Towards an Arabic Ontology

Defining Morpho-lexical Patterns for Semantic Relation Extraction

Mohamed Mahdi Boudabous

, Fatiha Sadat

and Lamia Hadrich Belhuith

ANLP Research Group, Laboratoire MIRACL, University of Sfax, Sfax, Tunisia

Université du Québec à Montréal (UQAM), Montréal, Canada

Keywords: Arabic Ontology, Morpho-lexical Patterns, Wikipedia, Semantic Relations, Pattern Definition.

Abstract: In this paper, we propose a method for defining morpho-lexical patterns used to detect semantic relation

between Arabic nouns. This method is based on study corpus built from online encyclopedia. This corpus

consists of a set of articles selected on the basis of a database containing pairs of terms linked by semantic

relations. Defined patterns are then implemented using NooJ platform. The pattern evaluation result is very

encouraging. We obtained 79% as F-Measure rate.

1 INTRODUCTION

Over the last decade, with the important

development of the Web, information sources have

become multiform and very rich. These sources are

represented in different forms, understandable by

users but not by computers. So the need of

techniques and tools for automatic pre-processing

information, which allows the computer to

understand the information and transfer the content

to the humans, is becoming important now days.

Ontologies are amongst the most powerful

knowledge representation tools for modeling and

managing various applications ranging over Natural

Language Processing (NLP), information retrieval,

semantic Web, etc (Baccar, 2012). In this context,

research on ontology building has become

increasingly widespread in computer science

community.

Recently, ontologies have emerged as a major

research topic in the fields of automatic language

processing, information retrieval and semantic web

(Baccar, 2012).

Several methodologies for building ontology

have emerged over the past scores of years namely:

 From scratch methodology;

 Re-engineering methodology;

 Cooperative construction methodology;

 Integration methodology;

 Learning methodology.

Learning methodology differs according to data

sources used for learning (Ben Mustapha, 2006)

such as texts, dictionaries, knowledge bases,

relational schemas and semi-structured schemas.

Through the analysis of the state of the art of

learning methods, we can identify a methodological

framework that consists of four steps:

 Corpus construction;

 Linguistic analysis of the corpus;

 Semantic standardization;

 Development of the operational ontology.

In this paper, we focus on the linguistic analysis of

the corpus which allows the passage from linguistic

level to conceptual one. In fact, we propose a pattern

based method for semantic relation detection

between the ontology concepts. The originality of

this method consists in the definition of morpho-

lexical patterns from Arabic wikipedia. Defined

patterns allow then to extract semantic relations

between nouns.

The present paper is outlined as follows: the first

section is an introduction as we have seen above.

The second section is devoted to present the basic

concepts of domain ontology building. The third

section presents an overview of approaches for

extracting semantic relations. The fourth section

exposes our method for defining morpho-lexical

patterns from online encyclopedia and gives details

on the corresponding stages. In the fifth section, we

present the implementation of defined patterns,

obtained results and discussion. The last section

presents the conclusion and the prospects of our

work.

342

Mahdi Boudabous M., Sadat F. and Hadrich Belguith L..

Towards an Arabic Ontology - Deﬁning Morpho-lexical Patterns for Semantic Relation Extraction.

DOI: 10.5220/0004157603420348

In Proceedings of the 14th International Conference on Enterprise Information Systems (SCOE-2012), pages 342-348

ISBN: 978-989-8565-11-2

 2012 SCITEPRESS (Science and Technology Publications, Lda.)

2 BASIC CONCEPTS

The concept of an ontology is inherited from a

philosophical tradition that focuses on the science of

Being. Over the last two decades, several definitions

and types of ontologies have emerged since the

introduction of this concept in computer science

domain (Arara, 2002). In this section, we review the

various definitions, the components of ontology,

types of ontologies and methodologies for building

ontologies.

In literature, many definitions are proposed for

the concept ontology. The most referenced and

synthetic one is that of Gurber (Gurber, 1993),

which predicts that an ontology is "an explicit

specification of conceptualization". This definition is

expanded in 1997 by Borst (Borst, 1997), then by

Studer and al. in 1998 (Studer, 1998) that define

ontology as "an explicit and formal specification of a

shared conceptualization".

According to Gurber (Gurber, 1993), ontologies

are composed of five components namely concepts,

relationships, properties, axioms and instances. The

concepts represent an object in the universe. The

relations reflect the relevant links existing between

the concepts in the field of study. The properties are

attributes that characterize the concepts and

relationships. The axioms are used to constraint the

value of concepts and relations. The instances are

used for representing elements in a domain.

After building the first ontologies, the

researchers define dimensions to classify ontologies.

In fact, different dimensions of classification have

emerged. The most known is the dimension

proposed by Gomez-Pérez in 2004 (Gómez-Pérez,

2004) which classifies ontologies according to their

objects of conceptualization. The types of ontologies

best known along this dimension are:

 Generic ontologies (top-level ontologies): this

type contain general concepts common to all

domains or multiple domains (time, space,

object, event);

 Domain ontologies: this type contains a set of

vocabularies and concepts that describe an

application domain;

 Tasks ontologies: this type is used to

conceptualize specific tasks in the system;

 Application ontologies: this type is used to

define ontologies that depend on both the

domain and the task.

In the ontology engineering field, many

methodologies are proposed for building ontologies.

In fact, the first methodology for building ontology

is called “from-scratch”, aimed to design a process

of building ontologies in the absence of knowledge

(Ben Mustapha, 2006). Given the limitations

presented by this methodology, the researchers

propose ontology re-engineering methodology that

tends to bind ontology under implementation to

another already built. After that, researchers propose

new methodology that follows a collaborative

approach including the intervention of people

located in different places. This methodology called

“cooperative construction methodology”. Moreover,

with the deployment and the diversification of

electronic resources, the researchers opt for the

learning methodology which is based on

heterogeneous data sources.

Building ontologies from texts is a sub-domain

of engineering ontologies. Actually, several methods

are involved for learning ontologies from texts.

These methods differ according to the techniques

used for extracting concepts and relations. Based on

this criterion, these methods are grouped into three

families of approach namely: statistical approaches,

linguistic approaches and hybrid approaches (Ben

Mustapha, 2006).

In this paper, we are interested in learning

methods from texts based on linguistic techniques.

Most of the existing methods are based on linguistic

techniques. Added to that, these methods treat indo-

European languages (George, 1993), (Vossen, 1998)

and use lexico-syntactic patterns to detect semantic

relations (Laignel, 2011). Moreover, to our

knowledge there is no research works that are done

on Arabic lexicon ontology for nouns. However,

there are some Arabic ontologies among them we

can cite Arabic WordNet (Black, 2006), Amine

Arabic WordNet (Abouenour, 2008) and Arabic

Ontology (Jarrar, 2011).

However, given the lack of tools for parsing

Arabic language and the complexity of treatments

specific to that language, we propose to define

morpho-lexical patterns to identify semantic

relations used to build a lexical ontology for Arabic.

3 OVERVIEW OF SEMANTIC

RELATIONS EXTRACTION

METHODS

In this section, we present an overview of the

different techniques for extracting semantic

relations.

Automatic identification of semantic relations in

text is a difficult problem, although it is important

for many applications (Green, 2002). Thus, different

methods for extracting semantic relations from texts

Towards an Arabic Ontology - Defining Morpho-lexical Patterns for Semantic Relation Extraction

343

have been proposed. These methods can be grouped

into three main categories namely: statistical

techniques, linguistic techniques and hybrid

techniques.

Statistical techniques are based on the principle

that terms which co-occur together are strongly

linked by semantic relations. These techniques use

statistical methods to calculate the distribution of

words in the corpus (Agirre, 2000) or probabilistic

methods to calculate the probability of occurrences

of a set of terms (Velardi, 2001), (Neshatian, 2004).

Once the concepts are detected, the relations that

connect them can be identified by calculating the

similarity between their syntactic contexts (Hindle,

1990), (Grefenstette, 1994), using either Bayesian

networks (Weissenbacher, 2007) or text mining

techniques (Grcar, 2007) or learning algorithms

(Giuliano, 2006).

However, the major drawback of these methods

is that they don’t always identify the correct

semantics of the relationship, so they require human

intervention (Kergosien, 2009).

Linguistic techniques are based on the structure

of sentences and texts. These techniques require

automatic processing tools for texts analyses such as

segmentation tools and grammatical tagging tools.

Moreover, they are based on lexico-syntactic

patterns to recognize linguistic markers of semantic

relations (Aussenac-Gilles, 2000), or on contextual

rules based on index and triggers.

The application of these techniques is carried out

at the sentence, while other studies analyzed all level

of the text. Thus, several methods have been

implemented for example CHAMELEON

(Aussenac-Gilles, 2000) and SEEK (Jouis, 1994).

This type of approach is also used by the Edelweiss

(Khelif, 2006).

Compared to numerical techniques, these

techniques have a major advantage view that is the

ability to identify semantics of the relationship.

Likewise, hybrid techniques combine statistical

methods and linguistic methods. They generally use

the syntactic distribution of terms to extract

relations.

4 THE PROPOSED METHOD

FOR SEMANTIC RELATION

EXTRACTION

We propose in this section a method for extracting

semantic relations from texts in order to build a

lexical ontology from online encyclopedia (Fig. 1).

Our method consists on defining a set of morpho-

lexical patterns specific to each relationship that will

be used to extract the relationships between

concepts.

Figure 1: The two phases of the proposed method.

Figure 1 shows the two phases of the proposed

method for defining semantic relationships between

concepts. The first phase consists on the pre-

treatment of the corpus and the second one consists

on the definition and validation of patterns. Defined

patterns ensure the passage from the textual level to

the conceptual one and form the informal to the

formal.

In the following sections, we detail the various

steps of this method.

4.1 Corpus Pre-treatment

In this section, we detail the different steps of the

pre-treatment corpus phase. The first step tends to

define semantic relationships specific to the domain

of the ontology. The second step consists on

building the corpus and it is crucial and delicate. The

third step is the corpus pre-treatment (segmentation,

sentences extraction and morphological analysis).

4.1.1 Semantic Relations Definition

The definition of semantic relationships between

concepts of an ontology is performed by an expert

based on the technical documentation of the

ontology. This documentation allows us to describe

the characteristics of the ontology, such as the main

objectives, the type of the ontology and application

areas.

In this work, we aim to build a lexical ontology

for Arabic language. This ontology must contain

Arabic lexicons and semantic relations between

them and it will be useful for several applications of

NLP such as Information Retrieval, Question

Answering (Q/A), etc.

From this description, the domain expert defines

semantic relationships. In our work, the domain

ICEIS 2012 - 14th International Conference on Enterprise Information Systems

344

expert defines eleven semantic relationships. Table 1

presents some examples of the defined semantic

relations.

Table 1: Some examples of the defined semantic relations.

Semantic

relation

Example

Hyponymy

(IS_A)

 Animal

« is hyponym of »

Dog, horse

Hyperonymy

Cat

« is hyperonym of »

 Animal

Holonymy

Car

« is holonym of »

Door

Meronymy

Motor

« is meronim of »

Car

Member

France

« is member of »

Union European

Synonymy

Person

« is synonym of »

Individual

…

Antonymy

بأ Father

« is antonym of »

Mother

4.1.2 Corpus Construction

The proposed method for detecting semantic

relationships is based on a corpus study. This corpus

is representative as it contains indicative sentences.

An indicative sentence is a sentence in the article

that indicates a semantic relationship between two

terms.

In fact, in the first step we build a database

composed of pairs of concepts from Arabic

WordNet (AWN). This database consists of 8000

nouns connected by 13,000 relationships extracted

from AWN and enriched by the expert. In the

second step we use the online encyclopedia Arabic

Wikipedia to download articles corresponding for

the list of database nouns. The choice of Arabic

Wikipedia is justified by the fact that it is currently

the largest source of knowledge on the web (i.e. it

contains more than 160 000 articles in Arabic).

The acquisition of the articles constituting our

study corpus is done in an automatic way. Our

corpus consists on 2050 articles (Downloaded in

March 2012).

4.1.3 Corpus Pre-treatment

The following automatic processing tasks are

applied to the corpus in order to be able to define

patterns:

 Segmentation: allows to segment articles in

sentences. Segmentation is based on the

punctuation markers, coordination conjunctions

and some alternative keywords (Belguith,

2005);

 Extracting indicative sentences: this step tends

to extract indicative sentences from articles;

 Sentences annotation: it consists of the

sentences morphological analysis in order to

determine for each unit (i.e. a word or a

compound word) the part of speech, gender,

number, tense, etc.

At the end of this phase all indicative sentences are

morphologically annotated. These sentences will

serve as an input for the patterns definition and

validation phase.

4.2 Patterns Definition and Validation

In this section, we detail the steps of the morpho-

lexical patterns definition phase. We define a

morpho-lexical pattern as a linguistic structure or

schema that consists of a set of words and / or

morphological categories in a specific order. The

first step groups sentences that have specific

semantic relationship. The second step has a manual

scan of all sentences belonging to the same

relationship in order to extract patterns related to

each relationship. The third step allows validating

defined patterns. These patterns are defined to

automate the process of detecting semantic relations

from texts.

4.2.1 Grouping of Sentences

This step categorizes sentences into groups

according to the semantic relations they indicate.

This task is done with reference to the database of

nouns defined in the first phase. Then, we group

sentences that have a common morphological

structure.

The main interest of this step is to facilitate the

task of defining patterns specific to each

relationship.

4.2.2 Sentences Analysis

In this state, the domain expert is responsible for the

study of morphological structures of sentences in

order to define patterns. This study tends to extract a

Towards an Arabic Ontology - Defining Morpho-lexical Patterns for Semantic Relation Extraction

345

morpho-lexical pattern from each sentence or group

of sentences. Defined patterns consist in

morphological categories of words and lexicons.

These lexicons are used to specify words that

indicate the relationship. Table 2 shows some

examples of sentences and the morpho-lexical

pattern matching.

Table 2: Examples of indicative sentences and morpho-

lexical pattern matching.

Phrases

Morpho-lexical pattern





The Air is

composed of

nitrogen gas

   X 

Y 

Present verb + X (Noun) + Tool (preposition)

+ Noun + Y (Noun)

   



The water is

composed of two

atoms of hydrogen

4.2.3 Pattern Validation

After defining the patterns, it is often useful to

validate the list of patterns by a human expert. This

step tends on conducting a comparative study

between all patterns of different relationships to

ensure that each pattern is specific to a relationship.

Based on this comparative study, we note the

existence of some ambiguous patterns, that is to say

belonging to more than a relationship. To resolve

this problem we add lexical indicators to

differentiate ambiguity patterns (table 3).

Table 3: Examples of an ambiguous pattern.

Relations

Phrases

Morpho-lexical patterns

Solution

Antonymy





Grief is

the

opposite

happiness

X



Y

X (Noun) + Pronoun

(He, she) + Noun + Y

(Noun)









Noun:

opposit

reverse,

versus.

synonymy





Currency

is the form

of money

X



Y

X (Noun) + Pronoun

(He, she) + Noun + Y

(Noun)









Noun:

synony

mous,

form,

model.

Table 3 shows two indicative sentences that have

the same morphological structure but belong to two

different relations. In this case we need a mark to

distinguish the two patterns. For this example the

solution proposed by the domain expert is to define

the list of prepositions possible specific to each

relationship.

5 PATTERNS

IMPLEMENTATION

Once patterns are validated by the domain expert,

the next step consists in implementing all defined

patterns. For this, we use NooJ platform. This

platform allows us to represent specific patterns to

each relationship as a grammar (Figure 2). In fact,

we characterize morpho-lexical elements present

before, after and between related terms. Also, we

characterize the form of the elements related by

markers. These elements are shown in parentheses in

the pattern. For example, in Figure 2, we use the

marker "var" to characterize the first term and "var1"

to characterize the second term.

Figure 2: Example of a NooJ grammar.

Obtained grammars are combined into a single

grammar called “main grammar” in order to be able

to apply all the grammar on all sentences of the

corpus to extract all relations of the ontology.

In order to evaluate the effectiveness of defined

patterns on the recognition of semantic relations, we

apply the principal grammar on a test corpus. This

corpus consists of 300 articles extracted from the

online encyclopedia Arabic Wikipedia. These

articles contain 370 relationships.

The first step consists in segmenting articles into

sentences. Then, in the second step, sentences are

annotated morphologically in order to apply defined

patterns and detect semantic relations in an

automatic way.

By comparing pairs of words and semantic

relationships that link them automatically extracts

with those extracted by the domain expert, we can

calculate measures of recall, precision and F-

measure for each relationship. In fact, we determine,

ICEIS 2012 - 14th International Conference on Enterprise Information Systems

346

for each pair of words detected, the relevance of the

terms and the semantic relationship between them.

Two values are possible:

 The value "valid": if the relationship is deemed

valid and the two words linked by this

relationship;

 The value "false": when the relationship is

wrong (in this case, the terms are often invalid).

Obtained results are shown in Table 4.

Table 4: Evaluation results of morpho-lexical patterns.

Relations

Recall

Precision

F-measure

Average

78%

85%

79%

Following the evaluation of built grammars, we

obtain values of recall, precision and F-measure,

respectively: 78%, 85% and 79%. Although the

results are encouraging, there are relationships that

are not detected by the defined patterns. By

analyzing non-detecting pairs of words, we find that

this problem is mainly due to two reasons:

 The lack of patterns that cannot recognize the

relationship: In fact, in some cases the patterns,

concerning some phrases, are not defined;

 The non-detection of compound nouns: using

NooJ morphological analyzer, we notice that it

is unable to detect compound nouns, which

prevents from applying some patterns to the

sentences.

Moreover, in some cases we notice that the

patterns recognize erroneous relationships. This can

be explained by two reasons:

 The existence of some ambiguous patterns;

 Morphological analysis using NooJ platform

produce several morphological categories: in

some cases NooJ return more than one

morphological category of a word, which allow

to us apply several patterns on one sentence and

detect more than one semantic relation between

two terms.

6 CONCLUSIONS AND FUTURE

WORK

In this paper, we propose a method to define

morpho-lexical patterns that is useful for extracting

semantic relations between arabic nouns. This

method is based on a corpus of 2050 Arabic

Wikipedia articles. We have detailed the various

steps of the proposed method. As a result, the

defined patterns are implemented using NooJ

platform in order to automatically identify the pairs

of words and the semantic relations between these

specific terms. Nevertheless, our method uses a

minimum of knowledge, based primarily on

morpho-lexical knowledge, obtained results are very

encouraging (i.e. 78% recall, 85% precision and

79% F-measure) which proves the importance of

morpho-lexical patterns in the detection of semantic

relations for Arabic language.

As future perspectives, we plan to resolve

ambiguous patterns. In addition, we intend to

propose a method for detecting compound nouns.

Finally, we consider applying these patterns to build

a lexical ontology for Arabic.

REFERENCES

Baccar, F., Gargouri, B., Ben Hamadou, A., 2012.

Towards Generation of Domain Ontology from LMF

Standardized Dictionaries. In Proceedings of the 22nd

International Conference on Software Engineering &

Knowledge Engineering (SEKE).

Ben Mustapha, N., Aufaure, M. A., Baazaoui Zghal, H.,

2006. Vers une approche de construction de

composants ontologiques pour le Web sémantique –

synthèse et discussion. In Troisième atelier Fouille de

Données Complexes dans un processus d’extraction

des connaissances.

Arara, A., Ben Slimane, D., 2002. Towards ontologies

building: a terminology based approach, In VLDB

Journal - Special Issue on Semantic Web.

Gurber, T. R., 1999. Toward Principles for the Design of

ontologiesused for Knowledge Sharing. In

International Journal of Human-Computer Studies.

Vol. 43 , pp. 907-928.

Borst, W., 1997. Construction of Engineering Ontologies

for Knowledge Sharing and Reuse. Ph.D.

Dissertation.

Studer, R., Benjamins, V. R., Fensel, D., 1998.

Knowledge Engineering: Principles and Methods. In

Data Knowl. Eng., vol. 25, pp. 161–197.

Gómez-Pérez, A., Fernández-López, M., Corcho, O.,

2004. Ontological engineering: with examples from

the areas of knowledge Management, e-Commerce

and the semantic Web.

George, A. M., Beckwith, R., Fellbaum, C., Gross, D.,

Miller K., 1993. Introduction to wordnet: An On-line

Lexical Database. In International Journal of

Lexicography.

Vossen, P., 1998. Eurowordnet: A Multilingual Database

with Lexical Semantic Networks. Livre.

Laignel, M., Kamel, M., Aussenac-Gilles, N., 2011.

Enrichir la notion de patron par la prise en compte de

la structure textuelle - Application à la construction

d’ontologie. In TALN 2011 (Traitement automatique

des langues naturelles).

Black, W., Elkateb, A., Rodriguez, H., Alkhalifa, M.,

Vossen, P., Pease, A., Fellbaum, C., 2006. Introducing

the Arabic wordnet Project.

Towards an Arabic Ontology - Defining Morpho-lexical Patterns for Semantic Relation Extraction

347

Abouenour, L., Bouzoubaa, K., Rosso, P., 2008.

Construction de l’ontologie Amine Arabic wordnet

dans le cadre des systèmes Q/R. In Proceedings de la

Journée Scienfique sur les Technologies de

l'Information et de la Communication, JOSTIC 08.

Jarrar, M., 2011. Building a Formal Arabic Ontology. In

proceedings of the Experts Meeting on Arabic

Ontologies and Semantic Networks.

Green, R., Bean, C. A., Myaeng, S. H., 2002. The

Semantics of Relationships An Interdisciplinary

Perspective, Springer.

Agirre, E., Ansa, O., Arregi, X., Artola, X., Diaz, A.,

Lersundi, M., Martinez, D., Sarasola, K., Urizar, R.,

2000. Extraction of semantic relations from a Basque

monolingual dictionary using Constraint Grammar.

Velardi, P., Missikoff, M., Basili, R., 2001 Identification

of relevant terms to support the construction of

Domain Ontologies. In: ACL-EACL Workshop on

Human Language Technologies, Toulouse, France.

Neshatian, K., Hejazi M. R., 2004. Text categorization and

classification in terms of multi-attribute concepts for

enriching existing ontologies. In: 2nd Workshop on

Information Technology and its Disciplines. Pp. 43–

48.

Hindle, D., 1990. Noun classification from predicate

argument structures. In: proceeding of the 28th Annual

Meeting of the Association for Computational

Linguistics (ACL’90). Berkeley USA.

Grefenstette, G., 1994. Explorations in Automatic

Thesaurus Discovery. MA: Kluwer Academic

Plubisher. Boston.

Weissenbacher, D., Nazarenko A., 2007. Identifier les

pronoms anaphoriques et trouver leurs antécédents :

l’intérêt de la classification bayésienne. In TALN

conférence.

Grcar, M., Klein, E., Novak, B., 2007. Using Term-

Matching Algorithms for the Annotation of Geo-

services. In Postproceedings of the ECML-PKDD

2007 Workshops.

Giuliano, C., Lavelli, A., Romano, L., 2006. Exploiting

Shallow Linguistic Information for Relation

Extraction from Biomedical Literature. In Proceeding

EACL.

Kergosien, E., Kamel, M., Sallaberry, C., Bessagnet, M.

N., Aussenac, N., Gaio, M., 2009. Construction

automatique d'ontologie et enrichissement à partir de

ressources externes. In 3es Journées Francophones

sur les Ontologies.

Aussenac-Gilles, N., Seguela, P., 2000. Les relations

sémantiques : du linguistique au formel. In Numéro

spécial linguistique de corpus. Toulouse.

Jouis, C., 1994. SEEK, un logicielle d’acquisition des

connaissances utilisant un savoir linguistique sans

employer de connaissances sur le monde externe. In

Actes des 6ème Journées Acquisition, Validation.

INRIA, pp. 159—172.

Khelif, K., 2006. Web sémantique et mémoire

d’expériences pour l’analyse du transcriptome. These

de doctorat.

Belguith Hadrich, L., Baccour, L., Ghassan, M., 2006.

Segmentation de textes arabes basée sur l'analyse

contextuelle des signes de ponctuations et de certaines

particules. In 12

ème

conférence sur le Traitement

Automatique des Langues Naturelles.

ICEIS 2012 - 14th International Conference on Enterprise Information Systems

348
