Bag-of-Words for Action Recognition using Random Projections

An Exploratory Study

Pau Agust

1,3

, V. Javier Traver

1,3

, Filiberto Pla

1,3

and Ra

ul Montoliu

2,3

DLSI, Jaume-I University, Castell

on, Spain

DICC, Jaume-I University, Castell

on, Spain

iNIT, Jaume-I University, Castell

on, Spain

Keywords:

Clustering, Human Action Recognition, Random Projections, Bag-of-Words.

Abstract:

During the last years, the bag-of-words (BoW) approach has become quite popular for representing actions

from video sequences. While the BoW is conceptually very simple and practically effective, it suffers from

some drawbacks. In particular, the quantization procedure behind the BoW usually relies on a computation-

ally heavy k-means clustering. In this work we explore whether alternative approaches as simple as random

projections, which are data agnostic, can represent a practical alternative. Results reveal that this randomized

quantization offers an interesting computational-accuracy trade-off, because although recognition performance

is not yet as high as with k-means, it is still competitive with an speed-up higher than one order of magnitude.

1 INTRODUCTION

Nowadays, human action recognition in videos has

become an important research topic within the com-

puter vision (Aggarwal and Ryoo, 2011), having a

high impact on large technical and social applications.

The goal in this ﬁeld is the recognition from video

sources of actions performed by individuals.

Some of the recent works are devoted to achieve

view-invariance (Li and Zickler, 2012), learn from

few examples (Natarajan et al., 2010), or explore

higher-level action representations (Sadanand and

Corso, 2012). Since, background segmentation is un-

realistic, spatio-temporal interest points and its de-

scriptors (Laptev, 2003) are one of the most suc-

cessful approaches. However, these techniques tend

to detect and describe too many non-discriminative

points (i.e. points from the background, illumination

changes, etc). To obtain more discriminative inter-

est points, some approaches ﬁlter the interest points

(Chakraborty et al., 2012).

As a complementary method to the interest points

detection and description, the Bag-of-Words (BoW)

approach has reached an important success in generat-

ing representation of those orderless features (Bilinski

and Bremond, 2011; Wang et al., 2009), or including

temporal order (Bregonzio et al., 2012).

Despite the advances and different approaches in

the BoW schemes, k-means (Jain, 2010) is the most

used clustering algorithm to construct vocabularies in

these problems. Despite the fact that k-means is con-

sidered one of the most important data mining algo-

rithm (Wu et al., 2007), the computation time is one

of its drawbacks. Many works attempt to speed up

the clustering processes. In (Boutsidis et al., 2010)

random projections are used as a dimensionality re-

duction technique that allows k-means to have better

computation time.

We interpret that in human action recognition, the

role of clustering in BoW is not necessarily “seman-

tic” (as in, e.g. image segmentation), but just for

quantization and eventually, classiﬁcation purposes.

Given that randomized algorithms have interesting

properties, the action representation could be based

on them. Thus, this work aims at exploring ran-

dom projections-based quantization as an alternative

to k-means-based to generate vocabularies in a BoW

scheme for action recognition.

Other related works use the concept of random-

ness to build vocabularies in a BoW model for recog-

nition tasks, like (Moosmann et al., 2008) for images

or (Mu et al., 2010) for human action recognition.

The approach presented here aims at using the

concept of randomness to perform a clustering of fea-

ture points, keeping the initial idea of a k-means clus-

tering to build a vocabulary, that is, to use clustering

as way to quantize the original data set, but taking the

advantage of the use of random projections to perform

614

Agustí P., Traver V., Pla F. and Montoliu R..

Bag-of-Words for Action Recognition using Random Projections - An Exploratory Study.

DOI: 10.5220/0004216906140619

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 614-619

ISBN: 978-989-8565-47-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

the clustering in a more efﬁcient way as k-means does.

Some preliminary work is presented in this paper to

analyze the performance both in terms of computa-

tional time and recognition rate in comparison with

k-means, widespread used and the de facto standard

for quantization in BoW models.

2 METHODOLOGY

The methodology used follows the classic BoW

STIP-based (Spatio Temporal Interst Point) proce-

dure. An interest point detector is applied to each

video (using Harris3D from (Laptev, 2003)) in order

to obtain a descriptor for each point of interest. The

descriptors extracted are, also from (Laptev, 2003),

the Histograms of Gradients (HOG), the Histograms

of Optical Flow (HOF) and a concatenation of both

(HOGHOF). Once the descriptors are extracted, a his-

togram is generated for each video. This part will be

tested using two different approaches to get the quan-

tization of the histogram. The traditional k-means-

based quantization, where descriptors are grouped

into clusters and the histogram is a quantization of

how many times each descriptor, from a video, be-

longs to a cluster. The second approach is the random

projection-based quantization, where the histogram is

done using random matrices. At the end of the pro-

cess, the whole database is split into training set, val-

idation set and test set. Finally, an SVM, with a χ

kernel, is trained. The recognition rate is obtained by

using the test set.

2.1 k-means-based Quantization

In the BoW scheme, the most common way to cre-

ate the histogram quantization is the use of k-means

clustering (Bilinski and Bremond, 2011; Wang et al.,

2009). In this approach, we will refer to the proce-

dure having two steps. First, all input data (SS

M×d

)

is grouped into a number (k) of clusters and the cen-

troids (CC

k×d

) of them are given as output (Algo-

rithm 1). The asymptotic cost of this step is O(γMdk),

where γ is the number of iterations to reach the con-

vergence, d is the dimensionality of original space

and M the number of examples to be clustered. The

second step (detailed in Algorithm 2), starts with the

data from a video (where N is the number of fea-

tures describing the video), and create a histogram of

k bins. For each feature vector, the closest centroid

is found and this contributes to the corresponding bin

number. The asymptotic cost of this step is O(Ndk).

Despite the great acceptance that the technique

has in the human action recognition ﬁeld, the com-

putation time to perform the clustering is very costly.

Indeed, it is shown that the problem to optimize the

cost function in the classical k-means algorithm is a

NP-hard problem (Aloise et al., 2009).

Algorithm 1: Finding the clusters by k-means (Step 1).

Input: Dimensionality of original space, d,

number of examples, M,

number of clusters, k, and

Input data matrix, SS

M×d

Output: Clusters centroids CC

k×d

1: Randomly initialize the cluster centroids CC

2: repeat

3: for i ← 1 to M do

4: Assign SS

to the closest CC

5: end for

6: for i ← 1 to k do

7: CC

← centroid of the points assigned to the

i-th cluster

8: end for

9: until convergence

Algorithm 2: Generating the histograms (Step 2).

Input: Dimensionality of original space, d,

number of clusters, k,

number of examples, N,

Centroids of clusters, CC

k×d

, and

Input data matrix, X

N×d

Output: The histogram h

1×k

1: for i ← 1 to N do

2: Let j be the closest cluster centroid of data in

i-th row of X

3: h

← h

+ 1

4: end for

5: h ←

2.2 Random Projections-based

Quantization

Random projections have been reported (Bingham

and Mannila, 2001) to be a competitive alternative

to other dimensionality reduction techniques such as

PCA, yet computationally simpler. The rationale be-

hind random projections is the Johnson-Lindenstrauss

lemma (Johnson and Lindenstrauss, 1984) which

states that distances between points in a given space

are preserved after they are randomly projected to a

space of suitable high dimensionality (see (Bingham

and Mannila, 2001) and references within it). Clus-

tering of data after their random projections has been

used in the past. For instance, the use of EM cluster-

ing is particularly suitable in conjunction with random

projections because EM assumes data are distributed

Bag-of-WordsforActionRecognitionusingRandomProjections-AnExploratoryStudy

615

as mixture of Gaussians, and high-dimensional data

are more Gaussian after being randomly projection to

low-dimensionality space (Fern and Brodley, 2003).

In the context of our problem, we are not inter-

ested in dimensionality reduction nor in clustering

per se, but in obtaining a histogram-like bag-of-words

representation. The proposed procedure to compute

these histograms using random projections has two

steps. First, a random projection matrix R and a par-

tition matrix H are computed (Algorithm 3). Impor-

tantly, this step is independent of the data to be clus-

tered and only its dimensionality d is required, along

with three parameters (P, L, and b). Parameter P is

the number of projections and can also be viewed as

the dimensionality of the projected space. Parame-

ter L is the number of partitions that are considered.

Each partition is a combination of b out of the P pro-

jections. The histograms will have 2

bins. The en-

tries of the projection matrix are generated from the

standard normal distribution N (0, 1). The asymptotic

cost of this step is O(Pd + Lb).

Algorithm 3 : Generating the projection and partitioning

matrices (Step 1).

Input: Dimensionality of original space, d,

number of projections, P,

number of partitions, L, and

number of bins of target histogram, 2

Output: the projection matrix R

P×d

, and

the partition matrix H

L×b

1: Fill in R with random numbers from N (0, 1)

2: Fill in each row of H with b random integers in

{1, P} without any repetition.

The second step (detailed in Algorithm 4) uses

a data matrix X, which is projected and (implic-

itly) clustered. Each data vector in X is projected

using the previously computed projection matrix R,

and contributes to an histogram entry using the par-

tition matrix H. For N data points in X, this step

is O(N(Pd + Lb)).

For STIP-based action recognition, d is the dimen-

sionality of the descriptor of the interest points, and

matrices R and H can be generated for some values

of P, L, and b. Data X would correspond to all the de-

scriptors computed on an action sequence. For given

matrices R and H, it is expected that the histograms

resulting from sequences of the same action will look

more similar than those of sequences of different ac-

tions.

2.3 Complexity Comparison

The computation complexity has been split into two

steps, each step corresponds to each one of the two

Algorithm 4: Projecting and quantizing the input data (Step

2).

Input: Input data matrix, X

N×d

the projection matrix R

P×d

, and

the partition matrix H

L×b

Output: the histogram h

1×2

, and

1: Z ← (RX

) > 0 {Project data and binarize}

2: for i ← 1 to N do

3: z ← i-th column of Z

4: for j ← 1 to L do

5: l ←

∑

k=1

· z

{Get bin index}

6: h

← h

+ 1 {increase histogram count}

7: end for

8: end for

9: h ←

h {Normalize histogram}

algorithm explained in the respective sections. If we

assume that Pd ≈ Lb, the second step in the random

projection-based quantization does not give any ad-

vantage, because in the worst case both are cubic

order and depends on the amount of data. The re-

ally great advantage for the random projections-based

quantization is in the ﬁrst step. The cost of k-means

clustering is, in the worst case, a polynomial of degree

4 and the random projections-based is only a polyno-

mial of degree 2. Another drawback, in this step, is

the k-means-based dependence of the amount of data,

N, what makes this method inconvenient when deal-

ing with high amount of data.

3 EXPERIMENTAL WORK

For the experiments, the Weizmann and KTH datasets

have been used. These datasets are ones of the most

used for human action recognition. They are pub-

licly available, what allows comparison with different

approaches. The Weizmann dataset (Gorelick et al.,

2007) contains 93 sequences showing 9 different peo-

ple performing 10 different actions. The KTH dataset

(Sch

uldt et al., 2004) contains 599 sequences showing

25 people performing 6 actions in 4 different scenar-

ios.

In this work, to study the feasibility of random

projections for quantization applied to human action

recognition, these following issues will be tested:

• Comparison of the runtime between k-means-

based quantization and random projections-based

quantization to generate the histograms (Section

3.1).

• Are the recognition results, using a random

projection-based quantization, comparable to the

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

616

state-of-art using a k-means-based quantization?

(Section 3.2)

• As the method is random by nature, how does this

affect the stability of the results? (Section 3.3)

• How does the parameters conﬁguration inﬂu-

ence to the random projection-based quantiza-

tion? (Section 3.4)

For evaluating the recognition performance, the

learning-classiﬁcation protocol follows the same con-

ditions as in (Bilinski and Bremond, 2011), which is

chosen as a reference for k-means results. For the

Weizmann dataset, a leaving-one-actor-out protocol

is used and for the KTH dataset, persons 2,3, 5–10

and 22 are used for the test set and the rest for the

training set.

3.1 Computation Time

As shown in Section 2.3, theoretical the compu-

tational complexity is lower when using a random

projection-based quantization than in a k-means-

based quantization. Nevertheless, does the running

time decrease? To answer this question, as the dimen-

sionality (d) has effect on the clustering, the objec-

tive was to penalize as much as possible the computa-

tional time, so a concatenation of the HOG and HOF

descriptor has been chosen (HOGHOF).

Figure 1 shows a comparison of the runtime us-

ing the k-means-based quantization and that of the

random projections-based quantization for the Weiz-

mann dataset (a) and the KTH dataset (b). The run-

time is calculated for the two steps together: (1) deﬁ-

nition of the clusters (k-means-based) or generation of

the random matrices (random projections-based) and

(2) generation of the histograms. For k, the values

1000, 2000 and 4000 clusters has been tested and the

closest values for the b in random projections-based

are 10, 11 and 12 (1024, 2048 and 4096 bins), and

ﬁxed values for L = 200 and P = 250.

For the Weizmann dataset, the time elapsed with

random projection is always less than 2 seconds and

using the k-means is always more than 40 seconds.

As it has been shown, k-means is really dependent on

the number of data, M. Indeed, following some works

like (Wang et al., 2009) to reduce the complexity, the

clustering has been performed using only a part of the

data (in that case, and in this work, ≈ 100, 000 de-

scriptors) for the KTH dataset. The runtime to create

the histograms using k-means is always over 25 min-

utes and using the random projections-based quanti-

zation is always less than 42 seconds. Nevertheless,

the times to generate the histograms only (the second

step, it has been shown also in Section 2.3) are almost

the same.

(a) Weizmann dataset

(b) KTH dataset

Figure 1: Computation time in logarithmic scale for differ-

ent number of clusters.

The speed-up factor of using random projections

over using k-means is about 30–50 in Weizmann, and

about 35–80 in KTH. Thus, the proposed clustering

is more than one order (and can be up to almost two

orders) of magnitude faster than k-means.

3.2 Accuracy

Once it is known that using a random projections-

based quantization instead a k-means, the computa-

tion time is a signiﬁcant advantage, the recognition

rate using random projection should be assessed with

respect to the k-means-based algorithm. Thus, for the

experiments, the k-means based BoW algorithm pro-

posed in (Bilinski and Bremond, 2011) is used.

Table 1 shows the best results obtained by (Bilin-

ski and Bremond, 2011) for different descriptors

using a k-means-based quantization (they test with

1000, 2000, 3000 and 4000 clusters) and the best re-

sults obtained with our method (the parameters con-

ﬁgurations tested for choosing the best will be re-

ported in section 3.4). The accuracy obtained just by

changing the histogram generation is, in most of the

cases, only around 3% less. And in comparison to

(Kl

aser et al., 2008) for Weizmann and (Wang et al.,

Bag-of-WordsforActionRecognitionusingRandomProjections-AnExploratoryStudy

617

2009) for KTH (the same strategy and k-means-based

quantization ara used) our recognition rate is always

(for all combination of HOG/HOF descriptors) higher

except for the HOG descriptor in KTH.

3.3 Stability

Assuming the random nature due to the generation of

random matrices, the question about the stability of

the results should be addressed. To perform this ex-

periment, the HOF descriptor has been chosen due

to the good results obtained in the experiments in

Section 3.2. For the same parameters conﬁguration

(b, L, P), 20 different random matrices were generated

and used for the random projection-based quantiza-

tion classiﬁcation. In both datasets, the best result and

the worst were used, according to the experiments in

Section 3.2.

Table 2 shows the mean of the recognition rates

and its standard deviation. It could be appreciated

there is not a signiﬁcant accuracy variation using the

same parameters conﬁguration. It is worth mention-

ing that the Weizmann database approximately has

10% of difference between the best and the worst re-

sult. In the case of the KTH dataset this difference is

more than 75%, what introduces the question about

the importance of the selection of parameters.

3.4 Conﬁguration Dependency

In order to assess the dependency of the random pro-

jections on the conﬁguration of the parameters, in

the experiments the following values have been used

b ∈ {8, 9, 10, 11}, L ∈ {5, 10, 25, 50, 100, 150, 200}

and P ∈ {50, 100, 150, 200, 250} and all the combi-

nations among them. Regarding the accuracy, exper-

iments show that only few parameters conﬁgurations

provided the best results, thus, the selection of param-

eters is really important.

Figure 2 shows in the left side the Weizmann

(HOF descriptor) results varying only one parame-

ter in each plot (the other two were ﬁxed at b = 8,

L = 200 and P = 250 depending on which one is vary-

ing). In the right side it is shown the KTH (HOF de-

scriptor) results varying only one parameter in each

plot (the other two were ﬁxed at b = 12, L = 100 and

P = 50 depending on which one is varying).

Despite the fact we can notice some pattern in

some cases (in Weizmann accuracy increase while in-

creasing the L and P parameters and in KTH the accu-

racy increase while increasing b), it seems there is not

a clear behavior rule. Therefore, in order to choose

the parameters conﬁguration, it seems necessary to

select them by a validation method.

0 1000 2000 3000

0.8

0.9

P=250, L=200

Accuracy (%)

0 50 100 150 200

0.7

0.8

0.9

=256, P=250

Accuracy (%)

50 100 150 200 250

0.7

0.8

0.9

=256, L=200

Accuracy (%)

0 1000 2000 3000

0.85

0.9

0.95

P=50, L=100

Accuracy (%)

0 50 100 150 200

0.5

=2048, P=50

Accuracy (%)

50 100 150 200 250

0.5

=2048, L=100

Accuracy (%)

Figure 2: Inﬂuence of different parameters conﬁgurations

on the recognition accuracy (Left for Weizmann, right for

KTH).

4 CONCLUSIONS

This papers has presented the use of random

projections-based quantization as an alternative to k-

means-based clustering for building vocabularies us-

ing a bag-of-words representation for action recogni-

tion. A preliminary work to assess the performance

of the method with respect to the widespread used k-

means-based algorithm has been done.

One clear advantage of the proposed random

projections-based algorithm is that it is computation-

ally more advantageous than the k-means. The rea-

son for this efﬁciency is that, unlike k-means, the ran-

dom projections-based algorithm does not make any

use of data to deﬁne the clustering. Regarding the

action recognition performance, competitive rates are

achieved, but those with k-means-based clustering are

generally better. Therefore, the proposed quantization

based on random-projection represents an interesting

trade-off between computational effort and accuracy.

Further work is directed to boost this approach with

quantization mechanisms that offer both high recog-

nition performance and great computational beneﬁt.

ACKNOWLEDGEMENTS

This work is partially supported by the Span-

ish research programme Consolider Ingenio-2010

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

618

Table 1: Recognition results (%) with the two BoW schemes explored.

(a) Weizmann dataset

k-means Random Projections

Descriptor k Accuracy b L P Accuracy Difference

HOG 2,000 86.02 512 100 200 82.47 3.55

HOF 3,000 91.40 256 200 250 90.25 1.15

HOGHOF 2,000 92.47 2,048 100 250 90.00 2.47

(b) KTH dataset

k-means Random Projections

Descriptor k Accuracy b L P Accuracy Difference

HOG 1,000 83.33 1,024 200 250 70.00 13.33

HOF 1,000 95.37 2,048 100 50 93.51 1.86

HOGHOF 3,000 94.44 2,048 200 200 92.12 2.32

Table 2: Stability results obtained by repeating 20 times each experiment with the same parameters conﬁguration (b, L, P).

Best result Worst result

Mean (µ) Std. dev. (σ) b L P Mean (µ) Std. dev. (σ) b L P

Weizmann 88.50 1.78 8 200 250 80.33 2.22 11 5 50

KTH 91.79 1.73 11 100 50 14.76 4.03 11 25 250

CSD2007-00018, Fundaci Caixa-Castell Bancaixa

(P11A2010-11 and P11B2010-27) and Generalitat

Valenciana (PROMETEO/2010/028).

REFERENCES

Aggarwal, J. and Ryoo, M. (2011). Human activity analy-

sis: A review. ACM CS.

Aloise, D., Deshpande, A., Hansen, P., and Popat, P. (2009).

NP-hardness of euclidean sum-of-squares clustering.

ML.

Bilinski, P. and Bremond, F. (2011). Evaluation of local

descriptors for action recognition in videos. In ICCVS.

Bingham, E. and Mannila, H. (2001). Random projection in

dimensionality reduction: applications to image and

text data. In KDD.

Boutsidis, C., Zouzias, A., and Drineas, P. (2010). Random

Projections for k-means Clustering. NIPS.

Bregonzio, M., Xiang, T., and Gong, S. (2012). Fus-

ing appearance and distribution information of interest

points for action recognition. PM.

Chakraborty, B., Holte, M. B., Moeslund, T. B., and Gon-

zlez, J. (2012). Selective spatio-temporal interest

points. CVIU.

Fern, X. Z. and Brodley, C. E. (2003). Random Projection

for High Dimensional Data Clustering: A Cluster En-

semble Approach. In ICML.

Gorelick, L., Blank, M., Shechtman, E., Irani, M., and

Basri, R. (2007). Actions as Space-Time Shapes.

tPAMI.

Jain, A. K. (2010). Data clustering: 50 years beyond k-

means. PRL.

Johnson, W. and Lindenstrauss, J. (1984). Extensions of

Lipschitz mappings into a Hilbert space. In CMAP.

aser, A., Marszałek, M., and Schmid, C. (2008). A spatio-

temporal descriptor based on 3d-gradients. In BMVC.

Laptev, I. (2003). On space-time interest points. IJCV.

Li, R. and Zickler, T. (2012). Discriminative virtual views

for cross-view action recognition. In CVPR.

Moosmann, F., Nowak, E., and Jurie, F. (2008). Ran-

domized Clustering Forests for Image Classiﬁcation.

tPAMI.

Mu, Y., Sun, J., Han, T. X., Cheong, L.-F., and Yan, S.

(2010). Randomized locality sensitive vocabularies

for bag-of-features model. In ECCV.

Natarajan, P., Singh, V. K., and Nevatia, R. (2010). Learn-

ing 3D action models from a few 2D videos for view

invariant action recognition. In CVPR.

Sadanand, S. and Corso, J. J. (2012). Action bank: A high-

level representation of activity in video. In CVPR.

Sch

uldt, C., Laptev, I., and Caputo, B. (2004). Recognizing

human actions: A local SVM approach. In ICPR.

Wang, H., Ullah, M. M., Kl

aser, A., Laptev, I., and Schmid,

C. (2009). Evaluation of local spatio-temporal fea-

tures for action recognition. In BMVC.

Wu, X., Kumar, V., Ross Quinlan, J., Ghosh, J., Yang, Q.,

Motoda, H., McLachlan, G. J., Ng, A., Liu, B., Yu,

P. S., Zhou, Z.-H., Steinbach, M., Hand, D. J., and

Steinberg, D. (2007). Top 10 algorithms in data min-

ing. KAIS.

Bag-of-WordsforActionRecognitionusingRandomProjections-AnExploratoryStudy

619
