Parsing and Maintaining Bibliographic References

Semi-supervised Learning of Conditional Random Fields with Constraints

Sebastian Lindner and Winfried H¨ohn

Institute of Computer Science, University of W¨urzburg, W¨urzburg, Germany

Keywords:

References Parsing, Bibliography, Conditional Random Fields (CRFs), Constraint-based Learning, Informa-

tion Extraction, Information Retrieval, Machine Learning, Sequence Labeling, Semi-supervised Learning.

Abstract:

This paper shows some key components of our workﬂow to cope with bibliographic information. We therefore

compare several approaches for parsing bibliographic references using conditional random ﬁelds (CRFs). This

paper concentrates on cases, where there are only few labeled training instances available. To get better label-

ing results prior knowledge about the bibliography domain is used in training CRFs using different constraint

models. We show that our labeling approach is able to achieve comparable and even better results than other

state of the art approaches. Afterwards we point out how for about half of our reference strings a correlation

between journal title, volume and publishing year could be used to identify the correct journal even when we

had ambiguous journal title abbreviations.

1 INTRODUCTION

In academic research it is good practice to compare

your own work with previously published documents

and acknowledge these in a reference section. In con-

sequence of the increasing number of scientiﬁc publi-

cations, there is a growing demand for an easy search-

ability of these previous works. Therefore the auto-

matic analysis of these publications and their biblio-

graphic references is getting more and more impor-

tant.

There already are a few search engines for this

kind of data like Google Scholar

or CiteSeerX

. In

order to search in single ﬁelds each reference has to

be divided into a set of ﬁelds or labels (e.g. author

or journal title). While the task of separating a refer-

ence string into different ﬁelds is simple for a human

reader, it is much more difﬁcult to automate, because

of the sheer diversity of reference strings.

First approaches in this ﬁeld of research tried rule

based algorithms, but these were too expensive to

maintain and too difﬁcult to adjust to other reference

domains. Because of that we use machine learning

techniques, which are much more easily adaptable to

other reference labeling domains (Zou et al., 2010).

In supervised machine learning already labeled ref-

erence instances are used to train a statistical model,

http://scholar.google.com

http://citeseerx.ist.psu.edu/index

which then can be used to label further reference

strings. Generating this labeled training data is a very

time consuming job.

Our focus lies on conditional random ﬁelds that

use additional prior knowledge in form of constraints

about the bibliography domain in addition to a few

already labeled instances for its training. In this sce-

nario a few labeled training instances and additional

unlabeled data for the training of constraints are used

in a semi-supervised training to achieve better results.

These constraints can easily be adapted for a new do-

main and the inclusion of valid constraints leads to a

signiﬁcant improvement in labeling accuracy.

In one of our projects with Springer Sci-

ence+Business Media we develop the web platform

SpringerMaterials

for an online presentation of pub-

lished documents. These contain a large amount of

bibliographic information. Because these documents

are divided into different books there are many differ-

ent citation styles. Due to that fact we can not use one

model for labeling all data, but we have to split the

reference data into smaller subsets and do a separate

labeling for each of these sets with only a few training

instances.

After separating the reference string into different

ﬁelds, we demonstrate own approaches to ﬁnd corre-

sponding long versions for journal title abbreviations.

http://www.springermaterials.com

233

Lindner S. and Höhn W..

Parsing and Maintaining Bibliographic References - Semi-supervised Learning of Conditional Random Fields with Constraints.

DOI: 10.5220/0004138602330238

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2012), pages 233-238

ISBN: 978-989-8565-29-7

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

The goal of this part of this paper is to reach a uniform

representation of reference string.

So we propose a workﬂow for dealing with bib-

liographic information that combines different ap-

proaches to analyze and clean bibliographic data.

2 REFERENCE PARSING

First of all we describe the problem to be solved. In

the ﬁrst step the reference string needs to be broken

down into tokens (i.e. split on whitespace). Each to-

ken in this sequence of input tokens x = {x

, x

, . . . x

}

then needs to be assigned a correct output label out of

a set of labels y = {y

, y

, . . . y

}. For example the

label AUTHOR has to be assigned to the name Meier.

The problem of assigning a label to a token of an

input sequence also is a common task in the research

area of natural language processing, for example in

part-of-speech tagging and semantic role labeling. So

the methods shown here can similarly be used in a va-

riety of other research areas as well (Park et al., 2012).

2.1 CRFs with Extended Generalized

Expectation Criteria

Linear-chain conditional random ﬁelds (CRFs) are

a probabilistic framework that use a discriminative

probabilistic model over an input sequence x and an

output label sequence y as shown in equation 1.

(y|x) =

Z(x)

exp

∑

(x, y)

, (1)

where in case of a linear chain CRF F

(x, y) are a

number of feature functions and Z(x) is a normal-

ization factor as described in (Sutton and McCal-

lum, 2006). CRFs outperform Hidden Markov Mod-

els (HMM) and maximum entropy Markov models

(MEMM) on a number of real world tasks (Lafferty

et al., 2001).

In the training process the parameters λ

for each

feature function are learned from the training data.

One approach for semi-supervised learning are CRFs

with Generalized Expectations (GE) as described in

(Mann and McCallum, 2010). For our experiments

we use MALLET (McCallum, 2002) which imple-

ments the CRF with Generalized Expectations. Gen-

eralized Expectation Criteria use prior knowledge in

form of a user provided conditional probability distri-

bution

ˆp

= p

| f

(x, k) = 1) (2)

given a feature f

. For example the probability for

a label AUTHOR of the word Meier should be 0.9.

So GE constraints express a preference for a speciﬁed

label given a certain feature.

We extended this version to allow more complex

constraints, though. In the original version only one

feature function is allowed for the target probability

distribution (compare equations 2 and 4). This way

more complex constraints can be used which depend

on multiple feature functions so that we could im-

prove our labeling results.

Given a set of training data T =

n

(1)

, y

(1)



, . . . ,



(m)

, y

(m)

o

the goal of training

a conditional random ﬁeld is to maximize equation

3 i.e. the log-likelihood (ﬁrst term) with a Gaussian

prior for regularization (second term) and a term to

take constraints into account.

Θ(λ, T, U) =

∑

logp



(i)



−

∑

2σ

−δD(q|| ˆp

(3)

where q is a given target distribution and

ˆp

= p

| f

(x, k) = 1, . . . , f

(x, k) = 1) (4)

with all f

(x, k) being feature functions that only de-

pend on the input sequence. D(q|| ˆp

) is a distance

function for the two provided probability distribu-

tions. In our case the Kullback-Leibler (KL) and L

distance are used and compared against each other.

The value δ is used to weight the divergence between

the two distributions. This way the expectations en-

courage the model to penalize differences in the dis-

tributions (Lafferty et al., 2001). In case of the L

distance a range-based version is used where a valid

probability range can be speciﬁed. If the compared

value is within this range the distance is 0.

2.2 CRF Features for Reference Parsing

For the task of tagging reference strings, we used a set

of binary feature functions similar to the ones used by

ParsCit (Councill et al., 2008). These can be divided

into the following four categories.

Word based Features. These features indicate

the presence of some signiﬁcant predeﬁned words

’No.’,’et al’, ’etal’, ’ed.’ and ’eds.’.

Dictionary based Features. These features indicate

whether a dictionary contains a certain word in the

reference string. We use dictionaries for author ﬁrst-

and lastnames, months, locations, stop words, con-

junctions and publishers.

Regular Expression based Features. Features that

indicate whether a word in the reference string

matches a regular expression. We use regular expres-

sion patterns for ordinals (e.g. 1st, 2nd.. .), years,

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

234

paginations (e.g. 200-215), initials (e.g. J.F.) and pat-

terns that indicate whether a word contains a hyphen,

ends with punctuation, contains only digits, digits or

letters, has leading/trailing quotes or brackets or if the

ﬁrst char is upper case.

Keyword Extraction based Features. We extract

keywords for a particular label in a separate step, so

that we can reuse this information when we deﬁne

constraints for the CRF. The corresponding training

feature then indicates whether a word is in an auto-

matically extracted list of keywords for a certain la-

bel.

We used the GSS measure mentioned in the pa-

per about automated text categorization (Sebastiani,

2002) for the purpose of automatic keyword extrac-

tion. GSS is thereby deﬁned as

GSS(t

, c

) = p(t

, c

) · p(t

, c

) − p(t

, c

) · p(t

, c

(5)

where p(t

, c

) for example is the probability that

given a label c

, the word t

does not occur under this

label.

The top GSS scored words and their correspond-

ing labels are then reviewed and used in a keyword

feature function and in our constraint set. Words with

less than three characters and stop words are speciﬁ-

cally excluded from the suggested keyword list.

Besides the already mentioned features we also

use a window feature with a size of 1 for training our

CRF. We also use a feature that indicates the position

of the word in the reference string itself. Therefore we

divide the reference string into six parts and give each

word a position number feature whose value indicates

its position from 1 to 6.

2.3 CRF Constraints for Reference

Parsing

Since we use Conditional Random Fields with ex-

tended Generalized Expectations for the reference la-

beling task, as shown in equation 3, we can choose

different distance metrics. We compare the KL-

divergence, where a full feature-label target probabil-

ity distribution q has to be speciﬁed, and the L

-Range

based distance.

We use the following constraints that depend on a

single feature function:

1. Words contained in the previously mentioned dic-

tionaries in section 2.2 should be tagged with

the corresponding label for that dictionary (ex-

ceptions: conjunctions, stop words, ﬁrst and last

names)

2. Extracted keywords for a label should be tagged

with that same label

3. Words that match a year pattern should be labeled

with DATE

4. Words that match a predeﬁned word should be

labeled with the corresponding label (see word

based features in section 2.2)

We encode these constraints into the model by

providing distributions q in the following kind:

For constraints 1.-3. we set the desired label prob-

ability to 0.8 and equally distribute the 0.2 among the

rest of the labels in the case of the KL-divergence as

the distance metric. When we use a L

-Range speciﬁ-

cation we deﬁne a target probability range from 0.8 to

1.0. We do this because ’1992’ for example could be

a page number. For constraint 4. the speciﬁed target

label has the probability 1.0.

We also use some more complex constraints that

take usage of the possibility to specify constraints

over multiple feature functions. These are:

1. Words that appear at the beginning of the refer-

ence string and are contained in the dictionary of

ﬁrst or last names should be labeled AUTHOR (for

the middle and ending of the reference string ED-

ITOR)

2. Conjunctions that appear at the beginning of the

reference string and are between words contained

in the dictionary of ﬁrst or last names should be

labeled AUTHOR (for the middle and ending of

the reference string EDITOR)

3. A number right to the word ’No.’ should be la-

beled VOLUME as the word ’No.’ itself

4. A year number right or left to a name of a month

should be labeled DATE as the month itself

We use the same target probability distribution as

in case of the constraints 1.-3. that use only one fea-

ture function. These more complex constraints show

that with our extension it is easy to deﬁne constraints

for CRFs with GE that take use of multiple features.

2.4 Experiments

As our test domain we used the Cora reference ex-

traction task (McCallum et al., 2000). This set

of citations contains 500 labeled reference strings

of computer science research papers. These cita-

tions contain the 13 labels: AUTHOR, BOOKTITLE,

DATE, EDITOR, INSTITUTION, JOURNAL, LOCA-

TION, NOTE, PAGES, PUBLISHER, TECH, TITLE,

VOLUME . We use this dataset to be able to compare

own labeling results with previous approaches.

2.4.1 Preparations

In order to get good labeling results for only a few

ParsingandMaintainingBibliographicReferences-Semi-supervisedLearningofConditionalRandomFieldswith

Constraints

235

training instances our ﬁrst step was to clean up the

dictionaries we had available. Therefore we ﬁrst re-

moved entries in the ﬁrst name, last name and loca-

tion dictionary that only contained two letters or less.

Then we made our dictionaries pairwise disjoint by

removing entries that are contained in more than one

dictionary.

Then we used the previously described keyword

extraction mechanism on several labeled citation

sources to gather important words. A brief excerpt

of these extracted keywords is shown in the following

list of labels with their extracted keywords:

BOOKTITLE: ’Proceedings’, ’Conference’,

’Symposium’, ’International’, ’Programming’ -

PAGES: ’pages’, ’pp’ - PUBLISHER: ’Press’ -

JOURNAL: ’ACM’

The list shows that GSS is able to extract several

useful keywords for different labels. So these not only

reduce the manual effort to get good labeling results,

but also ensure a better adaptability to other labeling

domains.

2.4.2 Labeling Results

We used the same test approach as described in

(Chang et al., 2007). Therefore we randomly split the

500 reference instances into three sets of 300/100/100

reference strings. We use the 300 as training, 100

as development and 100 as testing set. From the

set of 300 instances we randomly choose our refer-

ence strings for training with varying training set sizes

from 5 to 300. The 100 test instances are used in

the evaluation process. In the semi-supervised set-

tings we also use 1000 instances of unlabeled data

which we mostly took from FLUX-CiM and Cite-

SeerX databases which are available on the ParsCit

website.

The results are shown in Table 1. The column

Sup contains the results for a CRF with no constraints

that uses the same features as our approaches with

constraints. The results reported below are the aver-

ages over 5 runs with random training sets with cor-

responding size. The column GE-KL contains the

data for our Generalized Expectation with Multiple

Feature approach using the KL-divergence and last

column uses the L

-Range distance metric GE-L

Range. In this table we report token based accuracy

i.e. the percentage of correct labels.

We compare our method against other state of the

art semi-supervised approaches like the constraint-

driven learning framework in column CODL (Chang

et al., 2007), which iteratively uses the top-k-

inference results in a next learning step. We also

http://aye.comp.nus.edu.sg/parsCit/

Table 1: Comparison of token based accuracy for different

supervised/ semi-supervised training models for a varying

number of labeled training examples N. Results are an av-

erage over 5 runs in percent.

N Sup PR CODL GE-KL GE-

-Range

5 69.0 75.6 76.0 74.6 75.4

10 73.8 - 83.4 81.2 83.3

20 80.1 85.4 86.1 85.1 86.1

25 84.2 - 87.4 87.2 88.4

50 87.5 - - 89.0 90.5

300 93.3 94.8 93.6 93.9 94.1

compare our results with the results from CRF with

Posterior Regularization(Bellare et al., 2009). In Pos-

terior Regularization (column PR) the E-Step in the

expectation maximization algorithm is modiﬁed in

such a way that it also takes a KL-divergence into ac-

count(Ganchev et al., 2010). Dashes indicate that no

comparison data was available in the referenced pa-

pers.

As one can see our method has about the same

performance as other leading semi-supervised train-

ing methods. With a very limited amount of training

data the results are slightly worse than the other ap-

proaches but with more and more training instances it

outperforms most of the other techniques (e.g. with

N = 25). The provided constraints improve the la-

beling results in comparison to a CRF without con-

straints (column Sup). For N = 20 the improvement

for GE-L

-Range is 6 percentage points in token ac-

curacy. Our experiments show that we get the best

performances using GE constraints with multiple fea-

ture functions and L

− Range as distance metric.

The results also show that with an increasing num-

ber of training instances N, the positive inﬂuence of

constraints decreases. The traditional CRF is then

better able to extract the signiﬁcance of features for

a label by itself. We supposedly did not get the best

labeling result for N = 300 in comparison to PR be-

cause we used more complex constraints. These did

not have such a big inﬂuence on the labeling results

with a high number of training reference strings.

Table 2 shows precision, recall and the F

measure

for the label accuracy with 15 training instances using

GE with multiple feature functions and L

-Range as

distance metric.

As we can see there is a big difference in the F

value for different labels. Because of the deﬁned con-

straints AUTHOR and DATE labels have a high pre-

cision. NOTE labels are hard to identify and do not

occur very often in the training material. This results

in a rather poor labeling performance for NOTE la-

bels. Because some labels like authors are much more

common in reference strings, it is important to get a

good performance for such labels.

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

236

Table 2: Precision, recall and F1 measure for label accuracy

with N = 15 for a CRF with GE-L

-Range.

Label Precision Recall F

AUTHOR 98.5 98.6 98.6

DATE 95.0 82.5 88.3

EDITOR 92.3 52.8 67.2

TITLE 85.5 98.2 91.4

BOOKTITLE 84.3 84.1 84.2

PAGES 82.6 90.0 86.1

VOLUME 75.8 73.5 74.6

PUBLISHER 73.7 35.0 47.5

JOURNAL 71.9 66.6 69.1

TECH 67.5 25.7 37.2

INSTITUTION 62.4 43.4 51.2

LOCATION 51.4 60.0 55.4

NOTE 15.6 10.0 12.2

We also have to mention the fact that especially

in training runs with only few reference strings the

results might have a high standard deviation, because

of the diversity of the training material.

3 POSTPROCESSING

After our reference strings have been tagged, the ref-

erence data is split into ﬁelds like journal, author, title

and publishing year. But there could be different ab-

breviations and long versions for one journal name:

’Japan. J. Appl. Phys.’, ’Jpn. J. Appl. Phys.’ and

’Trans Japan Inst Metals’, ’Trans Jpn Inst Mct’. Jour-

nal title entries can also contain OCR errors like in the

second example.

When you search for a journal title or an author

name you want to get all occurrences of this particu-

lar entity, regardless of the exact term or abbreviation

used. Therefore it is important to collect all different

notations of this entity in order to trigger a search for

all these alternatives.

3.1 Journal Identiﬁcation

Our ﬁrst step is to use a string-based clustering for the

journal titles. This can however introduce conﬂicts,

e.g. when different journals have the same names or

abbreviations, but actually refer to different journals.

In this section we provide a method to resolve these

ambiguities.

For example the journal abbreviation ’Phys. Rev.’

for ’Physical Review’ is sometimes also used for

’Physical Review Letters’ or ’Physical Review B’. In

ﬁgure 1 you can see a plot for the volume-year combi-

nations of reference strings, which have ’Phys. Rev.’

as journal name. Although the reference data for the

two lines in this plot have the same journal abbrevia-

tion, they actually refer to two different journals with

Figure 1: Volume-year combinations for ’Phys. Rev.’.

different release schedules.

Therefore our disambiguation approach uses the

relationship between the ﬁelds journal name, volume

number and publishing date to separate same journal

title abbreviations. Since most journals are published

on a regular basis, there is a linear dependency be-

tween the volume number and publishing date for a

journal. In case of changes in the release schedule we

at least have line segments, which stand for periods

while the release schedules stay the same (see Figure

1 upper line).To detect these lines we use the Hough

transform (Duda and Hart, 1972).

This line detection is done for each of the string-

based clusters. After that we select the line which

contains the most data points. For this line we se-

lect the most common journal title in the cluster as

our representative title. Next we determine the cor-

responding start and end volume by selecting the

longest line segment which has only smaller gaps than

three years.

Because the extracted line segment may contain

data points from other journals (e.g. a crossing line

segment) we have to remove these data points from

our considered line segment. Therefore we take each

unique journal title from our cluster and remove all

of its data points if less than 25% in the year/volume-

range of the considered line segment lie on the line

segment itself. All journal titles that correspond to

remaining data points are extracted as synonyms for

that journal.

After that all references which match the found

characteristics are removed and the procedure is re-

peated until we are unable to ﬁnd further schedule

ranges which are longer than three years.

3.2 Journal Identiﬁcation Examples

We were able to extract 49 release schedules from our

data, which covers 48.4% of the 248407 input refer-

ence strings. Table 3 shows a few of this extracted

journal release schedules. Here example 1. and 3. are

correctly separated into different release schedules al-

though they often had the same abbreviation ’Phys.

ParsingandMaintainingBibliographicReferences-Semi-supervisedLearningofConditionalRandomFieldswith

Constraints

237

Table 3: Results of postprocessing.

No. Journal start end months between

month vol. month vol. consecutive volumes

1. Phys. Rev. B Jan. 1970 1 Jan. 2009 79 6

2. J. Am. Chem. Soc. Jan. 1900 22 Jan. 2008 130 12

3. Phys. Rev. Lett. Jul. 1958 1 Jul. 2008 101 6

4. J. Appl. Phys. Jan. 1941 12 Jan. 1984 55 12

Jul. 1984 56 Jan. 2006 99 6

Rev.’.

Since reference strings most of the time only con-

tain a publishing year but no month, this method can

just detect changes in the release schedule within this

accuracy. Likewise we are unable to detect changes in

the release schedule that are shorter than 3 years be-

cause we used this accuracy for our line segment de-

tection. We also have to note that in order for this pro-

cedure to work a large data set should be used where

single journal titles appear several times.

4 CONCLUSIONS AND FUTURE

WORK

We proposed a new method of parsing references

with constraints that can easily be adapted to new

domains of data. The labeling results show that the

proposed method’s performance is comparable to or

even performs better than other state of the art semi-

supervised machine learning algorithms. Afterwards

we demonstrated how bibliographic references can

be clustered using the novel approach of analyzing a

journal title, publishing month and release time span

correlation.

We want to concentrate future effort in the auto-

matic extraction of features and using constraints in

the inferenceprocess in addition to the learning phase.

Although we used a method for the automatic extrac-

tion of keywords for learning, we would like to in-

tegrate data from other web knowledge bases. We

would also like to investigate the possibility to auto-

matically categorize citation data and then use the op-

timal corresponding CRF for its labeling. Addition-

ally we are going to improve our string-based cluster-

ing methods since typical Levenshtein-distance based

metrics do not work well with abbreviations.

REFERENCES

Bellare, K., Druck, G., and McCallum, A. (2009). Alter-

nating projections for learning with expectation con-

straints. In Proceedings of UAI.

Chang, M.-W., Ratinov, L., and Roth, D. (2007). Guid-

ing semi-supervision with constraint-driven learning.

Proceedings of the 45th Annual Meeting of the Asso-

ciation of Computational Linguistics, pages 280–287.

Councill, I. G., Giles, C. L., and Kan, M.-Y. (2008). Parscit:

An open-source crf reference string parsing package.

In International Language Resources and Evaluation.

European Language Resources Association.

Duda, R. O. and Hart, P. E. (1972). Use of the hough trans-

formation to detect lines and curves in pictures. Com-

mun. ACM, 15(1):11–15.

Ganchev, K., Graa, J., Gillenwater, J., and Taskar, B.

(2010). Posterior regularization for structured latent

variable models. Journal of Machine Learning Re-

search, 11:2001–2049.

Lafferty, J., McCallum, A., and Pereira, F. (2001). Con-

ditional random ﬁelds: Probablistic models for seg-

menting and labeling sequence data. In Proceedings of

the Eighteenth International Conference on Machine

Learning (ICML-2001).

Mann, G. S. and McCallum, A. (2010). Generalized ex-

pectation criteria for semi-supervised learning with

weakly labeled data. Journal of Machine Learning

Research, 11:955–984.

McCallum, A. (2002). Mallet: A machine learning for lan-

guage toolkit. http://mallet.cs.umass.edu.

McCallum, A., Nigam, K., Rennie, J., and Seymore, K.

(2000). Automating the contruction of internet portals

with machine learning. Information Retrieval Journal,

3:127–163.

Park, S. H., Ehrich, R. W., and Fox, E. A. (2012). A hybrid

two-stage approach for discipline-independent canon-

ical representation extraction from references. In Pro-

ceedings of the 12th ACM/IEEE-CS joint conference

on Digital Libraries, JCDL ’12, pages 285–294, New

York, NY, USA. ACM.

Sebastiani, F. (2002). Machine learning in automated text

categorization. ACM Computing Surveys, 34(1):1–47.

Sutton, C. and McCallum, A. (2006). Introduction to Con-

ditional Random Fields for Relational Learning. MIT

Press.

Zou, J., Le, D., and Thoma, G. R. (2010). Locating and

parsing bibliographic references in html medical arti-

cles. International Journal on Document Analysis and

Recognition, 2:107–119.

KDIR2012-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

238
