QUASI: A Pipeline for the Quality Assessment and Statistical

Inference on Next Generation Sequencing Data from Pooled shRNA

Library Screens

Mark Onyango

, Carsten Ade

, Franz Cemič

and Jürgen Hemberger

Institute of Biochemical Engineering and Analytics, University of Applied Sciences Giessen,

Wiesenstrasse 14, Giessen, Germany

Theodor-Boveri Institute, University of Würzburg, Am Hubland, Würzburg, Germany

Keywords: DGE, RNA-Seq, Pipeline, Differential Expression, Quality Assessment, Tag-Seq, shRNA.

Abstract: With the development of next generation high-throughput sequencing solutions to expression profiling, the

efficient and effortless handling of such profiling data became a key challenge for bioinformaticians and

biologists alike. We therefore present a "fire and forget" style pipeline implemented in C and R, named

QUASI. It is capable of quality assessments, sequence alignments, shRNA quantification and statistically

inferring significant differential sequence abundance from datasets presented to it. Through blackboxing the

often complex and laborious steps, QUASI presents itself as a user-friendly and time-efficient solution to

handle pooled shRNA library screening data.

1 INTRODUCTION

The discovery of RNA interference (RNAi) in

Caenorhabditis elegans (Fire et al., 1998) introduced

new possibilities for the analysis of genes and the

identification of their biological functions in cellular

pathways. Introduction of double stranded RNA into

its cells led to the degradation of complementary

mRNA, thus silencing the corresponding gene. It

was later shown that these so-called loss-of-function

screens could also be applied to mammalian

organisms (Elbashir et al., 2001).

Such synthetic small interfering RNAs (siRNA)

were successfully employed, but the fast and

transient-only gene silencing in addition to the

inability to transfect otherwise hard-to-transfect cells

make them inferior to small hairpin RNAs (shRNA).

To overcome these downsides, new RNAi

approaches were developed, using viral-vector based

shRNA/shRNAmir (henceforth abbreviated shRNA)

based libraries (Fewell and Schmitt, 2006) avoiding

the shortcomings of siRNAs as a silencing agent,

mentioned by Fewell and Schmitt.

With the development of next generation

sequencing (NGS) technologies and the commercial

availability of whole genome shRNA libraries, large

scale RNAi screens, using barcode sequencing

protocols, have become more feasible. Features such

as the high dynamic range and the vast output of

DNA reads make it ideally suited for large genome-

wide screenings.

One conceivable application is the search for

new cancer therapeutics. The uncontrolled

proliferation of many tumors results from mutations

of one or several genes causing the over-expression

of oncogenes or the loss of tumor suppressors. In

addition, tumor cells often develop a dependency on

the activity of further genes and their products.

These dependencies can be exploited by suppressing

the expression of these genes via shRNA mediated

knockdown of the corresponding mRNA, inducing

synthetic lethality. Genes whose knockdown is

synthetic lethal selectively only for treated cells

(with for example an induced over-expression of an

oncogene) but not for untreated control cells may be

promising targets for tumor therapy. Comparing

untreated to treated tumor cells, significant

differences in the abundance of individual shRNAs

due to increased apoptosis or cell division may be

observed. The genes targeted by those shRNAs can

then be subjected to further validation experiments

and the positive hits may then be screened for

potential druggability.

Next generation sequencing technology is

increasingly used to enable the analysis of pooled

288

Onyango M., Ade C., Cemi

c F. and Hemberger J..

QUASI: A Pipeline for the Quality Assessment and Statistical Inference on Next Generation Sequencing Data from Pooled shRNA Library Screens.

DOI: 10.5220/0004220702880291

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2013), pages 288-291

ISBN: 978-989-8565-35-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

RNAi screens in a high-throughput format. As a

consequence, new methodologies had to be

developed to analyze both RNA-Seq and shRNA

sequencing (shRNA-Seq) data.

As our contribution to the topic, we developed

QUASI, a pipeline supporting the handling of

shRNA-Seq data by performing quality assessments,

alignments and the analysis of differential shRNA

abundances in cell populations infected with the

same pooled lentiviral shRNA libraries.

2 IMPLEMENTATION

The pipeline consists of three tools, handling the

quality assessment, quantification and alignment.

Each tool can be called individually from the

command-line.

2.1 Quality Assessment

The quality assessment tool takes as input a standard

FASTQ file, and reads out the information contained

in every read block.

Figure 1: Box-and-Whiskers plot displaying the quality

score (Phred score) distribution per cycle.

The Phred quality scores (Ewing et al., 1998) are

processed to be visualized in a "Box-and-Whiskers

Plot" (Figure 1), providing a powerful display of the

overall quality at a single glance.

The plot presents the distributions' five-number

summary in a convenient and intelligible way. The

upper and lower whiskers represent the 90th and

10th percentile, respectively. The upper and lower

edge of the box represent the 75th and 25th

percentile whereas the median, i.e. 50th percentile, is

shown as a red line located somewhere inside the

box.

The frequently observed deterioration of the read

quality towards the 3' end is caused by an effect

called "phasing" (Kircher et al., 2009). As the

sequencing errors begin to accumulate, the

distribution of quality scores, assigned to the

incorporated nucleotides, broadens, thus making the

boxes and whiskers longer.

Another measure of quality is the quality-per-

base distribution (Figure 2). The quality scores for

each incorporated base are individually saved for

Adenine, Thymine, Cytosine and Guanine,

respectively. Presenting the plot in this manner

provides more insight, as base-specific sequencing

errors or bias can be visualized.

Figure 2: Distribution of quality scores for each base.

The tool saves all the relevant information,

discussed above, in plain text files which are then

later processed by an R script.

2.1.1 Benchmark

We tested our quality assessment tool and compared

the results and consumption of computational

resources to the freely available tools fastx (Hannon,

2012) and the well known tool FastQC (Andrews,

2010).

In Table 1 FastQC is shown to have the longest

run time but at the same time also offers the most

detailed quality report. In omitting analysis modules,

which are not relevant for shRNA-Seq (that is k-mer

analysis), we are able to focus on the relevant details

and save valuable time.

FastX seems to be slightly faster than quasi-qa,

QUASI:APipelinefortheQualityAssessmentandStatisticalInferenceonNextGenerationSequencingDatafromPooled

shRNALibraryScreens

289

but this originates from the difference in analyses

performed. FastX only saves information concerning

the nucleotidic composition and the quality

distribution per cycle, whereas quasi-qa also

analyzes the read length distribution, nucleotidic

composition, quality distribution per cycle and the

quality distribution per base.

Table 1: Performance benchmark of the quality

assessment. All calculations were performed on an Apple

MacBook Pro (late 2011) equipped with 8 GB of RAM,

2.3 GHz Intel Core i5 and a SSD harddrive. The

measurements were derived from the GNU time command

which is available on all Unix systems. It should be noted

that the tools do not possess the same range of functions.

Filesize Tool Wall time (hh:mm:ss) Total RAM

1.1 GB

fastqc 0.10 00:01:05 568 MB

fastx 0.0.13 00:00:09 21 MB

quasi-qa 00:00:10 2 MB

2.2 Alignment

The proper alignment tool must be chosen according

to the nature of the experiment. If total mRNA was

used for sequencing (i.e. RNA-Seq), TopHat,

SOAPsplice or other slice-junction-aware aligners

need to be chosen over splice-junction-unaware

aligners, as the latter are only able to align intra-

exonic reads back to the reference. Using splice-

junction-unaware aligners would result in the

incorrect dropping of all junction spanning reads as

unmappable and therefore loosing many counts.

If specific tags are sequenced, as is the case in

shRNA-Seq, splice-junction-unaware aligners such

as Bowtie (Langmead et al., 2009), BWA (Li and

Durbin, 2009) or SOAP3 (Liu et al., 2012), are more

than sufficient.

The alignment script adheres to common

standards, thus only accepting FASTQ formatted

files as input and writing alignments in the well

known SAM format

The reads of a sample-specific FASTQ file are

aligned to a predefined reference data set containing

the relevant sequences of all shRNAs used in the

RNAi screening experiment.

Multiple cores in a CPU are automatically

detected and are assumed to be available. Using

multiple cores during the alignment, drastically

reduces the total runtime on a near linear scale.

A pre-defined set of parameters has been chosen

for the alignment tools. However, the set of

parameters can be adjusted by the user if necessary.

2.3 Quantification

The tool quasi-count must be presented with one or

multiple SAM files, which will be analyzed

sequentially. This tool counts the number of

allocated reads to each reference sequence during

the alignment step. The resulting counts will be

saved in a matrix style textfile, which will later be

used for the inference of statistically significant

changes in shRNA frequencies.

The only other requirement, when using quasi-

count, is that the header section of the SAM file is

intact as the tool uses the information given therein

to identify the sequenced shRNAs.

2.4 Statistical Inference

This part of the pipeline is implemented in the

programming language R. The R script contains

functions to read in the quality assessment data and

print them out in a single PDF file, read in the count

matrix textfile to start differential abundance

analysis or visualize the Pearson correlation between

samples.

Differential abundance analysis is done by the

freely available R packages DESeq (Anders and

Huber, 2010), edgeR (Robinson et al., 2010) or

baySeq (Hardcastle and Kelly, 2010). The statistical

assumptions, made in all three packages, are based

on a negative-binomial rather than a Poisson

distribution of the counts. The assumption of a

Poisson distribution is not applicable in this case,

due to the additional sources of variance

(overdispersion), when including biological replicate

samples, that cannot be accounted for as has been

shown by Lu et al., (2005). This underestimation of

the variance leads to an increased number of type-I

errors, that is false positive discoveries of

differential abundance.

Figure 3: Example Venn diagram of significantly

differentially abundant shRNAs inferred by baySeq,

edgeR and DESeq.

BIOINFORMATICS2013-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

290

After completing the differential abundance

analysis, the shRNAs that have shown statistically

significant changes in frequencies between analyzed

samples are saved in a plain text file for possible

further downstream analysis (e.g. GSEA, GO term

enrichment, etc.).

We recommend executing all three packages to

create a list containing only the overlap of shRNAs,

presumed to be differentially abundant (Figure 3).

This list is the most conservative estimate of

relevant shRNAs.

3 CONCLUSIONS

QUASI presents itself as a user-friendly and time-

efficient pipeline. Streamlining the analysis of

pooled shRNA library screens was achieved through

blackboxing the complex configurations, thus

decreasing the time span from raw to evaluated data.

4 AVAILABILITY

The software is freely available under the GPL

license from http://sourceforge.net/projects/quade.

Also, a detailed tutorial can be found at the URL

mentioned above, presenting the user a step-by-step

guide.

REFERENCES

Anders, S. & Huber, W., 2010. Differential expression

analysis for sequence count data. Genome biology,

11(10), p.R106.

Andrews, S., 2010. FastQC: A quality control tool for high

throughput sequence data. Available at:

http://www.bioinformatics.bbsrc.ac.uk/projects/fastqc/

Elbashir, S. M. et al., 2001. Duplexes of 21-nucleotide

RNAs mediate RNA interference in cultured

mammalian cells. Nature, 411(6836), pp.494–8.

Ewing, B. et al., 1998. Base-calling of automated

sequencer traces usingPhred. I. Accuracy assessment.

Genome research, pp.175–185.

Fewell, G. D. & Schmitt, K., 2006. Vector-based RNAi

approaches for stable, inducible and genome-wide

screens. Drug discovery today, 11(21-22), pp.975–82.

Fire, A. et al., 1998. Potent and specific genetic

interference by double-stranded RNA in

Caenorhabditis elegans. Nature, 391(6669), pp.806–

11.

Hannon, G., 2012. The FASTX-toolkit. Available at:

http://hannonlab.cshl.edu/fastx_toolkit/.

Hardcastle, T. J. & Kelly, K. A., 2010. baySeq: empirical

Bayesian methods for identifying differential

expression in sequence count data. BMC

bioinformatics, 11(1), p.422.

Kircher, M., Stenzel, U. & Kelso, J., 2009. Improved base

calling for the Illumina Genome Analyzer using

machine learning strategies. Genome biology, 10(8),

p.R83.

Langmead, B. et al., 2009. Ultrafast and memory-efficient

alignment of short DNA sequences to the human

genome. Genome biology, 10(3), p.R25.

Li, H. & Durbin, R., 2009. Fast and accurate short read

alignment with Burrows-Wheeler transform.

Bioinformatics (Oxford, England), 25(14), pp.1754–

60.

Liu, C.-M. et al., 2012. SOAP3: Ultra-fast GPU-based

parallel alignment tool for short reads. Bioinformatics

(Oxford, England), pp.24–25.

Lu, J., Tomfohr, J. K. & Kepler, T. B., 2005. Identifying

differential expression in multiple SAGE libraries: an

overdispersed log-linear model approach. BMC

bioinformatics, 6, p.165.

Robinson, M. D., McCarthy, D. J. & Smyth, G. K., 2010.

edgeR: a Bioconductor package for differential

expression analysis of digital gene expression data.

Bioinformatics (Oxford, England), 26(1), pp.139–40.

QUASI:APipelinefortheQualityAssessmentandStatisticalInferenceonNextGenerationSequencingDatafromPooled

shRNALibraryScreens

291
