B Protein levels of RPS3 and ENP1 (as a loading
control) derived from experiment shown in A were
detected by Western blotting. Note that si-DTNBP1-
2 reduces RPS3 levels.
4 CONCLUSIONS
The major objective of this paper was to describe a
new algorithm and software toolkit to analyse off-
target effects in RNAi screening data.
The test and validation phase has proven that the
software already provides a powerful and flexible
toolkit for analysing off-target effects. Testing and
validating the toolkit with an actual high content
dataset revealed that the workflow environment is
suitable for off-target analysis. The analyses of the
given dataset show that the environment allows for a
dynamic workflow adaption based on intermediate
results, e.g. by supplemental Text Filter integration.
In addition to the flexible workflow creation facility,
the individual configuration options of a single node
are also advantageous. All in all, the software
environment with its flexibility turns out to be very
suitable to analyse off-target effects in RNAi
screening data. An important aspect is the reliability
of the results obtained in the analysis process. In this
case the results seem to be reasonable and correct.
We would like emphasize that our predictions
neither include the effects of siRNA concentration
nor do they attempt to account for the siRNA pool
constructs. It is clear that both these effects are of
critical practical consequence and that a
computational model supporting them is desirable.
At the moment, however, there is insufficient
published data on the efficacies of pools to be able
to construct a high-confidence model of pool effects.
REFERENCES
Alemán, L. M., Doench, J. G. and Sharp, P. A., 2007.
Comparison of sirna-induced off-target rna and protein
effects. RNA, 13(3):385–95.
Altschul, S. F., Gish, W., Miller, W., Myers, E. W and
Lipman, D. J., 1990. Basic local alignment search tool.
J Mol Biol, 215(3):403–10.
Amarzguioui, M., Holen,T., Babaie, E. and Prydz, H.
2003. Tolerance for mutations and chemical
modifications in a sirna. Nucleic Acids Res,
31(2):589–95.
Anderson, E. M., Birmingham, A., Baskerville, S.,
Reynolds, A., Maksimova, E., Leake, D., Fedorov, Y.,
Karpilow, J. and Khvorova, A., 2008. Experimental
validation of the importance of seed complement
frequency to sirna specificity. RNA, 14(5):853–61.
Birmingham, A., Anderson, E. M., Reynolds, A., Ilsley-
Tyree, D., Leake, D., Fedorov, Y., Baskerville, S.,
Maksimova, E., Robinson, K., Karpilow, J., Marshall,
W.S and Khvorova, A., 2006. 3’ utr seed matches, but
not overall identity, are associated with rnai off-
targets. Nat Methods, 3(3):199–204.
Doench, J. G., Petersen, C. P. and Sharp, P. A., 2003.
Sirnas can function as mirnas. Genes Dev, 17(4):438–
42.
Elbashir, S. M, Martinez, J., Patkaniowska, A., Lendeckel,
W. and Tuschl, T., 2001. Functional anatomy of sirnas
for mediating efficient rnai in drosophila melanogaster
embryo lysate. EMBO J, 20(23):6877–88.
Fedorov, Y., King, A., Anderson, E. M., Karpilow, J.,
Ilsley, D., Marshall, W. S. and Khvorova, A., 2005.
Different delivery methods-different expression
profiles. Nat Methods, 2(4):241.
Fedorov, Y., Anderson, E. M, Birmingham, A., Reynolds,
A., Karpilow, J., Robinson, K., Leake, D., Marshall,
W.S. and Khvorova, A., 2006. Off-target effects by
sirna can induce toxic phenotype. RNA, 12(7):1188–
96.
Grillo, G., Turi, A., Licciulli, F., Mignone, F., Liuni, S.,
Banfi, S., Gennarino, V. A., Horner, D. S., Pavesi, G.,
Picardi, E., Pesole, G., 2010. UTRdb and UTRsite
(RELEASE 2010): a collection of sequences and
regulatory motifs of the untranslated regions of
eukaryotic mRNAs. Nucleic Acids Res., 38, 75-80.
Hannon, H. J., 2002. Rna interference. Nature,
418(6894):244–51, July.
Haley, B. and Zamore, P. D., 2004. Kinetic analysis of the
rnai enzyme complex. Nat Struct Mol Biol, 11(7):599–
606.
HCDC web page, bioinformatics module:
[http://hcdc.ethz.ch/index.php?view=article&id=25]
Jackson, A. L, Burchard, J., Leake,D., Reynolds, A.,
Schelter, J., Guo, J., Johnson, J. M., Lim, L.,
Karpilow, J., Nichols, K., Marshall, W. S., Khvorova,
A. and Linsley, P. S., 2006. Position-specific chemical
modification of sirnas reduces "off-target" transcript
silencing. RNA, 12(7):1197–205.
Jackson, A. L., Burchard, J., Schelter, J., Chau, B. N.,
Cleary, M., Lim, L. and Linsley, P. S., 2006.
Widespread sirna "off-target" transcript silencing
mediated by seed region sequence complementarity.
RNA, 12(7):1179–87.
Jackson, A. L., Bartz, S. R., Schelter, J., Kobayashi, S. V.,
Burchard, J., Mao, M., Li, B., Cavet, G. and Linsley,
P. S., 2003. Expression profiling reveals off-target
gene regulation by rnai. Nat Biotechnol, 21(6):635–7.
Lewis, B. P., Burge, C. B. and Bartel, D. P., 2005.
Conserved seed pairing, often flanked by adenosines,
indicates that thousands of human genes are microrna
targets. Cell, 120(1):15–20.
Lin, X., Ruan, X., Anderson, M. G., McDowell, J. A.,
Kroeger, P. E., Fesik, S. W. and Shen, Y., 2005. Sirna-
mediated off-target gene silencing triggered by a 7 nt
complementation. Nucleic Acids Res, 33(14):4527–35.
