Development of Prediction Models under Multiple Imputation for

Coronary Heart Disease in Type 2 Diabetes Mellitus

Guozhi Jiang

, Eric S. Lau

, Ying Wang

, Andrea O. Luk

, Claudia H. Tam

, Janice S. Ho

Vincent K. Lam

, Heung M. Lee

, Xiaodan Fan

, Wing-Yee So

, Juliana C. Chan

and Ronald C. Ma

Department of Medicine and Therapeutics, The Chinese University of Hong Kong, Shatin, Hong Kong, SAR, China

Department of Statistics, The Chinese University of Hong Kong, Shatin, Hong Kong, SAR, China

Keywords: Multiple Imputation, Bootstrap, Prediction Model, Coronary Heart Disease, Type 2 Diabetes.

Abstract: The objectives of this study were to develop and compare the prediction models based on imputed data sets

with that based on complete-case (C-C) data set for coronary heart disease (CHD) in type 2 diabetes melli-

tus (T2DM) and to identify novel genes associated with CHD from T2DM related genes. A prospective co-

hort of 5526 patients with T2DM and without known CHD and heart failure at baseline was used in this

analysis. During a median follow-up time of 8.8 years, 406 (7.3%) patients developed incident CHD. Multi-

ple imputation (MI) was performed to tackle missing values for 26 clinical variables and 40 genetic varia-

bles, while Cox proportional hazards regression with backward variable selection was applied to bootstrap

samples. Five different MI or C-C models were compared and the performance based on C-index, 5 years

AUC and the slope of prognostic index were similar, three SNPs located at NEGR1, CDKAL1 and

ADAMTS9 were found to be significant after adjusting for clinical variables. In conclusion, multiple impu-

tation and bootstrap can be benefit to the development of prediction model, and a stable risk factor set for

CHD was successfully identified from our dataset containing clinical and genetic variables.

1 INTRODUCTION

The prevalence of type 2 diabetes mellitus (T2DM)

is increasing around the world, and it leads to a 2-4

fold increased risk of coronary heart disease (CHD)

compared to those patients without T2DM (Laakso,

2001). Based on Chinese diabetic population, (Yang

et al., 2008) has developed a CHD prediction model

using available clinical variables. Due to the com-

plexity of CHD, however, this disease is influenced

not only by lifestyle factors, but also by genetic fac-

tors (Vaarhorst et al., 2012). Simultaneously, taking

account of the relationship between T2DM and CHD,

it was hoped that T2DM associated genes were also

associated with CHD and could be used to predict

CHD risk.

In basis of practical problems in the application

of model development, such as the processing of

missing values and variable selection, we undertake

this study to further investigate Yang’s CHD predic-

tion model. The objectives are to 1) perform multi-

ple imputation (MI) to tackle the missing values and

compare the performance of models developed from

imputed data sets and from complete-case (C-C)

data set for Yang’s model, 2) select a stable CHD

predictor list from a data set containing clinical and

genetic variables, and 3) identify novel genes asso-

ciated with CHD from T2DM related genes.

2 PATIENTS AND METHODS

2.1 Study Cohort

The data of this study was a cohort of the Hong

Kong Diabetes Registry established in 1995 at a

regional Hong Kong hospital. Among the total of

6013 unrelated T2DM patients (age 56.8±13.3 yr,

46% male) selected from this registry, 487 patients

with known baseline CHD and heart failure were

excluded. Therefore, a CHD prospective cohort in-

cluding 5526 patients with detailed clinical infor-

mation was used in this analysis.

CHD definition and detailed assessments of-

methods and laboratory assays were exactly the

same as those described by (Yang et al., 2008). To

312

Jiang G., S. Lau E., Wang Y., O. Luk A., H. Tam C., S. Ho J., K. Lam V., M. Lee H., Fan X., So W., C. Chan J. and C. Ma R..

Development of Prediction Models under Multiple Imputation for Coronary Heart Disease in Type 2 Diabetes Mellitus.

DOI: 10.5220/0004244303120315

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2013), pages 312-315

ISBN: 978-989-8565-35-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Table 1: Parameter estimates for two CHD clinical models in Chinese type 2 diabetic patients.

Variable

MI Clinical Model C-C Clinical Model

Beta SE HR (95% CI) P Beta SE HR (95% CI) P

Age 0.035 0.005 1.04 (1.03-1.04) <0.001 0.034 0.005 1.03 (1.02-1.04) <0.001

Male sex 0.334 0.108 1.4 (1.13-1.72) 0.002 0.301 0.113 1.35 (1.08-1.69) 0.008

Current smoker 0.364 0.143 1.44 (1.09-1.91) 0.011 0.348 0.150 1.42 (1.06-1.9) 0.020

Duration of diabetes 0.029 0.007 1.03 (1.02-1.04) <0.001 0.029 0.007 1.03 (1.01-1.04) <0.001

Log10(ACR) 0.277 0.078 1.32 (1.13-1.54) <0.001 0.272 0.080 1.31 (1.12-1.54) <0.001

Log10(eGFR) -1.182 0.306 0.31 (0.17-0.56) <0.001 -1.254 0.344 0.29 (0.15-0.56) <0.001

Non-HDL cholesterol 0.208 0.043 1.23 (1.13-1.34) <0.001 0.214 0.045 1.24 (1.13-1.35) <0.001

compare with Yang’s model, the same list of 26

baseline clinical variables as Yang used was includ-

ed in this study. As the total cholesterol was linear

with non-high-density lipoprotein cholesterol and

high-density lipoprotein cholesterol, and the family

history of CHD was not available in this dataset,

they were excluded from this candidate list.

In addi-

tion, 40 published single-nucleotide polymorphisms

(SNPs) known to be associated with T2DM in ge-

nome-wide association study were genotyped. All

SNPs passed quality control for Hardy-Weinberg

equilibrium, minor allele frequency and SNP call

rate.

2.2 Multiple Imputation and Variable

Selection by Bootstrap

To impute the missing values, Multiple Imputation

via Chained Equations (MICE) procedure was per-

formed according to the guidelines described by

(van Buuren et al., 1999). In short, predictive mean

matching and polytomous regression were specified

for continuous and categorical variables, respective-

ly. All 7 clinical variables selected in Yang’s final

model, as well as the outcome variable and the natu-

ral logarithm of survival time, were always kept. As

it was recommended that the suitable number of

variables used in each imputation model should be

no more than 25, we set the cut-off value of correla-

tion to 0.1 for clinical variables and 0.03 for genetic

variables. After those steps, a series of imputation

models that consisted of the best 10 to 23 predictor

variables were built. Usually 5 to 10 repeated impu-

tations would be enough to achieve high efficiency,

here we generated 10 imputed data sets. Moreover,

Rubin’s rules were used to combine the regression

coefficients and variances.

To take the sampling variation into account and

get a stable variable subset, we applied Cox propor-

tional hazards regression with backward variable

selection (p <0.05 for stay) to 100 bootstrap samples

for each of 10 imputed data sets. We calculated the

inclusion frequency for each variable appearing in

1000 variable subsets, and selected the top variables

with frequencies more than 50% to develop models

on each imputed data set. Finally, those models were

pooled into a final model by Rubin’s rules.

2.3 Development of Prediction Models

To compare the performance of different models

based on imputed data sets and C-C data set, two

pairs of MI models and C-C models were developed:

1) MI Clinical Model and C-C Clinical Model. Both

models were developed using 7 clinical variables

that Yang selected. 2) MI Final Model and C-C Fi-

nal Model. These two models were developed using

the top clinical and genetic variables selected by

variable selection on imputed data sets. Furthermore,

in order to measure the model variation induced by

training/test split method as Yang used, we also con-

structed the C-C Split Models based on 7 clinical

variables. We randomly split the C-C data into 1:1

training and test sets for 100 times, and training sets

were used to develop models while test sets were

used to evaluate performance.

The performance of the MI models or C-C mod-

els was measured by discrimination and calibration.

Three different evaluation methods were employed

to measure the discrimination: overall C index, time-

dependent area under the curve (AUC) of receiver

operator characteristics (ROC) curves with 5 years

specified and category-free net reclassification im-

provement (NRI). Meanwhile, we used the slope of

the prognostic index (PI) to quantify calibration.

Furthermore, bootstrapping method as described by

(Harrel Jr, 1996) was applied to provide nearly unbi-

ased estimates of predictive performance.

DevelopmentofPredictionModelsunderMultipleImputationforCoronaryHeartDiseaseinType2DiabetesMellitus

313

Table 2: Parameter estimates for two CHD final models in Chinese type 2 diabetic patients.

Variable

Inclusion

Frequency

MI Final Model C-C Final Model

Beta SE

(95% CI)

Beta SE

(95% CI)

Age 99.8% 0.029 0.005

1.03

(1.02-1.04)

<0.001

0.027 0.006

1.03

(1.02-1.04)

<0.001

Duration

of diabetes

95.6% 0.030 0.007

1.03

(1.02-1.04)

<0.001

0.029 0.008

1.03

(1.01-1.04)

<0.001

Log10(eGFR) 89.8% -1.111 0.310

0.33

(0.18-0.60)

<0.001

-1.298 0.367

0.27

(0.13-0.56)

<0.001

HDL cholesterol 87.5% -0.566 0.159

0.57

(0.42-0.78)

<0.001

-0.575 0.182

0.56

(0.39-0.8)

0.002

Peripheral arte-

rial disease

78.4% 0.458 0.154

1.58

(1.17-2.14)

0.003

0.494 0.170

1.64

(1.18-2.29)

0.004

rs2568958 72.8% 0.313 0.122

1.37

(1.08-1.74)

0.010

0.373 0.130

1.45

(1.13-1.87)

0.004

rs7754840 69.3% -0.211 0.074

0.81

(0.70-0.94)

0.004

-0.191 0.083

0.83

(0.7-0.97)

0.021

Log10(ACR) 64.2% 0.233 0.082

1.26

(1.08-1.48)

0.004

0.264 0.091

1.3

(1.09-1.56)

0.004

LDL cholesterol 60.1% 0.213 0.048

1.24

(1.13-1.36)

<0.001

0.232 0.055

1.26

(1.13-1.41)

<0.001

Male sex 53.3% 0.288 0.109

1.33

(1.08-1.65)

0.008

0.306 0.124

1.36

(1.07-1.73)

0.013

Current smoker 51.1% 0.348 0.144

1.42

(1.07-1.88)

0.016

0.405 0.162

1.5

(1.09-2.06)

0.012

Systolic BP 50.2% 0.005 0.003

1.01

(1-1.01)

0.037

0.004 0.003

(1-1.01)

0.151

rs4607103 50.1% 0.150 0.076

1.16

(1-1.35)

0.049

0.141 0.084

1.15

(0.98-1.36)

0.094

3 RESULTS

3.1 Cohort Description

Of the total 5526 T2DM patients in CHD prospec-

tive cohort, 406 (7.3%) were found to develop CHD

during a median follow-up period of 8.8 (IQR: 6.0-

11.4) years. Patients who progressed to CHD were

significantly older, higher BP, higher HbA1c, had a

longer duration of diabetes, and were more likely to

use drugs, compared to those who didn’t develop

CHD. For the missing value percentage of each clin-

ical and genetic variable, most of them were less

than 10%, only one variable (rs10838738) reached

15% while 16 variables had no missing values.

3.2 Performance of Prediction Models

The estimates of parameters for MI Clinical Model

and C-C Clinical Model were similar (Table 1). All

7 factors were significant and the effects were close

in both models, but the MI Clinical Model had a

relative lower standard error for each factor. The

biased-corrected C-index and 5-years AUC were

very close, and both models showed good calibra-

tion (Table 3). When comparing with C-C Split

Models, the performance was also similar (0.734 vs.

0.728 for C-index, 0.738 vs. 0.732 for AUC), but the

ranges of indicators were larger in C-C Split Models.

The C-index and AUC for Yang’s CHD model were

0.704 and 0.737 respectively; these values were also

included in this range.

Table 2 presents the MI Final Model and C-C

Final Model, all selected factors were significant in

imputed data sets, but systolic BP and rs4607106

were not significant in C-C data set. The effect of

each factor was similar, and standard error was low-

er in MI Final Model. When comparing with Yang’s

model, the selected factor list was a little different. 6

variables were included in both models, but our

model selected HDL cholesterol and LDL cholester-

ol instead of non-HDL cholesterol, and 2 other vari-

ables (peripheral arterial disease and systolic BP) as

well as 3 SNPs (rs2568958, rs7754840 and

rs4607103). From table 3, the performance of MI

Final Model and C-C Final Model was close, but the

MI Final Model was slightly better than MI Clinical

Model (0.744 vs. 0.734 for C-index, and 0.748 vs.

0.738 for AUC). When considering the impact of

SNPs to prediction model, the NRI was 14.6% for

MI Final Model but only 2.5% for C-C Final Model.

BIOINFORMATICS2013-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

314

Table 3: Bias-corrected predictive performance for five different models.

MI Final Model* MI Clinical Model* C-C Final Model C-C Clinical Model C-C Split Models*

C-index 0.744 [0.742-0.744] 0.734 [0.733-0.738] 0.747 0.731 0.728 [0.683-0.753]

AUC 0.748 [0.747-0.749] 0.738 [0.736-0.741] 0.749 0.732 0.732 [0.678-0.765]

Slope 0.961 [0.954-0.966] 0.981 [0.976-0.992] 0.949 0.975 0.956 [0.67-1.209]

NRI 14.6% [10%-17.9%] / 2.47% / /

* Data are expressed as median [full range].

4 DISCUSSION

In this study, we have given an example to illustrate

the process of prediction model development based

on incomplete data. To get a more stable risk factor

set from clinical and genetic variable list for CHD in

T2DM, we integrated bootstrap and backward varia-

ble selection on imputed data sets.

Incomplete data are commonly encountered in

medical research. Excluding all patients with any

missing values may lose useful information and re-

duce the power of prediction model, which leads to

some variables not attaining statistical significance,

such as for the systolic BP and rs4607106 in our MI

Final Model and C-C Final Model. In our study, the

MI models are very similar to the C-C models, it is

because the missing rates are not high and the sam-

ple sizes are close, but imputation makes it more

powerful to perform variable selection.

Combining bootstrap resampling with variable

selection will be benefit to the stability of selected

variables. Through bootstrap and variable selection,

variables with strong effects on the outcome will be

selected more frequently than those with no or weak

effects. To validate a model, data-splitting as a sim-

ple method is commonly used, but the model per-

formance will vary greatly with different splits, and

bias will be introduced. Our results showed the boot-

strapping bias-corrected indicators of performance

were close to the median indicators produced by

multiple times training/test splits. Therefore, to en-

sure an honest model evaluation, we would better

evaluate the models by generating multiple pairs of

training/test sets or use bias-corrected method.

Importantly, three SNPs (rs2568958, rs7754840

and rs4607103 located at NEGR1, CDKAL1 and

ADAMTS9 gene, respectively) were selected with

high inclusion frequencies and the NRI results indi-

cated they contributed to the CHD prediction. There-

fore, these three T2D-related SNPs may also have

association effects with CHD. To validate the effect

of these SNPs, we will try to do some further anal-

yses, such as replication study.

In conclusion, this cohort study illustrated the

MICE and bootstrap can be benefit to the develop-

ment of prediction model based on dataset contain-

ing clinical and genetic variables. An informative

risk factor set for CHD, including three T2D-related

SNPs, was successfully identified from CHD pro-

spective cohort of Hong Kong Chinese patients with

T2DM. Future research will be needed to validate

the effect of these selected SNPs.

ACKNOWLEDGEMENTS

This work was supported by the Innovation and

Technology Fund (ITS/487/09FP), RGC Central

Allocation Scheme (CUHK 1/04C), RGC Ear-

marked Research Grant (CUHK4724/07M), and the

CUHK Direct Grant (2150476 and 2141611).

REFERENCES

Harrel Jr, F. E. a. L., K. L. and Mark, D. B. 1996. Tutorial

in biostatistics: multivariable prognostic models:

issues in developing models, evaluating assumptions

and adequacy, and measuring and reducing error.

Statistics in Medicine, 361–387.

Laakso, M. 2001. Cardiovascular disease in type 2

diabetes: challenge for treatment and prevention. J

Intern Med, 249, 225-35.

Vaarhorst, A. A., Lu, Y., Heijmans, B. T., Dolle, M. E.,

Bohringer, S., Putter, H., Imholz, S., Merry, A. H., van

Greevenbroek, M. M., Jukema, J. W., Gorgels, A. P.,

van den Brandt, P. A., Muller, M., Schouten, L. J.,

Feskens, E. J., Boer, J. M. & Slagboom, P. E. 2012.

Literature-based genetic risk scores for coronary heart

disease: the Cardiovascular Registry Maastricht

(CAREMA) prospective cohort study. Circ

Cardiovasc Genet, 5, 202-9.

van Buuren, S., Boshuizen, H. C. & Knook, D. L. 1999.

Multiple imputation of missing blood pressure

covariates in survival analysis. Stat Med, 18, 681-94.

Yang, X., So, W. Y., Kong, A. P., Ma, R. C., Ko, G. T.,

Ho, C. S., Lam, C. W., Cockram, C. S., Chan, J. C. &

Tong, P. C. 2008. Development and validation of a

total coronary heart disease risk score in type 2

diabetes mellitus. Am J Cardiol, 101, 596-601.

DevelopmentofPredictionModelsunderMultipleImputationforCoronaryHeartDiseaseinType2DiabetesMellitus

315
