A Combined SVM/HCRF Model for Activity Recognition based

on STIPs Trajectories

Mouna Selmi, Mounim A. El-Yacoubi and Bernadette Dorizzi

Institut Mines-Telecom / Telecom SudPari, Evry, France

Keywords: Human Activity Recognition, Hidden Conditional Random Field, SVM/HCRF Combination, Space-time

Interest Points’ Trajectories.

Abstract: In this paper, we propose a novel human activity recognition approach based on STIPs’ trajectories as local

descriptors of video sequences. This representation compares favorably with state of art feature extraction

methods. In addition, we investigate the use of SVM/HCRF combination for temporal sequence modeling,

where SVM is applied locally on short video segments to produce probability scores, the latter being

considered as the input vectors to HCRF. This method constitutes a new contribution to the state of the art

on activity recognition task. The obtained results demonstrate that our method is efficient and compares

favorably with state of the art methods on human activity recognition.

1 INTRODUCTION

Recognition of human activity from video sequences

has a wide range of real-world applications such as

video surveillance, assistance for elder care, human

robot interaction, video indexing, etc. As a

consequence, a large number of approaches have

been devoted to human activity recognition. Based

on the features used for recognition, these

approaches can be classified into two categories:

holistic approaches (Blank et al., 2005) and local

approaches (Dollar et al., 2005); (Laptev, 2005). The

first category uses explicit body representation by

extracting features from the whole silhouette and

exploits both spatial information and motion

trajectory. However, it requires background

segmentation and tracking of the body or of the body

parts which may be difficult in the case of complex

scenes that contain a dynamic background, fast

motion and self occlusion. The second category uses

local Interest Points. It achieves state-of-the-art

performance for motion recognition tasks in

complex real-world scenes when combined with a

bag-of-word (BOW) representation. The major

advantage of these approaches is to provide a

concise representation of events while avoiding the

pre-processing phases related to

foreground/background segmentation and to

tracking. These interest points are usually described

by histograms of gradients (HOG) and histograms of

optical flows (HOF). However, these gradient-based

descriptors ignore the spatio-temporal layout of the

local features which may be very informative.

Addressing this problem, some recent research

(Messing et al., 2009); (Matikainen et al., 2009);

(Sun et al., 2009); (Wang et al., 2011) exploit the

trajectories information of local features. These

approaches outperform BOW based approaches in

activity recognition tasks in complexes real-world

scenes. In (Messing et al., 2009), trajectories of

Harris interest points are used for complex daily

living activity recognition. These trajectories are

tracked with a standard KLT method and encoded as

sequences of log-polar quantized velocities. In

(Matikainen et al., 2009), Matikainen et al use a

quantization of local features trajectory based on a

k-means clustering and affine transformation. Sun et

al. (Sun et al., 2009) recently used similar techniques

to model SIFT-feature trajectories. They considered

a fixed-dimensional velocity description using the

stationary distribution of a Markov chain velocity

model. Wang et al. (Wang et al., 2011) used dense

trajectories by sampling dense points from each

frame in multiple scales. The trajectories are

described by HOG, HOF and motion boundary

histogram (MBH) calculated in a volume

surrounding each trajectory. However, these

methods track local features that were proposed

essentially for image recognition tasks which are not

necessarily adapted to space-time data. These image

features correspond to points with a signiﬁcant local

variation of intensities in the corresponding frame

568

Selmi M., A. El-Yacoubi M. and Dorizzi B. (2013).

A Combined SVM/HCRF Model for Activity Recognition based on STIPs Trajectories.

In Proceedings of the 2nd International Conference on Pattern Recognition Applications and Methods, pages 568-572

DOI: 10.5220/0004267405680572

 SciTePress

without any consideration of the temporal context.

In this work, we consider the use of the

trajectories of local space-time interest points

(STIPs) that correspond to points with significant

local variation in both space and time, thus

extending the approaches above which are limited to

2D interest points. In fact, STIPs have proven to be a

strong feature extraction method that has given

impressing results in real-world human action

recognition tasks. Our motivation is that STIPs’

trajectories can provide rich spatio-temporal

information about human activity at the local level.

For sequence modeling at the global level, a suitable

statistical sequence model is required.

Hidden Markov Models (HMMs) (Rabiner,

1989) have been widely used for temporal sequence

recognition. However, HMMs make strong

independence assumptions on feature independence

that are hardly met in human activity tasks.

Furthermore, generative models like HMMs often

use a joint model to solve a conditional problem,

thus focusing on modeling the observations that at

runtime are ﬁxed anyway. To overcome these

problems, Lafferty et al. (Lafferty et al., 2001) have

proposed powerful discriminative models:

Conditional Random Fields (CRF) for sequence text

labeling. CRF is a sequence labeling model that has

the ability to incorporate a long range dependency

among observations. CRF assign to each observation

in a sequence a label but it cannot capture intrinsic

sub-structures of observations. To deal with this,

CRF is augmented with hidden states that can model

the latent structures of the input domain with the so

called Hidden CRF (HCRF) (Quattoni, 2004). This

makes it better suited to modeling temporal and

spatial variation in an observation sequence. Such a

capability is particularly important as human

activities usually consist of a sequence of elementary

actions. However, HCRF needs a long time range

for the training phase. To overcome this problem we

propose to combine HCRF with a discriminative

local classifier (e.g SVM). The local classifier

predicts confidence of activity labels from input

vectors. We use the predicted confidence

measurements of different classes from the local

discriminative classifier as the input observation to

the HCRF model. Assuming, as is the usual case,

that the number of classes is significantly lower than

feature dimensionality, this will reduce as much the

feature space dimensionality during HCRF inference

while exploiting the high discriminative aspect of

SVM.

To summarize, the first objective of this paper is

to investigate the use of STIPs’ trajectories as

activity descriptors. To the best of our knowledge,

such a descriptor has not been addressed before in

the state of the art. The second objective is to assess

the discriminant power of HCRF-SVM combination

on a daily living activities recognition task. This

constitutes the second contribution of our work.

The organization of the paper is as follows.

Section 2 gives a brief description of local space

time features. HCRF and its combination with SVM

are reviewed in Section 3. In Section 4, the

databases used for experiments are described and

results are detailed and compared with the state of

the art. Section 5 draws some conclusions and

sketches futures directions of this work.

2 LOCAL SPACE-TIME

TRAJECTORIES

Local space-time features capture structural and

temporal information from a local region in a video

sequence. A variety of approaches exist to detect

these features (Wang et al., 2009). One of the most

popular methods is the one detecting Space Time

Interest Points (STIP), proposed by Laptev et al.

(Laptev et al., 2001), that extends Harris corner

detector to the space- time domain. The main idea is

to find points that have a significant change in space

and time.

To characterize the detected points, histograms

of gradients (HOG) and histograms of optical flows

(HOF) are usually calculated inside a volume

surrounding the interest point and used as

descriptors.

To provide a description at the video action

level, one of the most popular methods is to

represent each video sequence by a BOW of

HOG/HOF STIP’s descriptors. However, this

representation does not capture the spatio-temporal

layout of detected STIPs. To overcome this

limitation, a number of recent methods encode the

spatio-temporal distribution of interest points.

Nevertheless, these methods typically ignore the

spatio-temporal evolution of each STIP in the video

sequence. As mentioned above, some approaches

have attained a good result when using the

trajectories of 2D-interest points that are mainly

adapted to 2D space domain. In this section, we

present our approach of activity representation based

on the trajectories of STIPs (Figure 1) which are

adapted to video data.

To construct our basic feature, we first extract

STIPs from the video sequences. Then we track

them with Kanade-Lucas-Tomasi (KLT) tracker

ACombinedSVM/HCRFModelforActivityRecognitionbasedonSTIPsTrajectories

569

(Lucas and Kanade, 1981) for a fixed number of

frames T.

The trajectories description considered in this

work is based on the following three temporal

sequences:

- horizontal and vertical position trajectories:





=<



,



- path-tangent angle:





arctan

















,

- path velocity magnitude:

































where n1..N is the time index and N is the time

duration.

As shown in Section 4, STIPs’ trajectories

outperform 2D-interest points’ trajectories and

HOG/HOF descriptor.

Figure 1: Example of STIPs trajectories in KTH dataset.

3 SVM-HIDDEN CONDITIONAL

RANDOM FIELDS

COMBINATION

HCRF is a powerful discriminative model that can

be used to predict a label z from an input y. y is a

vector of local observations y = {y

, y

,… , y

} and

each local observation y

is represented by a feature

vector, z is a member of a set Z which represents the

class labels.

An HCRF models the conditional probability of

a class label given a set of observations by:

where the summation is over hidden state sequences

h, and ω represents a specific window size. The

potential function Ψ(z, h, y : θ, ω), parameterized by

θ and ω measures the compatibility between a label,

a set of observations and a configuration of the

hidden states. The following objective function is

used in estimating the parameters:

where n is the total number of training sequences.

The first term is the conditional log likelihood of the

labels given the data while the second is the log of a

Gaussian prior with variance 

The training phase aims at finding the best

parameters, θ

∗

= arg min -L(θ). It can be carried out

by gradient descent using LBFGS optimization

method (Byrd et al., 1995).

Given a new test sequence y and the parameters

values θ

∗

learned from training examples, the label

for the sequence is determined by:

As mentioned in the introduction, HCRF suffers

from a slow convergence during training. In fact,

HCRF uses, for parameter estimation, the forward–

backward algorithm that needs to scan the training

set many times. The training duration is correlated to

the dimension of data. To deal with this problem, we

use a SVM-HCRF combination. Using the

probability scores given by SVM as input of HCRF

will reduce considerably feature’s dimension and so

will accelerate the training and testing phases. In

addition, SVM is a popular method for classiﬁcation

tasks due to its high discriminative and

generalization properties. It also has the ability to

use high-dimensional feature spaces via kernels.

Thus, using SVM as a local classifier can improve

the recognition rate while ensuring a significant

training speed-up.

To train SVM, first we split the video sequence

into segments. Each segment is locally represented

by a local Bag of Words (frequency histogram of

visual word occurrences): visual words are

constructed using k-means based on trajectories

descriptors. We train SVM on these local Bag of

Words and the generated activity probability scores

will be considered as the input of HCRF.

4 EXPRIMENTS

We start this section by an evaluation of STIP’s

trajectories performance, and then we evaluate the

performance of our model in a complex daily living

activity recognition task.

4.1 STIPs Trajectories Evaluation

In this section, we evaluate the proposed STIPs’

trajectories in action recognition task and compare it

ICPRAM2013-InternationalConferenceonPatternRecognitionApplicationsandMethods

570

to state-of-the-art methods. We provide detailed

analysis below.

4.1.1 Dataset Description

The KTH dataset (Schuldt et al., 2004) is one of the

most common datasets in evaluation of action

recognition. It consists of six types of human

actions: boxing, hand clapping, hand waving,

jogging, running and walking; performed by 25

subjects in 4 different scenarios. We divide the

samples into test set (9 subjects) and training set (16

subjects) as is usually done.

4.1.2 Evaluation Framework

In this section, we compare STIPs and Speeded Up

Robust Features (SURF) (Bay et al., 2006)

trajectories. SURF is a scale and rotation invariant

detector of distinctive key points from images. The

extracted points correspond to corners detected on

the integral image. We also compare the

performance of STIPs’ descriptors: trajectories and

HOG/HOF. Theses comparisons are based on the

bag of features approach where each video sequence

is represented as the frequency histogram over visual

words. We begin by extracting STIPs. We track

them during 15 frames using KLT tracker. STIPs’

trajectories are then quantized into visual words

using k-means clustering. In our experiments, we set

the number of visual words to 80 which gives the

optimal result. Finally, the video descriptor is

obtained by assigning every local descriptor to the

nearest visual word. This descriptor is the input of a

Gaussian kernel SVM.

4.1.3 Results and Interpretation

As Table1 shows, our trajectory descriptor

outperforms the HOG/HOF descriptor that contains

rich information about texture and local motion. And

it also outperforms the SURFs’ trajectories’

descriptor based on Velocity histories. The accuracy

gained is principally due to the fact that STIPs are

sparse and correspond to points with significant

local variation in both space and time. In addition,

most detected SURFs belong to the background.

Table 1: Comparison results on KTH dataset.

Methods Rates (%)

STIPs trajectories 84.25

HOG/HOF [4] 80

Velocity Histories(Messing et al., 2009) 74

4.2 SVM-HCRF Combination

4.2.1 Dataset Description

We evaluate our model on the Rochester dataset

(Messing et al., 2009). It consists of 10 complex

daily living activities: answering a phone, dialling a

phone, looking up a phone number in a telephone

directory, writing a phone number on a whiteboard,

drinking a glass of water, eating snack chips, peeling

a banana, eating a banana, chopping a banana, and

eating food with silverware. It was each performed

three times by ﬁve persons. To ensure appearance

variation, the activities are performed by people

having different shapes, sizes, genders, and

ethnicities.

4.2.2 Evaluation Framework

To evaluate our activity recognition system, we

compute recognition accuracy using the leave-one-

person-out cross-validation method. Each time, we

first leave out all the sequences pertaining to one

person. Then, we train the model using all the

remaining sequences, and we use the 10 activities of

the omitted person as test data. We average out the

results from all the persons to obtain the average

recognition rate.

As stated above, we first extract STIPs'

trajectories for L=15 frames. For each trajectory, we

calculate its basic descriptor (P

, θ

) sequence.

Then, we construct K visual words using k-means

(K is empirically optimized, K=100). Each video is

split into smaller segments using a sliding window

of length 10. Each segment is locally represented as

a frequency histogram of word occurrences (local

Bag of Words). Based on these features, we train a

Gaussian kernel SVM in order to obtain the activity

probability scores for each segment. These

probability vectors are the input of our HCRF model

which is trained using ten hidden states.

4.2.3 Results and Interpretation

Table 2 compares our results to the state of the art.

Our approach significantly outperforms STIP-based

Bag-of-word approach based on HOG/HOF

descriptor. It also outperforms considerably the

recognition rate given by the “Latent Velocity

Histories” method (Messing et al., 2009): This

method is based on the velocity histories of the

SURF trajectories and Markov chain. Note that the

authors (Messing et al., 2009) have obtained an

important improvement (22%) by adding texture and

ACombinedSVM/HCRFModelforActivityRecognitionbasedonSTIPsTrajectories

571

color information. However, it is clear that color

information is actually irrelevant to activity

recognition. Although in (Messing et al., 2009), it

brings high improvements, this is due to the fact the

activities are performed in the same kitchen

consisting of the same objects (refrigerator, plates,

knives, etc.) whose color does not change. Had the

activities were performed in different locations with

different objects, using color would have actually

decreased performance.

Table 2: Results comparison on Rochester dataset.

Methods Rates (%)

Our approach 80

BOW of HOG/HOF (Messing et al., 2009) 59

Latent Velocity Histories(Messing et al., 2009) 67

Augmented Velocity Histories(Messing et al., 2009) 89

5 CONCLUSIONS

In this work we have introduced an approach for

activity recognition based on STIPs’ trajectories and

HCRF model. Our STIPs’ trajectories are more

robust than state-of-the-art interest point descriptors.

In fact, this descriptor captures the motion

information of efficient sparse interest points,

namely “3D Harris points”.

We also have described a new approach to train

an HCRF for high-dimensional feature sequences.

Our approach is based on SVM-HCRF combination.

It is faster and more scalable than standard HCRF

model.

Experiments show that the proposed method

achieves high accuracy.

The results obtained using

SVM-HCRF based on STIPs’ trajectories compare

favorably with the state of the art on the same

dataset. This is quite promising if we bear in mind

that no color information is considered in our

approach.

We have shown that trajectory descriptors

outperform STIP descriptors by a margin of 5%,

while consisting of a radically different feature

representation. The former is based on the intrinsic

information of the trajectory while the later is based

on a rough HOG/HOF description of STIP

neighborhood. An interesting consequence is that the

two representations are good candidates for feature

combination as their orthogonality means a real

potential for accuracy improvement. We intend to

explore this direction in our future work.

REFERENCE

M. Blank, L. Gorelick, E. Shechtman, M. Irani, and R.

Basri, (2005). Actions as space-time shapes, 2005. In

International Conference on Computer Vision.

P. Dollar, V. Rabaud, G. Cottrell, and S. Belongie, (2005).

Behavior recognition via sparse spatio-temporal

features. In VS-PETS, pages 65-7.

I. Laptev (2005). On space-time interest points. In. J.

Comput. Vision.

R. Messing, C. Pal, and H. Kautz, (2009). Activity

recognition using the velocity histories of tracked

keypoints. In ICCV.

P. Matikainen, M. Hebert, and R. Sukthankar, (2009).

Trajectons: Action recognition through the motion

analysis of tracked features. In ICCV workshop on

Video-oriented Object and Event Classification.

J. Sun, X. Wu, S. Yan, L.-F. Cheong, T.-S. Chua, and J.

Li, (2009). Hierarchical spatio-temporal context

modeling for action recognition. In CVPR.

Heng Wang, Alexander Kl¨aser, Cordelia Schmid, Cheng-

Lin Liu, (2011). Action Recognition by Dense

Trajectories. In CVPR: 3169-3176

Rabiner, L., (1989). A tutorial on HMM and selected

applications in speech recognition. In Proceedings of

the IEEE, 77(2):257–286.

J. Lafferty, A. McCallum, and F. Pereira, (2001).

Conditional random ﬁelds: probabilistic models for

segmenting and labeling sequence data. In ICML.

A. Quattoni, M. Collins, and T. Darrell, (2004).

Conditional random ﬁelds for object recognition. In

NIPS.

H. Wang, M. M. Ullah, A. Klaser, I. Laptev, and C.

Schmid, (2009). Evaluation of local spatio-temporal

features for action recognition. In British Machine

Vision Conference.

B. D. Lucas and T. Kanade (1981). An iterative image

registration technique with an application to stereo

vision. In IJCAI, pages 674–679.

Bay, H., Tuytelaars, T., and Gool, L. J. V., (2006). Surf:

Speeded up robust features. In ECCV (1)’06, pages

404–417.

R. H. Byrd, P. Lu and J. Nocedal, (1995). A Limited

Memory Algorithm for Bound Constrained

Optimization, SIAM Journal on Scientific and

Statistical Computing, 16, 5, pp. 1190–1208.

C. Schuldt, I. Laptev, and B. Caputo, (2004.). Recognizing

human actions: A local svm approach. In ICPR, pages

32–36.

ICPRAM2013-InternationalConferenceonPatternRecognitionApplicationsandMethods

572
