Content Meets Semantics: Smarter Exploration of Image Collections

Presentation of Relevant Use Cases

Ilaria Bartolini

DEIS, Universit`a di Bologna, Bologna, Italy

Keywords:

Image Databases, Visual Content, Semantics, Browsing.

Abstract:

Current techniques for the management of image collections exploit either user-provided annotations or

automatically-extracted visual features. Although effective, the approach based on annotations cannot be

efﬁcient since the manual process of data tagging prevents its scalability. On the other hand, the organization

and search grounded on visual features, such as color and texture, is known to be a powerful (since it can be

made fully automatic), yet imprecise, retrieval paradigm, because of the semantic gap problem. This position

paper advocates the combination of visual content and semantics as a critical binomial for effectively and

efﬁciently managing and browsing image databases satisfying users’ expectations in quickly locating images

of interest.

1 INTRODUCTION

The advent of digital photography leads to an increas-

ing production of media data, such as images and

videos. Recent years have also witnessed the prolif-

eration of social media and the success of many web-

sites, such as Flickr, Facebook, Youtube, etc., which

drastically increase the volume of media resources,

available for sharing. Such websites allow users not

only to create and share media data, but also to anno-

tate them. Users of above systems are, however, also

interested in a number of other challenging applica-

tions; among them, image searching and browsing,

that avoid users to feel lost when facing large image

repositories.

Current solutions for exploring image collections

are based on a variety of heterogeneous techniques,

like tagging and visual features. Keyword-based re-

trieval exploits labels (or free tags), used to annotate

images, to search for images of interest. Free tags,

however, suffer the problem of ambiguity due to the

existence of synonymy (a single concept represented

by several, different labels) and homonymy/polysemy

(a single label representing several, different con-

cepts). For this, it is well known that concept hi-

erarchies represent a simple, yet powerful, way of

organizing concepts into meaningful groups (Hearst,

2006). This approach has been used in a variety of

contexts, also outside of multimedia. For example,

Yahoo uses a topic-based hierarchy to organize web

sites according to their topic and allows users

to quickly identify web pages of interest, while

Wikipedia contents are based on a hierarchy of cat-

egories. The biggest drawback of this approach is the

fact that, while categorization of items can be per-

formed (semi-)automatically, the hierarchies should

be manually built, although studies have also focused

on the automatically derivation of hierarchies (Dakka

et al., 2005). When the number of categories is large,

organizing them into a single taxonomy is detrimen-

tal for the usability of the overall structure. To this

end, faceted hierarchies (Hearst, 2006) are used in

a variety of scenarios as a very ﬂexible, and sim-

ple, way to represent complex domains. For example,

they are successfully exploited in systems like Cata-

lyst www.gettyimages.nl/Catalyst and Flamenco (Yee

et al., 2003).

Although effective, current tags-based approaches

cannot be efﬁcient due to the labor-intensive manual

process of data annotation that prevents its scalabil-

ity. We note that, exploiting social community con-

tribution in terms of trustable annotations of images

(e.g., Flickr), still represents an unreliable solution

due to the very high level of noise in the provided

meta-information.

Moreover, it is a fact that above presented tech-

niques are not able alone to reach satisfactory per-

formance levels. Just to give some concrete exam-

ples, text-based techniques, as exempliﬁed by the im-

age search extensions of Google, Microsoft Bing, and

186

Bartolini I..

Content Meets Semantics: Smarter Exploration of Image Collections - Presentation of Relevant Use Cases.

DOI: 10.5220/0004126901860191

In Proceedings of the International Conference on Signal Processing and Multimedia Applications and Wireless Information Networks and Systems

(SIGMAP-2012), pages 186-191

ISBN: 978-989-8565-25-9

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Yahoo!, and by systems like Google Picasa, Apple

iPhoto, and Yahoo’s Flickr, yield a highly variable re-

trieval accuracy. This is due to the imprecision and

the incompleteness of the manual annotation process,

in the case of Picasa, iPhoto, and Flickr, or to the poor

correlation that often exists between surrounding text

of Web pages and the visual image content, for the

case of Google, Bing, and Yahoo!

On the other hand, content-based search, which

relies on low-level similarity features, such as color

and texture, is known to be a powerful (i.e., full au-

tomatic and scalable) retrieval paradigm (Schaefer,

2010; Heesch, 2008; Bartolini et al., 2004; Santini

and Jain, 2000), yet it is imprecise because of the se-

mantic gap existing between the user subjective no-

tion of similarity and the one implemented by the sys-

tem (Smeulders et al., 2000).

Among the recent attempts to match content and

semantics, systems exist that proﬁtably use similarity

search principles to annotate general purpose images

(Pan et al., 2004; Bartolini and Ciaccia, 2008). The

basic idea is to exploit automatically extracted low-

level features from images that have been manually

annotated and use such information as training labels

in order to suggest tags for un-labeled visually sim-

ilar images. As another example, Picasa and iPhoto

are tag-based tools that also provide a speciﬁc visual

facility for automatic face recognition allowing users

to propagate manual annotations to the image folder

representing the same person; however this is clearly

limited to a single content type.

Recently, some efforts have tried to exploit infor-

mation contained in both visual content and semantics

within the same framework, e.g., (Bartolini, 2009). In

these approaches, however, the two kinds of informa-

tion are never fully integrated, rather they are merely

combined as a retrieval ﬁlter in order to support so-

called mixed queries (e.g., “images tagged as bear

that are also visually similar to the one provided as

query”). Similarly (but with retrievalﬁnality), Google

Images supports keyword-based search, but also pro-

vides the user the opportunity to get visual similar im-

ages with respect to a particular returned image. A

tentative joint use of low-level features and surround-

ing texts has been pursued by (Gao et al., 2005): here

the purpose is create clusters containing images with

homogeneous content and semantics, so as to display

images resulting from a Web search in an opportunely

organized way. The focus of the paper is on explo-

ration effectiveness only, while efﬁciency aspects are

not considered due to the bounded dimension of the

result set. This clearly prevents the use of such tech-

nique on large image collections.

In this position paper we show how visual content

and semantic-based paradigms can be seamlessly in-

tegrated for effectively and efﬁciently managing and

browsing image databases, satisfying users’ expecta-

tions in quickly locating images of interest. The basic

idea is to use the semantics to overcome visual con-

tent limitations and vice versa. We will elaborate our

reasoning through a number of relevant use cases on

a real browsing system. In particular, we will show

how the PIBE system (Bartolini et al., 2004; Bartolini

et al., 2006) can be extended to encompass concepts

drawn from both semantics and content realms.

1.1 Basics on PIBE

PIBE (Bartolini et al., 2004; Bartolini et al., 2006)

is a browsing engine whose principles are rooted on

the concept of “adaptable” content-based similarity.

PIBE is based on an automatically derived hierar-

chical tree structure (called Browsing Tree) and pro-

vides the user with a set of browsing and personal-

ization actions that enable an effective and efﬁcient

exploration of the image collection avoiding global

re-organizations.

PIBE provides the user with two main functional-

ities, browsing and personalization, that are available

through an intuitive and user-friendly GUI (see Fig-

ure 1).

Space View

Context View

Figure 1: PIBE’s interface.

In details, the Browsing Tree (BT) is automati-

cally derived from visual image descriptors (i.e., the

color distribution) whose only requirement is to be

points (feature vectors) in a N-dimensional space. By

recursively applying a clustering (k-means) algorithm

on such visual image descriptors, images sharing low

level characteristics are grouped together deriving the

nodes of the BT. The image comparison criterion is

based on a (dis)similarity function between the cor-

ContentMeetsSemantics:SmarterExplorationofImageCollections-PresentationofRelevantUseCases

187

responding feature vectors. A key point to highlight

with regards to the (dis)similarity function is that each

node of the BT uses an adaptable local similarity

criterion (the weighted Euclidean distance) to com-

pare images. In this way, user preferences are con-

textualized to the relevant portion of the dataset and

the hierarchical organization of the BT avoids costly

global reorganizations. In the ﬁrst step of the clus-

tering process, the k-means algorithm is applied to

the whole dataset by using default weights; then, it

is recursively applied down to the desired granularity

level to each of the derived k clusters using an up-

dated (dis)similarity function whose weight compo-

nents correspond to the inverse of the variance of the

feature vectors within the cluster along each compo-

nent. Finally, for each node a representative image

(the image that is closest to the cluster centroid) is

selected for visualization purposes.

Unfortunately, due to its fully automatic creation,

the initial structure of the BT may not always per-

fectly satisfy current user preferences. For example,

some images may be included in the wrong sub-tree

or a node may have too many/few children. To over-

come such problems, PIBE provides a set of person-

alization actions (e.g., move of an image to a differ-

ent cluster, fusion/split of clusters, etc.) to help the

user adapting the automatically built BT to her cur-

rent preferences.

With respect to browsing functionalities, the user

can explore the BT by means of a spatial visualiza-

tion approach (see the Space View in Figure 1), where

feature vectors are mapped on the 2-D screen to high-

light image similarity (the more images are similar,

the closer they are displayed to each other). Among

different browsing modalities, PIBE provides within

the Space View a traditional top-down navigation,

where the user selects an image on the display (by

clicking on it) and zooms in the corresponding BT

node (i.e., images representing the children nodes are

shown). The visualization concerns the local content

of one node; to distinguish between internal and leaf

BT nodes, representative images are framed in yellow

for internal nodes and in green for leaf nodes, respec-

tively (see Figure 1).

On the other hand, to offer a global visualization

modality of the BT, PIBE’s GUI provides the user

with a sequential visualization tool, named Tree View

(see the left side of Figure 1), which offers usual nav-

igational facilities (expanding/collapsingnodes, visit-

ing nodes, etc.). When the user clicks on (the repre-

sentative image of) a BT node in the Tree View, the

content of the Space View is replaced with images in-

cluded in the selected node. Due to space constraints,

each image in the Tree View is zoomed in only when

the pointer hovers over it (see the “shark” image in

Figure 1).

Finally, to help the user in remembering the his-

tory of its browsing session, the GUI provides a third

visualization tool, named Context View (see the top

of Figure 1), which takes memory of each verti-

cal/horizontal exploration action by highlighting the

sequence of clicked images, for the vertical explo-

ration, and using a grey box to represent a horizontal

browsing action. In particular, by clicking on each el-

ement of the Context View the user can return back to

a previous visualization in the Space View.

2 HOW SEMANTICS CAN HELP

CONTENT AND VICE VERSA

Despite the fact that PIBE includes personalization

facilities so as to partially ﬁll the semantic gap prob-

lem, browsing quality is still far from users’ expecta-

tions, due to the fact that the hierarchical organization

of the BT may prevent semantically related images to

appear within the same BT node. PIBE is therefore

a good candidate for the integration of semantics into

its content-based organization. For this, in this section

we show an evolution of the PIBE system, where se-

mantics are taken into account, using image labels, to

complement the visual similarity computed on low-

level features. By means of a set of use cases on this

advanced version of PIBE, we demonstrate the key

role played by the semantics in the image browsing

process. In details, it is possible to see how the basic

functionalities of PIBE can be opportunely extended

(by exploiting tags associated to images) in order to

improve users’ satisfaction. Towards this goal, we

distinguish two relevant scenarios:

1. use cases where the semantics assist the user dur-

ing her exploration;

2. use cases where the semantics help in improving

the image organization (i.e., the BT).

In the ﬁrst scenario, existing image tags are used

to reﬁne or augment the scope of current exploration.

The ﬁrst use case of this scenario deals with “hyper-

links to clusters of similar images”. One of the prob-

lems when browsing the BT in the original version of

PIBE is the fact that semantically correlated images

that do not share a similar visual content are likely

scattered in different parts of the tree. For example,

suppose the user is exploring the cluster represented

by the black bear in Fig. 2, i.e., the one highlighted in

the tree view. During the browsing session, the sys-

tem, by exploiting existing image tags, may suggest

SIGMAP2012-InternationalConferenceonSignalProcessingandMultimediaApplications

188

the user two relevant clusters of semantically corre-

lated images, i.e., brown bear and polar bear clus-

ters, respectively. She can easily explore such clusters

by following provided links within the space view in-

stead of repeating multiple, separate, BT explorations.

Figure 2: Hyperlinks to similar clusters.

The second use case consists in “suggesting good

browsing directions”. When looking for a particular

image, the user usually starts her exploration from the

root of the BT and navigates down the tree until she

reaches a leaf node. During this browsing session, she

has to select, at each step, which is the “best” sub-

tree to visit next, according to visual characteristics.

When siblings nodes are visually similar, such selec-

tion becomes a critical task, because a choice made in

the upper levels of the tree may lead the user to the

“wrong” part of the tree. The integration of semantics

with low-level features may alleviate the problem by

opportunely highlighting portions of the BT that are

not relevant to the speciﬁc browsing task, i.e., sub-

trees containing images whose annotations are not

correlated to the tags speciﬁed by the user.

In the example depicted in Fig. 3, the user is look-

ing for an image representing a “bird in the sky” (in-

put tags bird and sky, respectively). The system inter-

acts with the user by suggesting three different types

of browsing directions, each one distinguished by a

speciﬁc color (i.e., green for “visit”, red for “avoid to

visit”, and yellow for “visit, but only after exploring

green clusters”). This suggestion could be extremely

helpful for the user that, in order to quickly reach im-

ages of interest, should probably visit the green node

ﬁrst (the sub-tree represented by the sub picture); in

such node, the presence of at least one image seman-

tically relevant for the search is guaranteed. Then, the

user could possibly follow the yellow branch (repre-

sented by the brown bear image), where she would

likely ﬁnd untagged images that may be interesting

Figure 3: Suggesting good browsing directions.

for her. Finally, she should avoid exploring red clus-

ters, that contain no images with tags semantically

correlated with the input ones.

Our third use case deals with a facility which is

typically included in several multimedia applications,

i.e., “mixed queries”. In this case, the user asks for

images related to a speciﬁc concept (e.g., tag sub in

the example of Fig. 4) and that are also visually sim-

ilar to a pre-selected image (the ﬁsh image in our ex-

ample). The system returns the set of images belong-

ing the whole BT that match the input tag, providing

them to the user in descending order of visual similar-

ity with respect to the selected image.

Figure 4: Supporting mixed queries.

The ﬁnal use case for the ﬁrst scenario (how se-

mantics could assist the user during her exploration)

covers the “tag report” functionality, providing the

user with a general idea of the content of the image

collection. Given a user provided concept (e.g., the

tag bear in the example of Fig. 5), the system com-

putes a statistical report containing the set of tags that

are correlated with the input one (i.e., tags that co-

ContentMeetsSemantics:SmarterExplorationofImageCollections-PresentationofRelevantUseCases

189

Figure 5: Supporting tag report.

occur with bear in the images of the collection). In

the example, such tags are ice, grass, sky, and tree.

For each correlated tag, the number of relevant im-

ages for that tag is also provided in the report together

with a link to the image set containing both tags, that

the user is allowed to explore. In our example, the

collection contains 11 images tagged with bear and

ice, 10 pictures labeled with bear and grass, etc.

We now present relevant use cases belonging to

the second scenario, where semantics could help in

improving the BT. The basic idea is to highlight pos-

sible discrepancies between tags associated to images

belonging a same cluster, and to suggest viable ac-

tions to solve the problem (by consistently updat-

ing the browsing structure) in order to improve ex-

ploration effectiveness for future browsing sessions.

Regarding efﬁciency, we note that in all cases, re-

organizations of the BT are always performed using

local visual features, thus scalability of this process is

inherited from the original version of PIBE.

The ﬁrst use case deals with “alerting for mis-

placed images and suggesting destination clusters”.

Due to the semantic gap problem suffered by the orig-

inal version of PIBE, it may happen that an image

included in a cluster is semantically different with re-

spect to all the other images in the same cluster. In

such situation, by looking at image semantics (i.e.,

tags) the system may alert the user of these misplaced

images and consistently suggest possible relevant des-

tination clusters where those images could be moved.

In the example of Fig. 6, the alert concerns the

image representing a ﬁsh (such image is labeled as

ﬁsh and sea, while all the other 4 images are tagged

with tags sub and sea). The system concludes that,

even if visually similar to the others, the ﬁsh image

is misplaced in the current cluster and automatically

provides the user with a more suitable destination for

it. In order to derive a suitable destination cluster, the

system looks for cluster of images in the BT sharing

the same tags (o similar ones, exploiting a lexical on-

tology like WordNet (Miller, 1995)) as the misplaced

image. The user is then offered the choice to persis-

tently move that image to one of suggested clusters,

depending on her personal preferences. In alterna-

tive, a re-tagging action is also contemplated by the

Figure 6: Suggesting clusters for misplaced images.

system; this is important because the misplacement

alert may depend on a wrong annotation of the image.

In this way, the user has the possibility to re-tag (at

run time) the supposedly misplaced picture with the

same tags associated to the majority of other compo-

nents (the ﬁrst-class citizens) of the same cluster (in

the example, sub and sea).

Our second example deals with “suggesting clus-

ter split”. This is a particular case of the previoustask.

The envisioned scenario is as follows: some clusters

may exist containing images that, according to their

tags, should be semantically divided into two or more

(sub-)groups.

Figure 7: Suggesting cluster splitting.

In the example depicted in Fig. 7, the cluster is

composed of 5 images of birds and 3 images of planes

(again, this might be the result of a visual similarity

existing between images). The system notices a ques-

tionable situation and suggests the user a viable solu-

tion to solve the problem, that is, to divide (split) the

current cluster into two separate sub-clusters. Again,

the user may decide to persistently apply such modi-

SIGMAP2012-InternationalConferenceonSignalProcessingandMultimediaApplications

190

ﬁcations to the BT or to ignore the suggestion.

The last use case we envision, “suggesting cluster

merge”, is complementary to the previous one. This

time, the user is offered the possibility of merging

clusters containing images that are semantically sim-

ilar but visually different (and are therefore scattered

in different points of the original BT).

Figure 8: Suggesting cluster merging.

For example, consider again Fig. 2, where the

system suggested the user alternative browsing di-

rections: the system could also offer the user the

option to persistently merge suggested clusters with

the current one. Clearly, such re-organization would

move images in suggested clusters into a single clus-

ter, that may be subsequently divided into several sub-

clusters. In the speciﬁc case of Fig. 8, the system

allows the user to merge the currently opened clus-

ter (brown bear) with clusters containing polar bear

and/or black bear images, respectively.

3 CONCLUSIONS

In this position paper we advocate the combined use

of visual content and semantics as a critical binomial

for effectiveand efﬁcient browsingof large image col-

lections, so as to satisfy users’ expectations in quickly

locating images of interest. We have elaborated our

reasoning through a set of relevant use cases on a real

browsing system, namely PIBE. Such use cases tes-

tify how semantics can help visual content and vice

versa, both in assisting the user during her exploration

sessions and in improving image organization. We ﬁ-

nally note that, although use cases presented in this

paper all used simple labels (free tags), the underly-

ing model exploited in the improved version of PIBE

allows the use of semantic tags, i.e., paths extracted

from a variety of existing taxonomies (semantic di-

mensions); this is known to solve problems of ambi-

guity, polysemy, etc. that plague solutions based on

free tags (Hearst, 2006; Bartolini, 2009).

In the future, we plan to provide a thorough exper-

imental analysis and comparison evaluation of PIBE

on real users with large image benchmarks.

REFERENCES

Bartolini, I. (2009). Multi-faceted Browsing Interface for

Digital Photo Collections. In Proc. of CBMI 2009,

pages 65–72, Chania, Crete.

Bartolini, I. and Ciaccia, P. (2008). Imagination: Exploiting

Link Analysis for Accurate Image Annotation. Adap-

tive Multimedia Retrieval: Retrieval, User, and Se-

mantics (LNCS), 4918:322–44.

Bartolini, I., Ciaccia, P., and Patella, M. (2004). The PIBE

Personalizable image Browsing Engine. In Proc. of

CVDB 2004, pages 43–50, Paris, France.

Bartolini, I., Ciaccia, P., and Patella, M. (2006). Adaptively

Browsing Image Databases with PIBE. Multimedia

Tools Appl., 31(3):269–286.

Dakka, W., Ipeirotis, P. G., and Wood, K. R. (2005). Au-

tomatic Construction of Multifaceted Browsing Inter-

faces. In Proc. of CIKM 2005, pages 768–775, Bre-

men, Germany.

Gao, B., Liu, T.-Y., Qin, T., Zheng, X., Cheng, Q., and

Ma, W.-Y. (2005). Web Image Clustering by Con-

sistent Utilization of Visual Features and Surrounding

Texts. In Proc. of ACM MM 2005, pages 112–121,

New York, USA.

Hearst, M. A. (2006). Clustering Versus Faceted Cate-

gories for Information Exploration. Commun. ACM,

49(4):59–61.

Heesch, D. (2008). A Survey of browsing Models for

Content-based Image Retrieval. Multimedia Tools

Appl., 40(2):261–284.

Miller, G. A. (1995). WordNet: A Lexical Database for

English. Commun. ACM, 38(11):39–41.

Pan, J.-Y., Yang, H.-J., Faloutsos, C., and Duygulu, P.

(2004). Automatic Multimedia Cross-modal Corre-

lation Discovery. In Proc. of SIGKDD 2004, pages

653–658, Seattle, USA.

Santini, S. and Jain, R. (2000). Integrated Browsing and

Querying for Image Databases. IEEE MultiMedia,

7(3):26–39.

Schaefer, G. (2010). A Next Generation Browsing Environ-

ment for Large Image Repositories. Multimedia Tools

Appl., 47(1):105–120.

Smeulders, A. W. M., Worring, M., Santini, S., Gupta,

A., and Jain, R. (2000). Content-based Image Re-

trieval at the End of the Early Years. IEEE TPAMI,

22(12):1349–1380.

Yee, K.-P., Swearingen, K., Li, K., and Hearst, M. A.

(2003). Faceted Metadata for Image Search and

Browsing. In Proc. of CHI 2003, pages 401–408, Ft.

Lauderdale, Florida, USA.

ContentMeetsSemantics:SmarterExplorationofImageCollections-PresentationofRelevantUseCases

191
