Tagging with Disambiguation Rules

A New Evolutionary Approach to the Part-of-Speech Tagging Problem

Ana Paula Silva

, Arlindo Silva

and Irene Rodrigues

Escola Superior de Tecnologia, Instituto Polit´ecnico de Castelo Branco, Av

do Empres´ario, Castelo Branco, Portugal

Departamento de Inform´atica, Universidade de

Evora,

Evora, Portugal

Keywords:

Part-of-Speech Tagging, Disambiguation Rules, Evolutionary Algorithms, Genetic Algorithms, Natural

Language Processing.

Abstract:

In this paper we present an evolutionary approach to the part-of-speech tagging problem. The goal of part-of-

speech tagging is to assign to each word of a text its part-of-speech. The task is not straightforward, because a

large percentage of words has more than one possible part-of-speech, and the right choice is determined by the

surrounding word’s part-of-speeches. This means that to solve this problem we need a method to disambiguate

a word’s possible tags set. Traditionally there are two groups of methods used to tackle this task. The ﬁrst

group is based on statistical data concerning the different context’s possibilities for a word, while the second

group is based on rules, normally designed by human experts, that capture the language properties. In this

work we present a solution that tries to incorporate both these approaches. The proposed system is divided

in two components. First, we use an evolutionary algorithm that for each part-of-speech tag of the training

corpus, evolves a set of disambiguation rules. We then use a second evolutionary algorithm, guided by the

rules found earlier, to solve the tagging problem. The results obtained on two different corpora are amongst

the best ones published for those corpora.

1 INTRODUCTION

The words of a language are grouped by lexical cat-

egories, normally designated by part-of-speech tags

or word classes, such as nouns, verbs, adjectives,

and adverbs. These categories represent the type

of functions that words can assume in a sentence.

The process of classifying words into their parts-of-

speech, and labeling them accordingly, is known as

part-of-speech tagging, POS tagging, or, simply, tag-

ging. Tagging is a very important task in natural lan-

guage processing (NLP),because it is a necessarystep

in a large number of more complex processes like

parsing, machine translation, information retrieval,

speech recognition, etc. In fact, it is the second step

in the typical NLP pipeline, following tokenization

(Steven Bird and Loper, 2009).

An important aspect of this task is that the same

word can assume different functions depending on

how it is used in the sentence, more speciﬁcally de-

pending on it’s surrounding words (context). For in-

stance, the word ﬂy can assume the function of a

noun, or a verb, depending on how we choose to use

it on a sentence: The ﬂy is an insect and How insects

ﬂy is a very complex subject. These means that in or-

der to assign to each word of a sentence it’s correct

tag, we have to consider the context in which each

word appears.

A part-of-speech tagger processes a sequence of

words and attaches a part-of-speech tag (from a pre-

deﬁned tag set) to each word. Most current taggersare

based on statistical models deﬁned on a set of param-

eters whose values are extracted from texts marked

manually. The aim of such models is to assign to each

word in a sentence the most likely part-of-speech, ac-

cording to its context, i.e, according to the lexical cat-

egories of the words that surround it. In order to do

this, statistics on the number of occurrences of differ-

ent contexts, for each word part-of-speechassignment

possibilities, are collected.

The simplest stochastic tagger, called the unigram

tagger, makes decisions based only on the word itself.

It assigns the tag that is most likely for one particular

token. The training step just investigates all the words

presented in the training corpus, and saves the most

frequent tag for each word. The tagger then works

like a simple lookup tagger, assigning to each word

the tag learned on the training step. A n-gram tagger

Paula Silva A., Silva A. and Rodrigues I..

Tagging with Disambiguation Rules - A New Evolutionary Approach to the Part-of-Speech Tagging Problem.

DOI: 10.5220/0004112000050014

In Proceedings of the 4th International Joint Conference on Computational Intelligence (ECTA-2012), pages 5-14

ISBN: 978-989-8565-33-4

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

is a generalization of a unigram tagger whose context

is the current word together with the part-of-speech

tags of the n − 1 preceding tokens. In this case, the

training step saves, for each possible tag, the number

of times it appears in every different context presented

on the training corpus.

Since the surrounding words can also have various

possibilities of classiﬁcation, it is necessary to use a

statistical model that allows the selection of the best

choices for marking the entire sequence, according to

the model. These stochastic taggers, usually based

on hidden markov models, neither require knowledge

of the rules of the language, nor try to deduce them.

Therefore they can be applied to texts in any lan-

guage, provided they can be ﬁrst trained on a corpus

for that language.

Other type of taggers are rule-based systems, that

apply language rules to improve the tagging’s accu-

racy. The ﬁrst approaches in this category were based

on rules designed by human linguistic experts. There

are also attempts to automatically deduce those rules,

with perhaps the most successful one being the Brill

Tagger (Brill, 1995). The Brill’s system automatic ex-

tract rules from a training corpus, and applies them in

a iterative way in order to improve the tagging of the

text. The results presented by Brill on the Wall Street

Journal data set, with a closed vocabularyassumption,

(97.2%) are among the bests results obtained so far in

this task. Brill’s rules are called transformation rules,

and they allow to consider not only the tags that pre-

cede one particular word, like the traditional proba-

bilistic taggers, but also the tags of the words that fol-

low it.

Brill conduced experiments with two types of

transformation rules: nonlexicalized transformation

rules, which contemplate only the tags that surround

one particular word, and lexicalized transformation

rules, which consider the words itselves.

Considering Brill’s work, it seams that a model

based on rules can be more ﬂexible, since it allows

to consider not only the tags that precede but also

the tags that follow one particular word. Information

about the words itselves can also be used. Moreover,

the format of the information collected, in the form of

rules, is easier to analyze than a extreme high number

of probabilistic values.

More recently, several evolutionary approaches

have been proposed to solve the tagging problem.

These approaches can also be divided by the type

of information used to solve the problem, statistical

information (Araujo, 2002; Araujo, 2004; Araujo,

2006; Araujo, 2007; Araujo et al., 2004; Alba et al.,

2006), and rule-based information (Wilson and Hey-

wood, 2005). Shortly, in the former, an evolutionary

algorithm is used to assign the most likely tag to each

word of a sentence, based on a context table, that basi-

cally has the same information that is used in the tra-

ditional probabilistic approaches. Notwithstanding,

there is an important difference related with the con-

text’s shape, i.e they also take into account context in-

formation about the tags that follow a particular word.

On the other hand, the later is inspired by the

Brill’s tagger. In this case a genetic algorithm (GA)

is used to evolve a set of transformations rules, that

will be used to tag a text in much the same way as the

Brill’s tagger. While in Araujo’s work the evolution-

ary algorithm is used to discover the best sequence of

tags for the words of a sentence, using an informa-

tion model based on statistical data, in Wilson’s work

the evolutionary algorithm is used to evolve the infor-

mation model, in the form of a set of transformation

rules, that will be used to tag the words of a sentence.

There are also some other aspects that can be used

to determine a word’s category beside it’s context in

a sentence (Steven Bird and Loper, 2009). In fact, the

internal structure of a word may give useful clues as

to the word’s class. For example, -ness is a sufﬁx that

combines with an adjective to produce a noun, e.g.,

happy → happiness, ill → illness. Therefor, if we en-

counter a word that ends in -ness, it is very likely to

be a noun. Similarly, -ing is a sufﬁx that is most com-

monly associated with gerunds, like walking, talking,

thinking, listening. We also might guess that any word

ending in -ed is the past participle of a verb, and any

word ending with ’s is a possessive noun.

In this work we investigate the possibility of us-

ing an evolutionary algorithm to evolve a set of dis-

ambiguation rules, that contemplate not only con-

text information, but also some information about the

word’s morphology. This rules are not transformation

rules like Brill’s or Wilson’s rules, but a form of clas-

siﬁcation rules, which try to generalize the context

information that is used in probabilistic taggers. We

look at the problem as a classiﬁcation problem, where

the classes are the different part-of-speeches, and the

predictive attributes are the context information, and

some aspects about the words’ internal structure. Our

goal is to achieve a model that captures both of the

advantages of statistical and rule based systems.

The tagging itself is also made by a second evolu-

tionary algorithm, that uses the disambiguation rules

to ﬁnd the most likely sequence of tags for the words

of a sentence. So, our system is composed by two

steps. First, a set of disambiguation rules are discov-

ered by an evolutionary algorithm, and than an evolu-

tionary tagger is used to tag the words of a sentence,

using the rules found in the ﬁrst step.

The rest of the paper is organized as follows:

IJCCI2012-InternationalJointConferenceonComputationalIntelligence

Section 2 describes the evolutionary algorithm used

to discover the disambiguation rules. In section 3

we present the evolutionary tagger and the results

achieved. Finally, Section 4 draws the main conclu-

sions of this work.

2 EVOLUTIONARY ALGORITHM

FOR DISAMBIGUATION RULES

DISCOVERY

In this section we describe the use of a genetic algo-

rithm to discover a set of disambiguation rules that

solve the part-of-speech tagging problem. The algo-

rithm works on a set of annotated texts. We will ap-

proach the problem as if we were trying to solve a

classiﬁcation problem, by discovering a set of classiﬁ-

cation rules. The motivation for using a genetic algo-

rithm (GA) in this task, is that genetic algorithms are

robust, adaptive search methods that perform a global

search in the space of candidate solutions. As a result

of their global search, they tend to cope better with

attribute predictions than greedy data mining methods

(Freitas, 2003).

We begin by selecting the predictiveattributes that

we will use, then discuss the aspects that concern the

individuals’ representation, genetic operators, selec-

tion and, ﬁnally, the ﬁtness function.

2.1 Attribute Selection

Our aim is to discover a set of rules that take into con-

sideration not only context information but also infor-

mation about the words’ morphology. For the context,

we decided to consider the same information that was

used in the work of Brill (Brill, 1995) and (Wilson and

Heywood, 2005). Thus, we consider six attributes:

• The lexical category of the third word to the left.

• The lexical category of the secondword to the left.

• The lexical category of the ﬁrst word to the left.

• The lexical category of the ﬁrst word to the right.

• The lexical category of the second word to the

right.

• The lexical category of the third word to the right.

For the words’ morphology information we de-

cided to include the following attributes:

• The word is capitalized.

• The word is the ﬁrst word of the sentence.

• The word ends with ed or ing or es or ould or ’s

or s.

• The word has numbers or ’.’ and numbers.

The possible values for each of the ﬁrst six at-

tributes are the values of the corpus tag set from which

the evolutionary algorithm will extract the rules. This

set will depend on the annotated corpus used, since

the set of used labels will vary for different annotated

corpora. The last four attributes are boolean, and so

the possible values are simply 0 and 1.

2.2 Individuals

Genetic algorithms for rule discovery can be divided

into two dominant approaches, based on how the rules

are encoded in the population of individuals. In the

Michigan approach each individual encodes a single

rule, while in the Pittsburgh approach each individual

encodes a set of prediction rules. The choice between

these two approaches depends strongly on the type

of rules we want to ﬁnd, which in turn is related to

the type of data mining task we are interested to. In

the case of classiﬁcation tasks, we are interested in

evaluating the quality of the rule set as a whole, as

opposed to the individual assessment of a rule. That

is, the interaction between the rules is important and

therefore, for classiﬁcation, the Pittsburgh approach

seems to be more natural (Freitas, 2003). Examples

of GAs following the Pittsburgh’s approach are Gabil,

(De Jong et al., 1993), GIL, (Janikow, 1993).

In our work, we are interest in a set of rules that

will not be used for a standard classiﬁcation prob-

lem, but will help the disambiguation task necessary

to solve the tagging problem. In this sense, the Pitts-

burgh’s approach seems to be more appropriate. How-

ever there is an important question to consider when

we adopt this type of representation, and that concerns

the size of the individuals. We could adopt a tradi-

tional ﬁxed length representation, or we could adopt

a non standard variable length representation. In the

ﬁrst case, the problem is to deﬁne which size to con-

sider, since we usual don’t know how many rules are

necessary for a certain classiﬁcation task. In the other

hand, in the non standard variable length represen-

tation, there is a very difﬁcult problem to deal with,

which concerns the control of the individuals’ length.

Individuals tend to grow through the evolutionary al-

gorithm generations, making it increasingly slower -

this problem is the well known bloat problem.

Since we will have a very large training set, and

therefore the algorithm will be very time consuming,

we have chosen to adopt the Michigan’s approach, so

that we don’t have to deal with the bloat problem.

However, we didn’t consider all the population as a

set of rules representing a solution to the classiﬁcation

problem. Instead, we adopted a covering algorithm

TaggingwithDisambiguationRules-ANewEvolutionaryApproachtothePart-of-SpeechTaggingProblem

approach, i.e, we run the genetic algorithm as many

times as necessary to cover all the positive examples

of the training set, evolving a rule in each run. After

each execution ends, we store the rule represented by

the best individual in the population. We also update

the training set, removing all the positive examples

that were covered by the best individual obtained in

that run (see algorithm 1).

Algorithm 1: Covering Algorithm. sp and sn represent the

sets of positive and negative examples. ps and gm give the

population size and the maximum number of generations.

Require: sp,sn, ps,gm

Ensure: set o f rules

while sp 6= ∅ do

best

rule ⇐ GeneticAlgorithm(sp, sn, ps,gm)

sp ⇐ RemoveExamples(sp,best rule)

set

of rules ⇐ Add(set o f rules,best rule)

end while

Algorithm 2: Genetic Algorithm. sp and sn represent the

sets of positive and negative examples. ps and gm give the

population size and the maximum number of generations.

Require: sp,sn, ps,gm

Ensure: bestRule

pop=GenerateInitialPop(ps)

while gm 6= 0 do

Evaluate(pop)

mating

pool ⇐ Selection(pop)

new

pop ⇐ Crossover(pop)

new pop ⇐ Mutation(new pop)

best

old ⇐ GetBestInd(pop)

worst ⇐ GetWorstInd(new pop)

pop ⇐ Replace(worst, best

old,new pop)

gm ⇐ gm− 1

end while

best

ind ⇐ GetBestInd(pop)

best

rule ⇐ Fenotypel(best ind)

In our approach each individual represents a rule

of the form IF Antecedent THEN Consequent,

where Antecedent consists of a conjunction of predic-

tive attributes and Consequent is the predicted class.

In the next sections we explain how we encode the

antecedent and consequent of a rule.

2.2.1 The Rule’s Antecedent

A simple way to encode the antecedent of a rule (a

conjunction of conditions) in an individual is to use

a binary representation. Let’s assume that a given

attribute can take k discrete values. We can encode

these values using k bits. The i-th attribute value, with

(i = 1,....,k), is part of the rule condition if and only

if the ith bit equals 1.

For instance, let’s assume that we want to repre-

sent a rule antecedent that takes only one attribute into

consideration, let’s say, WeatherCondition, whose

possible values are Sunny, Raining, Foggy, and

Windy. Thus, a condition involving this attributes

may be encoded at the expense of four bits. The inter-

pretation of a sequence like 1001 would result in the

following antecedent:

IF ,WeatherCondition =

”Sunny” OR WeatherCondition = ”Windy”

As we have seen, this type of representation al-

lows conditions with disjunctions. If we want to in-

clude a new attribute, we just need to include the se-

quence of bits required to encode the respective val-

ues. The representation can thus be extended to in-

clude any number of attributes, assuming that all are

connected by logical conjunction. An important fea-

ture of this type of representation concerns the situ-

ation where all bits of a given attribute are 1. This

means that any value is acceptable for that particu-

lar attribute, which in terms of interpretation indicates

that this attribute should be ignored.

As we saw above, for our particular problem, we

have a relatively large number of possible values for

most of the attributes considered. Thus, a represen-

tation such as the one described above would lead to

very long individuals. For this reason we adopted a

slightly different representation, inspired by the rep-

resentation used by Wilson.

For each of the ﬁrst six attributes we used six bits.

The ﬁrst bit indicates whether the category should or

should not be considered, and the following ﬁve bits

represent the assumed value of the attribute in ques-

tion. We adopted a table of 29 entries, and used the

binary value represented by ﬁve bits to index this ta-

ble. If the value exceeds the number 29, we used the

remainder of the division by 29. The extra bit for

each attribute allows us to ignore, in the antecedent

of the rule, a given attribute, as in the previous rep-

resentation when all the bits are 1. The remaining

attributes were encoded by nine bits, each one indi-

cating whether the property is, or is not, present. In

short, each individual is composed by 6 × 6+ 9 = 43

bits.

Like in the standard representation, the attributes

are linked by logical conjunction. However, the rules

do not contemplate internal disjunctions between dif-

ferent allowable values for a given attribute. Never-

theless, this knowledge can be expressed by different

rules for the same class.

IJCCI2012-InternationalJointConferenceonComputationalIntelligence

2.2.2 The Rule’s Consequent

In general, there are three different ways to represent

the predicted class in an evolutionary algorithm (Fre-

itas, 2003). One way is to encode it into the genome

of the individual, opening the possibility of subject-

ing it to evolution (De Jong et al., 1993; Greene and

Smith, 1993). Another way is to associate all indi-

viduals of the population to the same class, which is

never modiﬁed during the execution of the algorithm.

Thus, if we are to ﬁnd a set of classiﬁcation rules to

predict k distinct classes, we need to run the evolu-

tionary algorithm, at least k times. In each i-th exe-

cution, the algorithm only discover rules that predict

the i-th class (Janikow, 1993). The third possibility

consists in choosing the predicted class in a more or

less deterministic way. The chosen class may be the

one that has more representatives in the set of exam-

ples that satisfy the antecedent of the rule (Giordana

and Neri, 1995), or the class that maximizes the per-

formance of the individual (Noda et al., 1999) . We

adopted the second possibility, so we didn’t need to

encode the rule’s consequent. Since we used a cover-

ing approach, we run the covering algorithm for each

class independently.

2.2.3 Initial Population

50% of the individuals of the initial population were

randomly generated and the other half were obtained

by randomly choosing examples from the set of pos-

itive examples. These examples were ﬁrst converted

to the adopted binary representation and then added

to the population.

2.3 Training Set

We used the Brown Corpus to create the training sets

that we provided as input to the evolutionary algo-

rithm. The examples considered were extracted from

90% of the corpus. For each word of the corpus we

collected the values for every attribute included in the

rule’s antecedent, creating a speciﬁc training exam-

ple. Then, for each tag of the tag set, we built a train-

ing set composed by positive and negative examples

of the tag. Usually, the set of positive (negative) ex-

amples of a class is composed by examples that do

(do not) belong to that particular class. However in

our case we are not interested in ﬁnding typical clas-

siﬁcation rules, our goal is not to solve a classiﬁcation

problem, we just need rules that allow us to choose

the best tag from a set of possible tags. This set is

not all the tag set, but a subset of it, usually composed

by a few number of elements. When we have a word

that has only one possible lexical class, the tagging is

straightforward. The problematic words are the ones

that are ambiguous. Thus, our training set only in-

cludes examples corresponding to ambiguous words.

With this in mind, we decided to use as positive exam-

ples of a class c

only the examples concerning words

that are ambiguous and are tagged with class c

in the

training corpus. As negative examples we consider

every example that correspond to a word that could

be used as c

, but is tagged with a class different from

2.4 Fitness Function

Rules must be evaluated during the training process

in order to establish points of reference for the evolu-

tionary training algorithm. The rule evaluation func-

tion must not only consider instances correctly classi-

ﬁed, but also the ones left to classify and the wrongly

classiﬁed ones. To evaluate our rules we used the well

known F

-measure:

= (1+ β)

precision× recall

(β

× precison) + recall

(1)

precision =

TP+ FP

(2)

recall =

TP+ FN

(3)

where:

• TP - True Positives = number of instances cov-

ered by the rule that are correctly classiﬁed, i.e.,

its class matches the training target class;

• FP - False Positives = number of instances cov-

ered by the rule that are wrongly classiﬁed, i.e.,

its class differs from the training target class;

• FN - False Negatives = number of instances not

covered by the rule, whose class matches the

training target class.

The F

-measure can be interpreted as a weighted

average of precision and recall. We used β = 0.09,

which means we put more emphasis on precision than

recall.

2.5 Genetic Operators and Selection

Since our representation is a typical binary represen-

tation, we didn’t need to use special operators. We

used a traditional two point crossover and binary mu-

tation as genetic operators. In the two point crossover

operator, two crossover points were randomly se-

lected, and the inner segments of each parent were

switched, thus producing two offsprings. The muta-

tion operator used was the standard binary mutation:

TaggingwithDisambiguationRules-ANewEvolutionaryApproachtothePart-of-SpeechTaggingProblem

if the gene has the allele 1, it mutates to 0, and vice

versa. We used a mutation probability of 0.01 and a

0.75 crossover probability. These values were empir-

ically determined.

For the selection scheme we used a tournament se-

lection of size two with k = 0.8. We also used elitism,

preserving the best individual of each generation by

replacing the worst individual of the new population

by the best of the old one (see algorithm 2).

2.6 Experimental Results

We developed our system in Python and used the re-

sources available on the NLTK (Natural Language

Toolkit ) package in our experiences. The NLTK

package provides, among others, the Brown corpus

and a sample of 10% of the Penn Treebank corpus.

It also provides several Python modules to process

those corpora. Since different corpora use different

formats for storing part-of-speech tags, the NLTK’s

corpus readers were very useful, by providing a uni-

form interface.

As we said before, tagged corpora use many dif-

ferent conventionsfor tagging words. This means that

the tag sets vary from corpus to corpus. To extract the

disambiguation rules from a set of annotated texts, we

need to run our algorithm for each of the tags belong-

ing to the tag set. However, if we want to test the

resulting rules in a different corpus, we will not be

able to measure the performance of our tagger, since

the corpus tag set may be different. To avoid this,

we decided to use the simplify

tags=True option of

the tagged sentence module of NLTK corpus readers.

When this option is set to True, NLTK converts the

respective tag set of the corpus used to a uniform sim-

pliﬁed tag set, composed by 29 tags. This simpliﬁed

tag set establishes the set of classes we use in our al-

gorithm. We ran the covering algorithm for each one

of the classes that had ambiguous words in the train-

ing corpus. There were 20 lexical classes in these

conditions and for each one we deﬁned the respective

sets of positive and negative examples. We used 90%

of the Brown corpus to extract the examples used to

discover the disambiguation rules, using the process

described in the previous section. This resulted in a

total of 61113 examples.

In the next table (1) we present for each class the

number of distinct examples (negative and positive)

used. Each one appears at least one time in the train-

ing corpus. To construct the training set of positive

and negative examples for each class, we reduced the

number of distinct examples by eliminating those that

were less frequent. This reduction is intended to make

the algorithm faster, by eliminating examples that are

not meaningful or even just noise. It is worth noting

that each example has associated the number of times

it occurs in the training corpus. This way we guaran-

tee that the statistical information of each instance is

not lost.

Table 1: TP (TN) column shows the number of distinct pos-

itive (negative) examples that where found in the training

corpus for each of the 20 tags considered; SP (SN) shows

the number of distinct positive (negative) examples that

were used in the discovery of the disambiguation rules. This

simpliﬁcation results from eliminating the less frequent ex-

amples.

Class TP TN SP SN

ADV 25420 99481 1194 8366

VD 17689 23200 484 683

TO 13754 10363 1895 1248

CNJ 21838 22387 1822 2151

PRO 13998 4411 1235 339

VG 8107 3176 145 83

DET 46427 40160 4648 2622

VN 21400 19790 669 683

N 66576 92770 2582 6336

UH 209 10499 198 866

P 66750 37380 7055 3613

NUM 5199 837 416 40

EX 2070 471 192 26

V 18474 63185 477 3046

NP 4185 11219 165 1182

VBZ 2773 8380 38 179

WH 2748 8512 233 822

ADJ 28466 29652 1065 1182

FW 279 25130 279 2990

MOD 5308 541 591 25

The genetic algorithm was run with a population

size of 200 individuals for a maximum of 80 genera-

tions. These values were established after some pre-

liminary experiments. The number of rules that re-

sult in the best tagging, discovered by the algorithm

for each of the 20 ambiguous classes, are presented

in table 2. A total number of 2834 rules were found.

The list below shows some examples of the discov-

ered rules:

• If Following tag is ADJ and Second Following

tag is N THEN DET with Precision = 0.976 and

TP = 4702.

• If Previous tag is V and Following tag is N THEN

DET with Precision = 0.981 and TP = 1720.

• If Previous tag is V and ends with -ed THEN VN

with Precision = 1 and TP = 753.

• If Following tag is V THEN TO with Precision =

1 and TP = 7113.

IJCCI2012-InternationalJointConferenceonComputationalIntelligence

Table 2: Number of rules discovered by the genetic algo-

rithm for each of the 20 ambiguous classes considered.

Class Number of Rules

ADV 396

VD 179

TO 5

CNJ 378

PRO 177

VG 43

DET 421

VN 62

N 364

UH 6

P 289

NUM 42

EX 13

V 121

NP 67

VBZ 15

WH 67

ADJ 196

FW 42

MOD 15

3 EVOLUTIONARY TAGGER

In the previous section we presented an evolutionary

algorithm designed to discover a set of sets of disam-

biguation rules for a predeﬁned set of tags. Each set is

composed by a certain number of rules, and each rule

has associated a precision value and the total number

of positive examples covered by that rule (including

repetitions).

We now want to use these rules so that we can

mark the words of a sentence with the appropriate

part-of-speech. Therefore, if we want to decide which

tag to choose for a particular word, from the set of

possible tags for that word, we should be able to do

that by applying the set of rules previously found.

We could do this by applying the correspondent

sets of rules to the particular word, choosing the class

indexing the set which includes the best rule. Thus,

if we want to tag the word w

, and w

can be tagged

with one of the tags of the set S

, for each possible tag

∈ S

, we should apply the correspondent set of dis-

ambiguation rules R

to w

. The best tag should be the

one that indexes the set which includes the best rule.

To measure the rule’s quality, we could use the prod-

uct between the precision value and the total number

of positive examples covered by that rule.

However, the decision we need to make so that

we can solve the tagging problem, does not only con-

cerns which tag is the best for a particular word, but

also the best sequence of tags to mark a sequence of

words. Since one tagging decision affects the tagging

choices for all the word’s neighbors, we need to use

a method that could give us the optimal sequence of

choices. We used an approach similar to the one pre-

sented in (Araujo, 2002). However, instead of using

the training table, we use the disambiguation rules.

Our tagger receives as input a non annotated sentence,

a dictionary with all the words present in the corpus

(and their possible tags), and a set of sets of disam-

biguation rules. The tagger returns the same sentence

with each word associated with a tag.

An important aspect of the tagging problem, be-

sides the existence of ambiguous words, is the pos-

sibility of occurring unknown words. In this work

we adopt a closed vocabulary assumption, i.e. there

are no unknown words in the test set. Our goal is to

compare our results to the ones achieved by the three

approaches presented earlier, based on the same as-

sumptions. However, we designed the evolutionary

tagging algorithm to be able to deal with this possi-

bility.

3.1 Representation

An individual is represented by a chromosome made

of a sequence of genes. The number of genes in a

chromosome equals the number of words in the input

sentence. Each gene proposes a candidate tag for the

word in the homologous position. For example, con-

sider the input sentence: ”The cat sat on the mat.” A

possible individual would be represented by a chro-

mosome made of six genes, such as the one below:

DET N VD P DET N

To evaluate the individual we need to apply the

disambiguation rules. However, as we discussed in

the previous section, our rules have six attributes

related with the word context, and other nine at-

tributes concerning some morphological properties of

the words. Therefore, so that we can apply the dis-

ambiguation rules, we need to extract the needed at-

tributes from the input sentence and from the tags

proposed by the genes. This way each pair w

gives rise to a 15-tuple of properties with the follow-

ing alignment:

1. The lexical category proposed by the third gene to

the left;

2. The lexical category proposed by the second gene

to the left;

TaggingwithDisambiguationRules-ANewEvolutionaryApproachtothePart-of-SpeechTaggingProblem

3. The lexical category proposed by the ﬁrst gene to

the left;

4. The lexical category proposed by the ﬁrst gene to

the right;

5. The lexical category proposed by the second gene

to the right;

6. The lexical category proposed by the third gene to

the right;

7. True if the homologous word is capitalized, false

otherwise;

8. True if the homologous word is the ﬁrst word of

the sentence, false otherwise;

9. True if the homologous word ends with ed, false

otherwise;

10. True if the homologous word ends with ing, false

otherwise;

11. True if the homologous word ends with es, false

otherwise;

12. True if the homologousword ends with ould, false

otherwise;

13. True if the homologous word ends with ’s, false

otherwise;

14. True if the homologous word ends with s, false

otherwise;

15. True if the homologous word has numbers or ’.’

and numbers, false otherwise.

When there is no gene (no corresponding word) in

one of the positions contemplated in the context, we

adopted an extra tag named ’None’. This can happen

with the ﬁrst three and last three genes of the individ-

ual.

We adopted a symbolic representation, i.e. the

possible alleles of a gene are the the tags of the tag

set adopted for the corpus in which the experiences

will be executed. However, the allowed alleles of a

gene are only the ones that correspond to the possible

tags of the word the gene represents.

The initial population is generated by choosing,

for each gene, one of the possible tags for the corre-

sponding word. If the word is not in the dictionary, the

algorithm chooses randomly one of the classes whose

rule set has a rule which covers the example deﬁned

by the 15-tuple of the corresponding gene. If none of

the rules cover the 15-tuple, the algorithm chooses by

default the class N, which is the most frequent lexical

class in the english language.

3.2 Genetic Operators and Selection

We used a typical one point crossover with a 0.8 prob-

ability. The mutation operator randomly chooses an-

other allele from the set of possible alleles for the par-

ticular gene and was applied with a 0.05 probability.

Again, if the word is unknown, the sets of rules will

be used to determine which ones include a rule that

covers the 15-tuple, and one of the possibilities will

be randomly chosen and assigned to the correspond-

ing gene. We adopted a tournament selection of size

two with k = 0.7 and also used elitism, replacing the

worst individual of each new population with the best

of the old one. All the values were empirically deter-

mined in a small set of preliminary experiments.

3.3 Fitness Function

The performance of an individual is measured by the

sum of the performances of his genes. Let’s consider

to be the lexical category proposed by the gene g

for the word w

, and p

to be the 15-tuple of prop-

erties determined by g

. If R

represents the set of

disambiguation rules for the lexical category t

, and

⊂ R

the set of all rules r

∈ R

that cover the

15-tuple p

, the evaluation of g

, is deﬁned by

FG(g

) =



max{P(r) ×TP(r)|r ∈ RP

} i f RP

6= ∅

Prob(t

) otherwise

(4)

where P(r) gives the precision of rule r, TP(r)

gives the number of examples of the training corpus

covered by r and Prob(t

) the probability of the

word w

appearing with tag t

in the corpus.

The ﬁtness of an individual i with n genes is given

by:

Fitness(i) =

∑

j=1

FG(g

) (5)

3.4 Experimental Results

We tested our evolutionary tagger on 12006 words of

the Penn Treebank corpus and on 7527 words of the

Brown corpus. We achieved an accuracy of 96.9%

on the Pen Treebank of the Wall Street Journal cor-

pus and a 96.49% accuracy on the Brown corpus (ta-

ble 3). We ran the evolutionary tagger with a popu-

lation of 20 individuals, during 30 generations. The

experiments that we performed show that the evolu-

tionary tagger usually ﬁnds a solution very quickly.

In fact the difﬁculty level of the tagging task depends

on the number of ambiguous words of the sentence

we want to tag. Although it is possible to construct

sentences in which every word is ambiguous (Hindle,

1989), such as the following:

Her hand had come to rest on that very book.

IJCCI2012-InternationalJointConferenceonComputationalIntelligence

Table 3: Results achieved by the Evolutionary Tagger on the Penn Treebank corpus and on the Brown corpus, along with the

results achieved by the approaches more similar to the one presented here.

Tagger Corpus Train Test Accuracy

Evolutionary Tagger Brown 61113 7527 96.5

Evolutionary Tagger Penn Treebank WSJ - 12006 96.9

Wilson’s Penn Treebank WSJ 600000 - 89.8

Brill’s Penn Treebank WSJ 600000 150000 97.2

Araujo’s Brown 185000 2500 95.4

those situations are not the most common. After

counting the number of ambiguous words that ap-

pear in the sentences of the 10% of the Brown corpus

we reserved for testing the tagger, we observed that,

in average, there are 6.9 ambiguous words per sen-

tence. This explain the considerable low number of

individuals and generations needed to achieve a solu-

tion. We could argue that in those conditions the use

of a genetic algorithm is unnecessary, and that a ex-

haustive search could be applied to solve the problem.

However, we can not ignore the worst case scenario,

where, like we see above, all the words, or a large ma-

jority of the words, on a very long sentence may be

ambiguous. Furthermore, we observed that the sen-

tence average size of the Brown corpus is of 20.25

tokens, with a maximum of 180. The largest number

of ambiguous words on a sentence belonging to this

corpus is 68. Even for the smallest degree of ambi-

guity, with only two possible tags for each word, we

have a search space of 2

, which fully justiﬁes the

use of a global search algorithm such as a GA.

The results achieved show that there are no sig-

niﬁcant differences on the accuracy obtained by the

tagger on the two test sets used. At this point, it is

important to recall that the disambiguation rules used

on the tagger were extracted from a subset (differ-

ent from the test set used in this experiments) of the

Brown corpus. Which bring us to the conclusion that

the rules learned on step one are generic enough to be

used on different corpora, and are not domain depen-

dent.

4 CONCLUSIONS

We described a new evolutionary approachto the part-

of-speach tagging problem that achieved results com-

parable to the best ones found in the area bibliogra-

phy. Although there are other approaches to this prob-

lem that use, in some way, evolutionary algorithms, as

far as we know this is the ﬁrst attempt that uses these

algorithms to solve all aspects of the task. In the pre-

vious works the evolutionary approach was applied in

two different ways:

• to perform the tagging (Araujo, 2002). Here the

evolutionary algorithm was oriented by statistical

data, that was collected in much the same way as

in the statistical approaches;

• to discover a set of transformation rules (Wilson

and Heywood, 2005). Here the tagging is not done

by the evolutionary algorithm. The author uses an

evolutionary algorithm to discover a list of trans-

formations rules, that is then used to perform the

tagging in a deterministic way.

In our approach to the problem, we used an evolution-

ary algorithm to discovera set of disambiguationrules

and then used those rules to evaluate the sequences of

tags for the words of a sentence, with the sequences

being evolved by another evolutionary algorithm.

When we ﬁrst begun to research this problem, we

concluded that there were two main approaches. The

most frequent were based on statistical data collected

from a training corpus, concerning the words’ left

context (the tags appearing left of a word); the oth-

ers were based on rules: disambiguation rules, gen-

erally constructed by human experts, and transforma-

tion rules, ﬁrstly presented by Brill. Our intention was

to capture the positive aspects of this two main ap-

proaches. We wanted to use rules since they are more

ﬂexible in terms of the kind of information we can

use to solve the disambiguation problem, and are also

more comprehensible than pure statistical data. How-

ever, we couldn’t ignore the good results presented by

the statistical approaches. And this led us to the idea

of transforming the statistical data in a set of disam-

biguation rules.

We wanted to generalize the statistical informa-

tion normally used on the traditional approaches, and,

simultaneously, include other type of information,

presenting it in a way that could be easily interpreted,

i.e. in the form of rules. This generalization was

achievedby the discovery of the disambiguationrules,

with the statistical information being reﬂected on the

quality measure of each rule. Our expectations were

that this generalization could reduce the size of the

data needed to do the disambiguation in the tagging

task and that the information acquired would be less

domain dependent than in previous approaches.

TaggingwithDisambiguationRules-ANewEvolutionaryApproachtothePart-of-SpeechTaggingProblem

We tested our approach on two different corpora:

in a test set of the corpus used to discover the disam-

biguation rules, and on a different corpus. The results

obtained are among the best ones published for the

corpora used in the experiments. Also there were no

signiﬁcant differences between the results achieved in

the subset belonging to the same corpus from which

we deﬁned the training set, used to discover the rules,

and the results obtained on the sentences of the other

corpus. This conﬁrms our expectations concerning

the domain independence of the obtained rules.

Although we consider our results very promising,

we are aware of the necessity of test our approach

with a larger tag set, and to apply it to more corpora.

We intend to test the tagger on other languages, as

well. We also think that this approach could be ap-

plied to other natural language processing tasks like

noun phrase chunking and named-entity recognition.

REFERENCES

Alba, E., Luque, G., and Araujo, L. (2006). Natural lan-

guage tagging with genetic algorithms. Information

Processing Letters, 100(5):173 – 182.

Araujo, L. (2002). Part-of-speech tagging with evolution-

ary algorithms. In Gelbukh, A., editor, Computational

Linguistics and Intelligent Text Processing, volume

2276 of Lecture Notes in Computer Science, pages

187–203. Springer Berlin / Heidelberg.

Araujo, L. (2004). Symbiosis of evolutionary techniques

and statistical natural language processing. Evolution-

ary Computation, IEEE Transactions on, 8(1):14 – 27.

Araujo, L. (2006). Multiobjective genetic programming for

natural language parsing and tagging. In Runarsson,

T., Beyer, H.-G., Burke, E., Merelo-Guerv´os, J., Whit-

ley, L., and Yao, X., editors, Parallel Problem Solving

from Nature - PPSN IX, volume 4193 of Lecture Notes

in Computer Science, pages 433–442. Springer Berlin

/ Heidelberg.

Araujo, L. (2007). How evolutionary algorithms are applied

to statistical natural language processing. Artiﬁcial In-

telligence Review, 28(4):275–303.

Araujo, L., Luque, G., and Alba, E. (2004). Metaheuris-

tics for natural language tagging. In Genetic and Evo-

lutionary Computation - GECCO 2004, Genetic and

Evolutionary Computation Conference, volume 3102

of Lecture Notes in Computer Science, pages 889–

900. Springer.

Brill, E. (1995). Transformation-based error-driven learning

and natural language processing: a case study in part-

of-speech tagging. Comput. Linguist., 21:543–565.

De Jong, K. A., Spears, W. M., and Gordon, D. F.

(1993). Using genetic algorithms for con-

cept learning. Machine Learning, 13:161–188.

10.1023/A:1022617912649.

Freitas, A. A. (2003). A survey of evolutionary algorithms

for data mining and knowledge discovery, pages 819–

845. Springer-Verlag New York, Inc., New York, NY,

USA.

Giordana, A. and Neri, F. (1995). Search-intensive concept

induction. Evol. Comput., 3:375–416.

Greene, D. P. and Smith, S. F. (1993). Competition-based

induction of decision models from examples. Machine

Learning, 13:229–257.

Hindle, D. (1989). Acquiring disambiguation rules from

text.

Janikow, C. Z. (1993). A knowledge-intensive genetic al-

gorithm for supervised learning. Machine Learning,

13:189–228. 10.1007/BF00993043.

Noda, E., Freitas, A., and Lopes, H. (1999). Discovering in-

teresting prediction rules with a genetic algorithm. In

Evolutionary Computation, 1999. CEC 99. Proceed-

ings of the 1999 Congress on, volume 2, pages 3 vol.

(xxxvii+2348).

Steven Bird, E. K. and Loper, E. (2009). Natural Language

Processing with Python. O’Reilly Media.

Wilson, G. and Heywood, M. (2005). Use of a genetic al-

gorithm in brill’s transformation-based part-of-speech

tagger. In Proceedings of the 2005 conference on

Genetic and evolutionary computation, GECCO ’05,

pages 2067–2073, New York, NY, USA. ACM.

IJCCI2012-InternationalJointConferenceonComputationalIntelligence
