Constraint-programming Approach for Multiset and Sequence Mining

Pablo Gay, Beatriz L

opez and Joaquim Mel

endez

University of Girona, Campus Montilivi, P4 Building, E17071, Girona, Spain

Keywords:

Data Mining, Itemset Mining, Multiset Mining, Sequence Mining, Pattern Discovery.

Abstract:

Constraint-based data mining is a ﬁeld that recently has started to receive more attention. Describing a problem

through a declarative model enables very descriptive and easy to extend implementations. Our work uses a

previous itemset mining model in order to extend it with the capabilities to discover different and interesting

patterns that have not been explored yet: multisets and sequences. The classic example domain is the retailer

organizations, trying to mine the most common combinations of items bought together. Multisets would allow

mining not only this itemsets but also the quantities of each item and sequences the order in with the items

are retrieved. In this paper, we provide the background of the original work and we describe the modiﬁcations

done to the model to extend it and support these new patterns. We also test the new models using real world

data to prove their feasibility.

1 INTRODUCTION

Itemset mining, a problem originated in the study of

retailer organization databases, has been a major con-

cern in the machine learning community due its im-

pact on different areas, such as games, census, traf-

ﬁc accidents, among other (Rep, 2012). The learn-

ing objective is to ﬁnd the most common combina-

tion of products bought toghether. After itemset min-

ing, sequence (Agrawal and Srikant, 1995) and mul-

tiset (David and Nourine, ence) mining algorithms

have been developed. The importance of sequences

is shown in ﬁelds as recommendations (Burke, 1999),

web browsing (Cadez et al., 2000), health care (Zhang

et al., 2003) or music (Brand, 1998) for instance. In

sequence mining, item order matters, while in multi-

sets item repetitions is taken into account.

The original itemset mining algorithm known is

Apriori (Agrawal and Srikant, 1994) and consists in

three phases. First, it builds an item lattice. Sec-

ond it scans the lattice looking for itemsets that have

at least a support of a user-speciﬁed threshold. And

third, and in order to build associational rules, builds

up the appropriate relationship between premises and

consequences. A similar process follows with se-

quences. Since the approach is bread ﬁrst search, it

is computationally expensive, and other authors have

been explored several alternatives to improve its efﬁ-

ciency. (Srikant and Agrawal, 1996) proposed the use

of taxonomies, some primitive data structures to count

the support of patterns, sliding windows to relax the

deﬁnition of frequent sequences, and time constraints

to discriminate whenever two elements of a transac-

tion belong to the same sequence or not. (David and

Nourine, ence) goes one step further by mixing se-

quences and multisets. All of these approaches are

procedural based, and they search in one way or an-

other a tree structure.

Recently, there has been an interest to use declar-

ative approaches for data mining (Bonchi and Luc-

chese, 2007). In the particular case of itemsets,

(De Raedt et al., 2008) proposes to use constraint

programming. Although constraint programming is

a well-studied ﬁeld in computer science, its use for

itemset mining had gone unnoticed until then. The

main achievement is the reformulation of the itemset

mining problem as a constraint satisfaction problem,

exploiting current and powerful solvers to ﬁnd out the

frequent itemset patterns. The framework proposed

at (De Raedt et al., 2008) is revisited in (De Raedt

et al., 2010), where the authors explore in deep the

formulation, propose models for frequent, closed, and

weighted itemset mining, and analyze the efﬁciency

gained with solvers. The constraint programming ap-

proach enables the extension, in a declarative manner,

of the data mining problem by the addition of new

constraints.

Our work concerns the extension of the previous

work of (De Raedt et al., 2010), to mine two different

kind of frequent patterns: multisets and sequences.

212

Gay P., López B. and Meléndez J..

Constraint-programming Approach for Multiset and Sequence Mining.

DOI: 10.5220/0004135302120220

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2012), pages 212-220

ISBN: 978-989-8565-29-7

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

Our ultimate goal is to provide a constraint program-

ming framework for frequent multiset and sequence

mining.

This paper is organized as follows. First, in Sec-

tion 2 we contextualize our research within some

other related work. Next, we provide in Section 3 the

basis of the constraint programming approach in (De

Raedt et al., 2010), that is then extended with our new

proposals in Sections 4 (multiset mining) and 5 (se-

quence mining). The experimental results and their

discussion is presented in Section 6. We end with

some conclusions and future work directions in Sec-

tion 7.

2 RELATED WORK

Constraint-based mining has been understood in fre-

quent itemset mining as the process of deﬁning con-

straints in the mining process. That means, that we

ﬁnd itemset patterns by constraining their length, du-

ration, gaps between adjacent items, preﬁxes, and so

on (Han et al., 2007). These methods follow a proce-

dural approach to ﬁnd out the frequent patterns. Our

work concerns on the use of the constraint program-

ming paradigm for mining frequent patterns, follow-

ing a declarative deﬁnition of the mining problem,

and letting the solvers ﬁnd the patterns, as in (De

Raedt et al., 2010).

An example of such systems is Molfea (De Raedt

and Kramer, 2001), which mines chemical structures

for sequences of atoms and bonds that are deﬁned

by some user criteria. These criteria are primitives

that represent fragments of the sequences of atoms

and may require having a minimum frequency on

the database. Another example is ConQuest (Bonchi

et al., 2009), a constraint-based querying system,

which interacts with the user to achieve the desired

learning results. MusicDFS (Soulet et al., 2006) is an-

other application example of a tool which implements

its own efﬁcient deep search ﬁrst algorithm to mine

constrained patterns. These kind of frameworks have

in common that they focus on the use of constraints in

the search process to improve mining results whereas

our approach focuses on create a model deﬁnition to

solve the problem of mining multisets and sequence

patterns using a constraint programming approach.

Other related works are in the ﬁeld of plan recog-

nition. The plan recognition problem (Schmidt et al.,

1978) takes as input a set of sequential actions per-

formed by some actors within the system and tries to

organize these actions in order to recreate the plan and

to infer the pursued goal. Moreover, the plans can be

considered sequential patterns if they are mined using

data from several actors. Recently, this community

has also moved to consider constraint-satisfaction for-

mulations to deﬁne their problem (Gal et al., 2012).

3 BACKGROUND

In this work, the modelization of frequent itemset

problem has been considered as starting point to ex-

tend it towards multiset and ordered itemset min-

ing. However, formalization can be generalized to

cover closed, maximal or typologies of itemset min-

ing problems.

As it has been commented above, our model is

based on the original and simpler design of (Guns

et al., 2011). It is a constraint programming approach

for itemset mining. We explain the essentials of the

method (the problem deﬁnition and the constraint pro-

gramming model) in this section to proceed afterward

with the deﬁnition of our models.

3.1 Problem Statement

The original motivation of itemset mining was on the

retailers, from which most of the terminology has

been derived. The input information is a database

containing all the products acquired by the clients ac-

cording to transactions. The output, the most frequent

items bought.

Let I = {1, . .. , m} be a subset of N that map

some items as for example {A, B, . . . , M} and A =

{1, . . . , n} a set of transaction identiﬁers. Now, let D

be a set of tuples with a transaction id t and an item-

set I. Finally, let D be the binary representation of D

such that:

= {(t,I) | t ∈ A, I ⊆ I , ∀i ∈ I : D

t,i

= 1} (1)

where D

t,i

is the position (t,i) of the D matrix. Us-

ing this deﬁnition itemsets can be discriminated using

their id and D contains 1s only when the itemset con-

tains that speciﬁc item. Table 1 shows an example of

this representations.

The occurrences of a speciﬁc itemset I within the

matrix D, that is, the coverage ϕ, is deﬁned as fol-

lows:

(I) = {t ∈ A | ∀i ∈ I : D

t,i

= 1} (2)

For example, using matrix D from Table 1,

({2, 3}) = {5, 8, 9, 10}.

The amount of transactions that contain the item-

set is denoted as support and is deﬁned as:

support

(I) = |ϕ

(I)| (3)

So using again the previous example,

support

({2, 3}) = |ϕ

({2, 3})| = |{5,8, 9, 10}| = 4

Constraint-programmingApproachforMultisetandSequenceMining

213

Table 1: Example of item database. Left: original itemset database. Central (D

): transactions database. Right (D): binary

representation.

A B C D

Transactions (id, Itemset) id 1 2 3 4

{C} (1, {3}) 1 0 0 1 0

{B} (2, {2}) 2 0 1 0 0

{A,C} (3, {1, 3}) 3 1 0 1 0

{B, D} (4, {2, 4}) 4 0 1 0 1

{B,C} (5, {2, 3}) 5 0 1 1 0

{C, D} (6, {3, 4}) 6 0 0 1 1

{A, D} (7, {1, 4}) 7 1 0 0 1

{B,C, D} (8, {2,3, 4}) 8 0 1 1 1

{A, B,C} (9, {1, 2, 3}) 9 1 1 1 0

{A, B,C, D} (10, {1, 2, 3, 4}) 10 1 1 1 1

Frequent itemset mining consists on ﬁnding all the

itemsets which support is equal or higher than a cer-

tain threshold θ. That is:

frequent itemsets = {I | I ∈ I , support

(I) ≥ θ} (4)

3.2 Constraint Programming Model

First of all, (Guns et al., 2011) deﬁne a boolean vari-

able I

for each individual item. Itemsets I are then

represented as a collection of this binary variables.

Another set of binary variables, T

, represent the trans-

actions of the set of T that cover a given itemset,

T = ϕ

(I). For example, transaction 8 of Table 1

is represented by the following setting of the binary

variables settings: I

= 0, I

= 1, I

= 1, T

= 1

for ϕ

(2, 3, 4).

Thanks to this new binary variables, the coverage

and support constraints are formulated. The coverage

constraints is modeled as follows:

T = ϕ

(I) ⇔ (∀t ∈ A : T

= 1 ↔

∑

i∈I

(1 − D

t,i

) = 0)

(5)

The second one, the frequency constrain, requires

computing if the sum of the binary vector T is greater

or equal to the θ threshold, as follows:

|T | > θ ⇔

∑

t∈A

≥ θ (6)

Therefore, the itemset mining from a constraint

programming approach consist on ﬁnding the set

(I, T )|I ⊆ I , T ⊆ A, T = ϕ

(I), |T | > θ (7)

4 MULTISET MINING

The previous section presented how to ﬁnd frequent

itemsets. This kind of patterns can be very useful,

since a lot of databases can be transformed into the bi-

nary representation shown at Equation 1. In the clas-

sical scenario, the retailer database, each row will be

considered as a client transaction and each column as

an item. Then the resulting itemset patterns are the

most common products bought together.

However, using this same scenario, we can see

that we could extract more information. Frequent pat-

terns at this point represent the products commonly

purchased together, but the amount of each product is

still unknown. We can know that beer and crisps are

bought together, but probably there is a proportional

relation among them, like for each six-pack of beer,

two bags of crisps. Consequently, the original prob-

lem deﬁnition and the model should be extended to

learn patterns with such property.

4.1 Problem Statement

Until now, we have been working under the assump-

tion that we were using sets of items called itemsets

that did not contain any item repeated. Now itemsets

can contain the same item more than once. Hence, we

need to modify also our description of D

and D to

use multisets:

= {(t,I) | t ∈ A, I ⊆ I , ∀i ∈ I , D

t,i

= Q

(I)} (8)

This new representation differs with the one at

Equation 1 when assigning the value of D

t,i

. In this

case instead of using a binary value to assert when-

ever the item exists or not in the itemset, we propose

the function Q

(I), which return the cardinal of the set

of all the items in I that are equal to i or, what is the

same, the Q uantity of i in I:

(I) = |{k ∈ I | k = i}| (9)

Table 2 show an example of how this new matrix

D is.

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

214

Table 2: Example of item database with repetition. Left

): transaction database, where items are repeated. Right

(D): new representation using repetitions.

, Itemset)

(1, {2, 3, 2})

(2, {4})

(3, {1, 3})

(4, {1})

(5, {2, 3})

(6, {4})

(7, {3, 4})

(8, {1, 2, 2, 3})

(9, {1, 2})

(10, {1, 2, 3})

A B C D

1 2 3 4

1 0 2 1 0

2 0 0 0 1

3 1 0 1 0

4 1 0 0 0

5 0 1 1 0

6 0 0 0 1

7 0 0 1 1

8 1 2 1 0

9 1 1 0 0

10 1 1 1 0

Since the input matrix now instead of containing

binary values it contains the speciﬁc amounts of items

in the transactions, the coverage deﬁnition (Equa-

tion 2) must change accordingly:

(I) = {t ∈ A | ∀i ∈ I, D

t,i

≥ Q

(I)} (10)

With this new deﬁnition we assure that support is

estimated properly, since itemsets with high amounts

of repeated items than the desired one provide support

but not vice versa. For example, {1, 3, 3} supports the

pattern {1, 3} but not the {1, 3, 3, 3} one. This new

deﬁnition does not affect the way support is estimated

(i.e. Equation 3), but we redeﬁne it for convenience,

since the coverage set to be taken into account is dif-

ferent:

support

(I) = |ϕ

(I)| (11)

Therefore, the multiset mining problem from a

constraint programming approach consists on ﬁnding

the set

frequent itemsets = {I | I ∈ I , support

(I) ≥ θ}

(12)

Observe that the problem deﬁnition for multisets

is still compatible with the original model since it is

equivalent to discover patterns from multisets where

at most there is one repetition for item.

4.2 Constraint Programming Model

According to the problem deﬁnition, the model main

extension is related to the coverage constraint. Now,

the instantiated vector T contain a 1 in the t

only if

the amount of each item i within a certain itemset I is

greater or equal in the t

transaction of the matrix D:

∀t ∈ A : T

= 1 ↔

i∈I

t,i

≥ Q

(I) (13)

Table 3: Output from the multiset mining.

A B C D

1 2 3 4 Support Itemset

0 0 0 1 3 {D}

0 2 0 0 2 {B,B}

0 2 1 0 2 {B,B,C}

1 1 1 0 2 {A,B,C}

1 0 1 0 3 {A,C}

0 1 1 0 4 {B,C}

0 0 1 0 6 {C}

1 1 0 0 3 {A,B}

1 0 0 0 5 {A}

0 1 0 0 5 {B}

The support constraint and the problem formula-

tion from the remain the same as in Section 3.2.

4.3 Example

Here we provide an illustrative example of the model

proposed. We use example provided in Table 2. The

θ threshold is 2 and it represents the 20% of the

database.

Thus, the multiset {B, B,C} has its representa-

tion in the D matrix as {0, 2, 1, 0}. To estimate the

coverage of {B, B,C}, all the transactions from D

must be checked to see if they meet the speciﬁcations

shown at Equation 10. Transactions 1 and 8 do, so

({0, 2, 1, 0}) = {1, 8}. The next step is calculat-

ing the support, so as it is the cardinal of the cov-

erage, support

({0, 2, 1, 0}) = |ϕ

({0, 2, 1, 0})| =

|{1, 8}| = 2. And ﬁnally, multiset {0, 2, 1, 0} will be

considered a frequent patterns since this support is

greater or equal to the previously speciﬁed θ.

Following the same procedure, multiset

{C, D} is represented as {0, 0, 1, 1} in D. Then,

({0, 0, 1, 1}) = {7} since 7 is the only transaction

that has elements C and D greater or equal to 1.

Finally, support

({0, 0, 1, 1}) = |ϕ

({0, 0, 1, 1})| =

|{7}| = 1, which obviously is lower than the θ thresh-

old an therefore it is not considered as a frequent

pattern.

All the frequent multiset patterns found for the ex-

ample are shown in Table 3.

5 SEQUENCE MINING

In this section we are considering itemsets with item

order information but without any repetition (see Ta-

ble 4).Back again to the retailers example, sequence

mining allows knowing the order in which items are

retrieved. Such knowledge can be useful for differ-

ent optimization purposes, as the product distribution:

Constraint-programmingApproachforMultisetandSequenceMining

215

Table 4: Example of ordered itemsets database. Left (D

transaction database. Right (D): representation including

order.

, Itemset)

(1, {4})

(2, {3, 2})

(3, {3, 1, 2})

(4, {1, 3, 2})

(5, {4, 1})

(6, {3, 4})

(7, {1, 2, 3})

(8, {3, 4, 2})

(9, {2, 4, 3, 1})

(10, {1, 4, 3, 2})

A B C D

1 2 3 4

1 0 0 0 1

2 0 2 1 0

3 2 3 1 0

4 1 3 2 0

5 2 0 0 1

6 0 0 1 2

1 2 3 0

8 0 3 1 2

9 4 1 3 2

10 1 4 3 2

the clients could ﬁnd a simpler route to gather ev-

erything or the store manager could introduce in the

mined routes products that usually are not bought by

the clients but they could be interested in.

5.1 Problem Statement

In this case, itemsets are ordered sets of items, so in

a certain itemset I, I

would be its n

item. Conse-

quently, the matrix D must be able to represent or-

der information. Our approach is similar to the ones

presented before, keeping the deﬁnitions as simple as

possible:

= {(t, I) | t ∈ A, I ⊆ I , ∀i ∈ I , D

t,i

= O

(I)} (14)

The main difference with Equation 1 is the binary

value assigned to D

t,i

to represent the existence of the

item in the itemset. Here we have replaced it with

the new function O

(I), where given a certain ordered

itemset I and a certain item i returns the position of i

within I, for example O

({2, 4, 3, 1}) = 2. The Order

function, O

(I), is the following:

(I) = k | ∃k ≤ |I|, I

= i (15)

The coverage constraint needs to be redeﬁned

too. In the original work and in our previous ex-

tension, coverage is a measure that estimates how

many times a combination of items or a quantity of

items is contained by the database. The new coverage

function we propose needs to change completely this

paradigm. Instead of counting the items, the items

must fulﬁll speciﬁc conditions between themselves.

That means that if we want to count the support of

a certain ordered itemset {C, A, B}, ﬁrst we need to

know which of the transactions in the database con-

tain items where the item C goes before A and B,

where item A goes after item C and before B and

where item B goes after items C and A, or what’s the

same, which transactions in the database follow the

order speciﬁed by the itemset. It is easy to see that

these conditions can be also considered rules or con-

straints, what makes the constraint-based deﬁnition an

excellent choice. The following equation shows how

simple is to represent this conditions:

(I) = {t ∈ A | ∀i, j ∈ I, i 6= j, (I

< I

) → (D

t,i

< D

t, j

)}

(16)

The new coverage represents the set of all the

transactions indices t where given all possible posi-

tions i and j (and i 6= j) within an itemset I, if item

appears before then item I

then in the item in the

position of the transaction must appear also before

the one at the j

Consistently, the support is deﬁned as follows:

support

(I) = |ϕ

(I)| (17)

Finally, the sequence mining problem from a con-

straint programming approach consists on ﬁnding the

set

frequent itemsets = {I | I ∈ I , support

(I) ≥ θ}

(18)

5.2 Constraint Programming Model

According to the problem deﬁnition, the coverage

constraint form is modeled as a constrained program-

ming approach as follows:

∀t ∈ A : T

= 1 ↔

i∈I

j∈I\{i}

< I

) → (D

t,i

< D

t, j

)

(19)

The model denoted by the above equation, comes

straightforward from Equation 16, but it has three

problems. The ﬁrst and most important one is the

following: the constraint checks the condition (I

) → (D

t,i

< D

t, j

) and if D

t,i

is equals to 0 (i.e. the

item does not belong to the transaction), a true as-

sertion will be occur. Consequently, we add an addi-

tional condition to the constraint, as follows:

∀t ∈ A : T

= 1 ↔

i∈I

j∈I\{i}

< I

) → . . .

. . . → ((D

t,i

> 0) ∧ (D

t,i

< D

t, j

))

(20)

The second problem relies in the constraint deﬁ-

nition itself. It looks for how many transactions ful-

ﬁll some denoted conditions between items, so the re-

sulting patterns will have at minimum two items. In

the case that patterns with single items were requested

the procedure becomes the same one as the previous

model: counting occurrences of items. In that case,

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

216

Table 5: Output from the sequence mining.

A B C D

1 2 3 4 Support Itemset

1 2 0 0 4 {A,B}

1 0 2 0 3 {A,C}

1 3 2 0 2 {A,C,B}

0 1 2 0 2 {B,C}

2 0 1 0 2 {C,A}

0 2 1 0 5 {C,B}

0 0 1 2 2 {C,D}

2 0 0 1 2 {D,A}

0 2 0 1 2 {D,B}

0 0 2 1 2 {D,C}

the previous model should be used adding a new con-

straint limiting the pattern length like |I| = 1 can be

used.

The third problem is that any solver fed with this

model could return malformed patterns. If we look

back to Table 4, the ordered itemset {0, 2, 1, 0} can

be considered a pattern since half of the transac-

tions contain this sequence. What makes inconsistent

the model is that the solver could return {0, 2, 1, 0},

{0, 3, 1, 0} or {0, 3, 2, 0} as well since we are check-

ing the transactions precedences without any point of

reference. All three of them have the same meaning:

that the item C has a lower value of than item B so

therefore it goes before, but only the ﬁrst one should

be returned. An auxiliary constrain like ∀i ∈ I, i ≤ |I|

limiting the maximum value that the items can have

should be more than enough to avoid this.

Finally, the support constraint and the problem

formulation from the remain the same as in Section

3.2.

5.3 Example

To provide an illustrative example of our mode, we

use the data shown in Table 4. We assume the thresh-

old value: θ = 2

Like in the previous example, the ﬁrst thing to

do is to translate the itemset to match the represen-

tation from Table 4. If we choose {C, B} (transac-

tion 2), then its representation is {0, 2, 1, 0}. If we

what know if it is a frequent pattern, from Equa-

tion 16, item C has a lower value (goes before)

than item B, and all the transactions in matrix D

that contain a lower value in item C than in item

B support this itemset. That is, ϕ

({0, 2, 1, 0}) =

{2, 3, 4, 8, 10}. Consequently, through Equation 17,

support

({0, 2, 1, 0}) = |{2, 3, 4, 8, 10}| = 5 and

since it is a value greater than the θ speciﬁed it is con-

sidered a frequent pattern.

All the frequent sequence patterns found for the

example are shown in Table 5.

Table 6: Multiset patterns.

Support Pattern

10% 2x frontpage, 2x tech, 1x msn-sports

12% 1x msn-sports

12% 1x frontpage, 1x news, 1x business

21% 1x news

21% 3x frontpage

22% 1x local

23% 1x tech

26% 1x on-air

32% 2x frontpage

51% 1x frontpage

6 EXPERIMENTATION

In order to test our approach with real data, the UCI

(Frank and Asuncion, 2010) dataset corresponding

to the MSNBC anonymous web navigation has been

used.

6.1 Experimental Setup

The raw information provided by the dataset con-

sist on 1000000 data lines, each one is the activity

of a user session and contains a sequence of num-

bers from 1 to 17 that represents the category of the

web page that was loaded. For instance the sequence

{2, 4, 4, 4, 3} means that the user loaded the “news”

section, then loaded three times the “local” news and

ﬁnally loaded the “technology” section.

The original work presented at (Guns et al.,

2011), used an implementation based in Essence lan-

guage (Frisch et al., 2008), but we have adopted a

solution using MiniZinc (Nethercote et al., 2007) be-

cause it allows the speciﬁcation of models using natu-

ral mathematical-like notation, speeding up our work.

6.2 Multisets Mining Resuts

As the original data from MSNCB.com contains re-

peated items per each transaction, so it can be used to

test our multiset model. First of all the database needs

to be ﬂattened into the matrix representation shown in

Section 4. That means that given the 17 different pos-

sible categories, a multiset {2, 4, 4, 4, 3} needs to be

transformed into {0, 1, 1, 3, 0,

0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0}. On the other hand, for

our testing experiments we have used only the ﬁrst

100 data entries.

Table 6 shows some of the patterns found. The

most common behavior found within the explored

data is to open the web front page, since 51% of users

loads it. Opening the front page is a rather common

Constraint-programmingApproachforMultisetandSequenceMining

217

way to start the browsing, but with our extension we

can know how many of them revisit this front page.

Results show that 32% of users during its web explo-

ration open a second time the front page and also that

a 21% opens it three times. If we don’t mind to re-

duce the support, we can ﬁnd that 10% of explored

users open twice the front page, twice again the tech-

nology page and also read the msn-sports.

Using the original approach, these patterns would

have been found too, but without knowing how many

times the users visit the pages. This proofs that there

is still more information to mine than just the common

pages browsed in the same session. Despite that we

have worked with little subset of information, the con-

clusions of our results can be considered quite similar

to previous works focused in the visualization of the

sequences with this database (Cadez et al., 2000): af-

ter the front page, tech an local sections recive a lot of

user visits.

6.3 Sequence Mining Results

Regarding sequence mining, the MSNBC data we

have used only the ﬁrst 100 data lines.

In Table 7 we present some of the patterns found.

In this case the support is not as high as in the pre-

vious example, but the sequences are still interesting.

The most common sequence followed by the 5% of

the explored users consists in loading ﬁrst msn-sports

and then the sports ones, which are obvious related

making a sensible pattern. The second most common

sequence is also reasonable, since 4% of the users ﬁrst

open the general news web page and after that the lo-

cal news.

We have to take under consideration that the found

patterns are quite short (no more than two consecutive

web sections) and that the support for these patterns is

not very hight (no more than 5%). That can be caused

by the original transformation we did in order to re-

move the repeated items, but still sustain the point that

there was still information that could not be mined us-

ing the existing constraint-based approaches. In this

case our transformation makes more difﬁcult to com-

pare our results with the ones at (Cadez et al., 2000),

but still there are some patters in common like the

{misc, local}.

6.4 Discussion

On one hand the experimentatrion done until now has

shown that the running time for these models depends

exclusively on the solver used. Minizinc has the ca-

pability of being a high level constraint programming

language what allows the users to change its under-

Table 7: Sequence patterns.

Support Pattern

3% frontpage, business

3% local, health

3% on-air, msn-news

3% frontpage, local

3% frontpage, news

3% tech, local

3% misc, local

3% on-air, misc

4% news, local

5% msn-sports, sports

lying solver easyly. Therefore, the implementation

of the models “as they are” in this paper resulted in

processing a set of data with a multipurpose solver

for several hours while a fully optimized one returned

the solutions with only less than a second of execu-

tion. Since the scope of this work does not involve

surveying different solver implementations we rele-

gate this task for future works. Another future work

regarding process optimization may be the reiﬁcation

of the already known contraints in order to simplyfy

the solver’s work allowuing it to work even faster.

On the other hand, the results presented in this sec-

tion show the feasibility of the constraint program-

ming paradigm for multiset and sequence learning.

Further experiments should be performed in other

scenarios, and particularly with big data to ﬁnd out the

limits of the methodology. However, the important

issue is that the learning process is not encapsulated

in a complex and static procedure, but provided in a

declarative way. This will allow the addition of new

constraints without the need of modifying the base

model, for instance, looking for closed or maximal

patterns instead of frequent.

7 CONCLUSIONS

In this paper we have explored some of the state-

of-the-art constraint-based mining and we have pre-

sented the modiﬁcations done to (Guns et al., 2011)

that extend the original model so now it can support

multiset and sequence mining.

Our model for multiset mining requires a change

on the deﬁnition of the coverage constraint that takes

into account the amount of items in the frequent pat-

tern. The second, sequence mining, has the handi-

cap of requiring more constraints in order to return

valid outputs but the learning problem is provided in

a declarative and simple way. We have shown exam-

ples of its application into toy problems to easily com-

prehend how the constraints works. Moreover, we

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

218

have applied the constraint programming models to

the MSNBC database from the UCI repository, hav-

ing successful results.

Our models where simple enough to work with

academic examples, but further experimentation is re-

quired, focussing on escalation (both: length of trans-

action and database size). In this sense, our research

is directed towards the use of reiﬁed constraints that

optimize the constraint programming model.

Note that we have presented two independent

models: one for mining item repetitions within item-

sets and another one or mining the itemsets with or-

der relations. The combination of both can lead us

into a complete sequence patter mining. Once the

combination is done, this model will be equiparable

to classical algorithms used nowadays like preﬁxspan

or clospan with the advantage of being declarative and

easily extensible.

ACKNOWLEDGEMENTS

This work is supported by the research projects

CTQ2008-06865-C02-02 and DPI2011-24929, and

the grant FPU-AP2009-2831, all of them funded

by the Spanish Government. The MSNBC dataset

has been extracted from the UCI Machine Reposi-

tory (Frank and Asuncion, 2010).

REFERENCES

(2012). Frequent itemset mining dataset repository. http://

ﬁmi.ua.ac.be/data/.

Agrawal, R. and Srikant, R. (1994). Fast algorithms for

mining association rules, volume 1215, pages 487–

499. Morgan Kaufmann.

Agrawal, R. and Srikant, R. (1995). Mining sequential pat-

terns. In Proceedings of the Eleventh International

Conference on Data Engineering, ICDE ’95, pages 3–

14, Washington, DC, USA. IEEE Computer Society.

Bonchi, F., Giannotti, F., Lucchese, C., Orlando, S., Perego,

R., and Trasarti, R. (2009). A constraint-based query-

ing system for exploratory pattern discovery. Informa-

tion Systems, 34(1):3–27.

Bonchi, F. and Lucchese, C. (2007). Soft constraint-based

pattern mining. Data Knowl. Eng., 60:377–399.

Brand, M. (1998). Pattern discovery via entropy minimiza-

tion. Technical report, MERL - A Mitsubishi Electric

Research Laboratory.

Burke, R. (1999). The wasabi personal shopper: a case-

based recommender system. In Proceedings of the

sixteenth national conference on Artiﬁcial intelligence

and the eleventh Innovative applications of artiﬁcial

intelligence conference innovative applications of ar-

tiﬁcial intelligence, AAAI ’99/IAAI ’99, pages 844–

849, Menlo Park, CA, USA. American Association

for Artiﬁcial Intelligence.

Cadez, I., Heckerman, D., Meek, C., Smyth, P., and White,

S. (2000). Visualization of navigation patterns on a

web site using model-based clustering. In Proceed-

ings of the sixth ACM SIGKDD international confer-

ence on Knowledge discovery and data mining, KDD

’00, pages 280–284, New York, NY, USA. ACM.

David, J. and Nourine, L. (Submitted to Theoretical

Computer Science). A generic algorithm for

sequence mining. 15 pages. http://www-lipn.univ-

paris13.fr/ david/old.version/articles/generation.pdf

[Accessed: 9.2.2012].

De Raedt, L., Guns, T., and Nijssen, S. (2008). Con-

straint programming for itemset mining. In Proceed-

ings of the 14th ACM SIGKDD international confer-

ence on Knowledge discovery and data mining, KDD

’08, pages 204–212, New York, NY, USA. ACM.

De Raedt, L., Guns, T., and Nijssen, S. (2010). Constraint

programming for data mining and machine learning.

In AAAI, pages 1671–1675.

De Raedt, L. and Kramer, S. (2001). The levelwise ver-

sion space algorithm and its application to molecular

fragment ﬁnding. In Proceedings of the 17th inter-

national joint conference on Artiﬁcial intelligence -

Volume 2, pages 853–859, San Francisco, CA, USA.

Morgan Kaufmann Publishers Inc.

Frank, A. and Asuncion, A. (2010). UCI machine learning

repository. http://archive.ics.uci.edu/ml.

Frisch, A., Harvey, W., Jefferson, C., Martinez-Hernandez,

B., and Miguel, I. (2008). Essence: A constraint lan-

guage for specifying combinatorial problems. Con-

straints, 13:268–306. 10.1007/s10601-008-9047-y.

Gal, Y., Reddy, S., Shieber, S. M., Rubin, A., and Grosz,

B. J. (2012). Plan recognition in exploratory domains.

Artiﬁcial Intelligence, 176(1):2270 – 2290.

Guns, T., Nijssen, S., and Raedt, L. D. (2011). Itemset min-

ing: A constraint programming perspective. Artiﬁcial

Intelligence, 175(12-13):1951 – 1983.

Han, J., Cheng, H., Xin, D., and Yao, X. (2007). Frequent

pattern mining: current status and future directions.

Data Min Knowl Disc, 15:55–86.

Nethercote, N., Stuckey, P. J., Becket, R., Brand, S., Duck,

G. J., and Tack, G. (2007). Minizinc: towards a stan-

dard cp modelling language. In Proceedings of the

13th international conference on Principles and prac-

tice of constraint programming, CP’07, pages 529–

543, Berlin, Heidelberg. Springer-Verlag.

Schmidt, C., Sridharan, N., and Goodson, J. (1978). The

plan recognition problem: An intersection of psychol-

ogy and artiﬁcial intelligence. Artiﬁcial Intelligence,

11(1-2):45 – 83. Applications to the Sciences and

Medicine.

Soulet, A., Kl

ema, J., and Cremilleux, B. (2006). Efﬁ-

cient mining under ﬂexible constraints through sev-

eral datasets. In D

zeroski, S. and Struyf, J., editors,

Proceedings of 5th International Workshop on Knowl-

edge Discovery in Inductive Databases, pages 131–

142, Berlin, Germany. Humbolt Universit

at Berlin,

2006, s.

Constraint-programmingApproachforMultisetandSequenceMining

219

Srikant, R. and Agrawal, R. (1996). Mining sequential

patterns: Generalizations and performance improve-

ments. In Apers, P. M. G., Bouzeghoub, M., and

Gardarin, G., editors, Proc. 5th Int. Conf. Extending

Database Technology, EDBT, volume 1057, pages 3–

17. Springer-Verlag.

Zhang, Z., Kwok, J. T., and Yeung, D.-Y. (2003). Paramet-

ric distance metric learning with label information. In

Proceedings of the 18th international joint conference

on Artiﬁcial intelligence, pages 1450–1452, San Fran-

cisco, CA, USA. Morgan Kaufmann Publishers Inc.

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

220
