Improving the Asymptotic Convergence of Memetic Algorithms
The SAT Problem Case Study
Noureddine Bouhmala
Department of Maritime Technology and Innovation, Vestfold University College, P.O. Box 2243, 3103 Tnsberg, Norway
Keywords:
Satisfiability Problem, Memetic Algorithm, Multilevel Techniques.
Abstract:
In this work, a memetic algorithm that makes use of the multilevel paradigm for solving SAT problems is
presented. The multilevel paradigm refers to the process of dividing large and difficult problems into smaller
ones, which are hopefully much easier to solve, and then work backward towards the solution of the original
problem, using a solution from a previous level as a starting solution at the next level. Results on real industrial
instances are presented.
1 INTRODUCTION
The Satisfiability (SAT) problem which is known to
be NP-complete (Cook, 1971) plays a central problem
in many applications in the fields of Very Large Scale
Integration (VLSI) Computer-Aided design, Comput-
ing Theory, and Artificial Intelligence. Generally, an
instance of the SAT problem is defined by a set of
Boolean variables V = {v
1
, ...., v
n
} and a Boolean for-
mula Φ : {0, 1}
n
→ {0, 1}. The formula Φ is in con-
junctive mormal form (CNF) and is formed of a con-
juction of clauses. Each clause in turn is a disjunc-
tion of literals and a literal is a variable or its nega-
tion. The task is to determine whether there exists an
assignment of values to the variables under which Φ
evaluates to True. Such an assignment, if it exists, is
called a satisfying assignment for Φ, and Φ is called
satisfiable. Otherwise, Φ is said to be unsatisfiable.
2 THE MULTILEVEL MEMETIC
ALGORITHM (MMA)
2.1 General Strategy
The multilevel paradigm involves recursive coarsning
to create a hierarchy of increasingly smaller and
coarser versions of the original problem. This phase
is repeated until the size of the smallest problem falls
below a specified coarsening threshold. Then, a so-
lution for the problem at the coarsest level is gener-
ated, and then successively projected back onto each
of the intermediate levels in reverse order (uncoars-
ening phase). The solution at each child level is im-
proved by a refinement algorithm before moving to
the parent level.
2.2 Coarsening
Let S
0
(the subscript represents the level of problem
scale) be the set of literals. The next level coarser
level S
1
is constructed from S
0
by merging literals.
The merging is computed using a randomized algo-
rithm similar to (Hendrickson and Leland, 1995). The
literals are visited in a random order. If a literal l
i
has
not been matched yet, then we randomly select one
randomly unmatched literal l
j
, and a new literal l
k
(a
cluster) consisting of the two literals l
i
and l
j
is cre-
ated. Unmerged literals are simply copied to the next
level. The new formed literals are used to define a new
and smaller problem and recursively iterate the coars-
ening process until the size of the problem reaches
some desired threshold.
2.3 Initial Solution
The coarsening procedure ceases when the problem
size shrinks to a desired threshold. Initialization is
then trivial and consists of generating an intial solu-
tion for the population at the lowest level |level
m
| us-
ing a random procedure. Each cluster of every indi-
vidual in the population is assigned the value of true
or false in a random manner.
294
Bouhmala N..
Improving the Asymptotic Convergence of Memetic Algorithms - The SAT Problem Case Study.
DOI: 10.5220/0004153702940296
In Proceedings of the 4th International Joint Conference on Computational Intelligence (ECTA-2012), pages 294-296
ISBN: 978-989-8565-33-4
Copyright
c
2012 SCITEPRESS (Science and Technology Publications, Lda.)
2.4 Uncoarsening
The uncoarsening phase refers to the inverse process
followed during the coarsening phase. Having im-
proved the assignment at the level level
m+1
, the as-
signment must be extended on its parent level
m
. The
extension algorithm is simple; if a given cluster C
i
be-
longing to an individual in the population at the level
j is assigned the value of true then the merged pair K
l
and K
m
of clusters that it represents, are also assigned
the true value.
2.5 Improvement
The idea of improvement is to use the projected pop-
ulation at level
m+1
as the initial population for level
m
for further refinement using a memetic algorithm de-
scribed in the next section. Even though the popula-
tion at the level
m+1
is at a local minimum, the pro-
jected population may not be at a local optimum with
respect to Level
m
. The projected population is al-
ready a good solution and contains individuals with
high fitness value, MA will converge quicker within
a few generation to a better assignment. As soon as
the population tends to loose its diversity, premature
convergence occurs and all individuals in the popu-
lation tend to be identtical with almost the same fit-
ness value. During each level, the memetic algorithm
is assumed to reach convergence when no further im-
provement of the best solution has not been made dur-
ing five consecutive generations.
3 EXPERIMENTAL RESULTS
3.1 Test Suite
The performance of the multilevel memetic algorithm
(MMA) was tested on a set of large problem instances
taken from real industrial problems. All the bench-
mark instances used in this experiment are satisfiable
instances. Due to the randomization nature of the al-
gorithms, each problem instance was run 100 times.
Time limit is set to 15 minutes. The tests were car-
ried out on a DELL machine with 800 MHz CPU and
2 GB of memory. The code was written in C and
compiled with the GNU C compiler version 4.6. The
following parameters have been fixed experimentally
and are listed below:
• Crossover probability = 0.85;
• Mutation probability = 0.1;
• Population size = 50;
• Stopping criteria for the coarsening phase: The
coarsening stops as soon as the size of the coarsest
problem reaches 100 variables (clusters). At this
level, MA generates an initial population.
• Convergence during the refinement phase: If there
is no observable improvement of the fitness func-
tion of the best individual during 10 consecutive
generations, MA is assumed to have reached con-
vergence and moves to a higher level.
3.2 Analysis of Results
Table 1 shows the range of all solved clauses (RAC),
the mean solved clauses (MSC) and the range of
solved clauses (RSC). As can be seen in Table 1
there is no overlap between the observed ranges for
MA and MMA. Hence all observed runs of MMA
is found to be better (closer to the solution) than the
runs of MA. The actual domination of MMA versus
MA is strengthened by the fact that a none of the
99% confidence intervals for the mean difference be-
tween MMA and MA contains the value 0. Finally,
we can see that MMA have better asymptotic conver-
gence (to around 0.39%−0.95% in excess of the solu-
tion ) as compared to MA which only achieve around
(10, 05% −11, 95%). We noticed that for small prob-
lems MA dominates MMA during the start of the
search, however as the time increases, MMA has a
marginally better asymptotic convergence for small
problems compared to MA while the convergence be-
havior becomes more distinctive for larger problems.
4 CONCLUSIONS
A new approach for addressing the satisfiability prob-
lem which combines the multilevel paradigm with a
simple memetic algorithm have been tested. A set
of industrial benchmark instances was used in or-
der to get a comprehensive picture of the new algo-
rithm’s performance. The multilevel memetic algo-
rithm clearly outperformed the simple memetic algo-
rithm in all instances. Results also show that the dif-
ference in performance between the two algorithms
increases for larger problems. The experiments have
shown that MLMA works well with a random coars-
ening scheme combined with a simple memetic algo-
rithm used as a refinement algorithm. The random
coarsening provided a good global view of the prob-
lem, while the memetic algorithm used during the re-
finement phase provided a good local view. It can
be seen from the results that the multilevel paradigm
greatly improves the memetic algorithm and always
returns a better solution for the equivalent runtime.
ImprovingtheAsymptoticConvergenceofMemeticAlgorithms-TheSATProblemCaseStudy
295
Table 1: Comparison of MMA and MA: Range of all solved clauses (RAC), Mean of solved clauses (MSC), Ranged of solved
clauses (RSC).
RAC MSC RSC
Instance MA MMA MA MMA MA MMA
1 2bitadd 10 0% 0% 98.85% 99.86% 98.24 – 99.23% 99.79 – 99.93%
2 2bitadd 11 0% 4% 98.96% 99.89% 98.46 – 99.49% 99.74 – 100%
3 2bitadd 12 8% 18% 99.91% 99.92% 99.76 – 100% 99.82 – 100%
4 2bitcomp 5 100% 100% 100% 100% — —
5 2bitmax 6 44% 56% 99.92% 99.94% 99.74 – 100% 99.74 – 100%
6 3bitadd 31 0% 0% 96.47% 99.58% 94.83 – 97.05% 99.31 – 99.61%
7 3bitadd 32 0% 0% 95.77% 99.58% 93.89 – 96.52% 99.42 – 99.62%
8 3blocks 0% 0% 99.93% 99.96% 99.91 – 99.96% 99.91 – 99.98%
9 4blocks 0% 0% 99.97% 99.98% 99.96 – 99.98% 99.97 – 100%
10 4blocksb 0% 0% 99.97% 99.98% 99.97 – 99.98% 99.97 – 99.99%
11 e0ddr2-10-by-5-1 0% 0% 89.53% 99.67% 88.09 – 90.47% 99.33 – 99.75%
12 e0ddr2-10-by-5-4 0% 0% 89.50% 99.69% 88.72 – 90.25% 99.31 – 99.74%
13 enddr2-10-by-5-1 0% 0% 89.20% 99.67% 88.46 – 90.08% 99.08 – 99.75%
14 enddr2-10-by-5-8 0% 0% 89.24% 99.68% 88.18 – 90.18% 99.15 – 99.76%
15 ewddr2-10-by-5-1 0% 0% 89.09% 99.66% 88.33 – 89.92% 99.05 – 99.76%
16 ewddr2-10-by-5-8 0% 0% 89.02% 99.71% 88.05 – 89.95% 99.42 – 99.76%
Our future work aims at investigating other coarsen-
ing schemes and identifying other parameters which
may influence the interaction between the memetic al-
gorithm and the multilevel paradigm.
REFERENCES
Cook, S. A. (1971). The complexity of theorem-proving
procedures. In Proceedings of the third annual ACM
symposium on Theory of computing, STOC ’71, pages
151–158, New York, NY, USA. ACM.
Hendrickson, B. and Leland, R. (1995). A multilevel
algorithm for partitioning graphs. In Proceedings
of the 1995 ACM/IEEE conference on Supercomput-
ing (CDROM), Supercomputing ’95, New York, NY,
USA. ACM.
