Friendship Prediction using Semi-supervised Learning of Latent

Features in Smartphone Usage Data

Yuka Ikebe

, Masaji Katagiri

1,2

and Haruo Takemura

3,2

R&D Center, NTT DOCOMO, Inc., Hikari-no-oka, Yokosuka-shi, Japan

Graduate School of Information Science and Technology, Osaka University, Suita-shi, Japan

Cybermedia Center, Osaka University, Ibaraki-shi, Japan

Keywords:

Link Prediction, Matrix Factorization, Latent Feature, Semi-supervised Learning, One-class Setting.

Abstract:

This paper describes a semi-supervised learning method that uses smartphone usage data to identify friend-

ship in the one-class setting. The method is based on the assumption that friends share some interests and

their smartphone usage reﬂects this. The authors combine a supervised link prediction method with matrix

factorization which incorporates latent features acquired from the application usage and Internet access. The

latent features are optimized jointly with the process of link prediction. Moreover, the method employs the

sigmoidal function to estimate user afﬁnities from the polarized latent user features. To validate the method,

ﬁfty university students volunteered to have their smartphone usage monitored for 6 months. The results of

this empirical study show that the proposal offers higher friendship prediction accuracy than state-of-the-art

link prediction methods.

1 INTRODUCTION

With the prevalence of social networking services

(SNSs) such as Facebook, Twitter and MySpace, the

mining of social network data is attracting more at-

tention because the results appear promising for in-

creasing the sales of products and services through

marketing strategies such as viral marketing.

However, according to a survey (Keller and Fay,

2009), such effects are mostly observed in real face-

to-face inter-personal relationships rather than in cy-

ber relationships on SNSs at this moment. This im-

plies that the social networks acquired from SNSs are

not sufﬁcient to acquire friend networks. Although

other information such as phone calls and/or e-mail

records is considered to be useful for identifying the

desired friend networks, they are, in practice, very

difﬁcult to collect on a massive scale due to privacy

concerns. Moreover, they still reﬂect only a part of

the whole network. Fig.1 shows a real example of

the friend networks collected by the authors (details

are shown in a later section). Solid lines represent

the friends captured by monitoring phone calls for 6

months. Dotted lines are showing the ground truth

obtained by questionnaires. The ﬁgure implies that,

in reality, only a small portion is likely to be observ-

able, and thus the capability to predict friendship from

Figure 1: An example of friend network.

small set of known links is important. This mo-

tivated the authors into proposing a semi-supervised

method to predict friendship relations by utilizing ap-

plication execution and web access histories on smart-

phones, rather than monitoring communication activ-

ities directly. The idea is based on the assumption that

friends share some interests, a characteristic known as

homophily (McPherson et al., 2001), and their smart-

phone usages reﬂect this.

A straight forward approach to predicting friend-

ship is to apply link prediction methods. Link pre-

diction is a common binary classiﬁcation task and

has been used in many studies (Lü and Zhou, 2011).

199

Ikebe Y., Katagiri M. and Takemura H..

Friendship Prediction using Semi-supervised Learning of Latent Features in Smartphone Usage Data.

DOI: 10.5220/0004133201990205

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2012), pages 199-205

ISBN: 978-989-8565-29-7

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Friendship prediction is seen as a subtask of link pre-

diction. However, there are three major difﬁculties

with friendship prediction not solved by existing link

prediction methods;

One-class Setting. Since it is virtually impossible to

monitor all activities of a pair of people, it is pos-

sible that they are friends even if no interaction

is observed between the pair. Thus, in practice,

we cannot distinguish known absent link from

unknown link. Therefore, available observations

consist of known present links only, i.e. positive

samples only, and no negative samples are avail-

able for learning.

Sparse Friend Network. In general and practical

settings, the number of friends is extremely small

compared to the total number of participants. In

conjunction with the one-class setting, this yields

a small number of known links, i.e. most links re-

main unknown.

Afﬁnity Differs from Similarity. General node sim-

ilarity approaches such as cosine similarity do not

always match the characteristics of friendship, es-

pecially given that node information is highly di-

mensional and sparse.

Existing missing link prediction methods can be

classiﬁed into two types: (1) topological-information-

based and (2) node-information-based. The ﬁrst type

uses only known network structure such as common

adjacent nodes or paths between nodes. Well-known

methods are Jaccard Similarity (Lü and Zhou, 2011)

and Adamic/Adar (Adamic and Adar, 2003). These

methods are problematic if the known network is

sparse. The second type uses information of nodes

as well as known network structure; they try to pre-

dict links even if a node is isolated from known links.

Since the number of known links is small for friend-

ship prediction as mentioned above, the proposed

method takes the node-information-based approach.

Two state-of-the-art node-information-basedlink pre-

diction methods were proposed recently.

Latent Feature Model: Menon et al. proposed a su-

pervised learning method to predict links by ap-

plying latent feature model (LFL) in (Menon and

Elkan, 2010) and (Menon and Elkan, 2011). This

method tries to minimize the loss between pre-

dicted results and known present/absent links by

adjusting latent features. Yang et al. proposed

Joint Friendship and Interest Propagation (FIP)

which combines latent feature models for user–

user and user–item (Yang et al., 2011).

Link Propagation: Kashima et al. proposed the

Link Propagation method; it tries to propagate

known links using observed node features with

pre-speciﬁed kernel (Kashima et al., 2009). If ob-

served node features are highly dimensional and

sparse, it is not trivial to construct the proper ker-

nel.

Besides the works related to link prediction, sev-

eral data-oriented approaches have been reported for

friendship prediction. The data used are;

1. Location data such as GPS coordinates: (Wang

et al., 2011), (Eagle et al., 2009), (Scellato et al.,

2011),

2. Bluetooth encounter data: (Quercia et al., 2010),

(Eagle et al., 2009),

3. Call records: (Wang et al., 2011), (Mirisaee et al.,

2010).

Although location trajectory and encounter data

show a strong correlation to friendship, they cap-

ture only the relationships that yield frequent physi-

cal contacts. Call records are hamstrung by privacy

issues and so are impractical for this purpose.

The authors’ basic idea to overcoming the one-

class setting and the sparsity of friend networks is to

incorporate rich user information for friendship pre-

diction. Here, rich user information means applica-

tion execution and web browsing histories. Applica-

tion execution and web browsing are universal activi-

ties for any smartphone user, and so it is reasonable to

expect those histories to be available for most users,

unlike friendship links. Since standard operating sys-

tems can create the logs needed, it is also practical in

terms of deployment. Moreover, application execu-

tion and web browsing histories are potentially infor-

mative enough, since recent research (Fujimoto et al.,

2011) showed that user’s interests can be extracted

from the web browsing history. However, note that

we need to extract interests from histories, since they

are expressed by items and are not directly observ-

able.

Yang et al. proposed a strategy similar to that of

the FIP model in (Yang et al., 2011); it enables the

incorporation of user–item interaction into user–user

modeling. However, they assume that the item is the

key point of interest and focus in obtaining latent fea-

tures from the observed node (i.e. user and item) in-

formation, not from user–item interaction, because of

its different problem setting.

Here, the authors propose to employ matrix factor-

ization to extract latent user features from each user’s

application execution and Internet access records.

The authors believe matrix factorization on user–item

interaction is promising as a method to identify latent

features, since it is successful in collaborativeﬁltering

by extracting users’ and items’ latent features from

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

200

the observed user–item rating matrix (Koren et al.,

2009). The supervised link prediction method is mod-

iﬁed to incorporate matrix factorization, so that the re-

sults of matrix factorization are optimized jointly with

link prediction. Moreover, to better model friend-

ship, the authors propose a speciﬁcally designed afﬁn-

ity measure that reﬂects the assumed correlation be-

tween friendship and the degree of interest matching.

This approach allows the proposed method to opti-

mize latent features (obtained by matrix factorization

with all user–item observations) and link prediction

(supervised by known links only) simultaneously in

terms of the proposed afﬁnity measure through semi-

supervised learning. To the best of our knowledge,

this is the ﬁrst paper to propose friendship prediction

in the one-class setting with an evaluation conducted

on realistic data.

In summary, this work makes the following con-

tributions;

• Proposed semi-supervised friendship prediction

method that combines supervised link prediction

method with matrix factorization technique in or-

der to acquire latent features from smartphone ap-

plication execution and web access histories. It

also employs a speciﬁc afﬁnity measure based on

a prior knowledge of the level of interest match-

ing.

• Validation of the method by real monitored data

from 50 university students.

This paper is organized as follows. Section 2 ex-

plains our formulation. Section 3 describes the pro-

posed method for friendship prediction. Section 4 ex-

plains the collected data and evaluation results. Sec-

tion 5 concludes the paper.

2 FORMULATION

2.1 Supervised Link Prediction

A supervised link prediction method using known

node information X is formulated as identifying un-

known parameters θ that minimize the following ob-

jective function;

min

(

∑

(i, j)∈O

ℓ(G

(X,θ)) + λΩ(θ)

)

, (1)

where O represents the set of known links. G is an n×

n adjacency matrix that indicates the graph structure,

in which each element takes one of three values, 0,

1 and ? representing a known absent link, a known

present link, and an unknown link, respectively. Here,

n represents the number of nodes. Note that in the

one-class setting, the value of G

takes either 1 or ?.

G represents the predicted graph structure. ℓ is a loss

function, Ω is a regularization term (e.g. ℓ2 norm) and

λ is a weight parameter for the regularization term. X

represents a set of known node information such as

observed features. θ represents the set of unknown

parameters to be acquired.

During the training phase, unknown parameters,

θ, are obtained by optimizing the objective function

Eq.1. Upon completion of training,

G gives predictive

results for unknown links using the identiﬁed θ and

the known node information X.

2.2 Matrix Factorization and Latent

Feature

In the context of friendship prediction, let X be

a user–item matrix which represents observed fre-

quency of item usage on each user. The dimension

of X is U × I, where U and I represent the number

of users and items, respectively. The equation below

describes the matrix factorization of X;

X ≈ WH. (2)

Matrices W and H are the outcome of matrix fac-

torization. W becomes a latent user feature matrix

whose dimension is U × L, and H becomes a latent

item feature matrix with dimension of L× I. Here L

is a given constant positive integer which deﬁnes the

number of dimensions for the latent features. Eq.3 is

the typical objective function used,

min

W,H



kX− WHk

+ λ

′

Ω

′

(W,H)



, (3)

where Ω

′

is a regularization term (e.g. ℓ2 norm) and

′

is a weight parameter of the regularization term.

3 PROPOSED METHOD

3.1 Afﬁnity Measure

To predict friendship, identifying the proper covariate

is one of the key requirements. Cosine similarity of

node features is a commonly used conventional mea-

sure. However, the possibility of being friends does

not always follow such “similarity”. For instance,

suppose user A has several interests such as baseball,

ﬁshing and camping. User A’s friend, user B, does

not necessarily like all of them. Typically, user B

shares only a few of the interests. Here, intuitively

we can see that the key factor in friendship is exis-

tence of common topics of interest. In other words,

FriendshipPredictionusingSemi-supervisedLearningofLatentFeaturesinSmartphoneUsageData

201

Table 1: Parameters in the proposed method.

Parameter Type Explanation

α Controlled A weight parameter for the supervised term in Eq.8

β Controlled A weight parameter for the matrix factorization term in Eq.8

′′′

Controlled A weight parameter for the regularization term in Eq.8

g Controlled Gain of sigmoid function in Eq.5

th Controlled Flexion point of sigmoid function in Eq.5

= threshold

L Controlled The number of latent feature dimensions

= Number of columns of matrix W

= Number of rows of matrix H

W, H Inferred Latent user / item matrix

the strength of interest is much less important in pre-

dicting friendship. Thus, based on this consideration,

the authors propose to model afﬁnity between user i

and j, denoted by f

, as the inner product of polar-

ized latent user features using the following sigmoidal

functions;

(W) =

σ(w

) · σ(w

)

, (4)

where,

σ(w

) =



1+ e

−g(w

−th)

,··· ,

1+ e

−g(w

−th)



(5)

Here, w

represents the latent user feature for user

i; it is a vector extracted from the ith row of matrix

W, w

= (w

,··· , w

). th and g represent a threshold

and a gain of sigmoid function, respectively. σ(w

)

polarizes each component of vector w

using sigmoid

function, thus the value of f

ranges 0 ≤ f

≤ 1.

3.2 Embedding Latent Features to

Supervised Link Prediction

In the one-class setting, G

is always 1 for any (i, j) ∈

O. In addition, afﬁnity f

acts as the covariate of

for friendship prediction. Thus, Eq.1 can be modiﬁed

into;

min

(

∑

(i, j)∈O

ℓ (1, f

(W)) + λ

′′

Ω

′′

(W)

)

. (6)

In order to combine afﬁnity measure with super-

vised link prediction, Eq.3 and Eq.6 need to be op-

timized simultaneously. Therefore, by merging Eq.3

and Eq.6, the objective function is deﬁned as;

min

W,H

(

∑

(i, j)∈O

ℓ(1, f

(W)) + βkX−WHk

+ λ

′′′

Ω

′′′

)

(7)

where α and β are mixture weight parameters (α,β >

0). In Eq.7, the matrix factorization process, i.e., the

second term, provides additional constraints regard-

ing the latent features for the supervised link predic-

tion process, i.e., the ﬁrst term.

If the loss function ℓ employs simple absolute loss,

Eq.7 can be modiﬁed to;

min

W,H

(

∑

(i, j)∈O

(1− f

(W)) + βkX−WHk

+ λ

′′′

Ω

′′′

)

(8)

Here, standard ℓ2 norm is typically used for regu-

larization term Ω

′′′

;

Ω

′′′

= kWk

+ kHk

. (9)

3.3 Parameter Estimation

To perform an empirical study, the steepest descent

method was applied to optimize Eq.8 because of its

ease of implementation. Table 1 lists the parame-

ters used in the proposed method. Control parameters

were determined experimentally based on extensive

parameter search so that the parameters achieved the

best optimization of the objective function (Eq.8).

After completion of optimization, high f

val-

ues indicate that user pair (i, j) are more likely to be

friends.

4 EXPERIMENTAL EVALUATION

4.1 Collected Data

Fifty university students voluntarily contributed by

becoming monitored subjects; proper informed con-

sent was given. Every student knew at least one of the

other participating students. Each student received a

smartphone Xperia



on which an application to mon-

itor user activities was installed. They were instructed

to use it freely for about 6 months (February 2011

– September 2011). The collected logs include two

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

202

types of records; (1) application execution, and (2)

access to Internet contents through the browser. Each

log record included timestamp, terminal ID, and asso-

ciated strings depending on its type, that are listed in

Table 2.

Table 2: Collected logs.

Type Log

Application exec. Application package name

Internet access Access URL

Fig.2 and Fig.3 represent statistical data for “Ap-

plication execution” and “Internet access”. Fig.2

shows the daily transition in the volume of collected

log records. Fig.3 shows the daily transition in the

number of unique users.

ηŽĨůŽŐƐ

ĂǇ

/ŶƚĞƌŶĞƚ

ƉƉůŝĐĂƚŝŽŶ

Figure 2: The volume of collected log records.

ηŽĨƵŶŝƋƵĞƵƐĞƌ

ĂǇ

/ŶƚĞƌŶĞƚ

ƉƉůŝĐĂƚŝŽŶ

Figure 3: The number of unique users.

User–item matrix X was acquired from the col-

lected logs. The column dimension of matrix X be-

came 4, 974, which is the total number of application

package names and URLs appearing in the logs. Each

element of X indicates the frequency of item usage

during the period, i.e. total number of times the corre-

sponding application was launched or the correspond-

ing URL was accessed.

In addition to the log records collected, an exit

questionnaire was conducted in order to obtain the

ground truth of friendships at the end of monitoring.

The authors asked students whom he or she had called

or received call(s) from during the experimental pe-

riod regardless of the phone used. Fig.1 shows the

results. According to the results, there were 157 pairs

of students who made phone calls during the period.

Here the authors treat these user pairs as the ground

truth of friendship.

4.2 Analysis of Collected Data

First, the authors tested whether simple afﬁnity mea-

sures such as cosine similarity were capable of iden-

tifying friendship from the raw behavioral data col-

lected. Let x

denote the vector that is the row of

matrix X for user i; its length is 4, 974. Similarity

measures shown below were calculated for each user

pair (i, j).

• Cosine similarity (CS):

· x

kkx

. (10)

• Dot product of binarized vectors (DB):

= x

′

· x

′

, (11)

where,

′

= (x

′

,··· , x

′

), (12)

′



1 if x

> 0,

0 otherwise

. (13)

• Dot product of log normalized vectors (DL):

= x

′′

· x

′′

, (14)

where,

′′

= (x

′′

,··· , x

′′

), (15)

′′

log(x

+ 1)

max

′

{log(x

′

+ 1)}

. (16)

In addition, by borrowingthe concept of LSA (La-

tent Semantic Analysis (Deerwester et al., 1990)),

possible user features were calculated by SVD (Sin-

gular Values Decomposition) with designated rank

number l. Cosine similarities were calculated based

on the outcome. CS_RD denotes this result.

By sorting the user pairs according to calculated

similarity (descending order), recall factors were ob-

tained from the top-k, see Fig.4. The dashed diago-

nal line shows the baseline of random sampling. The

ﬁgure reveals that the similarity measures offered no

discrimination ability on either the raw data or the

dimension-reduced data yielded by SVD. This im-

plies that non-supervised approaches cannot be pre-

dicted friendships from such behavioral data.

FriendshipPredictionusingSemi-supervisedLearningofLatentFeaturesinSmartphoneUsageData

203

0.0 0.2 0.4 0.6 0.8 1.0

k in ratio

Recall

CS_RD(l=10)

CS_RD(l=30)

CS_RD(l=50)

Figure 4: Top-k recall factors based on similarity of behav-

ioral data.

4.3 Performance Evaluation

Performance of the proposed method was compared

with that of the LFL model (Menon and Elkan, 2011),

a state-of-the-art link prediction method. Menon et al.

described in their paper a method to combine their

LFL model with observable side-information such

as node-information, as a possible extension to the

model. However, their approach assumes that the

side-information independentlycontributes to the pre-

diction performance as a source of performance im-

provement. As we saw in the previous section, be-

havioral data is not expected to directly improve the

prediction performance in our case. Thus here, the

authors employed the LFL model without using be-

havioral data as a performance reference. The authors

are not aware of any existing method which can uti-

lize such behavioral data for link prediction.

Performancewas evaluatedby precision and recall

on the top k predicted user pairs using the 3-fold cross

validation approach. As for 3-fold cross validation, to

simulate a realistic problem setting, only one third of

the positive links were used as known links for train-

ing, that means all of the rest were treated as unknown

for training. The other two thirds of the positive links

and all of the non-friend pairs were included in the

test set. For both methods, the best performing set

of control parameters were used in the evaluation; the

parameters were determined from the results of a pre-

liminary parameter scan. Table 3 lists values of some

control parameters used in the evaluation. To draw

a Precision-Recall graph, k was swept from 10 to 50

in steps of 10. Results are shown in Fig.5. The pro-

posed method demonstrated higher performance than

the LFL model.

Table 3: Parameter settings for performance comparison.

Parameter LFL Proposed

Latent feature dimension L 50 100

Loss function log mae

Regularization weight λ 0.0 0.0

Ϭ͘Ϭϱ

Ϭ͘ϭ

Ϭ͘ϭϱ

Ϭ͘Ϯ

Ϭ͘Ϯ Ϭ͘Ϯϱ Ϭ͘ϯ Ϭ͘ϯϱ Ϭ͘ϰ Ϭ͘ϰϱ Ϭ͘ϱ

ZĞĐĂůů

WƌĞĐŝƐŝŽŶ

WƌŽƉŽƐĞĚ

>&>

Figure 5: Precision-Recall graph.

5 CONCLUSIONS

This paper proposed a semi-supervised method for

friendship prediction. The method utilizes matrix fac-

torization for the user–item matrix to acquire latent

user features. The latent user features are embed-

ded into the process of supervised link prediction, so

that the latent user features are optimized jointly in

terms of known friendship links and observed user

item interactions. An afﬁnity measure speciﬁcally de-

signed for latent user features on friendship prediction

was also proposed. An extensive empirical evalua-

tion was conducted using real data collected from uni-

versity students. The results conﬁrmed that the pro-

posed method outperforms an existing state-of-the-art

method.

Possible extensions and further study items in-

clude;

• Employing stochastic gradient descent method in

the optimization process to improve its scalability

• Versatility should be studied by using different

types of data

• Model extension to include other aspects such as

FIP model

REFERENCES

Adamic, L. and Adar, E. (2003). Friends and neighbors on

the web. Social Networks, 25(3):211–230.

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

204

Deerwester, S., Dumais, S. T., Furnas, G. W., Landauer,

T. K., and Harshman, R. (1990). Indexing by latent

semantic analysis. Journal of the American Society

for Information Science, 41(6):391–407.

Eagle, N., Pentland, A. S., and Lazer, D. (2009). Inferring

friendship network structure by using mobile phone

data. Proceedings of the National Academy of Sci-

ences, 106(36):15274–15278.

Fujimoto, H., Etoh, M., Kinno, A., and Akinaga, Y. (2011).

Web user proﬁling on proxy logs and its evaluation

in personalization. In Proceedings of the 13th Asia-

Paciﬁc web conference on Web technologies and ap-

plications, APWeb’11, pages 107–118, Berlin, Hei-

delberg. Springer-Verlag.

Kashima, H., Kato, T., Yamanishi, Y., Sugiyama, M., and

Tsuda, K. (2009). Link propagation: A fast semi-

supervised learning algorithm for link prediction. In

Park, H., Parthasarathy, S., and Liu, H., editors,

SDM 2009, pages 1099–1110, Society for Industrial

and Applied Mathematics. Max-Planck-Gesellschaft,

Philadelphia, PA, USA.

Keller, E. and Fay, B. (2009). The Role of Advertising

in Word of Mouth. Journal of Advertising Research,

49(2):154–158.

Koren, Y., Bell, R., and Volinsky, C. (2009). Matrix factor-

ization techniques for recommender systems. Com-

puter, 42(9):30–37.

Lü, L. and Zhou, T. (2011). Link prediction in complex

networks: A survey. Physica A Statistical Mechanics

and its Applications, 390:1150–1170.

McPherson, M., Smith-Lovin, L., and Cook, J. M. (2001).

Birds of a feather: Homophily in social networks. An-

nual Review of Sociology, 27(1):415–444.

Menon, A. K. and Elkan, C. (2010). A log-linear model

with latent features for dyadic prediction. In Proceed-

ings of the 2010 IEEE International Conference on

Data Mining, ICDM ’10, pages 364–373, Washing-

ton, DC, USA. IEEE Computer Society.

Menon, A. K. and Elkan, C. (2011). Link prediction

via matrix factorization. In Proceedings of the

2011 European conference on Machine learning and

knowledge discovery in databases - Volume Part II,

ECML PKDD’11, pages 437–452, Berlin, Heidel-

berg. Springer-Verlag.

Mirisaee, S. H., Noorzadeh, S., and Sami, A. (2010).

Mining friendship from cell-phone switch data. In

Proceedings of the 3rd international conference on

Human-Centric Computing, HumanCom 2010, pages

1–5.

Quercia, D., Ellis, J., and Capra, L. (2010). Using mobile

phones to nurture social networks. IEEE Pervasive

Computing, 9(3):12–20.

Scellato, S., Noulas, A., and Mascolo, C. (2011). Exploit-

ing place features in link prediction on location-based

social networks. In Proceedings of the 17th ACM

SIGKDD international conference on Knowledge dis-

covery and data mining, KDD ’11, pages 1046–1054,

New York, NY, USA. ACM.

Wang, D., Pedreschi, D., Song, C., Giannotti, F., and

Barabasi, A.-L. (2011). Human mobility, social ties,

and link prediction. In Proceedings of the 17th ACM

SIGKDD international conference on Knowledge dis-

covery and data mining, KDD ’11, pages 1100–1108,

New York, NY, USA. ACM.

Yang, S.-H., Long, B., Smola, A., Sadagopan, N., Zheng,

Z., and Zha, H. (2011). Like like alike: joint friend-

ship and interest propagation in social networks. In

Proceedings of the 20th international conference on

World wide web, WWW ’11, pages 537–546, New

York, NY, USA. ACM.

FriendshipPredictionusingSemi-supervisedLearningofLatentFeaturesinSmartphoneUsageData

205
