An Ontology-based Framework for Syndromic Surveillance Method

Selection

Gabriela Henriques and Deborah Stacey

School of Computer Science, University of Guelph, 50 Stone Road East, Guelph, Canada

Keywords:

Ontology, Syndromic Surveillance, Algorithms, Optimization, Leveraging Knowledge.

Abstract:

Syndromic surveillance is the detection of a disease outbreak or bioterrorist attack. The process of surveil-

lance includes various steps: data collection, data analysis and result interpretation. The goal of syndromic

surveillance is to be able to make a rapid and accurate diagnostic of a potential outbreak. Method types range

from traditional statistical approaches to algorithms which have been adapted from other ﬁelds. With a variety

of options it can be difﬁcult selecting the method best suited for analysis on a given set of data. This paper will

focus on developing an ontology-based framework for selecting the best suited method(s) for data analysis,

focusing on the end-users perspective.

1 INTRODUCTION

Public health surveillance is the monitoring of bioter-

rorist attacks and disease outbreaks (Henning, 2004;

McDade and Franz, 1998). The term syndromic is

commonly used when discussing surveillance to em-

phasize its focus on early detection of an attack or out-

break in a geographical location. In the past decade,

the need for syndromic surveillance has become pri-

oritized; the early detection of an outbreak can pre-

vent massive illness and death (Henning, 2004; Mc-

Dade and Franz, 1998).

An ontology is a form of knowledge representa-

tion, it is used to represent a set of concepts and their

relationships within a domain. An ontology has the

ability to reason with the entities of a domain, and

can thus be used to describe the domain itself. Many

ontology-based frameworks have been developed in

various application areas to aid in data collection, or-

ganization, and classiﬁcation.

A variety of methods exist that can be used for

data analysis when determining whether a potential

outbreak has occurred within a region. Some of the

approaches include benchmark methods such as cu-

mulative sum, and moving average. Other meth-

ods include more non-traditional approaches that have

been adapted from different ﬁelds, such as neural

networks and genetic algorithms. Many syndromic

surveillance systems incorporate a variety of meth-

ods in their program, providing the end-user (analyst)

with different options to use for analysis. However,

these systems all have a different set of requirements

which may not be best suited for the technology cur-

rently used by the user. As well, the methods admin-

istered in a system may not be the most appropriate

for a set of data that needs to be analyzed.

This paper will start off by providing background

information on syndromic surveillance and existing

systems in section 2. Section 3 will provide a motive

and proposal for an ontology-based framework to aid

in the selection of a set of methods most appropriate

for a given set of data, focussing on the requirements

speciﬁed by an end-user. Section 4 will discuss two

disease detection examples, analyzing important pa-

rameters to be considered for the proposed system.

The paper will end off with future work directions

provided in section 5.

2 BACKGROUND

2.1 Syndromic Surveillance

Surveillance relies on three main steps: data collec-

tion, data analysis and result interpretation (Buck-

eridge et al., 2008). Data collection involves the gath-

ering of data from a variety of sources including hos-

pital emergency department (ED) records, over-the-

counter (OTC) pharmaceutical sales, and news reports

(Buckeridge et al., 2002; Lu et al., 2008; Crubezy

et al., 2005). In more recent years, the collection pro-

396

Henriques G. and Stacey D..

An Ontology-based Framework for Syndromic Surveillance Method Selection.

DOI: 10.5220/0004146003960400

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2012), pages 396-400

ISBN: 978-989-8565-30-3

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

cess has evolved from a time-consuming data gather-

ing process, to automatic real-time data collected and

distributed for analysis. Data analysis depends on the

process of data collection. In order for analysis to be

effective, a variety of methods should be considered

so that the best suited technique is selected.

Two key factors which must be taken into consid-

ered when discussing data collection for surveillance

are: timeliness and speciﬁcity (Buckeridge et al.,

2008). The timeliness of outbreak detection is very

important aspect in syndromic surveillance. A one-

day delay in detection could result in a loss of millions

of dollars, and massive illness and death(Buckeridge

et al., 2002). At present, new systems have automated

the process of gathering data in order to aid in the

speed of collection; public health departments now

have access to real-time data sets coming from a vari-

ety of different sources (Buckeridge et al., 2002; Tsui

et al., 2003).

Another factor that must be taken into considera-

tion when dealing with data collection, is the speci-

ﬁcity of the data. There are various sources from

which syndromic surveillance data is collected, some

of the forms of data include emergency department di-

agnostics, over-the-counter pharmaceutical sales, and

news reports (Buckeridge et al., 2002; Lu et al., 2008;

Crubezy et al., 2005). Generally, data can be grouped

into three different categories of sources: pre-clinical,

clinical pre-diagnostic and diagnostic (Buckeridge

et al., 2002). Pre-clinical data is gathered before go-

ing to a health care centre. This information typically

consists of school or ofﬁce absenteeism and is not

very speciﬁc. Clinical pre-diagnostic includes infor-

mation such as test orders, signs, symptoms and over-

the-counter sales. This information is timely, and rel-

atively speciﬁc. Diagnostics are data gathered from

test results and case interviews; these forms of data

are very speciﬁc however they are not timely. In or-

der for analysis methods to be accurate and effective,

it is important that the data is speciﬁc. However, due

to the need for timely detection, it has become more

popular to analyze clinical pre-diagnostic information

(Buckeridge et al., 2008). Since this data incurs a loss

of speciﬁcity during the collection process, some of

the algorithms used for detection may be ineffective

without taking extra precautions on how to interpret

the data in a classiﬁed manner.

2.2 Syndromic Surveillance Systems

Vast amounts of data are gathered in syndromic

surveillance. In order to perform a rapid and accurate

analysis, the most competent method must be used.

Aberration-detection algorithms are commonly used

for data analysis. These algorithms include statisti-

cal benchmark methods such as cumulative sums, re-

gression models, moving average calculations etc ...

along with knowledge-based algorithms such as ar-

tiﬁcial neural networks, genetic algorithms and on-

tologies. Some of these algorithms were developed

speciﬁcally for surveillance, while others have been

adapted from other ﬁelds.

2.2.1 Benchmark Methods & Systems

Systems that have been developed for syndromic

surveillance analysis include aberrancy-detection al-

gorithms. The Early Aberration Reporting System

(EARS) uses a variety of statistical aberration detec-

tion methods that have been developed by epidemi-

ologists to provide analysis for public health surveil-

lance data (Hutwagner et al., 2003). Another well-

known system for surveillance analysis is the Real-

time Outbreak and Disease Surveillance (RODS) sys-

tem. This system relies on real-time data collection

(Tsui et al., 2003). The data is saved to a database

where it then undergoes data warehousing techniques

to set up the data for analysis. The data is then an-

alyzed through various statistical aberrancy-detection

algorithms (Tsui et al., 2003). What’s strange about

recent events (WSARE) utilizes a bayesian network

to produce a baseline distribution that is then used to

compare against data (Wong et al., 2005). The soft-

ware SatScan analyzes spatial, temporal and space-

time scan statistics using the poisson or bernoulli

model based on requirements speciﬁed by the user

(Kulldorff, 2010).

2.2.2 Knowledge-based Systems

Syndromic surveillance requires the need for describ-

ing concepts, properties and relationships involved

in the process of data collection, analysis and re-

sult interpretation in order for a timely and accurate

evaluation to be performed (Buckeridge et al., 2002;

Buckeridge et al., 2008; Collier et al., 2010; Okhma-

tovskaia et al., 2009; Chapman et al., 2010). Ontolo-

gies are useful for describing, classifying and cate-

gorizing data. Due to this, a variety of ontologies and

ontology-based systems have been developed to aid in

the ﬁeld of syndromic surveillance. Some of the sys-

tems currently using ontologies includes bioSTORM

and BioCaster (Buckeridge et al., 2002; Buckeridge

et al., 2008; Collier et al., 2010).

BioSTORM (Biological Spatio-Temporal Out-

break Reasoning Module) is a software system which

aims at providing a variety of analysis techniques and

rapidly integrating a diverse data set in order to pro-

cess data analysis in a timely manner (Buckeridge

AnOntology-basedFrameworkforSyndromicSurveillanceMethodSelection

397

et al., 2002; OConnor et al., 2003). It contains three

ontologies in its framework: the data-source ontology,

the problem-solving ontology and the data-mapping

ontology. As discussed in Section 2, incoming data

can range from a variety of different sources, it is

common practice to gather a large amount of data

from all these sources in order to make-up for the

loss of speciﬁcity within the data (Buckeridge et al.,

2008). The data-source ontology aims at describ-

ing and unifying data from various sources and data

streams (Buckeridge et al., 2002; OConnor et al.,

2003). The problem-solving ontology contains a li-

brary of statistical based and knowledge based prob-

lem solvers for analyzing data (Buckeridge et al.,

2008). The problem solving methods are categorized

and annotated in the ontology. Lastly, the mapping

ontology, aims at providing the correct problem solv-

ing technique to use for a set of data source which

will result in efﬁcient data analysis(Buckeridge et al.,

2002; OConnor et al., 2003).

BioCaster is an ontology-driven system which

provides internet surveillance for potential outbreaks

found through global news reports (Collier et al.,

2010). The BioCaster ontology (BCO) aims at de-

scribing relations between terms in order to detect and

risk assess public health events, bridge the gap be-

tween (multilingual) grey literature and existing stan-

dards in biomedicine, mediate integration of content

across languages, and be available open source (Col-

lier et al., 2010).

Other ontologies that have been composed for

use in syndromic surveillance include: the syn-

dromic surveillance ontology (SSO) and the popu-

lation health ontology (Okhmatovskaia et al., 2009;

Chapman et al., 2010; Buckeridge et al., 2002). The

SSO aims at standardizing surveillance syndromes

and providing a classiﬁcation of these syndromes

(Okhmatovskaia et al., 2009; Chapman et al., 2010).

The population health ontology describes how popu-

lation level health data relate to the underlying state

of illness in a population (Buckeridge et al., 2002).

This ontology describes determinants of disease, dis-

ease, illness as well as temporal and spatial changes

in determinants, disease and illness (Buckeridge et al.,

2002).

3 PROPOSAL & DISCUSSION

The system aims at providing a recommendation of

methods to be used for syndromic surveillance data

analysis in a descriptive manner to an end user. This

will thus allow a user to interpret the recommended

method without the need of a technical background.

The methods provided will be recommended statis-

tics, algorithms or systems which can be used to efﬁ-

ciently detect a disease outbreak within a set of data.

The ontology will reason based on a set of parameters

provided by the user. Some of the parameters that

must be taken into consideration when developing an

ontology to describe an algorithm would be the data

source and input format, expected output format and

variables of importance to the end-user such as per-

formance, time, quality, and trust.

3.1 User Perspective

Systems are composed of many types of users rang-

ing from novice to experts. In the case of syndromic

surveillance, a typical end-user consist of a health an-

alyst or epidemiologist who analyzes a data set and

determines whether a disease outbreak is occurring.

There are various different methods which can be

used for conducting this analysis, some of these meth-

ods have been discussed in section 2.2. In order to de-

termine which method is best suited for a set of data,

the user performing the analysis would have to be an

expert in all systems. This is usually not the case,

for example, the user may be knowledgeable in var-

ious statistical methods which exist for analysis, but

may not consider other methods such as neural net-

works or genetic algorithms since they may not have

sufﬁcient background in the area to understand these

algorithms.

Determining which analysis approach to take is

also dependent on requirements speciﬁed by the user.

These requirements can be deﬁned based on what the

user believes will bring the most value to their analy-

sis. For example, a user can set one of their require-

ments as being performance measure. Different data

sets may require a different deﬁnition of performance;

OTC data can rely on how fast an outbreak was de-

tected, or the accuracy with which it was detected by

looking at false positives and false negatives attained

during the process. While ED data could also rely on

the timeliness of detection but also the speed at which

the geographical location of the outbreak was found

to occur.

It is important to consider a users perspective

when determining an algorithm best suited for anal-

ysis on a type of data-set. Deﬁning the need of the

user will aid in bringing value to their analysis. This

need will be deﬁned through requirements, presented

as input parameters in the proposed system.

3.2 Leveraging Knowledge

Leveraging knowledge describes how the transfer of

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

398

knowledge between two people is bi-directional and

that “knowledge grows when used and depreciates

when unused” (Firm et al., 2000). In order to take

full advantage of the existing syndromic surveillance

methods, the notion of leveraging knowledge is im-

portant to consider. For example, an epidemiologist

may look at data and determine a variety of bench-

mark statistics that they can pass through the data,

while a computer scientist could look at the same set

of data and come up with a list of algorithms which

could render interesting results. The epidemiologist

would not know to consider these algorithms before-

hand, and may not have a full-understanding of the

advantages they provide because they would not have

the technological background required.

For a system to be effective, it must be able to

eliminate the barrier formed and incorporate this no-

tion of bi-directional knowledge sharing. In other

words, by having the system describe each method

in a descriptive manner will aid in eliminating any in-

terpretation barrier previously encountered.

3.3 System Architecture

Figure 1 displays the proposed system architecture for

the procedure of gathering a set of methods best suited

for the data being analyzed. The following steps de-

scribe the overall process of the system.

1. Data is passed to the algorithm ontology. The data

includes information about the data specifying pa-

rameters such as input and expected output.

2. The reasoner classiﬁes the data based on relation-

ships deﬁned within the ontology.

3. A repository containing descriptions of algo-

rithms and systems is queried for the best suited

method(s) given the speciﬁcations provided.

4. & 5. A set of methods to use for analysis is at-

tained.

6. The recommended methods are described to the

user.

Figure 1: Proposed system architecture.

4 FUTURE WORK

The current proposed system evolves around an al-

gorithm ontology. This ontology will interpret a set

of parameters attained from an end-user, and recom-

mend method(s) best suited for the data set to be an-

alyzed. A better description of the parameters in-

volved is required for further development . As well,

a process for evaluating the system will also be in-

vestigated once further development has taken place.

Other factors will also be taken into consideration to

better the end-user experience, such as quality and

trust. Though the system will send a set of recom-

mended methods, the user would only use the method

if assured that it is reliable, and produces accurate re-

sults. Research will also be done on how to incorpo-

rate other existing ontologies to the system architec-

ture, such as the data source ontology found in BioS-

TORM, or the syndromic surveillance ontology.

ACKNOWLEDGEMENTS

I would like to thank Deb Stacey for her support and

guidance with this work.

REFERENCES

Buckeridge, D. L., Graham, J. K., O’Connor, M. J., Choy,

M. K., Tu, S., and Musen, M. A. (2002). Knowledge-

based bioterrorism surveillance. In AMIA Symp, pages

76–80.

Buckeridge, D. L., Okhmatovskaia, A., Tu, S., O’Connor,

M., Nyulas, C., and Musen, M. A. (2008). Un-

derstanding detection performance in public health

surveillance: Modelling aberrancy-detection algo-

rithms. Journal of the American Medical Informatics

Association, 15:760–769.

Chapman, W. W., Dowling, J. N., Baer, A., Buckeridge,

D. L., Cochrane, D., Conway, M. A., Elkin, P., Espino,

J., Gunn, J. E., Hales, C. M., Hutwagner, L., Keller,

M., Larson, C., Noe, R., Okhmatovskaia, A., Olson,

K., Paladini, M., Scholer, M., Sniegoski, C., Thomp-

son, D., and Lober, B. (2010). Developing syndrome

deﬁnitions based on consensus and current use. Jour-

nal of the American Medical Informatics Association,

17:595–601.

Collier, N., Goodwin, R. M., McCrae, J., Doan, S., Kawa-

zoe, A., Conway, M., Kawtrakul, A., Takeuchi, K.,

and Dien, D. (2010). An ontology-driven system for

detecting global health events. In Proceedings of the

23rd International Conference on Computational Lin-

guistics, COLING ’10, pages 215–222, Stroudsburg,

PA, USA. Association for Computational Linguistics.

Crubezy, M., O’Connor, M., Pincus, Z., Musen, M. A., and

Buckeridge, D. L. (2005). Ontology-centered syn-

AnOntology-basedFrameworkforSyndromicSurveillanceMethodSelection

399

dromic surveillance for bioterrorism. IEEE Intelligent

Systems, 20:26–35.

Firm, T., Chain, V., and Network, V. (2000). Ten Ways to

Leverage Knowledge for Creating Value. Knowledge

Creation Diffusion Utilization.

Guthrie, G., Stacey, D. A., Calvert, D., and Edge, V.

(2005). Detection of disease outbreaks in pharmaceu-

tical sales: Neural networks and threshold algorithms.

Public Health, pages 3138–3143 ST – Detection of

disease outbreaks in.

Henning, K. (2004). What is syndromic surveillance?

MMWR Morbidity and Mortality Weekly Report,

53:5–11.

Hutwagner, L., Thompson, W., Seeman, G. M., and Tread-

well, T. (2003). The bioterrorism preparedness and

response early aberration reporting system (EARS).

Journal of urban health bulletin of the New York

Academy of Medicine, 80:i89–i96.

Kulldorff, M. (2010). SatScan user guide.

Kulldorff, M., Heffernan, R., Hartman, J., Assuno, R.,

and Mostashari, F. (2005). A spacetime permutation

scan statistic for disease outbreak detection. PLoS

Medicine, 2(3):e59.

Lu, H.-M., Zeng, D., Trujillo, L., Komatsu, K., and Chen,

H. (2008). Ontology-enhanced automatic chief com-

plaint classiﬁcation for syndromic surveillance. Jour-

nal of Biomedical Informatics, 41:340–356.

McDade, J. and Franz, D. (1998). Bioterrorism as a public

health threat. Emerging Infectious Diseases, 4:488–

492.

Okhmatovskaia, A., Chapman, W., Collier, N., Espino, J.,

and Buckeridge, D. L. (2009). SSO: The syndromic

surveillance ontology. In Proc International Society

for Disease Surveillance, page (in press).

OConnor, M. J., Buckeridge, D. L., Choy, M., Crubezy,

M., Pincus, Z., and Musen, M. A. (2003). BioS-

TORM: A system for automated surveillance of di-

verse data sources. AMIA Annual Symposium pro-

ceedings, 2003:1071.

Tsui, F.-C., Espino, J. U., Dato, V. M., Gesteland, P. H.,

Hutman, J., and Wagner, M. M. (2003). Technical de-

scription of RODS: a real-time public health surveil-

lance system. Journal of the American Medical Infor-

matics Association, 10:399–408.

Wong, W.-K., Moore, A., Cooper, G., and Wagner, M.

(2005). What’s strange about recent events (wsare):

An algorithm for the early detection of disease out-

breaks. J. Mach. Learn. Res., 6:1961–1998.

KEOD2012-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

400
