 43400 UPM, Serdang, Selangor, Malaysia

nhusna.saad@gmail.com, {hamidah, fatimacd, razaliy}@fsktm.upm.edu.my

Keywords: Data Heterogeneity, Probabilistic Skyline Query, Data Management.

Abstract: Skyline queries have been aggressively researched recently due to its importance in realizing useful and

non-trivial application in decision-making environments. However, existing researches so far lack methods

to compute skyline queries over heterogeneous data where each data can be represented as either a single

certain point or a continuous range. In this paper, we tackle the problem of skyline analysis on

heterogeneous data and proposed method that will reduce the number of comparisons between objects as

well as gradually compute the probabilistic skyline of each object to be a skyline object. Our model employs

two techniques (local pruning and global pruning) for probabilistic skyline query.

1 INTRODUCTION

In recent years, preference evaluation methods have

gained a tremendous popularity amongst the

database research community as they have been

found to be useful in decision-making environments.

Almost everybody, either in their daily lives or in

professional scenarios, will face with multiple

conflicting criteria that need to be evaluated in order

to make a decision. Users will find that cost or price

of an item or service is usually the main criteria to

be considered in any decision makings and most of

the time, it will be in conflict with some other

measure of quality, which is also typically another

criterion in making the decisions. The most

prominent example used in this research area is hotel

selection. In selecting a hotel, price, distance, and

rate may be some of the main criteria a user might

consider. Users mostly want a hotel that is cheap and

near to certain places, i.e., beaches. It is rare to have

the cheapest hotel to be the nearest hotel to the

beach. Thus, this is where the implementation of

preference evaluation methods will benefit the user

as it leads the process of decision makings to more

informed and better results.

Skyline query is one of the most popular

preference evaluation methods that had been

receiving various interests in the literature

(Börzsönyi et al., 2001; Papadias et al., 2003; Kian-

Lee et al., 2001; Kossman et al., 2002; Godfrey et

al., 2005; Lee et al., 2007). Skyline queries return a

set of interesting multi-dimensional (multiple-

criteria) objects. In n-dimensional objects, we say

object U is more interesting than another object V if

U is better than or equal to V in all dimensions and

U is also better than V in at least one dimension.

Normally, it will be assumed whether lower or

higher value is preferred for all dimensions.

However, most researches that have been done in

this area have only been focusing on homogeneous

data, but in a real world application, the existence of

heterogeneous data could not be avoided. The study

of heterogeneity of data in skyline queries would

usually by default make this study fall under the

scope of uncertainty in skyline queries.

Nevertheless, in our study so far, we have found that

this is not the case as the study of data uncertainty in

skyline queries did not fully incorporated the

heterogeneity of data in their research. Consider

Figure 1 which shows examples of homogeneity of

data in the studies of skyline queries for both certain

and uncertain data. Both of the data shown in the

figure obviously have the same structure of data in

both dimensions x and y, and while the data in

Figure 1b did not have the same structure in both of

its dimensions, still, all the data in dimension x have

the same structure, thus making the process of

skyline queries on this data quite straightforward

(although, it is still not as straightforward as the

conventional skyline query processing on certain

153
