Small Vocabulary with Saliency Matching for Video Copy Detection

Huamin Ren

, Thomas B. Moeslund

, Sheng Tang

and Heri Ramampiaro

Visual Analysis of People Lab, Aalborg University, Aalborg, Denmark

Institute of Computing Technology, Chinese Academy of Sciences, Beijing, China

Department of Computer and Information Science, Norwegian University of Science and Technology, Trondheim, Norway

Keywords:

Visual Codebook, Bag of Words, Saliency Matching, Copy Detection.

Abstract:

The importance of copy detection has led to a substantial amount of research in recent years, among which

Bag of visual Words (BoW) plays an important role due to its ability to effectively handling occlusion and

some minor transformations. One crucial issue in BoW approaches is the size of vocabulary. BoW descriptors

under a small vocabulary can be both robust and efﬁcient, while keeping high recall rate compared with

large vocabulary. However, the high false positives exists in small vocabulary also limits its application. To

address this problem in small vocabulary, we propose a novel matching algorithm based on salient visual words

selection. More speciﬁcally, the variation of visual words across a given video are represented as trajectories

and those containing locally asymptotically stable points are selected as salient visual words. Then we attempt

to measure the similarity of two videos through saliency matching merely based on the selected salient visual

words to remove false positives. Our experiments show that a small codebook with saliency matching is quite

competitive in video copy detection. With the incorporation of the proposed saliency matching, the precision

can be improved by 30% on average compared with the state-of-the-art technique. Moreover, our proposed

method is capable of detecting severe transformations, e.g. picture in picture and post production.

1 INTRODUCTION

The rapid development of the Internet technology and

the dramatic increase of the available network band-

width have led to large quantity of videos and images

being uploaded to websites. Despite of the conve-

nience, it also brings a new challenge to detect unau-

thorized copies and further employ control policy to

protect legal copyright. Copy detection has been seen

as a key technique to solve this problem.

Various approaches based on different features

have been proposed for video copy detection (Law-

To et al., 2007) (Kim and Vasudev, 2005) (Gengembre

and Berrani, 2008) (Poullot et al., 2010) (Douze et al.,

2010). One of the most promising features is based

BoW feature, which is effective in handling occlusion

and some minor transformations, and can easily be

scaled to large datasets. The key idea behind BoW

representation is to quantize the high dimensional im-

age features to a manageable vocabulary size of vi-

sual words, which is also called codebook. This is

typically achieved by grouping the low-level features

collected from frames into a speciﬁed number of clus-

ters using an unsupervised algorithm such as k-means

clustering. By treating the center of each cluster as

a visual word in the codebook, each extracted feature

can be mapped into its closest visual word. Thus a

histogram over the codebook is generated as a rep-

resentation of a frame and a further retrieval scheme

based on bin-to-bin matching of their histograms are

used for ﬁnding similar or copy images.

Despite of the promising progress, there are still

many critical problems in Bow -based approaches that

need to be addressed, one of which is the size of the

vocabulary (or the size of the codebook). The size of

the vocabulary applied in BoW approaches has an im-

portant impact on the retrieval performance. A gen-

eral observation is that more visual words will result

in better performance (Liu et al., 2008) (Nist

er and

Stew

enius, 2006) owing to a better partitioned fea-

ture space. However, large vocabulary also has two

other negative effects: large storage and computation

resource requirement as well as low recall risk (Nist

and Stew

enius, 2006). In contrast, a small vocabulary

has many signiﬁcant merits, e.g. efﬁcient in feature

assignment, more compact storage requirement for

BoW descriptors and easier to scale up. Even though

a small vocabulary has many advantages, it also con-

tains other negative aspects: lacking discrimination

due to the tendency of more conﬂicts among differ-

768

Ren H., Moeslund T., Tang S. and Ramampiaro H..

Small Vocabulary with Saliency Matching for Video Copy Detection.

DOI: 10.5220/0004280207680773

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 768-773

ISBN: 978-989-8565-47-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

ent features into the same cluster, which will bring

high false positive rates and degrade its performance

in video copy detection.

To obtain robust, yet discriminative features, and

degrade high false positives in retrieval results, we

propose a salient BoW feature representation and fur-

ther a matching scheme to trackle the problems ex-

ists in small vocabulary. To be speciﬁc, we adopt In-

cremental Clustering algorithm in (Ren et al., 2012)

for codebook construction because of its robustness

in partitioning original features and transformed fea-

tures. Further, we propose a visual words selection

algorithm, during which only salient visual words are

selected and kept for later descriptors. Finally, we

provide a matching scheme to measure BoW features,

by only calculating the similarity among salient visual

words.

2 RELATED WORK IN BOW

FEATURE REPRESENTATION

The performance of BoW feature for copy detection

is highly dependent on codebook being built and the

process of quantization. Thus, we give a brieﬂy intro-

duction of the related work in these two topics.

Usually the codebook is built through vector quan-

tization based on k-means clustering. However, as

discussed in (Nist

er and Stew

enius, 2006) the size

of visual codebook should normally be very large to

attain a reasonable retrieval performance Some re-

searchers have started to improve the quality of code-

book by visual words selection, e.g. (Mallapragada

et al., 2010) (Wang, 2007) (Zhang et al., 2010). In

(Mallapragada et al., 2010), the author select a sub-

set of visual words, using a set of images, which is

deﬁned with related or unrelated link constraints. In

(Wang, 2007) the authors present a boosting feature

selection approach to select the most discriminative

visual words from a multi-resolution codebook. How-

ever, these algorithms are supervised methods, which

largely limit their scalability in a variety of applica-

tions. Thus in (Mallapragada et al., 2010), the authors

propose a DCS algorithm, which model the relation-

ship between the data matrix and the indicator matrix

using a linear function and select visual words that led

to minimal ﬁtting error as discriminative ones. Other

researchers have tried to introduce auxiliary informa-

tion to reduce the effect of quantization. In (Philbin

et al., 2007), the authors exploit spatial information

by using the feature layout to verify the consistency of

the retrieved images with the query region; In (Philbin

et al., 2008) (Jiang et al., 2010), the authors adopt soft

assignment, which assign a feature into several nearby

visual words, to bring more possible similar features

into consideration.

Feature assignment is quite time-consuming espe-

cially when a large vocabulary is adopted. Therefore,

some tree structures have been proposed to speed up

the assignment process. The vocabulary tree (Nist

and Stew

enius, 2006) proposes a hierarchical quan-

tization, by decomposing the large-scale clustering

problem into smaller-scale clustering. Nonetheless,

vocabulary tree suers from performance degradation.

Approximate k-means (AKM) (Philbin et al., 2007)

is proposed to replace the exact search of the clos-

est cluster centers by approximate search to speed up

the assignment. However, it is not guaranteed to con-

verge. Robust Approximate k-means (RAKM) (Li

et al., 2010) is proposed to guarantee convergence

through incorporation of the closest cluster centers in

the previous iterations.

Although the tree structures can speed-up fea-

ture assignment, they also need a large vocabulary to

achieve a good performance. Therefore these struc-

tures still require large storage, which, in turn, lim-

its their scalability. To address these problems, we

adopt the codebook construction algorithm in (Ren

et al., 2012) to build a small vocabulary, and propose a

saliency matching to attain a competitive performance

comparable to large vocabulary.

3 SALIENCY MATCHING

Observed by many researchers, different visual words

have distinct impacts on retrieval performance. Un-

like many approaches which use weighting scheme

to reinforce the effect of visual words extracted from

foreground, we advocate a matching scheme only

considering the coordinate of salient visual words,

which could measure the similarity between BoW de-

scriptors better. Since salient visual words are only

a subset of codebook, the computation cost can be

greatly saved. At the same time, frames which do

not contain any salient visual words are considered

as noisy frames and are ﬁltered out to improve the

retrieval performance. Salient visual words selection

from the codebook and saliency matching between

two videos are introduced respectively in the follow-

ing sections.

3.1 Salient Visual Words Selection

Video Q is denoted as a series of frames:

Q[1], Q[2], ..., Q[M], each of which is represented as

a BoW descriptor b

, M is the number of frames in

SmallVocabularywithSaliencyMatchingforVideoCopyDetection

769

Q. Let b

[w] be the w

coordinate of the BoW de-

scriptor in the i

frame.

From observation, we could ﬁnd out there are

some regular patterns exist in the variation of b

[w].

We ﬁrst select a reference video and its copy video

(with the same duration), then trace the variation of

BoW coordinates of different visual words across the

video. Six representative visual words are selected,

their variations in reference video and copy video are

marked as point and cross marks in Figure 1. X axis

represents the frame order, y axis represents the BoW

coordinates of current visual word in the video. As

can be found, the two variation curves tend to have a

similar trend: When BoW coordinate of the reference

video approaches a peak, the corresponding BoW co-

ordinate in the copy video is also very high, proba-

bly also achieves a peak. However, this consistency

pattern doesn’t exist between two different videos, as

seen in Figure 2. Based on this observation, the key

issue is to detect these representative visual words and

then ﬁnd out a proper measurement to calculate the

similarity between two videos by tracing their curves.

Figure 1: Comparison of BoW coordinate between copy

video and its reference video.

To obtain this goal, we denote the curve in a tra-

jectory form and then formulate the problem by trac-

ing saliency points in the curve. By tracing b

[w]

across time, the variation of the w

visual word in the

video Q can be represented as a trajectory: tra j

[w],...,b

[w]}. Hence a video could have at most

K trajectories, where K is the size of the codebook.

Unlike general trajectories, which trace matched key

points among adjacent frames, our trajectory is built

to ﬁnd out Salient Visual Words in which certain

”salient” visual content appear locally and continu-

ously.

Considering the variation of one visual word in the

Figure 2: Comparison of BoW coordinate between two dif-

ferent videos.

video, its trajectory has a locally asymptotic tendency

.This phenomenon is due to the fact that the same vi-

sual word representing a speciﬁc kind of visual con-

tent which appeared in former frames, will contin-

uously appear in the later frames. The coordinate

may change under some transformations such as crop

or shift. However, within a local time window, the

neighborhood should have an asymptotic tendency to-

wards one critical point. Normally this could not be

a global tendency because through time some visual

content may appear or disappear. Considering this lo-

cal tendency, we could make an analogy of the varia-

tion of the coordinates as a dynamic system in which

each point (the coordinate) changes similarly to the

state in the dynamic system.

According to the manifestation of the trajectory,

we deﬁne salient visual words as those whose trajec-

tory across the video can be represented by a serie

of locally asymptotically stable points, which are de-

ﬁned in deﬁnition 1.

Deﬁnition 1. Suppose a trajectory is represented

as {x(t

), x(t

)...}. A point x

∗

is locally asymptoti-

cally stable at t = t

∗

if it satisﬁes:

• x

∗

is stable and;

• x

∗

is locally attractive, e.g. there exists δ such that:

kt −t

∗

k < δ ⇒ lim

t→t

∗

x(t) = x(t

∗

) (1)

In other words, the point x

∗

is locally asymptoti-

cally stable if x

∗

is locally stable and, furthermore, all

solutions starting near x

∗

tend towards x

∗

as t → t

∗

Then, we provide a practical method to ﬁnd out

these possible locally asymptotically stable points in

trajectories. A stable point must be a maximum or

minimum point, so the main problem is how to ﬁnd

stable points that all the nearby points tend to enclose.

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

770

According to the second method of Lyapunov and

Lyapunovs stability theory, the original system is lo-

cally asymptotically stable if we can ﬁnd a Lyapunov-

candidate-function, which satisﬁes: 1) that the func-

tion is locally positive deﬁne and 2) time derivation

of the function is locally negative semideﬁnite. Dif-

ferent from the goals in dynamic system, we aim to

ﬁnd out such locally asymptotically stable points as-

suming that the trajectory is locally asymptotically

stable. Thus, we construct a candidate function and

in reverse to ﬁnd the points which is positive in ﬁrst

derivation and negative in second derivation. Actu-

ally this assumption is reasonable, because the points

in the trajectory may have a ﬂuctuation due to noise or

transformations, but from a local view all the points in

the neighborhood should have a tendency to a speciﬁc

point. Naturally, we propose to use gradient func-

tion as a candidate function, which is approximated

by ﬁrst differential of BoW coordinate, due to that

it can reﬂect the major ﬂuctuations existing in visual

content. After ﬁnding the extreme points of the gra-

dient function, we approximate the time derivation of

the gradient function by calculating, δ

, by using sec-

ond differential of BoW descriptors:

= |b

i+1

[w] +b

i−1

[w] −2 ∗ b

[w]| (2)

Finally, we draw trajectories of salient and non-

salient visual word individually in Figure 3 and 4.

We select 5 videos including original video, two copy

videos (by reencoding and quality degrade) and two

non-reference videos. The curves for salient visual

word in copy videos tend to have a high consistency

with the original video, and are distinguishable from

non-reference videos, while this tendency doesn’t ex-

ist in non-salient trajectories. This implies that the

matching of BoW descriptors on salient coordinates

can provide a better solution for measuring the simi-

larity between video and its copies.

3.2 Matching Scheme

Noisy frames are ﬁltered out after salient visual words

selection. For each left frame in the query video, we

search for L nearest neighbors in the database to get

matched pairs of frames, by computing the cosine dis-

tance of BoW descriptors. Note that only the coordi-

nate of salient visual words are taken into calculation.

This is because salient visual words tend to represent

particular and discriminative visual content that ap-

pears or disappears through time, while non-salient

visual words possibly represent background informa-

tion or noise. Therefore, incorporating non-salient vi-

sual words will degrade the discriminative power and

affect the reliability of similarity. A division of ac-

Figure 3: Salient visual word trajectories.

Figure 4: Non-salient visual word trajectories.

cumulated scores of matched frames by the number

of matched frames, is used to measure the similarity

between two videos.

4 EXPERIMENTS

To verify the effectiveness of our saliency matching in

copy detection, we compare our approach with state-

of-the-art technique using a subset of TRECVID 2009

Copy Detection Dataset. There are 7 types of trans-

formations in the dataset, including picture in picture,

insertion of patterns, strong reencoding, change of

Gamma, decrease in quality, post production and etc.

Some of the representative transformations are shown

in Figure 5, orignial images are on the left, their copy

images under different transformations are shown on

the right. To validate the performance under different

transformations, we select two representative queries

from each type. Accordingly, their reference videos

are selected to form a video dataset - consisting 12

reference videos, each of which is about 30 minutes

long on average.

We compare our saliency matching with the ap-

proaches proposed in (Jegou et al., 2008): HE +WGC,

which is one of the state-of-the-art techniques in copy

detection. We use HE + WGC to get matched pairs

of frames by searching L nearest frames, accumulate

the scores explained in Section 3.2 and calculate pre-

cision and recall to evaluate the performance of copy

detection.

We ﬁrst conduct experiments on our saliency

SmallVocabularywithSaliencyMatchingforVideoCopyDetection

771

Table 1: Comparison experiments between TF-IDF based BoW matching and saliency matching.

TF-IDF based BoW matching Saliency matching

Precision Recall F Score Precision Recall F Score

0.100 0.071 0.083 0.250 0.143 0.181

0.174 0.286 0.216 0.143 0.286 0.190

0.125 0.286 0.173 0.152 0.357 0.212

0.160 0.500 0.242 0.170 0.571 0.262

0.110 0.500 0.180 0.131 0.571 0.213

0.100 0.063 0.104 0.5 0.642 0.571

0.086 0.076 0.108 0.5 0.857 0.571

Table 2: Comparison experiments for copy detection.

Precision Recall

WGC+HE WGC+HE SVW WGC+HE WGC+HE SVW

K=65 K=20k K=65 K=65 K=20k K=65

0.100 0.042 0.250 0.071 0.285 0.143

0.174 0.04 0.143 0.286 0.285 0.286

0.125 0.04 0.152 0.286 0.285 0.357

0.160 0.038 0.170 0.5 0.285 0.571

0.110 0.045 0.131 0.5 0.357 0.571

0.100 0.063 0.104 0.5 0.642 0.571

0.086 0.076 0.108 0.5 0.857 0.571

T2: Picture in picture T3: Insertions of pattern

T4: Reencoding T5: Change of Gamma

T6: Decrease in quality

Figure 5: Representative original images and copy images

in TRECVID2009.

matching to get a good parameter of L. L determines

the number of the matched frames. True positives

may be missed under a small L, thereafter the recall

is usually increased when enlarging the parameter L.

However, with the increasing of L, the number of false

negatives are also increased accordingly which leads

to a low precision and longer processing time because

of more nearest neighbours being searched. For ex-

ample, when L = 4 the precision and recall are 0.17

and 0.57, respectively. However, when L = 40, they

are 0.09, 0.643. With respect to execution time, after

running 14 queries we found out that a query process-

ing with L = 4 only needs 45.14s on average, while

the processing time for L = 40 is 74.64s – i.e., 1.65

times longer. To get a balance between accuracy and

time cost, we compute the precision and recall values

by varying the values of L from 4 to 2000 and ﬁnally

choose L=4.

Then, we compare saliency matching with and

without frame ﬁltering. During frame ﬁltering, only

discriminative frames are used to ﬁnd L nearest neigh-

bors to form matched pairs of frames. Discriminative

frames turn out to be more contributive in copy de-

tection, obtaining a precision and recall of 0.17 and

0.57 respectively, compared to 0.15 and 0.5 without

frame ﬁltering. The main reason is that false matched

frames can be reduced and thus a higher precision is

achieved.

Next, we compare our methods with TF-IDF

weighting, which is a commonly used weighting

scheme in BoW-based methods. To wipe off the im-

pact of other factors, we use TF-IDF and saliency

matching seperately to get matched frames, then we

adopt matching scheme to compute the similarity of

two videos. Determing whether a query video is a

copy or not depends on threshold ﬁltering of similar-

ity score. By adjusting thresholds, comparative re-

sults can be seen in Table 1. As can be seen, our

methods outperform TF-IDF weighting.

At last, the comparative copy detection perfor-

mance between our methods and HE+WGC in terms

of precision and recall is summarized in Table 2. We

change the value of threshold that determines similar-

ity between two videos, and compare the performance

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

772

of the approach in (Jegou et al., 2008) using small

and large vocabulary with our saliency matching us-

ing the same small vocabulary. As can be seen, our

saliency matching using small vocabulary, not only

outperforms HE + WGC using the same small vocab-

ulary both in precision and recall, by 30% and 26% re-

spectively on average, but also surpasses HE + WGC

using large vocabulary by 240% and 13% respectively

on average.

Our proposed approach performs signiﬁcantly

well in detecting some severe transformations, e.g.

picture in picture and text insertion, in which new vi-

sual content appears continuously in a local time win-

dow In such cases, salient visual words can capture

these discriminative visual information. However, it

is not so promising in gamma transformation. Our

conjecture is that saliency matching may not have ob-

vious advantage in videos with insufﬁcient salient vi-

sual words.

5 CONCLUSIONS

In this paper, we propose a salient visual words selec-

tion algorithm and saliency matching to measure the

similarity between two videos. Due to the high con-

sistency in salient coordinate of BoW descriptors, the

number of mismatches will be reduced and the perfor-

mance of BoW - based approaches with small vocab-

ulary in copy detection can be improved by saliency

matching.

Our experiments have shown that our proposed

method performs well in copy detection, especially

in transformations that visual content has signiﬁcant

changes along time. Despite the good performance in

some sever transformations, e.g. picture in picture,

post production and some combination of transfor-

mations, our methods do not perform well in gamma

transformation, even when enlarging the number of

matching frames. This is partly due to the insufﬁ-

cience of visual words, partly due to a loss of infor-

mation during quantization in BoW features, which

could be our future research directions.

REFERENCES

Douze, M., J

egou, H., Schmid, C., and P

erez, P. (2010).

Compact video description for copy detection with

precise temporal alignment. In Proceedings of the

11th European conference on Computer vision: Part

I, ECCV’10. Springer-Verlag.

Gengembre, N. and Berrani, S. (2008). A probabilistic

framework for fusing frame-based searches within a

video copy detection system. In Proceedings of the

2008 international conference on Content-based im-

age and video retrieval. ACM.

Jegou, H., Douze, M., and Schmid, C. (2008). Ham-

ming embedding and weak geometric consistency for

large scale image search. In Proceedings of the 10th

European Conference on Computer Vision: Part I.

Springer-Verlag.

Jiang, Y., J. Yang, C. N., and Hauptmann, A. (2010). Repre-

sentations of keypoint-based semantic concept detec-

tion: A comprehensive study. IEEE Transactions on

Multimedia, 12.

Kim, C. and Vasudev, B. (2005). Spatiotemporal sequence

matching for efﬁcient video copy detection. IEEE

Trans. Circuits Syst. Video Techn.

Law-To, J., Chen, L., Joly, A., Laptev, I., Buisson, O.,

Gouet-Brunet, V., Boujemaa, N., and Stentiford, F.

(2007). Video copy detection: a comparative study.

In CIVR. ACM.

Li, D., Yang, L., Hua, X., and Zhang, H. (2010). Large-

scale robust visual codebook construction. In Pro-

ceedings of the international conference on Multime-

dia. ACM.

Liu, D., Hua, G., Paul, A., and Tsuhan, C. (2008). Inte-

grated feature selection and higher-order spatial fea-

ture extraction for object categorization. In CVPR.

IEEE Computer Society.

Mallapragada, P., Jin, R., and Jain, A. (2010). Online vi-

sual vocabulary pruning using pairwise constraints. In

CVPR’10. IEEE Computer Society.

Nist

er, D. and Stew

enius, H. (2006). Scalable recognition

with a vocabulary tree. In CVPR (2). IEEE Computer

Society.

Philbin, J., Chum, O., Isard, M., Sivic, J., and Zisserman, A.

(2007). Object retrieval with large vocabularies and

fast spatial matching. In CVPR. IEEE Computer So-

ciety.

Philbin, J., Isard, M., Sivic, J., and Zisserman, A. (2008).

Lost in quantization: Improving particular object re-

trieval in large scale image databases. In In CVPR.

Poullot, S., Buisson, O., and Crucianu, M. (2010). Scal-

ing content-based video copy detection to very large

databases. Multimedia Tools Appl.

Ren, H., Ramampiaro, H., Zhang, Y., and Lin, S. (2012).

An incremental clustering based codebook construc-

tion in video copy detection. In 2012 IEEE South-

west Symposium on Image Analysis and Interpreta-

tion. IEEE.

Wang, L. (2007). Toward a discriminative codebook: Code-

word selection across multi-resolution. In CVPR.

IEEE Computer Society.

Zhang, L., Chen, C., Bu, J., Chen, Z., Tan, S., and He, X.

(2010). Discriminative codeword selection for image

representation. In ACM Multimedia. ACM.

SmallVocabularywithSaliencyMatchingforVideoCopyDetection

773
