Identifying Most Relevant Concepts to Describe

Clinical Trial Eligibility Criteria

Krystyna Milian

1,2

, Anca Bucur

, Frank van Harmelen

and Annette ten Teije

VU University Amsterdam, Amsterdam, The Netherlands

Philips Research Eindhoven, Eindhoven, The Netherlands

Keywords:

Semantic Analysis, Selecting Ontology Subsets, Concepts Relevance, Ontology Annotators, Medical Ontolo-

gies.

Abstract:

Since eligibility criteria of clinical trials are represented as free text, their automatic interpretation and the eval-

uation of patient eligibility is challenging. Our approach to the criteria processing is based on the identiﬁcation

of contextual patterns and semantic concepts that together deﬁne the machine-interpretable meaning. The goal

of this research is to ﬁnd the most relevant concepts occurring in eligibility criteria that need to be mapped

to patient record to enable automatic evaluation of patient eligibility. Based on the analysis of annotation of

breast cancer trials obtained using different concept recognizers and ontologies from UMLS Thesaurus, we

chose to use MetaMap and SNOMED CT to create the mapping set. To prioritize the identiﬁed concepts, we

used the tf-idf measure and the corpus of over 38, 000 various clinical trials, to detect concepts speciﬁc for

breast cancer, and cancer in general. The obtained results can guide the mapping order of criteria concepts to

patient data. The observed substantial overlap between the terms occurring in criteria from the trials related to

breast cancer and other diseases will reduce the cost of extending the trial matching system to other diseases.

1 INTRODUCTION

Clinical trials examine the efﬁcacy of diagnosis and

treatment methods through case-control studies, but

ﬁnding eligible patients is expensive and difﬁcult. A

patient is enrolled in a clinical trial only when all

the eligibility criteria are fulﬁlled. They regard i.a.

age, gender, the current and prior diagnoses and treat-

ments. The problem is that they are deﬁned in free

text e.g. ’No prior cancer except for skin cancer’. In

our previous work we built the patterns that capture

general meaning of criteria (e.g. ’No prior [] except

[]’) which, when detected, provide crucial context in-

formation (Milian et al., 2012). Here, we explore the

concepts that occur in eligibility criteria related to a

particular disease. Identiﬁed concepts will be used to

link to corresponding data items in patient record, to

enable evaluation of patient eligibility. The links can

be deﬁned via the pointers to the type of a source doc-

ument (e.g. pathology report, discharge summary),

and/ or by deﬁning semantic relations (isA, sameAs)

to the terminology locally used in a hospital. Such

process will require signiﬁcant manual effort, during

the design or evaluation and involvement of medical

experts. Since medical ontologies contain hundreds

of thousands of concepts, there is a need to extract

subsets which are relevant for a particular purpose.

This study presents the experiment conducted to

compare 2 major ontology annotators: Bioportal and

MetaMap, and coverage of criteria from ClinicalTri-

als.gov

by the various medical ontologies (section

2). Further, section 3 describes in detail the MetaMap

annotation results of eligibility criteria of breast can-

cer trials, the quantitative characteristics of identiﬁed

concepts, their distribution over semantic types and

analysis of stability of obtained set. Section 4 demon-

strates the strategy used to prioritize the detected con-

cepts for creating mappings to patient record, and

presents ﬁndings about overlap of concepts occurring

in various types of trials. Final sections presents re-

lated work and conclusions.

2 DEFINING A STRATEGY

2.1 Selecting an Ontology Annotator

There are two major concepts recognizers available

for biomedical text mining: MetaMap (Aronson and

Lang, 2010) and NCBO annotator (Musen et al.,

2008). This section presents the experiment con-

ducted to compare the results of annotation of both

http://clinicaltrials.gov/

161

Milian K., Bucur A., van Harmelen F. and ten Teije A..

Identifying Most Relevant Concepts to Describe Clinical Trial Eligibility Criteria.

DOI: 10.5220/0004192501610166

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2013), pages 161-166

ISBN: 978-989-8565-37-2

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

tools on the trials corpus. We used 2135 trials from

ClinicalTrials.gov, related only to breast cancer, as it

is our main domain of interest. Both tools are highly

conﬁgurable, allow i.a. to select ontologies used for

annotations, MetaMap - any from UMLS (which inte-

grates more than 100 vocabularies), Bioportal - 16 out

of them. Because SNOMED CT is the largest relevant

ontology covered by both tools, we performed the ex-

periment restricting the vocabulary source to this one.

MetaMap returns the UMLS identiﬁers (CUI) of de-

tected concepts, Bioportal - the codes from a local on-

tology. To compare the results, we used the UMLS

API to retrieve the corresponding CUIs of SNOMED

ConceptIds, returned by NCBO annotator.

Figure 1 presents the annotation results, the num-

ber of concepts recognized by both tools, the over-

lap between them and the number of concepts found

only by one of them. Initially NCBO returned 7081

Figure 1: The number of SNOMED CT concepts detected

by Bioportal and MetaMap in the corpus of eligibility crite-

ria from 2135 breast cancer trials.

distinct concepts, which were mapped to 5005 CUIs.

The inspection of some of the remaining ones showed

that they were ﬂagged in UMLS as duplicate or am-

biguous. As can be seen in the ﬁgure, MetaMap re-

turned a larger number of concepts (5994 vs 5005).

The overlap between both results is 4075, meaning

only 59% of entire set (6924), which is rather worri-

some. Additionally, both tools detected concepts not

found by the other (1919 - MetaMap, 930 - Bioportal).

Table 1 provides the details about the top 3 semantic

types present in the set of concepts detected exclu-

sively by one of the tool. In the set detected only by

MetaMap the majority of concepts have types: Find-

ings, Disease or Syndrome, Laboratory procedure.

Third on the list of Bioportal is Therapeutic or Pre-

ventive procedure. In most cases, except for Diseases,

MetaMap returned more concepts.

The proper evaluation should also consider preci-

sion and recall of both tools. However, it would re-

quire the involvement of domain experts, which ex-

ceeds the scope of this work. In paper (Shah et al.,

2009) the authors of Bioportal report that Mgrep

(algorithm underlying the service) has higher preci-

sion than MetaMap when detecting UMLS concepts

having ’Disease or syndrom’ semantic type (0.87 vs

Table 1: Number of concepts belonging to particular seman-

tic types, detected only by MetaMap and only by NCBO,

percentage of all of a type, detected by corresponding tool.

Sementic Type Only by

MetaMap

Only by

NCBO

Finding 185 (43%) 139 (22%)

Disease or Syndrome 151 (26%) 189 (49%)

Laboratory Procedure 100 (59%) 31 (11%)

Therapeutic or Preven-

tive Procedure

95 (31%) 55 (21%)

0.71), but lower in case of ’Biological processes’ (0.6

vs 0.63). Clearly, the performance is dictionary de-

pendent. However, no information on other semantic

types, ontologies, nor recall is provided.

We choose MetaMap for the next experiments, as

it detects signiﬁcantly larger number of concepts.

2.2 Selecting a Medical Vocabulary

This section presents the MetaMap annotation results

of eligibility criteria from 2135 breast cancer clinical

trials. The aim is to compare the coverage of criteria

by various ontologies to support the choice for further

experiments, and learn about the uncovered phrases.

Coverage by Various Ontologies. In total

MetaMap detected 768439 UMLS concepts, 10924

distinct. Figure 2 presents the statistics of their

source (left bars). Listed are only ontologies which

contributed new concepts to the set, ordered by the

number of exclusive contributions (right bars).

The majority of concepts are covered by: MTH

(UMLS Metathesaurus), CHV (Consumer Health Vo-

cabulary), NCI ( NCI Thesaurus) and SNOMED CT.

The ﬁgure demonstrates remarkable overlap between

the terminologies, emphasized by the small contribu-

tions of distinct sources (highest for NCI, SNOMED

CT and CHV). The majority of concepts (88%) are

deﬁned by multiple ontologies. Based on the num-

ber of all detected concepts and unique contributions,

NCI seem to be the most appropriate ontology to use

for the concept recognition in eligibility criteria of

breast cancer trials. However, because SNOMED CT

is broadly used in clinical setting, and is still high on

the list, we decide to use it for the next experiments.

Uncovered Phrases. Additionally, we analyzed the

overall coverage of eligibility criteria by ontologies.

Table 2 presents the statistics about phrases distin-

guished by MetaMap. Both when using entire UMLS

and only SNOMED CT, around 32% of phrases re-

mains uncovered. To analyze the quality of obtained

HEALTHINF2013-InternationalConferenceonHealthInformatics

162

Figure 2: Number of concepts from various UMLS ontologies detected in eligibility criteria of breast cancer trials.

mappings, we checked their MetaMap score. When

using entire UMLS only 34.9% of mappings got the

maximal score, SNOMED CT, signiﬁcantly more,

47.8%. UMLS is a multi-purpose source, i.e. in-

cludes concepts from vocabularies developed for dif-

ferent purposes, therefore for effective usage needs to

be customized.

Table 2: Statistics about phrases from breast cancer trials.

Phrases UMLS SNOMED CT

Uncovered 31.6 % 32 %

Max mapping sore 34.9% 47.8%

Finally, we examined the unmatched phrases (see

Figure 3), observing mainly lay terms, which is a

promising ﬁnding about UMLS coverage. However,

these provide the context, therefore their recognition

is also crucial for automated interpretation of criteria.

Figure 3: The most frequent words in eligibility criteria,

uncovered by ontologies.

3 ESTIMATING EFFORT

Using selected annotator and ontology (MetaMap and

SNOMED CT), in this section, we investigate which

parts of SNOMED CT are actually relevant for de-

scribing eligibility criteria of medical trials and esti-

mate the effort indicators for mapping terms in eligi-

bility criteria to patient data.

3.1 Distribution of SNOMED CT

Concepts over Semantic Types

Annotation of criteria with SNOMED CT resulted

in detection of 393,511 occurrences of 5994 distinct

concepts. Figure 4 presents the distribution of all de-

tected concepts over the top 25 semantic types. Fig-

ure 5 presents the cardinality of top 25 mostly repre-

sented semantic types. The most frequent concepts

have types: Qualitative Concept (13%), Temporal

Concpet (10%), Therapeutic or Preventive Procedure

(8%). The majority of distinct concepts belong to:

Disease or Syndrome (10%), Finding (7%), Organic

Chemical, Pharmacologic Substance (6%).

For mappings, the ”cardinality of the type” is an

indicator of the effort needed to map this type to pa-

tient data, while the ”frequency of the type” is an in-

dicator of how many trials will be covered by such a

mapping. In loose terms, the size of a semantic type

is the ”cost” of mapping, while the frequency is its

”beneﬁt”. So ideally, we would like to ﬁnd semantic

types with high beneﬁt and low cost. Figure 6 shows

this beneﬁt/cost ratio (frequency/ cardinality) corre-

sponding to the highest ranking 25 semantic types.

The situation is most ”proﬁtable” for the type ”Re-

search activity” which occurs over 5k times and con-

tains only 4 concepts. Next are ”Patient or Disabled

Group”, ”Hormone”, ”Amino Acid, Peptide”. Only

few types contain concept that frequently occur and

are limited in number. The majority occurs sporadi-

cally with relatively large number of concepts, as the

ratio decreases very slowly. Concluding, the long tails

on the above graphs show that the mapping effort will

spread over many semantic types, and we cannot fo-

cus only on most frequent or largest types. However,

presented ordering should help to optimize the effort.

3.2 Verifying Stability of Annotation Set

By annotating the large corpus of trials we wanted to

obtain the set of concepts that is sufﬁciently broad to

cover the majority of trials, including those not pre-

sented in the initial corpus. To verify this idea, we an-

alyzed how the number of distinct concepts occurring

in eligibility criteria is growing with the number of tri-

als fed to the annotator. The results are plotted for the

major semantic types in Figure 7. Initially, the num-

ber of concepts grows rapidly, independently of the

type, then, the curves gradually slow down because of

the trials similarities. As expected, the number of con-

cepts belonging to some types keeps growing consid-

erably, e.g. Disease or Syndrome, while in other cases

IdentifyingMostRelevantConceptstoDescribeClinicalTrialEligibilityCriteria

163

Figure 4: Distribution of all detected concepts over semantic types.

Figure 5: Distribution of cardinality of semantic types.

Figure 6: The ratio: semantic type frequency/cardinality.

Figure 7: Growth of SNOMED concepts in eligibility crite-

ria of breast cancer trials, while increasing the trials corpus.

it stabilizes sooner, e.g. Laboratory or Test Result.

Figure 7 shows only the behavior of semantic types

with highest cardinality. The semantic types in the tail

of Figure 5 show a more promising behaviour: their

growth is small after an initial growth period, hence

for these semantic types there seem to exist a ”core

set of concepts” used in eligibility criteria. However,

we cannot expect to obtain a complete and stable set

of all concepts. Extending the trial matching system,

will require some effort of deﬁning new mappings.

4 PRIORITIZING CONCEPTS

Performed annotation led to the recognition of sev-

eral thousands of concepts in eligibility criteria from

breast cancer trials. In this section, we prioritize them,

to suggest the order used to map the terms to pa-

tient record. Previous section provides insights ag-

gregated for semantic types. Here, we focus on con-

crete terms. To prioritize the breast cancer concepts,

apart from concept frequency we take into account

concepts speciﬁcity for breast cancer, by comparing

their usage in other trials. Next, we rank higher con-

cepts that are speciﬁc to cancer trials in general, again

as compared to their use in any trial. Furthermore, we

verify the coverage of eligibility criteria from various

trials, by the top ranking concepts in breast cancer.

4.1 Description of a Method

The concepts speciﬁcity for breast cancer was mea-

sured using the tf-idf weight (Jones, 1972), com-

monly applied in information retrieval ﬁeld to detect

relevant terms (t) in a document (d) (see Formula 1).

t f ∗ id f (t, d, D) = t f (t, d) ∗ log(

|D|

|{d ∈ D}|

) (1)

HEALTHINF2013-InternationalConferenceonHealthInformatics

164

It grows proportionally to the term frequency (tf), and

inversely proportionally to the number of containing

it documents in a corpus D ( idf).

First, to rank higher concepts speciﬁc to breast

cancer, we concatenated all corresponding eligibility

criteria in one document, and as a corpus we used eli-

gibility criteria from all trials related to cancer. Anal-

ogously, to give the priority to the concepts speciﬁc

to cancer in general, we used as corpus trials studying

other diseases. We categorized the trials using their

meta data - each deﬁnes a list of studied conditions.

The numbers of applied trials are listed in table 3.

Table 3: Size of corpora used in the experiment.

Condition Trials Concepts

Breast cancer 2135 5994

Cancer 12022 13547

Non-cancer 23963 19428

4.2 Top Ranking Concepts

Using the described strategy, we obtained the order-

ing of concepts. 10 most typical for breast cancer tri-

als, and cancer in general, are listed in table 4. The

ﬁrst on breast cancer list is ”Carcinoma of breast”,

cancer - ”Metastatic to”. The outcome follows the in-

tuition, demonstrating the effectiveness of tf-idf. The

obtained ranking should help to optimize the mapping

effort needed to build a recruitment support tool.

Table 4: The most relevant concepts for BC and cancer tri-

als.

Most relevant for BC Most relevant for cancer

Carcinoma of breast Metastatic to

Breast cancer Before

Invasive Chemotherapy regimen

HER-2/neu Concurrent

Concurrent

Radiotherapy

Before Chemotherapy

Speciﬁc Therapeutic procedure

Breast Malignant neoplasm

Entire breast Neoplasms - malignant

Immunologic adjuvant Radiotherapy

4.3 Coverage in other Types of Trials

Here, we present the result of the experiment aimed

to analyze the extensibility of our approach to other

diseases. We want to verify how many concepts rele-

vant for breast cancer, are also used in eligibility cri-

teria of trials studying other diseases. The trials were

clustered based on the top frequently occurring condi-

tions in the corpus of cancer and non cancer trials. We

performed the experiment with the top 2000 concepts

according to the tf-idf weight. The ordering reﬂects

the concepts weights of on the merged list of breast

cancer and cancer speciﬁc items. Table 5 presents the

statistics about the trials groups, overlaps of the top

breast cancer concept and the percentage of all de-

tected concepts in a group.

Table 5: Coverage of criteria related to various diseases, by

the most relevant 2000 breast cancer concepts.

Condition Trials Overlaping concepts

Prostate cancer 1214 1657 (24%)

Lung cancer 854 1662 (38%)

Lymphoma 616 1476 (42%)

Leukemia 615 1378 (42% )

Healthy 2760 1480 (21% )

HIV 1881 1430 (25%)

Obesity 844 1217 ( 31%)

Hypertension 804 1185 (34%)

The highest overlap occurs between breast and

lung cancer trials. As expected, there is a bigger over-

lap between trials about breast cancer and other can-

cers, than those about non cancer conditions (consid-

ering also the number of compared trials). In all cases

more than half of top ranking concepts for breast can-

cer, are also detected in eligibility criteria related to

other diseases. This ﬁnding indicates that the substan-

tial part of mappings can be reused if the trial match-

ing algorithm should be extended to others diseases.

5 RELATED WORK

The problem of identiﬁcation of subsets of ontologies

can be compared to the problem of formal ontology

modularization. In (Clark and Parsia, 2008) the au-

thors provide an overview of existing methods, eval-

uate them from the perspective of correctness, com-

pleteness, minimality and import-safety. According

to their ﬁndings locality-based modules are proven to

be correct and complete and are empirically-shown to

approximate minimality better than ad-hoc and other

formal algorithms. These methods are applicable

when the extracted module should be sufﬁcient for

reasoning, which is not our concern.

In (Milian et al., 2009) we aimed to detect the sub-

set of UMLS related to breast cancer treatment, by ex-

panding the initial set of concepts (those considered

at the decision points in treatment guidelines) via the

ontology hierarchy and the UMLS semantic network.

With respect to the analysis of eligibility criteria,

(Ross et al., 2010) provide an informative overview

of types of criteria, based on randomly-chosen 1000

eligibility criteria from ClinicalTrials.gov. They cate-

gorized them along several axes: complexity, seman-

tic patterns, clinical content and data sources. They

IdentifyingMostRelevantConceptstoDescribeClinicalTrialEligibilityCriteria

165

demonstrated a large semantic and clinical variability

of criteria across the trials. They argue that the ma-

jority of criteria present the challenges for automatic

evaluation because of semantic connectors hard to ex-

press with current representation languages, temporal

constraints, need for clinical judgment or lack of ex-

pected data in patient record.

6 CONCLUSIONS

The work described in this paper is part of our re-

search aimed at supporting patient recruitment and

trial study feasibility. It focuses on the analysis of se-

mantics of eligibility criteria, detecting parts of med-

ical ontologies relevant for a particular disease.

First, we investigated which annotation tool,

MetaMap or NCBO annotator, is more appropriate

for our task. We compared the overlap of concepts

detected by both in eligibility criteria of 2135 breast

cancer trials. The results show that the intersection

accounts for only 59% of entire set. Because of the

advantage of MetaMap in the number of detected con-

cepts we decided to use it for further experiments. In

future work it could be interesting to deﬁne a voting

algorithm which takes into account precision and re-

call of both tools corresponding to particular types

of criteria or semantic types. Second, we analyzed

the source and semantic types of detected concepts.

The ﬁndings indicate the high majority of concepts

(88%) is deﬁned by more than one ontology cov-

ered by UMLS, majority by MTH, CHV, NCI and

SNOMED CT. The highest number of unique contri-

butions is provided by NCI, SNOMED CT and CHV.

We chose SNOMED CT for the next experiments, be-

cause of its wide usage in clinical setting and good

scores in the comparison. It should be noted that in

32% of criteria phrases MetaMap did not detect any

concept, which indicates that additional processing is

needed to recognize the context in which recognized

terms occur. Only approximately 35% of phrases an-

notated with UMLS obtained the maximal mapping

score, and 48% in case of using only SNOMED CT.

The analysis of the distribution of the detected

concepts over various semantic types and their fre-

quency revealed that the mapping effort will need to

be spread over many types. Furthermore, we analyzed

the stability of obtained concept set by studying its

growth while adding new trials. While some stabil-

ity of the growth curve can be observed, specially for

some semantic types, we cannot expect that obtained

annotation set is complete. Extending the solution to

other trials will involve creating more mappings.

Finally, we put the semantic of breast cancer trials

into broader perspective of over 38, 000 clinical trials

studying other diseases. We used tf-idf measure to

ﬁnd concepts that are speciﬁc for breast cancer, and

cancer in general, and used the results to prioritize

them. We also veriﬁed the overlap between the top

2000 ranking concepts for breast cancer and concepts

occurring in other types of eligibility criteria and ﬁnd

out that the substantial part is repeated: in all cases

above 1100, in other cancer types above 1300.

We believe that this analysis provides insights

about semantics of eligibility criteria that can be used

to prioritize the mapping process of eligibility crite-

ria to patient record, and enhance building the re-

cruitment support tool. The approach was demon-

strated on the breast cancer domain, but it can be eas-

ily reused for other diseases.

REFERENCES

Aronson, A. R. and Lang, F.-M. (2010). An overview of

metamap: historical perspective and recent advances.

Journal of the American Medical Informatics Associ-

ation, 17(3):229–236.

Clark, K. and Parsia, B. (2008). Modularity and owl. Liter-

ature survey.

Jones, K. S. (1972). A statistical interpretation of term

speciﬁcity and its application in retrieval. Journal of

Documentation, 28:11–21.

Milian, K., Aleksovski, Z., Vdovjak, R., ten Teije, A.,

and van Harmelen, F. (2009). Identifying disease-

centric subdomains in very large medical ontolo-

gies, a case-study on breast-cancer concepts in

snomed. In Knowledge Representation for Healthcare

(KR4HC09), LNCS.

Milian, K., Bucur, A., and ten Teije, A. (2012). Formaliza-

tion of clinical trial eligibility criteria: Evaluation of a

pattern-based approach. In 2012 IEEE International

Conference on Bioinformatics and Biomedicine.

Musen, M., Shah, N., Noy, N., Dai, B., Dorf, M., Grifﬁth,

N. B., Buntrock, J., Jonquet, C., Montegut, M., and

Rubin, D. (2008). Bioportal: Ontologies and data re-

sources with the click of a mouse. In AMIA Annual

Symposium, pages 1223–1224.

Ross, J., Tu, S. W., Carini, S., and Sim, I. (2010). Anal-

ysis of eligibility criteria complexity in clinical trials.

AMIA Summits on Translational Science Proceedings,

pages 46–50.

Shah, N. H., Bhatia, N., Jonquet, C., Rubin, D. L., Chi-

ang, A. P., and Musen, M. A. (2009). Comparison of

concept recognizers for building the open biomedical

annotator. BMC Bioinformatics, 10(S-9):14.

HEALTHINF2013-InternationalConferenceonHealthInformatics

166
