Multi-criteria Evaluation of Class Binarization and Feature Selection in

Tear Film Lipid Layer Classiﬁcation

Rebeca M´endez, Beatriz Remeseiro, Diego Peteiro-Barral and Manuel G. Penedo

Departamento de Computaci´on, Universidade da Coru˜na, Campus de Elvi˜na s/n, 15071, A Coru˜na, Spain

Keywords:

Tear Film Lipid Layer, Class Binarization Techniques, Feature Selection, Filters, Multiple Criteria Decision

Making, Multilayer Perceptron.

Abstract:

Dry eye is an increasingly popular syndrome in modern society which can be diagnosed through an automatic

technique for tear ﬁlm lipid layer classiﬁcation. Previous studies related to this multi-class problem lack of

analysis focus on class binarization techniques, feature selection and artiﬁcial neural networks. Also, all of

them just use the accuracy of the machine learning algorithms as performance measure. This paper presents

a methodology to evaluate different performance measures over these unexplored areas using the multiple

criteria decision making method called TOPSIS. The results obtained demonstrate the effectiveness of the

methodology proposed in this research.

1 INTRODUCTION

The tear ﬁlm is a complex layer of liquid covering the

anterior surface of the eye. It was classically deﬁned

by Wolff (E.Wolff, 1954) as a three-layered structure

which consists of an anterior lipid layer, an interme-

diate aqueous layer and a deep mucin layer. The tear

ﬁlm is a essential component of the eye which plays

some important functions (Korb, 2002), such as vi-

sual and cleaning functions. Also, it plays an essential

role in the maintenance of ocular integrity by remov-

ing foreign bodies from the front surface of the eye.

The lipid layer is the outermost and thinnest layer

of the tear ﬁlm and it is mainly secreted by the meibo-

mian glands (Nichols et al., 2004). It is a crucial com-

ponent of the tear ﬁlm because it provides a smooth

optical surface for the cornea and retards evaporation

of the eye during the inter-blink period (Bron et al.,

2004). Other functions of the lipid layer are estab-

lishing the tear ﬁlm or sealing the lid margins during

sleep.

Quantitative or qualitative changes in the normal

lipid layer have a negative effect on the evaporation

of tears from the ocular surface and on the quality of

vision (Rolando et al., 1998). In fact, these changes

are associated with the evaporative dry eye (EDE),

since it refers to disorders of the tear ﬁlm caused by

poor tear quality, reduced tear production or excessive

evaporation (Rolando et al., 1983). The international

committee of Dry Eye Workshop (DEWS) deﬁned the

EDE as follows (Lemp et al., 2007):

Dry Eye is a multifactorial disease of the tears

and the ocular surface that results in symp-

toms of discomfort, visual disturbance, and

tear ﬁlm instability with potential damage to

the ocular surface. It is accompanied by in-

creases osmolarity of the tear ﬁlm inﬂamma-

tion of the ocular surface

This disease affects a wide sector of the population,

specially among contact lens users, and worsens with

age. The proportion of people with EDE has in-

creased due to the current work conditions (Lemp

et al., 2007), such as computer use.

EDE diagnosis is very difﬁcult to accomplish, ba-

sically because of its multifactorial nature. There are

several clinical tests which measures the tear quality

and the quantity of tears. One of these test is called

lipid layer pattern assessment and consists on eval-

uating tear ﬁlm quality and lipid layer thickness by

non-invasively imaging the superﬁcial lipid layer by

interferometry. This test is based on a standard clas-

siﬁcation deﬁned by Guillon (Guillon, 1998), who

established various categories of lipid layer patterns:

open meshwork, closed meshwork, wave and color

fringe. Note that EDE is associated with the lipid

layer thickness since a thinner lipid layer speeds up

water evaporation, which means a reduction in tear

ﬁlm stability. Many eye care professionals have aban-

doned this test because it is very difﬁcult to inter-

Méndez R., Remeseiro B., Peteiro-Barral D. and G. Penedo M..

Multi-criteria Evaluation of Class Binarization and Feature Selection in Tear Film Lipid Layer Classiﬁcation.

DOI: 10.5220/0004224300620070

In Proceedings of the 5th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2013), pages 62-70

ISBN: 978-989-8565-39-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

pret the lipid layer patterns, specially the thinner ones

which lack color and/or morphological features. Nev-

ertheless, there is no doubt that this technique is a

valuable test which provides relevant information by

using noninvasive techniques. For this reason, the tear

ﬁlm lipid layer automatic classiﬁcation could become

a key step to diagnose EDE.

Some techniques have been designed to objec-

tively calculate the lipid layer thickness by analyz-

ing the interference color with an interference cam-

era (Goto et al., 2003) or by using a sophisticated op-

tic system (King-Smith et al., 1999). However, ﬁrst

attempts to automatize the lipid layer pattern assess-

ment test can be found in (Calvo et al., 2010; Ramos

et al., 2011; Garc´ıa-Res´ua et al., 2012) which demon-

strate how the interference phenomena can be charac-

terized as a color texture pattern. Therefore, the auto-

matic test can save time for experts and eliminate the

subjectivity of the process. Further investigation was

carried out in (Remeseiro et al., 2011) where a set of

color texture analysis techniques was applied to tear

ﬁlm lipid layer classiﬁcation and the previous results

were improved. Regarding machine learning tech-

niques, the behavior of ﬁve different algorithms was

studied over this set of color texture analysis methods

in (Remeseiro et al., 2012). A statistical comparison

of them was performed using only the accuracy of the

classiﬁers.

To the best knowledge of the authors, there are

no attempts in the literature to study this multi-class

problem using class binarization techniques. Class bi-

narization techniques may improve performance on

multi-class problems of learners which could directly

handle multi-class classiﬁcation (Furnkranz, 2002a;

Rifkin and Klautau, 2004). Furthermore, all previ-

ous researches analyses the color texture characteriza-

tion based on the accuracy of the classiﬁers, no other

performance measures were studied. In relation to

machine learning techniques, there is no deep study

about the performance of artiﬁcial neural networks

(ANNs). Finally, the number of features which deﬁne

the color texture pattern used to characterize the in-

terference phenomena is large enough to consider the

use of feature selection techniques.

In this sense, there are a lot of unexplored areas

of study in tear ﬁlm lipid layer automatic classiﬁca-

tion. Thus, a research methodology is proposed in

this work to analyze the performance of class bina-

rization techniques and feature selection methods ap-

plied to tear ﬁlm classiﬁcation using ANNs. For this

purpose, the obtained results will be analyzed in terms

of a wide set of performance measures and a multiple

criteria decision making method will be used in order

to validate the different approaches.

This paper is organized as follows: section 2 de-

scribes the steps of the research methodology, section

3 explains the experimental study performed, section

4 shows the results and discussion, and section 5 in-

cludes the conclusions and future lines of research.

2 RESEARCH METHODOLOGY

The methodology proposed in this search aims to

evaluate tear ﬁlm lipid layer classiﬁcation in terms

of several criteria when using class binarization tech-

niques and feature selection methods.

2.1 Class Binarization Techniques

Methods can be roughly divided between two dif-

ferent approaches—the “single machine” approaches,

which construct a multi-class classiﬁer by solving a

single optimization problem, and the “error correct-

ing” approaches, which use the ideas from error cor-

recting coding theory to combine a set of binary clas-

siﬁers (Rifkin and Klautau, 2004). There exist sev-

eral techniques for turning multi-class problems into

a set of binary problems (Dietterich and Bakiri, 1995;

Crammer and Singer, 2002; Furnkranz, 2002b; Hsu

and Lin, 2002). A class binarization is a mapping

of a multi-class learning problem to several two-class

learning problems in a way that allows a sensible de-

coding of the prediction (Furnkranz, 2002b).

• The “one-vs-all” strategy consists in constructing

one classiﬁer per class, which is trained to distin-

guish the samples of one class from the samples of

all remaining classes. These two-class problems

are constructed by using the examples of class i

as the positive examples and the examples of the

rest of the classes as the negative examples.

• The “one-vs-one” strategy consists in training one

classiﬁer for each pair of classes. Thus, for a prob-

lem with c classes,

c(c−1)

subproblems are con-

structed to distinguish the samples of one class

from the samples of another class. The binary

classiﬁer for a problem is trained with examples of

its corresponding classes i, j, whereas examples

of the rest of classes are ignored for this problem.

2.1.1 Decoding Methods

If the classiﬁers are soft, as is the case of ANNs, they

compute the “likelihood” of classes for a given input,

that is they obtain a conﬁdence p for the positive class

and a conﬁdence of 1− p for the negative class. The

decoding method in the one-vs-all technique, if we as-

sume the one-part as the positive class and the all-part

Multi-criteriaEvaluationofClassBinarizationandFeatureSelectioninTearFilmLipidLayerClassification

as the negative class, is simply done according to the

maximum probability p among classes. However, this

method is not appropriate for one-vs-one binarization

techniques. Therefore, several decoding methods for

one-vs-one binarization techniques are described as

follows,

• Hamming Decoding. Dietterich and Bakiri (Di-

etterich and Bakiri, 1995) suggested the use of a

matrix M ∈ {−1, 1}

N×F

, where N is the number

of classes and F is the number of binary classi-

ﬁers. The i-th row of the matrix induces a parti-

tion of the classes into two “metaclasses”, where

a sample x

is placed in the positive metaclass for

the j-th classiﬁer if and only if M

= 1 (Rifkin

and Klautau, 2004), where y

stands for the de-

sired class of sample x

. If a new sample ap-

pears for classiﬁcation, the Hamming distance be-

tween the sign of the output of every binary clas-

siﬁer f

(x), .. . , f

(x) and each row of the matrix

M is then compared as follows, choosing the min-

imizer,

f(x) = arg min

r=1...N

∑

i=1



1− sign(M

(x))



where sign(z) = +1 if z > 0, sign(z) = −1 if z < 0,

and sign(z) = 0 if z = 0. In (Allwein et al., 2001),

Allwein, Schapire and Singer extended the earlier

work of Dietterich and Bakiri. They chose the ma-

trix M ∈ {−1, 0, 1}

N×F

, rather than only allowing

-1 and 1 as entries in the matrix. If M

= 0, then

example x

is not used when the j-th classiﬁer is

trained.

• Loss-based Decoding. The major disadvantage of

Hamming decoding is that it ignores the signiﬁ-

cance of the predictions, which can be interpreted

as a measure of conﬁdence. If the classiﬁers are

soft, in (Allwein et al., 2001) the authors suggest

using the loss function L instead of the Hamming

distance. They proposed that the prediction for a

sample x should be the class n that minimizes the

total loss under the assumptions that the label for

sample x in the f-th binary classiﬁer is M

f(x) = arg min

r=1...N

∑

i=1

L(M

(x))

The loss function depends on the learning algo-

rithm. In this research, the most appropriate loss

function is the logistic regression L(z) = log(1+

−2z

) (Allwein et al., 2001).

• Accumulative probability with threshold. If the

classiﬁers obtain a conﬁdence p for the positive

class and a conﬁdence of 1 − p for the nega-

tive class, the accumulative probability for every

class is computed as the sum of their correspond-

ing probabilities p. The prediction for a sample

should be the class that maximizes the accumu-

lative sum. The accumulative probability with

threshold takes into consideration binary classi-

ﬁers that will be ignored if the difference between

p and 1− p is under a threshold ε. It is assumed

that ignored classiﬁers will correspond with class

samples not used for their training procedure. In

other words, only signiﬁcant positive or negative

probabilities will be considered.

2.2 Feature Selection

Feature selection is a dimensionality reduction tech-

nique aimed at detecting relevant features and dis-

carding irrelevant ones, with the goal of obtaining a

subset of features that describes properly the given

problem with minimum degradation of performance

(Guyon et al., 2006). Thus, feature selection is helpful

in reducing the computational effort, allocated mem-

ory and training time.

There exists three different models for feature

selection: ﬁlter, wrapper and embedded methods.

Wrappers use a prediction method to score subsets of

features. Filters rely on the general characteristics of

the training data to select features with independence

of the classiﬁer. Halfway these two models, embed-

ded methods perform feature selection as part of the

training process of the classiﬁer. It is well-known

that wrappers and embedded methods have the risk of

overﬁtting when having more features than samples

(Loughrey and Cunningham, 2005), as it is the case in

this research. Therefore, ﬁlters were chosen because

they prevent the risk of overﬁtting and also allow for

reducing the dimensionality of the data without com-

promising time and memory requirements of learning

algorithms.

The three ﬁlters used in this work will be de-

scribed as follows. They were selected based on pre-

vious researches (Bol´on-Canedo et al., 2011; Bol´on-

Canedo et al., 2011).

• Correlation-based Feature selection (CFS) is a

simple ﬁlter algorithm that ranks feature subsets

according to a correlation based heuristic evalua-

tion function (Hall, 1999). The bias of the evalu-

ation function is toward subsets that contain fea-

tures that are highly correlated with the class and

uncorrelated with each other. Irrelevant features

should be ignored because they will have low cor-

relation with the class. Redundant features should

be screened out as they will be highly correlated

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

with one or more of the remaining features. The

acceptance of a feature will depend on the ex-

tent to which it predicts classes in areas of the

instance space not already predicted by other fea-

tures. CFS’s feature subset evaluation function is

deﬁned as,

k+ k(k− 1)r

f f

where M

is the heuristic “merit” of a feature sub-

set S containing k features, r

is the mean feature-

class correlation (f ∈ S) and r

f f

is the average

feature-feature intercorrelation. The numerator of

this equation can be thought of as providing an

indication of how predictive of the class a set of

features is; and the denominator of how much re-

dundancy there is among the features.

• Consistency-based ﬁlter (Dash and Liu, 2003)

evaluates the worth of a subset of features by the

level of consistency in the class values when the

training instances are projected onto the subset of

attributes. The algorithm generates a random sub-

set S from the number of features in every round.

If the number of features of S is less than the cur-

rent best,the data with the features prescribed in

S is checked against the inconsistency criterion.

If its inconsistency rate is below a pre-speciﬁed

one, S becomes the new current best. The incon-

sistency criterion, which is the key to the success

of this algorithm, speciﬁes to what extent the di-

mensionally reduced data can be accepted. If the

inconsistency rate of the data described by the se-

lected features is smaller than a pre-speciﬁed rate,

it means the dimensionally reduced data is accept-

able.

• INTERACT (Zhao and Liu, 2007) is a subset ﬁl-

ter based on symmetrical uncertainty (SU) (Press

et al., 1986), which is deﬁned as the ratio between

the information gain (IG) and the entropy (H) of

two features, x and y:

SU(x, y) =

2IG(x|y)

H(x) + H(y)

where the information gain is deﬁned as:

IG(x|y) = H(y) + H(x) − H(x, y)

being H(x) the entropy and H(x, y) the joint en-

tropy. Besides SU, INTERACT also includes

the consistency contribution (c-contribution). C-

contribution of a feature is an indicator about how

signiﬁcantly the elimination of that feature will af-

fect consistency. The algorithm consists of two

major parts. In the ﬁrst part, the features are

ranked in descending order based on their SU val-

ues. In the second part, features are evaluated one

by one starting from the end of the ranked feature

list. If c-contribution of a feature is less than an

established threshold, the feature is removed, oth-

erwise it is selected. The authors stated in (Zhao

and Liu, 2007) that INTERACT can thus handle

feature interaction, and efﬁciently selects relevant

features.

2.3 Multiple-criteria Decision-making

Classiﬁcation algorithms are normally evaluated in

terms of multiple criteria such as accuracy, preci-

sion or training time. Thus, algorithm selection can

be modeled as a multiple-criteria decision-making

(MCDM) problem. MCDM methods evaluate clas-

siﬁers from different aspects and produce rankings of

classiﬁers (Kou et al., 2012). Among many MCDM

methods that have been developed up to now, tech-

nique for order of preference by similarity to ideal so-

lution (TOPSIS) (Hwang and Yoon, 1981) is a well-

known method that will be used in this research.

2.3.1 TOPSIS

TOPSIS is a MCDM method proposed by Hwang

and Yoon in 1981 (Hwang and Yoon, 1981). It ﬁnds

the best algorithms by minimizing the distance to the

ideal solution whilst maximizing the distance to the

anti-ideal one. The extension of TOPSIS proposed

by Opricovic and Tzeng (Opricovic and Tzeng, 2004)

and Olson (Olson, 2004) is used in this research,

1. Compute the decision matrix consisting of m al-

ternatives and n criteria. For alternative A

, i =

1, . . . , m, the performance measure of the j-th cri-

terion C

, j = 1, . . . , n, is represented by x

2. Compute the normalized decision matrix. The

normalized value r

is calculated as,

∑

i=1

3. Develop a set of weights w, where w

is the weight

of the j-th criterion and

∑

j=1

= 1, and compute

the weighted normalized decision matrix. The

weighted normalized value v

is computed as,

= x

4. Find the ideal alternative solution S

and the anti-

ideal alternative solution S

−

, which are computed

as,

Multi-criteriaEvaluationofClassBinarizationandFeatureSelectioninTearFilmLipidLayerClassification

= {v

, . . . , v

} =



max

|i ∈ I

′





min

|i ∈ I

′′



and

−

= {v

−

, . . . , v

−

} =



min

|i ∈ I

′





max

|i ∈ I

′′



respectively, where I

′

is associated with beneﬁt

criteria and I

′′

is associated with cost criteria.

5. Compute the distance of each alternative from the

ideal solution and from the anti-ideal solution, us-

ing the Euclidean distance,

∑

j=1

− v

)

and

−

∑

j=1

− v

−

)

respectively.

6. Compute the ratio R

equal to the relative close-

ness to the ideal solution,

−

+ D

−

7. Rank alternatives by maximizing the ratio R

3 EXPERIMENTAL STUDY

The aim of this research is to evaluate the inﬂuence

of binarization and feature selection in tear ﬁlm lipid

layer classiﬁcation. The multilayer perceptron (MLP)

was selected as base learning algorithm.

3.1 Data Source

The methodology proposed in this research has been

tested on the VOPTICAL-I1 dataset (Remeseiro,

2012). This set includes 105 images categorized by

optometrists from the School of Optics and Optom-

etry of the University of Santiago de Compostela

(Spain). All these images were acquired from healthy

subjects aged from 19 to 33 years. The dataset in-

cludes 29 open meshwork, 29 closed meshwork, 25

wave and 22 color fringe images. In (Remeseiro

et al., 2011), it was demonstrated that the interfer-

ence phenomena can be characterized as a color tex-

ture pattern and the automatic classiﬁcation into Guil-

lon categories is feasible. The results presented by

Remeseiro et al. (Remeseiro et al., 2011) show how

co-occurrence features (Haralick et al., 1973), as a

feature extraction method, and the Lab color space

(McLaren, 1976) provide the highest discriminative

power from a wide range of methods analyzed. From

a single image, a quantitative vector composed of 588

features is obtained to categorize it.

3.2 Performance Measures

Most performance measures in machine learning are

deﬁned to be used in two-class problems. Since a

multi-class problem is studied in this research, all

these measures will be calculated for each class indi-

vidually. As tear ﬁlm lipid layer classiﬁcation is a 4-

class problem, the total number of measures would be

four times the number of binary measures. In order to

reduce the total amount of measures, each multi-class

measure will be obtained as the minimum of its four

binary measures according to (Fernandez Caballero

et al., 2010). Thus, the performance of the learning

algorithms are computed as a lower bound, or pes-

simistic, estimation.

The binary performance measures considered are:

accuracy, true positive rate (TPR), true negative rate

(TNR), precision, F-measure and area under the curve

(AUC).

Finally, the training time of the learning algo-

rithms is also considered. It comprises the time

elapsed for training a learning model. Notice that this

comprises training a set of classiﬁers when class bina-

rization techniques are used. Note also that the test-

ing time, that is the time elapsed for outputting a new

classiﬁcation, is negligible thus it will not be consid-

ered as a selection criterion.

3.3 Experimental Procedure

A leave-one-out cross-validation was used, which

consists in using a single sample from the dataset as

the test set and the remaining samples are retained as

the training set. This process is repeated such that

each sample is used once as the test set. The experi-

mental research was carried out as follows,

1. Apply the three feature selection methods

(CFS, consistency-based and INTERACT) to the

VOPTICAL-I1 dataset, to provide the subset of

features that properly describes the given prob-

lem. Note that the binarization techniques modify

the output of the dataset thus the feature selection

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

methods have to be applied on each “dataset”, that

is,

• In the one-vs-all technique, four subsets of fea-

tures are obtained corresponding with 1-vs-all,

2-vs-all, 3-vs-all and 4-vs-all datasets.

• In the one-vs-one technique, six subsets of fea-

tures are obtained corresponding with 1-vs-

2, 1-vs-3, 1-vs-4, 2-vs-3, 2-vs-4 and 3-vs-4

datasets.

2. Train a MLP for each combination of binarization

technique, feature selection method, and num-

ber of hidden units. In (Hecht-Nielsen, 1990), it

was demonstrated that a MLP that contains a sin-

gle hidden layer with sufﬁcient number of hidden

units is able to approximate any function. Thus,

only the number of hidden units will vary in this

research ranging from 2 to 64. In particular, 2, 4,

8, 16, 32, and 64 hidden units were tested. Empir-

ical results showed risk of overﬁtting for a larger

number of hidden units. Finally, the mean square

error was used as error function and the hyper-

bolic tangent sigmoid was used as transfer func-

tion in the processing units.

3. Compute the performance measures, that is, accu-

racy, TPR, TNR, precision, F-measure, AUC and

training time.

4. Apply TOPSIS in order to evaluate the different

binarization techniques, feature selection methods

and number of hidden units proposed in this re-

search. The values of the weights (see Section

2.3.1) are assigned equally, except for the train-

ing time that is reduced to 0.01. Notice that the

training step is executed off-line, making its value

not as relevant as the other performancemeasures.

Note also that the training time is a cost criteria

while the other measures are beneﬁt criteria.

Experimentation was performed on an Intel



Core

i5-650 CPU @ 4M Cache, 3.20 GHz with RAM 6

GB DDR3. Matlab was the software used to train the

MLP networks.

4 RESULTS

Table 1 shows the number of features selected by

the three feature selection ﬁlters (CFS, consistency-

based, and INTERACT) in single machine, one-vs-

all, and one-vs-one approaches. The median percent-

age of features selected (out of 588 features) is in

parenthesis.

Broadly speaking, consistency-based ﬁlter per-

formed the most aggressive selection retaining only

Table 1: Number of features selected by the three ﬁlters

in single machine, one-vs-all, and one-vs-one approaches

(median percentage in parentheses).

Technique

Feature selection

CFS Cons INT

Single 27 6 21

Median(%) (4.59%) (1.02%) (3.57%)

One-vs-all 1-vs-all 17 2 14

2-vs-all 27 6 17

3-vs-all 11 3 14

4-vs-all 33 4 14

Median(%) (3.74%) (0.59%) (2.38%)

One-vs-one 1-vs-2 20 2 12

1-vs-3 53 1 53

1-vs-4 23 1 23

2-vs-3 27 3 14

2-vs-4 24 3 14

3-vs-4 27 4 13

Median(%) (4.34%) (0.43%) (2.38%)

the 1.02%, 0.59%, and 0.43% of the features in sin-

gle machine, one-vs-all, and one-vs-one approaches,

respectively. CFS retained from four to ten times

more features (4.59%, 3.74%, and 4.34%) than the

former. Halfway, INTERACT selected in average

3.57%, 2.38%, and 2.38% of the features, respec-

tively. As expected, in average the percentage of fea-

tures selected in the single machine approach is larger

than the percentage in binarization. Notice that bina-

rization may reduce the complexity of the problem.

The set of techniques, methods and topologies

used in this research lead to 120 alternatives in to-

tal. Thus, for purposes of simplicity only the most

signiﬁcant results are shown. Table 2 shows the top

20 results ranked by TOPSIS in terms of the binariza-

tion method, feature selection ﬁlter, number of hid-

den units (H), ratio R

(see TOPSIS, Section 2.3.1),

accuracy, TPR, TNR, precision, F-measure, AUC and

training time (in seconds). Note that single stands for

the single machine, multi-class, approach.

In general, the techniques and methods proposed

in this research outperform the single machine ap-

proach (see Table 2). In the top 20, 15 out of 20

classiﬁers use binarization, and 9 out of 20 classi-

ﬁers apply feature selection. Moreover, binarization

leads to smaller topologies in the MLP. In the top 20,

the average number of hidden units is 29.47 in bina-

rization against 51.20 in the single machine approach.

In a similar way, the average number of hidden units

is 35.77 when feature selection is applied whilst it is

42.18 when no feature selection selection is applied.

These are logical results because feature selection and

binarization reduce the size of the input and output

Multi-criteriaEvaluationofClassBinarizationandFeatureSelectioninTearFilmLipidLayerClassification

Table 2: Top 20 measure results obtained by TOPSIS.

# Method Filter H R

Acc. TPR TNR Prec. F AUC Time(s)

1 1-vs-all None 16 0.9876 0.96 0.92 0.97 0.92 0.93 0.95 118.12

2 1-vs-all None 8 0.9698 0.96 0.90 0.97 0.93 0.92 0.94 95.60

3 Single None 64 0.9560 0.96 0.91 0.96 0.90 0.92 0.94 125.83

4 Single CFS 64 0.9498 0.95 0.91 0.96 0.90 0.91 0.94 116.18

5 1-vs-1

†

CFS 64 0.9427 0.95 0.90 0.97 0.91 0.90 0.93 223.71

6 Single None 32 0.9404 0.95 0.91 0.96 0.89 0.91 0.94 90.18

7 1-vs-1

†

None 16 0.9386 0.95 0.90 0.96 0.90 0.90 0.94 214.07

8 1-vs-1

None 16 0.9354 0.95 0.90 0.96 0.90 0.90 0.93 195.33

9 1-vs-1

None 32 0.9353 0.95 0.91 0.97 0.89 0.90 0.94 221.36

10 1-vs-1

†

None 64 0.9352 0.95 0.91 0.97 0.89 0.90 0.94 298.69

11 1-vs-1

†

None 32 0.9294 0.95 0.89 0.96 0.90 0.90 0.93 231.25

12 1-vs-1

None 64 0.9293 0.95 0.89 0.96 0.90 0.90 0.93 287.23

13 1-vs-1

†

CFS 8 0.9159 0.94 0.89 0.96 0.90 0.89 0.92 185.72

14 1-vs-all None 32 0.9158 0.94 0.89 0.96 0.90 0.89 0.92 200.46

15 Single CFS 32 0.9155 0.95 0.88 0.96 0.89 0.90 0.93 95.65

16 1-vs-1

CFS 16 0.9142 0.95 0.89 0.96 0.88 0.90 0.93 187.08

17 1-vs-1

CFS 8 0.9058 0.94 0.88 0.96 0.88 0.90 0.93 183.44

18 Single INT 64 0.9040 0.94 0.88 0.95 0.88 0.90 0.93 130.61

19 1-vs-1

†

CFS 2 0.9037 0.94 0.88 0.96 0.89 0.89 0.92 205.10

20 1-vs-1

CFS 64 0.9020 0.95 0.89 0.96 0.87 0.89 0.94 221.06

Decoding methods in 1-vs-1 binarization: Hamming decoding

Loss-based decoding

†

space, respectively. Notice that the low number of

samples in the dataset, which is composed of 105 im-

ages, does not favor the use of the one-vs-one tech-

nique since the training datasets are reduced to the

samples of two classes.

5 CONCLUSIONS AND FUTURE

RESEARCH

Three binarization techniques and three feature selec-

tion methods have been used in this research for tear

ﬁlm lipid layer classiﬁcation. The evaluation of the

techniques and methods was based on several crite-

ria: accuracy, TPR, TNR, precision, F-measure, AUC

and training time. TOPSIS method was used as a tool

for selecting classiﬁcation algorithm when algorithm

selection involves more than one criterion. In general

terms, binarization and feature selection outperform

the single machine, multi-class, approach. To the best

knowledge of the authors, the use of binarization tech-

niques, features selection ﬁlters, and MCDM methods

was not attempt so far in the literature for improving

classiﬁcation performance in the assessment of the

tear ﬁlm lipid layer. These results demonstrate the

soundness of the methods presented in this research.

For future work, the authors plan to extend

this research to different learning algorithms (e.g.

naive Bayes classiﬁer or decision trees) and different

MCDM methods. Since different MCDM methods

will evaluate different learning classiﬁers from dif-

ferent criteria, they may produce divergent rankings.

Thus, the authors plan to implement an approach to

resolve disagreeing rankings.

ACKNOWLEDGEMENTS

This research has been partially funded by the Secre-

tar´ıa de Estado de Investigaci´on of the Spanish Gov-

ernment and FEDER funds of the European Union

through the research projects PI10/00578, TIN2009-

10748 and TIN2011-25476;and by the Conseller´ıa de

Industria of the Xunta de Galicia through the research

project CN2011/007. Beatriz Remeseiro and Diego

Peteiro-Barral acknowledge the support of Xunta de

Galicia under Plan I2C Grant Program.

We would also like to thank the Escuela de

Optica

y Optometr´ıa of the Universidade de Santiago de

Compostela for providing us with the annotated im-

age datasets.

REFERENCES

Allwein, E., Schapire, R., and Singer, Y. (2001). Reduc-

ing multiclass to binary: A unifying approach for mar-

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

gin classiﬁers. The Journal of Machine Learning Re-

search, 1:113–141.

Bol´on-Canedo, V., Peteiro-Barral, D., Alonso-Betanzos,

A., Guijarro-Berdi˜nas, B., and S´anchez-Maro˜no, N.

(2011). Scalability analysis of ANN training algo-

rithms with feature selection. Advances in Artiﬁcial

Intelligence, pages 84–93.

Bol´on-Canedo, V., S´anchez-Maro˜no, N., and Alonso-

Betanzos, A. (2011). On the behavior of feature

selection methods dealing with noise and relevance

over synthetic scenarios. In The 2011 International

Joint Conference on Neural Networks (IJCNN), pages

1530–1537. IEEE.

Bron, A., Tiffany, J., Gouveia, S., Yokoi, N., and Voon, L.

(2004). Functional aspects of the tear ﬁlm lipid layer.

Experimental Eye Research, 78(3):347–360.

Calvo, D., Mosquera, A., Penas, M., Garc´ıa-Res´ua, C., and

Remeseiro, B. (2010). Color Texture Analysis for Tear

Film Classiﬁcation: A Preliminary Study. In Lecture

Notes in Computer Science: International Conference

on Image Analysis and Recognition (ICIAR), volume

6112, pages 388–397.

Crammer, K. and Singer, Y. (2002). On the learnability and

design of output codes for multiclass problems. Ma-

chine Learning, 47(2):201–233.

Dash, M. and Liu, H. (2003). Consistency-based search

in feature selection. Artiﬁcial intelligence, 151(1-

2):155–176.

Dietterich, T. and Bakiri, G. (1995). Solving multiclass

learning problems via error-correcting output codes.

Journal of Artiﬁcial Intelligence Research, 2:263–

286.

E.Wolff (1954). Anatomy of the eye and orbit (4th edition).

H. K. Lewis and Co., London.

Fernandez Caballero, J., Mart´ınez, F., Herv´as, C., and

Guti´errez, P. (2010). Sensitivity versus accuracy in

multiclass problems using memetic pareto evolution-

ary neural networks. Neural Networks, IEEE Trans-

actions on, 21(5):750–770.

Furnkranz, J. (2002a). Pairwise classiﬁcation as an ensem-

ble technique. Machine Learning: ECML 2002, pages

9–38.

Furnkranz, J. (2002b). Round robin classiﬁcation. The Jour-

nal of Machine Learning Research, 2:721–747.

Garc´ıa-Res´ua, C., Gir´aldez-Fern´andez, M., Penedo, M.,

Calvo, D., Penas, M., and Yebra-Pimentel, E. (2012).

New software application for clarifying tear ﬁlm lipid

layer patterns. Cornea.

Goto, E., Yagi, Y., Kaido, M., Matsumoto, Y., Konomi, K.,

and Tsubota, K. (2003). Improved functional visual

acuity after punctual occlusion in dry eye patients. Am

J Ophthalmol, 135(5):704–705.

Guillon, J. (1998). Non-invasive tearscope plus routine for

contact lens ﬁtting. Cont Lens Anterior Eye, 21 Suppl

Guyon, I., Gunn, S., Nikravesh, M., and Zadeh, L. (2006).

Feature Extraction: Foundations and Applications.

Springer Verlag.

Hall, M. (1999). Correlation-based feature selection for

machine learning. PhD thesis, The University of

Waikato.

Haralick, R. M., Shanmugam, K., and Dinstein, I. (1973).

Textural Features for Image Classiﬁcation. IEEE

Transactions on Systems, Man, and Cybernetics,

3(6):610–621.

Hecht-Nielsen, R. (1990). Neurocomputing. Addison-

Wesley.

Hsu, C. and Lin, C. (2002). A comparison of methods for

multiclass support vector machines. IEEE Transac-

tions on Neural Networks, 13(2):415–425.

Hwang, C. and Yoon, K. (1981). Multiple attribute decision

making: methods and applications: a state-of-the-art

survey, volume 13. Springer-Verlag New York.

King-Smith, P., Fink, B., and Fogt, N. (1999). Three in-

terferometric methods for measuring the thickness of

layers of the tear ﬁlm. Optom Vis Sci, 76:19–32.

Korb, D. (2002). The Tear Film: Structure, Function and

Clinical Examination. Butterworth-Heinemann.

Kou, G., Lu, Y., Peng, Y., and Shi, Y. (2012). Evalua-

tion of Classiﬁcation Algorithms using MCDM and

Rank Correlation. International Journal of Infor-

mation Technology & Decision Making (IJITDM),

11(01):197–225.

Lemp, M., Baudouin, C., Baum, J., Dogru, M., Foulks, G.,

Kinoshita, S., Laibson, P., McCulley, J., Murube, J.,

Pfugfelder, S., Rolando, M., and Toda, I. (2007). The

deﬁnition and classiﬁcation of dry eye disease: Re-

port of the deﬁnition and classiﬁcation subcommittee

of the internation dry eye workshop (2007). Ocular

Surface, 5(2):75–92.

Loughrey, J. and Cunningham, P. (2005). Overﬁtting in

wrapper-based feature subset selection: The harder

you try the worse it gets. Research and Development

in Intelligent Systems XXI, pages 33–43.

McLaren, K. (1976). The development of the CIE 1976

(L*a*b) uniform colour-space and colour-difference

formula. Journal of the Society of Dyers and

Colourists, 92(9):338–341.

Nichols, K., Nichols, J., and Mitchell, G. (2004). The lack

of association between signs and symptons in patients

with dry eye disease. Cornea, 23(8):762–770.

Olson, D. (2004). Comparison of weights in TOPSIS mod-

els. Mathematical and Computer Modelling, 40(7-

8):721–727.

Opricovic, S. and Tzeng, G. (2004). Compromise solu-

tion by MCDM methods: A comparative analysis of

VIKOR and TOPSIS. European Journal of Opera-

tional Research, 156(2):445–455.

Press, W., Flannery, B., Teukolsky, S., Vetterling, W., et al.

(1986). Numerical recipes, volume 547. Cambridge

Univ Press.

Ramos, L., Penas, M., Remeseiro, B., Mosquera, A., Bar-

reira, N., and Yebra-Pimentel, E. (2011). Texture and

color analysis for the automatic classiﬁcation of the

eye lipid layer. In LNCS: Advances in Computational

Intelligence (International Work Conference on Arti-

ﬁcial Neural Networks-IWANN 2011), volume 6692,

pages 66–73.

Remeseiro, B. (2012). VOPTICAL I1, VARPA op-

tical dataset annotated by optometrists from

the Faculty of Optics and Optometry, Uni-

versity of Santiago de Compostela (Spain).

Multi-criteriaEvaluationofClassBinarizationandFeatureSelectioninTearFilmLipidLayerClassification

http://www.varpa.es/voptical I1.html, last access:

october 2012.

Remeseiro, B., Penas, M., Mosquera, A., Novo, J., Penedo,

M., and Yebra-Pimentel, E. (2012). Statistical com-

parison of classiﬁers applied to the interferential tear

ﬁlm lipid layer automatic classiﬁcation. Computa-

tional and Mathematical Methods in Medicine, 2012.

Remeseiro, B., Ramos, L., Penas, M., Mart´ınez, E., Penedo,

M., and Mosquera, A. (2011). Colour texture anal-

ysis for classifying the tear ﬁlm lipid layer: a com-

parative study. In International Conference on Dig-

ital Image Computing: Techniques and Applications

(DICTA), pages 268–273, Noosa, Australia.

Rifkin, R. and Klautau, A. (2004). In defense of one-vs-

all classiﬁcation. The Journal of Machine Learning

Research, 5:101–141.

Rolando, M., Iester, M., Marcr´ı, A., and Calabria, G.

(1998). Low spatial-contrast sensitivity in dry eyes.

Cornea, 17(4):376–379.

Rolando, M., Refojo, M., and Kenyon, K. (1983). In-

creased tear evaporation in eyes with keratoconjunc-

tivitis sicca. Arch Ophthalmol, 101(4):557–558.

Zhao, Z. and Liu, H. (2007). Searching for interacting

features. In Proceedings of the 20th international

joint conference on Artiﬁcal intelligence, pages 1156–

1161. Morgan Kaufmann Publishers Inc.

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence
