Semantically Enriched Obligation Management

An Approach for Improving the Handling of Obligations Represented in Contracts

Barbara Thönssen

1,2

and Jonas Lutz

Institute for Information Systems, University of Applied Sciences and Arts Northwestern Switzerland FHNW,

Riggenbachstr. 16, Olten, Switzerland

Dipartmento di Matematica e Informatica, University of Camerino, Via Madonna delle Carceri 9, Camerino (MC), Italy

Keywords: Enterprise Architecture, Enterprise Ontology, Risk Management, Contract Management, Information

Extraction, Obligation Management.

Abstract: Contract Management becomes increasingly important for companies and public administrations alike.

Obligations and liabilities are described in contract clauses that are often buried in documents of a hundred

pages and more. Although commercial Contract Management Systems (CMS) are available, with a few

exceptions relevant information has to be extracted manually which is time consuming and error prone. But

even if information extraction is automated and contracts are managed using a CMS, dealing with

obligations is still a challenge. Whereas the CMSs deal well with time triggered obligations like periodical

payments by setting up corresponding workflows, they fail to trigger obligations based on events, as this

knowledge is out of the systems’ scope. We introduce an approach to fill the gap as we relate information

about the obligations managed in a CMS with background knowledge modelled in an ontology. The

ontology is a formal representation of an enterprise architecture extended by top-level concepts. Motivating

scenario for the approach is the contract management of a large company. For proof of concept a prototype

has been developed.

1 INTRODUCTION

Contracting is a critical issue for enterprises and

public administrations alike, as “All organizations

depend upon their ability to make, manage, monitor

and perform against their business commitments, or

to structure and oversee those they receive from

their trading partners” (IACCM 2007). To manage

not only the sheer volume of contracts but their

growing complexity, The International Association

for Contract and Commercial Management

(IACCM) believes that automation is fundamental

and of critical importance. In a study that IAACM

provided (IACCM 2007), benchmarks have shown

that the benefits of Contract Management Software

are significant for most organizations, despite

reservations over the maturity and functionality of

the available options. One software flaw is the weak

support of obligation management. Even if a

Contract Management System (CMS) is in place,

clauses, terms, conditions, commitments and

milestones are buried in unstructured text. Thus, a

first step can be document segmentation and

information extraction. In the Swiss national funded

project DokLife contract documents are analysed

and information like contract partners, contract date,

jurisdiction, etc. is automatically extracted.

Moreover, the documents are divided into disjoint

sections for further analysis, e.g. classification and

section specific information extraction. The original

contract document, its segments and the extracted

metadata are imported into a commercial CMS.

However, although with such an approach

contract document management is improved,

obligation management remains a challenge.

Whereas time triggered obligations (e.g. sending a

report at a certain time) can be supported by the

workflow functionality of a Contract Management

System, event triggered obligations cannot. The

problem is that these events occur outside the CMS

and cannot be foreseen. If for example a company

goes bankrupt it is of vital interest to know whether

a relationship exits with this company, what kind of

relationship that is, whether the relationship is

contracted, and whether obligations are to be met.

Our approach aims at providing the context for

contract management by linking the extracted

Thönssen B. and Lutz J..

Semantically Enriched Obligation Management - An Approach for Improving the Handling of Obligations Represented in Contracts.

DOI: 10.5220/0004134700400048

In Proceedings of the International Conference on Knowledge Management and Information Sharing (KMIS-2012), pages 40-48

ISBN: 978-989-8565-31-0

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

information, i.e. contract metadata to business

objects described in an enterprise ontology. In the

ontology (background) knowledge about business

objects and business events are made explicit.

Hence, this knowledge can be used to automatically

assess business events, for example reported in

external sources of commercial information or

newspaper reports, and to identify affected

obligations for which the respective contract(s) can

be retrieved.

Figure 1: Obligation management overview.

Figure 1 gives an overview of the approach:

information is automatically extracted from contract

documents, the metadata is stored in the relational

database of an CMS and mapped to the respective

concepts in a ontology, which is a semantically

enriched Enterprise Architecture Description. A

business event (e.g. bankruptcy) triggers the search

for affected contracts in the ontology and if found,

the related documents can be accessed via the CMS.

The remaining paper is structured as follows:

Section two describes the motivating scenario for

semantically enriched obligation management. In

section three background and related work is

presented. Section four introduces the three pillars of

our approach and in section five we give proof of

concept by describing an implemented prototype.

We conclude in section six and give an outlook on

future work.

2 MOTIVATING SCENARIO

“Contracts exist because separate legal entities that

decide to form a relationship with each other need

some formal record of understanding regarding the

nature of the relationship and their respective rights

and obligations“ (IACCM 2007). Motivating

scenario for our approach is a large machine

manufacturer with several regional subsidiaries all

over the world. The enterprise as a whole as well as

each subsidiary has hundreds of contracts with

suppliers, customers, sub-contractors, etc. Contract

Management is considered one of the top ten risks

an enterprise must face (Grosse-Ruyken & Wagner

2011). Therefore, all contracts are managed with a

CMS. The company’s own contracts are created

with the CMS, but the biggest number by far is

issued externally and thus paper copies are scanned

and then stored in the CMS. Many of the contracts

are voluminous and identification of relevant

information, such as obligations and conditions is

error prone, cumbersome and time consuming.

However, if this metadata is entered the CMS

provides simple workflow functionality to trigger

time related obligations like periodic payments (to

make or to receive), submissions of reports, etc.

Besides managing contracts with a CMS, the

machine manufacturer mandated an information

provider for monitoring news about business

partners, competitors, suppliers, etc. A risk manager

is in charge of evaluating the news with respect to

their impact on the company. This task is also time-

consuming as well as time-critical and error-prone

(with respect to completeness of evaluation).

To improve contract capturing, metadata

generation and obligation management, the tasks

should be automated.

3 BACKGROUND AND RELATED

WORK

Although the importance of contract management is

well-known in the economy, little scientific research

has been done on that topic. Contract management

has been addressed in the European integrated

project TrustCoM (Wilson, 2007), that aims to

develop a framework for trust, security and contract

management in dynamic Virtual Organisations

(Dimitrakos et al., 2004). “Trust between VO

[Virtual Organisations] members can be supported

by each being transparently aware of the obligations

and performance of others, so that business risks are

both mitigated, and monitorable” (Wilson et al.,

2006). There are two main differences to our

approach: Firstly, TrustCoM obligation (policies)

are modelled in the form of Event-Condition-Action

rules which define how the VO should adapt to

failures, changes in requirements, security events,

etc. Secondly, TrustCoM starts from contract

creation based on (structured) templates. We

consider that ideal but oversimplified. Many

companies already have templates, approved by their

legal department, which they are obliged to use.

Even so, many commitments remain imprecisely

described in contracts, for example what efforts the

mitigation duty requires or what point in time the

SemanticallyEnrichedObligationManagement-AnApproachforImprovingtheHandlingofObligationsRepresentedin

Contracts

obligation arises (Goetz and Scott, 1983). In our

approach we address these issues as we start from

unstructured contract documents and describe

obligations semantically instead of transforming

them.

A well-known approach for describing entities of

an enterprise semantically is in terms of an ontology.

Bertolazzi et al. (2001) analysed and compared

existing ontologies, namely the Toronto Virtual

Enterprise (TOVE) and The (Edinburgh) Enterprise

Ontology (EO) with their own proposal for a Core

Enterprise Ontology (CEO). Leppänen (2005)

introduced a context-based enterprise ontology and

referred in his contribution in addition to TOVE and

EO to the REA Enterprise Information System. Most

recently, (Thönssen and Wolff, 2010) introduced a

ContextOntology for dealing better with change in

enterprises.

Whereas the term ‘ontology’ emerged in the

context of Artificial Intelligence and later in the

World Wide Web, particularly of the Semantic Web

(Dietz, 2006), roughly at the same time enterprise

architecture' became generally known as a

management topic in the end of the 1980ies

(Matthes, 2011). Contrary to enterprise ontologies,

which are concrete representations of (generalized)

enterprise architectures developed to be re-used in

enterprises (Uschold et al., 1998), adopted and

enhanced to the enterprise’s specific needs,

Enterprise Architecture Frameworks (EAF) “provide

the guidance and rules for developing, representing,

and understanding architectures” (DoDAF, 2007, p

4).

Kang et al. (2010), Hinkelmann et al. (2010) and

Thönssen (2010) suggested relating an enterprise

ontology to an Enterprise Architecture Framework

in order to increase the quality of the enterprise

ontologies, for example with respect to

completeness. Our approach is based on ArchiMate,

a standard that not only provides guidance but

comprises a lightweight and scalable modelling

language for architecture descriptions (The Open

Group, 2009). Since ArchiMate’s representation

language is based on the UML 2.0 notation for class

diagrams the ‘meaning’ of the entities is not

described. “A meaning […] is a specialized

description that aims to clarify or stipulate a

meaning. […] Typical examples of meaning

descriptions are definitions, ontologies, paraphrases,

subject descriptions, and tables of content” (The

Open Group, 2009).

Despite the consent about using an ontology for

describing meaning no agreement has been achieved

yet on the appropriate level of formalization and the

degree of formality (Fox and Grüninger, 1998). Fox

and Grüninger (1998) regard an enterprise model as

the computational representation of the structure,

activities, processes, information, resources, people,

behaviour, goals, and constraints of an enterprise.

This means that the enterprise ontology should be

represented in such a way that a machine can

process it. Because ArchiMate’s original

representation language is not expressive enough to

achieve that, a more formal representation is needed

for our purpose, like for example RDF(S) or OWL

(Yu, 2011).

Having enterprise objects represented in an

ontology, for example the business object ‘contract’

and related context information like business actor

‘contract partner’ and product ‘Service Level

Agreement’, allows the addition of background

information to a contract. In other words, a contract

document and its metadata can be stored in a CMS

but the business object ‘contract’ and its context are

stored in the enterprise ontology. That leads to the

issue of relating databases to ontologies, a

requirement that has been investigated from the very

beginning of the semantic web (Spanos et al., 2011).

Approaches to combine relational databases (RDB)

and ontologies have become known as ‘database to

ontology mapping problem’, or more generally

characterized as ‘object-relational impedance

mismatch problem’ (Spanos et al., 2011). The

problem that has to be solved lies in the structural

difference of the relational and object-oriented

models. It has been studied from different points of

view for various kinds of reason (Auer et al. 2010),

like semantic annotation of dynamic web pages,

heterogeneous database integration, mass generation

of Semantic Web data or ontology learning (Spanos

et al. 2011). Sahoo et al. (2009) distinguish between

‘Automatic Mapping Generation’ and ‘Domain

Semantics‐driven Mapping Generation’. Whereas

the first method directly maps RDB and RDF

schemas, the latter considers “domain semantics that

are often implicit or not captured at all in the RDB

schema” (Sahoo et al., 2009, p 5). As the focus of

our research here is not on the mapping, we refer to

some excellent papers on the subject (e.g. Barrasa et

al., (2004), Kontchakov et al., (2010) and Spanos et

al., (2011)). We also refer to the W3C RDB2RDF

Working Group who provides many publications on

automatic mapping, for example a strategy for

directly mapping relational data to RDF (Arenas et

al., 2011), and a language specification (R2RML) to

express customized mappings from relational

databases to RDF datasets (Das et al., 2011).

For our approach, Direct Mapping (DM) is

KMIS2012-InternationalConferenceonKnowledgeManagementandInformationSharing

sufficient as it is performant, simple and easy to

implement. Direct Mapping defines an RDF graph

representation of the data in any relational database

with a set of common datatypes (Arenas et al.,

2011). The DM technique entails the transformation

of relational database data and schema into an RDF

graph which is called the direct graph. The relational

tables are mapped to classes in an RDF vocabulary,

and the attributes of the tables to properties in the

vocabulary (Hert et al., 2001). This technique has

been introduced by the RDB2RDF working group

(W3C Working Group, 2011).

Our approach carries research further with

respect to modelling the context of a contract in

terms of an ontology that represents enterprise

objects in way that is machine executable. Taking a

standard of an enterprise architecture description as

a basis, i.e. formalizing and enhancing ArchiMate, is

a new approach to represent the background

information needed for event based obligation

management.

4 ENHANCING CONTRACT

MANAGEMENT

Our approach comprises three parts: contract

segmentation and classification, metadata creation,

and obligation monitoring. Because of the limited

space we focus on obligation management and only

briefly introduce the other two parts; they are simply

pre-requisites but our approach would work as well

with manually entered metadata.

4.1 Automatic Contract Segmentation

and Classification

In order to facilitate the problem of metadata

creation especially for large contract documents a

contract is automatically split into disjoint segments.

Paragraph numbers and titles are recognized and the

separated parts are stored for further processing.

Figure 2: Contract segments.

Figure 2 shows the different parts of a contract

document.

Contract segmentation is implemented in a

commercial third party product for layout analysis to

identify paragraph numbering based on regular

expressions. After that, each of the paragraphs is

classified with respect to the obligation type, e.g.

finance, report, notification. Classification is done

by a Support-Vector-Machine (libSVM, cf.

http://www.csie.ntu.edu.tw/~cjlin/libsvm/). Para-

graphs that are not numbered, like introduction and

closing section or header and footer, are omitted as it

is unlikely that they describe obligations.

4.2 Semi-automatic Metadata Creation

For the contract as a whole as well as for its

paragraphs metadata are automatically extracted,

e.g. contract partner, contract beginning, contract

end, applicable law. For information extraction

GATE (an open source solution for text processing

cf. http://gate.ac.uk/overview.html) is used and some

JAVA web-services. In addition to metadata for the

whole contract particular metadata is created for

single paragraphs, e.g. obligation type, trigger, dates

and conditions. For this we also use regular

expressions to extract due dates, conditions and

triggers (time, period or event).

The analysed contract document, its paragraphs

plus the created metadata are stored in an XML-file

for further editing. In the DokLife research project

for example, which is funded by the Federal Office

for Professional Education and Technology OPET

(Project KTI Nr. 10902.2 PFES-ES des

Bundesamtes für Berufsbildung und Technologie)

the file is imported into a commercial CMS (cf. to

the project’s Web-Site URL: http://www.doklife.ch

for more information). Within the CMS for each

obligation the text-segment and its metadata are

displayed and the user can accept or correct it.

Figure 3: Paragraph example with Metadata.

SemanticallyEnrichedObligationManagement-AnApproachforImprovingtheHandlingofObligationsRepresentedin

Contracts

Figure 4: Excerpt of ArchiMate concepts.

Figure 3 depicts an example of a simplified

paragraph recording the obligation regarding force

majeure events plus the automatically created

metadata. The paragraph is only one from an

average of about 120 paragraphs extracted from a

single contract. The information extracted from the

paragraph is indicated by a rectangle. As shown,

some of the obligation’s metadata can be extracted

(obligation trigger, obligation condition, due date),

obligation type is provided by the SVM, and

obligation provider and receiver are created by

resolving the information ‘a party’ (which can be the

contractor, here Enterprise X, or the contractee, here

Company Y).

Contract segmentation and classification, and

information extraction build the basis for improving

obligation management.

4.3 A Broader View on Contract

Management

To improve obligation management a contract

document is considered a representation that realizes

a business object (The Open Group, 2009) and “A

business object is defined as a unit of information

that has relevance from a business perspective”. The

quotation is taken from the ArchiMate framework,

standardized by the The Open Group (2009). We

adopted that notion and consider a contract

document a representation that realizes a contract

business object and one or more obligation business

objects. In ArchiMate, business objects are related to

business behaviour elements, such as business

events, to business roles and business actors. With

that all context information necessary for dealing

with event-based obligations, recorded in contract

are met.

For our purpose we refined the existing

ArchiMate concepts with respect to creating sub-

concepts and additional relations.

Figure 4 depicts a simplified excerpt of concepts

and relations, depicted in the ArchiMate notation,

relevant for our approach. We added two

BusinessObjects Contract and

Obligation that are realized in the

ContractDocument (which is a Represent-

ation). A BusinessObject is associated to a

BusinessEvent; Bankruptcy,

MoratoriumPetition, Injunction and

Merger&Acquisition are (instances of)

business events. A Contract is concluded with a

BusinessActor with the assigned

BusinessRole of a ContractPartner.

Conceptually we add three top-level concepts

(with its sub-concepts) time, location and

event. With this we are able to model events,

KMIS2012-InternationalConferenceonKnowledgeManagementandInformationSharing

externally to an enterprise, for example ActOfGod

(Hurricane, Tsunami, etc.) or ManMade (war, riots,

etc.), and to relate it to BusinessObjects in

order to infer obligations triggered by force majeure

events.

Further development of ArchiMEO followed Fox

& Grüninger (1997) methodology on elaborating

competency questions.

Example of an informal Competency Question:

Given an environmental disaster

(earthquake, hurricane, tsunami,

etc.) and some constraints (location

or about a business relationship),

which business partners are

concerned?

From the Competency Questions content of

ArchiMEO has been validated and further elaborated

as shown in Figure 4.

The Competency Questions are then rewritten in

a formal way using SPARQL (see chapter 5).

5 SERO

As a proof of concept we developed a prototype for

Semantically EnRiched Obligation management

(SERO). Pre-requisite for SERO is the enterprise

ontology and the results of contract segmentation

and metadata creation for ontology population. This

can be done automatically or manually.

The enterprise ontology used in SERO fully

comprises the ArchiMate entities but is enhanced

where necessary, as suggested in the standard (The

Open Group 2009), and detailed above. Since a

formal representation is needed the ArchiMate

language has been translated into OWL. The

enterprise ontology is named ArchiMEO to indicate

its roots in ArchiMate. ArchiMEO is modeled with

Protégé in OWL 2 QL dialect (it is also available in

RDFS) and actually comprises about 400 concepts

and 600 relations.

Currently the ontology is populated with a sub-

set of the metadata resulting from the automatic

contract segmentation, obligation classification and

information extraction, namely Contract-

Document, Contract, Obligation,

BusinessActor, Business-Role and

BusinessRelationship.

In the next phase Direct Mapping technique will

be implemented to relate the instances with the

entities stored in the relational database of the CMS.

For obligation management the ontology is

imported into a SESAME triple store. Querying of

the ArchiMEO ontology is realized in the SERO

prototype by a JAVA Swing Interface implementing

the OpenRDF Sesame API. The Application

connects to the Sesame Triple Store and uses

SPARQL queries, as exemplarily illustrated in

chapter 5.1, to receive the required information. To

simulate real world events the prototype interface

contains fields to specify type and location of the

occurring events. The depicted query in 5.1 presents

the data related to a specific Use Case, introduced

below, namely ‘Earthquake’ and ‘Fukushima’. Of

course, in SERO the implemented queries are more

generic, allowing the search for any location and

event stored in the Ontology. That is, via a graphical

user interface one can ask for an event to search for

affected business partners and if any contracted

obligations. The resulting Information is added to

JAVA objects and lists of objects such as

ContractDocument, Contract, Obligat-

ion and BusinessActor are displayed as

tangent contracts by the event in the GUI.

To illustrate our approach for improving the

handling of obligations represented in contracts, in

the following two use cases examples are provided,

based on the motivating scenario given above.

5.1 Use Case 1: Environmental

Disaster

Initial Situation: In a newspaper an environmental

disaster is reported and the machine manufacturer –

as global player – wants to know if business partners

are affected and if so, if obligations are due.

Analysis procedure: News, e.g. published on a

newspaper web-site, are analysed using the same

text analysis methods used for analysing the contract

documents. For simplification in the prototype, such

information is entered via a Graphical User Interface

(GUI); in use case 1 this could be ‘earthquake’ and

‘Fukushima’. Since in ArchiMEO events, e.g.

earthquake, tsunami, flood are modelled and also

information about locations, e.g. part of countries as

Fukushima or Tōhoku are stored, knowledge about

the type of the event (here: act of god) and the

location (here: Japan) can be inferred. Based on the

address of a business partner’s production plants,

headquarter, etc. it can easily be found out if he or

she is affected or not. The query can be refined with

respect to the closeness of a partner’s location to the

site of the disaster by exploiting geographical data

for distance determination.

If a business partner is affected the kind of

existing business relations can be inferred,

respectively, what role that partner plays, e.g.

supplier or consultant. Again, this information can

SemanticallyEnrichedObligationManagement-AnApproachforImprovingtheHandlingofObligationsRepresentedin

Contracts

be used to refine the query, as for example it would

be more important for the manufacturer if the

production plant of a supplier were in the epicentre

of the earthquake than the headquarters of a

consultant.

To find out whether obligations are due, the

business object obligation is queried for

obligation receiver and obligation provider. As

depicted in Figure 3 each party has the duty notify

the contract partner if a force majeure event affects

its performance. With our approach the business

partner affected by the earthquake in Fukushima is

automatically identified, his or her obligations can

be checked and, as an act of god like an earthquake

is a force majeure event, this obligation can be

identified also automatically. As result a warning

can be issued and the contract document in which

the obligation is represented can be retrieved from

the CMS.

Example of the query in SPARQL:

PREFIX eo:<http://ch.fhnw.eo#>

PREFIX rdf:<http://www.w3.org/1999/

02/22-rdf-syntax-ns#>

PREFIX top:<http://ch.fhnw.top#>

PREFIX rdfs:<http://www.w3.org/2000/

01/rdf-schema#>

SELECT ?businessActor ?eventType

?eventParent ?obligation ?role ?location

?partCountry ?locationCountry ?contract

WHERE {

Eo:Earthquake rdf:type ?eventType.

?eventType rdfs:subClassOf ?eventParent.

{ ?businessActor

eo:businessActorIsSituatedInLocation

?locationCountry.

?locationCountry rdf:type top:Country.

} UNION { ?businessActor

eo:businessActorIsSituatedInLocation

?location

{ { ?location top:cityIsLocatedInCountry

?locationCountry } UNION {

?location

top:cityIsLocatedInPartOfCountry

?partCountry.

?partCountry

top:partOfCountryBelongsToCountry

?locationCountry. } }

}

?businessActor

eo:businessActorHasAssignedBusinessRole

?role.

?businessActor

eo:ibusinessActorPerformsObligation

?obligation.

?obligation

eo:obligationIsAgreedInContract

?contract.

FILTER(?location = eo:Fukushima||

?partCountry = eo:Fukushima ||

?locationCountry = eo:Fukushima)

}

5.2 Use Case 2: Bankruptcy and

Dislocation

Initial situation: An information service provider

gives notice that a company filed bankruptcy in one

country but at the same time opens a new production

plant in another country. The machine manufacturer

wants to know what consequences this has for him.

Analysis procedure: The provided information is

analysed and ArchiMEO is queried for obligations

due in case of bankruptcy for that very business

partner. Whereas this part of the query is easy to

execute, finding out obligations related to the

production site is not. In SERO it can be done by

inferring information from the location. Assume the

production site has been in Singapore and is now

moved to Vietnam; the manufacturer is located in

Switzerland. Since Switzerland has a free trade

agreement with Singapore but not with Vietnam, the

reason for the supply contract is not valid any more.

In ArchiMEO legal bases for contracts can be

described and thus, in use case 2 not only the

obligation to notify the machine manufacturer about

the business event could be identified automatically

but also contracts affected by a change of legal pre-

requisites.

As a side effect, records management for

contract documents can be improved as well. If a

contract partner goes bankrupt all contracts become

invalid. The documents’ retention period starts by

then which can be triggered automatically based on

ArchiMEO.

With our approach we can improve the handling

of obligations represented in contract documents by

providing the missing link to external business

events (e.g. bankruptcy) or force majeure events

(e.g. earthquake). We can automatically identify

affected business partners, business relations,

business roles inferring the enterprise ontology and

trigger event-based obligations represented in

contract documents which can be stored in a

Contract Management System.

Our approach has been presented and reviewed

by two focus groups, namely the user group of a

commercial CMS and the consortium of the APPRIS

project. APPRIS (Advanced Procurement

Performance and Risk Indicator System) is a Swiss

national funded research project (KTI-Nr. 12102.1

PFES-ES) with the goal of integrating risk,

procurement and knowledge management into one

early warning system.

KMIS2012-InternationalConferenceonKnowledgeManagementandInformationSharing

6 CONCLUSIONS AND FURTHER

WORK

“According to 42% of enterprises in a new study the

top driver for improvements in the management of

contracts is the pressure to better assess and mitigate

risks” (Anon, 2007). With our approach, a first step

in this direction is taken, as the risk of overseeing

obligations and contracts affected by events

(business, acts of god or man-made) can be

minimized.

With the help of the SERO prototype the

feasibility can be (and has been) demonstrated that

obligations and contracts, triggered by business

events, can be identified automatically and thus,

contract management can be improved significantly.

Our approach will be used and further developed

in the APPRIS project. The functionality of SERO

will be used to detect warning signals based on risk

indicators related to events in order to address the

contract management risk.

Technologically, SERO will be improved with

respect to instance management. Whereas at present

the ontology is not yet physically linked to the

contract documents stored in a Contract

Management System, in the next version of SERO

instances of ArchiMEO will be related to entities of

of a CMS’s database via Direct Mapping.

Currently, all background information is fully

stored in ArchiMEO. In the future, Linked Open

Data sources like GeoNames will be integrated. The

GeoNames geographical database for example

covers all countries, and contains over eight million

place names (Wick n.d.). Also promising is the Open

Government Data initiative in Switzerland

(opendata.ch) with respect to integrating business

administration issues like laws and regulations.

Research will focus on how these sources can be

truly integrated into ArchiMEO instead of simply

mashing them up and displaying them alongside

each other (Bizer et al., 2009).

REFERENCES

Anon, 2007. Contract Management: Optimizing Revenues

and Capturing Savings. Contract Lifecycle

Management and the CFO. Available at:

http://findarticles.com/p/articles/mi_pwwi/is_200705/a

i_n19058810/ [Accessed April 19, 2012].

Arenas, M. et al., 2011. A Direct Mapping of Relational

Data to RDF. W3C Working Draft 20 September 2011,

(September 2011), pp.1-11.

Auer, S. et al., 2010. Use Cases and Requirements for

Mapping Relational Databases to RDF. W3C Working

Draft 2 June 2010, (June), pp.1-18. Available at:

http://www.w3.org/2001/sw/rdb2rdf/use-cases/

[Accessed January 26, 2012].

Bertolazzi, P. et al., 2001. An Approach to the Definition

of a Core Enterprise Ontology : CEO. In International

Workshop on Open Enterprise Solutions: Systems,

Experiences, and Organizations - OES-SEO 2001.

Rome, pp. 104-115.

Bizer, C., Heath, T. & Berners-Lee, T., 2009. Linked Data

- The Story So Far. International Journal on Semantic

Web and Information Systems (IJSWIS), 5(3), pp.1-22.

Dimitrakos, T., Golby, D. & Kearney, P., 2004. Towards a

Trust and Contract Management Framework for

dynamic Virtual Organisations. In Proceedings of the

eChallenges Conference (eChallenges 2004). Vienna,

Austria.

DoDAF, 2007. DoD Architecture Framework Volume I :

Definitions and Guidelines. Architecture, I(April

2007), pp.1-46.

Fox, M. S. & Grüninger, M., 1998. Enterprise Modeling.

AI Magazine, 19(3), pp.109-121.

Fox, M. S. & Grüninger, M., 1997. On Ontologies And

Enterprise Modelling. In International Conference on

Enterprise Integration Modelling Technology 97.

Springer. Available at: http://www.eil.utoronto.ca/

enterprise-modelling/papers/fox-eimt97.pdf.

Goetz, C. J. & Scott, R. E., 1983. Mitigation Principle:

Toward a General Theory of Contractual Obligation.

Virginia Law Review, 69(6). Available at:

https://litigation-essentials.lexisnexis.com/webcd/app?

action=DocumentDisplay&crawlid=1&srctype=smi&s

rcid=3B15&doctype=cite&docid=69+Va.+L.+Rev.+9

67&key=2c499ddc896515ef43456ba87a993188.

Grosse-Ruyken, P. T. & Wagner, S. M., 2011. APPRIS

Project Report, Zürich.

Hert, M., Reif, G. & Gall, H. C., 2001. A Comparison of

RDB-to-RDF Mapping Languages. In Proceedings of

the 7th International Conference on Semantic Systems.

Graz, Austria, pp. 25-32. Available at:

http://dl.acm.org/ft_gateway.cfm?id=2063522&ftid=1

054499&dwn=1&CFID=81605256&CFTOKEN=146

08054.

IACCM, 2007. Contract Management Software. Market

Sizing And Status Report,

Leppänen, M., 2005. A Context-Based Enterprise

Ontology. In G. Guizzardi & G. Wagner, eds.

Proceedings of the EDOC International Workshop on

Vocabularies, Ontologies and Rules for the Enterprise

(VORTE’05). Enschede, Netherlands: Springer Berlin,

pp. 17-24.

Sahoo, S.S. et al., 2009. A Survey of Current Approaches

for Mapping of Relational Databases to RDF. , pp.1-

15.

Spanos, D.-E., Stavrou, P. & Mitrou, N., 2011. Bringing

relational databases into the Semantic Web: A survey.

Semantic Web – Interoperability, Usability,

Applicability, 0, pp.1-41.

The Open Group, 2009. ArchiMate 1.0 Specification,

Available at: http://www.ncbi.nlm.nih.gov/pubmed/

SemanticallyEnrichedObligationManagement-AnApproachforImprovingtheHandlingofObligationsRepresentedin

Contracts

20087110.

Thönssen, B. & Wolff, D., 2010. A broader view on

Context Models to support Business Process Agility.

In S. Smolnik, F. Teuteberg, & O. Thomas, eds.

Semantic Technologies for Business and Information

Systems Engineering: Concepts and Applications.

W3C Working Group, 2011. RDB2RDF Implementations.

Available at: http://www.w3.org/2001/sw/rdb2rdf/wiki

/Implementations [Accessed January 25, 2012].

Wick, M., GeoNames. Available at: http://

www.geonames.org/ [Accessed April 22, 2012].

Wilson, E.M., 2007. TrustCoM Project Final Report V1,

Available at: ftp://ftp.cordis.europa.eu/pub/ist/docs/st/

trustcom-finalreport_en.pdf.

Wilson, M., Arenas, A. & Schubert, L., 2006. The

TrustCoM Framework for trust , security and contract

management of web services and the Grid - V2,

Available at: http://www.clrc.ac.uk/Activity/ACTIVIT

Y=Publications;SECTION=225.

Yu, L., 2011. Developer’s Guide to the Semantic Web

online., A. Springer. Available at:

<http://lib.myilibrary.com?ID=308236>

KMIS2012-InternationalConferenceonKnowledgeManagementandInformationSharing
